CAL. 7T92 & YM92
CHRONOGRAPH
TIME/CALENDAR
● Hour, minute and small second hands
● Date displayed in numerals
STOPWATCH
● Measures up to 12 hours in 1/20 second increments.
● Split time measurement
ENGLISH
6
1/20-second hand
Hour hand
Small second
English
STOPWATCH hour hand
2
a: Normal position
DISPLAY AND CROWN/BUTTONS
STOPWATCH
hand
Minute hand
A
a b c
CROWN
Date
B
STOPWATCH
second hand
STOPWATCH minute hand
c: Second clickb: First click
SCREW DOWN CROWN
[for models with screw down crown]
Unlocking the crown
1 Turn Crown counterclockwise until you no
longer feel the threads turning.
2 Crown can be pulled out.
Locking the crown
1 Push Crown back in to normal position.
2 Turn Crown clockwise while pressing it lightly
until tight.
English
3
SETTING THE TIME AND
ADJUSTING THE STOPWATCH HAND POSITION
● This watch is so designed that:
1) time setting and
2) stopwatch hand position adjustment
are both made with the crown at the second click position. Once the crown is
pulled out to the second click, be sure to make the above adjustments at the same
time.
English
4
CROWN
Pull out to second click when the second hand is at the 12
o’clock position.
1) TIME SETTING
Hour hand Minute hand
6
CROWN
Small second hand
* It is recommended that the hands be set to the time a few minutes ahead of the
current time, taking into consideration the time required to adjust the STOPWATCH
hand position if necessary.
Turn to set the hour
and minute hands.
2) STOPWATCH HAND POSITION ADJUSTMENT
● If the STOPWATCH hands are not in the “0” position, follow the procedure below
to set them to the “0” position.
English
5
STOPWATCH
second hand
STOPWATCH
1/20-second hand
A
6
English
6
STOPWATCH
hour hand
Press for 2 seconds to select the STOPWATCH hand(s) to be
A
adjusted.
▲
● Selection of the hand(s) to be adjusted can be made in the
following order by pressing button A for 2 seconds.
STOPWATCH
1/20-second hand
▲
* The selected hand(s) turn(s) a full circle.
▲
▲
B
STOPWATCH
second hand
STOPWATCH
minute hand
▲
STOPWATCH
hour and minute
hands
▲
▲
Press repeatedly to set the selected STOPWATCH hand(s) to the
B
“0” position.
* The hand(s) move(s) quickly if button B is kept pressed.
* After all the adjustments are completed, check that the hour and minute
hands for time display indicate the current time.
▲
CROWN
Push back in to normal position in accordance with a time
signal.
English
7
SETTING THE DATE
● Before setting the date, be sure to set the time.
➠
6
➠
English
Date
8
CROWN
1 Pull out to first click.
2 Turn clockwise until the desired
date appears.
3 Push back in to normal position.
STOPWATCH
● The stopwatch can measure up to 12 hours in 1/20-second increments.
● When the measurement reaches 12 hours, the stopwatch automatically stops
counting.
STOPWATCH
1/20-second hand
STOPWATCH minute hand
STOPWATCH
second hand
Start / Stop / Restart
A
B Reset /
Split /Split release
STOPWATCH hour hand
English
Ex.: 2 hours, 30 minutes and 10.85 seconds
9
Movement of the STOPWATCH 1/20-second hand
● After the stopwatch is started, the STOPWATCH 1/20-second hand moves for
about 10 minutes and automatically stops at the “0” position.
● When the measurement is stopped or split time is measured, it moves to
indicate the elapsed 1/20 seconds.
● After the stopwatch is restarted or split time is released, the STOPWATCH 1/
20-second hand moves for about 10 minutes and stops automatically.
● In the same manner, if the stopwatch is stopped and restarted repeatedly or
split time is measured and released repeatedly, the STOPWATCH 1/20second hand moves for about 10 minutes and stops automatically.
English
● Before using the stopwatch, be sure to check that the crown is set at the normal
position and that the STOPWATCH hands are reset to the “0” position.
* If the STOPWATCH hands do not return to the “0” position when the stopwatch
is reset to “0”, follow the procedure in “SETTING THE TIME AND ADJUSTING
THE STOPWATCH HAND POSITION”.
10
Split time measurement
Measurement of two competitors
A
START
A
START
▲
▲
COMPETITOR
B
SPLIT
B
FINISH TIME
OF 1ST
▲
SPLIT
RELEASE
▲
B
A
2ND
COMPETITOR
FINISHES
▲
▲
▲
A
STOP
B
FINISH TIME
OF 1ST
COMPETITOR
B
RESET
▲
B
RESET
English
11
TACHYMETER
[for models with tachymeter scale on the dial]
To measure the hourly average speed of a vehicle
[ Ex. 1 ]
STOPWATCH
second hand:
40 seconds
English
Tachymeter
scale: “90”
“90” (tachymeter scale figure) x
1 (km or mile) = 90 km/h or mph
Tachymeter scale can be used only when the time required is less than 60 seconds.
Ex. 2: If the measuring distance is extended to 2 km or miles or shortened to
0.5 km or miles and STOPWATCH second hand indicates “90” on
12
tachymeter scale:
1 Use the stopwatch to determine how
many seconds it takes to go 1 km or
1 mile.
▲
2 Tachymeter scale indicated by
STOPWATCH second hand gives
the average speed per hour.
“90” (tachymeter scale figure) x 2 (km or mile) = 180 km/h or mph
“90” (tachymeter scale figure) x 0.5 (km or mile) = 45 km/h or mph
To measure the hourly rate of operation
[ Ex. 1 ]
“180” (tachymeter scale figure) x
1 job = 180 jobs/hour
Ex. 2: If 15 jobs are completed in 20 seconds:
“180” (tachymeter scale figure) x 15 jobs = 2700 jobs/hour
STOPWATCH
second hand:
20 seconds
Tachymeter
scale: “180”
1 Use the stopwatch to measure the
time required to complete 1 job.
▲
2 Tachymeter scale indicated by
STOPWATCH second hand gives
the average number of jobs
accomplished per hour.
English
13
NOTES ON OPERATING THE WATCH
SETTING THE TIME AND ADJUSTING THE STOPWATCH HAND POSITION
● When the stopwatch is or has been measuring or is stopped, if the crown is pulled out
to the second click, it will automatically reset the STOPWATCH hands to “0”.
[TIME SETTING]
● When setting the hour hand, be sure to check that AM/PM is correctly set. The watch
is so designed that the date changes once in 24 hours.
● When setting the minute hand, first advance it 4 to 5 minutes ahead of the desired time
and then turn it back to the exact minute.
English
SETTING THE DATE
● It is necessary to adjust the date at the end of February and 30-day months.
● Do not set the date between 9:00 p.m. and 1:00 a.m. Otherwise, the date may not
change properly.
STOPWATCH
● Restart and stop of the stopwatch can be repeated by pressing button A.
● Measurement and release of split time can be repeated by pressing button B.
14
BATTERY CHANGE
Battery life : Approx. 3 years
3
Years
●
If the stopwatch is used for more than 2 hours a day, the battery life may be less than
the specified period.
●
As the battery is inserted at the factory to check the function and performance of the
watch, its actual life once in your possession may be less than the specified period.
●
When the battery expires, be sure to replace it as soon as possible to prevent any
malfunction.
●
We recommend that you contact an AUTHORIZED PULSAR DEALER for battery
replacement.
●
After the battery is replaced with a new one, set the time/calendar and adjust the
stopwatch hand position.
● Battery life indicator
When the battery nears its end, the small second hand moves at two-second intervals
instead of normal one-second intervals. In that case, have the battery replaced with a
new one as soon as possible.
Battery : SEIKO SR927SW
English
15
* The watch remains accurate while the small second hand is moving at two-second
intervals.
WARNING
● Do not remove the battery from the watch.
● If it is necessary to take out the battery, keep it out of the reach of
children. If a child swallows it, consult a doctor immediately.
● Never short-circuit, tamper with or heat the battery, and never expose
it to fire. The battery may burst, become very hot or catch fire.
English
CAUTION
● The battery is not rechargeable. Never attempt to recharge it, as this
may cause battery leakage or damage to the battery.
16
TO PRESERVE THE QUALITY OF YOUR WATCH
WATER RESISTANCE
● Non-water resistant
wet as water may damage the movement. If
the watch becomes wet, we suggest that you
have it checked by an AUTHORIZED PULSAR
DEALER or SERVICE CENTER.
● Water resistance (3 bar)
dental contact with splashes of water or rain, but it is
not designed for swimming or diving.
If “WATER RESISTANT” is not
inscribed on the case back, your
watch is not water resistant, and
care should be taken not to get it
If “WATER RESISTANT” is inscribed
on the case back, your watch is
designed and manufactured to
withstand up to 3 bar, such as acci-
● Water resistance (5 bar)*
5
bar WR
and is suitable for swimming, yachting and taking
a shower.
●
Water resistance (10 bar/15 bar/20 bar)*
10/15/20
bar WR
your watch is designed and manufactured to
withstand up to 10 bar/15 bar/20 bar and is
suitable for taking a bath, shallow diving, but not
for scuba diving. We recommend that you wear a
PULSAR Diver’s watch for scuba diving.
If “WATER RESISTANT 5 BAR”
is inscribed on the case back, your
watch is designed and manufactured to withstand up to 5 bar
English
If “WATER RESISTANT 10 BAR”,
“WATER RESISTANT 15 BAR”
or “WATER RESISTANT 20 BAR”
is inscribed on the case back,
17
* Before using the water resistance 5, 10, 15 or 20 bar watch in water, be sure the
crown is pushed in completely.
Do not operate the crown when the watch is wet or in water. If used in sea water,
rinse the watch in fresh water and dry it completely.
* When taking a shower with the water resistance 5 bar watch, or taking a bath with
the water resistance 10, 15 or 20 bar watch, be sure to observe the following:
• Do not operate the crown when the watch is wet with soapy water or shampoo.
• If the watch is left in warm water, a slight time loss or gain may be caused. This
condition, however, will be corrected when the watch returns to normal
temperature.
NOTE:
Pressure in bar is a test pressure and should not be considered as corresponding
to actual diving depth since swimming movement tends to increase the
English
pressure at a given depth. Care should also be taken on diving into water.
TEMPERATURES
Your watch works with stable
+50°C
accuracy within a temperature
range of 5° C and 35° C (41°
-5°C
F and 95° F).
(122° F) may cause battery leakage or
18
Temperatures over 50° C
shorten the battery life. Do not leave
your watch in very low temperatures
below –5° C (+23° F) for a long time
since the cold may cause a slight time
loss or gain.
However, the above conditions will be
corrected when the watch returns to
normal temperature.
CARE OF CASE AND BRACELET
To prevent possible rusting
of the case and bracelet
caused by dust, moisture and
perspiration, wipe them
periodically with a soft dry
cloth.
SHOCKS & VIBRATION
Light activities will not affect
your watch, but be careful not
to drop your watch or hit it
against hard surfaces, as this
may cause damage.
CHEMICALS
Be careful not to expose the
watch to solvents, mercury,
cosmetic spray, detergents,
adhesives or paints.
Otherwise, the case,
discolored, deteriorated or damaged.
bracelet, etc. may become
MAGNETISM
Your watch will be adversely
affected by strong magnetism.
Keep it away from close
contact with magnetic objects.
S
N
PERIODIC CHECK
It is recommended that the
2 - 3
Years
DEALER or SERVICE CENTER to ensure
that the case, crown, buttons, gasket and
crystal seal remain intact.
PRECAUTION REGARDING
CASE BACK PROTECTIVE FILM
watch be checked once every
2 to 3 years. Have your
watch checked by an
AUTHORIZED PULSAR
If your watch has a protective
film and/or a sticker on the
case back, be sure to peel
them off before using your
watch.
English
19
English
20
Loading...
