Thank you for purchasing the Pulsar™ Triad! It has everything you
need to vaporize waxes, herbs, and e-liquids. In order to ensure
safe use, please read all instructions and safety warnings before
operating your Pulsar™ Triad. Failure to follow instructions may
result in injury and may void your warranty.
This Kit Includes:
Charging Instructions
You will need to charge your Triad before using it. Screw the
charger cable onto the top of the Triad battery, then to a
dedicated USB port. A red light on the charger will glow red while
charging. Total charge time is approximately 1-2 hours. The red
light will turn green once fully charged. The Triad battery will deliver
approximately 1-2 hours of continuous power, depending on use.
Batery light will blink repeatedly once battery is depleted and
charging is needed. Both the battery and charger are designed to
prevent overcharging. ONLY USE APPROVED PULSAR™ CHARGERS!
Failure to do so can damage the battery, which can result in
property damage or personal injury.
Using The Wax Atomizer
Remove the cover then, using the vape tool provided, load a
small dab of wax or concentrate into the heating chamber, being
careful to avoid touching or damaging the heating element with
the vape tool. Replace the cover, and you’re ready to vape!
Battery Vape Tool
1 2
USB Charger
Liquid
Atomizer
Herb
Atomizer
Wax
Atomizer
Using The Herb Atomizer
Remove the cover then and unscrew the cap. Use the vape tool
provided to pack a small amount of finely ground herbs into the
heating chamber, being careful to avoid touching or damaging
the heating element with the vape tool. Replace the cap and
cover, and you’re ready to vape! Note: herb atomizer works best
with finely ground and slightly dried herbs. It may be necessary to
stir herbs occasionally to ensure even heat distribution.
Using The Liquid Atomizer
Remove the mouthpiece, hold the cartridge at a 45° angle, and
begin filling with e-liquid, using a needle tip bottle or syringe. DO
NOT pour liquid directly into center chamber. DO NOT fill liquid
above MAX line. Failure to follow these directions may result in
leakage, property damage, or personal injury.
3-Click Locking System
Pulsar™ Triad comes equipped with a locking mechanism that
prevents it from turning on accidentally. To arm or disarm the lock,
push the button three times within two seconds. The battery will blink
when armed/disarmed. Always arm the lock when not in use.
Auto-Shutoff Timer
To avoid waste and overheating, Pulsar™ Triad is equipped with a
15 second auto-shutoff timer. After 15 seconds of use, the battery
will blink times and turn off. Allow to cool for several seconds
between each use.
Technical Specifications
Battery Capacity: 180mAh
Battery Voltage: 3.7-4.2v
Wax Atomizer Resistance: 2.4-2.8W
Herb Atomizer Resistance: 2.4-2.8W
Liquid Atomizer Resistance: 2.4-2.8W
3 4
5
Important Safety Warnings
Only charge using Pulsar™ brand chargers.
Do not expose to extreme temperature or direct sunlight.
Do not drop the battery or atomizers.
Do not drop or submerge in any liquid.
Do not modify the electronics in any way.
Do not touch atomizer heating coils.
Pulsar™ Triad is intended for adults only. Do not sell or provide to
minors. Keep all parts, concentrates, herbs, and liquids away from
children and pets. Pulsar™ Triad is not a medical device and is
not intended to diagnose, treat, mitigate, cure, or prevent any
ailment, disease, or other conditions. Consult a physician before
use, especially if you suffer from heart disease or any other medical
condition, or if you are pregnant or breastfeeding. Failure to follow
any of these instructions could result in product damage, property
damage, or personal injury.
Limited Warranty
The Pulsar™ Triad is guaranteed from manufacturer defects or malfunction
from date of purchase for a period of 6 months. This limited warranty
protects against manufacturer defect under normal use and does not
apply to normal wear & tear; improper use; accidental damage from
dropping or submerging in liquid; improper cleaning; neglect; or any other
damage that is not a result of defective materials or workmanship. If your
Pulsar™ qualifies for servicing, we will repair or replace, at our discretion
and expense, any defective parts or materials. Purchaser must provide a
copy of the original dated sales receipt and may be required to provide
shipping to return defective parts or materials. We intend to complete all
repairs/replacements within 7 business days, although this timeframe may
vary depending on shipping, replacement part availability, or other related
factors. The lawful and proper use of this device is a condition of sale. Any
improper use of the Pulsar™ Triad will void the warranty. Warranty is nontransferable. This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
Important Note: All atomizers are disposable attachments. Once an
atomizer is used, no warranty coverage or replacement will be offered.
For warranty servicing, contact us at:
www.PulsarVapes.com
