Pulsar EDGE G2+ 1x21 Instruction Manual
W W W . P U L S A R - N V . C O M
SPECIFICATIONS
75095
75091
Type of image intensifier tube
CF-Super/ EP33-SF-U 2+ / EPM207G
Magnification, x
1
1
Objective lens, mm
20
21
Resolution in the centre FOV, lp/mm, min
36
40
Angular field of view, degree
36
40
Max. detection range, m/yds*
90/98
200/220
Eyepiece adjustment, diopter
±4
±4
Eye relief, mm
12
25
Operating voltage, V
3 (2xAAA)
3 (2xAAA)
Tripod mount, inch
¼
¼
Av. operation time with 2 AAA batteries,
(IR off/on), h
50 / 20
50 / 20
Operating temperature
-20 °C~+40 °C / -4 °F~+104 °F
Dimensions, mm/inch:
Length
163 / 6.4
163 / 6.4
Width
113 / 4.4
113 / 4.4
Height
60 / 2.4
60 / 2.4
Weight of the unit, kg/oz
0.65 / 22.9
0.65 / 22.9
Weight of the head mount, kg/oz
0.2 / 7
0.2 / 7
Edge GS 1x20 / Edge G2+ 1x21
unit
Head mount
Carrying case
User manual
Cleaning cloth
NV Goggles Edge G2+ 1x21
Warranty card
-
90?
+
* Max. detection range of an object measuring 1.7x0.5 m i n natural night conditions (0.05
lux, quarter moon).
PACKAGE CONTENTS
For improvement
purposes, design of
this product is
subject to change.
NV Goggles Edge GS 1x20
+ -
2
3 5 6
7
OPEN
4
1
7
