CAL. 5Y67
RETROGRADE DAY INDICATOR
● Time indicates by the hour, minute and
second hands
● Date indicates by the date hand
● Day of the week indicates by the day
hand
● The 24-hour hand indicates the hour in
the 24-hour indication
ENGLISH
Day hand
(retrograde day
indicator: see page 7)
DISPLAY AND CROWN
Minute hand
Date hand
Hour hand
a b c
English
Second hand
a. Normal position c. Second click
*
2
Orientation of the retrograde display may vary depending on the model.
b. First click
CROWN
24-hour hand
SCREW DOWN CROWN
[for models with screw down crown]
1 Turn Crown counterclockwise until you no
longer feel the threads turning.
2 Crown can be pulled out.
Locking the crown
1 Push Crown back in to normal position.
2 Turn Crown clockwise while pressing it lightly
until tight.
English
3
English
4
Day hand
DAY AND TIME SETTING
CROWN
clockwise
➠
➠
counterclockwise
1 Pull out to second click when Second
hand is at the 12 o’clock position.
2 Turn clockwise to advance Hour
and Minute hands until Day hand
is set to the desired day of the
week.
3 Turn to set the time.
4 Push the crown back into the
normal position in accordance
with a time signal.
DATE SETTING
➠
Date hand
CROWN
1 Pull out to first click.
2 Turn counterclockwise to set Date
hand to the desired date.
3 Push in.
English
5
NOTES ON OPERATING THE WATCH
TIME/DATE SETTING
● To advance the day hand quickly, turn back the hour and minute hands 4 to 5 hours
beyond the point the day changes (between 11:00 p.m. and 4:00 a.m.), and then
advance them again until the day hand is set to the next.
*The day hand will not move back by turning the crown counterclockwise.
● After the day hand reaches the last day of the week, turn the crown clockwise and the
hand will return to the first day of the week (retrograde day indicator).
● When adjusting the day hand, turn the crown slowly.
● The 24-hour hand moves correspondingly with the hour hand.
● When setting the hour hand, check that the 24-hour hand is correctly set.
English
● When setting the minute hand, advance it 4 to 5 minutes ahead of the desired time and
then turn it back to the exact time.
DATE SETTING
● Do not set the date hand between 9:00 p.m. and 1:00 a.m. Otherwise, it may not turn
properly.
● While setting the date hand, check that it moves properly in one-day increments.
● It is necessary to adjust the date on the first day after a 30-day month and February.
6
