Puls CP20.241, CP20.241-C1, CP20.241-S1, CP20.241-S2, CP20.241-V1 Data Sheet

CP20.241, CP20.241-C1, CP20.241-S1,

CP

P

S

Output voltage

Nominal

Adjustment range

24 - 28V

Factory setting 24.1V

Output current

24.0 - 20.6A

Below +45°C ambient

At +60°C ambient

15.0 – 13.0A

At +70°C ambient

Input voltage

Mains frequency

50-60Hz

±6%

Input current

A

Power factor

0.99 / 0.98

At 120 / 230Vac

Input voltage DC

DC 110-150V

±20%

For CP20.241 (-xx)

DC 110-300V

±20%

For CP20.242

Input current DC

4.64A / 1.66A

At 110 / 300Vdc

AC Inrush current

10.0 / 4.5Apk

At 120 / 230Vac

Efficiency

At 120 / 230Vac

Losses

29.6 / 22.1W

At 120 / 230Vac

Hold

At 120 / 230Vac

Temperature range

Size (WxHxD)

48x124x127mm

Without DIN-rail

Weight

O

M

IND. CONT. EQ.

CP20.241-S2, CP20.241-V1, CP20.242

RODUCT DESCRIPTION

The Dimension CP-Series are cost optimized power supplies without compromising quality, reliability and performance. The most outstanding features of the CP20 series are the high efficiency, electronic inrush current limitation, active PFC, wide operational temperature range and the extraordinary small size.

The CP20.241-C1 is equipped with conformal coated pcboards preferred for applications in harsh areas.

The CP20.241-S1 is equipped with quick-connect springclamp terminals preferred for applications which are exposed to mechanical vibration. The CP20.241-S2 has push-in terminals optimized for easy cabinet wiring.

The CP20.241-V1 is equipped with a remote ON/OFF feature and the CP20.242 features an enhanced DC input voltage range.

The devices have a power reserve of 20% included, which may even be used continuously up to +45°C.

High immunity to transients and power surges as well as low electromagnetic emission, a DC-OK relay contact and a large international approval package makes this unit suitable for nearly every situation.

RDER NUMBERS

Power Supply CP20.241

Mechanical Accessory

CP20.241-C1 With conformal coated pc-boards CP20.241-S1 With quick-connect spring-clamp terminals

CP20.241-S2 With push-in terminals CP20.241-V1 With remote ON/OFF

feature CP20.242 Enhanced DC input

ZM5.WALL Wall/Panel mount bracket

-Series

24V, 20A, 480W, SINGLE PHASE

OWER SUPPLY

 AC 100-240V Wide-range Input  Width only 48mm  Efficiency up to 95.6%  Excellent Partial Load Efficiency  20% Output Power Reserves  Easy Fuse Breaking – 3 times nominal current for 12ms  Safe Hiccup  Active Power Factor Correction (PFC)  Minimal Inrush Current Surge  Full Power Between -25°C and +60°C  DC-OK Relay Contact  Current Sharing Feature for Parallel Use  3 Year Warranty

PLUS

Overload Mode

HORT-FORM DATA

-up time 32/ 32ms

DC 24V

20.0 – 17.1A

Derate linearly between +45°C and +70°C

AC AC 100-240V -15%/+10%

AC 4.26 / 2.23A

94.2 / 95.6%

-25°C to +70°C

830g / 1.83lb

t 120 / 230Vac

AIN APPROVALS

For details or a complete approval list see section 20.

IECEx ATEX

Aug. 2019 / Rev. 1.1 DS-CP20.241-EN - All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 20A output load, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.

1/32

CP20.241, CP20.241-C1, CP20.241-S1,

CP

I

TERMINOLOGY AND ABREVIATIONS

CP20.241-S2, CP20.241-V1, CP20.242

-Series

24V, 20A, 480W, SINGLE PHASE

NDEX

Page Page

Intended Use .......................................................3

1.

2. Installation Instructions ......................................3

3. AC-Input...............................................................5

4. DC-Input...............................................................6

5. Input Inrush Current ...........................................7

6. Output .................................................................8

7. Hold-up Time ..................................................... 10

8. DC-OK Relay Contact ........................................ 10

9. Remote ON / OFF Function ............................... 11

10. Efficiency and Power Losses.............................. 12

11. Functional Diagram ........................................... 13

12. Front Side and User Elements ........................... 14

13. Connection Terminals ....................................... 15

14. Lifetime Expectancy .......................................... 16

15. MTBF .................................................................. 16

16. EMC .................................................................... 17

17. Environment ...................................................... 18

18. Safety and Protection Features ........................ 19

19. Dielectric Strength ............................................ 20

20. Approvals ........................................................... 21

The information given in this document is correct to the best of our knowledge and experience at the time of publication. If not expressly agreed otherwise, this information does not represent a warranty in the legal sense of the word. As the state of our knowledge and experience is constantly changing, the information in this data sheet is subject to revision. We therefore kindly ask you to always use the latest issue of this document

21. Other Fulfilled Standards ................................. 21

22. Physical Dimensions and Weight ..................... 22

23. Accessories ........................................................ 23

23.1. ZM5.WALL – Wall/Panel Mount Bracket . 23

23.2. UF20.241 Buffer Module .......................... 24

23.3. YR40.241 - Redundancy Module .............. 24

23.4. YR40.242 - Redundancy Module .............. 24

23.5. YR40.245 - Redundancy Modules ............ 25

24. Application Notes ............................................. 26

24.1. Peak Current Capability ........................... 26

24.2. Output Circuit Breakers ............................ 27

24.3. Charging of Batteries ............................... 28

24.4. Series Operation ....................................... 28

24.5. Parallel Use to Increase Output Power .... 29

24.6. Parallel Use for Redundancy .................... 30

24.7. Operation on Two Phases ........................ 31

24.8. Use in a Tightly Sealed Enclosure ............ 31

24.9. Mounting Orientations ............................ 32

No part of this document may be reproduced or utilized in any form without our prior permission in writing. Packaging and packaging aids can and should always be recycled. The product itself may not be disposed of as

domestic refuse.

PE and symbol PE is the abbreviation for Protective Earth and has the same meaning as the symbol .

Earth, Ground This document uses the term “earth” which is the same as the U.S. term “ground”.

T.b.d. To be defined, value or description will follow later.

AC 230V A figure displayed with the AC or DC before the value represents a nominal voltage with

standard tolerances (usually ±15%) included. E.g.: DC 12V describes a 12V battery disregarding whether it is full (13.7V) or flat (10V)

230Vac A figure with the unit (Vac) at the end is a momentary figure without any additional

tolerances included.

50Hz vs. 60Hz As long as not otherwise stated, AC 230V parameters are valid at 50Hz mains frequency.

may A key word indicating flexibility of choice with no implied preference.

shall A key word indicating a mandatory requirement.

should A key word indicating flexibility of choice with a strongly preferred implementation.

Aug. 2019 / Rev. 1.1 DS-CP20.241-EN - All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 20A output load, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.

2/32

CP20.241, CP20.241-C1, CP20.241-S1,

CP

1. I

2. I

WARNING

CP20.241-S2, CP20.241-V1, CP20.242

-Series

24V, 20A, 480W, SINGLE PHASE

NTENDED USE

This device is designed for installation in an enclosure and is intended for commercial use, such as in industrial control, process control, monitoring and measurement equipment or the like.

Do not use this device in equipment where malfunction may cause severe personal injury or threaten human life.

NSTALLATION INSTRUCTIONS

Risk of electrical shock, fire, personal injury or death

- Turn power off before working on the device. Protect against inadvertent re-powering.

- Do not modify or repair the unit.

- Do not open the unit as high voltages are present inside.

- Use caution to prevent any foreign objects from entering the housing.

- Do not use in wet locations or in areas where moisture or condensation can be expected.

- Do not touch during power-on, and immediately after power-off. Hot surfaces may cause burns.

Obey the following installation instructions: This device may only be installed and put into operation by qualified personnel. This device does not contain serviceable parts. The tripping of an internal fuse is caused by an internal defect. If damage or malfunction should occur during installation or operation, immediately turn power off and send unit to

the factory for inspection. Install the device in an enclosure providing protection against electrical, mechanical and fire hazards. Install the device onto a DIN-rail according to EN 60715 with the input terminals on the bottom of the device. Other

mounting orientations require a reduction in output current. Make sure that the wiring is correct by following all local and national codes. Use appropriate copper cables that are

designed for a minimum operating temperature of 60°C for ambient temperatures up to +45°C, 75°C for ambient temperatures up to +60°C and 90°C for ambient temperatures up to +70°C. Ensure that all strands of a stranded wire enter the terminal connection.

Unused screw terminals should be securely tightened. The device is designed for pollution degree 2 areas in controlled environments. No condensation or frost is allowed. The enclosure of the device provides a degree of protection of IP20. The isolation of the device is designed to withstand impulse voltages of overvoltage category III according to IEC

60664-1. The device is designed as “Class of Protection I” equipment according to IEC 61140. Do not use without a proper PE (Protective Earth) connection. Use the terminal on the input block for earth

connection and not one of the screws on the housing. The device is suitable to be supplied from TN-, TT- and IT mains networks. The voltage between the L or N terminal

and the PE terminal must not exceed 300Vac continuously. The input can also be powered from batteries or similar DC sources. The voltage between the input terminal and the

PE terminal must not exceed 375Vdc continuously. A disconnecting means shall be provided for the input of the device. The device is designed for convection cooling and does not require an external fan. Do not obstruct airflow and do not

cover ventilation grid! The device is designed for altitudes up to 6000m (19685ft). See additional requirements in the product datasheet for

use above 2000m (6560ft).

Aug. 2019 / Rev. 1.1 DS-CP20.241-EN - All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 20A output load, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.

3/32

CP20.241, CP20.241-C1, CP20.241-S1,

CP

CP20.241-S2, CP20.241-V1, CP20.242

Keep the following minimum installation clearances: 40mm on top, 20mm on the bottom, 5mm left and right side. Increase the 5mm to 15mm in case the adjacent device is a heat source. When the device is permanently loaded with less than 50%, the 5mm can be reduced to zero.

The device is designed, tested and approved for branch circuits up to 32A (IEC) and 30A (UL) without additional protection device. If an external fuse is utilized, do not use circuit breakers smaller than 10A B- or C-Characteristic to avoid a nuisance tripping of the circuit breaker.

The maximum surrounding air temperature is +70°C (+158°F). The operational temperature is the same as the ambient or surrounding air temperature and is defined 2cm below the device.

The device is designed to operate in areas between 5% and 95% relative humidity.

Installation instructions for use in hazardous location areas:

The power supply is suitable for use in Class I Division 2 Groups A, B, C, D locations. See chapter 20 for details.

WARNING EXPLOSION HAZARDS!

Substitution of components may impair suitability for this environment. Do not disconnect the unit or operate the voltage adjustment or S/P jumper unless power has been switched off or the area is known to be non-hazardous.

Wiring must be in accordance with Class I, Division 2 wiring methods of the National Electrical Code, NFPA 70, and in accordance with other local or national codes.

A suitable enclosure must be provided for the end product which has a minimum protection of IP54 and fulfils the requirements of the EN 60079-0.

-Series

24V, 20A, 480W, SINGLE PHASE

Aug. 2019 / Rev. 1.1 DS-CP20.241-EN - All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 20A output load, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.

4/32

CP20.241, CP20.241-C1, CP20.241-S1,

CP

3. AC-INPUT

AC input

AC input range

Allowed voltage L or N to earth

Input frequency

Turn

Shut

External input protection

Input current

Power factor

Cre

Start

Rise time Turn

Turn-on

85V

Rated

input range

max.

500ms

V

IN

P

OUT

300Vac

264V

Shut-down

Start-up

delay

Rise

Time

Overshoot

- 5%

Output Voltage

Input Voltage

24A

2 4 6 8 10 12 14 16 18

0

1

2

3

4

5

6A

Input Current, typ.

20 22

a) 100Vac b) 120Vac c) 230Vac

b

a

c

Output Current

Power Factor, typ.

2 4 6 8 10 12 14 16 18 24A

0.75

0.8

0.85

0.9

0.95

1.0

20 22

a) 100Vac b) 120Vac c) 230Vac

a, b

c

Output Current

CP20.241-S2, CP20.241-V1, CP20.242

-Series

24V, 20A, 480W, SINGLE PHASE

The device is suitable to be supplied from TN-, TT- and IT mains networks with AC voltage. For suitable DC supply voltages see chapter 4.

Nom. AC 100-240V

Min. 85-264Vac Continuous operation

Min. 264-300Vac Occasionally for maximal 500ms

Max. 300Vac Continuous, according to IEC 60664-1

Nom. 50–60Hz ±6%

-on voltage Typ. 82Vac Steady-state value, see Fig. 3-1

-down voltage Typ. 72Vac Steady-state value, see Fig. 3-1 See recommendations in chapter 2.

AC 100V AC 120V AC 230V

Typ. 5.15A 4.26A 2.23A At 24V, 20A, see Fig. 3-3

Typ. 0.996 0.996 0.980 At 24V, 20A, see Fig. 3-4

st factor*) Typ. 1.65 1.63 1.63 At 24V, 20A, The crest factor is the

mathematical ratio of the peak value to RMS value of the input current waveform.

-up delay Typ. 450ms 450ms 450ms See Fig. 3-2 Typ. 145ms 145ms 145ms At 24V, 20A const. current load,

0mF load capacitance, see Fig. 3-2

Typ. 160ms 160ms 160ms At 24V, 20A const. current load,

20mF load capacitance, see Fig. 3-2

-on overshoot Max. 200mV 200mV 200mV In single use mode, see Fig. 3-2

Fig. 3-1 Input voltage range Fig. 3-2 Turn-on behavior, definitions

Fig. 3-3 Input current vs. output current at

24V output voltage

Aug. 2019 / Rev. 1.1 DS-CP20.241-EN - All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 20A output load, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.

Fig. 3-4 Power factor vs. output current at

24V output voltage

5/32

CP20.241, CP20.241-C1, CP20.241-S1,

CP

4. DC-I

DC input DC input range DC input current

Allowed Voltage (+) or ( to Earth

Turn

Shut

+

-

Load

L

PE

+

-

Power Supply

AC

DC

Battery

N

CP20.241-S2, CP20.241-V1, CP20.242

-Series

24V, 20A, 480W, SINGLE PHASE

NPUT

The device is suitable to be supplied from a DC input voltage. Use a battery or a similar DC source. A supply from the intermediate DC-bus of a frequency converter is not recommended and can cause a malfunction or damage the unit.

Connect +pole to L, –pole to N and the PE terminal to an earth wire or to the machine ground.

Nom. DC 110-150V ±20%

For CP20.241, CP20.241-C1, CP20.241-S1, CP20.241S2, CP20.241-V1

Nom. DC 110-300V ±20%

For CP20.242

Min. 88-180Vdc Continuous operation for CP20.241, CP20.241-C1,

CP20.241-S1, CP20.241-S2, CP20.241-V1

88-360Vdc Continuous operation for CP20.242

Typ. 4.64A At 110Vdc, at 24V, 20A

Typ. 1.66A At 300Vdc, at 24V, 20A

-) input

-on voltage Typ. 80Vdc Steady state value

-down voltage Typ. 70Vdc Steady state value

Fig. 4-1 Wiring for DC Input

Max. 375Vdc Continuous according to IEC 60664-1

Aug. 2019 / Rev. 1.1 DS-CP20.241-EN - All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 20A output load, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.

6/32

CP20.241, CP20.241-C1, CP20.241-S1,

CP

5. I

Inrush current

Inrush energy

CP20.241-S2, CP20.241-V1, CP20.242

-Series

24V, 20A, 480W, SINGLE PHASE

NPUT INRUSH CURRENT

An active inrush limitation circuit limits the input inrush current after turn-on of the input voltage. The charging current into EMI suppression capacitors is disregarded in the first microseconds after switch-on.

Max. 15A

Max. 1A2s 1A2s 1A2s Temperature independent

Fig. 5-1 Typical turn-on behavior at nominal

load and 25°C ambient

Typ. 12A

AC 100V AC 120V AC 230V

12A

peak

10A

peak

5.5A

peak

4.5A

peak

Temperature independent Temperature independent

Aug. 2019 / Rev. 1.1 DS-CP20.241-EN - All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 20A output load, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.

7/32

CP20.241, CP20.241-C1, CP20.241-S1,

CP

6. O

Output voltage

Adjustment range

Factory setting output voltage

Typ.

24.1V

±0.2% in “single use” mode at full load, cold unit

Line regulation

Load regulation

Ripple and noise voltage

Output current

Fuse breaking current

Overload behavior

Continuous current

For output voltage above 13Vdc, see Fig. 6-1

Overload/ short

Output ca

Back

CP20.241-S2, CP20.241-V1, CP20.242

-Series

24V, 20A, 480W, SINGLE PHASE

UTPUT

The output provides a SELV/PELV/ES1 rated voltage, which is galvanically isolated from the input voltage. The device is designed to supply any kind of loads, including capacitive and inductive loads. If extreme large

capacitors, such as EDLCs (electric double layer capacitors or “UltraCaps”) with a capacitance > 1F are connected to the output, the unit might charge the capacitor in an intermittent mode.

The output is electronically protected against overload, no-load and short-circuits. In case of a protection event, audible noise may occur.

Nom. 24V

Min. 24-28V Guaranteed value

Max. 30V This is the maximum output voltage which can occur

at the clockwise end position of the potentiometer due to tolerances. It is not a guaranteed value which can be achieved.

Typ. 24.1V ±0.2% in “parallel use” mode at 20A, cold unit

(results to 23.9V ±0.2% at 24A and 25.1V ±0.2% at no load)

Max. 10mV Between 85 and 300Vac input voltage change

Max. 100mV Between 0 and 24A in “single use” mode, static value

Typ. 1000mV Between 0 and 20A in “parallel use” mode, static

value, see Fig. 6-2

Max. 50mVpp Bandwidth 20Hz to 20MHz, 50Ohm

Nom. 24A1) At 24V and an ambient temperature below 45°C

Nom. 20A At 24V and 60°C ambient temperature Nom. 15A At 24V and 70°C ambient temperature Nom. 20.6A1) At 28V and an ambient temperature below 45°C Nom. 17.1A At 28V and 60°C ambient temperature Nom. 13A At 28V and 70°C ambient temperature Derate linearely between +45°C and +70°C

Typ. 60A Up to 12ms once every five seconds, see Fig. 6-4.

The fuse braking current is an enhanced transient current which helps to trip fuses on faulty output branches. The output voltage stays above 20V.

Intermittent current2) For output voltage below 13Vdc, see Fig. 6-1

-circuit current Max. 29.8A Continuous current, see Fig. 6-1 Typ. 29A Intermitted current peak value for typ. 2s

Max. 9.8A Intermitted current average value (R.M.S.)

pacitance Typ. 8 500µF Included inside the power supply

-feeding loads

1) This current is also available for temperatures up to +70°C with a duty cycle of 10% and/ or not longer than 1 minute every 10 minutes.

Aug. 2019 / Rev. 1.1 DS-CP20.241-EN - All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 20A output load, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.

Max. 35V The unit is resistant and does not show

Load impedance 10mOhm, see Fig. 6-3 Discharge current of output capacitors is not included.

Load impedance 10mOhm, see Fig. 6-3

malfunctioning when a load feeds back voltage to the power supply. It does not matter whether the power supply is on or off. The absorbing energy can be calculated according to the built-in large sized output capacitor.

8/32

CP20.241, CP20.241-C1, CP20.241-S1,

CP

Output Voltage (Single Use, typ.)

0

0 25

4

8

12

28V

16

20

24

40A

155

10

20

30 35

Adjustment

Range

Output Current

A: continuous current B: intermitted current

A

B

Output Voltage (Parallel Use, typ.)

22V

0 8 16

23V

24V

25V

29V

26V

27V

28V

24A

20124

Adjustment

Range

Factory setting

Output Current

0

29A

18s

2s

t

Short -circuit

Normal

operation

Normal

operation

Output Voltage (dynamic behavior, < 12ms)

0

4

8

12

28V

16

20

24

70A3010 40 5020 60

Adjustment

Range

Output Current

CP20.241-S2, CP20.241-V1, CP20.242

-Series

24V, 20A, 480W, SINGLE PHASE

2) At heavy overloads (when output voltage falls below 13V), the power supply delivers continuous output current for 2s. After this, the output is switched off for approx. 18s before a new start attempt is automatically performed. This cycle is repeated as long as the overload exists. If the overload has been cleared, the device will operate normally. See Fig. 6-3.

Fig. 6-1 Output voltage vs. output current,

typ.

Fig. 6-2 Output voltage in “parallel use”

mode, typ.

Fig. 6-3 Short-circuit on output, Hiccup

PLUS®

mode, typ. Fig. 6-4 Dynamic overcurrent capability, typ.

Aug. 2019 / Rev. 1.1 DS-CP20.241-EN - All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 20A output load, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.

9/32

CP20.241, CP20.241-C1, CP20.241-S1,

CP

7. HOLD-UP TIME

Hold

Min.

54ms

At 24V, 10A, see Fig. 7-1

0

10

20

30

40

80ms

85 120 155 190 230Vac

Input Voltage

50

60

Hold-up Time

24V, 20A, typ.

24V, 10A, min.

24V, 10A, typ.

70

24V, 20A, min.

- 5%

Hold-up Time

Zero Transition

Output Voltage

Input Voltage

8. DC-OK R

Contact closes

Contact opens Switching hysteresis

Contact ratings

Minimal permissible load: 1mA at 5Vdc

Isolation voltage

100ms

0.9* V

ADJ

<

1ms

10%

open

V

OUT

= V

ADJ

openclosed closed

>

1...4ms

CP20.241-S2, CP20.241-V1, CP20.242

-Series

24V, 20A, 480W, SINGLE PHASE

The hold-up time is the time during which a power supply’s output voltage remains within specification following the loss of input power. The hold-up time is output load dependent. At no load, the hold-up time can be up to several seconds. The green DC-ok lamp is also on during this time.

AC 100V AC 120V AC 230V

-up Time Typ. 65ms 65ms 65ms At 24V, 10A, see Fig. 7-1

Typ. 32ms 32ms 32ms At 24V, 20A, see Fig. 7-1 Min. 24ms 24ms 24ms At 24V, 20A, see Fig. 7-1

Fig. 7-1 Hold-up time vs. input voltage Fig. 7-2 Shut-down behavior, definitions

ELAY CONTACT

This feature monitors the output voltage on the output terminals of a running power supply.

As soon as the output voltage reaches typ. 90% of the adjusted output voltage level. As soon as the output voltage dips more than 10% below the adjusted output voltage.

Short dips will be extended to a signal length of 100ms. Dips shorter than 1ms will be ignored.

1V

Maximal 60Vdc 0.3A, 30Vdc 1A, 30Vac 0.5A, resistive load

See dielectric strength table in section 18.

Fig. 8-1 DC-ok relay contact behavior

Aug. 2019 / Rev. 1.1 DS-CP20.241-EN - All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 20A output load, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.

10/32
