PTN TPUH630R, TPUH630T User Manual

www.PTN-electronics.com

User Manual

TPUH630

HDMI2.0 HDBaseT Extender

All Rights Reserved

Version: TPUH630_2017V1.0

HDMI2.0 HDBaseT Extender

Preface

Read this user manual carefully before using this product. Pictures shown in this manual
is for reference only, different model and specifications are subject to real product.

This manual is only for operation instruction only, not for any maintenance usage. The
functions described in this version are updated till April 2017. In the constant effort to
improve our product, we reserve the right to make functions or parameters changes
without notice or obligation. Please refer to the dealers for the latest details.

All product function is valid till 2017-4-13.

Trademarks

Product model, PTN and its logo are trademarks of PTN Electronics Limited.
Any other trademarks mentioned in this manual are acknowledged as the properties of
the trademark owner. No part of this publication may be copied or reproduced without
the prior written consent of PTN Electronics Limited.

FCC Statement

This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. It has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a commercial
installation.

Operation of this equipment in a residential area is likely to cause interference, in which
case the user at their own expense will be required to take whatever measures may be
necessary to correct the interference.

Any changes or modifications not expressly approved by the manufacture would void
the user’s authority to operate the equipment.

PTN Electronics Limited www.PTN-electronics.com

HDMI2.0 HDBaseT Extender

SAFETY PRECAUTIONS

To insure the best from the product, please read all instructions carefully before using
the device. Save this manual for further reference.

 Unpack the equipment carefully and save the original box and packing material for

possible future shipment

 Follow basic safety precautions to reduce the risk of fire, electrical shock and injury

to persons.

 Do not dismantle the housing or modify the module. It may result in electrical shock

or burn.

 Using supplies or parts not meeting the products’ specifications may cause damage,

deterioration or malfunction.

 Refer all servicing to qualified service personnel.
 To prevent fire or shock hazard, do not expose the unit to rain, moisture or install this

product near water.

 Do not put any heavy items on the extension cable in case of extrusion.
 Do not remove the housing of the device as opening or removing housing may

expose you to dangerous voltage or other hazards.

 Install the device in a place with fine ventilation to avoid damage caused by

overheat.

 Keep the module away from liquids.
 Spillage into the housing may result in fire, electrical shock, or equipment damage. If

an object or liquid falls or spills on to the housing, unplug the module immediately.

 Do not twist or pull by force ends of the optical cable. It can cause malfunction.
 Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to

the device before cleaning.

 Unplug the power cord when left unused for a long period of time.
 Information on disposal for scrapped devices: do not burn or mix with general

household waste, please treat them as normal electrical wastes.

PTN Electronics Limited www.PTN-electronics.com

HDMI2.0 HDBaseT Extender

Contents

1. Introduction ................................................................................................................. 1

1.1 Brief Introduction ............................................................................................... 1

1.2 Features ............................................................................................................ 1

1.3 Package List ...................................................................................................... 1

2. Panel Description ........................................................................................................ 2

2.1 Transmitter TPUH630T ...................................................................................... 2

2.2 Receiver TPUH630R ......................................................................................... 3

3. System Connection ..................................................................................................... 5

3.1 Usage Precautions ............................................................................................ 5

3.2 System Diagram ................................................................................................ 5

4. Specification ............................................................................................................... 8

5. Troubleshooting & Maintenance ................................................................................. 9

6. After-sales Service .................................................................................................... 11

PTN Electronics Limited www.PTN-electronics.com

HDMI2.0 HDBaseT Extender

 1 x TPUH630T

 1 x TPUH630R

 1 x Power Adapter (DC24V 1.25A)

 2 x 3-pin Phoenix Connector

 4 x Mounting Ears & 4 x Screws

 8 x Plastic Cushions

 1 x User Manual

1. Introduction

1.1 Brief Introduction

TPUH630 is an ultra-thin HDMI2.0 HDBaseT Extender, includes Transmitter TPUH630T
& Receiver TPUH630R. It extends 3840x2160@60Hz 4:4:4 (Max) HDMI signal up to
100m via Cat5e/6 based on HDBaseT technology, providing a good solution for
long-distance transmission application.

Flexible power design (24V PoC) allows this extender to be powered at either the
Transmitter or Receiver end, and only one power supply is required.

The extender boasts 3 Ethernet ports to work as Ethernet Switch, with any one
connecting to LAN, other ports access Ethernet.

The bidirectional wideband IR, bidirectional RS232 pass-through capabilities make the
extender compatible with most control systems. Furthermore, TPUH630 supports ARC
function, making it more flexible.

1.2 Features

 Support HDMI 2.0, 3840x2160@60Hz 4:4:4, HDR.
 HDCP2.2 pass-through.
 Extends 3840x2160@60Hz 4:4:4 (Max) signal up to 100m.
 Supports bi-directional IR/RS232 pass-through.
 Supports bi-directional 24V PoC.
 Works as Ethernet Switch.
 LEDs indicate the system status.

1.3 Package List

 Confirm if the product and the accessories are all included, if not, please contact

with the dealers.

PTN Electronics Limited 1 ww.PTN-electronics.com

HDMI2.0 HDBaseT Extender

No.

Name

Description

①

Power LED

RED when DC power present.

②

IR IN

Connect with IR Receiver to collect infrared signal, work with
far-end IR OUT port.

③

IR OUT

Connect with IR Emitter to send infrared signal, work with
far-end IR IN port.

④

RS232

Serial port, supports bi-directional RS232 pass-through.

⑤

RS232 MODE
switcher

 CTRL: RS232 pass-through control mode;
 UPDATE A: Update Valens IC program, connect a PC to

the RS232 port, and then double-click the update file
(.bat).

 UPDATE B: Update compression IC program, the

upgrade method is the same as the above UPDATE A.

⑥

ARC Switcher

ON: Enable ARC function; OFF: Disable ARC function

⑦

HDMI IN

Connect with HDMI source.

⑧

SPDIF OUT

Digital audio output port.

⑨

L+R OUT

Stereo analog audio output port.

⑩

ETHERNET

Ethenet port, work as Ethernet Switch together with the 2
Ethenet ports of Receiver. Connect router to any one port, the
others are able to access LAN.

IR IN IR OUT

ARC

OFF

UPDATE A UPDATE B

CTRL

ON

Tx Rx

R

L

1

2

3

4

5

6

7

8

9

10

11

12

2. Panel Description

2.1 Transmitter TPUH630T

PTN Electronics Limited 2 ww.PTN-electronics.com

HDMI2.0 HDBaseT Extender

⑪

HDBT OUT

Connect to the Receiver via Cat5e/6 cable.

⑫

DC 24V

Connect with the included power adapter.

No.

Name

Description

①

Power LED

RED when DC power present.

②

IR IN

Connect with IR Receiver to collect infrared signal, work with
far-end IR OUT port.

③

IR OUT

Connect with IR Emitter to send infrared signal, work with
far-end IR IN port.

④

RS232

Serial port, supports bi-directional RS232 pass-through.

⑤

RS232 MODE
switcher

 CTRL: RS232 pass-through control mode;
 UPDATE A: Update Valens IC program, connect a PC to

the RS232 port, and then double-click the update file
(.bat).

 UPDATE B: Update compression IC program, the

upgrade method is the same as the above UPDATE A.

⑥

ARC Switcher

ON: Enable ARC function; OFF: Disable ARC function.

⑦

HDMI OUT

Connect with HDMI display.

⑧

SPDIF IN/TO TX
Toslink audio input port, connect with audio source.

Coaxial audio input port, when this port is connected with
audio source， the Toslink audio input port shouldn’t be

IR IN IR OUT

ARC

OFF

UPDATE A UPDATE B

CTRL

ON

Tx Rx

1

2

3

4

5

6

7

8

9

10

11

2.2 Receiver TPUH630R

PTN Electronics Limited 3 ww.PTN-electronics.com

HDMI2.0 HDBaseT Extender

connected.

⑨

ETHERNET

2 Ethenet ports, work as Ethernet Switch together with the
Ethenet port of Transmitter. Connect router to any one port,
the others are able to access LAN.

⑩

HDBT IN

Connect to the TPUH630T via Cat5e/6 cable.

⑪

DC24V

Connect with the included power adapter.

 This extender to be powered at either the Transmitter or Receiver end, and only

one power adaptor is required.

PTN Electronics Limited 4 ww.PTN-electronics.com

HDMI2.0 HDBaseT Extender

Mode

ARC Switcher Status

Description

Transmitter

Receiver

①

ON

ON

The audio signal can be transmitted from the
HDTV display back to HDMI IN, SPDIF OUT and
L+R OUT ports.

②

OFF

OFF

The audio signal can be transmitted from the
SPDIF IN to SPDIF OUT and L+R OUT ports.

3. System Connection

TPUH630 has a good application in occasions where high-definition AV distribution,
long-distance transmission, Ethernet Switch are needed, such as computer realm,
monitoring, big screen displaying, meeting room, education and bank & securities
institution etc.

3.1 Usage Precautions

 System should be installed in a clean environment and has a prop temperature

and humidity.

 All of the power switches, plugs, sockets and power cords should be insulated and

safety.

 All devices should be connected before power on.

3.2 System Diagram

TPUH630 boast ARC (Audio Return Channel) function, which enables a display via a
single audio/ HDMI cable, to send (upstream) audio to amplifiers/ speakers, increasing
user flexibility.

PTN Electronics Limited 5 ww.PTN-electronics.com

HDMI2.0 HDBaseT Extender

R

L

4K 100m 1080P 150m ,

Route r

4K Blu- Ray

Lapto p

IR Emit ter

AR C ON

IR Rece iver T V Remot e

HDTV

IR Emit ter

IR Rece iver

Lapto p Lapto p

Ampli fier

Speak er

Speak erSpeak er

ARC

PoC

Blu-R ay
Remot e

HDMI:

IR:

RS232 :

CATx:

Power :

ARC

R

L

4K 100m 1080P 1 50m ,

Route r

4K Blu- Ray

Lapto p

IR Emit ter

IR Rece iver TV Remo te

HDTV

IR Emit ter

IR Rece iver B lu-Ra y

Remot e

Lapto p Lapto p

HDMI :

IR:

RS23 2:

CATx :

Powe r:

Ampli fierSpeak er

ARC

PoC

AR C OFF

① Transmitter: ARC ON; Receiver: ARC ON

Figure 3-1 System Diagram (ON ON)

② Transmitter: ARC OFF; Receiver: ARC OFF

Figure 3-2 System Diagram (OFF OFF)



 When using ARC feature, please connect the amplifier via HDMI cable.
 All utilized devices including the HDMI cable should support ARC.
 System Diagram shown in this manual are for reference only, more specific

schemes depend on real devices.

 Connect HDBT ports via straight-thru CAT5e/6 cable with TIA/EIAT568B standard

terminations at both ends.

PTN Electronics Limited 6 ww.PTN-electronics.com

HDMI2.0 HDBaseT Extender

 RS232 communication protocol: Baud Rate: 9600; data bit: 8; stop bit: 1; parity:

none. TPUH630 receives RS232 control from devices with various baud rate (2400,
4800, 9600, 19200, 38400, 57600, 115200).

 HDBT ports can work with our company’s HDBT devices that has same power

supply solution.

 Make sure the switchers on front panel are in the necessary status.

PTN Electronics Limited 7 ww.PTN-electronics.com

HDMI2.0 HDBaseT Extender

Model
Spec

Transmitter TPUH630T

Receiver TPUH630R
Audio& Video

Input

(1) HDMI

(1) HDBT; (1) SPDIF

Input Connector

(1) 19-pin Type-A male

(1) RJ45; (1) Toslink/Coax

Output

(1) HDBT; (1) L+R ; (1) SPDIF

(1) HDMI

Output Connector

(1) RJ45; (1) L&R (RCA);
(1) Toslink

(1) 19-pin Type-A male

Control Parts

Control

(1) IR IN; (1) IR OUT;
(1) RS232; (1) Ethernet

(1) IR IN; (1) IR OUT;
(1) RS232; (2) Ethernet

Control Connector

(2) 3.5mm mini jack;
(1) 3-Pin phoenix connector;
(1) RJ45

(2) 3.5mm mini jack;
(1) 3-Pin phoenix connector;
(2) RJ45

General

Transmission Mode &
Distance

HDBaseT; 4Kx2K@60Hz 4:4:4≤100m

Resolution

Up to 3840x2160@60Hz 4:4:4.

Signal Standard

HDMI2.0& HDCP2.2.

Temperature

-10~ 55℃.

Reference Humidity

10% ~ 90%.

Power Supply

Input: 100V~240V AC; Output: 24VDC, 1.25A.

Power Consumption

19W (Max.)

Dimension(W*H*D)

152mm x 19mm x84mm

152mm x 19mm x84mm

Net Weight

227g

232g

4. Specification

PTN Electronics Limited 8 ww.PTN-electronics.com

HDMI2.0 HDBaseT Extender

Problems

Causes

Solutions

No reaction to
any operation,
power indicator
is off

Haven’t been powered on.

Insert power adapter to either
end.

The poor quality of network
cable.

Should the replacement
CAT5e/CAT6a cable of high
quality.

Abnormal
indication of the
status LEDs

Wrong specification of the power
adapter.

Change for DC 24V 1.25A power
adapter.

Color lose or
poor picture
quality

Bad quality of the HDMI cable.

Ensure the HDMI cables used at
source, transmitter, receiver and
display are properly connected
and are of good quality.

HDMI cables are too long to
transmit 4K HDMI signal
successfully.
The longest HDMI cable is 8m
for 4K input signal, and 20m for
4K output signal.

Shorten the length of HDMI
cables.

No video output
Communication cables has no

connection or bad connection.

Recheck all cables and ports.

The display that you use is
incompatible with this device.

It is recommended that you use
mainstream display.

No digital audio
output

Input source and output device
are connected to the wrong
ports.

Check again and make sure
input source and output device
are connected correctly.

Audio Output device don’t
support the audio format.

Change for other output devices
that support the audio formats
listed in Specifications.

No analog audio

Audio OUT port (RCA connector)

Change for other audio input

5. Troubleshooting & Maintenance

PTN Electronics Limited 9 ww.PTN-electronics.com

HDMI2.0 HDBaseT Extender

output

only support PCM format.

device that support PCM format.

Cannot use
ARC function

ARC switcher is dialed to OFF

Dial the switcher to ON.

Devices or cables utilized don’t
support ARC

Change for devices/ cables that
support ARC

Cannot work as
an Ethernet
Switch. PCs
cannot connect
to the internet.

The DHCP switch of Router is
turned on, but the IP address of
PCs are static.

Recheck all PCs and set these
Pcs to use dynamic IP mode.

The DHCP switch of Router is
turned off, but the IP address of
PCs are dynamic.

Recheck all PCs and set these
Pcs to use static IP mode and
make sure the difference of IP
addresses to avoid IP address
conflict.

Network or server failure.

Please contact to your Internet
Service Provider.

Cannot use the
device

the device is broken

Send it to authorized dealer for
repairing.

If your problem persists after following the above troubleshooting steps, seek further
help from authorized dealer or our technical support.

PTN Electronics Limited 10 ww.PTN-electronics.com

HDMI2.0 HDBaseT Extender

6. After-sales Service

If there appear some problems when running the device, please check and deal with the
problems reference to this user manual.

 Product Limited Warranty: PTN warrants that its products will be free from defects

in materials and workmanship for three years, which starts from the first day the
product leaves warehouse (check the SN mark on the product).

Proof of purchase in the form of a bill of sale or receipted invoice must be presented
to obtain warranty service.

 What the warranty does not cover:

 Warranty expiration.
 Factory applied serial number has been altered or removed from the product.
 Damage, deterioration or malfunction caused by:

 Normal wear and tear
 Use of supplies or parts not meeting our specifications
 No certificate or invoice as the proof of warranty.
 The product model showed on the warranty card does not match with the

model of the product for repairing or had been altered.

 Damage caused by force majeure.
 Servicing not authorized by PTN.
 Other causes which does not relate to a product defect.

 Delivery, installation or labor charges for installation or setup of the product.

 Technical Support: Email to our after-sales department or make a call, please

inform us the following information about your cases.

 Product version and name.
 Detailed failure situations.
 The formation of the cases.

Remarks: For any questions or problems, please try to get help from your local
distributor, or email PTN at: [e-mail]

PTN Electronics Limited 11 ww.PTN-electronics.com

www.PTN-electronics.com

PTN Electronics Limited
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Website: www.PTN-electronics.com


