Psion HFAM2G2 Users Manual

WORKABOUT PRO G2

RFID Reader HF-AM2-G2

User Manual

Title
Doc Type
Doc Id

Revision Date Name Status/Comment

A00 12/12/07 F.DEBULOIS Initial Version

RFID reader HF-AM2-G2 User Manual
User Manual
TS A00350

Specifications are subject to change without notice
Psion Teklogix™ is a trademark of Psion Teklogix Inc. Other product names mentioned

in this document may be trademarks of Psion Teklog ix Inc. or trademarks or registered
trademarks of other hardware, software, or service providers and are used herein for
identification purposes only.

RFID Reader HF-AM2-G2 – User Manual
TS-A00350-A00 Page 2/19

Table of Content

I. Important – read carefully.............................................................................................4

II. Overview .....................................................................................................................4

II.1. Bill of Material................................................................................................................. 4

II.2. Interface Board installation..............................................................................................5

II.3. Reader Board Installation.................................................................................................6

II.3.1. HF-AM2-G2 Endcap ...............................................................................................................6

II.3.2. SAGEM endcap dual reader with slot......................................................................................6

III. Hardware installation .................................................................................................7

III.1. Preparing......................................................................................................................... 7

III.2. Interface Board installation.............................................................................................8

III.3. Reader Board installation................................................................................................8

III.3.1. HF-AM2-G2 Endcap assembly ..............................................................................................8

III.3.2. SAGEM endcap dual reader with slot assembly...................................................................10

III.4. Endcap connection........................................................................................................14

III.4.1. HF-AM2-G2 Endcap............................................................................................................14

III.4.2. SAGEM endcap dual reader with slot..................................................................................15

III.5. Final steps.....................................................................................................................15

IV. Reading Area................... .........................................................................................16

V. RFID Regulatory Information...................................................................................16

RFID Reader HF-AM2-G2 – User Manual
TS-A00350-A00 Page 3/19

I. Important – read carefully

All Approval and safety information is outlined in the ‘Workabout pro G2 Handheld-computer User
Manual’ – part number 8100140A. This manual is available on our website

www.psionteklogix.com through the Teknet extranet

II. Overview

II.1. Bill of Material

RFID Reader HF-AM2-G2 is composed of :

- an interface board, connected in the Workabout Pro G2 Handheld computer

- a reader board, with its built-in antenna

- a flex cable, which connects the two boards.

Flex cable

Reader Board

Interface

Board

RFID Reader HF-AM2-G2 – User Manual
TS-A00350-A00 Page 4/19

II.2. Interface Board installation

The interface Board has to be installed in the Workabout Pro:

Specific end

cap

Flex cable to
reader board

Interface

Board

Built-in scanner

flex cable

RFID Reader HF-AM2-G2 – User Manual
TS-A00350-A00 Page 5/19

II.3. Reader Board Installation

The reader board has to be installed in a specific endcap depending of the configuration:

II.3.1. HF-AM2-G2 Endcap

II.3.2. SAGEM endcap dual reader with slot

RFID Reader HF-AM2-G2 – User Manual
TS-A00350-A00 Page 6/19
