Chapter 1: Introduction
1.1About This Manual..................................................................................................3
C.9ENDING THIS AGREEMENT ........................................................................................ C-4
C.10 GENERAL ............................................................................................................ C-4
Index ...........................................................................................I
Psion EP10 HDK User Manual
iii
INTRODUCTION
1
INTRODUCTION1
1.1About This Manual........................................................3
1.2 Text Conventions.........................................................3
1.3 About the HDK..........................................................3
1.4 Development Platform......................................................3
1.5 Contents of the HDK.......................................................4
1.5.1 Files in the HDK....................................................4
1.6 Obtaining the HDK........................................................5
1.7About the EP10 Hand-Held Computer.............................................5
Psion EP10 HDK User Manual
1
1.1About This Manual
>
This manual provides guidance on using the EP10 HDK to create peripherals that attach to the docking connector of the Psion EP10 hand-held computer. The manual is organised into the following chapters:
Chapter 1: Introduction
provides an overview of the EP10 Hand-Held Computer and the EP10 HDK.
Chapter 2: Hardware
describes, in general terms, the hardware of EP10.
Chapter 3: Software
gives an overview of the registry entries and API for controlling peripherals and the installation of device drivers.
Chapter 4: Mechanical Considerations
describes the physical considerations of designing peripherals.
Chapter 5: Connections
describes the physical and electrical aspects of the docking connector of the EP10, and of the
connectors available on the EP10 snap modules.
Chapter 6: HDK Demo Application
describes the features and functions of the HDK Demo application program.
Appendix A: Resources
lists extra resources which may be of use in conjunction with the HDK.
Appendix B: EP10 Specifications
lists the specifications of the EP10.
Appendix C: HDK License Agreement
provides the license agreement that is assumed by using the EP10 HDK.
Chapter 1: Introduction
About This Manual
1.2Text Conventions
The following conventions and syntax are followed throughout this document:
Important: These statements provide important instructions or additional information that is critical
Warning:These statements provide important information that may prevent injury, damage to the
An arrow next to field description information (usually in tables) indicates a recommended or suggested
configuration setting.
to the operation of the computer or other equipment.
equipment, or loss of data.
1.3About the HDK
The EP10 HDK (Hardware Development Kit) provides the software tools and technical information necessary to design and integrate peripherals for your EP10 hand-held computer.
The docking connector on the EP10 provides access to USB and serial interfaces for connecting to standard
devices (barcode scanners, imagers, RFID readers, etc.).
3D model files and 2D schematic drawings are provided which give the precise measurements needed for
designing custom devices that fit snugly with the main housing around the docking connector.
Finally, the EP10 HDK API library provides the software tools necessary to access and control the peripheral
attached to the docking connector.
1.4Development Platform
The EP10 API library is designed for application development using Visual Studio 9 (2008).
Psion EP10 HDK User Manual
3
Chapter 1: Introduction
Contents of the HDK
1.5Contents of the HDK
The HDK (Hardware Development Kit) for EP10 includes the following items:
•This manual.
•Installer for development files, including C header files for managing peripherals and HDK Demo application. See Section 3.7 EP10 HDK Application Development Software and Section 3.8 EP10 HDK Demo
Application for more details on these files.
•2D drawings and 3D models of the EP10 outer shell, and existing EP10 snap modules for reference.
1.5.1Files in the HDK
The following files are included with the EP10 Hardware Development Kit:
Table 1.1 Files in the HDK
FilenameDescription
Hdk7515.hEP10 HDK header file
Hdk7515Const.hEP10 HDK constants header file
7515HDK.expEP10 HDK export file
7515HDK.libEP10 HDK library file
7515HDK.dllEP10 HDK dynamic link library
EP10HDKDemo.exeEP10 HDK demo application
EP10HDKDemoSrc.zipZip file containing the source code of the demo application
EP10.stp3D step file of the EP10 external case
EP10_Case_Front.pdf2D drawing of EP10 front case
EP10_Case_Rear.pdf2D drawing of EP10 rear case
Serial_SnapOn.stp3D step file of the DE9 RS-232 snap module assembly
Serial_SnapOn_Lower.pdf2D drawing of the lower housing of the DE9 RS-232 snap module
Serial_SnapOn_Upper.pdf2D drawing of the upper housing of the DE9 RS-232 snap module
Snap_On_Latch_Left.pdf2D drawing of the left latch for an EP10 snap module
Snap_On_Latch_Right.pdf2D drawing of the right latch for an EP10 snap module
USB_SnapOn_Lower.pdf2D drawing of the lower housing of the USB snap module
USB_SnapOn_Upper.pdf2D drawing of the upper housing of the USB snap module
USB_SnapOn.stp3D step file of the USB snap module assembly
Serial_SnapOn_Schematics.pdfElectrical schematics of the DE9 RS-232 snap module
USB_SnapOn_Schematics.pdfElectrical schematics of the USB snap module
Psion EP10 HDK User ManualThis document (P/N 8000255)
Software Development Files
EP10 HDK Demo Application
2D Schematic and 3D Model Files
Documentation
Psion EP10 HDK User Manual
4
1.6Obtaining the HDK
The EP10 HDK is available for download on the Psion Community website (http://community.psion.com).
You will need an account on the website in order to download files. An account can be easily created by
clicking on the Join link in the upper right corner of the home page.
To download the HDK:
1.Click on the Downloads link in the top bar of the Community home page.
2.Click on Psion HDK in the list that appears.
3.Click on Hardware Development Kit (HDK) for EP10.
4.Click on the link to view the license agreement and download the .zip file containing the HDK files.
5.Open the .zip file and extract the files within to a folder on your PC hard drive.
To continue with installing the HDK files required for developing applications to work with your peripherals,
see Section 3.7 EP10 HDK Application Development Software.
1.7About the EP10 Hand-Held Computer
The EP10 hand-held computer is a small and durable PDA device that has been built to withstand
challenging weather and environmental conditions. EP10 uses the Microsoft® Windows® Embedded 6.5
operating system.
For more information on the EP10 operation, refer to the EP10 Hand-Held Computer User Manual
(P/N 8000227).
This chapter gives an overview of the hardware of EP10.
2.2Hardware Variants
2.2.1Keyboard Variants
EP10 has three standard variants for the keyboard layout: numeric, QWERTY and AZERTY.
Numeric Keyboard
This numeric keyboard has the number keys arranged telephone-style, with the numbers 1,2,3 along the top
row. The alphabetic characters are also arranged telephone-style, in groups of 3 or 4 [FN]-shifted characters on the number keys.
QWERTY Keyboard
This alphabetic keyboard has the alpha keys arranged in standard QWERTY layout. The number keys are accessed as [FN]-shifted characters on the left-middle side of the keyboard, and are arranged telephonic-style, with the numbers 1,2,3 along the top row (on the E, R, and T keys, respectively).
AZERTY Keyboard
This alphabetic keyboard has the alpha keys arranged in the AZERTY layout favoured by many
French-speaking parts of Europe. It is identical to the QWERTY keyboard in all respects except that the locations of the Q and W keys are interchanged with the A and Z keys, respectively.
Chapter 2: Hardware
Overview
2.2.2Barcode Scanner/Imager Variants
EP10 comes standard with no barcode scanner/imager installed. An optional EA11 2D imager is available.
Specifications of the EA11 imager can be found in Appendix B: “EP10 Specifications”.
2.2.3WWAN Radio Variants
The EP10 is available with one of the following Wireless WAN (WWAN) radio options:
•Cinterion PH8 GSM/UMTS (worldwide)
•Sierra Wireless MC5728v CDMA Sprint (US)
•Sierra Wireless MC5728v CDMA Verizon (US)
Specifications of these radios can be found in Appendix B: “EP10 Specifications”.
Psion EP10 HDK User Manual
9
Chapter 2: Hardware
Main Board
CPU
AM 3715
Power Supply
And Charger
Display
Proconn
(U)SIM
WAN
(PH8)
(Sierra)
MicroSD
Camera
SysCon
RTC
Audio Codec
POP
mDDR
256MB
eMMC
2GB
WI-FI a/b/g/n
Bluetooth
GPS
Star IV
SPI
FLASH
Speaker
Co-extistence
WAN
Antenna
5G
Antenna
GPS
Antenna
I2S
I2C
PCM
Keyboard
Data
Capture
Display Module
Speaker
Camera Modu le
Sharp LCD
3.7" with
Touch panel
3Mpix
Flash
LED x 2
Docking Port
LED Backlight
Microphone
I2C
USB OTG
USB Host 2.0
Power In/O ut
S Modules
(USB/RS232)
Vehicle Cr adles
Desk Dock
Quad Dock
2D imager
EA11
Sensor
2.4G
Antenna
Sensor
Imager
Receiver
Receiver
I/O
WAN 2'nd
Antenna
GPS 2'nd
Antenna
Light Sensor
+ Proximit y
Accelerometer
+ Compass
Gyroscope
Side Key
Buttons
SDIO
UART
UART
High
Speed
USB
PHY
USB
USB
SDIO
SDIO
I2C
VibratorIndicators
Indicators
LED x 3
Vibrator
Dual MIPI
To CIF
Camera to
MIPI Conver ter
MIPI
Camera Interface
MIPI
Display I nterface
Camera Interface
MIC
Keyboard
MIC
Side Key
Buttons
Quad Batter y
Charger
CLA
AC
Wall
Adpt
Battery
Fuel
Gauge
AC
brick
Adpt
SIM/SD
Socket
Radios
Processor
2.3Processor
EP10 is built around a Texas Instruments AM3715 800MHz ARM Cortex-A8 processor.
2.4Identifying Hardware
An overview of the operating system and the installed hardware on EP10 can be viewed by opening the
System applet in the Windows Control Panel.
2.5LEDs
Three LEDs are located on the upper-right side of the EP10, just above the display. When you press the
Power button, the LED flashes yellow to indicate that the EP10 has been powered up.
10
Psion EP10 HDK User Manual
Chapter 2: Hardware
Power Management
Keep in mind that the application running on the EP10 can dictate how the application LED operates.
Review the documentation provided with your application to determine LED behaviour.
Table 2.1 Function of EP10 LEDs
LEDFunction
Green/Yellow/Red Charge LED
(left-most LED)
Yellow Application LED (centre LED)Application LED. The behaviour of this LED is application dependent.
Blue Radio Power LED (right-most LED) Radio power indicator.
Charge indicator, when connected to an external power supply. See the
table below for descriptions of Charge LED behaviour.
If the EP10 is attached to an external power supply (through a snap module or dock), the charge LED (the
left-most LED) reflects the battery charge status.
Table 2.2 EP10 Charge LED Behaviour
Charging StatusLED ColourLED Flash RateDuty Cycle
No external power detected.Not applicableOFFNot applicable
Battery charge complete.GREENSolid ONContinuous
Battery charging normally.GREENSlowRegular
Battery not charging because battery
temperature is outside the allowable
range: 0° C to 40° C, 32° to 104° F.
Battery charge failure. Unable to read
battery or non Psion battery.
YELLOWNormalRegular
REDSolid ONContinuous
2.6Power Management
EP10 is powered by a lithium-ion rechargeable battery pack and can also be powered from external power.
When EP10 is powered from external power, the battery pack also charges.
Use only power sources recommended or sold by Psion for EP10.
2.6.1Batteries
Two Lithium-Ion battery pack variants are available for the EP10: High Capacity 3600 mAh battery pack,
Model Number RV3010 and Standard Capacity 2400 mAh battery pack, Model Number RV3005. For more
details on battery safety, charging and usage, refer to the EP10 Hand-Held Computer User Manual
(P/N 8000227).
