Psion 7505BTSDCMHC25 Users Guide
MODEL: PSIONBTL169
INSTALLATION INSTRUCTIONS
The bluetooth module, model number PSIONBTL169, and the bluetooth antenna need to be soldered
to the printed circuit board using following information:
6. Dimensions, Marking and Terminal Configurations
<Top View> <Bottom View><Side View>
LT
Preliminary Specification Number : SP-6LCS-B
p.2/20
L1
b1
a1
e1
W
(28)
1pin index
(23) (15)
(14)(24)
(10)
b4
e3
a3
(14)
(13)
(12)
(11)
(10)
(32)
(30) (29)
(31)
(23)(22)(21)(20)(19)(18)(17)(16)(15)
b3
(1) (9)
(9) (8) (7) (6) (5) (4) (3) (2) (1)
m1
c3
e4
Dimensions
(Unit : mm)
Mark Dimension Mark Dimension Mark Dimension
L 6.65 +/- 0.30 W 6.15 +/- 0.30 T 1.5 max.
a1 0.3 +/- 0.1 a2 0.3 +/- 0.1 a3 1.2 +/- 0.1
b1 0.725 +/- 0.200 b2 0.2 +/- 0.2 b3 1.225 +/- 0.200
b4 0.2 +/- 0.2 c1 0.6 +/- 0.1 c2 0.6 +/- 0.1
c3 1.0 +/- 0.2 e1 0.3 +/- 0.1 e2 0.3 +/- 0.1
e3 0.35 +/- 0.1 e4 0.4+/-0.1 e5 0.4+/-0.1
m1 0.3+/-0.1 m2 0.3+/-0.1 L1 6.55+/-0.30
c2
b2
(24)
(25)
(26)
(27)
(28)
c1
a2
e5
m2
e2
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
