Page 1
ACTIVE 17-2
SWISS MADE BY RELEC SA 1400 YVERDON
Technical data sheet
www.psiaudio.com
Page 2
ACTIVE 17-2
SWISS MADE BY RELEC SA 1400 YVERDON
Technical data sheet
*C P R : Compensated Phase Response system.
*A O I : Adaptive Output Impedance system.
LEVEL
INPUT
1=Gnd
2=Hot
3=Cold
MAINS EMI LP ON/OFF FUSE TRAFO RECT. REG.
ROLL OFF
115/220V
HP LP
Hi. ± 45V.
LIMITER
Low ± 18V.
www.psiaudio.com
AOI
HP
PWR
AMP.
CPR*
AOI
LP
PWR
AMP.
POWER
Puissance RMS
Power RMS
Puissance programme
Program power
Impédance d'entrée
Input Impedance
Sensibilité pour 100 dB @ 1m
Sensivity for 100 dB @ 1m
Rapport signal sur Bruit
Signal to Noise Ratio
Saturation d'entrée
Input Overload
Niveau max. continu, 1m
Continuous Max SPL, 1m
Niveau max. programme, 1m
Program Max SPL, 1m
Réponse à -6 dB
Response at -6dB
Tolérances
Tolerances
Distorsions THD
Distortion THD
Phase tolérances
Phase tolerances
Dispersion (B.R. 4 - 16 kHz) à -6 dB
Dispersion (P.N. 4 - 16 kHz) at -6 dB
Système
System
Fréquence de coupure
Crossover frequency
Dim. basses Ext. / Membrane
Woofer's dim. Ext. / Diaphragm
Dim. aigues Ext. / Membrane
Tweeter's dim. Ext. / Diaphragm
Connecteurs
Connectors
Signal entrée
Signal input
Matériaux du boîtier
Box Material
Dimensions boîtier L x H x P mm
Dimensions cabinet W x H x D mm
Poids net
Net Weight
Tension de secteur
Voltage
Consommation
Power Consumption
Humidité Moy / Max
Mean / Max Humidity
Température externe
External Temperature
70+50 W
120 W
Sym, 10k Ohms
0.775 V
-96 dBA
24 Vpp
104 dB (single)
115 dB (pair)
48 - 23000 Hz
±2.5 dB (55Hz - 20kHz)
< 1.8% (50Hz-20kHz)
±45° (220Hz - 20kHz)
90° x 90° (H x V)
2 Way(s)
4 kHz
Ø170 mm / Ø130 mm
Ø 100 mm / Ø 25 mm
1 x XLR F / 3P
1=GND, 2=(+), 3=(-)
MDF
200 x 320 x 230
7 Kg
115/230V (50-60Hz)
7 - 70 VA
< 75% / < 90%
5 - 40 °C
[dB]
+10
-10
-20
-30
[Deg]
+540
+450
+360
+270
+180
+90
-90
-180
[%]
0.5
0.2
0.1
[dB]
130
120
110
100
[Q]
SPL@1m Active 17-2
0
20
50
200
100
500
-10dB Roll Off
1k
2k
5k
20k [Hz]
10k
ACOUSTIC PHASE Active 17-2
0
1k
20
10
5
2
1
20
50
50
200
100
200
100
500
THD Active 17-2
500
2k
1k
2k
5k
5k
20k [Hz]
10k
20k [Hz]
10k
Max Continuous SPL 1m 17-2
90
31
405063
405063
80
100
125
200
250
315
160
400
Directivity Factor Active 17-2
80
100
125
200
250
315
160
400
25
10
5
2
1
31
25
1k
2k
4k
500
630
800
1k6
1k25
1k
500
630
800
2k
1k6
1k25
5k
2k5
2k5
6k38k10k
3k15
4k
5k
6k38k10k
3k15
16k
12k5
16k
12k5
PSI Active 17-2 III © RELEC SA all data subject to change without prior notice.
Page 3
SATELLITE 17-225
SWISS MADE BY RELEC SA 1400 YVERDON
Technical data sheet
www.psiaudio.com
Sytem setup
L R
LEVEL
CAL
IN 1
IN 2
LINK 1
LINK 2
Impédance d'entrée
Input Impedance
Saturation d'entrée
Input Overload
Sensibilité pour 100 dB @ 1m
Sensivity for 100 dB @ 1m
Rapport signal sur Bruit
Signal to Noise Ratio
Niveau max. continu, 1m
Continuous Max SPL, 1m
Niveau max. programme, 1m
Program Max SPL, 1m
Réponse à -6 dB
Response at -6dB
Tolérances
Tolerances
Distorsions THD
Distortion THD
Fréquence de coupure
Crossover frequency
Sym, 5k Ohms
24 Vpp
0.775 V
-96 dBA
111 dB (single)
117 dB (pair)
28 - 23000 Hz
±2.5 dB (28Hz - 20kHz)
< 1.8% (30Hz-20kHz)
95Hz / 4 kHz
-10dB
ROLL
OFF
A17/2 A17/2
System Response
[dB]
+10
[dB]
130
120
110
100
0
-10
-20
-30
20
90
SPL@1m SUB A225/1 A17-2(- 10 dB Roll Off) SUM
50
31
405063
25
80
200
100
Max Continuous SPL 1m 1xSUB225/1 & 2x17-2
100
125
200
250
315
160
SUB A225/1
1k
500
1k
500
630
800
400
1k25
-10dB
ROLL
OFF
2k
2k
1k6
5k
4k
5k
2k5
6k38k10k
3k15
20k [Hz]
10k
16k
12k5
PSI Actives 17-2 III & SUB 225/1 I © RELEC SA all data subject to change without prior notice.
Page 4
ACTIVE 17-2
SWISS MADE BY RELEC SA 1400 YVERDON
Mounting
Technical data sheet
www.psiaudio.com
All dimensions are in mm
100
30 30
65
135
30
140
Panel
screwing area
depth 16mm
Front
200
Bottom view Side view
Acoustical axis
70
Gravity
center
160
Minimum well-aired space
230
320
Front
100
190
Front view
PSI Actives 17-2 III © RELEC SA all data subject to change without prior notice.
