Table of Contents
Unpacking and Inspecting Your Scanner..................................... 3
After unpacking your new scanner, check the contents of the shipping carton to ensure all the items you ordered are included:
•PowerScan
•Interface Cable
•Power Supply (if you ordered one)
•User’s Guide (this manual)
•Programming Guide
•Optional Accessories that you ordered. (The PowerScan
handheld bar code scanner can be purchased with or without
accessory kits.)
If your package contains wrong or missing components, contact your
place of purchase. If there are damaged components, immediately file
a claim with the carrier. You may want to save your packing material
in case you need to ship the scanner at some later time.
NOTE
™ handheld scanner
Manuals for the PowerScan scanner are available
on our website. See the back cover for our web
address.
User’s Guide 3
Installation
Refer to Figure 1 and follow these steps to install the scanner:
Consult your host terminal manual to determine if power must be
turned off before connecting peripheral devices such as the scanner.
1.Should you need to disconnect the interface (I/F) cable from
the scanner, loosen the Phillips head screw at the bottom of
the handle and rotate the cable restraint clip away from the
cable to release it. Reverse this procedure to connect the
cable.
Do not attempt to pull the End Cap off, as this may
damage the scanner.
CAUTION
2.Connect the I/F cable to the proper port on the host terminal.
3.If your system requires an AC/DC adapter to power the
scanner, connect the adapter’s power cord at the I/F connector. (Note: In most cases, the scanner uses Power Off the Terminal [P.O.T.], and does not require this step.) Contact your
PSC dealer if you’re not sure if an AC/DC adapter should be
used with your system.
4.Connect the AC/DC adapter at the wall outlet. (P.O.T. units
skip this step.)
5.Verify operation—point at a flat surface and pull the trigger.
A red beam should be visible. Scan a sample bar code and
confirm that the scanner reads the bar code by beeping and/
or sending the data to the host terminal.
Power Supply
The scanner requires either a Listed Class 2 or Listed LPS power
source which supplies power directly to the scanner.
4PowerScan™ Scanner
Figure 1. Installing the Scanner
1
5
2
3
4
User’s Guide 5
How to Scan
Figure 2 illustrates some tips to help get the best scanning results:
1.The scanner must be pointed at a slight angle to the bar code.
Do not hold the scanner perpendicular to the bar code.
2.The laser beam must cross the entire bar code. The scanner
cannot correctly read if the entire bar code is not scanned.
Figure 2. Scanning Tips
1
1
2
2
6PowerScan™ Scanner
Scanning Range
There are currently four different model types for this scanner.
Depending upon the model type of your scanner, you’ll need to hold
the unit at a given distance from the bar code to achieve optimum
scanning results. The following diagrams provide range of field information for each of the models when scanning grade A, Code 39 bar
codes: Standard Range (SR), High Density (HD), Long Range (LR)
and Extra Long Range (XLR).
In the context of the illustration below, a "mil" represents the minimum bar code element width. Measurements are based on SR models set with the
standard 28° scan width (as opposed to the Half
Angle setting of 14°). Reference the PowerScan Pro-
NOTE
gramming Manual (P/N R44-1840) for more information about the Half Angle feature.
Specifications are subject to change without notice.
Figure 3. Depth of Field (SR)
Depth of Field
Paper Labels (SR decoded model, Code 39)
5 mil
7.5 mil
10 mil
FRONT OF SCANNER
0
10
15 mil
20 mil
12345
2030405060708090 100 110 120 130 140 150 160 170
40 mil
55 mil
FEET
CENTIMETERS
User’s Guide 7
In the context of the illustration below, a "mil" represents the minimum bar code element width. Measurements are based on HD models set with the
standard 28° scan width (as opposed to the Half
Angle setting of 14°). Reference the PowerScan Programming Manual (P/N R44-1840) for more informa-
NOTE
tion about the Half Angle feature.
Specifications are subject to change without notice.
Figure 4. Depth of Field (HD)
Depth of Field
Paper Labels (HD decoded model, Code 39)
3 mil
4 mil
FRONT OF SCANNER
5 mil
7.5 mil
10 mil
20 mil
1 234 5678
0
5
INCHES
CENTIMETERS
101520
8PowerScan™ Scanner
In the context of the illustration below, a "mil" represents the minimum bar code element width. Measurements are based on LR models set with the a
14° scan width (as opposed to the alternate Full
Angle setting of 28°). Reference the PowerScan Programming Manual (P/N R44-1840) for more informa-
NOTE
tion about the Half Angle feature.
Specifications are subject to change without notice.
In the context of the illustration below, a "mil" represents the minimum bar code element width. Measurements are based on XLR models set with a 10°
scan angle width.
NOTE
Specifications are subject to change without notice.
The active (enabled) bar code symbologies in the factory defaults are:
•Code 39 (C39)
•Code 128 (C128)
•Interleaved 2 of 5 (I 2 of 5)
Your scanner should be pre-programmed with these standard factory
default settings, unless...
...it was shipped to you programmed with unique, customer con-
figuration settings.
...you or another user have made changes to scanner program-
ming.
Enhanced Scanning for Hard-to-Read Bar Codes
Decoded scanners can be programmed to decode extremely poor
quality bar codes by activating advanced Quadralogic
To select this feature, see the PowerScan™ Scanner Programming
Guide (P/N R44-1840) available from your dealer, or you can download the manual from our website.
™ Decoding.
Scanner programming can also be performed using your PC and the
Configurator Express
from your dealer.
™ On-Screen Programming tool also available
User’s Guide 11
Test Your Scanner
The bar code below (Figure 7) is provided to test your scanner’s ability to read a typical Code 39 label.
Figure 7. Code 39 Bar Code Sample
Tes t
Figure 8. Scanner Labeling
CLASS No.
SERIAL No.
MFG. DATE:
Complies with 21CFR 1040
ACN
and part 15 of FCC Rules.
073200496
Applicable patents are listed
on label inside unit.
CAUTION—LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO BEAM.
T
T
E
D
F
R
O
M
T
H
I
S
D
E
V
Other patents pending
I
C
E
.
Figure 8 above shows label placement ONLY. For
actual regulatory, patent and other applicable information, view the labels on the product itself, or call
NOTE
your nearest sales or service representative.
12PowerScan™ Scanner
Laser Cautions
The PowerScan bar code scanner is certified in the U.S. to conform to
the requirements of DHHS/CDRH 21CFR Subchapter J for Class II laser products. Class II products are not considered to be hazardous. The
scanner contains a Visible Laser Diode (VLD) at a wavelength of 650-670 nanometers and is designed so that there can be no human access
to harmful levels of laser light during normal operation, user maintenance, or during prescribed service operations.
If the scan pattern is a single dot when depressing
the trigger, discontinue operation and return the
unit to the factory. Exception: When using Marker
Beam Mode a single aiming dot is projected
CAUTION
CAUTION
momentarily.
Do not attempt to open or otherwise service any
components in the optics cavity. Opening or servicing any part of the optics cavity by unauthorized
personnel may violate laser safety regulations.
Radio Frequency Interference
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1.This device may not cause harmful interference, and
2.This device must accept any interference received, including
interference that may cause undesired operation.
This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
Cet appareil numerique de la classe B respecte toutes les exigences du
Reglement sur le material broilleur du Canada.
User’s Guide 13
Troubleshooting
You can isolate problems with your scanning system by performing
these checks (refer to Figure 9):
1.If your scanner ’s cable is designed to receive Power Off the
Terminal (P.O.T.), it will not operate unless it is connected to a
working host terminal that is powered on.
2.Ensure that the interface cable is securely attached to the
host. Consult your technical support manager or refer to
your host system manual to identify the proper connection
for the scanner.
3.If an external power supply is used, verify that it is securely
connected to the interface cable and AC outlet. Also ensure
that the power supply is the correct voltage rating for your
area.
4.Check to see that the interface cable is securely connected at
the scanner handle. Push the connector in to assure that it is
firmly seated. Use a Phillips head screwdriver to ensure that
the screw at the bottom of the scanner is fully tightened (but
do not overtighten).
5.If, after checking all connections, the scanner still fails to
function properly, exchange the power supply with a known
good power supply.
6.Ensure that the scanner's interface type is compatible with
the host terminal by consulting your POS system manual
and/or the PowerScan Scanner Programming Guide
(P/N R44-1840).
7.Verify that the bar codes you are scanning are of satisfactory
quality. Bar code label verifiers are available from your
dealer if you need precise reporting of bar code details. Bar
codes that are damaged (wrinkled, smudged, or torn) may
cause the scanner to read poorly or not at all. If bar code
quality seems to be the problem, check to see if the scanner
will read a known good bar code (see Figure 7). You may also
want to modify the programmable setting for advanced
Quadralogic
titled, Enhanced Scanning for Hard-to-Read Bar Codes).
™ decoding (see the section in this manual
14PowerScan™ Scanner
Figure 9. Troubleshooting the Scanner
7
ON
Programming
Kit
5
531 75790
99
1
6
OFF
5
O
N
O
F
F
4
2
3
User’s Guide 15
NOTES
16PowerScan™ Scanner
DECLARATION OF CONFORMITY
PSC hereby declares that the Equipment specified below has
been tested and found compliant to the following Directives
and Standards:
Directives:EMC 89/336/EEC
Low Voltage 73/23/EEC
Standards:EN55022-B EN60825
EN50082-1 EN60950
Equipment
Type:Bar Code Scanning Equipment
Product:
Charles W. Vanlue
Director, Corporate Quality
PSC, Inc.
959 Terry Street
Eugene, OR 97402
U.S.A.
PowerScan
PowerScan™ LR Bar Code Scanner
PowerScan
™ Bar Code Scanner
™ XLR Bar Code Scanner
Nigel Davis
Vice President
Europe, Middle East & Africa
PSC Bar Code Ltd.
Axis 3, Rhodes Way
Watford, England
WD24YW
UK
