Proxima dp800 Specification Sheet

DP8000

ProjectorNet

PROJECTORNET™READY

Built-in networking for projector control and administration in

feature rich, easy to manage

an intuitive tool that gives you the power to remotely monitor
and manage projectors for improved reliability, increased
security and reduced total cost of ownership

COMPACT DESIGN

Just over 13 pounds, with efficient, unobtrusive
styling for dedicated installations

WHISPER-QUIET PERFORMANCE

3300 max ANSI lumens at less than 38dB
for distraction-free presentations

EXTENSIVE CONNECTIVITY

Accepts virtually any source—VCR,
DVD, PC/Mac, LAN, and DVI

ASK LOGO

DP8000

THE COMPLETE
TECHNOLOGY SOLUTION

The Proxima®DP8000 is the IT solution

for rooms that need a standalone or

network-ready projector that’s easy to

install, set up, and connect for powerful

projection on demand. Ideal for large

rooms, classrooms, training centers,

hotel meeting rooms and conference

venues. Sturdy and compact—nearly

half the size of competitive projectors

with the same features—the DP8000

is an essential part of your corporate

projector lineup, event rental or

institutional resource pool.

PACKED WITH FEATURES

At last, simplicity doesn’t come with

a trade-off. Input source flexibility,

3300 max ANSI lumens, network-

readiness, and native XGA resolution

—without the barriers of complicated

set up. The DP8000 is one of the only

projectors to support HDCP and digital

video through DVI for the best image

quality. RS-232 provides seamless

compatibility with control systems

such as AMX and Crestron, and the

DP8000 has USB and PS/2 for mouse

control. The DP8000 will project

incredible images every time with

950:1 contrast ratio, DVI connectivity

for translation-free digital projection

and an advanced DVDO processor

for amazingly smooth video. Less

than 38dB of audible noise ensures

distraction-free meeting rooms. This

projector is simply the easiest way

to bring feature-packed, high-quality

projection to users with a variety of

applications.

Wired remote + IR

S-Video/Video

Audio Out

Video Audio In

INFOCUS QUALITY VIDEO

An advanced DVDO processor for line

doubling and smooth images gives the

audience a cinema-quality experience

when viewing video. From both the

data and video sources, the rich color

saturation, brightness (3300 max ANSI

lumens) and high contrast ratio

(950:1) deliver an exceptionally stun-

ning display for any large-room applica-

tion. The Digital Visual Interface (DVI)

provides loss-free connections for rich

images in a large format.

Comp VGA + Audio 1

Monitor Out

RS-232 Control

(top) and 2 (bottom)

(Computer 3) and

YPbPr Video + Audio

CONNECT, MANAGE
AND CONTROL OVER
YOUR NETWORK

With InFocus ProjectorNet™software,

IT managers can command and control

the DP8000 over their existing net-

works. Designed as a snap-in to the

®

Microsoft

InFocus ProjectorNet provides unique

control features. Ideal to reduce time

spent needed to manage multiple

projectors and reduce total cost of

ownership (TCO).

Management Console—

ProjectorNet

RGB In

Comp DVI-D + Audio

(Computer 4)

PS/2 Mouse

USB Mouse

installation & integration

TCP/IP Network

InFocus Quality Video

The advanced video processor converts
existing standard definition video from DVD,
videotape, laser disc, satellite or standard
broadcast television to a near high-definition
signal, dramatically improving the video image.

Video Processing

• Motion-adaptive video deinterlacing

• Source adaptive processing

• Film mode detection with 3:2 and
2:2 pull-down

• Source Transition Management provides
seamless transitions between source types

• Auto-dynamic thresholds enable reliable
3:2 pull-down and 2:2 pull-down
detections even with noisy sources

• Motion detection on per-pixel basis

• Four input fields used to determine
contents of each output frame

• Cubic interpolation for pixel calculations

• Diagonal processing reduces artifacts
and distortion

• Low-noise, high-accuracy 10-bit video DACs

installation & integration

DP8000

SERVICE YOU CAN COUNT ON

InFocus Corporation is the worldwide leader

in digital projection. Our dedication to quality

and customer satisfaction is reflected in

service options that will bring you a greater

return on your investment. Most InFocus

Corporation projectors come with a standard

two-year limited factory warranty, including

parts and labor and a 90-day lamp replace-

ment. Our customer support of fers you

unparalleled service and convenience,

whatever your needs.

For service program details in your region,

please visit:

www.infocus.com/service/service_offerings

Ships Standard With:

• Wired/wireless remote control with
mouse control and laser pointer

• AC power cord (US or European)

• PS/2 mouse control cable

• USB cable

• VGA cable

• Standard video cable

• Multiple language user guide

• Quick Start Card

•CD

ORDERING INFORMATION

Model Number

DP8000 For worldwide use

Optional Accessories

• Samsonite

• ATA Shipping Case (CA-ATA-008)

• Digital/Analog Inter face Card
(SP-DVI-CARD)

• Ceiling Mount Kit (SP-CEIL-001)

• PC Guardian
(SP-LOCK)

• 20m wired remote cable (301145)

• Mind Path®PocketPoint RF Remote
(HW-RF-POCKTPNT)

• 50-inch Por table Projection Screen
(A650)

• 60-inch Deluxe Insta-Theatre Screen
(HW-DLXSCRN)

• Replacement Lamp – 1,500 hours

• 50ft VGA Extension Bundle
(SP-VGAEXT-D or SP-VGAEXT-I)

• ProjectorNet Software 5-Seat CD
package (SW-PN-5UD)

• ProjectorNet network adapter and cable
bundle (HW-PN-AC1)

To learn more about ProjectorNet™please
visit www.infocus.com/projectornet

®

Deluxe Travel Case (CASE-801)

®

(SP-LAMP-008)

Projector Cable Lock

TECHNICAL SPECIFICATIONS

Native Resolution • XGA (1024 x 768)
Display Technology • 1.3" polysilicon TFT x 3 with micro lens array
Input Sources • Computer: HD15 x 2 (analog RGB), DVI-D, 5BNC

Output Sources • RGB (HD15), audio (RCA x 2)
Computer Compatibility • SXGA+, SXGA, XGA, SVGA, VGA, Macintosh
Video Compatibility • HDTV (1080i, 720p), NTSC, NTSC 4.43, PAL, SECAM
Brightness • 3300 max ANSI lumens
Brightness Uniformity • 85%
Contrast Ratio • 950:1 full on/full off
Number of Colors • 16.7 million
H-Synch Range • 15 – 100 kHz
V-Synch Range • 43.5 – 130 Hz
Dot Clock • 12 – 165 MHz
Digital Keystone Correction • +/-15°
Projection Lens • f = 47 – 61 mm
Throw Ratio • 1.75 – 2.24:1
Minimum

Projection Distance • 1.1 m
Aspect Ratio • 4:3 native; 5:4, 16:9 supported
Image Size (diagonal) • 30" – 300" (762 mm – 7620 mm)
Projection Methods • Front/rear, ceiling/desktop
Audio • 2 x 2.5-Watt stereo with 20-Watt subwoofer
Control • USB mouse, PS/2 mouse, RS-232
Communication • Onboard TCP/IP networking for projector control
Lamp • 250-Watt UHP, 1500 hours
Dimensions • 12.7" (W) x 5.1" (H) x 13.9" (L)

Weight • 13.2 lbs /6.0 kg
Power Consumption • 400 Watts
Power Supply • 100V – 240V at 50 – 60 Hz
Operating Temperature • 5° – 35° C at sea level (0 – 10,000’); 41° – 95° F
Menu Languages • English, German, French, Spanish, Italian,

Audible Noise • Less than 38dB
Approvals • UL, cUL, CE, FCC Class A,TUV, C-tick, NOM, IRAM
Lamp Warranty • 90 days or 500 hours, whichever comes first
Warranty • Two years parts and labor

(RGBHV, RGB, RGsB), audio x 4 (3.5 mm stereo
mini jack)
Video: YPbPr and RGB Component Video
(via 5BNC), S-Video, Composite Video, audio (RCA x 2)

®

322 mm (W) x 130 mm (H) x 352 mm (L)

Norwegian, Por tuguese, Japanese, Chinese

PROJECTION DISTANCES/IMAGE SIZES

Distance Diagonal Image Image Width Diagonal Image Image Width

3.6' 1.1 m 2' 0.61 m 1.6' 0.49 m 2.57' 0.78 m 2.06' 0.63 m
5' 1.5 m 2.79' 0.85 m 2.23' 0.68 m 3.57' 1.09 m 2.86' 0.87 m

10' 3.0 m 5.58' 1.70 m 4.46' 1.36 m 7.14' 2.18 m 5.71' 1.74 m
15' 4.6 m 8.37' 2.55 m 6.70' 2.04 m 10.71' 3.27 m 8.57' 2.61 m
20' 6.1 m 11.16' 3.40 m 8.93' 2.72 m 14.29' 4.35 m 11.43' 3.48 m
25' 7.6 m 13.95' 4.25 m 11.16' 3.40 m 17.86' 5.44 m 14.29' 4.35 m
30' 9.1 m 16.74' 5.10 m 13.39' 4.08 m 21.43' 6.53 m 17.14' 5.23 m
35' 10.7 m 19.53' 5.95 m 15.63' 4.76 m 25.00' 7.62 m 20.00' 6.10 m

Minimum Image Maximum Image
