PRESENTATION SOLUTIONS

www.infocus.com

1.888.294.6400

Desktop Projector

InFocus Corporation: 27700B SW Parkway Avenue • Wilsonville , Oregon 97070-9215

Phone: 503-685-8888 • 1-800-294-6400 • Fax: 503-685-8887 http://www.infocus.com

In Europe: Strawinskylaan 585. 1077 XX Amsterdam, The Netherlands Phone: (31) 20 579 2000 • Fax: (31) 20 579 2999

In Asia: 238A Thomson Road • #18-01/04 Novena Square Singapore 307684 • Telephone: (65) 6334-9005 • Fax: (65) 6334-4525

User's Guide 010-0410-00

Part No.010-0410-00

DP6870 User's Manual.qxd

Printed in Japan

010-0410-00

QR55041

Liquid Crystal Projector

User's Guide

Thank you for purchasing this liquid crystal projector.

WARNING • Please read the accompanying manual “Safety Instruction" and this user's guide thoroughly to ensure correct usage through

understanding. After reading, store this instruction manual in a safe place for future reference.

NOTE

• The manufacturer assumes no responsibility for any errors that may appear in this manual

• The reproduction, transmission or use of this document or contents is not permitted without express written authority.

TRADEMARK ACKNOWLEDGMENT : PS/2, VGA and XGA are registered trademarks of International Business Machines Corporation. Apple, Mac and ADB are registered trademarks of Apple Computer, Inc. VESA and SVGA are trademarks of the Video Electronics Standard Association. Windows is a registered trademark of Microsoft Corporation. Carefully observe the trademarks and registered trademarks of all companies, even when not mentioned.

CONTENTS

FEATURES .......................................2

BEFORE USE ...................................2

Contents of Package ..............................2

Part Names.............................................3

Loading the Batteries..............................5

INSTALLATION ................................6

Installation of the Projector and Screen

Angle Adjustment ...................................6

Cabling ...................................................7

Power Connection ..................................8

Example of System Setup ......................8

Plug & Play.............................................8

OPERATIONS...................................9

Power ON ..................................................9

Power OFF

Basic Operation....................................10

Setup Menu ..........................................12

Input Menu............................................13

Image Menu..........................................14

Options Menu .......................................15

No Signal Menu....................................16

MAINTENANCE ..............................17

Lamp.....................................................17

Air Filters ..............................................19

Other Maintenance...............................19

• The information in this manual is subject to change without notice.

Page

TROUBLESHOOTING ....................20

OSD Message ......................................20

Indicators Message ..............................21

Symptom ..............................................22

SPECIFICATIONS...........................23

........6

.......................................................................................

TABLES

Table 1. Installation Reference.................6

Table 2. Cabling .......................................7

Table 3. Basic Operation........................10

Table 4. Setup Menu ..............................12

Table 5. Input Menu................................13

..............................................9

Table 6. Image Menu..............................14

Table 7. Options Menu ...........................15

Table 8. No Signal Menu........................16

Table 9. OSD Message ..........................20

Table 10. Indicators Message ................21

Table 11. Symptom ................................22

Table 12. Specifications .........................23

.......................................................................................

For "TECHNICAL" and "REGULATORY NOTICE", see the end of the manual.

ENGLISH

Page

ENGLISH-1

FEATURES

User's Guide (this manual)

Safety Instruction

Quick Start Guide

Product Registration Card

"Technology

Upgarde Program

" Card

"Thank you" Card

Mouse cable

(PS/2)

xxxxxxx

XXXXXX

FEATURES

This liquid crystal projector is used to project various computer signals as well as NTSC / PAL / SECAM video signals onto a screen. Little space is required for installation and large images can easily be realized.

Outstanding Brightness

The UHB lamp and high-efficiency optical system assure a high level of brightness.

Partial Magnification Function

Interesting parts of images can be magnified for closer viewing.

Distortion Correction Function

Distortion-free images are quickly available.

BEFORE USE

Contents of package

Make sure all of the following items are included in the package. If anything is missing, please contact your dealer.

NOTE

• Keep the original packing material for future reshipment.

Projector

(with Lens Cap)

PRESENTATION SOLUTIONS

XXXXXX

www.infocus.com

1.800.294.6400

XXXXXX

Digital RGB Cable

Power Cord

(US Type)

Power Cord

(Europe Type)

Video/Audio Cable

(with white lead)

Batteries

for Remote Control

Transmitter

RGB Cable

Component

Video Cable

(with green lead)

BLANK

STANDBY/ON

LASER

RGB

VIDEO

AUTO

KEYSTONE

MENU SELECT

RESET

POSITION

PinP

FREEZE

MAGNIFY

MUTE

OFF

ZOOMFOCUS

VOLUME

ENGLISH-2

Remote Control

Transmitter

BBBBEEEEFFFFOOOORRRREEEE UUUUSSSSEEEE ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

Part Names

))

ZOOM Button

KEYSTONE Button

STANDBY/ON Button

LAMP Indicator

POWER Indicator

Remote Control Sensor

Lens

Filter Cover

( Air Filter )

Foot Adjuster

Lens Cap

Remote Control Sensor

Speaker

ZOOM

KEYSTONE INPUT

STANDBY/ON

POWER TEMPLAMP

FOCUS

RESET

Control Panel

(Refer to P.9 "OPERATIONS")

Front/Right View

FOCUS Button

ENGLISH

INPUT Button

MENU Button

RESET Button

TEMP Indicator

Control Panel Ventilation Openings

(exhaust) Carrying Handle Filter cover

Air Filter and Intake

( )

for the Cooling Fan

Foot Adjuster

Terminal Panel

(Refer below)

Power Switch

AC Inlet

(to Power Cord)

DVI Terminal

S-VIDEO Terminal

VIDEO Terminal

AUDIO(MONO)/L

Terminal

AUDIO R Terminal

USB Terminal

Rear/Left View

DVI

S-VIDEO

VIDEO

(MONO)/L

AUDIO

USB

Terminal Panel

COMPO

VIDEO

RGB IN 1 Terminal RGB IN 2 Terminal

RGB IN 2

NENT

RGB OUT

B/PB

R/PR

AUDIO IN AUDIO

RGB 2

RGB 1

DVI

CONTROL

OUT

RGB OUT Terminal

CONTROL Terminal AUDIO IN RGB1/DVI Terminal

AUDIO IN RGB2 Terminal AUDIO OUT Terminal

COMPONENT VIDEO Y Terminal CB/PB Terminal C

R/PR Terminal

ENGLISH-3

BBBBEEEEFFFFOOOORRRREEEE UUUUSSSSEEEE ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

ZOOM

FOCUS

LASER

BLANK

RGB

VIDEO

AUTO

MENU SELECT

KEYSTONE

ESET

FREEZE

PinP

MAGNIFY

POSITION

OFF

VOLUME

MUTE

))

Part Names (continued)

STANDBY/ON Button

VIDEO Button

Disk Pad

BLANK Button LASER Button

RGB Button MOUSE / RIGHT Button

Used to operate the mouse shift function and left click function.

AUTO Button

MENU Button

KEYSTONE Button

RESET Button

MENU SELECT Button

Used to click the left mouse button.

, , , Button

Used to operate the mouse shift function.

POSITION Button

MAGNIFY Button

PinP Button

FREEZE Button

MUTE Button

VOLUME Button

ZOOM Button FOCUS Button

REMOTE CONTROL TRANSMITTER

(Refer to P.9 "OPERATIONS")

These functions work when the mouse control function is activated. Remember, the POSITION,

BLANK ON and MENU ON functions disable the mouse control function.

WARNING • The laser pointer of the remote control transmitter is used in place of a finger or rod. Never look directly into the laser beam outlet or point the laser beam at

other people. The laser beam can cause vision problems.

CAUTION • Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

AVOID EXPOSURE-

LASER RADIATIONS IS

EMITTED FROM THIS

APERTURE

Complies with 21 CFR 1040. 10 and 1040. 11 except for deviations

NOTE

• Do not give the remote control transmitter any physical impact. Take care not to drop.

• Do not place the heavy objects on the remote control transmitter.

• Keep the remote control transmitter away from children and pets.

• Do not wet the remote control transmitter or place it on any wet object.

• Do not place the remote control transmitter close to the cooling fan of the projector.

• Do not disassemble the remote control transmitter.

pursuant to Laser Notice No.50, dated 2001.7.26 SMK CORPORATION 6-5-5 Togoshi Shinagawa-ku, Tokyo, JAPAN 142-8511 MANUFACTURED PLACE OF MANUFACTURER: A

Novemver 2001

CAUTION

LASER RADIATIONDO NOT STARE INTO BEAM MAX. OUTPUT: 1mW WAVE LENGTH

: 650nm

CLASS2 LASER PRODUCT

LASER RADIATION

DO NOT STARE INTO BEAM

CLASS2 LASER PRODUCT MAX. OUTPUT: 1mW WAVE LENGTH: 650nm

IEC60825-1 :1993+A1:1997

ENGLISH-4

Used to click the right mouse button.

BBBBEEEEFFFFOOOORRRREEEE UUUUSSSSEEEE ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Loading the Batteries

Install the AA batteries into the remote control transmitter.

1. Remove the battery cover. Push the knob while lifting up the battery cover.

2. Load the batteries. Make sure the plus and minus poles are correctly oriented.

3. Close the battery cover.

CAUTION • Use only the specified batteries with this remote control transmitter. Also, do not mix new and old batteries. This could cause battery

cracking or leakage, which could result in fire or personal injury.

• When loading the batteries, make sure the plus and minus terminals are correctly oriented as indicated in the remote control transmitter. Incorrect orientation could cause battery cracking or leakage, which could result in personal injury or pollution of the surrounding environment.

• When you dispose the battery, you should obey the law in the relative area or country.

• Keep the battery away from children and pets.

• When not to be used for an extended period, remove the batteries from the

remote control transmitter.

ENGLISH

NOTE

Replace the batteries when remote control transmitter operation becomes difficult.

ENGLISH-5

INSTALLATION

Installation of the Projector and Screen

Refer to the drawing and table below for determining the screen size and projection distance.

The projection distances shown in the table below are for full size (1024 x 768 dots).

a: Distance from the projector to the screen. (±10%) b: Distance from the lens center to the bottom of the

screen. (±10%)

Table 1. Installation Reference

Screen size [inches (m)]

40 (1.0) 55 (1.4) 73 (1.9) 1 (3) 60 (1.5) 85 (2.2) 114 (2.9) 2 (4)

80 (2.0) 114 (2.9) 151 (3.8) 2 (6) 100 (2.5) 144 (3.7) 191 (4.9) 3 (7) 120 (3.0) 176 (4.5) 231 (5.9) 3 (9) 150 (3.8) 220 (5.6) 282 (7.2) 4 (11)

200 (5.0) 291 (7.4) 386 (9.8) 6 (15)

CAUTION • Install the projector in a suitable environment according to instructions of the accompanying manual “Safety instruction” and this manual.

• When you fix this unit with a metal tool and the like, you must connect it with ground wire; otherwise, fire or electric shock can result. Connect the ground terminal of AC inlet of this unit with the ground terminal provided at the building using an optional three-core power-supply cord.

• Please basically use liquid crystal projector at the horizontal position. If you use liquid crystal projector by the lens up position, the lens down position and the side up position, this may cause the heat inside to build up and cause damage. Be especially careful not to install it with ventilation holes blocked.

• Do not install LCD projector in smoke effected environment. Smoke residue may buildup on critical parts (i.e.LCD panel, Lens Assy etc.).

a [inches (m)]

Min. Max.

[inches (cm)]

Screen

Lens center

Top View

Side View

Angle Adjustment

Use the foot adjusters on the bottom of the projector to adjust the projection angle. It is variable within 0˚ to 9˚ approximately.

1. Lift up the front side of the projector, and pressing the foot adjuster button, adjust the projection angle.

2. Release the button to lock at the desired angle.

3. Use the foot adjusters for fine adjustment. Do not force the adjuster screws. This could damage the adjusters or cause the lock to fail.

CAUTION • Do not release the foot adjuster button unless the projector is being held; otherwise, the projector could overturn or fingers could get

caught and cause personal injury.

ENGLISH-6

Foot Adjusters

Variable within the range of approximately 0° - 9°

IIIINNNNSSSSTTTTAAAALLLLLLLLAAAATTTTIIIIOOOONNNN ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Cabling

Refer to the table below for connecting each terminal of the projector to a device.

Table 2. Cabling

Function Terminal Cable

Analog RGB input

Analog RGB output RGB OUT

Digital RGB input DVI DVI cable with inch thread screws

Audio input (from the computer)

PS/2 mouse control

ADB mouse control ADB mouse cable

Serial mouse control Serial mouse cable

RS-232C communication RS-232C cable USB mouse control USB USB cable

S-video input S-VIDEO S-video cable with mini DIN 4-pin jack

Video input VIDEO Video/Audio cable

Component video input

Audio input (from video equipment)

Audio output AUDIO OUT Audio cable with stereo mini jack

RGB IN 1 RGB IN 2

AUDIO IN [RGB 1] / [DVI]

(interlocked with RGB IN 1 or DVI)

AUDIO IN [RGB 2]

(interlocked with RGB IN 2)

CONTROL

COMPONENT VIDEO Y

/PB COMPONENT VIDEO CR/PR AUDIO (MONO)/L AUDIO R

RGB cable with D-sub 15-pin shrink jack and inch thread screws

Audio cable with stereo mini jack

PS/2 mouse cable

Component Video cableCOMPONENT VIDEO CB

Video/Audio cable or Audio cable with RCA jack

ENGLISH

CAUTION • Incorrect connecting could result in fire or electrical shock. Please read this manual and the separate “Safety Instruction”.

• Before connecting, turn off to all devices to be connected, except for the USB cable.

• The cables may have to be used with the core set to the projector side. Use the cables which are included with the projector or specified.

NOTE

projector is compatible with the device.

• Secure the screws on the connectors and tighten.

• For some RGB input modes, the optional Mac adapter is necessary.

• To select the DVI input, the computer may need some settings. See the manuals of the computer for details.

• Some computers may have multiple display screen modes. Use of some of these modes will not be possible with this projector.

• Refer to the “TECHNICAL” section for the pin assign of connectors and RS-232C communication data.

• When the DVI terminal is used, the RGB OUT terminal may not function.

• Before connecting, read instruction manuals of the devices to be connected, and make sure that the

ENGLISH-7

IIIINNNNSSSSTTTTAAAALLLLLLLLAAAATTTTIIIIOOOONNNN ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Power Connection

Use the correct power cord depending on the power outlet to be used. Connect the AC inlet of the projector to the power outlet firmly by the power cord.

CAUTION • Be carful in handling the power

cord according to instructions of the accompanying manual "Safety Instruction" and this manual.

• Connect the power cord firmly. Avoid using a loose, unsound outlet or failed contact.

Example of System Setup

Computer

(desktop type)

S-Video Tape Recorder

DIGTAL

S-VIDEO

COMPO

NENT

VIDEO

(MONO)/L

AUDIO

USB

RGB OUT

AUDIO IN AUDIO

B/PB

RGB 1 DIGITAL

CR/PR

RGB IN 2

RGB 2

CONTROL

Power outlet

AC Inlet

Power Cord

Computer

(notebook type)

Display Monitor

OUT

Speaker with amplifier

NOTE

DVD Player

• When connecting with a notebook computer, set the proper RGB external image output

Computer (desktop type)

(setting CRT display or simultaneous display of LCD and CRT). Please read instruction manual of the notebook for more information.

Plug & Play

This projector is VESA DDC 1/2B compatible. Plug & play is possible by connecting to a computer that is VESA DDC (Display Data Channel) compatible. Please use this function by connecting the RGB cable with RGB IN 1 terminal (DDC 1/2B compatible), or by connecting a DVI cable with DVI terminal (DDC 2B compatible). Plug & play may not operate by other connections.

NOTE

display and an operating system.

• This projector is recognized as a plug & play monitor. Use the standard display drivers.

• Plug & play may not operate by the computer to connect. Use the RGB IN 2 terminal if plug & play does not operate correctly.

ENGLISH-8

• Plug & play is a system configured with peripheral equipment including a computer,

OPERATIONS

POWER Indicator

FOCUS button

Power Switch

STANDBY/ON Button

ZOOM button

STANDBY/

ON Button

STANDBY/ON

POSITION

VIDEO

AUTO

MENU SELECT

MAGNIFY

LASER

FREEZE

OFF

BLANK

RGB

KEYSTONE

RESET

PinP

MUTE

FOCUS button

ZOOMFOCUS

VOLUME

Lens cap

ZOOM button

Power ON

1. Check that the power cord is connected correctly.

2. Set the power switch to [ | ]. The standby mode is selected, and the POWER indicator is turned to orange.

3. Press the STANDBY/ON button on the control panel or the remote control transmitter. Warm-up begins and the POWER indicator blinks in green.

4. The POWER indicator ceases blinking and turns to green when power is on. Remove the lens cap.

5. Adjust picture size using the ZOOM button.

6. Adjust focus using the FOCUS button .

Power OFF

1. Press the STANDBY/ON button on the control panel or the remote control transmitter. Then, the message "Power off?" will appear on the screen, and the message will disappear by any operation or no operation for 5 seconds. During this message indication, press the STANDBY/ON button again. The projector lamp is extinguished and lamp cooling begins. The POWER indicator blinks orange during lamp cooling. Pressing the STANDBY/ON button has no effect while the POWER indicator is blinking.

2. The system assumes the Standby mode when cooling is complete, and the POWER indicator ceases blinking and changes to orange. Check that the indicator is orange and set the Power switch to [

3. The POWER indicator is extinguished when power is off. Attach the lens cap.

WARNING • Please read this manual, and the separate "Safety Instruction" Ithoroughly before using the equipment. Always ensure that the equipment

is used safely.

ENGLISH

NOTE

• Except in emergencies, follow the above-mentioned procedure for turning power off.

If the projector is used improperly, it may be very difficult to turn off the projector caused by heating inside the unit. And the reduction of life time of lamp and LCD panels will be caused by incorrect procedure.

• To prevent any trouble, turn on/off the projector when the computer or video tape recorder is OFF. Providing a RS-232C cable is connected, turn on the computer before the projector.

• When a projector continues projecting the same image, the image may remain as an afterimage. Please do not project the image same for a long time.

ENGLISH-9

OOOOPPPPEEEERRRRAAAATTTTIIIIOOOONNNNSSSS ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

OFF

))

Basic Operation

The basic operations shown in Table 3 is performed from the supplied remote control transmitter or the projector control panel. Items indicated by (*) may be used from the control panel.

Table 3 . Basic Operation

Item Description

Select Input Signal (*) : Press the INPUT button.

RGB IN 1 → RGB IN 2 → DVI → VIDEO → S-VIDEO → COMPONENT VIDEO (→ RGB IN 1)

Select RGB Input : Press the RGB button.

INPUT SELECT

POSITION

RESET (*)

MAGNIFY

FREEZE

VIDEO/S-VIDEO/COMPONENT VIDEO → RGB IN 1/RGB IN 2/DVI RGB IN 1 → RGB IN 2 → DVI (→ RGB IN 1)

Select Video Input : Press the VIDEO button.

RGB IN 1/RGB IN 2/DVI → VIDEO/S-VIDEO/COMPONENT VIDEO VIDEO → S-VIDEO → COMPONENT VIDEO (→ VIDEO)

• The selected signal name is displayed for approximately 3 seconds when the input signal is changed.

Set/Clear Position Adjustment Mode : Press the POSITION button.

The [ ] icon is displayed in the POSITION mode.

Image Position Adjustment: Press the , , and buttons in the POSITION mode.

• Valid only in the MAGNIFY mode with a video signal is input.

• After approximately 10 seconds of inactivity the [ ] icon is extinguished and the

POSITION mode is cleared automatically.

• , , and

buttons may operate as the mouse control button. Refer to page 4.

Initialize Each Item : Select an item and press the RESET button. Initialize Position Adjustment : Press the RESET button and the

POSITION mode. This function is valid only when RGB signal is input.

• Valid except for the VOLUME, LANGUAGE, WHISPER and H PHASE.

• The RESET button may operate as the mouse control button. Refer to page 4.

Set MAGNIFY Mode : Press the MAGNIFY button. Move Magnified Area : Run the POSITION in the MAGNIFY mode. Adjust Magnification : Press the MAGNIFY / button in MAGNIFY

mode. Clear MAGNIFY Mode : Press the MAGNIFY button.

• The MAGNIFY mode is cleared by running or setting the AUTO, ASPECT, INPUT SELECT or VIDEO, or by changing the input signal.

Set/Clear FREEZE Mode : Press the FREEZE button. The [II] icon is displayed, and the image is frozen, in the FREEZE mode.

• The FREEZE mode is cleared by running or setting POSITION, VOLUME, MUTE, Automatic Adjustment, BLANK ON/OFF, or MENU ON/OFF, or by changing the input signal.

• Do not forget to clear frozen static images.

NOTE

• Use the remote control transmitter at a distance of approximately 5m from the sensor on the front of the projector, and within a range of 30° left-right. Strong light and obstacles will interfere with operation of the remote control transmitter.

ENGLISH-10ENGLISH-10

OOOOPPPPEEEERRRRAAAATTTTIIIIOOOONNNNSSSS ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

Items indicated by (*) may be used from the control panel.

Table 3. Basic Operation (continued)

Item Description

VOLUME

MUTE

AUTO

BLANK ON/OFF

MENU ON/OFF (

MENU SELECT

Volume Adjustment : Press the VOLUME / button. Set/Clear Mute Mode : Press the MUTE button. No sound is heard in the

MUTE mode. Automatic Adjustment at RGB Input : Press the AUTO button. Horizontal

position(H.POSIT), vertical position (V.POSIT),clock phase (H.PHASE), and horizontal size(H.SIZE) are automatically adjusted. Use with the window at maximum size in the application display. Automatic Adjustment at Video Input : Press the AUTO button. A signal type appropriate for the input signal is selected automatically. Valid only when AUTO is set for VIDEO on the menu.

• This operation requires approximately 10 seconds. It may not function correctly with some input signals.

Set/Clear Blank Mode: Press the BLANK button. No image is displayed in the Blank mode. The screen color is as set in BLANK on the Image menu.

Menu Display Start/Stop: Press the MENU button.

• The menu display is terminated automatically after approximately 10 seconds of

inactivity.

Select Menu Type: Press the MENU SELECT button. Allows the user to select the normal menu or the single menu. Only the selected item is displayed on the single menu, and other items are displayed with the and buttons as with the normal menu.

• Valid only when the Setup menu is used. Push the MENU SELECT button after selecting items such as "BRIGHTNESS".

• The MENU SELECT button may operate as the mouse control button. Refer to page 4.

Normal menu Single menu

SETUP INPUT OPT.IMAGE

BRIGHT

CONTRAST

V POSIT H POSIT H PHASE

H SIZE COLOR BAL R COLOR BAL B

ASPECT

-2 100 100

800

0 0

(MENU SELECT)

))

ENGLISH

-2

CONTRAST

P.IN P. MODE

ZOOM (*)

FOCUS (*)

KEYSTONE

Select Mode of P.IN P. Display : Press the PinP button.

→ Large → P.IN P. off (→Small)

Small

• P.IN P. function superimposes a video image over RGB or DVI signals.

Adjust Screen Size : Press the ZOOM / button. Adjust Focus : Press the FOCUS / button.

Set / Clear KEYSTONE Mode : Press the KEYSTONE button. Select KEYSTONE Mode : Press the / button in the KEYSTONE mode.

Vertical ↔ Horizontal Adjust KEYSTONE : Press the / button.

(

• The image may not be appeared properly when this function is activated on some input signals.

• The adjustable range of distortion correction will be different among input signals.

ENGLISH-11

OOOOPPPPEEEERRRRAAAATTTTIIIIOOOONNNNSSSS ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

BRIGHT

CONTRAST

V POSIT

H POSIT

H PHASE

H SIZE COLOR BAL R COLOR BAL B

ASPECT

-2

0 0

100 100

800

SETUP INPUT OPT.IMAGE

BRIGHT

CONTRAST

SHARPNESS

COLOR

TINT

H PHASE COLOR BAL R COLOR BAL B

ASPECT

0 +1 +1

0 +1

SETUP INPUT OPT.IMAGE

Setup Menu

The following adjustments and settings are possible when SETUP is selected at the top of the menu. Part of the Setup menu differs between RGB input and video input. Select an item with the and buttons, and start operation. Use the Single menu to reduce menu size (see Table 3, MENU SELECT).

Table 4. Setup Menu

Item Description

RGB IN 1 RGB IN 2

DVI

))

S-VIDEO

COMPONENT VIDEO

RGB IN 1 RGB IN 2

VIDEO

DVI

VIDEO

S-VIDEO

COMPONENT

BRIGHT

CONTRAST

V POSIT

H POSIT

H PHASE

H SIZE

SHARPNESS

COLOR

TINT

COLOR BAL R

COLOR BAL B

ASPECT

ENGLISH-12ENGLISH-12

Adjustment: Dark ↔ Light

Adjustment: Weak ↔ Strong

Adjustment: Down ↔ Up

Adjustment: Left ↔ Right Adjustment: Left ↔ Right

• Adjust to eliminate flicker.

✔ ✔ ✔

✔

- -

✔

- -

✔

Adjustment: Small ↔ Large

• The image may not be displayed correctly if the horizontal size is excessive. In such cases, press the RESET button, and initialize the horizontal size.

Adjustment: Soft ↔ Clear

Adjustment: Light ↔ Dark Adjustment: Red ↔ Green

• Valid only when NTSC or NTSC 4.43 signal is received.

Adjustment: Light ↔ Dark Adjustment: Light ↔ Dark

✔

- -

✔ ✔ ✔

✔

Select Image Aspect Ratio :

4:3[ ]

Select Position of Image:

↔ 16:9[ ]

✔ ✔

Press the button while 16:9[ ] is selected. Center

→ Down → Up ( → Center )

Select Image Aspect Ratio:

4:3[ ]

↔ 16:9[ ] ↔ 4:3 small[ ]

Select Position of Image :

Press the button while 16:9[ ] / 4:3 small[ ] is selected. Center

→ Down → Up ( → Center )

- -

• 4:3 small cannot be selected with the input of 720P or 1080i component.

• 4:3 small may not be displayed correctly with some input signals.

✔

OOOOPPPPEEEERRRRAAAATTTTIIIIOOOONNNNSSSS ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Input Menu

The following functions are available when INPUT is selected on the menu. Select an item with the and buttons, and start or stop operation with the and buttons. The function indicated (**) are effective on video input mode only, not on RGB input mode, except in the P.IN P. window on RGB input mode.

Table 5. Input Menu

Item Description

Automatic Adjustment at RGB Input: Select the EXECUTE with the button.

Horizontal position (H.POSIT), vertical position (V.POSIT), clock phase (H.PHASE), and horizontal size (H.SIZE) are automatically adjusted. Use with the window at maximum size in the application display.

AUTO

RGB

VIDEO (**)

VIDEO NR

(**)

Progressive

(**)

BLACK(**)

HDTV (**)

Automatic Adjustment at Video Input: Select the signal type appropriate for the input signal is selected automatically when is selected automatically. Valid only when AUTO is set for VIDEO on the menu.

•

This operation requires approximately 10 seconds. It may not function correctly with

some input signals. Pressing the AUTO button in this case may correct this problem.

• This function is the same as for the AUTO function in Basic operation.

Displays RGB Input Frequency: Displays the horizontal and vertical sync signal frequencies for RGB input.

• Valid only at RGB input. Select Video Signal Type: Select the signal type with the and buttons.

Select NTSC, PAL, SECAM, NTSC4.43, M-PAL, or N-PAL as appropriate for the input signal. The selection of AUTO enables and executes the function AUTO (Automatic Adjustment at Video Input), except for the N-PAL input.

• Use this function when the image becomes unstable (eg. the image becomes irregular, or lacks color) at VIDEO/S-VIDEO input.

• Automatic Adjustment requires approximately 10 seconds. It may not function correctly with some input signals. Pressing the AUTO button in this case may correct this problem except for the N-PAL input.

• For the COMPONENT VIDEO input, this function is not effective and the signal type is distinguished automatically. Refer to the item HDTV of the OPT. Menu for the signal of HDTV.

Set/Clear Noise Reduction Mode: Select the TURN ON / TURN OFF with the / button. When the TURN ON is selected, the NR mode is active and the noise on screen of the video input will be reduced.

• Valid except for the HDTV.

Select Progressive Mode: Select the mode suitable for the input signal with the and buttons. The TV mode and the FILM mode convert the interlaced video signal into the progressive signal. The FILM mode is adptable 2-3 Pull-Down system to the conversion.

• Use this function to raise resolution, at the interlaced video input except HDTV signal.

Set/Clear Black Enhancement Mode: Select the TURN ON / TURN OFF with the

/ button. When the TURN ON is selected, the black enhancement mode is active and the contrast ratio of the screen for the video input will be raised by making black level darker.

Select HDTV mode: Select the 1035i mode or 1080i mode suitable for the input signal with the / button.

EXECUTE

SETUP INPUT OPT.

AUTO

RGB

VIDEO

VIDEO NR

Progressive

BLACK

HDTV

with the button. A


EXECUTE CANCEL

EXECUTE

ENGLISH

ENGLISH-13

OOOOPPPPEEEERRRRAAAATTTTIIIIOOOONNNNSSSS ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Image Menu

The following adjustments and settings are available when IMAGE is selected on the menu. Select an item with the and buttons, and start or stop operation with the and buttons.

Table 6. Image Menu

Item Description

Select Blank Screen: Select the screen in case of the BLANK mode with the /

button.The selected one (MyScreen, ORIGIAL or one colors) is displayed when the BLANK mode is ON.

BLANK

START UP

MyScreen

MIRROR

P. IN P. POSIT

P. IN P. INPUT

GAMMA

ENGLISH-14ENGLISH-14

MyScreen is a mode that the customer-customized screen is displayed. This is the blue screen at the factory setting. Refer to the description of MyScreen below. ORIGINAL is a mode that the factory fixed screen is displayed.

• When MyScreen or ORIGIAL is selected, the screen is going to the black after several minutes.

Select Start Up Screen:Select the screen in case of no signal input with the / button. The selected one (MyScreen, ORIGIAL or TURN OFF) is displayed when no signal is input MyScreen is a mode that the customer-customized screen is displayed. This is the blue screen at the factory setting. Refer to the description of MyScreen below.

ORIGINAL is a mode that the factory fixed screen is displayed. TURN OFF displays the blue screen.

• When MyScreen or ORIGIAL is selected, the screen is going to the black after several minutes.

Set MyScreen Mode: Select the EXECUTE with the button to display the MyScreen menu and set the MyScreen mode for BLANK and START UP functions.

ESC clears and closes the menu box. NORM. is default of the MyScreen menu. FREEZE freezes the image and displays the frame to capture.

Press the button after freeze to go to the MyScreen Capture Position mode. In the MyScreen Capture Position mode, the buttons , , and allow to move the frame to capture. After adjusting the position, press the KEYSTONE button to go to the MyScreen Display Size mode. To cancel freezing and return to the NORM. of the MyScreen menu, press the RESET button. In the MyScreen Display Size mode, select the magnification x1, x2 or FULL with the button / . After selecting the magnification, press the KEYSTONE button to go to the CAPT. mode and start capturing. To return to the MyScreen Capture Position mode, press the RESET button. CAPT. executes a capturing the image. It requires about 20 seconds. After capturing, the captured image will be displayed for about 10 seconds.

Select Mirror Status: Select mirror status with / button. Select Position of P. in P. Display : Press the / button.

↔↔↔

• P.IN P. function superimposes a video image over RGB or DVI signals.

Select signal of P. in P. Display : Press the / button.

VIDEO ↔ S-VIDEO ↔ COMPONENT

Select Gamma Mode: Select the gamma mode with the / button.

NORMAL ↔ CINEMA ↔ DYNAMIC

SETUP INPUT OPT.

BLANK

START UP

MyScreen

MIRROR P.IN P. POSIT P.IN P. INPUT

GAMMA


MyScreen ORIGINAL

OOOOPPPPEEEERRRRAAAATTTTIIIIOOOONNNNSSSS ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Options Menu

The following adjustments and settings are available when OPT. is selected on the menu. Select an item with the and buttons, and start operation.

Table 7. Options Menu

Item Description

VOLUME

MENU COLOR

LANGUAGE

AUTO OFF

SYNC ON G

WHISPER

Volume Adjustment: Reduce VOLUME ↔ Increase VOLUME

Select Menu Background Color: Select with the and buttons.

Operation Start/Stop: Press the / button. Select Menu Display Language: Select with the and buttons.

Operation Start/Stop: Press the / button. Set AUTO OFF: Set 1~99 minutes with the and buttons. The

system automatically enters the standby mode when a signal is not received for the set time. Clear AUTO OFF: Select STOP (0 min.) with the button. When STOP is selected the system does not enter the standby mode even if no signal is received.

Operation Start/Stop: Press the / button. SYNC ON G Valid: Select TURN ON with the button. SYNC ON G Invalid: Select TURN OFF with the button.

• May not be displayed correctly with some input signals when SYNC ON G is valid. In such cases, remove the signal connector so that no signal is received, set SYNC ON G to invalid, and reconnect the signal.

Set / Crear WHISPER Mode: Press the / button. When the WHISPER is selected, the WHISPER mode is active. In the WHISPER mode, acoustic noise level from the unit is reduced, and brightness level on screen is a little lower.

SETUP INPUT OPT.

VOLUME

MENU COLOR

LANGUAGE

AUTO OFF

SYNC ON G

WHISPER


ENGLISH

ENGLISH-15

OOOOPPPPEEEERRRRAAAATTTTIIIIOOOONNNNSSSS ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

No Signal Menu

The same adjustments and settings are available with the Image and Options menus when the MENU button is pressed during display of the “NO INPUT IS DETECTED ON ***” or “SYNC IS OUT OF RANGE ON ***” message while no signal is received.

Table 8. No Signal Menu

Item Description

Volume Adjustment: Reduce VOLUME ↔ Increase VOLUME

VOLUME

BLANK

START UP

MIRROR

MENU COLOR

LANGUAGE

AUTO OFF

SYNC ON G

WHISPER

ENGLISH-16ENGLISH-16

• When this function is used, audio input is automatically switched to video. The audio input can be switched by moving the DISK PAD left and right during the display of the volume adjustment bar. The volume adjustment bar is displayed by pressing VOLUME or VOLUME button.

Select Blank Screen: Select the screen in case of the BLANK mode with the / button.The selected one (MyScreen, ORIGIAL or one colors) is displayed when the BLANK mode is ON. MyScreen is a mode that the customer-customized screen is displayed. This is the blue screen at the factory setting. Refer to the description of MyScreen below. ORIGINAL is a mode that the factory fixed screen is displayed.

• When MyScreen or ORIGIAL is selected, the screen is going to the black after several minutes.

ORIGINAL is a mode that the factory fixed screen is displayed. TURN OFF displays the blue screen.

• When MyScreen or ORIGIAL is selected, the screen is going to the black after several minutes.

Operation Start/Stop: Press the / button. Select Mirror Status: Select the mirror status with the and buttons.

Select Menu Background Color: Select the color with the and buttons. Operation Start/Stop: Press the / button.

Select Menu Display Language: Select the language with the and buttons. Operation start/stop: Press the / button.

Set AUTO OFF: Set 1~99 minutes with the and buttons. The system

automatically enters the standby mode when a signal is not received for the set time. Clear AUTO OFF: Select the STOP (0 min.) with the button. When the STOP is selected the system does not enter the standby mode even if no signal is received.

Operation Start/Stop: Press the / button. SYNC ON G Valid: Select the TURN ON with the button. SYNC ON G Invalid: Select the TURN OFF with the button.

• May not be displayed correctly with some input signals when the SYNC ON G is valid. In such cases, remove the signal connector so that no signal is received, set the SYNC ON G to invalid, and reconnect the signal.

VOLUME

BLANK

START UP

MIRROR

MENU COLOR

LANGUAGE

AUTO OFF

SYNC ON G

WHISPER

MAINTENANCE

Lamp

HIGH VOLTAGE

HIGH TEMPERATURE

HIGH PRESSURE

Contact your dealer before replacing the lamp. For the optional lamp, see the item “Option Parts” of the Table 12. Before replacing the lamp, switch power OFF, remove the power cord from the power outlet, and wait approximately 45 minutes until the lamp has cooled. The lamp may explode if handled at high temperatures.

WARNING A mercury lamp used in this LCD projector is made of glass and has high

internal pressure. The mercury lamp can burst with a big noise due to deterioration resulting from a shock, crack and passage of time, and can end its service life in unlit condition. Lamps also have a considerably different service life and can sometimes end up in burst or turn to unlit condition soon after use. Furthermore, when the lamp is blown up, glass fragments can get scattered around the lamp house and some gas containing mercury inside the lamp can leak out of the projector’s air vent.

• Handle the lamp with utmost care as it can burst during use if subjected to a shock or impact or if scratched or cracked.

• Probability for the burst will increase if the lamp is used for extended period of time or used exceeding the period of replacement. You are advised to follow instructions for lamp replacement as soon as they are given (Refer to Table 9 of Page 20, Table 10 of Page 21). Avoid any reuse of an old lamp (used lamp) since such reuse can result in burst.

• In case the lamp gets blown up in a short period of time after use, some electrical failures or troubles other than the lamp itself may be suspected as causes. Under such circumstances, consult the store where you purchased it or a service company.

• Should the lamp burst (accompanied by a big bursting noise), perform ventilation sufficiently, and exercise maximum caution not to inhale any gas out of the projector’s air vent or not to let it enter your eyes or mouth.

• Should the lamp burst (accompanied by a big bursting noise), make absolutely sure to unplug the power cord from the outlet and ask the store where you bought the lamp for immediate replacement. You should not engage in cleanup or replacement of the lamp by yourself since scattered glass fragments can damage the inside of projector or can result in personal injury when you handle it.

• When you dispose of any used lamps, be sure to observe and follow local ordinances and regulations of the area or district where they are subjected to disposal. Generally speaking, the lamps are treated similarly as glasses and bottles in most cases, but there are areas or districts where lamps are classified as a separate collection, and so be sure to use caution.

• Never use the lamp in a state where the lamp cover is removed.

ENGLISH

Lamp Life

Projector lamps have a finite life. The image will become darker, and hues will become weaker, after a lamp has been used for a long period of time. Replace the lamp if the LAMP indicator is red, or the CHANGE THE LAMP message appears when the projector is switched ON. See Table 9 of P.20 and Table 10 of P.21.

NOTE

replacing the lamp, switch power OFF, wait approximately 20 minutes, and switch power ON again. If the LAMP indicator is still red, replace the lamp.

• The LAMP indicator is also red when the lamp unit reaches high temperature. Before

ENGLISH-17

MMMMAAAAIIIINNNNTTTTEEEENNNNAAAANNNNCCCCEEEE ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

Replacing the Lamp

1. Switch the projector OFF, remove the power cord from the power outlet, and wait at least 45 minutes for the unit to cool.

2. Prepare a new lamp.

3. Check that the projector has cooled sufficiently, and gently turn it upside down.

4. Loosen the screw as shown in the diagram, and remove the lamp cover.

5. Loosen the two screws, and gently remove the lamp while holding the grips. Touching the inside of the lamp case may result in uneven coloring.

6. Install the new lamp and tighten the two screws firmly. Also steadily push the opposite side of the screwed lamp into the unit.

7. Replace the lamp cover in position and tighten the screw firmly.

8. Gently turn the projector right-side up.

CAUTION • Ensure that screws are tightened properly. Screws not tightened fully may result

in injury or accidents.

• Do not use the projector with the lamp cover removed.

))

Resetting the Lamp Timer

Reset the lamp timer after replacing the lamp. When the lamp has been replaced after the LAMP indicator is red, or the CHANGE THE LAMP message is displayed, complete the following operation within ten minutes of switching power ON. The power will be turned off automatically in over 10 minutes.

1. Switch power ON, and press the RESET button, for approximately three seconds. The ‘LAMP xxxx hr’ message will appear on the lamp timer on the bottom of the screen.

2. Press the MENU button on the remote control transmitter, or the RESET button on the control panel, while the lamp timer is displayed. The ‘LAMP xxxx then appear.

3. Press the and select 0, and wait until the timer display is cleared.

NOTE

when replacing the lamp. The message functions will not operate properly if the lamp timer is not reset correctly.

• Do not reset the lamp timer without replacing the lamp. Reset the lamp timer always

→ 0 ■ CANCEL’ message will

ENGLISH-18ENGLISH-18

MMMMAAAAIIIINNNNTTTTEEEENNNNAAAANNNNCCCCEEEE ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Air Filters

Cleaning Air Filters

This projector uses 2 air filters. These air filters should be cleaned as described below at intervals of approximately 100 hours.

1. Switch the projector power supply OFF, and remove the

power cord from the power outlet.

2. Remove the filter cover and the air filter.

3. Clean the air filter with a vacuum cleaner.

4. Set the air filter and the filter cover.

Replacing the Air Filter

Replace the air filter if contamination cannot be removed, or if it is damaged.

1. Switch the projector power supply OFF, and remove the power cord from the power outlet.

2. Remove the filter cover and the old filter.

3. Set the new filter and the filter cover.

CAUTION • Switch power OFF and remove the power cord from the power outlet before beginning maintenance work. Please read the separate “Safety

Instruction” thoroughly to ensure that maintenance is performed correctly.

• Replace the air filter if contamination cannot be removed, or if it is damaged. Contact your dealer in such case. For the optional air filter, see the item “Optional Parts” of the Table 12.

• Do not use the equipment with the air filter removed.

• When the air filter is clogged with dust etc. the power supply is switched OFF

automatically to prevent the temperature rising inside the projector.

filter cover

filters

Other Maintenance

Maintenance Inside the Equipment

For safety reasons, ensure that the equipment is cleaned and checked by the dealer once every two years. Maintaining the equipment by yourself is dangerous.

Cleaning the Lens

Gently wipe the lens with lens cleaning paper. Do not touch the lens with your hands.

Cleaning the Cabinet and Remote control transmitter

Gently wipe with a soft cloth. If dirt and stains etc. are not easily removed, use a soft cloth dampened with water, or water and a neutral detergent, and wipe dry with a soft, dry cloth.

ENGLISH

CAUTION • Switch power OFF and remove the power cord from the power outlet before beginning maintenance work. Please read the separate “Safety

Instruction” thoroughly to ensure that maintenance is performed correctly.

• Do not use detergents or chemicals other than those noted above (e.g. benzene or thinners).

• Do not use cleaning sprays.

• Do not rub with hard materials, or tap the equipment.

NOTE

take place on the projection lens and mirror inside, blurring the screen and reducing your eyesight, but do not worry. The condensation will disappear and the screen will return to a normal condition no sooner than the projector acclimates to the surrounding temperature.

• When this projector is brought into a warm room from a cold outdoor, condensation can

ENGLISH-19

TROUBLESHOOTING

OSD Message

The messages as described below may appear on the screen at power ON. Take the appropriate measures when such messages appears.

Table 9. OSD Message

Message Contents

CHANGE THE LAMP

AFTER REPLACING LAMP,

RESET THE LAMP TIME.

CHANGE THE LAMP

AFTER REPLACING LAMP,

RESET THE LAMP TIME.

THE POWER WILL TURN OFF

AFTER ** hr.

CHANGE THE LAMP

AFTER REPLACING LAMP,

RESET THE LAMP TIME.

THE POWER WILL

TURN OFF

AFTER 0 hr.

The usage time of lamp will be reaching 2000 hr shortly.(*2) It is recommended to replace the lamp soon. Prepare a

(*1)

new lamp as a replacement.

The usage time of lamp will be reaching 2000 hr shortly. It is recommended to replace the lamp within * * hours.(*2) It might be happened that the lamp is cut off before * * hr by any chance. Power will be switched OFF automatically in * * hours. Replace the lamp as shown in

(*1)

P.17~18 “Lamp”. Always reset the lamp timer after replacing the lamp.

The usage time of lamp is about to reach. Power will be switched OFF in a few minutes.(*2) Switch power OFF immediately and replace the lamp as shown in P.17 ~18 “Lamp”. Always reset the lamp timer after replacing the lamp.

NO INPUT IS DETECTED

ON ***

SYNC IS OUT OF RANGE

ON ***

CHECK THE AIR FLOW

NOTE

appears every time power is switched ON. (*2) The unit has a function to turn the power off which will be active when the usage time reaches 2000 hr. However the life of lamp might be much different among lamps, so that it might be happened that a lamp is cut off before the function is active.

(*1) This message is cleared automatically after approximately three minutes, and

No input signal found. Check signal input connections and signal sources.

The horizontal or vertical frequency of the input signal is not within the specified range. Check the specifications of the equipment and the signal source.

The internal temperature has risen. Switch power OFF, and wait 20 minutes until the equipment cools. Check the following and Switch power ON again. * Are the ventilation openings blocked. * Is the air filter dirty. * Is the ambient temperature in excess of 35°C.

ENGLISH-20ENGLISH-20

TTTTRRRROOOOUUUUBBBBLLLLEEEESSSSHHHHOOOOOOOOTTTTIIIINNNNGGGG ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Indicators Message

The POWER indicator, LAMP indicator, and TEMP indicator are lit and blank as follows. Take the appropriate measures.

Table 10. Indicators Message

POWER

indicator

Lights

orange

Blinks green

Lights green

Blinks

orange

Lights red

Lights red Turns off

LAMP

indicator

Turns off Turns off The Standby mode has been set.

Turns off Turns off Warming up. Please wait.

Turns off Turns off ON. Normal operation possible.

Turns off Turns off Cooling. Please wait.

Lights

red

Blinks

red

TEMP

indicator

Turns off

Blinks

red

Lights

red

Contents

Lamp is not lit. The interior of the equipment may be too hot. Switch power OFF, wait 20 minutes until the equipment cools, and check whether the ventilation openings are blocked, whether the air filter is dirty, or whether the ambient temperature exceeds 35 °C. And switch power ON again. Replace the lamp if the same problem occurs.

Lamp or lamp cover is not found, or hasn’t been fitted in correctly. Switch power OFF, and wait for 45 minutes until the equipment cools. Check fitting of the lamp and lamp cover, and switch power ON again. Contact your dealer if the same problem occurs again.

The cooling fan is not operating. Switch power OFF, and wait for 20 minutes until the equipment cools. Check for foreign matters in the fan, and switch power ON again. Contact your dealer if the same problem occurs again.

The interior of the equipment is too hot. Switch power OFF, and wait for 20 minutes until the equipment cools. Check whether the ventilation openings are blocked, whether the air filter is dirty, or whether the ambient temperature exceeds 35 °C. Then switch power ON again. Contact your dealer if the same problem occurs again.

ENGLISH

NOTE

for safety reasons, and the indicator is extinguished. Set the power switch to [ minutes until the equipment has cooled sufficiently.

When the internal temperature becomes excessive power is switched OFF automatically

] and wait for 20

ENGLISH-21

TTTTRRRROOOOUUUUBBBBLLLLEEEESSSSHHHHOOOOOOOOTTTTIIIINNNNGGGG ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

Symptom

Before requesting repair, check in accordance with the following chart. If the situation cannot be corrected, then contact your dealer.

Table 11. Symptom

Symptom Possible cause Remedy Page

The power is not turned on.

No video or audio.

Video is present but no audio.

The main power switch is not turned on.

The power cord is disconnected.

The main power was disconnected during operation by the power failure and so on.

The input is not correctly set.

No signal input. Connect correctly.

The projector is not correctly connected.

The volume is set to minimum.

Mute is turned on.

The projector is not correctly connected.

Turn on the main power switch.

Plug the power cord into an AC power outlet.

Turn off the projector with the main power switch (set the power switch to [O]), and wait for about 20 minutes. When the equipment has cooled enough, turn power on.

Use the projector or remote control transmitter to set.

Connect correctly.

Press VOLUME on the remote control or display the menu screen and adjust the volume.

Press the MUTE button.

Connect correctly.

11,15

))

8,9

7,8

Audio is present but no video.

Colors are pale and color matching is poor.

Images are dark.

Video is blurred.

ENGLISH-22ENGLISH-22

The brightness adjustment knob is rotated fully clockwise.

The lens cap is still attached. Remove the lens cap.

Color density and color matching are not correctly adjusted.

Brightness and contrast are not correctly adjusted.

The lamp is nearing the end of its service life.

Focus or H PHASE is out of adjustment.

Select BRIGHT with the MENU button and the press the button.

Adjust the video.

Replace with a new lamp.

Adjust the focus or H PHASE.

9,12

SPECIFICATIONS

Table 12. Specifications

Item Specification

Product name Liquid crystal projector

Liquid crystal panel

Lens Zoom lens F=1.7 ~ 2.3 f=49.0 ~ 64.0 mm

Lamp 275 W UHB

Speaker 1.2 W + 1.2W (Stereo)

Power supply AC100 ~ 120V, 4.7A / AC220 ~ 240V, 2.0A

Power consumption 440W

Temperature range 0 ~ 35°C (Operating)

Size 289 (W) x 144 (H) x 350 (D) mm

Weight (mass) 6.5 kg

RGB signal input

Video signal input

Signal output

Control functions

Optional Parts

NOTE

Panel size 3.3 cm (1.3 type)

Drive system TFT active matrix

Pixels 786,432 pixels (1024 horizontal x 768 vertical)

Video: Analog 0.7Vp-p, 75Ω terminator (positive)

RGB IN

DVI

RGB1

AUDIO IN

VIDEO

S-VIDEO

COMPONENT VIDEO

AUDIO

RGB OUT

AUDIO OUT

CONTROL D-sub 15-pin shrink plug

USB USB jack (B type)

DVI RGB2

L/MONO

H/V. sync.: TTL level (positive/negative) Composite sync.: TTL level

D-sub 15-pin shrink jack

TMDS, DC: 150~1200 mV / AC: 1.56 Vp-p TTL Level (Positive/Negative)

200mVrms, 50 kΩ (max. 3.0Vp-p) Stereo mini jack

1.0Vp-p, 75Ω terminator RCA jack

Brightness signal: 1.0Vp-p, 75Ω terminator Color signal: 0.286Vp-p (burst signal), 75Ω terminator Mini DIN 4-pin jack

Y 1.0 Vp-p, 75 Ω Terminator (Positive) CB/PB 0.7 Vp-p, 75 Ω Terminator (Positive) CR/PR 0.7 Vp-p, 75 Ω Terminator (Positive)

200mVrms, 50 kΩ (max. 3.0Vp-p) RCA jack

Video: Analog 0.7Vp-p, 75Ω output impedance (positive) H/V. sync.: TTL level (positive/negative) Composite sync.: TTL level D-sub 15-pin shrink jack

200mVrms, output impedance 1 kΩ (max. 3.0Vp-p) Stereo mini jack

Lamp: DT00491 Air Filter: MN04531 * For others, consult your dealer.

• This specifications are subject to change without notice.

ENGLISH

ENGLISH-23

ENGLISH-24ENGLISH-24

TECHNICAL

1213

1415

TECHNICAL

Dimension Diagram

395

350

289

308.5

139

144

30.5

Unit : mm

Signal Connector Pin Assignment

1. D-sub 15-pin Shrink Connector (RGB IN 1/RGB IN 2/RGB OUT)

Pin No Signal Pin No Signal Pin No Signal

1 Video input Red 9 -

2 Video input Green 10 Ground RGB IN 2: -

3 Video input Blue 11 - RGB OUT: -

4 -

5 Ground RGB IN 2: -

6 Ground Red RGB OUT: -

7 Ground Green 13

8 Ground Blue 14 Vertical sync

RGB IN 1: SDA(DDC)

H. sync./ Composite sync.

2. Digital Receptacle Connector (DVI)

Pin No Signal Pin No Signal Pin No Signal

1 T.M.D.S. Data 2 - 11 T.M.D.S. Data 1 / 3 Shield 21 -

2 T.M.D.S. Data 2 + 12 - 22 T.M.D.S. Clock Shield

3 T.M.D.S. Data 2 / 4 Shield 13 - 23 T.M.D.S. Clock +

4 - 14 +5V Power 24 T.M.D.S. Clock -

5 - 15

6 DDC Clock 16 Hot-Plug Sense

7 DDC Data 17 T.M.D.S. Data 0 -

8 Analog V. Sync. 18 T.M.D.S. Data 0 +

9 T.M.D.S. Data 1 - 19 T.M.D.S. Data 0 / 5 Shield

10 T.M.D.S. Data 1 + 20 -

Ground (+5V, Analog H/V Sync.)

3. Mini Din 4-pin Connector (S-VIDEO)

Pin No Signal

Color:0.286Vp-p (NTSC, burst signal),75Ω terminator

2 Brightness:1.0Vp-p, 75Ω terminator

3 Ground

4 Ground

0.3Vp-p (PAL/SECAM, burst signal),75Ω terminator

RGB IN 1: SCL(DDC)

123456 78 9 101112131415

17 18 19 20 21 22 23 24

TECHNICAL

TECHNICAL - 1

TTTTEEEECCCCHHHHNNNNIIIICCCCAAAALLLL((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Example of computer signal

Resolution

H ××V

720 × 400

640 × 480

800 × 600

832 × 624

1024 × 768

1152 × 864

1280 × 960

1280 × 1024

1600 × 1200

fH (kHz) fV (Hz) Rating Signal mode

37.9 85.0 VESA TEXT Zoom in

31.5 59.9 VESA VGA (60Hz) Zoom in

35.0 66.7 Mac13"mode Zoom in

37.9 72.8 VESA VGA (72Hz) Zoom in

37.5 75.0 VESA VGA (75Hz) Zoom in

43.3 85.0 VESA VGA (85Hz) Zoom in

35.2 56.3 VESA SVGA (56Hz) Zoom in

37.9 60.3 VESA SVGA (60Hz) Zoom in

48.1 72.2 VESA SVGA (72Hz) Zoom in

46.9 75.0 VESA SVGA (75Hz) Zoom in

53.7 85.1 VESA SVGA (85Hz) Zoom in

49.7 74.5 Mac16"mode Zoom in

48.4 60.0 VESA XGA (60Hz)

56.5 70.1 VESA XGA (70Hz)

60.0 75.0 VESA XGA (75Hz)

68.7 85.0 VESA XGA (85Hz)

67.5 75.0 VESA SXGA (75Hz) Zoom out

60.0 60.0 VESA SXGA (60Hz) Zoom out

64.0 60.0 VESA SXGA (60Hz) Zoom out

80.0 75.0 VESA SXGA (75Hz) Zoom out

75.0 60.0 VESA VXGA (60Hz) Zoom out

Display

mode

NOTE

• Some computers may have multiple display screen modes. Use of some of these modes

will not be possible with this projector.

• Be sure to check jack type, signal level, timing and resolution before connecting this projector to a computer.

• Depending on the input signal, full-size display may not be possible in some cases. Refer to the number of display pixels above.

• The image may not be displayed correctly when the input sync. signal is "Composite Sync." or "Sync. on G".

• The image might be something wrong with computer by computer on the DVI mode. In the case, it is recommended to reduce the resolution and / or reflesh rate.

TECHNICAL - 2

TTTTEEEECCCCHHHHNNNNIIIICCCCAAAALLLL((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

DATA

HSYNC

DATA

VSYNC

))

Initial set signals

The following signals are used for the initial settings. The signal timing of some computer models may be different. In such case, refer to adjust the V.POSIT and H.POSIT of the menu.

Back porch b

Display interval c

Sync a

Computer /

Signal

TEXT 2.0 3.0 20.3 1.0

VGA (60Hz) 3.8 1.9 25.4 0.6

Mac 13"mode 2.1 3.2 21.2 2.1

VGA (72Hz) 1.3 3.8 20.3 1.0

VGA (75Hz) 2.0 3.8 20.3 0.5

VGA (85Hz) 1.6 2.2 17.8 1.6

SVGA (56Hz) 2.0 3.6 22.2 0.7

SVGA (60Hz) 3.2 2.2 20.0 1.0

SVGA (72Hz) 2.4 1.3 16.0 1.1

SVGA (75Hz) 1.6 3.2 16.2 0.3

SVGA (85Hz) 1.1 2.7 14.2 0.6

Mac 16"mode 1.1 3.9 14.5 0.6

XGA (60Hz) 2.1 2.5 15.8 0.4

XGA (70Hz) 1.8 1.9 13.7 0.3

XGA (75Hz) 1.2 2.2 13.0 0.2

XGA (85Hz) 1.0 2.2 10.8 0.5

1152×864 (75Hz)

1280×960 (60Hz)

1280×1024 (60Hz)

1280×1024 (75Hz)

1600×1200 (60Hz)

Horizontal signal timing (µs)

a b c d

1.2 2.4 10.7 0.6

1.0 2.9 11.9 0.9

1.0 2.3 11.9 0.4

1.1 1.8 9.5 0.1

1.2 1.9 9.9 0.4

Front porch d

Back porch b

Display interval c

Sync a

Computer /

Signal

TEXT 3 42 400 1

VGA (60Hz) 2 33 480 10

Mac 13"mode 3 39 480 3

VGA (72Hz) 3 28 480 9

VGA (75Hz) 3 16 480 1

VGA (85Hz) 3 25 480 1

SVGA (56Hz) 2 22 600 1

SVGA (60Hz) 4 23 600 1

SVGA (72Hz) 6 23 600 37

SVGA (75Hz) 3 21 600 1

SVGA (85Hz) 3 27 600 1

Mac 16"mode 3 39 624 1

XGA (60Hz) 6 29 768 3

XGA (70Hz) 6 29 768 3

XGA (75Hz) 3 28 768 1

XGA (85Hz) 3 36 768 1

1152×864 (75Hz)

1280×960 (60Hz)

1280×1024 (60Hz)

1280×1024 (75Hz)

1600×1200 (60Hz)

Vertical signal timimg (lines)

a b c d

3 32 864 1

3 36 960 1

3 38 1024 1

3 46 1200 1

Front porch d

TECHNICAL

TECHNICAL - 3

TTTTEEEECCCCHHHHNNNNIIIICCCCAAAALLLL((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

CLK

DATA

SEL0

RTS

GND

+5V

DATA

GND +5V CLK

678

11 12

))

Connection to the Mouse Control

1. PS/2, ADB or Serial Mouse

(1) Turn off the projector and computer, and connect the two units with the appropriate cable. For

PS/2 mouse control (for IBM and compatible), use the enclosed mouse cable. For others, consult

your dealer. (2) Disconnect the USB cable from the projector if it is connected. Then turn on the projector. (3) Turn on the computer.

Start the mouse function. If the mouse has not been started, reboot the computer (soft reboot or

(4)

reboot buttons). Refer to the descriptions of “DISC PAD” and “MOUSE/RIGHT button” of page 4.

2. USB Mouse

(1) Connect the projector and computer with a suitable commercially available USB cable. Consult

your dealer to get the cable, if you need. (2) Start the mouse function. Refer to the descriptions of “DISC PAD” and “MOUSE/RIGHT

button” of page 4.

NOTE

• Before connecting, read the instruction manuals of the devices to be connected.

• In the case of notebook type computers with an internal pointing device, the mouse control function will not work unless the internal pointing device is disabled. In such case, disable the internal pointing device and change the BIOS setting to select an external mouse before the operations described in (1) to (4) above. Also, some computers may not have a utility program to operate a mouse. Refer to the computer hardware manual for detail.

PS/2 Mouse

CONTROL Terminal

D-sub 15-pin shrink jack

Projector

Computer

TECHNICAL - 4

Mouse jack

Mini DIN 6-pin

TTTTEEEECCCCHHHHNNNNIIIICCCCAAAALLLL((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

—

DATA

GND

—

DATA

GND

234

RTS

GND

+5V

ADB

GND

+5V

(

POWER ON

)

DATA

678

11 12 13

678

11 12 13

))

ADB Mouse

CONTROL Terminal

D-sub 15-pin shrink jack

Serial Mouse

CONTROL Terminal

D-sub 15-pin shrink jack

USB Mouse

USB jack

(B type)

Projector

SEL0

RTS

GND

Projector

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15

USB cable

Computer

1 2 3 4 5 6 7 8 9

Computer CD

RD TD

DTR GND DSR RTS CTS RI

Mouse jack

Mini DIN 4-pin

Mouse jack D-sub 9-pin

USB jack

(A type)

TECHNICAL - 5

TECHNICAL

TTTTEEEECCCCHHHHNNNNIIIICCCCAAAALLLL((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

1213

1415

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15

GND

SELO

RTS

1 2 3 4 5 6 7 8 9

CD RD TD DTR GND DSR RTS CTS RI

2345

))

RS-232C communication

(1) Turn off the projector and computer power supplies and connect with the RS-232C cable. (2) Turn on the computer power supply and, after the computer has started up, turn on the projector

power supply.

Projector Computer

Control jack

D-sub 15-pin shrink jack

Communications setting

19200bps, 8N1

1 Protocol

Consist of header (7 bytes) + command data (6 bytes).

2 Header

BE + EF + 03 + 06 + 00 + CRC_low + CRC_high CRC_low : Lower byte of CRC flag for command data. CRC_high : Upper byte of CRC flag for command data.

3 Command data

Command data chart

byte_0 byte_1 byte_2 byte_3 byte_4 byte_5

Action Type Setting code

low high low high low high

RS-232C jack

D-sub 9-pin

TECHNICAL - 6

Action (byte_0 - 1)

Action Classification Content

1 SET Change setting to desired value.

2 GET Read projector internal setup value.

4 INCREMENT Increment setup value by 1.

5 DECREMENT Decrement setup value by 1.

6 EXECUTE Run a command.

TTTTEEEECCCCHHHHNNNNIIIICCCCAAAALLLL((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Requesting projector status (Get command)

(1) Send the request code Header + Command data (‘02H’+‘00H’+ type (2 bytes) +‘00H’+‘00H’)

from the computer to the projector.

(2) The projector returns the response code ‘1DH’+ data (2 bytes) to the computer.

Changing the projector settings (Set command)

(1) Send the setting code Header + Command data (‘01H’+‘00H’+ type (2 bytes) + setting code (2

bytes)) from the computer to the projector. (2) The projector changes the setting based on the above setting code. (3) The projector returns the response code ‘06H’ to the computer.

Using the projector default settings (Reset Command)

(1) The computer sends the default setting code Header + Command data (‘06H’+‘00H’+ type (2

bytes) +‘00H’+‘00H’) to the projector. (2) The projector changes the specified setting to the default value. (3) The projector returns the response code ‘06H’ to the computer.

Increasing the projector setting value (Increment command)

(1) The computer sends the increment code Header + Command data (‘04H’+‘00H’+ type (2 bytes)

+‘00H’+‘00H’) to the projector. (2) The projector in creases the setting value on the above setting code. (3) The projector returns the response code ‘06H’ to the computer.

Decreasing the projector setting value (Decrement command)

(1) The computer sends the decrement code Header + Command data (‘05H’+‘00H’+ type (2 bytes)

+‘00H’ + ‘00H’) to the projector. (2) The projector decreases the setting value on the above setting code. (3) The projector returns the response code ‘06H’ to the computer.

When a command sent by the projector cannot be understood by the computer

When the command sent by the projector cannot be understood, the error command ‘15H’ is returned by the computer. Some times, the projector ignores RS-232C commands during other works. If the error command ‘15H’ is returned, please send the same command again.

When data sent by the projector cannot be practice

When the command sent by the projector cannot be practiced, the the error code ‘1cH’ +‘xxxxH’ is returned. When the data length is greater than indicated by the data length code, the projector will ignore the excess data code. Conversely, when the data length is shorter than indicated by the data length code, an error code will be returned to the projector.

NOTE

data.

Provide an interval of at least 40ms between the response code and any other code.

•

• The projector outputs test data when the power supply is switched ON, and when the lamp is lit. Ignore this data.

• Commands are not accepted during warm-up.

• Operation cannot be guaranteed when the projector receives an undefined command or

TECHNICAL - 7

TECHNICAL

TTTTEEEECCCCHHHHNNNNIIIICCCCAAAALLLL((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Command data chart

Names Operation type Header

Red BE EF 03 06 00 3B D3 01 00 00 30 00 00

Orange BE EF 03 06 00 AB D2 01 00 00 30 01 00

Green BE EF 03 06 00 5B D2 01 00 00 30 02 00

Blue BE EF 03 06 00 CB D3 01 00 00 30 03 00

Purple BE EF 03 06 00 FB D1 01 00 00 30 04 00

Blank Color

Mirror

Freeze

Menu Color

Startup

Language

Set

White BE EF 03 06 00 6B D0 01 00 00 30 05 00

Black BE EF 03 06 00 9B D0 01 00 00 30 06 00

MyScreen BE EF 03 06 00 FB CA 01 00 00 30 20 00

ORIGINAL BE EF 03 06 00 FB E2 01 00 00 30 40 00

Get BE EF 03 06 00 08 D3 02 00 00 30 00 00

Normal BE EF 03 06 00 C7 D2 01 00 01 30 00 00

H Inverse BE EF 03 06 00 57 D3 01 00 01 30 01 00

Set

V lnverse BE EF 03 06 00 A7 D3 01 00 01 30 02 00

H&V Inverse BE EF 03 06 00 37 D2 01 00 01 30 03 00

Get BE EF 03 06 00 F4 D2 02 00 01 30 00 00

Normal BE EF 03 06 00 83 D2 01 00 02 30 00 00

Set

Freeze BE EF 03 06 00 13 D3 01 00 02 30 01 00

Get BE EF 03 06 00 B0 D2 02 00 02 30 00 00

Red BE EF 03 06 00 7F D3 01 00 03 30 00 00

Orange BE EF 03 06 00 EF D2 01 00 03 30 01 00

Green BE EF 03 06 00 1F D2 01 00 03 30 02 00

Set

Blub BE EF 03 06 00 8F D3 01 00 03 30 03 00

Purple BE EF 03 06 00 BF D1 01 00 03 30 04 00

Transparent BE EF 03 06 00 2F D0 01 00 03 30 05 00

Gray BE EF 03 06 00 DF D0 01 00 03 30 06 00

Get BE EF 03 06 00 4C D3 02 00 03 30 00 00

ORIGINAL BE EF 03 06 00 0B D2 01 00 04 30 00 00

OFF BE EF 03 06 00 9B D3 01 00 04 30 01 00

MyScreen BE EF 03 06 00 CB CB 01 00 04 30 20 00

Get BE EF 03 06 00 38 D2 02 00 04 30 00 00

English BE EF 03 06 00 F7 D3 01 00 05 30 00 00

Français BE EF 03 06 00 67 D2 01 00 05 30 01 00

Deutsch BE EF 03 06 00 97 D2 01 00 05 30 02 00

Español BE EF 03 06 00 07 D3 01 00 05 30 03 00

Italiano BE EF 03 06 00 37 D1 01 00 05 30 04 00

Norsk BE EF 03 06 00 A7 D0 01 00 05 30 05 00

Nederlands BE EF 03 06 00 57 D0 01 00 05 30 06 00

Português BE EF 03 06 00 C7 D1 01 00 05 30 07 00

Japanese BE EF 03 06 00 37 D4 01 00 05 30 08 00

Get BE EF 03 06 00 C4 D3 02 00 05 30 00 00

CRC Action Type Setting code

Command data

TECHNICAL - 8

TTTTEEEECCCCHHHHNNNNIIIICCCCAAAALLLL((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Command data chart

Names Operation type Header

Get BE EF 03 06 00 7C D2 02 00 07 30 00 00

Magnify

Auto off

Brightness Reset Execute BE EF 03 06 00 58 D3 06 00 00 70 00 00

Contrast Reset Execute BE EF 03 06 00 A4 D2 06 00 01 70 00 00

V.Position Reset Execute BE EF 03 06 00 E0 D2 06 00 02 70 00 00

H.Position Reset Execute BE EF 03 06 00 IC D3 06 00 03 70 00 00

H.Size Reset Execute BE EF 03 06 00 68 D2 06 00 04 70 00 00

Color Balance R Reset Execute BE EF 03 06 00 94 D3 06 00 05 70 00 00

Color Balance B Reset Execute BE EF 03 06 00 D0 D3 06 00 06 70 00 00

Sharpness Reset Execute BE EF 03 06 00 C4 D0 06 00 09 70 00 00

Color Reset Execute BE EF 03 06 00 80 D0 06 00 0A 70 00 00

Tint Reset Execute BE EF 03 06 00 7C D1 06 00 0B 70 00 00

Keystone_V Reset Execute BE EF 03 06 00 08 D0 06 00 0C 70 00 00

Keystone_H Reset Execute BE EF 03 06 00 98 D8 06 00 20 70 00 00

Auto Execute BE EF 03 06 00 91 D0 06 00 0A 20 00 00

Blank on/off

Error Status Get

Power

Input Source

Volume

Increment BE EF 03 06 00 1A D2 04 00 07 30 00 00

Decrement BE EF 03 06 00 CB D3 05 00 07 30 00 00

Get BE EF 03 06 00 08 86 02 00 10 31 00 00

Increment BE EF 03 06 00 6E 86 04 00 10 31 00 00

Decrement BE EF 03 06 00 BF 87 05 00 10 31 00 00

off BE EF 03 06 00 FB D8 01 00 20 30 00 00

Set

on BE EF 03 06 00 6B D9 01 00 20 30 01 00

Get BE EF 03 06 00 C8 D8 02 00 20 30 00 00

BE EF 03 06 00 D9 D8 02 00 20 60 00 00

(Example of Return) 00 00 01 00 02 00 03 00 (Normal) (Cover-error) (Fan-error) (Lamp-error)

04 00 05 00 06 00 (Temp-error) (Air flow-error) (Lamp-Time-over)

OFF

Set

Get

RGB1 BE EF 03 06 00 FE D2 01 00 00 20 00 00

RGB2 BE EF 03 06 00 3E D0 01 00 00 20 04 00

Digital BE EF 03 06 00 0E D2 01 00 00 20 03 00

Set

Video BE EF 03 06 00 6E D3 01 00 00 20 01 00

SVideo BE EF 03 06 00 9E D3 01 00 00 20 02 00

Component

Get BE EF 03 06 00 CD D2 02 00 00 20 02 00

Get BE EF 03 06 00 31 D3 02 00 01 20 00 00

Increment BE EF 03 06 00 57 D3 04 00 01 20 00 00

Decrement BE EF 03 06 00 86 D2 05 00 01 20 00 00

BE EF 03 06 00 2A D3 01 00 00 60 00 00 BE EF 03 06 00 BA D2 01 00 00 60 01 00

BE EF 03 06 00 19 D3 02 00 00 60 00 00

BE EF 03 06 00 AE D1 01 00 00 20 05 00

CRC Action Type Setting code

Command data

TECHNICAL - 9

TECHNICAL

TTTTEEEECCCCHHHHNNNNIIIICCCCAAAALLLL((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Command data chart

Names Operation type Header

Normal BE EF 03 06 00 46 D3 01 00 02 20 00 00

Mute

Brightness

Contrast

Color

Balance R

Color

Balance B

Keystone_V

Keystone_H

Aspect

Display

Position at

16 : 9 or Small

V.Position

H.Position

H.Size

H.Phase

Set

Mute BE EF 03 06 00 D6 D2 01 00 02 20 01 00

Get BE EF 03 06 00 75 D3 02 00 02 20 00 00

Get BE EF 03 06 00 89 D2 02 00 03 20 00 00

Increment BE EF 03 06 00 EF D2 04 00 03 20 00 00

Decrement BE EF 03 06 00 3E D3 05 00 03 20 00 00

Get BE EF 03 06 00 FD D3 02 00 04 20 00 00

Increment BE EF 03 06 00 9B D3 04 00 04 20 00 00

Decrement BE EF 03 06 00 4A D2 05 00 04 20 00 00

Get BE EF 03 06 00 01 D2 02 00 05 20 00 00

Increment BE EF 03 06 00 67 D2 04 00 05 20 00 00

Decrement BE EF 03 06 00 B6 D3 05 00 05 20 00 00

Get BE EF 03 06 00 45 D2 02 00 06 20 00 00

Increment BE EF 03 06 00 23 D2 04 00 06 20 00 00

Decrement BE EF 03 06 00 F2 D3 05 00 06 20 00 00

Get BE EF 03 06 00 B9 D3 02 00 07 20 00 00

Increment BE EF 03 06 00 DF D3 04 00 07 20 00 00

Decrement BE EF 03 06 00 0E D2 05 00 07 20 00 00

Get BE EF 03 06 00 E9 D0 02 00 0B 20 00 00

Increment BE EF 03 06 00 8F D0 04 00 0B 20 00 00

Decrement BE EF 03 06 00 5E D1 05 00 0B 20 00 00

4:3 BE EF 03 06 00 9E D0 01 00 08 20 00 00

16:9 BE EF 03 06 00 0E D1 01 00 08 20 01 00

Small BE EF 03 06 00 FE D1 01 00 08 20 02 00

Get BE EF 03 06 00 AD D0 02 00 08 20 00 00

Default BE EF 03 06 00 62 D1 01 00 09 20 00 00

Bottom BE EF 03 06 00 F2 D0 01 00 09 20 01 00

Top BE EF 03 06 00 02 D0 01 00 09 20 02 00

Get BE EF 03 06 00 51 D1 02 00 09 20 00 00

Get BE EF 03 06 00 0D 83 02 00 00 21 00 00

Increment BE EF 03 06 00 6B 83 04 00 00 21 00 00

Decrement BE EF 03 06 00 BA 82 05 00 00 21 00 00

Get BE EF 03 06 00 F1 82 02 00 01 21 00 00

Increment BE EF 03 06 00 97 82 04 00 01 21 00 00

Decrement BE EF 03 06 00 46 83 05 00 01 21 00 00

Get BE EF 03 06 00 B5 82 02 00 02 21 00 00

Increment BE EF 03 06 00 D3 82 04 00 02 21 00 00

Decrement BE EF 03 06 00 02 83 05 00 02 21 00 00

Get BE EF 03 06 00 49 83 02 00 03 21 00 00

Increment BE EF 03 06 00 2F 83 04 00 03 21 00 00

Decrement BE EF 03 06 00 FE 82 05 00 03 21 00 00

CRC Action Type Setting code

Command data

TECHNICAL - 10

TTTTEEEECCCCHHHHNNNNIIIICCCCAAAALLLL((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Command data chart

Names Operation type Header

Get BE EF 03 06 00 F1 72 02 00 01 22 00 00

Sharpness

Color

Tint

Video Format

Video NR

Progressive

Black

HDTV

PinP Size

Increment BE EF 03 06 00 97 72 04 00 01 22 00 00

Decrement BE EF 03 06 00 46 73 05 00 01 22 00 00

Get BE EF 03 06 00 B5 72 02 00 02 22 00 00

Increment BE EF 03 06 00 D3 72 04 00 02 22 00 00

Decrement BE EF 03 06 00 02 73 05 00 02 22 00 00

Get BE EF 03 06 00 49 73 02 00 03 22 00 00

Increment BE EF 03 06 00 2F 73 04 00 03 22 00 00

Decrement BE EF 03 06 00 FE 72 05 00 03 22 00 00

Auto BE EF 03 06 00 9E 75 01 00 00 22 0A 00

NTSC BE EF 03 06 00 FE 71 01 00 00 22 04 00

PAL BE EF 03 06 00 6E 70 01 00 00 22 05 00

Set

SECAM BE EF 03 06 00 6E 75 01 00 00 22 09 00

NTSC 4.43 BE EF 03 06 00 5E 72 01 00 00 22 02 00

M-PAL BE EF 03 06 00 FE 74 01 00 00 22 08 00

N-PAL BE EF 03 06 00 0E 71 01 00 00 22 07 00

Get BE EF 03 06 00 0D 73 02 00 00 22 00 00

off BE EF 03 06 00 B6 73 01 00 06 22 00 00

on BE EF 03 06 00 26 72 01 00 06 22 01 00

Get BE EF 03 06 00 85 73 02 00 06 22 00 00

off BE EF 03 06 00 4A 72 01 00 07 22 00 00

TV BE EF 03 06 00 DA 73 01 00 07 22 01 00

FILM BE EF 03 06 00 2A 73 01 00 07 22 02 00

Get BE EF 03 06 00 79 72 02 00 07 22 00 00

off BE EF 03 06 00 5E 71 01 00 08 22 00 00

on BE EF 03 06 00 CE 70 01 00 08 22 01 00

Get BE EF 03 06 00 6D 71 02 00 08 22 00 00

1080i BE EF 03 06 00 F2 73 01 00 05 22 00 00

1035i BE EF 03 06 00 62 72 01 00 05 22 01 00

Get BE EF 03 06 00 C1 73 02 00 05 22 00 00

off BE EF 03 06 00 FE 22 01 00 00 23 00 00

Large BE EF 03 06 00 6E 23 01 00 00 23 01 00

Small BE EF 03 06 00 9E 23 01 00 00 23 02 00

Get BE EF 03 06 00 Cd 22 02 00 00 23 00 00

Command data

CRC Action Type Setting code

TECHNICAL - 11

TECHNICAL

TTTTEEEECCCCHHHHNNNNIIIICCCCAAAALLLL((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Command data chart

Names Operation type Header

Upper left BE EF 03 06 00 02 23 01 00 01 23 00 00

Upper right BE EF 03 06 00 92 22 01 00 01 23 01 00

Set

PinP Position

PinP Audio ch

PinP Input

FOCUS

Zoom

Sync on G

WHISPER

GAMMA

bottom left BE EF 03 06 00 62 22 01 00 01 23 03 00

bottom right BE EF 03 06 00 F2 23 01 00 01 23 02 00

Get BE EF 03 06 00 31 23 02 00 01 23 00 00

Set

RGB BE EF 03 06 00 BA 22 01 00 03 23 00 00

Video BE EF 03 06 00 2A 23 01 00 03 23 01 00

Get BE EF 03 06 00 89 22 02 00 03 23 00 00

Video BE EF 03 06 00 D6 22 01 00 02 23 01 00

S-Video BE EF 03 06 00 26 22 01 00 02 23 02 00

Component BE EF 03 06 00 16 20 01 00 02 23 05 00

Get BE EF 03 06 00 75 23 02 00 02 23 00 00

Increment BE EF 03 06 00 6A 93 04 00 00 24 00 00

Decrement BE EF 03 06 00 BB 92 05 00 00 24 00 00

Increment BE EF 03 06 00 96 92 04 00 01 24 00 00

Decrement BE EF 03 06 00 47 93 05 00 01 24 00 00

off BE EF 03 06 00 CB D0 01 00 08 30 01 00

on BE EF 03 06 00 5B D1 01 00 08 30 00 00

Get BE EF 03 06 00 68 D1 02 00 08 30 00 00

NORMAL BE EF 03 06 00 3B 23 01 00 00 33 00 00

WHISPER BE EF 03 06 00 AB 22 01 00 00 33 01 00

Get BE EF 03 06 00 08 23 02 00 00 33 00 00

NORMAL BE EF 03 06 00 C7 F0 01 00 A1 30 00 00

CINEMA BE EF 03 06 00 57 F1 01 00 A1 30 01 00

DYNAMIC BE EF 03 06 00 A7 F1 01 00 A1 30 02 00

6500K BE EF 03 06 00 37 F0 01 00 A1 30 03 00

Get BE EF 03 06 00 F4 F0 02 00 A1 30 00 00

Command data

CRC Action Type Setting code

TECHNICAL - 12

REGULATORY NOTICES

EN 55022 Warning

This is a Class A product. In a domestic environment it may cause radio

This is a Class A product. In a domestic environment it may cause radio interference, in which case the user may be required to take adequate measures.

interference, in which case the user may be required to take adequate measures. The typical use is in a conference room, meeting room or auditorium.

The typical use is in a conference room, meeting room or auditorium.

FCC Statement Warning

WARNING:

for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits

for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference

are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment

when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed

generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful

and used in accordance with the instruction manual, may cause harmful interference to radio communications, Operation of this equipment in a

interference to radio communications, Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will

residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

be required to correct the interference at his own expense.

INSTRUCTIONS TO USERS:

FCC (Federal Communication Commission) Class A equipments provided that

FCC (Federal Communication Commission) Class A equipments provided that following conditions are met.

following conditions are met. The cables may have to be used with the core set to the projector side. Use the

The cables may have to be used with the core set to the projector side. Use the cables which are included with the projector or specified.

cables which are included with the projector or specified.

This equipment has been tested and found to comply with the limits

This equipment complies with the requirements of

Core

CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

For the Customers in CANADA

NOTICE: This Class A digital apparatus complies with Canadian ICES-003.

Pour les utilisateurs au Canada

AVIS: Cet appareil numérique de la Classe A est conforme à la norme NMB-003 du Canada.

REGULATORY NOTICES - 1

imited Warranty

InFocus Corpor ation (“InFocus”) warrants that the Projector (“Product”) pu rchased from InFocus, an InFocus distributor, or an InFocus reseller will conform to the manufacturer’s specifications and be free from defects in material or workmanship for the Warranty period provided below. InFocus does not warrant that the Product will meet the specific requirement of the end-user customer.

If the Product, which is the subject of this Limited Warranty, is defective in material or workmanship during the warranty period, InFocus,

All exchanged parts and products replaced under this Warranty will become property of InFocus. InFocus’ sole obligation is to supply (or pay for) all labor necessary to repair the Product found to be defective within the Warranty period and to repair or replace defective parts with new parts or, able used parts that are equivalent or superior to new parts performance.

imited

arranty Alternatives:

rants as follows:

・ 2

Year Parts and Labor Product Warranty

will conform to the manufacturer’s specifications and free from defects in material or workmanship for a period of two (2) years.

Year Parts Only Accessory Warranty

・ 1

replaceable and accessory products will conform to the manufacturers’ sp ecific ations and be fr ee from de fects i n material or workmanship for a period of one (1) year.

・ 90

Day/

500 H

our Replacement Lamp Warranty

replacements after the original projector purchases is Ninety (90) days or 500 hours, whichever comes first. During the Warranty period for the Product, InFocus warrants that Replacement lamps, which are purchased at the time of projector purchase, will have a 90-day or 500 hour warranty, whichever comes first, from the date the spare lamp is put into use.

ARRANTY LIMITATION AND EXCLUSION

THIS WARRANTY SETS FORTH INFOCUS’ MAXUMUM LIABILITY FOR ITS PRODUCT. THIS WARRANTY EXTENDS ONLY TO PRODUCTS PURCHASED FROM INFOCUS OR AN INFOCUS AUTHORIZED RESELLAER. I nFocus shall have no further obligation under foregoing Limited Warranty if the Product has been damaged due to abuse, misuse, neglect, smoke exposure (cigarette or otherwise), accident, unusual physical or electrical stress, unauthorized modifications (including use of an unauthorized mount), tampering, alterations, or service other than by InFocus or its authorized agents, causes other than from ordinary use or failure to properly use the Product in the application for which said Product was intended.

This Warranty excludes Product or accessory cleaning, repair, or replacement of plastics due to cosmetic damage and damage as a re sul t of no rmal wear. Product repair outside of the terms of the Limited Warranty will be on a time and material basis. Prolonged Product “demonstration” causes manual Product wear and is not considered normal use under the terms of this Limited Warranty.

The Accessory Warranty covers the accessory items only and excludes normal wear. The Lamp product Warranty excludes expected lamp degradation.

Remanufactured products and Software Products are exempt from the foregoing Limited Warranty. Please refer to the appropriate Remanufactured Product Limited Warranty or Software Product Limited Warranty for applicable Warranty information.

at its option

, will REPAIR or REPLACE the Product.

Subject to the Limitations, Exclusions and Disclaimers, InFocus War-

- From the date of purchase, InFocus warrants that the Product

- From the date of purchase, InFocus warrants that the customer

- Lamp Products purchased in projectors or separately as

DISCLAIMER OF UNSTATED WARRANTIES

THE WARRANTY PRINTED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE ARE DISCLAIMED. THERE ARE NO WA RRA NT IES THAT EXTEND BEYON D T HE D E SCRI PTI ON O N T HE FA CE H EREOF THE FOREGOING WARRANTY SHALL NOT BE EXTENDED, ALTERED OR VARIED EXCEPT BY WRITTEN INSTRUMENT SIGNED BY INFOCUS. SOME JURISDICTION DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY MAY LAST, SO SUCH LIMITATIONS MAY NOT APPLY TO YOU.

at the option of InFocus

, service-

AND

imited

arranty Period

The Limited Warranty period commences on the date of purchase by the end-user customer for both the 2 year Product Warranty and the 1 year Accessory Warranty. These Limited Warranty provisions shall apply only to the end-user purchaser (first person or entity that purchased a new Product for personal or business use and not for the purpose of distribution or resale).

To Be E

InFocus both the date of purchase and that the Product was purchased new. The sales receipt or invoice, showing the date of purchase of the Product or Accessory is the proo f of the date of purchase.

To O

contact 1) InFocus, 2) a service facility authorized by InFocus or 3) the place of original purchase.

freight and all fees prepaid, to an InFocus Service Center or to a service facility authorized by InFocus. When returning Product to InFocus, a Return Material Authorization Number (RMA #) is required and must be clearly displayed on the outside of the shipping carton or similar package affording an equal degree of protection. In Focus or the service faci lity authorized by InFocu s will return the repaire d/replaced Product freight prepaid to the purchaser.

the problem; (ii) provides proof of date of purchase; (iii) provides the dealer’s name; and (iv) provides the model and serial number of the Product. Upon request of InFocus Corporation or an authorized repair center for InFocus, proof of legal importation must accompany the warranty repair Product, otherwise the Product must be returned to the place of original purchase, to the manufacturer (Purchaser must bear all tax, duty and freight), or the Purchaser must bear charges for the warranty repair.

the entire Product. Warranty on the repair part and workmanship shall only be effective for a period of ninety (90) days following the repair or replacement of that part or the remaining period of the Product Limited Warranty whichever is greater.

LIMITATION OF LIABILITY

TORT, UNDER ANY WARRANTY, IN NEGLIGENCE OR OTHERWISE SHALL NOT EXCEED THE RETURN OF THE AMOUNT OF THE PURCHASE PRICE PAID BY PURCHASER AND UNDER NO CIRCUMSTANCES SHALL INFOCUS BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGE S OR LOST PROFITS, LOST REVENUES O R LOST SAVINGS. THE PRICE STA TED FOR THE PRODUCTS IS A CONSIDERATION IN LIMITING INFOCUS’ LIABILITY.

the product may be brought by purchaser more than one year after the cause of action has accrued.

governed by Oregon law.

product is subject to mandatory arbitration.

OR CONSEQUENTIAL DAMAGES SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, DEPENDING ON JURISDICTION.

ligible For Limited Warranty Coverage

Any person exercising a claim under Limited Warranty must establish to the satisfaction of

btain Warranty Service

During the Limited Warranty period, to exercise this Limited Warranty, the purchaser must first

InFocus Customer Service – 1-800-799-9911 or techsupport@infocus.com

For Warranty service, the purchaser will be advised to return or deliver the defective Product

Products returned for Warranty service must be accompanied by a written letter that: (i) explains

No repair or replacement of Product or part thereof shall extend the Limited Warranty period as to

IT IS UNDERSTOOD AND AGREED THAT INFOCUS’ LIABILITY WHETHER IN CONTRACT, IN

imitation on Bringing Action

overning Law

andatory Arbitration

– Any action, regardless of form, arising out of the agreement to purchase the product is

SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL

– No action, regardless of form, arising out of the agreement to purchase

– Any action, regardless of form, arising out of the agreement to purchase the

InFocus Corporation („InFocus”) garantiert, dass der von InFocus, einem InFocus-Distributor oder einem InFocus-Wiederverkäu fer erworb ene Proj ektor („Pro dukt” ) den technisc hen Angab en des Herstellers entsp rich t und für die unten angegebene Garantie dauer frei von Material- und Herstellu ngsfehlern is t. InFocus garanti ert nicht, dass das Produkt den spezifischen Anforderungen des Endbenutzerkunden entspricht.

Falls das Produkt, das Gegenstand dieser eingeschränkten Garantie ist, während der Garantiezeit Material- oder

Herstellungsfehler aufweist, wird das Produkt

Alle im Rahmen dieser Garantie ausgetauschten Teile und ersetzten Produkte gehen in das Eigentum von InFocus über. Arbeitsleistun g, die zum Reparier en des Produkts er forderli ch ist, das während der G arantiezei t als mangelha ft festgeste llt wurde, und im Reparieren oder Erset zen mangelhafter Teile durch neue Te ile oder verwendbare gebrauchte Teile, die der Leistung neuer Teile gleichwertig oder besser sind.

mfang der eingeschränkten Garantie: Vorbehaltlich der Einschränkungen und Ausschlüsse garantiert InFocus

Folgendes:

・ 2-Jahre-Produktgara ntie auf Te ile und Arbeitsleistung - InFocus garantie rt für die Dauer von zwei (2) Jahre n ab

・ 1

kundenseitig aus wechselbar e Produkte und Zube hörprodu kte den technische n Angaben des Hers tellers entspr echen un d frei von Material- und Herstellungsfehlern sind.

Die ausschließliche Verpflichtung von InFocus

dem Kaufdatum, dass das Produkt den technischen Angaben des Herstellers entspricht und frei von Material- und Herstellungsfehlern ist.

-Jarr-Zubehörgarantie nur auf Teile - InFocu s ga rant ie rt für die Daue r vo n e ine m ( 1) Jah r a b de m K au fda tu m, dass

nach Ermessen von InFocus

besteht in der Be reitstell ung (bzw. Be zahlung ) der gesamte n

REPARIERT oder ERSETZT.

im Ermessen von InFocus

durch

・ 90-Tage/500-Stunden-Ersatzlampengarantie – Auf Lampenprodukte, die in prokektoren oder gesondert als

Ersatztei le nach dem Originalkauf des projectors erworben wurde n, wird eine G arantie von neunzig (90) Tagen oder 500 Stunden gewährt, je nachdem, was zuerst eintritt. Während der Garantiezeit für das Produkt gewährt InFocus auf die Ersatzlampen, die zusammem mit dem Projektor gekauft wurden, eine Garantiedauer von 90 Tagen oder 500 Stunden, je

Eingeschrankte Garantie

nachdem, was zuerst eintritt, ab dem Datum, an dem die Ersatzlampe eingesetzt wurde.

GARANTIEEINSCHRÄNKUNG UND -AUSSCHLUSS

DIESE GARANTIE LEGT DIE MAXIMALE HAFTUNG SEITENS INFOCUS FÜR INFOCUS-PRODUKTE FEST. DIESE GARANTIE GILT NUR FÜR PRODUKTE, DIE VON INFOCUS ODER EINEM AUTORISIERTEN INFOCUSWIEDERVERKÄUFER ERWORBEN WURDEN. InFocus übernimmt hiermit keine Haftun g, wenn das Produkt aufgrund von Misshandlung, Missbrauch, Fahrlässigkeit, Rauch (Zigarettenrauch oder anderer Rauch), Unfall, ungewöhnlicher physikalischer oder elektrischer Belastung, nicht genehmigten Modifikationen (einschließlich nicht genehmigter Befestigung), unsachgemäßen Ein gri ffen, Änderun gen, Wartun g durch nicht von InFoc us autoris ier te Stellen, Urs achen, die nicht auf normalen Einsatz zurückzuführen si nd, oder Verwendung des Pr odukts in einer nicht für das Produkt bestimmten Anwendung beschädigt wird.

Diese Garantie gilt nicht für die Produkt- bzw. Zubehörreinigung, Reparatur oder den Austausch von Kunststoffteilen aufgrand eines kosmetischen Schadens oder Achäden infolge normaler Abnutzung. Für Produktreparaturen, die nicht im Rahmen der eingeschränkten Garantie durchgeführt werden, werden Zeit- und Material kosten bere chnet. Ein e „Produk tdemons tration” üb er einen längeren Z eitraum verursacht e ine ungewöhnlich hohe Produktabnutzung, die unter den Bedingungen dieser eingesch ränkten Garantie nicht a ls normaler Gebrauch betrachtet wird.

Die Zibehörgarantie gilt nur für das Zubehör und schließt normale Abnutzung aus. Die Lampenproduktgarantie schließt einen erwarteten Qualitätsverlust der Lampe durch Alterun g a u s ..

Wiederaufbereitete Produkte und Softwareprodukte sind von der vorangegangenen eingeschränkten Garantie ausgeschlossen. Die hierfür zutreffenden Garantieinformationen sind in der eingeschränkten Garantie für das wiederaufbereitete Produkt bzw. Das betreffende Softwareprodukt zu finden.

AUSSCHLUSS ODER STILLSCHWEIGENDE GAR ANTIEN

DIE OBEN AUFG E FÜHRTE GARANTIE IST D IE EINZIG GÜLTIGE G A R ANTIE FÜR DIESES PRODUKT. ALLE ANDEREN, GLEICH OB AUSDRÜCKLICH ODER IMPLIZIT GEWÄHRTEN GARANTIEN, EINSCHLIESSLICH, JEDOCH NICHT BESCHRÄNKT AUF DIE IMPLIZITEN GARANTIEN DER MARKTFÄHIGKEIT UND EIGNUNG FÜR EINEN BESTIMMTEN ZWECK, SIND NICHT GÜLTIG. GARANTIEN ERWEITERT UNTERSCHRIEBEN WURDE, ERWEIT ERT ODER GEÄNDERT WERDEN. EINIGE GERICHTSBARKEITEN ER LAUBEN KEINE FRISTEN FÜR GESETZLICHE GEWÄHRLEISTUNGEN. IN DIESEM FALL TRIFFT DIE OBEN AUFGEFÜHRTE EINSCHRÄNKUNG U.U.NICHT AUF SIE ZU.

UND NUR DURCH EINE SCHRIFTLICHE UNTERLAGE, DIE VON INFOCUS

DIE OBIGE GARANTIE KANN NICHT DURCH ANDERE

Dauer der eingeschränkten Grantie

Die Garatiezeit sowohl für die 2- Jah re -P roduktgarantie als auch für die 1-Jahr-Zu behörgarantie beginnt am Tag

des Kaufs durch den Endbenutzerkunden. Die eingeschränkte Garantie gilt nur für Endbenutzerkäufer (erste Person bzw. Organisation, die ein neues Produkt zur persöblichen oder ges chäftlic hen Verwendung und nicht zur Verteilung oder zum Wiederverkauf erwirbt).

nsprüche im Rahmen dieser eingeschränkten Garantie

Jede Person, die einen Anspruch im Rahmen dieser eingeschränkten Garantie geltend macht, muss zur Befriedigun g von InFocus das Kaufdatum n achweise n und beweis en, dass das P rodukt neu ge kauft wurde. Di e Verkaufsquittun g oder Verkaufsrechnu ng mit dem Kaufdatum des Pro dukts oder Zubehörs ist der Na chweis für das Kaufdatum.

nanspruchnahme von Garantieleistungen

Zur Inanspruchnahme von Leistungen während der Garantiezeit muss sich der Käufer zuerst mit 1) InFocus, 2) einer von InFocus a uto ri sier te n Wart un gs stä tt e oder 3 ) de m Hän dle r, be i dem er d as Pro duk t er wor ben hat, in Verb in dun g setzen.

InFocus-Kundendienst – 1-800-799-9911 oder techsupport@infocus.com

Für den Erhalt von Dienstleistungen im Rahmen der Garantie muss der Käufer das fehlerhafte Produkt mit vorausbezahlter Fracht un d vorausbez ahlten G ebühren an ein In Focus-Ser vicecent er oder eine von InFo cus autorisi erte Wartungsstätte einsenden. Bei der Rücksendung des Produkts an InFocus ist eine sogenannte „Return-MaterialAuthorization”- (RMA-) Nummer e rforderlich, die gut leserlich au f der Außenseite des Orig inalkartons oder eines ähnlichen Kartons, der einen gleichwertigen Schutz bietet, angebracht werden muss. InFocus oder die von InFocus autorisierte Wartungsstätte wird das reparierte bzw. Ersetzte Produkt mit vorausbezahlter Fracht an den Käufer zurücksenden.

Produkten, die für Garantieleistun gen eingesendet werden, muss ein Schreiben beigefü gt werden, das (i) das Problem beschrebt, (ii ) den Nachweis für das Kaufdatum ebthält, (iii) den Namen des Händlers enthält und (iv) das Modell und die Seriennu mmer des Produkts angibt. Au f Anfrage von InFocus Corpo ration oder einem von InFocu s autorisierten Reparaturzentrum muss dem zu Garantiezwecken eingesandten Produkt ein Nackweis zur legalen Einfuhr beigele gt werden; andern falls muss das Produ kt zu dem Händler, bei dem das Produkt geka uft wurde, oder zum Hersteller (Käufer übernimmt sämtliche Steuern, Zölle und Frachtkos ten) zurückgesandt werden, oder der Käufer muss die Kosten für die Garantiereparatur übernehmen.

Durch eine Reparatur oder einen Austausch des Produkts oder Teilen davon wird die Garantiezeit des gesamten Produkts nicht ve rlän gert. Di e Garan tie fü r das repa rier te Teil und die He rstel lung gilt nur für ei ne Zeitd auer von neunz ig (90) Tagen nach der Reparatur bzw. Dem Austausch dieses Teils oder die restliche Zeitdauer der Produktgarantie, je nachdem, welcher Zeitraum länger ist. HAFTUNGSEINSCHRÄNKUNG

DIE HAFTUNG SEITENS INFOCUS, GLEICH OB VERTRAGSMÄSSIG, WEGEN UNERLAUBTER HANDLUNG, UNTER EINER GARANTIE, AUS FAHRLÄSSIGKEIT ODER AUS ANDEREN GRÜNDEN, ÜBERSCHREITET NICHT DIE RÜCKERSTATTUNG DES KAUFPREISES AN DEN KÄUFER. INFOCUS ÜBERNIMMT AUF KEINEN FALL DIE HAFTUNG FÜR SPEZIELLE, MITTELBARE, NEBEN- ODER FOLGESCHÄDEN ODER ENTGANGENEN GEWINN, UMSATZVERLUST ODER VERLUST VON ERSPARNISSEN. DER AUFGEFÜHRTE PREIS FÜR DAS P RO DUKT IST EIN FAKTOR B E I DER H AF TU NG SE IN S CHR Ä NKU NG S E ITE NS INFOCUS .

echtsbehelfsfrist – Keine Rechtshandlung, gleich welcher Art, die sich aus Ein kaufsvereinbarung für das Produkt

ergibt, kann vom Käufer nach mehr als einem Jahr nach Entstehendes Klageanspruchs eingebracht werden.

nwendbares Recht – Alle Rechtshandlungen, gleich welcher Art, die sich aus Einkaufsvereinbarung für das Produkt

ergeben, unterliegen den Gesetzen des US-Bundesstaates Oregon.

wangsschlichtung – Alle Rechtshandlungen, gleich welcher Art, die sich aus Einkaufsverein barung für das Produkt

ergeben, sind vorbehaltlich einer Zwangsschlichtung. EINIGE GERICHTSBARKEITEN ERLAUBEN KEINEN HAFTUNGSAUSSCHLUSS BZW. KEINE HAFTUNGSEINSCHRÄNKUNG FÜR NEBEM- ODER FOLGESCHÄDEN. IN DIESEM FALL TRIFFT DIE OBEN AUFGEFÜHRTE EINDCHRÄNKUNG BZW. DER AUSSCHLUSS U.U. NICHT AUF SIE ZU. DIESE GARANTIE GIBT IHNEN BESTI MMTE RECHT E. SIE KÖNNEN W EITERE RECHT E HABEN, DI E VIN DER GERI CHTSBARKEIT ABHÄNGIG SIND.

Proxima DP6870 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
