Desktop Projector

DP6860

ENGLISH

Liquid Crystal Projector

USER'S GUIDE

USER'S GUIDE

ENGLISH-1

Thank you for purchasing this liquid crystal projector.

CONTENTS

CONTENTS

Page

FEATURES .......................................2

BEFORE USE ...................................2

Contents of Package ..............................2

Part Names.............................................3

Loading the Batteries..............................5

INSTALLATION ................................6

Installation of the Projector and Screen

........6

Angle Adjustment ...................................6

Cabling ...................................................7

Power Connection ..................................8

Example of System Setup ......................8

Plug & Play.............................................8

OPERATIONS...................................9

Power On ...................................................9

Power Off

................................................9

Basic Operation....................................10

Setup Menu ..........................................12

Input Menu............................................13

Image Menu..........................................14

Options Menu .......................................15

No Signal Menu....................................16

MAINTENANCE ..............................17

Lamp.....................................................17

Air Filter ................................................19

Other Maintenance...............................19

Page

TROUBLESHOOTING ....................20

OSD Message ......................................20

Indicators Message ..............................21

Symptom ..............................................22

SPECIFICATIONS...........................23

WARRANTY AND AFTER-SERVICE

......24

.......................................................................................

TABLES

Table 1. Installation Reference.................6

Table 2. Cabling .......................................7

Table 3. Basic Operations ......................10

Table 4. Setup Menu ..............................12

Table 5. Input Menu................................13

Table 6. Image Menu..............................14

Table 7. Options Menu ...........................15

Table 8. No Signal Menu........................16

Table 9. OSD Message ..........................20

Table 10. Indicator Message ..................21

Table 11. Symptom ................................22

Table 12. Specifications .........................23

.......................................................................................

For "TECHNICAL" and "REGULATORY
NOTICE", see the end of this manual.

• The information in this manual is subject to change without notice.

• The manufacturer assumes no responsibility for any errors that may appear in this manual

• The reproduction, transmission or use of this document or contents is not permitted without
express written authority.

TRADEMARK ACKNOWLEDGMENT : PS/2, VGA and XGA are registered trademarks of
International Business Machines Corporation. Apple, Mac and ADB are registered trademarks of
Apple Computer, Inc. VESA and SVGA are trademarks of the Video Electronics Standard
Association. Windows is a registered trademark of Microsoft Corporation. Carefully observe the
trademarks and registered trademarks of all companies, even when not mentioned.

NOTE

WARNING • Please read the accompanying manual “SAFETY

INSTRUCTIONS” and this “USER'S GUIDE” thoroughly to ensure correct
usage through understanding. After reading, store this instruction manual in a
safe place for future reference.

ENGLISH-2

FEATURES

FEATURES

This liquid crystal projector is used to project various computer signals as well as NTSC / PAL /
SECAM video signals onto a screen. Little space is required for installation and large images can
easily be realized.

Outstanding Brightness

The UHB lamp and high-efficiency optical system assure a high level of brightness.

Partial Magnification Function

Interesting parts of images can be magnified for closer viewing.

Distortion Correction Function

Distortion-free images are quickly available.

BEFORE USE

BEFORE USE

Contents of package

Make sure all of the following items are included in the package. If anything is missing, please
contact your dealer.

• Keep the original packing material for future reshipment.

NOTE

Projector

ENGLISH-3

BBBBEEEEFFFFOOOORRRREEEE UUUUSSSSEEEE ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

ENGLISH

Part Names

Control Panel

(Refer to P.9 "OPERATIONS")

Front/Right View

Rear/Left View

Terminal Panel

(Refer below)

Terminal
Panel

DIGITAL Terminal

S-VIDEO Terminal

VIDEO Terminal

AUDIO(MONO)/L

Terminal

AUDIO R Terminal

USB Terminal

ZOOM Button

MUTE Button

STANDBY/ON Button

LAMP Indicator

POWER Indicator

FOCUS Button

INPUT Button

MENU Button

RESET Button

TEMP Indicator

Remote Control Sensor

Lens

Foot Adjuster

Lens Cap

Control Panel

Ventilation Openings
(exhaust)

Carrying Handle

Air Filter and Intake
for the Cooling Fan

Foot Adjuster

Remote Control Sensor

Speaker

Power Switch

AC Inlet

(to Power Cord)

RGB IN 1 Terminal
RGB IN 2 Terminal

RGB OUT Terminal

CONTROL Terminal

AUDIO IN RGB1 Terminal
AUDIO IN RGB2 Terminal
AUDIO OUT Terminal

COMPONENT VIDEO
Y Terminal
C

B/PB Terminal

C

R/PR Terminal

ZOOM

MUTE INPUT

STANDBY/ON

MENU

POWER TEMPLAMP

FOCUS

RESET

DIGITAL

S-VIDEO

COMPO

VIDEO

(MONO)/L

AUDIO

R

USB

RGB IN 2

NENT

VIDEO

RGB OUT

CONTROL

AUDIO IN AUDIO

B/PB

C

CR/PR

RGB 1
DIGITAL

OUT

RGB 2

ENGLISH-4

BBBBEEEEFFFFOOOORRRREEEE UUUUSSSSEEEE ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Part Names (continued)

STANDBY/ON

LASER

VIDEO

BLANK

RGB

AUTO

MENU

MENU SELECT

POSITION

RESET

FREEZE

MAGNIFY

PinP

OFF

VOLUME

MUTE

ZOOM

FOCUS

REMOTE CONTROL TRANSMITTER

(Refer to P.9 "OPERATIONS")

To prevent any malfunction;

• Do not give the remote control transmitter any physical impact. Take care not to drop.

• Do not place the heavy objects on the remote control transmitter.

• Do not wet the remote control transmitter or place it on any wet object.

• Do not place the remote control transmitter close to the cooling fan of the projector.

• Do not disassemble the remote control transmitter in case of malfunction. Please bring it to the
service station.

NOTE

STANDBY/ON Button

LASER Button

BLANK Button

Disk Pad

Used to operate the
mouse shift function and
left click function.

AUTO Button

MENU Button

MENU SELECT Button

Used to click the left
mouse button.

, , , Button

Used to operate the
mouse shift function.

MAGNIFY Button

VIDEO Button

RGB Button

MOUSE / RIGHT Button

Used to click the right
mouse button.

RESET Button

Used to click the right
mouse button.

VOLUME Button

FREEZE Button

MUTE Button

POSITION Button

ZOOM Button

These functions works when the mouse control function is activated. Remember, the POSITION,

BLANK ON and MENU ON functions disable the mouse control function.

WARNING • The laser pointer of the remote control transmitter is used in

place of a finger or rod. Never look directly into the laser beam outlet or point
the laser beam at other people. The laser beam can cause vision problems.

FOCUS Button

PinP Button

CAUTION

LASER RADIATION­DO NOT STARE INTO BEAM

WAVE LENGTH: 650nm
MAX . OUTPUT: 1mW

CLASS 2 LASER PRODUCT

RADIAZIONI LASER
NON GUARDARE NEL RAGGIO LUCE
APPARECCHIO LASER DI CLASSE 2
RAYONNEMENT LASER
NE PAS REGARDER DANS
LE FAISCEAU APPAREIL
A LASER DE CLASSE 2
LASER-STRAHLUNG
NICHT IN DEN STRAHL
BLICKEN LASER KLASSE2

MANUFACTURED

PLACE OF
MANUFACTURER:A
MADE IN JAPAN

IEC60825-1:1993+A1:1997

ENGLISH-5

BBBBEEEEFFFFOOOORRRREEEE UUUUSSSSEEEE ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

ENGLISH

Loading the Batteries

Install the AA batteries into the remote control
transmitter.

1. Remove the battery cover.
Push the knob while lifting up the battery cover.

2. Load the batteries.
Make sure the plus and minus poles are correctly
oriented.

3. Close the battery cover.

1

2

Replace the batteries when remote control transmitter operation becomes difficult.

NOTE

CAUTION • Use only the specified batteries with this remote control
transmitter. Also, do not mix new and old batteries. This could cause battery

cracking or leakage, which could result in fire or personal injury.

• When loading the batteries, make sure the plus and minus terminals are
correctly oriented as indicated in the remote control transmitter. Incorrect
orientation could cause battery cracking or leakage, which could result in
personal injury or pollution of the surrounding environment.

• When you dispose the battery, you obey the law in the relative area or country.

• Keep the battery away from children and pets.

• When not to be used for an extended period, remove the batteries from the

remote control transmitter.

ENGLISH-6

INSTALLATION

INSTALLATION

Installation of the Projector and Screen

Refer to the drawing and table below for determining of the screen size and projection distance.

Top View

Side View

Diagonal Screen
Size [inches (m)]

a [inches (m)]

b

[inches (cm)]

Min. Max.

40 (1.0) 55 (1.4) 73 (1.9) 1 (3)

60 (1.5) 85 (2.2) 114 (2.9) 2 (4)

80 (2.0) 114 (2.9) 151 (3.8) 2 (6)

100 (2.5) 144 (3.7) 191 (4.9) 3 (7)

120 (3.0) 176 (4.5) 231 (5.9) 3 (9)

150 (3.8) 220 (5.6) 282 (7.2) 4 (11)

200 (5.0) 291 (7.4) 386 (9.8) 6 (15)

Angle Adjustment

Use the foot adjusters on the bottom of the
projector to adjust the projection angle. It is
variable within 0˚ to 9˚ approximately.

1. Lift up the front side of the projector, and
pressing the foot adjuster button, adjust the
projection angle.

2. Release the button to lock at the angle to be
fixed.

3. Make the foot adjusters screw for fine
adjustment. Do not force the adjusters to make
screw. This could damage the adjusters or
cause the lock to fail.

Foot Adjusters

The projection distances shown in the table below
are for full size (1024 x 768 dots).

a: Distance from the projector to the screen. (±10%)
b: Distance from the lens center to the bottom of the

screen. (±10%)

Table 1. Installation Reference

b

a

Lens center

Screen

CAUTION • Install the projector in a suitable environment according to
instructions of the accompanying manual “SAFETY INSTRUCTIONS” and this

manual.

• Please basically use liquid crystal projector at the horizontal position.

If you use
liquid crystal projector by the lens up position, the lens down position and the side up
position, this may cause the heat inside to build up and become the cause of damage.
Be especially careful not to install it with ventilation holes blocked.

• Do not install LCD projector in smoke effected environment. Smoke residue may
buildup on critical parts (i.e.LCD panel, Lens Assy etc.).

CAUTION • Do not release the foot adjuster button unless the projector is
being held; otherwise, the projector could overturn or the fingers could get

caught and cause personal injury.

Variable within the range of approximately 0° - 9°

ENGLISH-7

ENGLISH

IIIINNNNSSSSTTTTAAAALLLLLLLLAAAATTTTIIIIOOOONNNN ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

• Before connecting, read instruction manuals of the devices to be connected, and make sure that the

projector is compatible with the device.

• Secure the screws on the connectors and tighten.

• For some RGB input modes, the optional Mac adapter is necessary.

• To select the digital RGB input, the computer may need some settings. See the manuals of the computer for
details.

• Some computers may have multiple display screen modes. Use of some of these modes will not be possible
with this projector.

• Refer to the “TECHNICAL” section for the pin assign of connectors and RS-232C communication data.

• When the DIGITAL terminal is used, the RGB OUT terminal may not function.

NOTE

CAUTION • Incorrect connecting could result in fire or electrical shock.
Please read this manual and the separate “SAFETY INSTRUCTIONS”.

• Before connecting, turn off to all devices to be connected, except for the USB
cable.

• The cables may have to be used with the core set to the projector side. Use the
cables which are included with the projector or specified.

Cabling

Refer to the table below for connecting each terminal of the projector to each device.

Table 2. Cabling

Function Terminal Cable

Analog RGB input

RGB IN 1

Accessory RGB cable or optional RGB
cable with D-sub 15-pin shrink jack and
inch thread screws

RGB IN 2

Analog RGB output RGB OUT

Digital RGB input DIGITAL

Optional digital RGB cable with inch thread
screws

Audio input
(from the computer)

AUDIO IN [RGB 1] / [DIGITAL]

(interlocked with RGB IN 1 or
DIGITAL)

Optional audio cable with stereo mini jack

AUDIO IN [RGB 2]

(interlocked with RGB IN 2)

PS/2 mouse control

CONTROL

Accessory PS/2 mouse cable

ADB mouse control Optional ADB mouse cable

Serial mouse control Optional Serial mouse cable

RS-232C communication Optional RS-232C cable

USB mouse control USB Optional USB cable

S-video input S-VIDEO

Optional S-video cable with mini DIN 4-pin
jack

Video input VIDEO Accessory video/audio cable

Component video input

COMPONENT VIDEO Y

Accessory component video cableCOMPONENT VIDEO CB/PB

COMPONENT VIDEO CR/PR

Audio input
(from video equipment)

AUDIO (MONO)/L

Accessory video/audio cable or optional
audio cable with RCA jack

AUDIO R

Audio output AUDIO OUT Optional audio cable with stereo mini jack

Example of system setup

S-Video Tape
Recorder

Computer

(desktop type)

Computer

(notebook type)

• When connecting with notebook computer, set to valid the RGB external image output
(setting CRT display or simultaneous display of LCD and CRT). Please read instruction manual of
the notebook for more information.

Plug & Play

This projector is VESA DDC 1/2B compatible. Plug & play is possible by connecting to a computer
that is VESA DDC (Display Data Channel) compatible.
Please use this function by connecting the accessory RGB cable with RGB IN 1 terminal (DDC
1/2B compatible), or by connecting an optional digital RGB cable with DIGITAL terminal (DDC
2B compatible). Plug & play may not operate by other connecting.

• Plug & play is a system configured with peripheral equipment including a computer and
display, and an operating system.

• This projector is recognized as a plug & play monitor. Use the standard display drivers.

• Plug & play may not operate by the computer to connect. Plug & play will not operate in the
connection with Apple computer.

NOTE

NOTE

ENGLISH-8

IIIINNNNSSSSTTTTAAAALLLLLLLLAAAATTTTIIIIOOOONNNN ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Power Connection

Use the correct one of the enclosed power cords depending on the power outlet to be used.
Connect the AC inlet of the projector to the power outlet firmly by the power cord.

AC Inlet

Power Cord

Power outlet

Speaker
with
amplifier

Display
Monitor

CAUTION • Be carful in handling the power

cord according to instructions of the
accompanying manual "SAFETY INSTRUCTIONS"
and this manual.

• Connect the power cord firmly. Avoid using a
loose, unsound outlet or contact failure.

Computer

(desktop type)

DVD Player

DIGTAL

RGB IN 2

S-VIDEO

COMPO

NENT

VIDEO

VIDEO

(MONO)/L

AUDIO

R

USB

RGB OUT

AUDIO IN AUDIO

B/PB

C

RGB 1

RGB 2

DIGITAL

CR/PR

CONTROL

OUT

ENGLISH-9

ENGLISH

ENGLISH-9

OPERATIONS

OPERATIONS

Power ON

1. Check that the power cord is connected correctly.

2. Set the power switch to [ | ]. The standby mode is selected, and the POWER indicator is turned to
orange.

3. Press the STANDBY/ON button on the control panel or the remote control transmitter.
Warm-up begins and the POWER indicator blinks in green.

4. The POWER indicator ceases blinking and turns to green when power is on. Remove the lens
cap.

5. Adjust picture size using the ZOOM button.

6. Adjust focus using the FOCUS button .

Power OFF

1. Press the STANDBY/ON button on the control panel or the remote control transmitter for
approximately 2 seconds. The projector lamp is extinguished and lamp cooling begins. The
POWER indicator blinks orange during lamp cooling. Pressing the STANDBY/ON button
has no effect while the POWER indicator is blinking.

2. The system assumes the Standby mode when cooling is complete, and the POWER indicator
ceases blinking and changes to orange. Check that the indicator is orange and set the Power
switch to [

O

].

3. The POWER indicator is extinguished when power is off. Attach the lens cap.

Power Switch

Lens cap

STANDBY/ON Button

POWER Indicator

STANDBY/

ON Button

ZOOM button

FOCUS button

• Except in emergencies, do not turn off unless the POWER indicator is orange as it will

reduce the life of the projector lamp.

• To prevent any troble, turn on/off the projector when the computer or video tape recorder is OFF.

Providing a RS-232C cable is connected, turn on the computer before the projector.

NOTE

WARNING • Please read this manual, and the separate “SAFETY
INSTRUCTIONS” thoroughly before using the equipment. Always ensure that

the equipment is used safely.

FOCUS button

ZOOM button

STANDBY/ON

BLANK

AUTO

MENU

MENU SELECT

PinP

MAGNIFY

LASER

FREEZE

OFF

ZOOMFOCUS

VIDEO

RGB

POSITION

RESET

VOLUME

MUTE

ENGLISH-10ENGLISH-10

OOOOPPPPEEEERRRRAAAATTTTIIIIOOOONNNNSSSS ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Basic Operation

The basic operations shown in Table 3 is performed from the supplied remote control transmitter or
the projector control panel. Items indicated by (*) may be used from the control panel.

Table 3 . Basic Operation

Item Description

INPUT
SELECT

Select Input Signal (*) : Press the INPUT button.

RGB IN 1 → RGB IN 2 → DIGITAL
→ VIDEO → S-VIDEO → COMPONENT VIDEO (→ RGB IN 1)

Select RGB Input : Press the RGB button.

VIDEO/S-VIDEO/COMPONENT VIDEO → RGB IN 1/RGB IN 2/DIGITAL
RGB IN 1 → RGB IN 2 → DIGITAL (→ RGB IN 1)

Select Video Input : Press the VIDEO button.

RGB IN 1/RGB IN 2/DIGITAL → VIDEO/S-VIDEO/COMPONENT VIDEO
VIDEO → S-VIDEO → COMPONENT VIDEO (→ VIDEO)

• The selected signal name is displayed for approximately 3 seconds when the input
signal is changed.

POSITION

Set/Clear Position Adjustment Mode : Press the POSITION button.

The [ ] icon is displayed in the POSITION mode.

Image Position Adjustment: Press the , , and buttons in the
POSITION mode.

• Valid only in the MAGNIFY mode with a video signal is input.

• After approximately 10 seconds of inactivity the [ ] icon is extinguished and the

POSITION mode is cleared automatically.

• , , and

buttons may operate as the mouse control button. Refer to page 4.

RESET (*)

Initialise Each Item : Select an item and press the RESET button.
Initialise Position Adjustment : Press the RESET button and the

POSITION mode. This function is valid only when RGB signal is input.

• Valid except for the VOLUME, LANGUAGE and H PHASE.

• The RESET button may operate as the mouse control button. Refer to page 4.

MAGNIFY

Set MAGNIFY Mode : Press the MAGNIFY button.
Move Magnified Area : Run the POSITION in the MAGNIFY mode.
Adjust Magnification : Press the MAGNIFY / button in MAGNIFY

mode.
Clear MAGNIFY Mode : Press the MAGNIFY button.

• The MAGNIFY mode is cleared by running or setting the AUTO, ASPECT, INPUT
SELECT or VIDEO, or by changing the input signal.

OFF

FREEZE

Set/Clear FREEZE Mode : Press the FREEZE button. The [II] icon is
displayed, and the image frozen, in the FREEZE mode.

• The FREEZE mode is cleared by running or setting POSITION, VOLUME, MUTE,
Automatic Adjustment, BLANK ON/OFF, or MENU ON/OFF, or by changing the input
signal.

• Do not forget to clear frozen static images.

• Use the remote control transmitter at a distance of approximately 5m from the sensor on
the front of the projector, and within a range of 30° left-right. Strong light and obstacles will
interfere with operation of the remote control transmitter.

NOTE

Item Description

VOLUME

Volume Adjustment : Press the VOLUME / button.

MUTE (*)

Set/Clear Mute Mode : Press the MUTE button. No sound is heard in the
MUTE mode.

AUTO

Automatic Adjustment at RGB Input : Press the AUTO button. Horizontal
position(H.POSIT), vertical position (V.POSIT),clock phase (H.PHASE), and
horizontal size(H.SIZE) are automatically adjusted. Use with the window at
maximum size in the application display.
Automatic Adjustment at Video Input : Press the AUTO button. A signal
type appropriate for the input signal is selected automatically. Valid only
when AUTO is set for VIDEO on the menu.

• This operation requires approximately ten seconds. It may not function correctly
with some input signals.

BLANK
ON/OFF

Set/Clear Blank Mode: Press the BLANK button. No image is displayed in
the Blank mode. The screen color is as set in BLANK on the Image menu.

MENU
ON/OFF (

*)

Menu Display Start/Stop: Press the MENU button.

• The menu display is terminated automatically after approximately ten seconds of
inactivity.

MENU
SELECT

Select Menu Type: Press the MENU SELECT button. Allows the user to
select the normal menu or the single menu. Only the selected item is
displayed on the single menu, and other items are displayed with the
and buttons as with the normal menu.

• Valid only when the Setup menu is used. Push the MENU SELECT button after
selecting items such as "BRIGHTNESS".

• The MENU SELECT button may operate as the mouse control button. Refer to
page 4.

Normal menu Single menu

P.IN P.
MODE

Select Mode of P.IN P. Display : Press the PinP button.

Small

→ Large → P.IN P. off (→Small)

• Valid only at RGB IN 1, RGB IN 2 or DIGITAL input.

ZOOM

Adjust Screen Size : Press the ZOOM / button.

FOCUS

Adjust Focus : Press the FOCUS / button.

ENGLISH-11

ENGLISH

ENGLISH-11

OOOOPPPPEEEERRRRAAAATTTTIIIIOOOONNNNSSSS ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Items indicated by (*) may be used from the control panel.

Table 3. Basic Operation (continued)

CONTRAST

-2

BRIGHT

CONTRAST

V POSIT
H POSIT
H PHASE

H SIZE
COLOR BAL R
COLOR BAL B

ASPECT

0

-2

+1

0
0

100
100

800

SETUP INPUT OPT.IMAGE

(MENU SELECT)

ENGLISH-12ENGLISH-12

OOOOPPPPEEEERRRRAAAATTTTIIIIOOOONNNNSSSS ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Setup Menu

The following adjustments and settings are possible
when SETUP is selected at the top of the menu. Part
of the Setup menu differs between RGB input and
video input. Select an item with the and
buttons, and start operation. Use the Single menu to
reduce menu size (see Table 3, MENU SELECT).

Table 4. Setup Menu

VIDEO

S-VIDEO

COMPONENT VIDEO

RGB IN 1
RGB IN 2

DIGITAL

BRIGHT

CONTRAST

V POSIT
H POSIT

H PHASE

H SIZE
COLOR BAL R
COLOR BAL B

ASPECT

0

-2

+1

0
0

100
100

800

SETUP INPUT OPT.IMAGE

BRIGHT

CONTRAST

SHARPNESS

COLOR

TINT
COLOR BAL R
COLOR BAL B

ASPECT

0
+1
+1

0

0

0

0

SETUP INPUT OPT.IMAGE

Item Description

RGB IN 1
RGB IN 2

DIGTAL

VIDEO

S-VIDEO

COMPONENT

BRIGHT

Adjustment: Dark ↔ Light

✔ ✔ ✔

CONTRAST

Adjustment: Weak ↔ Strong

✔ ✔ ✔

V POSIT

Adjustment: Down ↔ Up

✔

- -

H POSIT

Adjustment: Left ↔ Right

✔

- -

H PHASE

Adjustment: Left ↔ Right

• Adjust to eliminate flicker.

✔

- -

H SIZE

Adjustment: Small ↔ Large

• The image may not be displayed correctly if the horizontal
size is excessive. In such cases, press the RESET button,
and initialize the horizontal size.

✔

- -

SHARPNESS

Adjustment: Soft ↔ Clear

- -

✔

COLOR

Adjustment: Light ↔ Dark

- -

✔

TINT

Adjustment: Red ↔ Green

• Valid only when NTSC or NTSC 4.43 signal is received.

- -

✔

COLOR BAL R

Adjustment: Light ↔ Dark

✔ ✔ ✔

COLOR BAL B

Adjustment: Light ↔ Dark

✔ ✔ ✔

ASPECT

Select Image Aspect Ratio : 4:3[ ] ↔
16:9[ ]

Select Position of Image:

Press the button while 16:9[ ] is selected.
Center

→ Down → Up ( → Center )

✔ ✔

-

Select Image Aspect Ratio:

4:3[ ] ↔ 16:9[ ] ↔ 4:3 small[ ]

Select Position of Image :

Press the button while 16:9[ ] / 4:3 small[ ]
is selected.
Center

→ Down → Up ( → Center )

• 4:3 small may not be displayed correctly with some input
signals.

- -

✔

ENGLISH-13

ENGLISH

ENGLISH-13

OOOOPPPPEEEERRRRAAAATTTTIIIIOOOONNNNSSSS ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Input Menu

The following functions are available when INPUT is selected on the
menu. Select an item with the and buttons, and start or stop
operation with the and buttons. The functions indicated (**) are
effective on video input mode only, not on RGB input mode, except in
the P.IN P. window on RGB input mode.

Table 5. Input Menu

Item Description

AUTO

Automatic Adjustment at RGB Input: Select the EXECUTE with the
button.

Horizontal position (H.POSIT), vertical position (V.POSIT), clock
phase (H.PHASE), and horizontal size (H.SIZE) are automatically adjusted.
Use with the window at maximum size in the application display.
Automatic Adjustment at Video Input: Select the

EXECUTE

with the
button. A signal type appropriate for the input signal is selected
automatically when

EXECUTE

is selected automatically. Valid only when

AUTO is set for VIDEO on the menu.

•

This operation requires approximately 10 seconds. It may not function correctly with

some input signals. Pressing the AUTO button in this case may correct this problem.

• This function is the same as for the AUTO function in Basic operation.

RGB

Displays RGB Input Frequency: Displays the horizontal and vertical sync
signal frequencies for RGB input.

• Valid only at RGB input.

VIDEO (**)

Select Video Signal Type: Select the signal type with the and
buttons. Select NTSC, PAL, SECAM, NTSC4.43, M-PAL, or N-PAL as
appropriate for the input signal. The selection of AUTO enables and
executes the function AUTO (Automatic Adjustment at Video Input), except
for the N-PAL input.

• Use this function when the image becomes unstable (eg. the image becomes
irregular, or lacks color) at VIDEO/S-VIDEO input.

• Automatic Adjustment requires approximately ten seconds. It may not function
correctly with some input signals. Pressing the AUTO button in this case may correct
this problem except for the N-PAL input.

• For the COMPONENT VIDEO input, this function is not effective and the signal type
is distinguished automatically. Refer to the item HDTV of the OPT. Menu for the
signal of HDTV.

VIDEO NR

(**)

Set/Clear Noise Reduction Mode: Select the TURN ON / TURN OFF with
the / button. When the TURN ON is selected, the NR mode is active
and the noise on screen of the video input will be reduced.

Progressive

(**)

Select Progressive Mode: Select the mode suitable for the input signal
with the and buttons. The TV mode and the CINEMA mode convert
the interlaced video signal into the progressive signal. The CINEMA mode is
adptable for 2-3 Pull-Down system.

• Use this function to raise resolution, at the interlaced video input except HDTV
signals.

BLACK(**)

Set/Clear Black Enhancement Mode: Select the TURN ON / TURN OFF
with the / button. When the TURN ON is selected, the black
enhancement mode is active and the contrast ratio of the screen for the
video input will be raised by making black level darker.

SETUP INPUT OPT.

AUTO

RGB

VIDEO

VIDEO NR

Progressive

BLACK


EXECUTE
CANCEL

ENGLISH-14ENGLISH-14

OOOOPPPPEEEERRRRAAAATTTTIIIIOOOONNNNSSSS ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Image Menu

The following adjustments and settings are available when IMAGE is
selected on the menu. Select an item with the and buttons, and
start operation.

Table 6. Image Menu

Item Description

KEYSTONE

Keystone Adjustment:

Reduce size of bottom of image ↔ Reduce size of top of image

• When this function is activated, the image may not be displayed correctly with
some input signals.

BLANK

Select Blank Screen Color: Select color with the and buttons.

• The image is cleared when the BLANK mode is set with BLANK ON, or when there
is no signal, and the entire screen is displayed in the selected color.

MIRROR

Operation Start/Stop: Press the or button.
Select Mirror Status: Select mirror status with and buttons.

START UP

Operation Start/Stop: Press the or button.
Setup Initial Screen Display: Select TURN ON with the button.
Clear Initial Screen Display: Select TURN OFF with the button.

• Note that if TURN OFF is selected the blank screen is displayed in blue when there
is no signal.

P. IN P.

Operation Start/Stop: Press the or button.
Select Position of P. in P. Display : Press the or button.

↔↔↔(↔)

• Valid only at RGB IN 1, RGB IN 2 or DIGITAL input.

SETUP INPUT OPT.

KEYSTONE

BLANK

MIRROR

START UP

P. IN P.


+1

ENGLISH-15

ENGLISH

ENGLISH-15

OOOOPPPPEEEERRRRAAAATTTTIIIIOOOONNNNSSSS ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Options Menu

The following adjustments and settings are available when OPT. is
selected on the menu. Select an item with the and buttons, and
start operation. The function indicated (**) is effective on video input
mode only, not on RGB input mode, except in the P.IN P. window on
RGB input mode.

Table 7. Options Menu

VOLUME

MENU COLOR

LANGUAGE

AUTO OFF

SYNC ON G

HDTV

16

SETUP INPUT OPT.IMAGE

Item Description

VOLUME

Volume Adjustment: Reduce VOLUME ↔ Increase VOLUME

MENU COLOR

Select Menu Background Color: Select with the and buttons.

LANGUAGE

Operation Start/Stop: Press the or button.
Select Menu Display Language: Select with the and buttons.

AUTO OFF

Operation Start/Stop: Press the or button.
Set AUTO OFF: Set 1~99 minutes with the and buttons. The

system automatically enters the standby mode when a signal is not
received for the set time.
Clear AUTO OFF: Select STOP (0 min.) with the button. When
STOP is selected the system does not enter the standby mode even if
no signal is received.

SYNC ON G

Operation Start/Stop: Press the or button.
SYNC ON G Valid: Select TURN ON with the button.
SYNC ON G Invalid: Select TURN OFF with the button.

• May not be displayed correctly with some input signals when SYNC ON G is
valid. In such cases, remove the signal connector so that no signal is received,
set SYNC ON G to invalid, and reconnect the signal.

HDTV (**)

Select HDTV mode: Select the 1035i mode or 1080i mode suitable for
the input signal with the / button.

ENGLISH-16ENGLISH-16

OOOOPPPPEEEERRRRAAAATTTTIIIIOOOONNNNSSSS ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

No Signal Menu

The same adjustments and settings are available as with the Image and
Options menus when the MENU button is pressed during display of the
“NO INPUT IS DETECTED ON ***” or “SYNC IS OUT OF RANGE
ON ***” message while no signal is received.

Table 8. No Signal Menu

VOLUME

KEYSTONE

BLANK

MIRROR

START UP

MENU COLOR

LANGUAGE

AUTO OFF

SYNC ON G

16
+1

Item Description

VOLUME

Volume Adjustment: Reduce VOLUME ↔ Increase VOLUME

• When this function is used, audio input is automatically switched to video. The
audio input can be switched by moving the DISK PAD left and right during the
display of the volume adjustment bar. The volume adjustment bar is displayed by
pressing VOLUME or VOLUME button.

KEYSTONE

Keystone Adjustment: Reduce the size of bottom of image ↔
Reduce the size of top of image

BLANK

Select Blank Screen Color: Select the color with the and
buttons.

• When the blank mode is set with BLANK ON, by absence of a signal, or by
input of a non-standard signal, the image is cleared and the complete screen is
displayed in the selected color.

MIRROR

Operation Start/Stop: Press the or button.
Select Mirror Status: Select the mirror status with the and

buttons.

START UP

Operation Start/Stop: Press the or button.
Setup Initial Screen Display: Select the TURN ON with the button.
Clear Initial Screen Display: Select the TURN OFF with the button.

• Note that if TURN OFF is selected the blank screen is displayed in blue when
there is no signal.

MENU COLOR

Select Menu Background Color: Select the color with the and
buttons.

LANGUAGE

Operation Start/Stop: Press the or button.
Select Menu Display Language: Select the language with the and

buttons.

AUTO OFF

Operation start/stop: Press the or button.
Set AUTO OFF: Set 1~99 minutes with the and buttons. The

system automatically enters the standby mode when a signal is not
received for the set time.
Clear AUTO OFF: Select the STOP (0 min.) with the button. When
the STOP is selected the system does not enter the standby mode even
if no signal is received.

SYNC ON G

Operation Start/Stop: Press the or button.
SYNC ON G Valid: Select the TURN ON with the button.
SYNC ON G Invalid: Select the TURN OFF with the button.

• May not be displayed correctly with some input signals when the SYNC ON G
is valid. In such cases, remove the signal connector so that no signal is received,
set the SYNC ON G to invalid, and reconnect the signal.

ENGLISH-17

ENGLISH

ENGLISH-17

MAINTENANCE

MAINTENANCE

Lamp

HIGH VOLTAGE

HIGH TEMPERATURE

HIGH PRESSURE

Contact your dealer before replacing the lamp.
For the optional lamp, see the item “Option Parts” of the Table 12.
Before replacing the lamp, switch power OFF, remove the power cord from the power outlet, and
wait approximately 45 minutes until the lamp has cooled. The lamp may explode if handled at high
temperatures.

Lamp Life

Projector lamps have a finite life. The image will become darker, and hues will become weaker,
after a lamp has been used for a long period of time.
Replace the lamp if the LAMP indicator is red, or the CHANGE THE LAMP message appears
when the projector is switched ON. See Table 9 of P.20 and Table 10 of P.21.

• The LAMP indicator is also red when the lamp unit reaches high temperature. Before

replacing the lamp, switch power OFF, wait approximately 20 minutes, and switch power ON again.
If the LAMP indicator is still red, replace the lamp.

NOTE

Lamp

Front
glasss

Reflector

WARNING • For disposal of used lamp, treat
according to the instruction of community

authorities.

• Since the lamp is made of glass, do not apply shock
to it and do not scratch it.

• Also, do not use old lamp. This could also cause
explosion of the lamp.

• If it is probable that the lamp has exploded (explosive
sound is heard), disconnect the power plug from the
power outlet and ask your dealer to replace lamp. The
lamp is covered by front glass , but, in rare cases, the
reflector and the inside of the projector may be
damaged by scattered broken pieces of glass, and
broken pieces could cause injury when being handled.

• Do not use the projector with the lamp cover removed.

ENGLISH-18ENGLISH-18

MMMMAAAAIIIINNNNTTTTEEEENNNNAAAANNNNCCCCEEEE ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Replacing the Lamp

1. Switch the projector OFF, remove the power cord from the
power outlet, and wait at least 45 minutes for the unit to cool.

2. Prepare a new lamp.

3. Check that the projector has cooled sufficiently, and gently
turn it upside down.

4. Loosen the screw as shown in the diagram, and remove the
lamp cover.

5. Loosen the two screws, and gently remove the lamp while
holding the grips. Touching the inside of the lamp case may
result in uneven coloring.

6. Install the new lamp and tighten the two screws firmly. Also
steadily push the opposite side of the screwed lamp into the
unit.

7. Replace the lamp cover in position and tighten the screw
firmly.

8. Gently turn the projector right-side up.

Resetting the Lamp Timer

Reset the lamp timer after replacing the lamp. When the lamp has been replaced after the LAMP
indicator is red, or the CHANGE THE LAMP message is displayed, complete the following
operation within ten minutes of switching power ON. The power will be turned off automatically in
over 10 minutes.

1. Switch power ON, and press the RESET button, for approximately three seconds. The ‘LAMP
xxxx hr’ message will appear on the lamp timer on the bottom of the screen.

2. Press the MENU button on the remote control transmitter, or the RESET button on the control
panel, while the lamp timer is displayed. The ‘LAMP xxxx

→ 0 ■ CANCEL’ message will

then appear.

3. Press the and select 0, and wait until the timer display is cleared.

• Do not reset the lamp timer without replacing the lamp. Reset the lamp timer always

when replacing the lamp. The message functions will not operate properly if the lamp timer is not
reset correctly.

NOTE

CAUTION • Ensure that screws are tightened
properly. Screws not tightened fully may result

in injury or accidents.

• Do not use the projector with the lamp cover
removed.

ENGLISH-19

ENGLISH

ENGLISH-19

MMMMAAAAIIIINNNNTTTTEEEENNNNAAAANNNNCCCCEEEE ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Air Filter Maintenance

The air filter should be cleaned as described below at intervals of approximately 100 hours.

1. Switch the projector power supply OFF, and remove the power cord from the power outlet.

2. Clean the air filter with a vacuum cleaner.

Other Maintenance

Maintenance Inside the Equipment

For safety reasons, ensure that the equipment is cleaned and checked by the dealer once every two
years. Maintaining the equipment by yourself is dangerous.

Cleaning the Lens

Gently wipe the lens with lens cleaning paper. Do not touch the lens with your hands.

Cleaning the Cabinet and Remote control transmitter

Gently wipe with a soft cloth. If dirt and stains etc. are not easily removed, use a soft cloth
dampened with water, or water and a neutral detergent, and wipe dry with a soft, dry cloth.

CAUTION • Switch power OFF and remove the power cord from the power
outlet before beginning maintenance work. Please read the separate “SAFETY

INSTRUCTIONS” thoroughly to ensure that maintenance is performed correctly.

• Do not use detergents or chemicals other than those noted above (e.g. benzene

or thinners).

• Do not use cleaning sprays.

• Do not rub with hard materials, or tap the equipment.

CAUTION • Switch power OFF and remove the power cord from the power
outlet before beginning maintenance work. Please read the separate “SAFETY

INSTRUCTIONS” thoroughly to ensure that maintenance is performed correctly.

• Replace the air filter if contamination cannot be removed, or if it is damaged.

Contact your dealer in such case. For the optional air filter, see the item “Option
Parts” of the Table 12.

• Do not use the equipment with the air filter removed.

• When the air filter is clogged with dust etc. the power supply is switched OFF

automatically to prevent the temperature rising inside the projector.

ENGLISH-20ENGLISH-20

TROUBLESHOOTING

TROUBLESHOOTING

OSD Message

The messages as described below may appear on the screen at power ON. Take the appropriate
measures when such a message appears.

Table 9. OSD Messages

Message Contents

CHANGE THE LAMP

AFTER REPLACING LAMP,

RESET THE LAMP TIME.

*1)

The message shown at left appears after the lamp has
been used for more than 1700 hours.
The lamp is approaching the end of its life.
Power is switched OFF automatically when the lamp
reaches the end of its life. Prepare a new lamp for
installation.
Always reset the lamp timer after replacing the lamp.

CHANGE THE LAMP

AFTER REPLACING LAMP,

RESET THE LAMP TIME.

THE POWER WILL TURN OFF

AFTER ** hr.

*1)

The lamp will reach the end of its life in ** hours.
Power will be switched OFF automatically in

** hours.
Replace the lamp as shown in P.17~18 “Lamp”.
Always reset the lamp timer after replacing the lamp.

CHANGE THE LAMP

AFTER REPLACING LAMP,

RESET THE LAMP TIME.

THE POWER WILL

TURN OFF

AFTER 0 hr.

The lamp has reached the end of its life. Power will be
switched OFF in a few minutes.
Switch power OFF immediately and replace the lamp as
shown in P.17~18 “Lamp”.
Always reset the lamp timer after replacing the lamp.

NO INPUT IS DETECTED

ON ***

No input signal found.
Check signal input connections and signal sources.

SYNC IS OUT OF RANGE

ON ***

The horizontal or vertical frequency of the input signal is
not within the specified range.
Check the specifications of the equipment and the signal
source.

*1) This message is cleared automatically after approximately three minutes, and appears

every time power is switched ON.

NOTE

ENGLISH-21

ENGLISH

ENGLISH-21

TTTTRRRROOOOUUUUBBBBLLLLEEEESSSSHHHHOOOOOOOOTTTTIIIINNNNGGGG ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Indicators Message

The POWER indicator, LAMP indicator, and TEMP indicator are lit and blank as follows. Take the
appropriate measures.

Table 10. Indicators Message

POWER

indicator

LAMP

indicator

TEMP

indicator

Contents

Lights

orange

Turns off Turns off The Standby mode has been set.

Blinks

green

Turns off Turns off Warming up. Please wait.

Lights

green

Turns off Turns off ON. Normal operation possible.

Blinks

orange

Turns off Turns off Cooling. Please wait.

Lights red

Lights

red

Turns off

Lamp is not lit.
The interior of the equipment may be too hot. Switch
power OFF, wait 20 minutes until the equipment cools,
and check whether the ventilation openings are blocked,
whether the air filter is dirty, or whether the ambient
temperature exceeds 35 °C. And switch power ON
again. Replace the lamp if the same problem occurs.

Lights red

Blinks

red

Turns off

Lamp or lamp cover is not found, or hasn’t been fitted in
correctly.
Switch power OFF, and wait for 45 minutes until the
equipment cools. Check fitting of the lamp and lamp
cover, and switch power ON again. Contact your dealer if
the same problem occurs again.

Lights red Turns off

Blinks

red

The cooling fan is not operating.
Switch power OFF, and wait for 20 minutes until the
equipment cools. Check for foreign matters in the fan,
and switch power ON again. Contact your dealer if the
same problem occurs again.

*1) When the internal temperature becomes excessive power is switched OFF

automatically for safety reasons, and the indicator is extinguished. Set the power switch to [

O

] and

wait for 20 minutes until the equipment has cooled sufficiently.

NOTE

ENGLISH-22ENGLISH-22

TTTTRRRROOOOUUUUBBBBLLLLEEEESSSSHHHHOOOOOOOOTTTTIIIINNNNGGGG ((((ccccoooonnnnttttiiiinnnnuuuueeeedddd))

))

Symptom

Before requesting repair, check in accordance with the following chart. If the situation cannot be
corrected, then contact your dealer.

Table 11. Symptom

Symptom Possible cause Remedy Page

The power is not
turned on.

The main power switch is not
turned on.

Turn on the main power switch.

8,9

The power cord is
disconnected.

Plug the power cord into an AC
power outlet.

No video or audio.

The input is not correctly set.

Use the projector or remote control
transmitter to set.

10

No signal input. Connect correctly.

7,8

Video is present but
no audio.

The projector is not correctly
connected.

Connect correctly.

7,8

The volume is set to minimum.

Press VOLUME on the remote
control or display the menu screen
and adjust the volume.

11,15

Mute is turned on.

Press the MUTE button.

11

Audio is present but
no video.

The projector is not correctly
connected.

Connect correctly.

7,8

The brightness is set to
minimun.

Select BRIGHT with the MENU
button and the press the button.

12

The lens cap is still attached. Remove the lens cap.

9

Colors are pale and
color matching is
poor.

Color density and color
matching are not correctly
adjusted.

Adjust the video.

12

Images are dark.

Brightness and contrast are not
correctly adjusted.

Adjust the video.

12

The lamp is nearing the end of
its service life.

Replace with a new lamp.

17

Images are blurred.

Focus or H PHASE is out of
adjustment.

Adjust the focus or H PHASE.

9,12

ENGLISH-23

ENGLISH

ENGLISH-23

SPECIFICATIONS

SPECIFICATIONS

Table 12. Specifications

• This specifications are subject to change without notice.

NOTE

Item Specification

Product name Liquid crystal projector

Liquid
crystal
panel

Panel size 3.3 cm (1.3 type)

Drive system TFT active matrix

Pixels 786,432 pixels (1024 horizontal x 768 vertical)

Lens Zoom lens F=1.7 ~ 2.3 f=49.0 ~ 64.0 mm

Lamp 250 W UHB

Speaker 1.2 W + 1.2W (Stereo)

Power supply AC100 ~ 120V, 4.5A / AC220 ~ 240V, 2.2A

Power consumption 400W

Temperature range 0 ~ 35°C (Operating)

Size 289 (W) x 124 (H) x 350 (D) mm

Weight (mass) 6.4 kg

RGB
signal
input

RGB IN

1

Video: Analog 0.7Vp-p, 75Ω terminator (positive)
H/V. sync.: TTL level (positive/negative)
Composite sync.: TTL level
D-sub 15-pin shrink jack

2

DIGITAL

TMDS, DC: 150~1200 mV / AC: 1.56 Vp-p
TTL Level (Positive/Negative)

AUDIO IN

RGB1

200mVrms, 50 kΩ (max. 3.0Vp-p)
Stereo mini jack

DIGITAL
RGB2

Video
signal
input

VIDEO

1.0Vp-p, 75Ω terminator
RCA jack

S-VIDEO

Brightness signal: 1.0Vp-p, 75Ω terminator
Color signal: 0.286Vp-p (burst signal), 75Ω terminator
Mini DIN 4-pin jack

COMPONENT
VIDEO

Y 1.0 Vp-p, 75 Ω Terminator (Positive)
CB/CR 0.7 Vp-p, 75 Ω Terminator (Positive)
PB/PR 1.0 Vp-p, 75 Ω Terminator (Positive)

AUDIO

L

200mVrms, 50 kΩ (max. 3.0Vp-p)
RCA jack

R

Signal
output

RGB OUT

Video: Analog 0.7Vp-p, 75Ω output impedance (positive)
H/V. sync.: TTL level (positive/negative)
Composite sync.: TTL level
D-sub 15-pin shrink jack

AUDIO OUT

200mVrms, output impedance 1 kΩ (max. 3.0Vp-p)
Stereo mini jack

Control
functions

CONTROL D-sub 15-pin shrink plug

USB USB jack (B type)

Optional Parts

Lamp: LAMP-030
Air Filter: MU00832
* For others, consult your dealer.

ENGLISH-24ENGLISH-24

WARRANTY AND AFTER-SERVICE

WARRANTY AND AFTER-SERVICE

If a problem occurs with the equipment, first refer to the P.20 “TROUBLESHOOTING” section and
run through the suggested checks. If this does not resolve the problem contact your dealer or service
company.

PLEASE READ

We are in no way responsible for the
contents of the manual. We do not guarantee
its accuracy and we do not make any claim
of copyright. The copyright remains the
property of their respective owners.

Visit the site to read the latest projector
news and reviews, read and comment on
projector specifications, download user
manuals and much more.
