Chapter 1

Your Proxima Desktop Projector™ 4100/4200

The Proxima® Desktop Projector™ family consists of portable, color data and
video LCD and Digital Light Processing™ (DLP) Desktop Projection™
products that make sharing data and presenting information as easy as
connecting your computer to your monitor.

800
600
400
200

800
600
400
200

0

APR

MAY

JUN

JUL

0

APR

MAY

JUN

JUL

Figure 1-1 The Proxima DP4100/4200 in use

This manual covers the Desktop Projector™ 4100 and 4200, which both use
Digital Light Processing technology to provide images of unrivaled clarity
and color accuracy.

Your Proxima Desktop Projector™ 4100/4200

1-1

WHAT’S IN THE BOX?

After you’ve opened the box and removed the DP4100/4200 and accessory
packs, make sure you have all of the items shown in Figure 1-2.

CAUTION! The DP4100/4200 should be treated like any other precision

optical instrument. Handle it carefully.

MUTE

–VOLUME+

/O

MENU

SOURCE

SETUP

PROG 1PROG 2/

Proxima 

Remote Control Power Cord

Desktop Projector

S-Video Cable Computer 

Audio Cable

MAC

Mac – VGA

Cable Adapter

preview select

source

Monitor Adapter

VGA

MAC

VGA – Mac

Cyclops Quick

Remote Control

A85

Figure 1-2 Items included with the DP4100/4200

Audio/Video 

(AV) Cable

VGA Video Cable

Mini Jack to

RCA Adapter

Serial Cable ADB Cable

Also included but not shown:


• (2) AAA Alkaline Batteries

• User's Guide

• Product Registration Card


1-2

Chapter One

All models also include power cords for Europe, Great Britain, and Italy.

QUICK START

Place the DP4100/4200 on a solid flat surface at a right angle
(perpendicular) to the projection screen, parallel to the floor. Follow the
appropriate section below for the type of system that you have.

NOTE: The DP4100/4200 has two sets of computer video and audio inputs.
The following examples describe the use of input 1.

Desktop PCs

1 Unplug the monitor cable from the computer.
2 Plug the end of the supplied VGA cable with the large round collar into

the COMPUTER 1 IN port on the projector. Plug the other end into the
computer Monitor Out port.

3 Connect your audio source to the COMPUTER 1 AUDIO inputs on the

projector.

4 You can project without using the PC monitor. To use the monitor, plug

the monitor cable into the MONITOR OUT port on the projector.

5 Turn the projector on and press the key.

Desktop Macintosh Computers

1 Unplug the monitor cable from the computer.
2 Plug the end of the supplied VGA video cable with the large round collar

into the COMPUTER 1 IN port on the projector. Attach the VGA end of
the Mac - VGA cable adapter to the other end of the VGA video cable.

3 Plug the Mac end of the Mac - VGA cable adapter into your computer's

video port.

4 Connect your audio source to the COMPUTER 1 AUDIO inputs on the

projector.

5 To project and view the monitor at the same time, plug the monitor cable

into the Mac end of the VGA - Mac monitor adapter.

NOTE: The DP4100/4200 only supports the Multi-Sync standard as separate
monitors for Macintosh desktop computers.

6 Plug the VGA end of the VGA -Mac monitor adapter into the MONITOR

OUT port on the projector.

7 Turn the projector on and press the key.

Your Proxima Desktop Projector™ 4100/4200

1-3

NOTE: If you turn the projector off while the computer is running, the
external monitor will go blank. This is normal. Just turn the projector on
again and the monitor display will return.

Notebooks

NOTE: If you are connecting to an Apple PowerBook, attach the Mac - VGA
cable adapter to the computer’s Video Out port (or video adapter cable).

1 Plug the COMPUTER end of the VGA Video cable into the notebook’s

VGA Out port or into the Mac - VGA cable adapter (Macintosh only).

2 Plug the end of the VGA Video cable with the large round collar into the

COMPUTER 1 IN port on the projector.

3 Connect your audio source to the COMPUTER 1 AUDIO inputs on the

projector.

4 Turn on the projector and press the key.

Special Configurations

If your computer has an internal monitor but no external video capability
(such as the Macintosh Performa 575, PowerMac 5200, and certain
PowerBooks), you need a video adapter card in order to attach the DP4100/

4200.

1-4

Chapter One

Setup for a third-party adapter is identical to the procedures outlined in the
Quick Start section above. Contact your dealer, Proxima Customer Service, or
a third-party supplier for more information about an appropriate video
adapter.

CONNECTOR PANEL

All connections between the DP4100/4200 and computer or video source
are made on the side connector panel.

545

4

Video 1

S-Video1

Video 2

S-Video 2

3

Audio

Audio

Aux Port

Mic

6

7

Cyclops

8

3

Computer 1 Audio

Computer 1 In Monitor Out

2

1

2

Computer 2 Audio

Computer 2 In

1

Figure 1-3 The Connector Panel

CONNECTOR DESCRIPTION

1 COMPUTER 1 & 2 IN Connects computer video to the projector.

2 COMPUTER 1 & 2 AUDIO Allows stereo/mono audio input from the computer.

3 AUDIO Allows stereo/mono audio input from an NTSC,

PAL, or SECAM source.

Audio Out

10

9

4 VIDEO 1 & 2 Allows video input from an NTSC, PAL, or SECAM

source.

5 S-VIDEO 1 & 2 Allows S-Video video input.

6 AUX PORT For serial mouse use and software upgrades.

7 MIC Allows audio input from a microphone.

8 CYCLOPS Connects your computer for Cyclops input or output

and for use of Cyclops F/X software.

9 AUDIO OUT Provides audio output to an external stereo system.

10 MONITOR OUT Provides computer video output to a separate

monitor.

Your Proxima Desktop Projector™ 4100/4200

1-5

CONTROL PANEL

The DP4100/4200's control panel keys are used to turn the projector on or
off, adjust the projected image, and to display and hide the menu.

Power, warning, and alert lights give you important information about how
your projector is working.

Desktop Projector™ 4200

Source

4

5

3

3

Setup

2

6

Menu

7

1

8

Figure 1-4 The Control Panel

KEY FUNCTION

1 Turns the projector on or off if AC power switch is

on.

Power

Over-Temperature

Replace Lamp

1-6

Chapter One

2 Turns the image to a black screen.

3 Adjusts the volume up or down.

4 Activates the MediaExpress system (if installed).

5

6

7

Setup

Menu

Source

Activates the Setup menu.

Displays or hides the menu.

Switches the video inputs.

8 Controls the menu and adjusts screen position.

LIGHT FUNCTION

Glows green if AC input and projector power supplies are okay.
Glows red if not.

Glows red to warn of an over-temperature condition.

Glows red if the projection lamp burns out.

OPTIONS AND ACCESSORIES

The MediaExpress System

The MediaExpress™ system is a hybrid, next-generation product that brings
the functionality of computers and projectors much closer together.

The MediaExpress system eliminates the need to hook up a computer to the
DP4100/4200. Just print your presentation from whatever application you're
using to a special kind of file (called a .PDF file), copy or store the file on a
disk, then place the disk in the MediaExpress disk drive and start the show.

Cyclops

The Proxima Cyclops® interactive pointer system uses a built-in camera to
function like a cordless mouse. With Cyclops, you can control your
computer's cursor by moving the hand-held wand or pointing with an
optional hand-held laser.

Wireless Audio

Proxima’s exclusive wireless audio system operates in the 900 MHz RF band.
A user-installable transmitter sends stereo audio to speakers that decode the
signal for room-filling stereo sound.

The speakers have built-in RF receivers and can be switched to receive left,
right, or monaural signals. The user can power the speakers with either AC
or battery power.

NOTE: Check your local regulations to make sure that the 900 MHz frequency
is available for use.

Your Proxima Desktop Projector™ 4100/4200

1-7

Chapter 2

Setting Up the Desktop Projector 4100/4200

YOUR DP4100/4200

Before you begin, locate the main parts of the DP4100/4200.

1

2

1

3

2

11

4

PROXIMA

5

12

preview select

source

Video 1

Video 2

S-Video 2

Computer 1 Audio

Computer 1 In

S-Video 1

Audio

Computer 2 Audio

Computer 2 In

Aux Port

Audio

Cyclops

Mic

Audio Out

Video Out

10

Figure 2-1 The Proxima DP4100/4200 and Cyclops Remote Controls

SOURCE

PROG 1 PROG 2/

MUTE

–VOLUME+

/O

MENU

SETUP

6

7
8

9

1. Internal Speakers 7. Circuit Breaker

2. Cooling Fans 8. Main AC Power Switch

3. Control Panel 9. Power Cord Receptacle

4. Zoom Lens Assembly 10. Connector Panel

5. Cyclops/Infrared Lens 11. Workgroup Knob

6. Cyclops Remote Control 12. Cyclops Quick Remote

NOTE: The international version has three extra power cords for Europe,
Great Britain, and Italy.

Setting Up the Desktop Projector™ 4100/4200

2-1

GETTING STARTED

Positioning the Projector

Place the projector on a solid, flat surface at a right angle (perpendicular) to
the projection screen and parallel to the floor. If you’re using a media cart,
make sure the wheels are locked to prevent it from moving.

T op Vie w

Perpendicular to the

projection screen

Projection Screen

12 to 17.7°



Side View

Depending on zoom setting

2-2

Chapter Two

Parallel to the floor

Figure 2-2 Positioning the projector

Transporting and Moving the Projector

The projector has a recessed handle located in one of the side panels. Always
use the handle to transport the projector. The projector has protective feet
on the side opposite the handle, as well as on the bottom.

Figure 2-3 Transporting the projector

If you are moving the projector a short distance, grasp it securely at the sides
by the lower parts of the housing to support the weight of the unit.

Figure 2-4 Moving the projector

®

Setting Up the Desktop Projector™ 4100/4200

2-3

Projector Cooling and Airflow

Locate the air intake grills on the front and rear of the projector, and the air
exhaust grill on the top cover.

CAUTION! Never operate the projector if these grills are clogged or

obstructed, or if the electric fans are not running.

PROXIMA

Figure 2-5 Allow for proper air flow

2-4

Chapter Two

CONNECTOR PANEL

All connections between the projector and your computer or video source
are made on the side connector panel.

545

4

Video 1

S-Video 1

Video 2

S-Video 2

3

Audio

Audio

Aux Port

Mic

6

7

Cyclops

8

3

Computer 1 Audio

Computer 1 In Monitor Out

2

1

2

Computer 2 Audio

Computer 2 In

1

Figure 2-6 The Connector Panel

CONNECTOR DESCRIPTION

1 COMPUTER 1 & 2 IN Connects computer video to the projector.

2 COMPUTER 1 & 2 AUDIO Allows audio input from the computer.

3 AUDIO Allows audio input from an NTSC, PAL, or

SECAM source.

Audio Out

10

9

4 VIDEO 1 & 2 Allows video input from an NTSC, PAL, or

SECAM source.

5 S-VIDEO 1 & 2 Allows S-Video input.

6 AUX PORT For serial mouse use and software upgrades.

7 MIC Allows audio input from a microphone.

8 CYCLOPS Connects computer for Cyclops input or output

and for use of Cyclops F/X software.

9 AUDIO OUT Provides stereo audio output to an external

speaker system.

10 MONITOR OUT Provides computer video output to a separate

monitor.

Setting Up the Desktop Projector™ 4100/4200

2-5

CONNECTING POWER TO THE PROJECTOR

The power cord receptacle, AC POWER switch, and circuit breaker are
located next to the connector panel of the projector.

Circuit Breaker

Video 1

Audio

S-Video 1

Video 2

S-Video 2

Audio

Aux Port

Cyclops

Mic

AC Power Switch

Power Receptacle

Computer 1 Audio

Computer 1 In

Computer 2 Audio

Computer 2 In

Audio Out

Video Out

Figure 2-7 Power receptacle, AC Power switch, and circuit breaker reset switch

1 Plug the appropriate power cord into the power receptacle on the side of

the projector.

2 Connect the power cord to a properly-grounded wall outlet.

CONNECTING COMPUTER VIDEO

Connecting a PC

Use the included VGA video cable to connect your PC to the projector. Use
your existing monitor cable to connect the projector to a separate monitor,
so that you can use your monitor and DP4100/4200 at the same time.

VGA

VGA Connector Cable

VGA

2-6

Chapter Two

Figure 2-8 VGA Video cable

VGA Cable

To COMPUTER IN

From

MONITOR OUT

Figure 2-9 VGA connections

1 Unplug the monitor cable from the computer.
2 Plug the end of the supplied VGA cable with the large round collar into

the COMPUTER 1 IN port on the projector. Plug the other end of the
VGA cable into the computer's Video Out (VGA) port.

3 Connect your audio source to the COMPUTER 1 AUDIO inputs on the

projector.

NOTE: If you are using a second computer video or audio source, plug their
outputs into the COMPUTER 2 IN and COMPUTER 2 AUDIO connectors.

4 If you want to use an external monitor, connect the monitor cable to the

MONITOR OUT port of the projector.

5 Turn the projector on and press the key.

NOTE: An external monitor is not required to use the DP4100/4200.

Setting Up the Desktop Projector™ 4100/4200

2-7

Connecting Macintosh Computers

The video adapters shown below are used to connect a Macintosh computer
and monitor to the DP4100/4200.

From

Mac CPU



MAC

To VGA

Cable

Mac – VGA Cable Adapter

To Mac

Monitor Cable



MAC

From Projector

MONITOR OUT

VGA– Mac Monitor Adapter

Figure 2-10 The Macintosh adapters

Use the cable adapters and supplied VGA video cable to connect the
projector to your Macintosh computer.

VGA Cable 

to 

COMPUTER 1 

Mac - VGA

Cable Adapter

IN Port

2-8

Chapter Two

CPU

MAC II

Macintosh

Monitor Cable

To MONITOR OUT Port

Figure 2-11 Macintosh connections

VGA - Mac

Monitor Adapter

1 Unplug the Macintosh monitor cable from the computer.
2 Plug the end of the supplied VGA video cable with the large round collar

into the COMPUTER 1 IN port on the projector. Attach the VGA end of
the Mac - VGA cable adapter to the other end of the VGA video cable.

3 Plug the Mac end of the Mac - VGA cable adapter into the Macintosh

video port.

4 Connect the audio source to the projector's COMPUTER AUDIO 1 ports.

NOTE: If you are using a second computer video or audio source, plug their

outputs into the COMPUTER 2 IN and COMPUTER 2 AUDIO connectors.

Use the VGA - Mac monitor adapter and your existing monitor cable to
connect the projector to a separate computer monitor, so you can view
computer video on the projector screen and the monitor at the same time.

NOTE: The DP4100/4200 only supports the Multi-Sync standard as separate
monitors for Macintosh desktop computers.

5 To project and view the monitor at the same time, plug the monitor cable

into the Mac end of the VGA - Mac monitor adapter.

6 Plug the VGA end of the VGA - Mac monitor adapter into the MONITOR

OUT port on the projector.

7 Turn the projector on and press the key.

NOTE: An external monitor is not required to use the DP4100/4200.

Connecting Notebook Computers

Use the appropriate cable and adapter to connect your portable computer to
the projector.

To VIDEO

OUT Port

MAC II

CPU

MAC - VGA

Adapter

Figure 2-12 Laptop connections

VGA Cable

To COMPUTER 1

IN Port

Setting Up the Desktop Projector™ 4100/4200

2-9

NOTE: If you are connecting to an Apple PowerBook, attach the Mac - VGA
cable adapter to the computer’s VIDEO OUTPUT port (or video adapter cable).

1 Plug the COMPUTER end of the VGA cable into the computer’s VGA or

Video Out port or into the Mac - VGA cable adapter (Macintosh only).

2 Plug the end of the supplied VGA cable with the large round collar into

the COMPUTER 1 IN port on the projector.

3 Connect your audio source to the COMPUTER AUDIO 1 ports on the

projector.

4 Turn the projector on and press the key.

NOTE: If your projector is unable to project an image at the same time your

laptop monitor displays an image, refer to your laptop documentation for
information on switching between the internal screen and the video port.

Special Configurations

If your computer has an internal monitor but no external video capability
(Macintosh Performa 575, PowerMac 5200, and certain PowerBooks), you
need a video adapter card in order to attach the DP4100/4200.

Setup for a third-party adapter is identical to the procedures outlined in the
Quick Start section in Chapter 1. Contact your dealer, Proxima Customer
Service, or a third-party supplier for more information about an appropriate
video adapter.

2-10

Chapter Two

CONNECTING COMPUTER AUDIO

Connect audio inputs from a computer to the COMPUTER 1 & 2 AUDIO
ports with the supplied audio cable.

Computer 1 Audio

Computer 1 In

Figure 2-13 Computer 1 & 2 Audio ports

1 Insert the mini-jack end of the computer audio cable into the AUDIO

OUT port of a Macintosh or the sound card of a PC.

Computer 2 Audio

Computer 2 In

2 Insert the RCA jacks on the other end of the computer audio cable into

the projector’s left and right COMPUTER 1 AUDIO ports. If you are using
two audio sources, connect the second one to the projector's COMPUTER
2 AUDIO ports.

If your audio source is monaural, your projector will provide a simulated
stereo output. Connect your source to the left COMPUTER 1 AUDIO port.

NOTE: Although both COMPUTER AUDIO and AUDIO may be connected
simultaneously, only one can be active. If computer video is selected,
COMPUTER AUDIO is active. If NTSC/PAL/SECAM/S-Video video is being
viewed, AUDIO is active.

CONNECTING COMPOSITE VIDEO

You can display composite video (NTSC, PAL or SECAM) on the DP4100/

4200.

Video 1

Figure 2-14 Video 1 & 2 ports

Video 2S-Video 1

S-Video 2

Use the supplied AV cable (see page 1-2) to connect an NTSC, PAL, or
SECAM source to your projector.

1 Find the RCA connector on your video source marked VIDEO OUT or

something similar. This connector is usually yellow. Insert one of the AV
cable’s yellow connectors into the VIDEO OUT jack of the video source.

2 Insert the other yellow connector into the projector’s VIDEO 1 port.

CONNECTING AN S-VIDEO SOURCE

To connect an S-Video source, use the supplied S-Video cable (see page 1-2)
instead of an RCA cable connection. The S-Video cable has identical, round,
4-pin mini-DIN connectors on both ends.

Video 1

Figure 2-15 The S-VIDEO port

Video 2S-Video 1

S-Video 2

Setting Up the Desktop Projector™ 4100/4200

2-11

To connect an S-video source:

1 Insert one end of the S-VIDEO cable into the mini-DIN Video Out port of

the video source device.

2 Insert the other end of the S-VIDEO cable into the projector’s S-VIDEO

port.

CONNECTING NON-COMPUTER AUDIO

The AUDIO ports allow the projector to receive stereo or monaural audio
inputs from a composite video source.

Audio Audio

Figure 2-16 Audio Input ports

For stereo audio, use the supplied AV cable.

1 Insert the red (right) and white (left) ends of the cable into the AUDIO

OUT ports of a composite video's audio source.

2 Connect the other end of each cable to the projector’s AUDIO ports.

NOTE: Although both COMPUTER AUDIO and AUDIO may be connected

simultaneously, only one can be active. If computer video is selected,
COMPUTER AUDIO is active. If NTSC/PAL/SECAM/S-Video video is being
viewed, AUDIO is active.

2-12

If your TV audio source outputs only monaural audio, your Desktop
Projector will provide simulated stereo audio. Connect the audio source to
the left AUDIO port.

Chapter Two

Connecting a Mouse to the AUX Port (Serial)

A Microsoft®-compatible mouse can be connected to the AUX PORT to
control many of the projector’s built-in features. You can use your mouse to
navigate the projector’s menus in Local Mode or to function as the
computer's system mouse in Host Mode (see Chapter 3).

Aux Port

Figure 2-17 The Aux port

Connecting a Microphone

When you need to address a larger audience while projecting an image, plug
an amplified or wireless microphone equipped with a line level output
(maximum level of 1 volt, peak-to-peak) into the MIC port.

Cyclops

Mic

Audio Out

Figure 2-18 Microphone input

Connecting Cyclops

Use the CYCLOPS port to connect the projector and optional Cyclops
interactive pointer system to the computer.

Cyclops

Mic

Audio Out

Figure 2-19 The Cyclops port

Setting Up the Desktop Projector™ 4100/4200

2-13

The optional Cyclops interactive pointer system is shipped with its own
Installation and User’s Guides. The Cyclops kit also includes extra cables to
connect the projector and the computer.

1 Connect one end of the appropriate serial cable to the projector’s

CYCLOPS port.

2 Connect the other end of the cable to the computer:

• On a PC, connect the computer end to a serial port.

• On a Macintosh, connect the computer end to an ADB connector.

Projector Audio Out

The projector contains an internal stereo system consisting of an amplifier
and two speakers. Although this system provides high-quality stereo output,
a multimedia presentation may require independently powered speakers or
an external sound system.

NOTE: The projector’s internal speakers can be turned on or off using the
Audio menu (see page 3-24).

Audio Out

Video Out

2-14

Figure 2-20 The Audio Out port

To connect your projector to an external stereo system:

1 Insert the RCA jacks of the stereo system speaker composite video/audio

cable into the projector’s AUDIO OUT ports.

2 Insert the RCA jacks at the other ends into the external amplifier or

powered speaker system’s left and right AUDIO IN ports.

NOTE: A mini-jack to RCA adapter is provided (see page 1-2) in case your
external speaker system has a mini-jack plug.

Chapter Two
