QUICK SET-UP
The following steps will quickly lead you through set-up and
adjustments for the projector connected to a single computer.
The sequence numbers refer to the drawing of the quick setup. Before connecting, please remember to switch off the
computer and disconnect the projector power cord.
ENGLISH
SETTING UP
POWER OFF (1)
Switch off all equipment before
connecting.
COMPUTER (2)
Connect to the computer graphics
port. Use an optional MAC adapter
if needed.
SOUND (3)
Connect sound from the computer
using an optional 3.5 mm stereo
jack cable.
MOUSE (4)
Connect to the PS/2 mouse port.
Use optional cable and adapters for
MAC or serial mouse.
VIDEO (5)*
Connect video. Use a SCART
adapter if needed.
MAINS (6)
Connect the power cord.
USE
ZOOM , FOCUS AND POSITION
Zoom the lens for desired image size,
focus the lens for an optically sharp
image and tilt the unit using the
integral adjustable feet to position the
image on screen.
RESET
Press RESET to automatically adjust
for position, width and stability.
RESET is automatically invoked when
a new source is connected.
CONTRAST AND BRIGHTNESS
Adjust CONTRAST and
BRIGHTNESS as preferred.
* Video version only
POWER ON (7)
First switch on the projector, then
the source equipment for correct
recognition of the projector.
*** ILLUSTRATION, QUICK SETUP ***
USER GUIDE SVGA LCD PROJECTOR
TABLE OF CONTENTS
1 INTRODUCTION .................................................................................... 5
2 SYMBOL DESCRIPTIONS.....................................................................6
3 SAFETY INSTRUCTIONS......................................................................7
4 MAIN FEATURES................................................................................. 10
5 SUPPLIED MATERIAL......................................................................... 11
5.1 STANDARD MATERIAL......................................................... 11
5.2 OPTIONAL MATERIAL........................................................... 12
5.2.1 SERIAL MOUSE........................................................... 12
5.2.2 MACINTOSH................................................................ 12
5.2.3 CEILING MOUNT......................................................... 12
6 MAKING THE CONNECTIONS............................................................ 13
7 IMAGE ADJUSTMENTS....................................................................... 15
8 USING THE PROJECTOR ................................................................... 17
8.1 REMOTE CONTROL.............................................................. 17
8.1.1 REMOTE CONTROL KEYS .........................................18
8.2 PROJECTOR KEYBOARD AND INDICATORS..................... 20
8.2.1 KEYBOARD KEYS....................................................... 20
8.2.2 INDICATORS ............................................................... 21
8.3 THE MENU SYSTEM ............................................................. 22
8.3.1 THE SETUP MENU SELECTIONS .............................. 23
8.3.2 THE PICTURE MENU SELECTIONS........................... 23
8.3.3 THE SOUND SELECTIONS......................................... 24
8.3.4 THE OPTIONS SELECTIONS...................................... 24
8.3.4 THE HELP SELECTIONS ............................................25
9 CEILING MOUNTING........................................................................... 26
9.1 SELECTING A MOUNT.......................................................... 26
9.2 MOUNTING IN THE CEILING................................................ 27
9.3 WIRING.................................................................................. 27
10 TROUBLE-SHOOTING......................................................................... 28
11 MAINTENANCE.................................................................................... 30
11.1 GENERAL .............................................................................. 30
11.2 LAMP REPLACEMENT.......................................................... 30
11.3 THE REMOTE CONTROL...................................................... 32
12 TECHNICAL DATA............................................................................... 33
12.1 GENERAL ENVIRONMENTAL LIMITS .................................. 33
12.2 PROJECTOR UNIT................................................................ 34
PROJECTOR WEIGHT.......................................................... 34
12.3 POWER SUPPLY................................................................... 35
12.4 REMOTE CONTROL.............................................................. 35
12.5 COMPATIBILITY .................................................................... 35
12.6 PROJECTION DISTANCES................................................... 36
13 CONNECTOR PORTS ......................................................................... 37
13.1 COMPUTER........................................................................... 37
3
USER GUIDE SVGA LCD PROJECTOR
13.2 MONITOR............................................................................... 37
13.3 MOUSE .................................................................................. 38
13.4 AUDIO.................................................................................... 38
13.5 S-VIDEO* ............................................................................... 38
13.6 VIDEO (YELLOW)*................................................................. 38
13.7 LEFT AUDIO (WHITE)*.......................................................... 38
13.8 RIGHT AUDIO (RED)*............................................................ 39
14 ENVIRONMENTAL HANDLING ........................................................... 40
15 FCC STATEMENT................................................................................ 41
This publication is printed on environmentally friendly paper
The information contained in this User Guide, and the products described
herein are subjected to change without prior notice.
4
USER GUIDE SVGA LCD PROJECTOR
1 INTRODUCTION
Thank you for purchasing this state of the art SVGA ultra portable projector!
For long and lasting, safe and secure operation, please read this user guide,
and follow the instructions given. Failing to do so may cause product failure
that could void any warranties given, and in some cases be harmful and
dangerous to people.
For the experienced user, a quick set-up guide is included at the beginning
of this manual.
Please retain this user guide for future reference.
All references to video/video interface/video connections
made in this document only apply to the Video version of the
SVGA LCD Projector.
5
USER GUIDE SVGA LCD PROJECTOR
2 SYMBOL DESCRIPTIONS
DANGEROUS VOLTAGE
This symbol indicates the presence of high voltages inside
the product. High voltages may constitute electric shock
and may be lethal.
WARNING
This symbol alerts the user of important operating,
maintenance (servicing) and safety-related instructions.
HOT
This symbol indicates hot surfaces.
NOTE
This symbol is used to highlight specific information for the
user.
6
USER GUIDE SVGA LCD PROJECTOR
3 SAFETY INSTRUCTIONS
The following list of instructions is provided to ensure safe
and risk free use and operation of the projector. Failing to
read and follow these instructions may void any warranties
and may also cause personal injury and material damage.
1. READ INSTRUCTIONS - All safety and operating instructions should be
read before the projector is operated.
2. RETAIN INSTRUCTIONS - The safety and operating instructions should
be retained for future reference.
3. HEED WARNINGS - All warnings on the projector and in the User Guide
should be adhered to. If ignored, use of this projector may cause death,
injury or material damage.
4. CABLES AND CORDS - Use only original cables and cords as supplied
with the projector or as optional accessories. Using third party cables
that may look identical may lead to material damage and personal injury,
as the internal wiring in the cables may be different.
5. LAMP LIFE - The high-pressure lamp may explode if improperly used.
When the lamp lifetime is exceeded, the projector will issue a warning on
screen at start up, and a red indicator on the projector will light up.
Change lamp with an identical spare part as described elsewhere in this
User Guide.
6. LAMP BEAM - Do not look directly into the projector or lens when
operating the projector. The lamp emits rays of strong light, which may
cause eye injury and/or sunburns.
7. WATER AND MOISTURE - The projector is designed for indoor use only
and should not be used near water and moisture.
8. CARTS AND STANDS - Place the projector on a stable, hard surface in
a manner that does not obstruct ventilation ports and openings in the
projector housing. Unstable carts, stands, tables and other
arrangements may cause the projector to fall, which may cause serious
injury to people and/or damaging the projector and other material.
9. CEILING MOUNTING - When mounting the projector in the ceiling,
always ensure that all screws, bolts and other fixing devices of the
ceiling mount hardware are securely in place and tightened. Use only
7
USER GUIDE SVGA LCD PROJECTOR
well dimensioned ceiling mounts from a renowned supplier. Connect the
projector to a switched mains power supply, and switch off when not in
use, for maximum protection against fire. Switching off using the remote
control only puts the projector in a standby (sleep) mode with live
internal voltages.
10. VENTILATION - Slots and openings in the projector housing are
provided for ventilation. Air inlet filters are employed to reduce dust
build-up internally. Periodically vacuum the filters (from the outside of the
ventilation grilles) as needed. To ensure reliable operation of the
projector and protection from overheating, do not block or cover slots or
openings in any way. Do not insert any foreign objects or instruments
into the slots and openings, as this may block the ventilation fans. Do
not place the projector on a soft surface (carpet etc.). Never install the
projector in an enclosed unit unless it is properly ventilated by a
separate cooling system.
1
2
1 & 2 Ventilation slots
11. HEAT - The projector should be situated away from heat sources such
as sunlight, radiators stoves or other strong heat sources. Do not
operate the projector outside the maximum temperature specifications.
12. OBJECT OR LIQUID ENTRY - Care should be taken so that objects are
not put or do not fall into the projector housing. Be careful not to spill
liquids that may flow into the projector interior. Do not insert metal or
flammable objects into the projector.
13. POWER SOURCES - The projector must only be connected to proper
electrical voltage as marked on the projector body, on the label at the
power inlet. The projector should be connected to the electrical outlet
using a power cord compatible with the local electrical voltage. Never
operate the projector outside the electrical voltage specification. If you
are unsure about the type of electrical service at your location, please
consult your dealer or local Power Company.
8
USER GUIDE SVGA LCD PROJECTOR
14. POWER CORD PROTECTION - Power cords should be routed so that
they are not likely to be walked on, pinched or unduly bent by items
placed upon or against them. Pay particular attention to cords and
cables at the point where they exit from the projector.
15. GROUNDING OR POLARIZATION - Precautions should be taken so
that grounding or polarization of the projector is maintained. Do not use
a three prong to a two-prong adapter.
16. ELECTRICAL SHOCK - To reduce the risk of electrical shock, do not
open the unit. Refer all servicing to authorized personnel only.
17. CLEANING - The projector should be cleaned only as recommended,
see the Maintenance section. Disconnect the power cord from the power
outlet before cleaning. Do not use liquid, spray or aerosol cleaners.
18. NON-USE PERIODS - The power cord of the projector should be
unplugged from the outlet when left unused for a long period of time.
19. LAMP REPLACEMENT - Replace projection lamp with same type and
rating as shown in the Technical Data section. Allow unit to cool down
before replacement.
20. SERVICING - The user should not attempt to perform unusual or
technical service to the projector. Do not open the unit, except for the
lamp replacement door. Refer all servicing to authorized personnel only.
Replace damaged cords or cables with original replacement parts only.
21. DAMAGE REQUIRING SERVICE - The projector should be serviced by
authorized personnel when:
Objects have fallen, or liquid spilled, into the projector
The projector has been exposed to water or moisture
The projector does not appear to operate normally (fan not working,
Noise, smell, smoke, heat etc.)
The projector has been dropped or damaged
22. ABNORMALITY - If you detect any abnormal smell or smoke,
immediately turn off the power switch. Disconnect the power plug from
the inlet to prevent fire or electrical shock.
23. LIFTING AND MOVING - Let the projector cool down before moving.
Disconnect the power cod and all other cables. Carry the unit by the
handle provided. The projector should preferably be transported in a
suitable case.
9
USER GUIDE SVGA LCD PROJECTOR
4 MAIN FEATURES
The unit employs the following important features that in total provide you
with a highly functional and powerful projector:
• High brightness image
• Compact and light
• Automatic adjustments/setup
• Digital zoom
• User replaceable UHP-lamp
• True SVGA 800 x 600 resolution
• 640 x 480 to 1152 x 864 image compatibility
• 16.7 million colors
• Stereo sound
• Infrared remote control with trackball mouse
emulation
• Comprehensive menu system
• On screen display (OSD)
• User and source settings memorized
• Low noise cooling system
• False light blocking
• Power down management
• Smooth scaling of non SVGA image
• Low power consumption
10
USER GUIDE SVGA LCD PROJECTOR
5 SUPPLIED MATERIAL
5.1 STANDARD MATERIAL
A complete set includes the following components:
2
3
4
1. LCD Projector 5. Remote Control
2. Computer cable w/PS/2 mouse 6. Batteries
3. RCA Cable* 7. User Guide
4. Power Cord 8. Soft Case (not shown in drawing)
* Video version only
The standard material is subject to change without prior notice
6
7
11
USER GUIDE SVGA LCD PROJECTOR
5.2 OPTIONAL MATERIAL
Various cables, adapters and accessories are available as options. Consult
your dealer for further information.
5.2.1 SERIAL MOUSE
In order to connect to a Serial Mouse the following is required:
• 4 meter mouse cable
• Serial Mouse adapter
5.2.2 MACINTOSH
In order to connect to a MAC computer the following is required:
• MAC computer adapter
• MAC monitor adapter
• 4 meter mouse cable
• MAC Mouse adapter
5.2.3 CEILING MOUNT
To mount the projector in the ceiling, a special ceiling mount kit is available
12
USER GUIDE SVGA LCD PROJECTOR
6 MAKING THE CONNECTIONS
The projector may be connected to different equipment. The following
sections describe in detail how to connect to these systems.
See the illustration on the rear of the quick set-up card on
how the various system parts connect together.
Be aware of static electricity that may build up in the dry
season and when operating on synthetic carpets. Discharge
any static electricity by touching a metallic surface before
you start.
Place the projector on a table at a suitable distance to the projection screen.
Select a screen with good reflectivity and avoid direct sunlight shining in.
Place the projector so that the image is visible to the whole audience, and
so that the unit does not obstruct the view.
Various cables are supplied or optionally available to connect to different
sources. Follow the list below in numerical order for a trouble-free set-up!
1. SWITCH OFF all equipment before making all the connections.
2. COMPUTER GRAPHICS ADAPTER.
Computer graphics adapters use different connectors depending on the
actual computer system in use. Adapters are used at the computer end
for non-VGA type connections
• PC. Use the computer cable directly to connect to the graphics port.
If needed, connect your monitor to the MONITOR connector on the
projector.
• MAC. Connect the optional MAC adapter marked COMPUTER on
the computer end to adapt to the graphics-port. The optional
adapater marked MONITOR is connected to the monitor cable if
needed.
13
USER GUIDE SVGA LCD PROJECTOR
3. SOUND.
Connect sound using an optional 3.5 mm stereo cable.
4. MOUSE.
You may control the mouse directly from the wireless remote control.
• PS/2. The cable connects directly, without the use of an adapter.
Running the computer mouse in parallel is not possible, unless your
computer itself has provision for two mice simultaneously. You may
consider using the serial (RS232) adapter and run your mouse on
the serial port instead, in order to be able to run your local mouse in
parallel. This will require a different mouse driver setting. Please
consult your computer documentation or local dealer for details.
• SERIAL (RS 232). Use the optional cable and serial adapter with a
branch for the local computer mouse. The serial adapter is fitted with
a 9-pin DSUB connector. Use an extra 9 to 25 pin adapter (available
from your dealer) if your computer has a 25 pin serial connector.
Connect your computer mouse to the free branch of the adapter if
desired. With some computers, the branched adapter may not work.
For this purpose, an optional straight serial adapter is available.
• MAC. Use the optional cable and MAC mouse adapter to connect to
the mouse port on your MAC computer.
5. VIDEO. *
The video version connects directly to standard RCA (phono) connectors
for sound and video. You may use a SCART adapter at the source end if
needed.
6. MAINS POWER.
Connect the mains cord to the projector and all other equipment in the
set-up.
7. SWITCH ON the projector first, then the computer. It is important to
switch the projector on first in order for correct detection of the projector
as a display and mouse peripheral device to the computer.
14
USER GUIDE SVGA LCD PROJECTOR
7 IMAGE ADJUSTMENTS
This section will aid in adjusting a stable, flicker-free image for best viewing
results.
Use the remote control or the projector keypad to adjust settings, either
directly or through the menu system.
The following list aids in a trouble free set-up of the
projector. Try using a patterned background (tiles,
checkerboard pattern etc) when adjusting the image.
1
2
1. Zoom
2. Focus
3
4
3. Foot release button
4. Adjustable foot
1. ZOOM, FOCUS AND POSITION IMAGE. The projection lens has a
manually adjustable zoom and focus. Place the projector at a suitable
distance to the projection screen; alternatively zoom the image, to obtain
the desired screen size. (See the Technical Data section for max and
min projection distances.) Focus the image and observe that the picture
elements (pixels) become sharp on screen. The projector has two
15
USER GUIDE SVGA LCD PROJECTOR
adjustable feet in the front, so that the image can be shifted to a desired
height on the wall. Tilt the projector body in the desired position and
press the foot-release buttons. If necessary, fine adjust the height by
screwing the feet either direction.
2. RESET in most cases automatically adjusts the image position, width
(FREQUENCY) and stability (TUNE). If RESET fails to adjust the image
correctly, see FREQUENCY, POSITION and TUNE below. RESET is
automatically activated when a new source is connected.
3. CONTRAST and BRIGHTNESS may be adjusted according to your
personal taste, the image and the viewing conditions. The controls are
directly accessible on the remote control and on the projector keyboard.
4. FREQUENCY. The frequency controls the width of the image. A wrong
frequency setting can be seen as equally spaced, vertical stripes or
irregularities in the pattern displayed. Press the MENU key, SET-UP,
FREQUENCY and press ENTER. Adjust the value up or down using the
trackball or keyboard cursor controls, observing that the amount of
vertical stripes reduces, until the distortion is gone. You may still have an
unstable image, please see the next section.
5. POSITION the image correctly by accessing SET-UP, POSITION, then
press ENTER and adjust position with the trackball or keyboard cursor
controls
6. TUNE the image for a stable projection. In the menu, select SET-UP,
TUNE and press ENTER. Adjust stability using the trackball.
Set-up should be done once with the source(s) you are using most
frequently. Allow some minutes for the unit to warm up before adjusting the
settings. Most settings will be memorized individually for each source for
future use.
16
USER GUIDE SVGA LCD PROJECTOR
8 USING THE PROJECTOR
The projector has a set of features and functions you should familiarize with
in order to get the most out of using the unit.
8.1 REMOTE CONTROL
The remote control is used to adjust the projector for the best possible
image, either directly or through the menu system. It is also used during
presentations for computer mouse control and with special presentation
tools.
The remote control may be pointed directly at the projector
front or rear, where the receivers are situated, or indirectly
by pointing at the projection screen. When pointing at the
screen, point at an angle that reflects the beam towards the
projector.
3
4
6
8
1. Wire Connection* 4. Light Key 7. Right Key
2. ON/OFF Switch 5. Trackball 8. Bottom Key (Drag)
3. LED Indicator 6. Left Key (Enter)
* Not applicable for this product
17
1
2
5
7
USER GUIDE SVGA LCD PROJECTOR
The trackball is by default controlling the computer mouse (if the mouse
cable is connected properly). With some functions, like POINTER, MASK
and in the menu system, the mouse control is disabled.
In the menu system, the trackball is used for navigation between the
different alternatives, and when a function is selected, the trackball is used
for adjustment of that function.
Turn on the remote control by sliding the ON/OFF-switch to ON position. To
avoid draining the batteries, turn the remote control OFF after use.
8.1.1 REMOTE CONTROL KEYS
The following table describes each key in detail. Some functions are
memorized, while other functions are only momentary.
The MEM column indicates whether the function setting is memorized.
ON/OFF
CONTR
BRIGHT
VOLUME
POWER
RESET
MASK
PROG
MUTE
FREEZE
Switches the remote control on/off (battery save)
Adjusts contrast.
Controls brightness.
Adjusts audio sound volume.
Turns the projector into either operating or
standby mode. In standby mode the projection
lamp is switched off.
Automatically adjusts the image correctly
Applies a mask to the image, which can be moved
up and down using the trackball.
This key may be programmed to any one of the
menu controls.
Switches the sound on/off.
Holds the image projected on the screen.
MEM
MEM
MEM
MEM
18
USER GUIDE SVGA LCD PROJECTOR
COMPUTER
VIDEO *
S-VIDEO *
AUX **
POINTER
ZOOM
PAN
LIGHT
MENU
TRACKBALL
RIGHT
Selects computer as the active source.
Selects video as the active source.
Selects S-video as the active source.
Selects optional auxilliary input as the active
source.
Applies a trackball-controlled pointer to the screen.
Press to zoom in on the image. Use the trackball
to zoom in or out. Change the zoom area by using
PAN.
Allows panning within oversized (zoomed) images
using the trackball.
Press to illuminate the keypad.
Invokes the menu system.
The trackball is mainly used to control the mouse
pointer (if the mouse cable is attached properly).
When ZOOM, MASK, PAN or MENU is invoked,
mouse control is disabled, as the trackball is used
to control these functions instead. Trackball
sensitivity, except for the mouse, is set under
OPTIONS in the menu system. Mouse sensitivity
is set at your computer as with the standard
mouse.
Emulates the right mouse key.
BOTTOM/
DRAG
LEFT/
ENTER
* Video version only.
** Only when auxilliary adapter is fitted
This emulates the “click-and-hold” function of the
desktop mouse.
Use BOTTOM/DRAG key instead of RIGHT key
when connected to a Macintosh computer.
Emulates the left mouse key.
Once the menu is accessed selections are
confirmed using LEFT/ENTER key.
19
USER GUIDE SVGA LCD PROJECTOR
which can be altered to suit local lighting conditions.
POWER
ALARM
8.2 PROJECTOR KEYBOARD AND INDICATORS
The keypad on the projector gives access to all controls, either directly or
through the menu system.
VOLUME
CONTRAST
8.2.1 KEYBOARD KEYS
POWER
CONTRAST
BRIGHT
VOLUME
MENU
SOURCE
CURSOR
KEYS
ENTER
HELP
RESET
BRIGHT
Turns the projector into either operating or
standby mode. In standby mode the projection
lamp is switched off.
Adjusts contrast, the ratio between light and dark
colors.
Adjusts brightness, the whiteness of the image,
Volume of the audio output can be altered to suit
local conditions.
Invokes the menu system.
Toggles between available input ports.
The cursor keys are used to navigate in the menu
system.
Emulates the left mouse key.
Once the menu is accessed selection are
confirmed using ENTER.
Enters help-section in menu
Automatically adjusts the image correctly
MENU
SOURCE
ENTER
HELP
RESET
MEM
MEM
MEM
20
USER GUIDE SVGA LCD PROJECTOR
8.2.2 INDICATORS
POWER
ALARM
• NO LIGHT indicates that the unit power cord is
disconnected.
• GREEN FLASHING indicates that the POWER key
has been pressed and the fan is starting.
• GREEN indicates that the unit is operational.
• YELLOW indicates that the unit is in standby mode
(switched off using the remote control or the
keypad)
• YELLOW FLASHING when the POWER key is
pressed to switch the projector off (fan runs/lamp
switched off).
• RED indicates lamp lifetime overdue.
• RED FLASHING when the projector is overheated.
21
USER GUIDE SVGA LCD PROJECTOR
8.3 THE MENU SYSTEM
The menu system is designed to gain access to functions not often used, as
opposed to frequently used features that are directly available through the
remote control and the projector keypad.
• Press the MENU key to invoke or exit from the menu system. The
MENU is also switched off after one minute of inactivity. Most
settings are memorized unless otherwise noted.
• When the menu is active, the trackball is used to navigate between
options (and therefore is not available for mouse control etc. at the
same time). The ENTER key is used to activate or deactivate a
function.
• Toggle functions (like OSD, REAR etc) are tagged when active and
untagged when not active.
• Increase/decrease functions (like TUNE and FREQUENCY etc) are
adjusted using the trackball or keyboard cursor controls. The OSD
field (in the lower left corner of the screen) indicates the actual
settings.
• The PROG key may be assigned to any of the menu functions.
The main menu selections SETUP, SOUND, OPTIONS and HELP are
explained in detail below.
Features available with some sources only are shown in grey color
characters, while generally available functions are in normal case.
22
USER GUIDE SVGA LCD PROJECTOR
8.3.1 THE SETUP MENU SELECTIONS
TUNE
FREQUENCY
POSITION
REAR
CEILING
COLOR TEMP.
FACTORY
RESET
Is used to stabilize the image. An untuned
image can be seen as sideways instability or
“swimming”.
Is provided to adjust image width. Generally,
an incorrect frequency setting can be
observed as an image too wide or too narrow,
combined with vertical, unstable bands.
Due to minor variations in graphic cards, the
horizontal and vertical position may need
adjustment. Select POSITION, then press
LEFT and use the cursor keys or trackball.
Inverts the image for use in rear projection
arrangements i.e. projection from the back of a
screen.
Switches between an upright and an upsidedown projection by flipping the image
vertically.
(Color Temperature) adjusts the red and blue
color components.
This function resumes factory settings of all
parameters.
8.3.2 THE PICTURE MENU SELECTIONS
These functions are only active for video sources.
MEM
MEM
MEM
MEM
MEM
MEM
MEM
TINT
SHARPNESS
COLOR
16 : 9
Controls the hue of an image, and is only
active in NTSC-video.
Controls the sharpness of the lines in an
image.
Adjusts color saturation.
Switches between standard 4 : 3 format and
16 : 9 Widescreen format.
23
MEM
MEM
MEM
MEM
USER GUIDE SVGA LCD PROJECTOR
8.3.3 THE SOUND SELECTIONS
TREBLE
BASS
BALANCE
MUTE
Controls the higher sound range.
Controls the lower sound range.
Controls the sound balance between the two
stereo speakers.
Switches the sound on/off separately for each
source.
MEM
MEM
MEM
MEM
8.3.4 THE OPTIONS SELECTIONS
ZOOM
PAN
HIDE OSD
SOURCE
SEARCH
POWER
MANAGEMENT
RS232
TRACKBALL
SENSITIVITY
Use the trackball or the cursor keys on the
projector keyboard to zoom in or out. Change
the zoom area by using PAN.
Allows panning within oversized images using
either the keyboard cursor keys or the remote
control trackball.
Switches the on-screen echoing of controls on
and off. This setting only affects the direct
control operations, not the menu system
A toggle function that control whether or not
the projector shall automatically search for an
active source on the other input ports when
the selected source is not active.
Manual source selection is maintained in both
modes.
System initiating power down of the projector
to avoid image imprint on the module. Refer to
the Projector Keyboard section for details.
Controls the serial interface of the MOUSE
port. MOUSE (default) and CONTROL* are
available options.
Controls the response of the remote control
trackball in the menu system. FAST, MEDIUM
and SLOW are available options.
(These functions do not affect the response of
MEM
MEM
MEM
MEM
24
USER GUIDE SVGA LCD PROJECTOR
the computer mouse. If you want to adjust the
mouse sensitivity, please do this on the
computer).
LANGUAGE
POINTER
MASK
SPLIT SCREEN
SERVICE
* For more information on RS232 control, contact your local dealer or consult the manufacturers’
home page.
A selection of languages is available for the
menu options, including :
English, German, French, Italian, Spanish,
Norwegian, Japanese, Korean and Chinese.
Other languages may apply
Selects the pointer appearance. Options
include BALL, ARROW and CROSS. Other
shapes may apply.
Selects whether the mask is applied
downwards or upwards.
Selects between ordinary full screen and split
screen, which is used to project a large image
with four projectors. Options include NONE,
UPPER LEFT, LOWER LEFT, UPPER RIGHT
and LOWER RIGHT.
Is used to reset the lamp timer.
MEM
MEM
MEM
MEM
MEM
8.3.4 THE HELP SELECTIONS
SOURCE INFO
ABOUT
Provides a status list of parameters relating to
the source selected.
Provides system information about the
projector.
25
USER GUIDE SVGA LCD PROJECTOR
9 CEILING MOUNTING
The projector is prepared for ceiling mounting. As opposed to desktop use
(most tables are approx. 80 cm tall, are flat and have a hard surface finish),
ceilings vary in height and material. Also considerations must be made with
respect to signal and power wiring.
9.1 SELECTING A MOUNT
Various mounting systems are available from different sources. Contact
your dealer for further details or consult vendor catalogs. Be sure that the
vendor has tested the mount with this specific projector for operational
safety. Check that the mounting brackets fit the integral mounts of the
projector (illustration below), and that the ventilation slots are not blocked.
98 mm
182 mm
26
USER GUIDE SVGA LCD PROJECTOR
9.2 MOUNTING IN THE CEILING
An improperly mounted projector is a potential danger to
people and equipment. A projector and mount falling down
may cause personal injury and material damage. Such
damage caused by bad workmanship in mounting and
operation may lead to legal action and should be avoided.
Avoid ceiling mounting of the projector in areas of frequent
or probable earthquakes.
When fixing the mount in the ceiling, be sure to check the ceiling material
and if it will hold the total weight of the mount and the projector. Look for
wood, steel beams or concrete that will secure a good and lasting fixture.
Avoid plaster or other fragile materials that do not have sufficient structural
properties. Follow the detailed instructions supplied with the ceiling mount
for proper mounting and operation.
After having mounted the projector in the ceiling, test if the holding force is
sufficient by adding a load to the mount at least double the weight of the
combined projector and mount. The mount should hold this extra weight with
no sign of fatigue and with no sign of mounting screws loosening.
9.3 WIRING
Ceiling mounted projectors require long signal and power wires. The signals
should be wired using high quality coaxial cable. The cables usually need to
be customized. Some vendors have specialized in this field. Contact your
dealer for further detail.
If the signal cables run over a longer distance from the source to the
projector, a line buffer (distribution amplifier) may be needed (available from
third party vendors).
For potential fire reasons, the power wiring should be
separately switched so that the projector can be switched off
completely when not in use. The ON/OFF on the remote
control only suspends operation of the projector without
switching off completely.
27
USER GUIDE SVGA LCD PROJECTOR
10 TROUBLE-SHOOTING
This is a checklist to help you pinpoint any problem that may arise. Check
the symptoms carefully if you experience any problem. The cure may be at
your fingertips!
Always check that the red LED indicator in the front of the
projector flashes when a key on the remote control is
pressed. This indicates that the projector is receiving signals
from the remote control.
Be aware that the projector has to cool down for 30 seconds
after entering standby-mode, before it can be turned back on
again.
The projected image is completely black.
• The unit may have overheated due to the ventilation slots being
covered while the projector was in use. Also ensure that the ambient
temperature is within spec.
• Check the air inlet filters, as they may need vacuuming (see
Maintenance). Wait until the unit has completely cooled down before
using again.
The projector is only displaying logo.
• Check if a source is connected.
The projected image is too dark or too light.
• Adjust the CONTRAST and BRIGHTNESS settings.
• Push HELP to view the setup picture/information.
• Press RESET, which will remove the pre-determined settings for the
current source, and make the setup adjustments again.
Some colors are unstable or flickering
• Try to improve the tuning by accessing TUNE in the menu system.
• Check first that there are no loose cable connections, or any bent
pins in the cable connector.
• You can try to adjust the image quality with the CONTRAST and
BRIGHTNESS keys.
28
USER GUIDE SVGA LCD PROJECTOR
The whole image appears to be unstable or misplaced
• Press reset.
• Adjust the frequency and tuning settings (instability), or the image
position settings (misalignment).
• Check that you are using a source with compatible resolution.
• The projector may be connected to a source with a non-standard
computer (or video card). Adjust the frequency and position of the
image.
Cooling fan is not working when lamp is lit
• If the fan does not work the projector must not be used and should
be returned to your dealer for repair.
The remote control is not working
• The red LED on the remote control should flash when transmitting. If
not, check the ON/OFF switch or the batteries.
• Make sure you point the remote control at the projection screen or
directly at the IR receivers. The front red LED indicator flashes when
receiving signals from the remote.
• The maximum range of the IR transmitters is 15m (50 feet) - Are you
standing close enough?
• If the effective range of the transmitters is significantly reduced, the
remote control needs new batteries.
The desktop mouse is not working
• Remember to follow this sequence when connecting the mouse:
- Connect the mouse cable.
- Connect the projector power cable
- Power on the computer
• You must boot the computer after the cable has been connected for
it to recognise the mouse. If you are unsure whether this was the
case, reboot your computer.
• Are the mouse cable (and mouse adapter) connections secure?
• Check the mouse driver settings on the computer
29
USER GUIDE SVGA LCD PROJECTOR
11 MAINTENANCE
The projector needs very little maintenance in order to function properly.
11.1 GENERAL
Use a damp cloth to wipe off dust on the exterior. Clean the lens with a
damp, non-abrasive cloth, using just water or a standard lens cleaning
solution available from photographic dealers.
Vacuum the air inlets periodically, especially when build-up
of dust is observed. This will ensure cool operation of the
unit.
Do not scratch the lens surface. Use the lens cap when the projector is not
in use for added protection. Remember to remove the lens cap before
operating the unit!
11.2 LAMP REPLACEMENT
The projector is using a custom UHP-lamp for illumination. The lamp is high
pressure when hot (operating or immediately after switch-off). Lamp
pressure is normal when cold.
A lamp timer is available in the menu system under HELP, ABOUT, that
may be used to track lamp operating time. The user may reset the timer.
Disconnect the power cord before opening the lamp lid to
change the lamp.
1. To change lamp, remove the lamp lid by pressing in the snap lock and
lifting up (see illustrations below). A safety switch will cut off the power
supply to the lamp completely.
2. Unscrew the 2 safety screws holding the lamp holder, fold out the
handle and pull out the old lamp holder.
3. Insert a new lamp holder/lamp all the way until it positively stops, fold
the handle and reverse the procedure above.
Use only original lamp and holder as specified. The lamp is
individually adjusted with the holder to maintain optimum
illumination. Replacement using a different lamp may result
in poor illumination, malfunction (potentially explosion) and
will void any warranties.
30
USER GUIDE SVGA LCD PROJECTOR
1
2
3
To reset the lamp timer, invoke the menu system under OPTIONS,
SERVICE, and LAMP TIMER RESET. You need to confirm that you actually
intend to reset the lamp timer, or cancel if you accidentally invoked the
function.
1. Snap lock
2. Lamp lid
4
5
3. Lamp assembly
4. Handle
5. Securing screws
31
USER GUIDE SVGA LCD PROJECTOR
11.3 THE REMOTE CONTROL
The infrared remote control requires little maintenance.
The trackball element may be cleaned occasionally with a damp (not wet)
cloth. To take out the ball, twist the ring holding the ball anti-clockwise.
Having taken out the ball, you may also clean the trackball interior using a
damp (not wet) cotton swab.
To change the batteries, open the battery holder on the rear of the handset.
Remove the old batteries and dispose of carefully. Insert new batteries of
the type described in the Technical Data section, observing the polarity
instructions inside the battery holder, and close the snap lock door. Switch
the remote control back on by using the ON/OFF-switch on the right hand
side of the remote. Test that the remote control functions correctly by
pressing the LIGHT key to see if the backlighting operates properly.
32
USER GUIDE SVGA LCD PROJECTOR
12 TECHNICAL DATA
The technical data given in this section was correct at the
This projector is designed for indoor use and should not be operated or
stored in conditions outside the general environmental limits given in section
below, as this may lead to permanent damage and will violate any
warranties.
12.1 GENERAL ENVIRONMENTAL LIMITS
time of going to print, but may change without prior notice in
order to improve product performance.
STORAGE
TEMPERATURE
STORAGE HUMIDITY
OPERATING
TEMPERATURE
OPERATING HUMIDITY
Allow for slow acclimatization after storing at extreme
temperatures and humidities, to avoid condensation. Should
condensation appear, leave the projector unit in a controlled
environment within the operating limits until the
condensation has evaporated before using the projector.
-20 - 60°C (-4 - 140 F), sea level
10 - 90 % relative humidity, non-
condensing
10 - 35°C (50 - 95 F) ambient, sea level
20 - 80 % relative humidity
33
USER GUIDE SVGA LCD PROJECTOR
0.48 – 7.62 m / 19 - 300 inches (Tele)
12.2 PROJECTOR UNIT
PROJECTOR DIMENSIONS
(H x W x L)
PROJECTOR WEIGHT
PROJECTION LENS
IMAGE SIZE
PROJECTION DISTANCE
ANTI-KEYSTONE CORRECTION
PROJECTION LAMP
LIGHT OUTPUT
LIGHT VALVE
COLOR RESOLUTION
CONTRAST RATIO
PIXEL RESOLUTION
DEFECTIVE PIXELS
VIDEO FREQUENCY
HORIZONTAL SYNC
VERTICAL SYNC
COMPUTER INPUT
AUDIO INPUT
SPEAKERS
CONFORMANCE
113 x 225 x 313 (358 incl. lens) mm
45 x 89 x 123 (141incl. lens) inch
3.5kg / 7.7 lbs.
Manual zoom and focus lens
1.3 zoom ratio
f 38-49 mm
F 1.7-2.0
0.65 - 7.62 m / 25 - 300 inches (wide)
1.2 – 15.6 m / 3.9 – 51.2 ft
8 - 11 degrees
120 W UHP
650 ANSI lumen
3 x 0.9” polysilicon TFT LCD
16.7 MILLION
300:1
800 x 600 x 3
15 (max)
12 - 150 MHz
15 - 100 KHZ
43.5 - 130 HZ
0 - 1 Vpp
1V RMS
2 x 1 W speakers
• CE
• UL
• CUL
• FCC, Subpart J, Part 15
34
USER GUIDE SVGA LCD PROJECTOR
12.3 POWER SUPPLY
DUAL VOLTAGE
12.4 REMOTE CONTROL
UNIT SIZE (H x W x L)
UNIT WEIGHT
BATTERIES
FUNCTIONAL RANGE
COMPATIBILITY
CONFORMANCE
12.5 COMPATIBILITY
The projector is compatible with the interfaces and resolutions shown below,
some of which are predefined. However since different varieties of these
exist, a frequency adjustment may be needed.
VGA
SVGA
XGA
MAC
NTSC
PAL/
SECAM
640 x 350
640 x 400
640 x 480
720 x 400
800 x 600
1024 x 768 (compressed)
640 x 480
832 x 624
1024 x 768
1152 x 870 (compressed)
640 x 480
768 x 576
100 - 120 VAC, 60 Hz, +/- 10 %
220 - 240 VAC, 50 Hz, +/- 10 %
200 W OPERATING, 15 W STANDBY
20 x 50 x 190 mm / 0.78 x 1.97 x 7.48 inch
100 g / 0.22 lb. (with batteries)
4 pcs LR03/AAA 1.5V penlight
15 m (50 ft)
Microsoft 2-key serial; MAC; PS/2
CE, FCC
35
USER GUIDE SVGA LCD PROJECTOR
15.60m/ 614
12.6 PROJECTION DISTANCES
The following table shows the combinations of projection distances and
screen sizes that are possible.
MINIMUM MAXIMUM
WIDE
DISTANCE
DIAGONAL
WIDTH
HEIGHT
TELE
DISTANCE
DIAGONAL
WIDTH
HEIGHT
1.00m/ 39” 3.20m/ 126” 5.60m/ 220” 12.00m/ 472”
0.63m/ 25”
0.51m/ 20” 1.63m/ 64” 2,84m/ 112” 6.10m/ 240”
0.38m/ 15”
1.00m/ 39” 3.10m/ 122” 5.30m/ 209”
0.48m/ 19” 1.52m/ 60” 2.54m/ 100”
0.39m/ 15” 1.22m/ 48” 2.00m/ 80” 6.10m/ 240”
0.29m/ 11” 0.91m/ 36” 1.52m/ 60” 4.57m/ 180”
2.00m/ 80”
1.22m/ 48”
3.56m/ 140” 7.62m/ 300”
2.13m/ 84 ”
4.57m/ 180”
7.62m/ 300
”
”
Please consider the values given as nominal, with a variation of +/- 10%.
36
USER GUIDE SVGA LCD PROJECTOR
13 CONNECTOR PORTS
The pinouts of all the connector ports is described in this section.
S-VIDEO VIDEO
AUDIO
R
L
COMPUTER
MOUSE
AUDIO
Do not connect any devices or cables other than those
supplied with the projector into the connector ports on the
projector unit, even if the connector ports appear identical,
as this voids any warranty and may cause permanent
damage to the projector.
13.1 COMPUTER
This port relays all signals from the computer to the projector.
11
15
10
5
1
ANALOG R IN
2
ANALOG G IN
3
ANALOG B IN78
4
GND
5 GND
6 ANALOG R GND IN
9
10
15 PIN HIGH DENSITY DSUB
6
FEMALE (FRONT VIEW)
1
ANALOG G GND IN
ANALOG B GND IN
RESERVED
SYNC GND IN
11
12
13
14
15
GND
DDC/SDA
HSYNC IN
VSYNC IN
DDC/SCL
13.2 MONITOR
This port relays all signals from the projector to the monitor.
11
15
10
5
15 PIN HIGH DENSITY DSUB
6
FEMALE (FRONT VIEW)
1
MONITOR
1
ANALOG R OUT
2
ANALOG G OUT
3
ANALOG B OUT
4
RESERVED
5 GND
6 ANALOG R GND OUT
78ANALOG G GND OUT
ANALOG B GND OUT
9
RESERVED
SYNC GND OUT
10
37
11
NOT USED
12
DDC/SDA
HSYNC OUT
13
14
VSYNC OUT
DDC/SCL
15
USER GUIDE SVGA LCD PROJECTOR
3.5 mm
JACK
(FRONT VIEW)
TIP
STEM
COMMON
RIGHT
RING
LEFT
4 PIN MINIDIN
FEMALE
(FRONT VIEW)
12341
234
GND
GND
LUMA
CHROMA
PHONO / RCA
FEMALE
(FRONT VIEW)
STEM
SHIELD
GND
COMPOSITE
PHONO / RCA
FEMALE
(FRONT VIEW)
STEM
SHIELD
COMMON
LEFT
13.3 MOUSE
This port is used to relay mouse signals (Serial RS 232, PS/2 and Mac) from
the projector to the computer.
2
1
5
8
8 PIN MINIDIN
FEMALE
(FRONT VIEW)
4
3
6
7
1
MAC ADB
2
PS/2 CLOCK
3
PS/2 DATA
4
RS232 TXD
5
NOT USED
RS232 RXD
6
RS232 CTS
7
8
GND
13.4 AUDIO
This port is used for computer sound input.
13.5 S-VIDEO*
This port is used as S-video input.
13.6 VIDEO (YELLOW)*
This port is used as composite video input.
13.7 LEFT AUDIO (WHITE)*
This port is used as left audio input for video sources.
38
USER GUIDE SVGA LCD PROJECTOR
PHONO / RCA
FEMALE
(FRONT VIEW)
STEM
SHIELD
COMMON
RIGHT
13.8 RIGHT AUDIO (RED)*
This port is used as left audio input for video sources.
* Video version only
39
USER GUIDE SVGA LCD PROJECTOR
14 ENVIRONMENTAL HANDLING
Care has been taken in the manufacture of this projector so that
environmental stress and pollution has been minimized. No CFCs are used
during the manufacture of the unit. Where possible, recyclable materials
have been used to minimize the environmental impact.
The delivery packaging can be recycled without further ado.
With respect to the projector unit itself, thought should be given to the
eventual disposal of the unit in the most environmentally friendly manner
considering the mechanical, electronic and chemical components inside. If
possible, return the unit to a speciallized company handling electronic
waste.
40
USER GUIDE SVGA LCD PROJECTOR
15 FCC STATEMENT
This equipment complies with the limits for a Class A computing device,
pursuant to Subpart J of Part 15 of FCC rules. Only peripherals (computer
input/output devices, terminals, printers, etc.) certified to comply with the
Class A limits may be attached to a computer that complies with Class A
limits. When connecting to a peripheral device, a shielded input/output cable
is required to ensure compliance with FCC rules. The shielded cable that
must be used is supplied with the equipment. Operation with non-certified
peripherals or non-shielded cables is likely to result in interference to radio
and TV reception.
This equipment generates and uses radio-frequency energy and, if not
installed and used in accordance with the instruction manual, may cause
interference to radio and television reception. It has been tested and found
to comply with the limits for a Class A computing device in accordance with
the specifications in Subpart J of Part 15 of the FCC rules, which are
designed to provide reasonable protection against such interference when
operated in a commercial environment. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient the receiving antenna.
• Relocate the projector with respect to the receiver.
• Plug the equipment to a different outlet so that equipment
and receiver are on different branch circuits.
• Fasten cables using mounting screws to ensure adequate EMI control.
You may require the following booklet from the Federal Communications
Commission (FCC): "How to identify and resolve radio and TV interference
problems", available from the U.S. Government Printing Office, Washington,
DC 20402, Stock No. 004-000-00345-4.
41
PLEASE READ
We are in no way responsible for the
contents of the manual. We do not guarantee
its accuracy and we do not make any claim
of copyright. The copyright remains the
property of their respective owners.
Visit the site to read the latest projector
news and reviews, read and comment on
projector specifications, download user
manuals and much more.
Loading...
