Provision ISR Ultra-Z IP series, Z-20IP-1, Z-30IP-2, Z-30IP-1 User Manual

Table of Contents

Chapter

Overview.......................................................................................................................................4

1.1 Functions............................................................................................................................ 4

Chapter

Network Connection

..................................................................................................................... 6

2.1 Setting the IP PTZ Camera over the LAN ............................................................................. 6

2.1.1 Wiring over the LAN ...................................................................................................... 6

2.1.2 Detecting and Changing the IP Address ......................................................................... 6

2.2 Setting the IP PTZ Camera over the WAN ........................................................................... 7

2.2.1 Static IP Connection...................................................................................................... 7

2.2.2 Dynamic IP Connection ................................................................................................. 7

Chapter

Access

to the Network Speed Dome

.............................................................................................. 9

3.1 Accessing by Web Browsers .............................................................................................. 9

3.2 Accessing by Client Software ............................................................................................. 9

Chapter

Live V

iew

..................................................................................................................................... 11

4.1 Power-up Action ............................................................................................................... 11

4.2 Live View Page.................................................................................................................. 11

4.3 Starting Live V iew ............................................................................................................. 12

4.4 Recording and Capturing Pictures Manually ...................................................................... 13

4.5 Operating PTZ Control....................................................................................................... 14

4.5.1 PTZ Control Panel ......................................................................................................... 14

4.5.2 Setting / Calling a Preset ............................................................................................... 14

4.5.3 Setting / Calling a Patrol ................................................................................................ 17

4.5.4 Setting / Calling a Pattern.............................................................................................. 18

4.6 Configuring Live View Parameters ..................................................................................... 19

Chapter

PTZ Configuration.......................................................................................................................... 20

5.1 Configuring Power Off Action............................................................................................ 20

5.2 Configuring Park Actions ................................................................................................... 20

Chapter

Speed Dome Configuration

........................................................................................................... 21

6.1 Configuring Local Parameters............................................................................................ 21

6.2 Configuring Time Settings ................................................................................................. 22

6.3 Configuring Network Settings............................................................................................ 24

6.3.1 Configuring TCP/IP Settings ............................................................................................2 4

6.3.2 Configuring Port Settings .............................................................................................. 26

6.3.3 Configuring PPPoE Settings ........................................................................................... 26

6.3.4 Configuring DDNS Settings ............................................................................................ 27

6.3.5 Configuring SNMP Settings ........................................................................................... 28

6.3.6 Configuring 802.1X Settings .......................................................................................... 29

6.3.7 Configuring QoS Settings............................................................................................... 30

6.3.8 Configuring FTP Settings ............................................................................................... 31

6.3.9 Configuring UPnP™ Settings .......................................................................................... 32

6.3.10 Configuring NAT (Network Address Translation) Settings ........................................... 32

6.3.11 Configuring Email Settings ........................................................................................ 33

6.4 Configuring Video and Audio Settings ............................................................................... 35

6.4.1 Configuring Video Settings............................................................................................ 35

6.4.2 Configuring Audio Settings ............................................................................................ 36

6.4.3 Configuring ROI Settings ............................................................................................... 36

6.5 Configuring Image Settings ............................................................................................... 38

6.5.1 Configuring Display Settings .......................................................................................... 38

6.5.2 Configuring OSD Settings .............................................................................................. 43

6.5.3 Configuring Text Overlay Settings .................................................................................. 44

6.6 Configuring and Handling Alarms ...................................................................................... 44

6.6.1 Configuring Motion Detection....................................................................................... 45

6.6.2 Configuring Video Loss Alarm ....................................................................................... 48

6.6.3 Configuring Video Tampering Alarm.............................................................................. 49

6.6.4 Configuring External Alarm Input .................................................................................. 50

6.6.5 Configuring Alarm Output ............................................................................................. 51

6.6.6 Handling Exception ....................................................................................................... 52

Chapter

Record Settings

............................................................................................................................

7.1 Configuring NAS Settings................................................................................................... 53

7.2 Configuring Recording Schedule ........................................................................................ 61

7.3 Configuring Snapshot Settings........................................................................................... 65

Chapter

Log Searching

(Not available on this model)

Chapter

Others ........................................................................................................................................

10.1 Managing User Accounts .................................................................................................. 66

10.2 Configuring RTSP Authentication....................................................................................... 69

10.3 Configuring Anonymous Visit ............................................................................................ 69

10.4 Configuring IP Address Filter ............................................................................................. 70

10.5 V iewing Device Information .............................................................................................. 70

10.6 Maintenance .................................................................................................................... 71

10.6.1 Rebooting the Camera .............................................................................................. 71

10.6.2 Restoring Default Settings ......................................................................................... 71

10.6.3 Importing/Exporting Configuration File ..................................................................... 71

10.6.4 Upgrading the System ............................................................................................... 72

10.7 RS-485 Settings......................................................................................................... 72

Chapter 11 OSD Settings………………………………………………………………………………………………………………………..…………..74

Appendix

...............................................................................................................................................................

Appendix 1 IP Tool Software Introduction ..................................................................................... 86

Chapter

1 Overview

1.1 Functions

Note:

The functions may vary depending on the models of PTZ. Limit Stops The dome can be programmed to move within the limit stops (left/right, up/down). Scan Modes The dome provides 5 scan modes: auto scan, tilt scan, frame scan, random scan and panorama scan. Pre

sets

A preset is a predefined image position. When the preset is called, the dome

will

automatically

move to the defined position. The presets can be added, mod

ifi

ed, deleted and called. Label Display The on-screen label of the preset title, azimuth/elevation, zoom, time and dome name can be displayed on the monitor. The displays of time and PTZ name can be programmed. Auto Flip In manual tracking mode, when a target object goes directly beneath the dome, the video will automatically flips 180 degrees in horizontal direction to maintain continuity of tracking. This function can also be realized by auto mirror image depending on different camera models.

3D Posit

ioning In the client software, use the left key of mouse to click on the desired position in the video image and drag a rectangle area in the lower right direction, then the dome system will move the position to the center and allow the rectangle area to zoom in. Use the left key of mouse to drag a rectangle area in the upper left direction to move the position to the center and allow the rectangle area to zoom out. Proportional Pan/Tilt Proportional pan/tilt automatically reduces or increases the pan and tilt speeds according to the amount of zoom. At telephoto zoom settings, the pan and tilt speeds will be slower than at wide zoom settings. This keeps the image from moving too fast on the live view image when there is a large amount of zoom. Auto Focus The auto focus enables the camera to focus automatically to maintain clear video images. Day/Night Auto Switch The PTZs deliver color images during the day. And as light diminishes at night, the PTZs switch to night mode and deliver black and white images with high qu

ality. Slow Shutter In slow shutter mode, the shutter speed will automatically slowdown in low illumination conditions to maintain clear video images by extending the exposure time. The feature can be enabled or disabled.

Backlight Compensation (BLC) If you focus on an object against strong backlight, the object will be too dark to be seen clearly. The BLC (Backlight Compensation) function can compensate light to the object in the front to make it clear, but this causes the over-exposure of the background where the light is strong. (Digital) Wide Dynamic Range (WDR)

The wide dynamic range (WDR) function helps the camera provide clear images even under back light circumstances. When there are both very bright and very dark areas simultaneously in the field of view, Digi tal WDR balances the brightness level of the whole image and provide clear images with det

ails. White Balance (WB) White balance can remove the unrealistic color casts. White balance is the white rendition function

of the camera to adjust the color temperature according to the environment automatic

ally. Patrol A patrol is a memorized series of pre-defined preset function. The scanning speed between two presets and the dwell time at the preset are programmable. Pattern A pattern is a memorized series of pan, tilt, zoom, and preset functions. By default the focus and iris are in auto status during the pattern is being memorized. Power Off Memory The dome supports the power off memory capability with the predefined resume time. It allows the dome to resume its previous position after power is restored. Park Act

ion

This feature allows the dome to start a predefined action automatically after a period of inact

ivity. User Management The dome allows you to edit users with different levels of permission, in the admin login status. Multiple users are allowed to access and control the same network PTZ via network simultaneous

ly.

3D Digital Noise Reduct

ion (DNR) Comparing with the general 2D digital noise reduction, the 3D digital noise reduction function processes the noise between two frames besides processing the noise in one frame. The noise will be much less and the video will be cl

earer.

Chapter 2 Network

Con

necti

Before you start:

If you want to set the IP PTZ via a LAN (Local Area Network), please refer to Section

2.1 Setting

the IP PTZ Camera

over the LAN.

If you want to set the network PTZ via a WAN (Wide Area Network), please refer to Section

2.2

Setting the IP PTZ Camera

over the WAN.

2.1 Setting the IP PTZ Camera over the LAN

Purpose:

To view and configure the PTZ via a LAN, you need to connect the network PTZ in the same subnet with your computer, and install the Provided IP Tool to search and change the IP of the network PTZ.

2.1.1

Wiring over the LAN

The following figures show the two ways of cable connection of a network PTZ and a computer:

Purpose:

To test the network PTZ, you can directly connect the network PTZ to the computer with a network cable as shown in Figure 2-1. Refer to the Figure 2-2 to set the network PTZ over the LAN via a switch or a router.

2.1.2

Detecting and Changing the IP A

ddress

You need the IP address to visit the network PTZ.

Steps:

1. To get the IP address, you can choose either of the following methods:

Use IP Tool, a software tool which can automatically detect the online network PTZs in

the LAN and list the device information including IP address, subnet mask, port number, device

serial number, device version, etc., shown in Figure 2-3.

Use the client software to list the online devices. Please refer to the user

manual of client

software for detailed information.

2. Change the IP address and subnet mask to the same subnet as that of your computer.

3. Enter the IP address of network PTZ in the address field of the web

browser to view the

live video.

Notes:

Out of the box, the camera will work on DHCP and get an IP address automatically from the DHCP server. In case a “Restore to factory default” was done, the default IP address will change to

192.168.0.99. The default user name is admin and password is admin. For accessing the network PTZ from different subnets, please set the gateway for the network PTZ after you logged in. For det

ail

ed information, please refer to Section

6.3.1 Configuring TCP/IP

Settings.

2.2 Setting the IP PTZ Camera over the WAN

Purpose:

This section explains how to connect the network PTZ to the WAN with a static IP or a dynamic IP.

2.2.1

Static IP Connection

Before you start:

Please apply a static IP from an ISP (Internet Service Provider). With the static IP address, you can connect the network PTZ via a router or connect it to the WAN direct

ly.

Connecting the network PTZ via a

router

Steps:

1. Connect the network PTZ to the router.

2. Assign a LAN IP address, the subnet mask and the gateway. Refer to Section 2.1.2

Detecting and Changing

the

IP Address

for detailed IP address configuration of the PTZ.

3. Save the static IP in the router.

4. Set port mapping, E.g., 80, 8000 and 554 ports. The steps for port mapping vary depending on

different routers. Please call the router manufacturer for assistance with port mapping.

Note:

Refer to Appendix 2 for detailed information about port mapping.

5. Visit the network PTZ through a web browser or the client software over the internet.

Connecting the network PTZ with static IP directly You can also save the static IP in the PTZ and directly connect it to the internet without using a router. Refer to Section

2.1.2 Detecting and Changing the IP

Address

for detailed IP address configuration

of the PTZ.

2.2.2

Dynamic IP Connection

Before you start:

Please apply a dynamic IP from an ISP. With the dynamic IP address, you can connect the network PTZ to a modem or a router.

Connecting the network PTZ via a

router

Steps:

1. Connect the network PTZ to the router.

2. In the PTZ, assign a LAN IP address, the subnet mask and the gateway. Refer to Section

2.1.2 Detecting and Changing

the

IP Address

for detailed LAN configuration.

3. In the router, set the PPPoE user name, password and confirm the password.

4. Set port mapping. E.g. 80, 8000 and 554 ports. The steps for port mapping vary depending

on different routers. Please call the router manufacturer for assistance with port mapping.

Note:

Refer to Appendix 2 for detailed information about port mapping.

5. Apply a domain name from a domain name provider.

6. Configure the DDNS settings in the setting interface of the router.

7. Visit the PTZ via the applied domain name.

Connecting the network PTZ via a modem

Purpose:

This PTZ supports the PPPoE auto dial-up function. The PTZ gets a public IP address by ADSL dialup after the PTZ is connected to a modem. You need to configure the PPPoE parameters of the network PTZ. Refer to Section

6.3.3 Configuring PPPoE Settings

for detailed configuration.

Note:

The obtained IP address is dynamically assigned via PPPoE, so the IP address always changes after rebooting the PTZ. To solve the inconvenience of the dynamic IP, you need to get a domain name from the DDNS provider (E.g.

DynDns.com). Please follow below steps for normal domain

name resolution and private domain name resolution to solve the problem.

Normal Domain Name Resolution

Steps:

1. Apply a domain name from a domain name provider.

2. Configure the DDNS settings in the

DDNS Settings

interface of the network PTZ. Refer to Section

6.3.4

Configuring DDNS Settings

for det

ail

ed configuration.

3. Visit the PTZ via the applied domain name.

Private Domain Name Resolution

Steps:

1. Install and run the IP Server software in a computer with a static IP.

2. Access the network PTZ through the L AN with a web browser or the client software.

3. Enable DDNS and select IP Server as the protocol type. Refer to Section 6.3.4

Configuring DDNS Settings

for detailed configuration.

Chapter 3 Access

to the

IP PTZ Camera

3.1

Accessing by Web-Browsers

Steps:

1. Open the web browser.

2. In the address field input the IP address of the network PTZ, e.g., 192.168.0.99 and press the Enter

key to enter the login interface.

3. Select English as the interface language on the top-right of login interface.

4. Input the user name and password and click

Note:

The default user name is admin, password is admin.

Figure 3-1 Login Interface

5. Before being able to view the camera you will need to install the camera’s plug in. Please follow the installation prompts to install the plug-in

Note:

You may have to close the web browser for the installation to take place. Please reopen the web browser and log in again after installing the plug-in.

3.2

Accessing

by IP Tool

 The product CD contains the IP Tool. You can view the live video and manage the PTZ with

the client software.

 Follow the installation prompts to install the IP Tool. The configuration interface and live

view interface of client software are shown bellow.

Figure 3-6 IP Tool Control Panel

Figure 3-7 IP Tool Live View Interface

Notes:

If you use Provision-ISR CMS software, please refer to the CMS user manual for proper configuration of the camera as this manual mainly introduces accessing to the network PTZ by web browser.

Chapter 4 Live

View

4.1

Power-up Action

After the power is applied, the PTZ will perform self-test actions. It begins with lens actions and then pan and tilt movement. After the power-up self-test actions, the information as shown in Figure 4-1 will be displayed on screen for 40 seconds. The System Information displayed on the screen includes the dome model, address, protocol, version and other information. The COMMUNICATION refers to the baud rate, parity, data bit and stop bit of the dome. e.g., 2400, N, 8, 1 indicates the dome is configured with the baud rate of 2400, no parity, 8 data bits and 1 stop bit.

Model XX-2XXXXX-X ADDRESS

COMMUNICATION 0000,0,0,0

SOFTWARE VERSION V000

CAMERA VERSION V000

LANGUAGE ENGLISH

Figure 4-1 Power-up information

4.2

Live View Page

Purpose:

The live video page allows you to view live video, capture images, control the PTZ, set/call presets and configure video parameters. Log in the network speed dome to enter the live view page, or you can click

on the menu bar of the main page to enter the live view page.

Descriptions of the live view page:

Menu Bar

Live View Parameters

Click to show or hide

PTZ control pane

Live view window

reset/patrol/patt

ern

Toolbar

Figure 4-2 Live View Page

Menu Bar: Click each tab to enter Live View, Playback, Log and Configuration page respectively. Live View Window:

Display the live video

oolbar:

Operations on the live view page, e.g., live view, capture, record, audio on/off, twoway audio, etc. PTZ Control:

Panning, tilting, focusing and zooming actions of the PTZ. The lighter, wiper, one-touch focus and lens initialization control. Pre

set/patrol/pattern:

Set and call the preset/patrol/pattern for the PTZ.

Live View Parameters:

Configure the image size and stream type of the live video.

4.3 Starting Live V iew

In the live view window as shown in Figure 4-3, click on the toolbar to start the

liv

e view of

the PTZ.

Figure 4-3 Start Live View

Table 4-1 Descriptions of the Toolbar

Icon Descript

ion

Icon Descript

ion

Live view on

Live view off

Manually capture the pic

tures

Manual recording off

Manual recording on

Audio on and adjust volume

Mute Two-way audio off

Two-way audio on

3D positioning

Manual tracking

Note:

Before using the two-way audio or recording with audio functions, please set the

Stream Type to

Video & Audio

referring to Section 6.4.1

Configuring

Video Settings.

Full-screen Mode: You can double-click on the live video to switch the current live view into full-screen or return to normal mode from the full-screen.

3D Posit

ioning:

Steps:

1. Click on the tool bar of live view interface.

2. Operate the 3D positioning function: Left click a position of the live video. The corresponding position will be moved to the center of the live video.

3. Hold down the left mouse button and drag the mouse to the lower right on the live video. The corresponding position will be moved to the center of the

liv

e video and zoomed in.

4. Hold down the left mouse button and drag the mouse to the upper left on the live video. The corresponding position will be moved to the center of the

liv

e video and zoomed out.

4.4

Recording and Capturing Pictures

Manually

In the live view interface, click on the toolbar to capture the live pictures or click to

record the live video. The local saving paths of the captured pic

tures and clips can be set in the

Configuration >

Local

Configuration interface.

To configure remote automatic recording, please refer to Section 7.2 Configuring Recording Schedule.

Note:

The captured image will be saved as a JPEG file in your computer.

4.5

Operating PTZ Control

Purpose:

In the live view interface, you can use the PTZ control buttons to control panning, tilting and zooming.

4.5.1

PTZ Control Panel

On the live view page, click to show the PTZ control panel or click to hide

it. Click the direction buttons to control the pan/tilt movements. Click the zoom/iris/focus buttons to realize lens control.

Figure 4-4 PTZ Control Panel

Button

Descript

ion

Zoom

in/out

Focus near/fa

Iris +/-

Adjust speed of pan/tilt movements

Table 4-2 Descriptions of PTZ Control Panel

4.5.2 Setting / Calling a Preset

Purpose:

A preset is a predefined image position. For the defined preset, you can click the calling button to quickly view the desired image position.

Setting a Pre

set:

Steps:

1. In the PTZ control panel, select a preset number from the preset list.

Figure 4-5 Setting a Preset

2. Use the PTZ control buttons to move the lens to the desired position.

• Pan the PTZ to the right or left.

• Tilt the PTZ up or down.

• Zoom in or out.

• Refocus the lens.

3. Click to finish the setting of the current preset.

4. You can click to delete the preset.

Note:

You can configure up to 256 presets.

Calling a Preset: In the PTZ control panel, select a defined preset from the list and click to call the preset.

Figure 4-6 Calling a Preset

For convenient preset selection, refer to the following steps to navigate to the preset you want.

Steps:

1. Select any preset from the

list.

2. Click the preset number you need on the keyboard.

Note:

The following presets are predefined with special commands. You can only call

them but not configure them. For instance, preset 95 is the “Open OSD Menu”. You may need to use the OSD (On Screen Display) menu when controlling the PTZ remotely. To display the OSD menu on the live view screen, you can call

the preset number 95. Note that the

OSD menu doesn’t appear on the Analog CVBS output.

Serial

No.

Command

Fast Call Up

Note

Open OSD Menu

Call 95

Start Pattern Tour

Call 97

Default to start pattern

tour of group No.1

Start Sequence Tour

Call 98

Configure the Sequence via

the OSD Menu (Page 82)

3 Start Auto Scan

Call 99

Configure the Auto Scan via

the OSD Menu (Page 81)

Remote Reset

Call 94

4.5.3 Setting / Calling a Patrol

Purpose:

A patrol is a memorized series of preset function. It can be configured and called on the patrol settings interface. There are up to 8 patrols for customizing. A patrol can be configured with 32 presets.

Before you start:

Please make sure that the presets you want to add into a patrol have been defined.

Setting a Patrol:

Steps:

1. In the PTZ control panel, click to enter the patrol settings interface.

2. Select a patrol number from

3. Click to enter the adding interface of preset as shown in Figure 4-8.

Figure 4-8 Adding Presets

4. Configure the preset number, patrol duration and patrol speed.

Name

Descript

ion

Patrol Duration

It is the duration staying on one patrol point. The PTZ moves to another patrol point after the patrol time. Patrol Speed

It is the speed of moving from one preset to another.

5. Click to save a preset into the patrol.

6. Repeat the steps from 3 to 5 to add more presets.

7. Click to save all the patrol settings.

Calling a Patrol:

In the PTZ control panel, select a defined patrol from and click to call the patrol as shown in Figure 4-9.

Figure 4-9 Calling a Preset

Buttons on the Patrols interfa

ce:

Buttons

Descript

ion

Save a patrol

Call a patrol

Stop a patrol

Enter the adding interface of preset

Modify a preset Delete a preset

Delete all the presets in one patrol

4.5.4 Setting / Calling a Pattern

Purpose:

A pattern is a memorized series of pan, tilt, zoom, and preset functions. It can be called on the pattern settings interface. There are up to 4 patterns for customizing.

Setting a Pattern:

Steps:

1. In the PTZ control panel, click to enter the pattern settings interface.

2. Select a pattern number from the list as shown in Figure 4-10.

Figure 4-10 Patterns Settings Interface

3. Click to enable recording the panning, tilting and zooming actions.

4. Click to save all the pattern settings.

Buttons on the Patterns interfa

ce:

Buttons

Descript

ion

Start to record a pattern. Stop recording a pattern.

Call the current pattern.

Stop the current pattern.

Delete the current pattern.

Notes

These 4 patterns can be operated separately and with no priority

evel.

When configuring and calling the pattern, proportional pan is valid; the

limi

t stops and

auto flip will be invalid; and the 3D positioning operation is not supported.

4.6

Configuring Live View Par

ameters

Main stream/Sub-stream/Third stream:

You can select or as the stream type of live viewing. The main stream is with a relatively high resolution and needs much bandwidth. The sub-stream is with a low resolution and needs less bandwidth.

The

default setting of stream type is.

Note:

Please refer to Section 6.4.1

Configuring V

ideo Settings

for more det

ail

ed parameter settings

of the main stream, sub-stream and third stream respectively.

Image Size:

You can scale up/down the live view image by clicking . The image size can be 4:3, 16:9, original or auto.

Chapter 5 PTZ

Configuration

5.1

Configuring Power Off Memory

Purpose:

This feature allows the dome to resume whichever actions that the PTZ was performing after a power off has occurred.

Steps:

1. Enter the Basic Settings interface:

Configuration >

PTZ > Basic

2. Select the duration after the power off where the camera should resume the last performed action:

3. Click “Save”

5.2

Configuring Park Actions

Purpose:

This feature allows the dome to start a predefined park action (scan, preset, patrol) automatically after a period of inactivity (park time).

Note: Scheduled Tasks

function is prior to

Park Action

function. When these two

functions are set at

the same time, only the

Scheduled Tasks

function takes effect.

Steps:

1. Enter the Park Action Settings interface:

Configuration >

PTZ > Park Action

Figure 5-7 Set the Park Acti

2. Check the checkbox of

Enable Park Act

ion.

3. Set the

Park Time

as the inactivity time of the dome before it starts the park actions.

4. Choose

Action Type

the from the drop-down list.

Figure 5-8 Action Types

5. Click to save the settings.

Chapter 6 Speed Dome

Configuration

6.1

Configuring Local Par

ameters

Note:

The local configuration refers to the parameters of the live view and other operations

using the web browser.

Steps:

1. Enter the Local Configuration interface:

Configuration > Advanced Configuration >

Local Configuration

Figure 6-1 Local Configuration Interface

2. Configure the following settings:

Live View Parameters: Set the protocol type, stream type, image size and

liv

e view performance.

Protocol Type:

TCP, UDP, MULTICAST and HTTP are selectable.

TCP:

Ensures complete delivery of streaming data and better video qu

ality

, yet the real-

time transmission will be affected. UDP:

Provides real-time audio and video streams.

HTTP:

Allows the same quality as of TCP without setting specific ports for streaming

under some network environments

MULTICAST: It’s recommended to select the protocol type to when using the Multicast function. For other information about Multicast, refer to Section

6.3.1 Configuring

TCP/IP Settings.

Live View Performance:

Set the live view performance to Least Delay, Balanced or Best Fl

uency.

Note:

Please set Live View Performance as Best Fluency for the high frame rate PTZ.

Rules:

You can enable or disable the rules of dynamic analysis for motion here.

Image Format:

The captured pictures can be saved as different format. JPEG

and BMP are

vailabl

Record File Settings: Set the saving path of the video

files.

Record File Size:

Select the packed size of manually recorded and downloaded video files. The size can be set to 256M, 512M or 1G. Save record files to:

Set the saving path for the manually recorded video

files.

Save downloaded files to:

Set the saving path for the downloaded video

fil

es in playback

nterface.


and

Clip Settings: Set the saving paths of the captured pictures and

clipped video

files.

Save snapshots in live view to:

Set the saving path of the manually captured pictures in

nterface.

Save snapshots

when

playback

to: Set the saving path of the captured playback

nterface.

Note:

You can click “ B r o w s e ” to change the directory for saving video files, clips and pic

tures.

3. Click to save the settings.

6.2

Configuring Time Settings

Purpose:

You can follow the instructions in this section to configure the time which can be displayed on the video. There are Time Zone, T ime Synchronization, Daylight Saving Time (DST) functions for setting the time. Time Synchronization consists of auto mode by Network Time Protocol (NTP) server and manual mode.

To enter the Time Settings interface:

Configuration > Advanced Configuration > System > Time Settings

Figure 6-2 Time Settings

Configuring Time Synchronization by NTP Server

(1) Check the checkbox to enable the

NTP

function. (2)

Configure the following settings:

Server

Address:

IP address of NTP server

NTP Port:

Port of NTP server, 123 by default.

Interval:

The time interval between the two synchronizing actions by NTP server. It can be set

from 1 to 10080 minutes.

Figure 6-3 Time Sync by NTP Server

Note:

If the PTZ is connected to a public network, you should use a NTP server that has a time

synchronization function, such as the server at the Nation

Time Center (IP Address:

210.72.145.44). If the PTZ is set in a customized network, NTP software can be used to establish a NTP server for time synchronization.

Configuring T

ime Synchronization

Manually

(1) Check the

Manual Time

Sync.

Checkbox.

(2) Click to set the system time from the pop-up calendar. (3) Click

to save the settings.

Note:

You can also check the

Sync.

with computer time

checkbox to synchronize the

time of the PTZ with

the time of your computer

Figure 6-4 Time Sync Manu

ally

Select the T

ime Zone

Purpose:

When the PTZ is taken to another time zone, you can use the

Time Zone function to adjust the

time. The time will be adjusted according to the origin

time and the time difference between

the two time zones.

From the

Time Zone

drop-down menu as shown in Figure 6-5, select the Time

Zone in which the PTZ locates.

Figure 6-5 Time Zone Settings

6.3

Configuring Network Settings

6.3.1

Configuring TCP/IP Settings

Purpose:

TCP/IP settings must be properly configured before you operate the PTZ over network. IPv4 and IPv6 are both supported.

Steps:

1. Enter TCP/IP Settings interface: Configuration > Advanced Configuration > Network > TCP/IP

Figure 6-7 TCP/IP Settings

2. Configure the NIC settings, including the

IPv4 (IPv6) Address, IPv4 (IPv6) Subnet

Mask

and

IPv4 (IPv6)

Default

Gateway.

3. Click to save the above settings

Notes:

 If the DHCP server is available, you can check to automatically obtain an

P address

and other network settings from that server.



The valid value range of Maximum Transmission Unit (MTU) is 500 ~ 9676. The

default value is

1500.

 The Multicast sends a stream to the multicast group address and allows mu

ltipl

e clients to

acquire the stream at the same time by requesting a copy from the multicast group address.

 Before utilizing this function, you have to enable the Multicast function of

our router and

configure the gateway of the network PTZ.

 If the DNS server settings are required for some applications (e.g., send

ng email), you should

properly configure the

Preferred DNS Server

and Alternate

DNS server.

Figure 6-8 DNS Server Settings

Note:

The router must support the route advertisement function if you select Route

the IPv6 mode.

6.3.2

Configuring Port Settings

Purpose:

If there is a router and you want to access the PTZ through W ide Area Network (WAN), you need to forward the 3 ports for the PTZ.

Steps:

1. Enter the Port Settings interface:

Configuration > Advanced Configuration > Network > Port

Figure 6-9 Port Settings

2. Set the HTTP port, RTSP port and port of the PTZ. HTTP Port: The default port number is 80.

RTSP

Port: The default port number is 554.

HTTPS

Port: The default port number is 443.

SDK

Port: The default

port number is 8000.

3. Click to save the settings.

6.3.3

Configuring PPPoE Setti

ngs

Purpose:

If you have no router but only a modem, you can use Point-to-Point Protocol over Ethernet (PPPoE) function.

Steps:

1. Enter the PPPoE Settings interface:

Configuration >Advanced Configuration > Network >

PPP

Figure 6-10 PPPoE Settings

2. Check the

Enable PPPoE

checkbox to enable this feature.

3. Enter

User Name, Password, and

Confirm

password for PPPoE access.

Note:

The User Name and Password should be assigned by your ISP.

4. Click to save and exit the interface.

6.3.4

Configuring DDNS Settings

Purpose:

If your PTZ is set to use PPPoE as its default network connection, you can use the Dynamic DNS (DDNS) for network access.

Before you start:

Registration on the DDNS server is required before configuring the DDNS settings of the PTZ.

Steps:

1. Enter the DDNS Settings interface:

Configuration > Advanced Configuration > Network > DDNS

Figure 6-11 DDNS Settings

2. Check the

Enable DDNS

checkbox to enable this feature.

3. Select

DDNS Type. Three DDNS types are selectable: DynDNS & NO-IP

DynDNS:

Steps:

(1) Enter Server Address

of DynDNS (e.g. members.dyndns.org).

(2) In the

Domain

text field, enter the domain name obtained from the DynDNS website.

(3) Enter the

Port

of DynDNS server.

(4) Enter the

User Name

and

Password

registered on the DynDNS website. (5) Click

to save the settings.

Figure 6-12 DynDNS Settings

IP Server:

Steps:

(1) Enter the Server Address of the IP Server. (2) Click t to save the settings.

Note:

The Server Address

should be entered with the static IP address of the computer that runs the IP Server software. For the IP Server, you have to apply a static IP, subnet mask, gateway and preferred DNS from the ISP.

Figure 6-13 IPServer Settings

6.3.5

Configuring SNMP Settings

Purpose:

You can use SNMP to get PTZ status and parameters related information.

Before you start:

Before setting the SNMP, please use the SNMP software and manage to receive the PTZ information via SNMP port. By setting the Trap Address, the PTZ can send the alarm event and exception messages to the surveillance center.

Note:

The SNMP version you select should be the same as that of the SNMP software.

Steps:

1. Enter the SNMP Settings interface:

Configuration > Advanced Configuration > Network > SNMP

Figure 6-15 SNMP Settings

2. Check the corresponding version checkbox to enable the feature.

3. Configure the SNMP settings.

Note:

The configuration of the SNMP software should be the same as the settings you configure

here.

4. Click to save and finish the settings.

6.3.6

Configuring 802.1X Settings

Purpose:

The PTZ supports IEEE 802.1X standard. IEEE 802.1X is a port-based network access control. It enhances the security level of the LAN. When devices connect to this network with IEEE 802.1X standard, the authentication is needed. If the authentication fails, the devices don’t connect to the network.

The protected LAN with 802.1X standard is shown as follows:

before connecting the Network Camera to the protected LAN, please apply a digital

certificate from a Certificate Authority.

The network camera requests access to the protected LAN via the

authenticator (a

switch).

The switch forwards the identity and password to the authent

ication server (RADIUS

server)

The switch forwards the certificate of authentication server to the network

camera.

If all the information is validated, the switch allows the network access to

the protected

network.

Steps:

1. Connect the network camera to your PC directly with a network cable.

2. Enter the 802.1X Settings interface: Configuration > Advanced Configuration > Network >

802.1X

Figure 6-17 802.1X Settings

3. Check the

Enable IEEE 802.1X

checkbox to enable it.

4. Configure the 802.1X settings, including user name and password.

Note:

The EAP-MD5 version must be identical with that of the router or the switch.

5. Enter the user name and password (issued by the CA) to access the server.

6. Click to finish the settings.

Note:

The camera reboots when you save the settings.

7. After the configuration, connect the camera to the protected network.

6.3.7

Configuring QoS Settings

Purpose:

QoS (Quality of Service) can help solve the network delay and network congestion by configuring the priority of data sending.

Steps:

1. Enter the QoS Settings interface: Configuration >Advanced Configuration > Network > QoS

Figure 6-18 QoS Settings

2. Configure the QoS settings, including video/audio DSCP, event/alarm DSCP and Management DSCP. The valid DSCP value ranges from 0 to 63. The DSCP value is bigger, the priority is higher.

3. Click to save the settings.

Notes:

Make sure that you enable the QoS function of your network device (such as a router). It will ask for a reboot for the settings to take effect

6.3.8

Configuring FTP Settings

Purpose:

You can set a FTP server and configure the following parameters for uploading captured pic

tures.

Steps:

1. Enter the FTP Settings interface: Configuration >Advanced Configuration > Network >

FTP

Figure 6-19 FTP Settings

2. Configure the FTP settings, including server address, port, user name, password, directory and upload type.

Setting the directory in

FTP server for saving files

In the

Directory Structure

field, you can select the root directory, parent directory and

child directory.

Root directory: The files will be saved in the root of FTP server. Parent directory

The files will be saved in a folder in FTP server. The name of folder

can be defined as shown in following Figure 6-20.

Figure 6-20 Parent Directory

Child directory

It is a sub-folder which can be created in the parent directory. The files will be saved in a sub-folder in FTP server. The name of folder can be defined as shown in following Figure 6-21.

Figure 6-21 Child Directory

Upload type:

To enable uploading the captured picture to the FTP server.

3. Click to save the settings.

Note:

If you want to upload the captured pictures to FTP server, you also have to enable t h e

c o n t i n u o u s snapshot or e v e n t -triggered s n a p s h o t in Snapshot

interface. For

detailed information, please refer to the Section 7.3 Configuring Snapshot Settings.

6.3.9

Configuring UPnP™ Settings

Universal Plug and Play (UPnP™) is a networking architecture that provides compatibility among networking equipment, software and other hardware devices.

The UPnP protocol allows devices to connect seamlessly and to simplify the implementation of networks in the house and corporate environments. With the function enabled, you don’t need to configure the port mapping for each port, and the camera is connected to the Wide Area Network via the router.

Steps:

1. Enter the UPnP™ settings interface.

Configuration >Advanced Configuration > Network > UPnP

2. Check the checkbox to enable the UPnP™ function.

You can edit the Friendly Name of the PTZ. This name can be detected by corresponding device, such as a router.

Figure 6-22 Configure UPnP Settings

6.3.10Configuring NAT (Network

Address Translation) Settings

Steps:

1. Set the port mapping mode:

To port mapping with the default port numbers:

hoose

To port mapping with the customized port numbers:

hoose

And you can customize the value of the port number by yourself.

2. Click to save the settings.

6.3.11Configuring Email Settings

Purpose:

The system can be configured to send an Email notification to all designated receivers if an alarm event is detected, e.g., motion detection event, video loss, tamper-proof, etc.

Before you start:

Please configure the DNS Server settings under

Advanced Configuration > Network > TCP/IP

before

using the Emai

l function.

Steps:

1. Enter the Email Settings

nterface:

Configuration > Advanced Configuration > Network > Em

ail

Figure 6-23 Email Settings

2. Configure the following settings:

Sender:

The name of the email sender.

Sender’s Address:

The email address of the sender.

SMTP Server:

The SMTP Server IP address or host name (e.g., smtp.263xmail.c

om).

SMTP Port:

The SMTP port. The default TCP/IP port for SMTP is 25.

Enable

SSL:

Check the checkbox to enable SSL if it is required by the SMTP server.

Attached Image:

Check the checkbox of Attached Image if you want to send emails with attached alarm images. Interval:

The interval refers to the time between two actions of sending attached pic

tures

Authentication

(optional): If your email server requires authentication, check this checkbox to use authentication to log in to this server and enter the login user name and password. Receiver:

Select the receiver to which the email is sent. Up to 2 receivers can be configured.

Receiver:

The name of the user to be not

ified.

Receiver’s Address: The email address of user to be not

ified.

3. Click to save the settings

6.4

Configuring Video and Audio Se

ttings

6.4.1

Configuring Video Settings

Steps:

1. Enter the Video Settings interface: Configuration > Advanced Configuration > Video / Audio >

Video

Figure 6-24 Configure Video Settings

2. Select the Stream Type

of the PTZ to main stream (normal), sub-stream or third stream.

The main stream is usually for recording and live viewing with good bandwidth,

and the sub-

stream can be used for live viewing when the bandwidth is limited. Refer to the Section 6.1

Configuring Local Parameters

for switching the main stream and sub-stream for live viewing.

3. You can customize the following parameters for the selected main stream or sub-stream:

Video Type

: Select the stream type to video stream, or video & audio composite stream. The audio signal will be recorded only when the

Video Type

Video & A

udio. Resolut

ion: Select the resolution of the video output. Bitrate Type: Select the bitrate type to constant or variable. Video Quality: When bitrate type is selected as

Variable, 6 levels of video quality are selectable. Frame Rate: The frame rate is to describe the frequency at which the video stream is updated and it is measured by frames per second (fps). A higher frame rate is advantageous when there is movement in the video stream, as it maintains image quality throughout.

Max. Bitrate: Set the max. bit-rate to 32~16384 Kbps. The higher value corresponds to the higher video quality, but the higher bandwidth is required. Video Encoding: The

Video Encoding

standard can be set to H.264 or MJPEG.

Profile

You can set the profile level to

High Profile, Main Profile

Basic Profile.

Frame Interval:

Set the I-Frame interval from 1 to 400.

4. Click to save the settings.

6.4.2

Configuring Audio Settings

Steps:

1. Enter the Audio Settings interface Configuration > Advanced Configuration > Video / Audio > Audio

Figure 6-25 Audio Settings

2. Configure the following settings

Audio Encoding:

G.711ulaw, G.711alaw and G.726, MP2L2, AAC selectable.

3. Click to save the settings.

6.4.3

Configuring ROI Settings

Before you start:

ROI (Region of Interest) encoding is used to enhance the quality of images which are specified in advance. Stream Type: You can set the ROI function for main stream, sub stream or third stream. Select a stream type and then configure the ROI settings. Fixed Region:

The fixed region encoding is the ROI encoding for the manua

lly

configured area. And you can choose the Image Quality Enhancing level for ROI encoding, and you can also name the ROI area.

Steps:

1. Enter the ROI Settings interface

Configuration > Advanced Configuration > Video / Audio > ROI

2. Select a

Region

No..

3. Check the check box of

Enable

under

Fixed Region.

4. Click and draw a red frame in the live view image.

5. Adjust the

ROI level

from 1 to 6. The higher the value, the better image quality in the red frame.

6. Enter a

Region Name

and click

Save

to save the settings.

Figure 6-26 Region of Interest

Dynamic Region:

And the dynamic tracking refers to the ROI defined by intelligent analysis

such as human face detection. You can choose the Image Qu

ality

Enhancing level for the ROI

encoding.

Steps:

1. Check the check box of

Enable

under

Dynamic Tracking.

2. Adjust the

ROI level

from 1 to 6. The higher the value, the better the ROI qu

ality.

3. Click

Save

to save the settings.

6.5

Configuring Image Settings

6.5.1

Configuring Display Settings

Purpose:

You can set the image quality of the PTZ, including brightness, contrast, saturation, sharpness, etc.

Notes:

The parameters in

Display Settings

interface vary depending on the models of PTZ.

You can double click the live view to enter full screen mode and double click

it again to exit.

Steps:

1. Enter the Display Settings interface:

Configuration >

Basic

Configuration> Image> Display Settings

Configuration > Advanced Configuration> Image> Display Settings

2. Set the image parameters of the PTZ.

Figure 6-27 Display Settings

Image Adjustment

Brightness This feature is used to adjust brightness of the image. The value ranges from 0 to 100. Contrast This feature enhances the difference in color and light between parts of an image. The value ranges from 0 to 100.

Saturat

ion This feature is used to adjust color saturation of the image. The value ranges from 0 to 100. Sharpness Sharpness function enhances the detail of the image by sharpening the edges in the image. The

value ranges from 0 to 100.

Exposure Settings

Exposure

Mode

The

Exposure Mode

can be set to

Auto, Iris Priority, Shutter

Priority,

Manual. Auto: The iris, shutter and gain values will be adjusted automatically according to the brightness of the environment. Iris Priority: The value of iris needs to be adjusted manually. The shutter and gain values

will

be adjusted

automatically according to the brightness of the environment.

Shutter Priority:

Figure 6-28 Manual Iris

The value of shutter needs to be adjusted manually. The iris and gain values

will

be adjusted

automatically according to the brightness of the environment.

Gain Priority:

Figure 6-29 Manual Shutter

The value of gain needs to be adjusted manually. The shutter and iris values

will

be adjusted

automatically according to the brightness of the environment.

Figure 6-30 Manual Gain

Manual: In

Manual

mode, you can adjust the values of

Gain, Shutter, Iris

manua

lly.

Limit

Gain This feature is used to adjust gain of the image. The value ranges from 0 to 100. Slow Shutter This function can be used in underexposure condition. It lengthens the shutter time to ensure full exposure. The slow shutter value can be set to Low, Normal

and High.

Figure 6-31 Slow Shutter

Focus Settings

Focus

Mode

The

Focus

Mode

can be set to

Auto, Manual, Semi-auto. Auto: The PTZ focuses automatically at any time according to objects in the scene. Semi-auto: The PTZ focuses automatically only once after panning, tilting and zooming. Manual:

Manual

mode, you need to use on the control panel to focus manu

ally.

Min.

Focus Distance

This function is used to limit the minimum focus distance. The value can be set to

1.5m, 3m, 6m, 10cm and 50cm.

Day/Night Switch

Day/Night Switch The Day/Night

Switch

mode can be set to

Auto, Day

and Night. Auto: In

Auto

mode, the day mode and night mode can switch automatic

ally

according to the light

condition of environment. The switching sensitivity can be set to Low, Normal, High.

Day: In

Day

mode, the PTZ displays color image. It is used for normal lighting conditions.

Night: In

Night

mode, the image is black and white.

Night

mode can increase the sensitivity in

low light conditions.

Notes

When the

IR Light Mode is auto, the day/night mode is adjusted automatically

according to the IR Light Mode. Manually setting the day/night mode is invalid.

When the

IR Light

Mode

is manual and the

IR Light

Bright

is 0, you can set the day/night

mode manu

ally.

When the

IR Light

Mode

is manual and the

IR Light

Bright

is not 0, the night mode is set as the

default mode. Manually setting the day/night mode is in

valid.

IR Light Mode IR light mode can be set to

Auto

and Manual. Auto: The brightness of the infrared light will be adjusted automatically. IR Light Sensitivity value ranges from 0 to 100. Manual: you need to adjust the brightness value of infrared light manu

ally.

IR Light

Bright

value ranges from 0 to 100.

Note:

For detailed parameters configuration of IR light, you can enter the OSD menu by calling

the special preset 95.

Backlight Settings

BLC If there’s a bright backlight, the subject in front of the backlight appears silhouetted or dark. Enabling

BLC

(back

light compensation) function can correct the exposure of the subject. But the backlight environment is washed out to white. WDR (Wide Dynamic Range) The wide dynamic range (WDR) function helps the camera provide clear images even under back light circumstances. When there are both very bright and very dark areas simultaneously in the field of view, WDR balances the brightness level of the whole image and provide clear images with det

ails. You can enable or disable the WDR function as shown in Figure 6-33. The wide dynamic level ranges from 0 to 100.

Figure 6-33 WDR

HLC (Not Functional)

HLC (High Light Compensation) makes the camera identify and suppress the strong light sources that usually flare across a scene. This makes it possible to see the det

ail

of the image that would

normally be hidden

White Balance

The

White Balance

mode can be set to

Auto, MWB, Outdoor, Indoor, Fluore

scent Lamp.

Auto: In

Auto

mode, the camera retains color balance automatically according to the current color temperature. Manual White Balan

ce: In MWB mode, you can adjust the color temperature manually to meet your own demand as shown in Figure 6-34.

Figure 6-34 Manual White Balance

Out

doo

r You can select this mode when the PTZ is installed in outdoor environment. Indoor You can select this mode when the PTZ is installed in indoor environment. Fluorescent Lamp You can select this mode when there are fluorescent lamps installed near the PTZ.

Image Enhancement

3D Digital Noise Reduct

ion

You can enable or disable the 3D

Digital Noise Reduction

function as shown in Fi

gure

6-35. The level ranges from 0 to 100.

Figure 6-35 3D Digital Noise Reduction

De-fog

Mode When there is fog in the image, you can enable this function to get clear image. Chroma Suppress The

Chroma Suppress

level ranges from 0 to 100 as shown in F igure 6-36.

Figure 6-36 Chroma Suppress

Video Adjustment

Mirror If you turn the

MIRROR

function on, the image will be flipped. It is like the image in the mirror. The

flip direction can be set to OFF, LEFT/RIGHT, UP/DOWN or CENTER.

Video St

andard

You can set the

Video St

andard

to 50hz (PAL) or 60hz (NTSC) according to the video system in your

ountr

Other

Lens Initialization The lens operates the movements for initialization when you check the check box of Lens Initialization. Zoom Limit You can set

Zoom Limit value to limit the maximum value of zooming. The value can be set to 20,

40, 80, 160 and 320. Local

Output

You can select the output mode to ON or OFF.

6.5.2

Configuring OSD Settings

Purpose:

The PTZ supports following on screen displays:

Zoom:

Identifies the amount of magn

ification.

Direction:

Displays panning and tilting direction, with the format of PXXX TXXX. The XXX following P indicates the degrees in pan direction, while the XXX following T indicates the degrees in tilt position. Time:

Supports for time displa

Preset Title:

Identifies preset being called.

Camera Name:

Identifies the name of PTZ.

You can customize the on screen display of time.

Steps:

1. Enter the OSD Settings interface:

Configuration > Advanced Configuration > Image > OSD Settings

Figure 6-37 OSD Settings

2. Check the corresponding checkbox to select the display of PTZ name, date or week if required.

3. Edit the PTZ name in the text field of

Camera Name.

4. Select from the drop-down list to set the time format, date format and display mode.

5. You can use the mouse to click and drag the text frame in the live view window

to adjust the OSD position.

2015-01-18 Sunday 14:38:05

Figure 6-38 Adjust OSD Location

6. Click to activate above settings.

6.5.3

Configuring Text Overlay Settings

Purpose:

You can customize the text overlay.

Steps:

1. Enter the Text Overlay Settings interface:

Configuration > Advanced Configuration > Image > Text

Overlay

2. Check the checkbox in front of textbox to enable the on-screen display.

3. Input the characters in the textbox.

4. Use the mouse to click and drag the red text frame in the live view window to

adjust the text overlay position.

5. Click

Note:

There are up to 8 text overlays configurable.

6.6

Configuring and Handling Alarms

Purpose:

This section explains how to configure the network PTZ to respond to alarm events, including motion detection, external alarm input, video loss, tamper-proof and exception. These events can trigger the alarm actions, such as Notify Surveillance Center, Send Email, Trigger Alarm Output, etc. For example, when an external alarm is triggered, the network PTZ sends a notification to an email address.

2015-01-18 Sunday 14:38:05

6.6.1

Configuring Motion Detection

Purpose:

Motion detection is a feature which can trigger alarm actions and actions of recording videos when the motion occurred in the surveillance scene.

Steps:

1. Set the Motion Detection Area.

Steps:

(1) Enter the motion detection settings interface

Configuration > Advanced Configuration> Events > Motion Detection

(2) Check the checkbox of

Enable Motion

Detection.

Figure 6-40 Enable Motion Detection

(3) Click . Click and drag the mouse on the live video image to draw a motion

detection area.

Note:

You can draw up to 8 motion detection areas on the same image.

(4) Click to finish dr

awing.

Note:

You can click to clear all of the areas.

(5) Move the slider to set the sensitivity of the detection.

2. Set the Arming Schedule for Motion Detection.

Steps:

(1) To edit the arming schedule as shown in Figure 6-42, click in

Figure 6-41.

Figure 6-41 Arming Schedule

(2) Choose the day you want to set the arming schedule as shown in Figure 6-42. (3) Click

to set the time period for the arming schedule.

(4) After you set the arming schedule, you can click to copy the schedule to

other days (Optional).

(5) Click to save the settings.

Note:

The time of each period can’t be overlapped. Up to 4 periods can be configured for

each da

Figure 6-42 Arming T ime Schedule

3. Set the Alarm Actions for Motion Detection.

Purpose:

You can specify the linkage method when an event occurs. The following contents are about how to configure the different types of linkage method.

Figure 6-43 Linkage Method

Check the checkbox to select the linkage method. Notify surveillance center, send email, upload to FTP, trigger channel and trigger alarm output are selectable. Notify Surveillance Center Send an exception or alarm signal to remote management software when an event occurs. Send Em

ail

Send an email with alarm information to a user or users when an event occurs.

Note:

To send the Email when an event occurs, you need to refer to Section

6.3.10 Configuring Email Settings

to set the Email parameters.

Upload to

FTP

Capture the image when an alarm is triggered and upload the picture to a FTP server.

Note:

You need a FTP server and set FTP parameters first. Refer to Section

6.3.8 Configuring FTP Settings

for setting FTP parameters.

Trigger Channel

Record a video when an event occurs.

Note:

You have to set the recording schedule to realize this function. Please refer to Section

7.2

Configuring Recording Schedule

for settings the recording schedule.

Trigger Alarm

Output Trigger one or more external alarm outputs when an event occurs.

Note:

To trigger an alarm output when an event occurs, please refer to Section 6.6.5

Configuring Alarm

Output to set the alarm output parameters.

6.6.2

Configuring Video

Loss

Alarm

Steps:

1. Enter the Video Loss Setting interface: Configuration > Advanced Configuration> Events > Video Loss

Figure 6-44 Video Loss

2. Check the

Enable

Video

Loss

Detection

checkbox to enable the video loss detection.

3. Click to edit the arming schedule for video loss detection. The arming schedule configuration is the same as the setting of the arming schedule for

motion detection. Refer to

Step 2 Set the

Arming Schedule

for Motion Detection in

Section

6.6.1.

4. Check the checkbox to select the linkage method taken for the video loss alarm. Notify surveillance center, send email and trigger alarm output are selectable. Please Step 3 Set

the Alarm

Actions

for Motion Detection

in Section 6.6.1.

5. Click to save the settings.

6.6.3

Configuring Video Tampering Alarm

Purpose:

You can configure the PTZ to trigger the alarm actions when the lens is covered.

Steps:

1. Enter the tampering Settings interface:

Configuration > Advanced Configuration > Events > Video Tampering

Figure 6-45 Tamper-proof Alarm

2. Check

Enable Video Tampering

checkbox to enable the tampering detection

3. Set the tampering area. Refer to Step 1 Set

the Motion Detection Area

in Section

6.6.1 Configuring Motion Detection.

4. Click to edit the arming schedule for tampering. The arming schedule configuration is the same as the setting of the arming schedule for motion

detection. Refer to

Step 2 Set

the Arming

Schedule

for Motion Detection

in Section

6.6.1 Configuring Motion Detection.

5. Check the checkbox to select the linkage method taken for the tampering. Not

ify

surveillance

center, send email and trigger alarm output are selectable. Please refer to Step 3 Set the

Alarm

Actions for

Motion Detection

in Section

6.6.1 Configuring

Motion Detection.

6. Click to save the settings.

6.6.4

Configuring External Alarm

Input

Steps:

1. Enter the Alarm Input Settings interface:

Configuration > Advanced Configuration> Events > Alarm

Input:

2. Choose the alarm input No. and the Alarm Type. The alarm type can be NO (Normally

Open) and NC (Normally Cl

osed).

3. Edit the name in to set a name for the

alarm input (optional)

Figure 6-46 Alarm Input Settings

4. Click to set the arming schedule for the alarm input. Refer to Step 2

Set

the

Arming Schedule

for Motion

Detection

in Section 6.6.1 Configuring

Motion Detection.

5. Check the checkbox to select the linkage method taken for the alarm input. Refer to Step 3 Set

the

Alarm Actions

for Motion

Detection

in Section 6.6.1

Configuring Motion Detection.

6. You can also choose the PTZ linking for the alarm input. Check the relative checkbox and select

the No. to enable Preset Calling, Patrol Calling or Pattern Calling.

7. You can copy your settings to other alarm inputs.

8. Click to save the settings.

Figure 6-47 Linkage Method

6.6.5

Configuring Alarm

Output

Steps:

1. Enter the Alarm Output Settings interface:

Configuration>Advanced Configuration> Events > Alarm

Output

2. Select one alarm output channel in the

Alarm Output

drop-down

list.

3. Set a name in for the alarm output

(optional).

4. The

Delay

time can be set to

5sec, 10sec, 30sec, 1min, 2min, 5min, 10min

or Manual. The delay time refers to the time duration that the alarm output remains in effect after alarm occurs.

5. Click to enter the

Edit Schedule Time

interface. The time schedule configuration is

the same as the settings of the arming schedule for motion

detection. Refer to Step 2 Set

the Arming

Schedule

for Motion Detection in

Section

6.6.1 Configuring Motion Detection.

6. You can copy the settings to other alarm outputs.

7. Click to save the settings.

Figure 6-48 Alarm Output Settings

6.6.6

Handling Exception

The exception type can be HDD full, HDD error, network disconnected, IP address conflicted and illegal login to the PTZs.

Steps:

1. Enter the Exception Settings interface: Configuration > Advanced Configuration> Events > Ex

ception

2. Check the checkbox to set the actions taken for the Exception alarm. Refer to

Step 3 Set the

Alarm Actions Taken

for Motion

Detection

in Section 6.6.1

Configuring Motion Detection.

Figure 6-49 Exception Settings

3. Click to save the settings

Chapter 7 Record Setti

ngs

Before you start:

To configure record settings, please make sure that you have the network storage device within the network or the SD card inserted in your PTZ.

7.1

Configuring NAS Settings

Before you start:

The network disk should be available within the network and properly configured to store the recorded files, log files, etc.

Steps:

1. Add the network disk

(1) Enter the NAS (Network-Attached Storage) Settings interface:

Configuration > Advanced Configuration > Storage > NAS

Figure 7-1 Add Network Disk

(2) Enter the IP address of the network disk, and the default format of file path is/dvr/share as shown in Figure 7-1.

Note:

The network disk file path name share is user-defined while creating the DVR network

storage. Please refer to the User Manual of NAS for creating the

fil

e path.

(3) Click to add the network

disk.

Note:

After having saved successfully, you need to reboot the PTZ to activate the settings.

2. Initialize the added network disk. (1) Enter the HDD Settings interface (Advanced Configuration > Storage > Storage

Management

which you can view the capacity, free space, status, type and property of the

disk.

(2) If the status of the disk is

Uninitialized

as shown in Figure 7-2, check the

corresponding

checkbox to select the disk and click to start initializing the disk.

Figure 7-2 Initialize Disk

Figure 7-3 Init

ializi

When the initialization completed, the status of disk will become

Normal

as shown in F

igure 7-4.

Figure 7-4 View Disk Status

Notes:

Up to 8 NAS disks can be connected to the PTZ. To initialize and use the SD card after insert it to the PTZ, please refer to the steps of NAS disk

initiali

zation.

7.2

Configuring Recording Schedule

Purpose:

There are two kinds of recording for the PTZs: manual recording and scheduled recording. For the manual recording, refer to Section 4.4

Recording

and

Capturing Pictures Manually. In this section, you

can follow the instructions to configure the scheduled recording. By default, the record files of scheduled recording are stored in the SD card (if supported) or in the network

disk.

Steps:

1. Enter the Record Schedule Settings interface:

Configuration > Advanced Configuration> Storage > Record Schedule

Figure 7-5 Recording Schedule Interface

2. Check the checkbox of

Enable Record Schedule

to enable scheduled recording.

3. Set the record parameters of the PTZ.

Figure 7-6 Record Parameters

Pre-record:

The time you set to start recording before the scheduled time or the event. For example, if an alarm triggers recording at 10:00, and the pre-record time is set as 5 seconds, the PTZ starts to record at 9:59:55. The Pre-record time can be configured as No Pre-record, 5 s, 10 s, 15 s, 20 s, 25 s, 30 s or not limited.

Note:

The pre-record time changes according to the video bitrate.

Post-record:

The time you set to stop recording after the scheduled time or the event. For example, if an alarm triggered recording ends at 11:00, and the post-record time is set as 5 seconds, the PTZ records until 11:00:05. The Post-record time can be configured as 5 s, 10 s, 30 s, 1 min, 2 min, 5 min or 10 min. Overwrite: If you enable his function and the HDD is full, the new record

fil

es overwrite the

oldest record files automatic

ally.

4. Click to edit the record schedule.

Figure 7-7 Record Schedule

5. Choose the day to set the record schedule. (1) Set all-day record or segment record: If you want to configure the all-day recording, please check the

All

Day checkbox.

If you want to record in different time sections, check the Customize

checkbox. Set

the Start

Time

and

End

Time.

Note:

The time of each segment can’t be overlapped. Up to 4 segments can be configured.

(2) Select a

Record Type. The record type can be Normal, Motion Detection, Alarm, Motion

| Alarm, Motion & Alarm.

Normal

If you select

Normal, the video will be recorded automatically according to the time of the schedule. Record Triggered by Motion

Detection

If you select Motion

Detection

the video will be recorded when the motion is detected. Besides configuring the recording schedule, you have to set the motion detection area and check the checkbox of

Trigger Channel

in the Linkage

Method

of Motion Detection

Settings interface. For detailed information, please refer to the Step 1 Set the

Motion

Detection Area

in the Section

6.6.1 Configuring Motion Detection.

Record Triggered by Alarm

If you select

Alarm, the video will be recorded when the alarm is triggered via the external alarm input channels. Besides configuring the recording schedule, you have to set the

Alarm Type

and check the

checkbox of

Trigger Channel

in the

Linkage

Method of

Alarm Input Settings

interface. For

detailed information, please refer to Section

6.6.4 Configuring External Alarm

Input.

Record Triggered by Motion & Alarm

If you select

Motion & Alarm, the video will be recorded when the motion and alarm are triggered at the same time. Besides configuring the recording schedule, you have to configure the settings on the Motion

Detection

and

Alarm

Input Settings

interfaces. Please refer to Section

6.6.1

and

Section

6.6.4

for detailed information.

Record Triggered by Motion & Alarm

If you select

Motion &

Alarm, the video will be recorded when the external alarm is triggered or the motion is detected. Besides configuring the recording schedule, you have to configure the settings on the Motion

Detection

and

Alarm

Input Settings

interfaces. Please refer to Section

6.6.1

and

Section

6.6.4

for detailed information.

Figure 7-8 Edit Record Schedule

(3) Check the checkbox and click to copy settings of this day to the

whole week. You can also check any of the checkboxes before the date and click c o p y.

(4) Click to save the settings and exit the

Edit Record Schedule i

nterface.

6. Click to save the settings.

7.3

Configuring Snapshot Settings

Purpose:

You can configure the scheduled snapshot and event-triggered snapshot. You can upload the captured pictures to a FTP server. Basic Settings

Steps:

1. Enter the Snapshot Settings interface: Configuration > Advanced Configuration > Storage > Snapshot

2. Check the

Enable Timing Snapshot

checkbox to enable continuous snapshot.

Check the

Enable Event-triggered Snapshot

checkbox to check event-triggered snapshot.

3. Select the quality of the snapshot

4. Set the time interval between two snapshots.

5. Click to save the settings.

Uploading to

FTP

Please make sure that the FTP server is online.

You can follow below configuration instructions to upload the snapshots to FTP.

Upload continuous snapshots to FTP

Steps:

1) Configure the FTP settings and check checkbox in FTP Settings interface.

Please refer to Section

6.3.8 Configuring FTP Settings

for more

details to configure FTP parameters.

2) Check the

Enable T iming Snapshot checkbox.

Upload event-triggered snapshots to FTP

Steps:

1) Configure the FTP settings and check checkbox in FTP

Settings interface. Please refer to Section

6.3.8 Configuring FTP Settings

for more details to configure

FTP parameters.

2) Check checkbox in Motion Detection Settings or Alarm Input interface.

ease refer to Step 3 Set the

Alarm Actions Taken

for Motion

Detection

in Section

6.6.1 Configuring Motion Detection, or Step 4 Configuring

External Alarm Input

in Section

6.6.1 Configuring Motion Detection.

3) Check the

Enable Event-triggered Snapshot checkbox.

Figure 7-9 Snapshot Settings

Chapter

9 Log (not available on this model)

Chapter

10 Others

10.1 Managing User Acc

ounts

Enter the User Management interface: Configuration >Basic Configuration>Security > User

Configuration > Advanced Configuration>Security > User

The

admin

user has access to create, modify or delete other accounts. Up to 32 user accounts can

be created.

Figure 10-1 User Information

Add a User

Steps:

1. Click to add a user.

2. Input the new

User Name, select Level and input Password.

Note:

The level indicates the permissions you give to the user. You can define the user as

Operator

or User.

3. In the

Basic Permission

field and

Camera Configuration

field, you can check or

uncheck the

permissions for the new user.

4. Click to finish the user addition

Modify a User

Steps:

1. Left-click to select the user from the list and click

2. Modify the

User Name, Level

or Pa

ssword.

3. In the

Basic Permission

field and

Camera Configuration

field, you can check or uncheck the

permissions.

4. Click to finish the user mod

ification

Figure 10-3 Modify a User

Delete a User

Steps:

1. Left-click the user name you want to delete and click

2. Click on the pop-up dialogue box to delete the user.

Figure 10-4 Delete a User

10.2 Configuring RTSP Authentication

Purpose:

You can specifically secure the stream data of live view.

Steps:

1. Enter the RTSP Authentication interface:

Configuration> Advanced Configuration

Security >

RTSP Authentication

Figure 10-5 RTSP Authenticati

2. Select the

Authentication

type

basic

disable

in the drop-down list to enable or disable the RTSP

authentication.

3. Click to save the settings.

10.3 Configuring Anonymous Visit

When you enable this function, you can log into the camera without a username and password. In login interface, check the

Anonymous

checkbox and click

to enter the camera as shown

in Figure 10-7.

Figure 10-6 Anonymous Login

Figure 10-7 Login Interface

10.4 Configuring IP Address Filter

With this function on, the camera allows certain IP addresses whether to log in or not.

Filter Type

Descript

ion

orbidden

Forbid the IP addresses added in the

IP Address Filter

interface to log

in.

Allow

Allow only the IP addresses added in the

IP Address Filter

interface to log in.

Figure 10-8 IP Address Fil

ter

10.5 Viewing Device Information

Enter the Device Information interface:

Configuration > Basic

Configuration> System >

Device Information

Configuration > Advanced Configuration> System >

Device Information

In the

Device Information

interface, you can edit the Device Name.

Other information of the network PTZ, such as Model, Serial No., Fi

rmware Version, Encoding Version, Number of Channels, Number of HDDs, Number of Alarm Input and Number of Alarm Output are displayed. The information cannot be changed in this menu. It is the reference for maintenance or modification in future.

Figure 10-9 Device Information

10.6 Maintenance

10.6.1

Rebooting the Speed

Dome

Steps:

1. Enter the Maintenance interface:

Configuration > Basic

Configuration> System > Mainte

nance

Configuration > Advanced Configuration> System > Mainte

nan

ce:

2. Click to reboot the network PTZ.

Figure 10-10 Reboot the Devic

10.6.2

Restoring Default Settings

Steps:

1. Enter the Maintenance interface:

Configuration > Basic

Configuration> System > Mainte

nance

Configuration > Advanced Configuration> System > Mainte

nan

2. Click or to restore the default settings.

Note:

Clicking restores all the parameters to default settings including the IP address

and user information. Please use this button with caution.

Figure 10-11 Restore Default Settings

10.6.3

Importing/Exporting

Configuration File

Steps:

1. Enter the Maintenance interface:

Configuration > Basic

Configuration> System > Mainte

nance

Configuration > Advanced Configuration> System > Mainte

nance

2. Click to select the local configuration file and then click to start

mporting configuration

fil

Note: You need to reboot the PTZ after importing configuration

file.

3. Click and set the saving path to save the configuration file in local storage.

Figure 10-12 Import/Export Configuration Fil

10.6.4

Upgrading the System

Steps:

1. Enter the Maintenance interface:

Configuration > Basic

Configuration> System > Mainte

nance

Configuration > Advanced Configuration> System > Mainte

nan

2. Click to select the local upgrade file and then click

to start remote upgrade.

Note:

The upgrading process will take 1 to 10 minutes. Please don't disconnect

power of the PTZ

during the process. The PTZ reboots automatic

ally

after upgrading.

Figure 10-13 Remote Upgrade

10.7 RS-485 Settings

Purpose:

The RS-485 serial port is used to control the PTZ of the camera. The configuring of the PTZ parameters should be done before you control the PTZ unit.

Steps:

1. Enter RS-485 parameter setting interface: Configuration> Advanced Configuration> System > RS

485

Figure 10-14 RS-485 Settings

2. Set the RS-485 parameters and click to save the settings.

By default, the Baud Rate is set as 9600 bps, the Data Bit is 8, the stop bit is 1 and the Parity and Flow Control is None.

Note:

The Baud Rate, PTZ Protocol and PTZ Address parameters of the PTZ should be exactly the

same as those of the remote control device.

Note:

In order to switch the control method from Network to RS-485 – the Baud rate value must be

2400

Chapter 11: OSD Menu

MAIN MENU

LANGUAGE:ENGLISH < INFORMATION> <DOME SETTINGS> <MOTION> RESTART FACTORY DEFAULTS

EXIT

INFORMATION

VERSION :VR220T-128 TEMPERATURE:31℃ VOLTAGE:12.0V

BACK EXIT

DOME SETTINGS

BACK EXIT

DOME SETTINGS

BACK EXIT

MOTION

AUTO

IR LEDs turn on or off automatically according to light conditions

TIMING

LED is adjusted according to On and Off Times.

OPEN

IR LED forcedly open

IR LED forcely close

CAMERA

IR LED status (Open/Close) will be synchronized with Camera day and night switching

11.1) IR LED

In the menu the user can enable and disable the IR LED manually and set up the IR LED work mode under this OSD mean

CONTROL MODE:

1) SENSE: Here the user can manually set the sensitivity from 1-9. The smaller the

number is, the lower light of the environment will be when the IR LED on.

3) NEAR POWER COMPENSATION: set the near power compensation to a value from 0-100%.

The default is 100%. Any value lower than 100% will reduce the light of the LED

4) FAR POWER COMPENSATION: set the far power compensation to a value from 0-100%. The

default is 100%. Any value lower than 100% will reduce the light of the LED

5) AUTO CONTROL: When it is on, the IR LED will turn its power consumption to the

standby status which will effectively extend the service life of IR LEDs. And under this mode, when objects appear in the screen, the IR LED will turn its power consumption back to the normal status.

OFF

Alarm function is deactivated.

Alarm function is activated.

AUTO

AUTO Alarm function will be activated and deactivated between START TIME and STOP TIME.

IDLE setting (Also known as “Park Action”): if the PTZ will not receive any command for the specified time, it will run the defined command.

1) TIME: Move the cursor to “TIME” and click IRIS + to enter, and click up or down button

to select among 30 sec, 1 min, 5 min, 10 min and 30 min. And click IRIS + to confirm.

2) ACTION: Move the cursor to “ACTION” and click IRIS + to enter. Click up or down button

to select the actions including NONE, PRESET, SCAN, SEQUENCE, and PATTERN. Click IRIS + to confirm.

Alarm: The dome system has 1 alarm input and 1 alarm output. When alarm is received, an input signal to the dome triggers the user defined action (such as presets, patterns, etc.), and at meantime the alarm output signals is activated.

ALARM NO.: Move the cursor to ALARM NO. Click “Iris +” to enter and click up or

down button to select the alarm input no.

INPUT STATE: Set the alarm contact status. There are two input states, N/O – Normally

Open and N/C - Normally Close.

ALARM MODE:

NONE

(default) No action

PRESET

Dome goes to preset. (Default as Preset 1)

SCAN

Dome starts auto scan (Default as Auto Scan 1)

SEQ

Dome runs auto cruise (Default as Auto Cruise 1)

PATTERN

Dome runs pattern (Default as Pattern 1)

ACTION: Set the alarm action:

ALARM OUT: Move the cursor to ALARM OUT. Click IRIS + to enter and click up or

down button to select alarm output channels among “OFF”, “OUTPUT1”, “ALL”, which is used to set linkage alarm to the output switch after receiving effective alarm input signals.

RESET DELAY: Move the cursor to the ALARM OUT. Click IRIS + to enter and click up or

down button to select reset delay among “10SEC” “30SEC” “1MIN” “5MIN” “10MIN”.Which means the time of the speed dome from detecting alarm signals

to alarm reset and return to normal. The setting is valid under AUTO ALARM MODE.

Dome Limitation: The user can set up the software (Soft) limit to define the left

and right boundaries for the pan movement.

SOFT LIMIT: Move the cursor here and click IRIS + to enter. Click the up or down button

to select “ON” or “OFF” to enable or disable this function.

LEFT LIMIT: Move the cursor here and click IRIS + to enter and control the PAN movement of the dome to a defined position for the left limit. Click IRIS + to confirm.

RIGHT LIMIT: Move the cursor here and click IRIS + to enter and control the PAN

movement of the dome to a defined position for the right limit. Click IRIS + to confirm.

LIMIT DELETE: Move the cursor here and click IRIS + to delete all the settings.

NONE

(default) No action

PRESET

Dome goes to preset. (Default as Preset 1)

SCAN

Dome starts auto scan (Default as Auto Scan 1)

SEQ

Dome runs auto cruise (Default as Auto Cruise 1)

PATTERN

Dome runs pattern (Default as Pattern 1)

Dome Speed: This menu is to define the top speed of the dome.

Move the cursor to DOME SPEED and click IRIS + to enter to select the dome speed when doing the pan movement.

Move the cursor to BACK/EXIT and click IRIS + to run the command of BACK or EXIT.

Power-Up Action: The user can define the dome action when power on, Move the

cursor to POWER ON ACTION and click IRIS+ to enter the mode of setup

Tilt Angle: The user can set up the tilt angle limit under the menu of TILT ANGLE.

Move the cursor to “TILT ANGLE” and click IRIS + to the setup of tilt angle. Click the up or down button to select the angle and click the IRIS + to confirm.

Others Menu: The user can set up TEMP MODE, INTERNAL FAN, PRESET FREEZE, STOP TIME. MENU OFF TIME and NORTH ZERO.

TEMP MODE: Should be set to Auto.

AUTO FLIP: When the camera tilts downward and goes just beyond the vertical position,

the camera will rotate 180 degrees. The user can click IRIS + to enter and choose to turn this function on/off.

MENU OFF TIME: To set up the time that OSD menu be off when no operations. Options

include 1/2/5/10 min.

DISPLAY: To set up the time that OSD parameters will show after moving the camera.

AZUIMUTH ZERO: To set up the north angle of the dome (pan 0º)

Move the cursor here and click IRIS + to enter. Click the up or down button to control the dome to pan 0º and click IRIS+ to confirm.

Motion Menu: The dome supports 220 presets. Please check the following steps

to set up a preset.

Preset Menu:

1) PRESET NO.: Move the cursor here and click IRIS + to enter

up or down button to select a preset number (1-64 and 100-255) and click IRIS + to confirm.

the setup of Preset Number. Click the

2) TITLE: Move the cursor here and click IRIS + to enter the

above in DOME TITLE settings.

3) <SET>: Move the cursor here and click IRIS + to enter. Move

point and click IRIS + to save the preset position.

4) CALL: Move the cursor here and click IRIS + to call up the

5) DELETE: Move the cursor here and click IRIS + to delete the

6) SPEED: Move the cursor here and click IRIS + to set up the

setup of Preset Title. Check the detailed

the dome to a defined position as preset

current preset.

preset call up speed of LOW, MID and HIGH.

Scan Menu:

The dome supports 8 groups of auto scan. Please check the following steps to set up a scan.

1) SCAN NO.: Move the cursor here and click IRIS + to enter the

down button to select a preset number (1-8) and click IRIS + to confirm.

setup of SCAN Number. Click the up or

2) TITLE: Move the cursor here and click IRIS + to enter the setup of SCAN Title. Check the detailed above

in DOME TITLE settings.

3) <LEFT LIMIT>: Move the cursor here and click IRIS + to enter.

Move the dome to a defined position as left limit and click IRIS + to save this left boundary.

4) <RIGHT LIMIT>: Move the cursor here and click IRIS + to enter. Move the dome to a defined

position as right limit and click IRIS + to save this right boundary.

5) START: Move the cursor here and click IRIS + to start the

current scan.

6) SCAN SPEED: Move the cursor here and click IRIS + to set up the scan speed ranging 1-30.

Sequence Menu:

The dome supports 8 groups of auto cruise and each cruise supports 32 presets. . Please check the following steps to set up cruise.

1) SEQ NO.: Move the cursor here and click IRIS + to enter the

up or down button to select a preset number (1-8) and click IRIS + to confirm.

2) TITLE: Move the cursor here and click IRIS + to enter the setup of Sequence Title. Check the detailed above

in DOME TITLE Settings.

3) <SEQUENCE SET>: Move the cursor here and click IRIS + to enter. Move the cursor to EDIT and

click IRIS + enter edit mode of sequence. Move the left and right button to select each item.

a) When the < > is on the item NO., move the up or down button to select the Serial NO. of the preset in

a sequence. There are up to 32 presets in each sequence.

b) When the < > is on the item PRESET, move the up or down button to select the preset NO. that the

user wants to add in the sequence.

c) When the < > is on the INTERVAL, move the up or down button to select the interval time between

each preset.

d) When the < > is on the last item, move the up or down button to select edition mode as “INS (insert)”,

“ok” and “delete”.

Click IRIS + when selecting INS to insert the settings into the position of current Serial No.

setup of Sequence Number. Click the

Click IRIS + when selecting OK to override the settings of Current Serial No.

Click IRIS + when selecting delete to delete the settings of the Current Serial No.

Click IRIS + to save all the setting and click IRIS CLOSE to exit.

4) DELETE/START: Move the cursor here and click IRIS + to delete/start the current sequence.

Pattern Menu:

The dome supports 4 pattern tours and each pattern cover at most 10 Minutes of 500 commands. Please check the following steps to set up a pattern.

1) PATTERN NO.: Move the cursor here and click IRIS + to enter

up or down button to select a pattern number (14) and click IRIS + to confirm.

the setup of Pattern Number. Click the

2) TITLE: Move the cursor here and click IRIS + to enter the setup of Pattern Title .Check the detailed above in

DOME TITLE settings.

3) <SET>: Move the cursor here and click IRIS + to enter. Click the

in/out and click IRIS + to save the pattern tour.

4) START: Move the cursor here and click IRIS + to start the current

5) DELETE: Move the cursor here and click IRIS + to delete the

dome up/down/left/right, make the zoom

pattern tour.

current pattern tour.

Auto Tracking Menu (This can be set up through the web-client as well):

With Auto tracking active, the dome will auto track the moving objects entering the scene. When the object is moving out of the scene, the dome will return to a preset position as defined after the defined time.

SENSITIVITY: The user can set up the auto tracking sensitivity under

will do auto tracking when obvious object entering the screen. When set as HIGH, the dome will do auto tracking when small object moving into the screen. Move the cursor there and click the IRIS + to enter. The options include: LOW, MID and HIGH.

TARGET: To set up the size of the tracking object. The options include

AUX: If set “ON” here, the object auto tracking will activate alarm aux output at the same time. Click IRIS + to

enter to select “ON” or “OFF”

this menu. When set as LOW, the dome

Large. MID and SMALL.

ZOOM MATCH: Under the auto tracking model, if turn on the function of ZOOM MATCH, the dome will do

zooming in and out during auto tracking to keep the right proportion between the object and background. Move

the cursor there and click the IRIS + to enter. And click the up or down to select the optical zoom.

ENABLE: Move the cursor here and click IRIS + to enter to select “ON” or “OFF” to enable or disable this

function.

TRACKING SCENE SET: Here the user can set up the scene that the dome will get

back to when finishing the action of auto tracking. Move the cursor here and click IRIS + to enter. Move the dome to the wanted scene and click IRIS + to confirm.

DELETE (Available only after setting the scene): Move the cursor here and click IRIS + to delete

the return scene.

RETURN DELAY (Available only after setting the Scene): To set up the time that dome will

waiting to return to this scene.

General:

RESTART: The dome allows the user to reset its settings remotely

under this menu.

Move the cursor here and click IRIS + to enter.

Select “OK” or “CANCEL” to continue the reset or cancel the reset.

FACTORY DEFAULTS: Allows the user to recover all the setting to factory default setting.

Move the cursor here and click IRIS + to enter. Select “OK” or “CANCEL” to continue the reset or cancel the reset.

ppe

ndix

Appendix 1 IP Tool Software Intr

oduction

Description of

IP Tool

IP Tool (Search Active Devices Protocol) is a kind of user-friendly online device search tool. It searches the active online devices within your subnet and displays the information of the devices. You can also modify the basic network information of the devices using this software.

Logging in the IP Tool

In order to have full control over the camera and its settings – you must log into the IP Tool with the Administrator username and password (In this case, User name: admin, Password: Admin). Once logged in – the IP Tool will use these credentials when communicating with the online cameras.

Search active devices

online

Search online devices automatically After launch the IP Tool software, it automatically searches the online devic

es from the subnet where your computer locates. It displays the total number and information of the searched devices in the Online Devices interface. Device information including the device firmware and IP address will be displayed

Figure A.1.1 Searching Online Devic

Search online devices

manually

You can also click to refresh the online device list manually. The newly searched devices will be added to the list.

Modify network parameters

Steps:

1. Select the device to be modified in the device list (Left column). The device menu will open next

to it. Click on

Network Settings

on the panel on the right side

2. A new column with the network settings will open on the right

2. Edit the modifiable network parameters, e.g. IP address and port number

3. Click “Apply” to save the changes.

Provision ISR Ultra-Z IP series, Z-20IP-1, Z-30IP-2, Z-30IP-1 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
