Content
2
2
3
4
5
7
7
9
13
16
17
19
21
22
25
27
29
30
31
32
Features
Precautions
Structure and Components
System connection
OSD Menu
OSD Menu Operation
1) LENS
2) SHUTTER/AGC
3) WHITE BAL
4) BACKLIGHT
5) PICT ADJUST
6) ATR (Adaptive Tone Reproduction)
7) PRIVACY
8) DAY/NIGHT
9) NR
10) CAMERA ID
11) SYNC
12) LANGUAGE
13) CAMERA RESET
Specifications
Features
• 650TV Lines.
• 2D-DNR
• OSD control.
• 0.03 Lux sensitivity
• Motion detection
• HLC
• Color rolling control
• Privacy masking
1. Do not install the camera in places where the temperature is above
50°C or under -10°C.
2. Do not touch the CCD surface with your finger. If cleaning is
needed, please wipe it using a soft cloth with a little bit of alcohol.
3. Do not install in places with high humidity, it can seriously damage
the quality of the picture.
4. Do not drop the camera and the controller and avoid physical shock.
5. Do not face your camera to a strong light, it can damage the CCD.
6. Do not expose the camera to rain or dusty surroundings.
7. It’s highly important to use the correct and suitable power supply
(DC12V) for the camera.
8. Only professional and qualified technician can install and test this
camera.
9. During use, if any errors occur, cut off the power immediately and
contact your local distributor.
Precautions
① Use one camera and one monitor
②Use Several Cameras and one Monitor
VCN
Monitor
MULTIPLEXER
Video Divider
DVR
3 4
BNC
BNC
DC 12V
Monitor
⑴ Confirm that the power supply for the camera is correct;
Connect Power Supply Socket to the power supplier.
⑵ Connect "Video Out" of the camera to the monitor or
other video equipment (DVR) with a 75 ohm cable (RG59).
2
1
Color Camera
AES Auto Electronic Shutter Switch (Auto)
BLC Backlight Compensation Switch (Auto)
AGC Auto Gain Control Switch (Auto)
AWB Auto White Balance Switch (Auto)
Video Cable:
①Power Supply Socket
②Video out
Structure and Components
System connection
Operation Steps
2
1
Video Cable
Lens
Shield
IR Led
OSD Menu
▲ - Joystick Up – Moves the cursor upwards.
▼ - Joystick Down – Moves the cursor downwards.
◄ - Joystick Left – Moves the cursor to the left/change selection.
► - Joystick Right – Moves the cursor to the right/change selection.
O - Joystick button – Press the Joystick to execute selections and
displays a Submenu for an item with the mark.
- To enter the SETUP MENU press the Joystick button – “O”,
The menu will appear on the screen.
5 6
You can push "UP" and "DOWN" to browse the main function.
Push "LEFT" and "RIGHT" to change the value.
Press the joystick for sub-menus and more configurations.
SETUP MENU
LENS AUTO
SHUTTER/AGC AUTO
WHITE BAL ATW
BACKLIGHT BLC
PICT ADJUST
ATR ON
MOTION DET ON
NEXT
EXIT SAVE ALL
Main Menu
Lens
Auto/Manual
Shutter
Auto/Manual
White Balance
ATW/Push/User1/User2/Anti CR/Manual
Backlight
BLC/HLC/Off
Picture Adjust
Mirror/Brightness/Contrast/Sharpness/HUE/Gain
ATR
On/Off
Motion Detect
On/Off
Privacy
On/Off
Day/Night
Auto/BW/Color
NR
Mode/Y Level/C Level
Camera ID
On/Off
Sync
INT
Language
English/Chinese/Deutsch/Francais/Russian/Portugues/Spanish
OSD Main Menu
7 8
OSD Menu Operation
1) LENS
The LENS menu allows you to set the lens which attached to
You’re camera.
MANUAL IRIS LENS: Where the aperture is fixed or set manually by
the user. Iris is mechanism which closes and opens allowing more or
less light into the lens.
AUTO IRIS LENS: In which the aperture is continuously controlled
by the camera to automatically set to the desired level of brightness.
TYPE – you can select between 2 types of lens: DC or VIDEO.
MODE – adjusts the LENS mode to CLOSE/OPEN/AUTO.
SPEED –
• When using a camera with a normal lens – set the LENS mode to
MANUAL.
• When using an AUTO IRIS lens – set the LENS mode to AUTO.
SETUP MENU
LENS AUTO
SHUTTER/AGC AUTO
WHITE BAL ATW
BACKLIGHT BLC
PICT ADJUST
ATR ON
MOTION DET ON
NEXT
EXIT SAVE ALL
- Scroll to LENS using ▲ or ▼.
- Use ◄ or ► to select AUTO and press O to enter the
AUTO IRIS menu.
- Use ▲ or ▼to scroll the setup page.
- Use ◄ or ► to change different parameters:
AUTO IRIS
TYPE DC
MODE AUTO
SPEED 0 |----------|----------|255
RETURN
9 10
- You can choose Auto/Manual option and set brightness level,
AGC level or mode on/off.
SETUP MENU
LENS AUTO
SHUTTER/AGC AUTO
WHITE BAL ATW
BACKLIGHT BLC
PICT ADJUST
ATR ON
MOTION DET ON
NEXT
EXIT SAVE ALL
- Scroll to SHUTTER/AGC using ▲ or ▼.
- Press O to enter the SHUTTER/AGC menu.
- Use ◄ or ► to select Auto and press O to enter the
AUTO SETUP menu.
AUTO SETUP
HIGH LUMINANCE
MODE SHUT+AUTO IRIS / AUTO IRIS
BRIGHTNESS |------|-----------------|
LOW LUMINANCE
MODE AGC
BIRHGTNESS x0.50
RETURN
HIGH LUMUNANCE
- MODE – Use ◄ or ► to set AUTO IRIS (Recommended).
- BRIGHTNESS – Use ◄ or ► to set brightness level between
0 – 255.
LOW LUMUNANCE
AGC level – At low lightning conditions, if the image is too dark –
select higher AGC level which means that the camera would amplify
the CCD input signal and make image will become brighter but
noisier.
- Mode – Use ◄ or ► to use AGC mode or turn it OFF.
- Brightness - Use ◄ or ► to set brightness level between x0.25/
x0.50/ x0.75/ x1.0.
RETURN – Return to previous menu.
2) a) SHUTTER/AGC
Here you can control SHUTTER function such as brightness level
and AGC mode.
The shutter – Controls the amount of light according to your own
environment. Increase SHUTTER value in dark places for a brighter
picture,
Decrease SHUTTER value in places with more light for reducing
amount of light.
11 12
MANUAL SETUP
MODE SHUT+AGC
SHUTTER 1/50
AGC 12.00
RETURN
- Use ◄ or ► to select MANUAL and press O to enter the
MANUAL SETUP menu.
- Use ▲ or ▼ to move up and down in the menu.
- Use ◄ or ► to change SHUTTER value between 1/50,
1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000.
- Use ◄ or ► to change AGC value between 6.00/ 12.00/
18.00/ 24.00/ 30.00/ 36.00/ 42.00/ 44.80.
Remember
Increase SHUTTER value in dark places for a brighter picture,
Decrease SHUTTER value in places with more light for reducing
amount of light.
AGC At low lightning conditions, if the image is too dark – select
higher AGC level.
- Scroll to SHUTTER/AGC using ▲ or ▼.
b) From the main menu
SHUTTER/AGC MANUAL SETTINGS.
SETUP MENU
LENS AUTO
SHUTTER/AGC AUTO
WHITE BAL ATW
BACKLIGHT BLC
PICT ADJUST
ATR ON
MOTION DET ON
NEXT
EXIT SAVE ALL
13 14
- From main menu - Scroll to WHITE BAL using ▲ or ▼.
- Use ◄ or ► to select ATW and press O to enter ATW
MENU.
- Use ▲ or ▼ to navigate in the menu.
- Use ◄ or ► to change values of SPEED, DELAY CNT, ATW
FRAME and ENVIRONMENT,
According to your environment – Outdoor/Indoor.
ATW
SPEED 0|-------|--------|255
DELAY CNT |------|---------|255
ATW FRAME x2.00
ENVIRONMENT INDOOR
RETURN
- Scroll to WHITE BAL using ▲ or ▼.
- Use ◄ or ► to select between the different modes: ATW/
PUSH / USER1 / USER2 / ANTI CR / MANUAL / PUSH
LOCK (see explanations about different modes next page) :
3) WHITE BAL
White balance adjustment - adjust the white balance of color
necessary for the correct reproduction of colors including white as
white and other colors based on it. In changing light conditions
(changing the color temperature of light), white balance needs to be
done again.
White balance setting can be adjusted according to the color
temperature of object.
SETUP MENU
LENS AUTO
SHUTTER/AGC AUTO
WHITE BAL ATW
BACKLIGHT BLC
PICT ADJUST
ATR ON
MOTION DET ON
NEXT
EXIT SAVE ALL
a) A TW
Auto Tracing White Balance - Auto white balance of color, which
tracks the changes of white at the pictures in real time, comparing it
with standard white color and reproduce the colors without the need
for manual setup.
15 16
- Scroll to BACKLIGHT using ▲ or ▼.
- Use ◄ or ► to change BACKLIGHT value between
HLC / BLC / OFF.
SETUP MENU
LENS AUTO
SHUTTER/AGC AUTO
WHITE BAL ATW
BACKLIGHT BLC
PICT ADJUST
ATR ON
MOTION DET ON
NEXT
EXIT SAVE ALL
- From main menu - Scroll to WHITE BAL using ▲ or ▼.
- Use ◄ or ► to select USER 1 and press O to enter USER 1
menu.
- Use ▲ or ▼ to navigate in the menu.
- Use ◄ or ► to change values of B-GAIN and R-GAIN.
b) USER 1/USER 2
Manually adjusts blue color lever and red color level.
B-GAIN – Blue color level.
R-GAIN – Red color level.
c) ANTI CR
- From main menu - Scroll to WHITE BAL using ▲ or ▼.
- Use ◄ or ► to select ANTI CR.
USER 1 WB
B-GAIN 0|-------|--------|255
R-GAIN 0|------|---------|255
RETURN
4) BACKLIGHT
You can select between the special backlights modes – BLC or HLC
according to your envioroment or turn it off.
counter light, taillight, facilitating the photographed object to be
separated from the background. Often with different color
temperature compared with that of the front lighting, this creates a
color perspective.
17 18
HLC (highlight compensation)
(function that suppresses strong headlights at night and improves
visibility to provide clear images with superb picture quality.
- Scroll to PICT ADJUST using ▲ or ▼.
BLC
5) PICT ADJUST
The camera features a backlight compensation circuit that prevents
the object in front of the light to become like a black shadow and to
create clear detailed picture.
OFF MIRROR
In this page you can easily adjust picture parameters like Brightness,
Contrast, Sharpness, HUE and Gain.
Also contain the MIRROR effect-for un-normal installations.
Example:
SETUP MENU
LENS AUTO
SHUTTER/AGC AUTO
WHITE BAL ATW
BACKLIGHT BLC
PICT ADJUST
ATR ON
MOTION DET ON
NEXT
EXIT SAVE ALL
- Press O to enter to PICT ADJUST menu.
PICT ADJUST
MIRROR OFF
BRIGHTNESS 0 |-----------|---------|255
CONTRAST 0 |-------|-------------|255
SHARPNESS 0 |-------|-------------|255
HUE 0 |-------|-------------|255
GAIN 0 |-------|-------------|255
RETURN
19 20
- Use ◄ or ► to select ON and press O to enter ATR menu.
(You can use ◄ or ► to turn OFF the ATR option).
- Use ▲ or ▼ to navigate in the menu.
- Scroll to ATR using ▲ or ▼.
6) ATR (Adaptive Tone Reproduction)
improves the ability to create more detailed picture in both high and
low luminance areas exist in the same picture.
Here you can adjust luminance level (refers to both high and low
luminance) and contrast level according to your envioronment.
SETUP MENU
LENS AUTO
SHUTTER/AGC AUTO
WHITE BAL ATW
BACKLIGHT BLC
PICT ADJUST
ATR ON
MOTION DET ON
NEXT
EXIT SAVE ALL
ATR
LUMINANACE LOW
CONTRAST LOW
RETURN
- Use ◄ or ► to LUMINANACE/CONTRAST value between
LOW/MID/HIGH.
- Press O for next page,
- the second page of the setup menu will appear.
- Scroll to NEXT using ▲ or ▼.
SETUP MENU
LENS AUTO
SHUTTER/AGC AUTO
WHITE BAL ATW
BACKLIGHT BLC
PICT ADJUST
ATR ON
MOTION DET ON
NEXT
EXIT SAVE ALL
SETUP MENU
PRIVACY ON
DAY/NIGHT AUTO
NR
CAMERA ID ON
SYNC INT
LANGUAGE ENGLISH
CAMERA RESET
BACK
EXIT
21 22
- Scroll to DAY/NIGHT using ▲ or ▼.
7) PRIVACY
This function is aiming at the protection of personal privacy, you can
select up to 4 parts on the screen to be masked with colored cover
size and location of the area is also adjustable.
8) DAY/NIGHT
This option allow you to adjust your camera to the day or night mode
to give maximum quality of picture.
You can select between AUTO/COLOR/B/W.
SETUP MENU
PRIVACY ON
DAY/NIGHT AUTO
NR
CAMERA ID ON
SYNC INT
LANGUAGE ENGLISH
CAMERA RESET
BACK
EXIT
Not in use.
SETUP MENU
PRIVACY ON
DAY/NIGHT AUTO
NR
CAMERA ID ON
SYNC INT
LANGUAGE ENGLISH
CAMERA RESET
BACK
EXIT SAVE ALL
- Use ◄ or ► to select AUTO/COLOR/B/W.
If selected AUTO or B/W, press O to enter the sub menu.
23 24
- Use ▲ or ▼ to scroll in the menu.
- Use ◄ or ► to change parameters value.
- Use ◄ or ► to change BURST mode ON/OFF.
a) AUTO sub menu
BURST: Selects whether to output the burst signal when the B/W
(NIGHT mode established (forcibly) status has been
identified.
DELAY CNT: Sets the Night/Day identification transfer time.
DAY -> NIGHT: Sets the threshold for identifying the Night status
from the Day status.
NIGHT -> DAY: Sets the threshold for identifying the Day status from
the Night status.
b) B/W (Black/White) sub menu
For setting BURST mode ON/OFF.
DAY/NIGHT
BURST ON
DELAY CNT 0 |-------|-------|255
DAY -> NIGHT 0 |-------|-------|255
NIGHT -> DAY 0 |-------|-------|255
RETURN
B/W
BURST ON
RETURN
25 26
9) NR
This function is used to set the noise reduction function.
NR MODE - This function is used to set the noise reduction mode.
C LEVEL - Sets the Y filter strength.
Y LEVEL - Sets the Y filter strength.
- Scroll to NR using ▲ or ▼.
- Press O to enter NR menu.
- Use ▲ or ▼ to scroll in the menu.
- Use ◄ or ► to change the parameters.
(You can also switch OFF the NR MODE).
SETUP MENU
PRIVACY ON
DAY/NIGHT AUTO
NR
CAMERA ID ON
SYNC INT
LANGUAGE ENGLISH
CAMERA RESET
BACK
EXIT SAVE ALL
NR
NR MODE Y/C
Y LEVEL 0|-----------|-----------|15
C LEVEL 0|-----------|-----------|15
RETURN
27 28
CAMERA ID
ABCDEFGHIJKLMNOPQRSTUV
WXYZ0123789-!”#$%&’
( )_`,: ; < = > ? @ \ ^ *. x . + /
CHR1 CHR2
◄ ► ▲ ▼ CLR POS
RETURN
- When finished go to RETURN and press O.
10) CAMERA ID
This option allows you to select a name for your camera and select
rather it will be displayed or not.
If selected off the name will not be displayed.
- Scroll to CAMERA ID using ▲ or ▼.
- Use ◄ or ► to change CAMERA ID to ON and press O to
enter the sub menu.
You can select OFF if you don’t want to display CAMERA ID.
- Use ◄ / ► /▲ / ▼ to move the mark to select a name for
your camera.
To clear last note use CLR (clear).
Camera ID can contain more the one word or line.
Use ▲ / ▼ to move the mark to different line.
Use ◄/ ► to create space between the words,
Or move the mark between different notes in the word.
SETUP MENU
PRIVACY ON
DAY/NIGHT AUTO
NR
CAMERA ID ON
SYNC INT
LANGUAGE ENGLISH
CAMERA RESET
BACK
EXIT SAVE ALL
29 30
11) SYNC
This option is not adjustable – it’s always on. The Line-Lock (L/L)
feature allows the camera to synchronize its frame rate to the power
line phase. The function is only available when the camera is
operated by AC power. It allows the reduction of the fluorescent
lights color rolling effect. When using 12v DC power, the camera is
automatically set to internal (INT) synchronization mode.
SETUP MENU
PRIVACY ON
DAY/NIGHT AUTO
NR
CAMERA ID ON
SYNC INT
LANGUAGE ENGLISH
CAMERA RESET
BACK
EXIT SAVE ALL
12) LANGUAGE
You can select different languages for the OSD to be displayed in:
English, Chinese, Deutsch, France, Russian, Portuguese, Spanish.
- Scroll to LANGUAGE using ▲ or ▼.
- Use ◄ or ► to change the language.
SETUP MENU
PRIVACY ON
DAY/NIGHT AUTO
NR
CAMERA ID ON
SYNC INT
LANGUAGE ENGLISH
CAMERA RESET
BACK
EXIT SAVE ALL
31 32
- Scroll to CAMERA RESET using ▲ or ▼.
- Press O to reset camera to default values.
SETUP MENU
PRIVACY ON
DAY/NIGHT AUTO
NR
CAMERA ID ON
SYNC INT
LANGUAGE ENGLISH
CAMERA RESET
BACK
EXIT SAVE ALL
13) CAMERA RESET
Reset camera to default settings.
Specifications
Image Sensor
DSP System
Effective Pixels
Scanning System
Horizontal Resolution
Min. Illumination
OSD Menu
Backlight Compensation
Sync. System
S/N Ratio
White Balance
Gamma Correction
Gain Control
Motion Detection
Privacy Masking
Mirror(H-REV)
SHARPNESS
D/N Selection
ATR
Noise Reduce
Picture Adjustment
White Pixel Detection
and Compensation
Automatic Adjustment of
Mechanical Iris
Analog Output
Lens
Power
Dimension
Net Weight
I2-370CS
MODEL
On/Off( 4 Zone )
On/Off
On/Off
On/Off (Level Adjutable)
Color/B/W/Auto
PAL/NTSC
On/Off( 4 Zone )
Yes
2D-DNR
Yes
Static and Dynamic
Yes
Y/C Separate video, Composite video
0.45
Internal
650TVL
PAL:976(H)x582(V) / NTSC:976(H)x494(V)
0.003 Lux / F1.0 (0 Lux IR On), 28 IR Leds / 20mt
Available( 7 languages )
BLC/HLC/OFF selectable
ATW/PUSH/USER 1/USER 2/ANTI CR/MANUAL/PUSH CLOCK
DC12V±10% Max 2.0W
1/3” Sony DS CCD (PAL:ICX673AK/NTSC:ICX672AK)
CXD4127
≥48db (AGC Off)
4/6mm Lens
130L x 75W x 80H mm
430g
33 34
SpecificationsSpecifications
Image Sensor
DSP System
Effective Pixels
Scanning System
Horizontal Resolution
Min. Illumination
OSD Menu
Backlight Compensation
Sync. System
S/N Ratio
White Balance
Gamma Correction
Gain Control
Motion Detection
Privacy Masking
Mirror(H-REV)
SHARPNESS
D/N Selection
ATR
Noise Reduce
Picture Adjustment
White Pixel Detection
and Compensation
Automatic Adjustment of
Mechanical Iris
Analog Output
Lens
Power
Dimension
Net Weight
I3-370CSVF
MODEL
On/Off( 4 Zone )
On/Off
On/Off
On/Off (Level Adjutable)
Color/B/W/Auto
PAL/NTSC
On/Off( 4 Zone )
Yes
2D-DNR
Yes
Static and Dynamic
Yes
Y/C Separate video, Composite video
0.45
Internal
650TVL
PAL:976(H)x582(V) / NTSC:976(H)x494(V)
0.003 Lux / F1.0 (0 Lux IR On), 36 IR Leds / 30mt
Available( 7 languages )
BLC/HLC/OFF selectable
ATW/PUSH/USER 1/USER 2/ANTI CR/MANUAL/PUSH CLOCK
DC12V±10% Max 2.0W
1/3” Sony DS CCD (PAL:ICX673AK/NTSC:ICX672AK)
CXD4127
≥48db (AGC Off)
4~9mm Vari-Focal lens
195L x 78W x 175H mm
810g
Image Sensor
DSP System
Effective Pixels
Scanning System
Horizontal Resolution
Min. Illumination
OSD Menu
Backlight Compensation
Sync. System
S/N Ratio
White Balance
Gamma Correction
Gain Control
Motion Detection
Privacy Masking
Mirror(H-REV)
SHARPNESS
D/N Selection
ATR
Noise Reduce
Picture Adjustment
White Pixel Detection
and Compensation
Automatic Adjustment of
Mechanical Iris
Analog Output
Lens
Power
Dimension
Net Weight
MODEL
On/Off( 4 Zone )
On/Off
On/Off
On/Off (Level Adjutable)
Color/B/W/Auto
PAL/NTSC
On/Off( 4 Zone )
Yes
2D-DNR
Yes
Static and Dynamic
Yes
Y/C Separate video, Composite video
0.45
Internal
650TVL
PAL:976(H)x582(V) / NTSC:976(H)x494(V)
0.003 Lux / F1.0 (0 Lux IR On), 64 IR Leds / 40mt
Available( 7 languages )
BLC/HLC/OFF selectable
ATW/PUSH/USER 1/USER 2/ANTI CR/MANUAL/PUSH CLOCK
DC12V±10% Max 2.0W
1/3” Sony DS CCD (PAL:ICX673AK/NTSC:ICX672AK)
CXD4127
≥48db (AGC Off)
138L x 89W x 89H mm
970g
I4-370CSVFI4-370CS
4~9mm Vari-Focal lens6/8/12mm lens
Loading...
