PD-DVR100
DVD Recorder
User’s Manual
DVD+ReWritable
STANDBY/ON
OPEN/CLOSE
E
C
R
U
O
S
N
V
R
E
E
E
X
R
C
T
P
S
T
P
O
P
A
/
Y
U
A
S
L
E
P
Page 2
OMPDDVR100.book Page ii Monday, September 19, 2005 8:35 AM
Protron PD-DVR100 DVD Recorder User’s Manual.
© 2005 Protron Digital Corporation. All rights reserved.
Under copyright law, this manual may not be reproduced in any form, in whole or in part,
without the prior written consent of Protron Digital Corporation.
Disclaimer
Protron Digital Corporation has reviewed this manual and provides it only as a guide to
operation. All statements, technical information, and recommendations in this manual and in
any guides or related documents are believed reliable, but the accuracy and completeness
thereof are not guaranteed or warranted, and they are not intended to be, nor should they be
understood to be, representations or warranties concerning the products described.
Specifications are subject to change without notice.
Trademarks
Protron is a registered trademark of Prosonic Group Corporation.
Protron Digital Corporation
2133 S. Green Privado
Ontario, CA 91761
Printed in China
Page 3
OMPDDVR100.book Page i Monday, September 19, 2005 8:35 AM
Product Cautions
TO PREVENT POSSIBLE DANGER, ELECTRIC SHOCK, AND OTHER INJURIES WHEN
HANDLING YOUR DVD RECORDER, PLEASE BE AWARE OF OF ALL WARNINGS AND
SAFETY PRECAUTIONS LISTED BELOW.
Never spill any liquid of any kind on the device.
A
P
/
U
Y
S
A
E
L
P
OPEN/CLOSE
E
N
V
C
E
R
E
X
R
E
R
T
C
U
P
O
S
S
T
P
STANDBY/ON
O
high voltage nodes or damage internal components.
Do not attempt to service the device yourself. Opening or removing covers
exposes high voltage nodes and other hazards. Refer all servicing to qualified
service personnel.
Do not touch the device or antenna during thunderstorms. Unplug the device
during thunderstorms or if it will not be used for extended periods. Failure to
do so may result in electric shock or fire.
Before cleaning the device, unplug it from the wall. Use a damp cloth for
cleaning. Never use liquid or aerosol cleaners.
Never insert anything into the device, where objects can come into contact with
A
P
/
U
Y
S
A
E
L
P
OPEN/CLOSE
E
N
V
C
E
R
E
X
R
E
R
T
C
U
P
O
S
S
T
P
STANDBY/ON
O
To prevent overheating and ensure reliable operation, place the device only in a
well ventilated location. Avoid cramped or inadequately ventilated locations.
A
P
/
U
Y
S
A
E
L
P
OPEN/CLOSE
E
N
V
C
E
R
E
X
R
E
R
T
C
U
P
O
S
S
T
P
STANDBY/ON
O
Note: Read all safety and operating instructions before operating your new DVD recorder.
i
Page 4
OMPDDVR100.book Page ii Monday, September 19, 2005 8:35 AM
Conformity and Compliance
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception (this can be
determined by turning the device off and on), the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution:
To comply with the limits for an FCC Class B computing device, the user should use the shielded
signal cable and power cord supplied with the unit. The FCC warns that changes or modifications
of the unit not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
Radio Frequency Interference Statement
Warning:
This is a Class B product. In a domestic environment this product may cause radio interference, in
which case the user may be required to take adequate measures.
Canadian DOC Notice for Class B Computing Devices
This digital apparatus does not exceed the Class B limits for radio noise emissions from a digital
apparatus as set out in the Radio Interference Regulations of the Canadian Department of
Communications.
CE Marking and Declaration of Conformity
This device complies with the requirements of related European standards, which
include the following:
• Emission: EN 55022, EN 61000-3-2, EN 61000-3-3
• Immunity: EN 50082-1
• Safety: EN 60950 Low-Voltage Directive (73/23/EEC)
ii
Page 5
OMPDDVR100.book Page iii Monday, September 19, 2005 8:35 AM
Table of Conte n t s
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Unpacking Your New DVD Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Connecting the Recorder to Other Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Connecting to a Display Using Component Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Connecting to a Display Using S-Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connecting to a Display Using Composite Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connecting to a Television Signal Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connecting to a 5.1 Channel Audio System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connecting to a Stereo Audio System Using an Analog Connection . . . . . . . . . . . . . . . . . . . . 8
Connecting to a Stereo Audio System Using a Digital Connection . . . . . . . . . . . . . . . . . . . . . . 8
Connecting Other Audio/Video Sources to the Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Using the Recorder for the First Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Operating the Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Turning the Recorder On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Inserting a Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Understanding the LCD Readout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Bringing Up the On-Screen Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Accessing the Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Using the Remote Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Replacing the Remote Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Recording DVDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Supported Media Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
About DVD Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
The LCD Readout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
The On-Screen Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Recording Video Manually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Scheduling Recordings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Finalizing the Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Editing Recorded DVDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Using the Disc Edit Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Renaming the Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Erasing the Disc (DVD+RW Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Creating a New Title . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Overwriting the Disc (DVD+RW Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Making the Disc Compatible with Other DVD Players (DVD+RW Only) . . . . . . . . . . . . . . . . . 20
Locking and Unlocking the Disc (DVD+RW Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Finalizing the Disc (DVD+R Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Using the Title Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Editing a Title . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Renaming a Title . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Erasing a Title . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Overwriting a Title (DVD+RW Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Overwriting from a Title (DVD+RW Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Using Edit Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Creating/Deleting a Chapter Marker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Hiding a Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Setting an Index Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Splitting a Title (DVD+RW Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
iii
Page 6
OMPDDVR100.book Page iv Monday, September 19, 2005 8:35 AM
Table of Contents
Playing DVDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
The LCD Readout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
The On-Screen Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Navigating Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Controlling Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Searching to a Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Programming Playback Sequence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Playing Video CDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
The LCD Readout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
The On-Screen Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Navigating Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Controlling Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Searching to a Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Programming Playback Sequence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Playing Audio CDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
The LCD Readout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
The On-Screen Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Controlling Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Programming Playback Sequence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Playing Kodak Picture CDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
The LCD Readout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Controlling Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Navigating Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Transforming Images. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Enabling Slideshow Transition Effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Repeating Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Playing Media on Data CDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
The LCD Readout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
The On-Screen Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Using the Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Controlling Audio File Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Controlling Image File Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Controlling Video File Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Searching to a Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Programming Playback Sequence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Configuring the Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Record. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Channel Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Support Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Television Tuner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
iv
Page 7
OMPDDVR100.book Page 1 Monday, September 19, 2005 8:35 AM
Introduction
Congratulations on purchasing your new Protron DVD Recorder!
With a television tuner and three audio/video inputs, you can record television broadcasts and
video signals from other devices on DVD, for up to 360 minutes of recorded video on each DVD.
Further, with a progressive scan component video output and 5.1 channel surround sound, your
DVD recorder can play back DVDs with the highest quality available. And it can even play music,
video, and photo CDs.
Features
• Records on DVD+R/RW media
• Up to 360 minutes of recorded video on a 4.7GB DVD (SLP mode)
• 3 S-Video/composite video inputs with corresponding stereo audio inputs
• 4-pin IEEE 1394 (i.LINK/FireWire) input
• TV tuner input/output
• Plays DVD, DVD±R/RW, CD-ROM, CD-R/RW, Audio CD (CD-DA), MP3 CD, Video CD (VCD),
Super Video CD (SVCD), and Kodak Picture CD media
• Displays media files (MP3, WMA, JPEG, MPEG, AVI, DAT/VCD) stored on data CDs
• Multi-angle video playback
• 10-bit, 525-line digital video converter
• 24-bit, 96kHz digital audio converters for high fidelity sound
• 5.1 channel surround sound
• Audio formats supported: Dolby Digital, DTS, MPEG-2, PCM
• Progressive scan component video output for crisp, flicker-free video
• S-Video output
• Composite video output
• Digital optical audio output
• Digital coaxial audio output
• Stereo audio output
1
Page 8
OMPDDVR100.book Page 2 Monday, September 19, 2005 8:35 AM
Unpacking Your New DVD Recorder
Before using your new DVD recorder, you should unpack the
contents of the box and check to make sure everything is present
and undamaged.
To unpack the player:
1. Open the box. Remove the recorder and styrofoam pads.
2. Remove the remote control from the recess in the left
styrofoam pad.
3. Remove the styrofoam pads and plastic bag enclosing the
player and set it aside.
4. Check to ensure the items indicated below are included in the
box. If any items are missing or damaged, contact the seller
immediately.
Remote Control
INPUT
ANGLE AUDIO SUBTITLE
CHANNEL
SEARCH ADD/CLEAR PROGRAM
ENTER
DISPLAY TITLE MENU RETURN
STOP PAUSE/STEP PLAY
VOLUME
(LEVEL)
REV FWD
SLOW REC
MUTE
ZOOM
A-B
P-SCAN REPEAT TIMER
SETUP DISC EDIT EDIT
RCA Cables
2 AAA Batteries
NEXTPREV
MODE
2
Page 9
OMPDDVR100.book Page 3 Monday, September 19, 2005 8:35 AM
5. Install the included AAA batteries in the remote.
6. Place the recorder in its intended position and
connect the power cable to a wall socket.
FL
FR
SW
C
Video
S Video
SR
SL
AUDIO OUT VIDEO OUT
Unpacking Your New DVD Recorder
Y/G
Pb/B
Coaxial Optical
Pr/R
DIGITAL AUDIO OUT
NT SC
!
3
Page 10
OMPDDVR100.book Page 4 Monday, September 19, 2005 8:35 AM
Connecting the Recorder to Other Devices
There are numerous connections on the rear of the recorder that may be used to connect to
other devices for video and audio playback and recording.
Connecting to a Display Using Component Video
Component video offers higher quality than all other video outputs on the recorder. In addition,
you can configure the component video output to transmit progressive scan video, which offers
crisp, flicker-free video.
The Y, Pb, and Pr outputs in the VIDEO OUT block on the rear of the recorder are the recorder’s
component video outputs.
To connect to a display using component video:
1. Using three RCA cables, connect the
Y, Pb, and Pr outputs in the VIDEO
OUT block on the rear of the
recorder to the corresponding
component video inputs on the
display.
2. If you would also like to connect the
audio output to the display, connect
the FR (right) and FL (left) outputs
in the AUDIO OUT block on the rear
of the recorder to the display’s
audio input.
3. If you have connected the audio
output to the display, go to the
Setup menu, select the Playback
sub-menu and set Analog Audio
Output to 2 CH (see “Playback” on
page 36).
VIDEO
AUDIO
Pr
Pb
Y
L
R
(OPTIONAL)
4. In the Setup menu, select the
General sub-menu and set Video
Output Format as appropriate for
your display (see “General” on
page 35).
5. Also in the General sub-menu, set
Progressive/Interlace as desired.
Note: Progressive scan only works
with component video connections to displays that support it. Check to ensure your
display supports progressive
scan before configuring the
recorder to use it.
RF IN
S-Video Video R --- Audio --- L
IN
1
RF OUT
IN
2
UHF/VHF
4
FL
FR
C
SR
SOURCE INPUT AUDIO OUT VIDEO OUT
Y/G
SW
Video
Pb/B
S-Video
Pr/R
SL
Coaxial Optical
DIGITAL AUDIO OUT
Page 11
OMPDDVR100.book Page 5 Monday, September 19, 2005 8:35 AM
Connecting to a Display Using S-Video
S-Video offers higher quality than composite video, but lower quality than component video.
The S-Video output is located in the VIDEO OUT block on the rear of the recorder.
To connect to a display using S-Video:
1. Using an S-Video cable (not
included), connect the S-Video
output in the VIDEO OUT block on
the rear of the recorder to the
display’s S-Video input.
2. If you would also like to connect the
audio output to the display, connect
the FR (right) and FL (left) outputs
in the AUDIO OUT block on the rear
of the recorder to the display’s
audio input.
Connecting the Recorder to Other Devices
VIDEO
L
AUDIO
R
(OPTIONAL)
3. If you have connected the audio
output to the display, go to the
Setup menu, select the Playback
sub-menu and set Analog Audio
Output to 2 CH (see “Playback” on
page 36).
4. In the Setup menu, select the
General sub-menu and set Video
Output Format as appropriate for
your display (see “General” on
page 35).
5. Also in the General sub-menu, set
Progressive/Interlace to Interlace.
RF IN
S-Video Video R --- Audio --- L
IN
1
RF OUT
IN
2
UHF/VHF
FL
FR
C
SR
SOURCE INPUT AUDIO OUT VIDEO OUT
Y/G
SW
Video
Pb/B
S-Video
Pr/R
SL
Coaxial Optical
DIGITAL AUDIO OUT
5
Page 12
OMPDDVR100.book Page 6 Monday, September 19, 2005 8:35 AM
Connecting the Recorder to Other Devices
Connecting to a Display Using Composite Video
Composite video is the most common video connection, but offers lower quality than either
S-Video or component video. The yellow Video output in the VIDEO OUT block on the rear of the
recorder is the recorder’s composite video output.
To connect to a display using composite video:
1. Using an RCA cable, connect the
Video output in the VIDEO OUT
block on the rear of the recorder to
the display’s composite video
input.
2. If you would also like to connect the
audio output to the display, connect
the FR (right) and FL (left) outputs
in the AUDIO OUT block on the rear
of the recorder to the display’s
audio input.
VIDEO
AUDIO
L
R
(OPTIONAL)
3. If you have connected the audio
output to the display, go to the
Setup menu, select the Playback
sub-menu and set Analog Audio
Output to 2 CH (see “Playback” on
page 36).
4. In the Setup menu, select the
General sub-menu and set Video
Output Format as appropriate for
your display (see “General” on
page 35).
5. Also in the General sub-menu, set
Progressive/Interlace to Interlace.
RF IN
S-Video Video R --- Audio --- L
IN
1
RF OUT
IN
2
UHF/VHF
FL
FR
C
SR
SOURCE INPUT AUDIO OUT VIDEO OUT
Y/G
SW
Video
Pb/B
S-Video
Pr/R
SL
Coaxial Optical
DIGITAL AUDIO OUT
6
Page 13
O
OMPDDVR100.book Page 7 Monday, September 19, 2005 8:35 AM
Connecting to a Television Signal Source
The RF IN jack on the rear of the recorder is the recorder’s television signal input. When a signal
is connected to RF IN, you can record it to DVD.
The RF OUT jack allows you to connect to another device the same television signal connected to
RF IN.
To connect a television signal to the
recorder:
1. Using a coaxial cable (not included),
connect the signal source to the RF IN
jack on the rear of the recorder.
2. If you would like to connect the same
signal source to another device as well,
use another coaxial cable to connect the
RF OUT jack to the other device.
3. In the Setup menu, select the Channel
Scan sub-menu and set Tuner Input
Source as appropriate (see “Channel
Scan” on page 39).
TV IN
Connecting the Recorder to Other Devices
TV SIGNAL
RF IN
S-Video
IN
1
RF OUT
IN
(OPTIONAL)
2
UHF/VHF
S
Connecting to a 5.1 Channel Audio System
The AUDIO OUT block on the rear of the recorder contains the recorder’s 5.1 channel surround
sound outputs.
To connect to an audio system using
5.1 channel surround sound:
1. Using six RCA cables, connect each of
AUDIO SYSTEM
the outputs in the AUDIO OUT block on
the rear of the recorder—FR (front
right), FL (front left), C (center), SW
(subwoofer), SR (surround right), and SL
(surround left)—to the corresponding
audio system inputs.
2. In the Setup menu, select the Playback
sub-menu and set Analog Audio Output
to 5.1 CH (see “Playback” on page 36).
RF IN
S-Video Video R --- Audio --- L
IN
1
RF OUT
IN
2
UHF/VHF
SOURCE INPUT AUDIO OUT VIDEO OUT
3. Also in the Playback sub-menu, select Speaker Setting and select the desired 5.1 channel
output settings (see “Speaker Setting” on page 37).
5.1 CHANNEL
AUDIO INPUT
SR
C
FR
FR
C
SR
SL
SW
FL
FL
Y/G
SW
Video
Pb/B
S-Video
SL
Coaxial Optical
Pr/R
DIGITAL AUDIO OUT
7
Page 14
OMPDDVR100.book Page 8 Monday, September 19, 2005 8:35 AM
Connecting the Recorder to Other Devices
Connecting to a Stereo Audio System Using an Analog Connection
The FR (right) and FL (left) outputs in the AUDIO OUT block on the rear of the recorder are the
recorder’s analog stereo audio outputs.
To connect to an audio system using
analog stereo sound:
1. Using two RCA cables, connect the FR
AUDIO SYSTEM
STEREO
AUDIO INPUT
L
(right) and FL (left) outputs in the
AUDIO OUT block on the rear of the
R
recorder to the audio system’s analog
stereo audio input.
Y/G
2. In the Setup menu, select the Playback
sub-menu and set Analog Audio Output
to 2 CH (see “Playback” on page 36).
RF IN
S-Video Video R --- Audio --- L
IN
1
RF OUT
IN
2
UHF/VHF
FR
C
SR
SOURCE INPUT AUDIO OUT VIDEO OUT
FL
SW
Video
Pb/B
S-Video
SL
Coaxial Optical
Pr/R
DIGITAL AUDIO OUT
Connecting to a Stereo Audio System Using a Digital Connection
There are two digital audio outputs in the DIGITAL AUDIO OUT block on the rear of the player:
Coaxial and Optical.
To connect to an audio system using
coaxial digital audio:
1. Using a coaxial digital cable (not
included), connect the Coaxial
connector in the DIGITAL AUDIO OUT
block on the rear of the recorder to the
audio system’s coaxial digital audio
input.
2. In the Setup menu, select the Playback
sub-menu and set Digital Audio Output
as appropriate (see “Playback” on
page 36).
AUDIO SYSTEM
RF IN
RF OUT
UHF/VHF
COAXIAL DIGITAL
AUDIO INPUT
FR
S-Video Video R --- Audio --- L
IN
1
IN
2
SOURCE INPUT AUDIO OUT VIDEO OUT
C
SR
FL
Y/G
SW
Video
Pb/B
S-Video
SL
Coaxial Optical
Pr/R
DIGITAL AUDIO OUT
To connect to an audio system using
optical digital audio:
1. Remove the plastic lens protectors from
the Optical connector in the DIGITAL
AUDIO OUT block on the rear of the
recorder and from the audio system’s
optical digital audio input.
2. Using a optical digital cable (not
included), connect the Optical
connector on the recorder to the audio
system’s optical input.
3. In the Setup menu, select the Playback
sub-menu and set Digital Audio Output
as appropriate (see “Playback” on page 36).
AUDIO SYSTEM
RF IN
S-Video Video R --- Audio --- L
IN
1
RF OUT
IN
2
UHF/VHF
8
OPTICAL DIGITAL
AUDIO INPUT
FR
C
SR
SOURCE INPUT AUDIO OUT VIDEO OUT
FL
SW
Video
S-Video
SL
Y/G
Pb/B
Pr/R
Coaxial Optical
DIGITAL AUDIO OUT
Page 15
OMPDDVR100.book Page 9 Monday, September 19, 2005 8:35 AM
Connecting Other Audio/Video Sources to the Recorder
There are three audio/video inputs on the recorder, one on the front and two on the rear. Each
has an S-Video input, a composite video input, and a stereo audio input.
In addition, there is a 4-pin IEEE 1394 (i.LINK/FireWire) input on
the front of the recorder.
You can record the video signal from any one of these sources to
DVD.
To connect a digital audio/video (IEEE 1394) source to the
recorder, use an IEEE 1394 cable to connect the device to the
DV IN input on the front of the recorder.
To connect analog audio/video sources to the recorder:
1. Select an audio/video input from the three available on the recorder.
Note: You should use the input on the front of the recorder for non-permanent connections,
such as to a camcorder when transferring its recorded video to DVD.
Connecting the Recorder to Other Devices
P
A
/
Y
U
A
S
L
E
E
C
R
U
O
S
P
N
V
R
E
C
E
E
X
R
T
P
S
T
P
O
2. If you would like to use S-Video, which
offers higher quality video than
composite, connect an S-Video cable
(not included) between the video
source and the S-Video input in the
input block selected in step 1 above.
If you would like to use composite
video, connect an RCA cable between
the video source and the Video input in
the input block selected in step 1 above.
3. Using two RCA cables, connect the
audio source to the L (left—white) and
R (right—red) inputs in the input block
selected in step 1 above.
AUDIO/VIDEO SOURCE
OR
RF IN
S-Video Video R --- Audio --- L
IN
1
RF OUT
IN
2
UHF/VHF
SOURCE INPUT AUDIO OUT VIDEO OUT
OUTPUT
S-VIDEO
VIDEO
AUDIO
R
L
FL
FR
C
SR
Y/G
SW
Video
Pb/B
S-Video
SL
Coaxial Optical
Pr/R
DIGITAL AUDIO OUT
9
Page 16
OMPDDVR100.book Page 10 Monday, September 19, 2005 8:35 AM
Using the Recorder for the First Time
Before using your new DVD recorder, you will need to set the clock and, if you have connected a
television signal, scan the signal spectrum to disable weak channels.
To set the clock:
1. Turn the recorder on.
2. Press SETUP to enter the Setup menu.
3. Use and to select the Clock sub-menu
SYSTEM SETUP - CLOCK
and press ENTER.
4. Use and to select Date and press
ENTER.
Date (mm/dd/yy)
Time (hh:mm:ss)
1 2 / 0 1 / 0 3
1 2 : 0 0 : 0 0
5. Enter the current date using the keypad.
Alternatively, you can select each digit
individually by pressing and , then
adjust it by pressing and .
6. Press ENTER to set the date.
7. Use and to select Time and press ENTER.
8. Enter the current time using the keypad.
Alternatively, you can select each digit individually by pressing and , then adjust it by
pressing and .
9. Press ENTER to set the time.
To scan the television signal spectrum:
1. Ensure the recorder is on and enter the Setup menu with the SETUP button.
2. Use and to select the Channel Scan
SYSTEM SETUP - CHANNEL SCAN
sub-menu and press ENTER.
3. Ensure the Tuner Input Source is set
correctly (see “Channel Scan” on page 39
for a full description of the choices).
Tuner input source
Scan channels
Modify channel information
Air
SCAN
EDIT
Note: If you are connecting directly to a
cable television wall outlet, contact your cable company to find
out which system is in use in your
area. IRC will work with most systems.
4. Use and to select Scan Channels and press ENTER.
The recorder will scan the signal spectrum and display its progress as it does so.
10
Page 17
OMPDDVR100.book Page 11 Monday, September 19, 2005 8:35 AM
Operating the Recorder
Turning the Recorder On and Off
Once the recorder is attached to a power outlet, you can turn it on and off by pressing the
button on the front of the recorder or on the remote.
Inserting a Disc
The receptacle for DVDs and CDs is located on the front of the player.
To insert a disc:
1. Press the button on the front of the player or on the remote to open the receptacle.
2. Place the disc on the tray.
3. Press the button again to close the receptacle.
Understanding the LCD Readout
The LCD readout on the front of the recorder displays information about the current disc,
playback, and recording. When the recorder is off, the readout shows the current time.
REPEAT
ALL
A- B CHANNEL
MP3 P N
S
DVD
PBC L RThFrSa
D
The following is a brief description of each of the indicators on the LCD readout. Consult the
sections in this manual on disc playback and recording for more detailed information.
Indicator Indication
REPEAT ALL/A-B The recorder is in a repeat mode:
• REPEAT—Repeating a chapter/track/file
• REPEAT ALL—Repeating all chapters/tracks/files on the disc
• REPEAT A-B—Repeating an arbitrary section of the audio/video
MP3/SVCD/DVD The current disc type:
• MP3—MP3 CD
• SVCD—Super Video CD
• VCD—Video CD
• CD—Audio CD or CD-ROM
• DVD—DVD or DVD-R/RW or DVD+R/RW
REC
ANGLE
AM
PM Su MoTu WeVCD
PROGRAM
RANDOM
The current video output format:
•—PAL
•—NTSC
The recorder is playing the current disc.
The current disc is paused.
11
Page 18
OMPDDVR100.book Page 12 Monday, September 19, 2005 8:35 AM
Operating the Recorder
Indicator Indication
PBC Playback control is on (Video CDs). When playback control is on, the
Video CD’s menu will be available.
CHANNEL The input source is set to Tuner. The two digits immediately below
CHANNEL will indicate the current channel number.
DTS multi-channel sound is enabled.
Dolby Digital multi-channel sound is enabled.
Recording(s) have been scheduled (see “Scheduling Recordings” on
page 17).
The recorder is recording.
ANGLE There are multiple camera angles available for the DVD video currently
playing.
AM/PM When the time is showing on the readout, these indicate AM or PM.
L/R The audio channel used for Audio CD and Video CD playback:
• L/R—stereo sound
• L—left channel mono
• R—right channel mono
PROGRAM The recorder is playing back a programmed sequence.
RANDOM The recorder is playing back chapters/tracks/files in a random sequence.
Su/Mo/Tu/We/Th/Fr/Sa The current day of the week
Bringing Up the On-Screen Display
The On-Screen Display (OSD) displays and allows you to to change information about the current
disc and playback. To bring up the OSD, press the DISPLAY button on the remote.
Accessing the Setup Menu
The Setup menu allows you to configure the operation of the recorder. You can change video,
audio, television, and language settings, and control access to mature programming. See
“Configuring the Recorder” on page 35 for more information. To access the Setup menu, press
the SETUP button on the remote.
12
Page 19
OMPDDVR100.book Page 13 Monday, September 19, 2005 8:35 AM
Using the Remote Control
The remote control can be used to control every aspect of the recorder’s operation and includes
more functionality than the controls on the recorder itself.
INPUT
ANGLE AUDIO SUBTITLE
CHANNEL
SEARCH ADD/CLEAR PROGRAM
ENTER
DISPLAY TITLE MENU RETURN
STOP PAUSE/STEP PLAY
VOLUME
(LEVEL)
NEXTPREV
REV FWD
SLOW REC
MUTE
ZOOM
MODE
A-B
P-SCAN REPEAT TIMER
SETUP DISC EDIT EDIT
The following is a list of all buttons on the remote and their functions:
Button Function
Turns the player on and off (standby)
Cycles through the signal sources: Tuner, AV1, AV2, AV3, DV (IEEE 1394) and
the current disc (if a disc is inserted)
Ejects the disc
Cycles through the camera angles available on the disc
Cycles through the audio channels available on the disc
Cycles through the subtitle channels available on the disc
Used to enter numbers and navigate directly to a specified track (CDs),
chapter (DVDs), or photo (photo CDs)
Changes the television channel
Brings up the search display, which you can use to jump to a location on the
current disc
13
Page 20
OMPDDVR100.book Page 14 Monday, September 19, 2005 8:35 AM
Using the Remote Control
Button Function
Adds a selection to the program playlist or removes a selection from the
playlist
Brings up the Program menu, which allows you to program playback sequence
Used to navigate menus
Confirms the current selection or entry
Brings up the On-Screen Display (OSD), which displays and allows you to
change current playback information
Returns to the Title menu
Returns to the previous menu viewed on the disc
When playing a Video CD, this button turns playback control on and off. When
playback control is on, any menu on the disc will be available.
Returns to the menu
When navigating directories on a data CD, this button navigates up one level.
Stops playback
Pauses playback. When playback is paused, pressing this button steps forward
one frame at a time.
Begins or resumes normal playback
Adjusts the audio volume
Returns to the previous chapter, track, photo, or media file
Skips to the next chapter, track, photo, or media file
Fast reverses the audio/video. Pressing this button cycles through the fast
reverse speeds.
Fast forwards the audio/video. Pressing this button cycles through the fast
forward speeds.
Mutes the audio
Slows down playback. Pressing this button repeatedly cycles through the slow
play speeds.
Begins recording. See “Recording Video Manually” on page 17 for more
information.
14
Page 21
OMPDDVR100.book Page 15 Monday, September 19, 2005 8:35 AM
Button Function
Zooms in on the picture. Pressing this button repeatedly cycles through the
zoom levels.
Repeats an arbitrary section of audio/video. Press once to mark the beginning
of the section, a second time to mark the end of the section and begin
repeating, and a third time to return to normal play mode.
Cycles through the recording modes: HQ, SP, LP, EP, and SLP (see
“Recording DVDs” on page 16).
Toggles the video output between progressive scan and interlaced
Cycles through the available repeat modes
Brings up the Record Scheduler, which allows you to schedule future
recordings
Brings up the Setup menu, which allows you to configure the recorder
Using the Remote Control
Brings up the Disc Edit menu, where you can edit the disc and its titles
Puts the recorder in Edit Mode, in which you can edit the contents of titles on
the disc
Replacing the Remote Batteries
The remote requires two AAA batteries, which are held in an enclosure on the back
of the remote.
To replace the battery:
1. Turn the remote over.
2. Slide the battery enclosure cover down off the remote.
3. Remove the old batteries and replace them with the new batteries. Be sure to
match the orientation indicated in the enclosure.
4. Slide the enclosure cover back onto the remote.
15
Page 22
OMPDDVR100.book Page 16 Monday, September 19, 2005 8:35 AM
Recording DVDs
Your DVD recorder can record up to six hours of video on a 4.7GB disc from any of the three
analog audio/video sources, the IEEE 1394 input, or the television tuner.
Upon inserting a blank disc, the recorder will immediately begin to format the disc to prepare it
for recording. This takes a few minutes, and a message will display on the screen informing you
that the formatting is in progress.
Supported Media Types
The recorder will record to DVD+R and DVD+RW discs. It will not record to DVD-R/RW or
DVD-RAM discs, so be sure you obtain DVD+R or DVD+RW discs for use with your recorder.
DVD+R discs may be written to only once—that is, any recording on a DVD+R is permanent.
However, you can add video to a DVD+R disc that still has empty space.
DVD+RW discs may be written to over and over again, as many as 1000 times, allowing you to
overwrite old video or edit any video currently on the disc.
About DVD Layout
DVDs are divided into titles and chapters.
Titles are generally used for full movies, shows, clips, etc.
There are usually only a few titles on a DVD.
Titles are further divided into chapters. Chapters are
generally used for individual scenes or coherent sections of
video. This allows you to navigate directly to a specific
scene or section of video. There are often many chapters in
a given title.
For example, if you had two movies on a DVD, each movie would inhabit its own title. The titles
would then be divided into chapters, one for each movie scene.
In recording DVDs, the recorder saves each recording session in a separate title. You can then edit
the DVD and create chapters within each title.
TITLE TITLE TITLE
CHAPTER CHAPTER CHAPTER
The LCD Readout
When in DVD record mode, though not actually recording, the first three digits of the readout
indicate the current signal source—if the source is television, “CHANNEL” will illuminate and the
first two digits will indicate the current channel. The last two digits on the readout indicate the
current quality setting.
When recording a DVD, the first two digits of the readout indicate the current signal. The rest of
the digits indicate the current recording time count.
When in Edit Mode (see “Using Edit Mode” on page 22), the first two digits of the readout
indicate the current title. The rest of the digits indicate the current playback time.
The rest of the readout behaves as described in “Understanding the LCD Readout” on page 11.
16
Page 23
OMPDDVR100.book Page 17 Monday, September 19, 2005 8:35 AM
The On-Screen Display
The DVD recording OSD has two modes:
The first mode (press DISPLAY once) shows the current signal source and recording quality.
Monitor Ch001 (No signal) SP
Recording DVDs
The second mode (press DISPLAY twice) displays and allows you
to change the current recording mode, signal source, recording
quality, recording state, title, chapter, and playback time.
RECORD (DVD+RW)
MODE New Title
SOURCE Ch001
QUALITY SP
REC TO DVD-VIDEO
TRICK Stop
TITLE 01/03
CHAPTER 01
TIME 00:00:01 / 01:59:59
Recording Video Manually
If you have a DVD+R or DVD+RW disc in the recorder, you can begin recording manually by
pressing the REC button. The recorder will begin recording video from the current source to the
disc.
Pressing REC again when the recorder is recording turns on timed recording, which will
automatically stop the recording after a set period of time. Pressing REC repeatedly cycles
through the options: 30 minutes, 60 minutes, 90 minutes, and Off. If there is insufficient space on
the disc for a particular timed recording mode, that mode will be unavailable.
Press to stop recording.
Scheduling Recordings
You can schedule future recordings using the
TIMER button on the remote. The TIMER button
brings up the Record Scheduler, which allows you
to schedule up to 20 recordings by source and
time.
To schedule a recording:
1. Press TIMER to bring up the Record Scheduler.
Record scheduler
Source
1
2
3
4
5
6
Quality Date Start End
2. Use and to select the first empty slot.
3. Press ENTER to bring up the Item Editor.
4. Use and to select Source and press ENTER.
5. Use and to select the desired source and press ENTER.
17
Item Editor
Source
Quality
Mode
Date
Start
End
OK Cancel
Ch001
SP
Once
1 2 / 0 1 / 0 3
1 2 : 0 0
1 2 : 3 0
Page 24
OMPDDVR100.book Page 18 Monday, September 19, 2005 8:35 AM
Recording DVDs
6. Set the desired Quality in the same fashion. The following qualities are available:
Name Format Bit Rate Capacity Quality
HQ (High Quality) 720 × 480 (NTSC)
9.5Mbps ~60 minutes Full DVD quality
720 × 576 (PAL)
SP (Standard Play) 720 × 480 (NTSC)
5.1Mbps >120 minutes Standard DVD quality
720 × 576 (PAL)
LP (Long Play) 352 × 480 (NTSC)
3.4Mbps >180 minutes Similar to S-VHS
352 × 576 (PAL)
EP (Extended Play) 352 × 480 (NTSC)
352 × 576 (PAL)
SLP (Super Long Play) 352 × 240 (NTSC)
352 × 288 (PAL)
2.5Mbps >240 minutes Similar to VHS in SP
mode
1.7Mbps >360 minutes Similar to VHS in EP
mode
7. Set the desired Mode in the same fashion. By setting the Mode properly, you can schedule the
player to record a particular program every time it plays. The options are
• Once—The recorder will record the program only once.
• Daily—The recorder will repeat this recording every day at the same time.
• Weekly—The recorder will repeat this recording every week on the same day at the same
time.
• Mon–Fri—The recorder will repeat this recording every week day at the same time.
• Mon–Sat—The recorder will repeat this recording every day except Sunday, at the same
time.
• Weekend—The recorder will repeat this recording every weekend day at the same time.
8. Use and to select Date and press ENTER.
9. Enter the date of the program (or the next date of the program if you’ve set Mode to repeat
the recording) using the keypad.
Alternatively, you can select each digit individually by pressing and , then adjust it by
pressing and .
10.Press ENTER to set the date.
11.Set Start and End to the program’s start and end times in the same fashion.
12.Use and to select OK and press ENTER.
To change a scheduled recording, select it in the Record Scheduler and press ENTER.
To clear a scheduled recording, select it in the Record Scheduler and press ADD/CLEAR.
Finalizing the Disc
If you are recording to a DVD+R disc, you must finalize the disc before it can be read by other
DVD players. For information on how to do this, see “Using the Disc Edit Menu” on page 19 and
“Finalizing the Disc (DVD+R Only)” on page 20.
Note: Once you have finalized a disc, no further recordings or changes can be made to it. Be
sure any recordings or changes are complete before you finalize.
18
Page 25
OMPDDVR100.book Page 19 Monday, September 19, 2005 8:35 AM
Editing Recorded DVDs
Once a DVD has been recorded, you can edit the video on the DVD using the Disc Edit menu and
Edit Mode.
Using the Disc Edit Menu
Press DISC EDIT to enter the Disc Edit menu. This menu
allows you to change settings for the entire disc. You can do
the following with the Disc Edit menu:
•Play the disc
• Rename, erase, or overwrite the disc
NTSC
DVD
EDIT
Play
Rename disc
Erase disc
Record a new title
Overwrite disc
Lock disc
• Lock or finalize the disc
• Make the disc compatible
• Create a new title
Renaming the Disc
The Rename Disc option in the Disc Edit menu allows you to change the disc title.
To rename the disc:
1. In the Disc Edit menu, use and to select
Rename Disc, and press ENTER.
2. In the Disc Name pop-up box that appears, use
the arrow controls and ENTER to select and press
the on-screen buttons to change the title.
3. Select OK to save the new name.
4. Select Exit to cancel the change.
Disc Name:
MY DVD_
A B C D E F G H I J K 0 1 2
L M N O P Q R S T U V 3 4 5
W X Y Z ( ) _ : ? . 6 7 8 9
Space Caps BkSp Delete Clear Exit OK
Erasing the Disc (DVD+RW Only)
If you are using a DVD+RW disc, you can erase the entire disc from the Disc Edit menu using the
Erase Disc menu option.
To erase the disc:
1. In the Disc Edit menu, use and to select Erase Disc, and press ENTER.
2. In the confirmation dialog that appears, select Yes and press ENTER to erase the disc.
Creating a New Title
The Record a New Title option in the Disc Edit menu allows you to create a new title on the disc.
When you select this option, the recorder will automatically set the recording mode to New Title,
at which point any new recording will be stored in a new title on the disc.
To create a new title:
1. In the Disc Edit menu, use and to select Record a New Title, and press ENTER.
2. Begin a new recording. It will be stored in a new title on the disc.
19
Page 26
OMPDDVR100.book Page 20 Monday, September 19, 2005 8:35 AM
Editing Recorded DVDs
Overwriting the Disc (DVD+RW Only)
If you are using a DVD+RW, you can overwrite the entire disc using the Overwrite Disc option in
the Disc Edit menu. When you select this option, the recorder will automatically set the recording
mode to Overwrite Disc, at which point any new recording will overwrite the video on the disc.
To overwrite the disc:
1. In the Disc Edit menu, use and to select Overwrite Disc, and press ENTER.
2. Begin a new recording. It will overwrite the video stored on the disc.
Making the Disc Compatible with Other DVD Players (DVD+RW Only)
The Make Compatible option in the Disc Edit menu will make a DVD+RW disc created with the
recorder compatible with other DVD players. (If the option is not available, the disc is already
compatible with other DVD players.)
Note: This feature will not necessarily make the disc compatible with your DVD player. It works
with many, but not all, DVD players.
To make the disc compatible with other DVD players, select the Make Compatible option in the
Disc Edit menu. The recorder will then begin the process, which may take a minute.
Locking and Unlocking the Disc (DVD+RW Only)
Locking a disc prevents it from being written to, protecting the data currently on the disc. If you
are using a DVD+RW disc, you can lock the disc using the Lock Disc option in the Disc Edit menu.
To lock the disc, select Lock Disc in the Disc Edit menu. The recorder will take a few seconds to
perform the lock procedure.
If a disc is already locked, the Unlock Disc option will show in the Disc Edit menu. Select this
option to unlock the disc. The recorder will take a few seconds to perform the unlock procedure.
Finalizing the Disc (DVD+R Only)
A DVD+R disc must be finalized before it can be read by other DVD players. You can finalize a
disc with the Finalize Disc option in the Disc Edit menu.
Note: Once you have finalized a disc, no further recordings or changes can be made to it. Be
sure any recordings or changes are complete before you finalize.
To finalize the disc:
1. In the Disc Edit menu, use and to select Finalize Disc, and press ENTER.
2. In the confirmation dialog that appears, select Yes and press ENTER to finalize the disc. The
recorder will begin the process of finalizing the disc, which can take up to an hour, depending
on the amount of video on the disc.
20
Page 27
OMPDDVR100.book Page 21 Monday, September 19, 2005 8:35 AM
Using the Title Menu
Press TITLE to enter the Title menu. This menu allows you to
change individual titles on the disc. You can do the
following with the Title menu:
• Play a title
• Edit, rename, erase, or overwrite an existing title
• Overwrite from the beginning of a title to the end of
the disc
Editing a Title
Using the Edit Title option in the Title menu, you can enter
Edit Mode for a title (see “Using Edit Mode” on page 22).
To edit a title:
1. In the Title menu, use and to select the title.
Editing Recorded DVDs
Play title
Edit title
Rename title
Erase title
Overwrite title
Overwrite disc
3. TITLE
12/01/2003
12:00:00
SP 00:45:00
2. Press to bring up the menu for the title.
3. Use and to select Edit Title, and press ENTER.
Renaming a Title
The Rename Title option in the Title menu allows you to change the name of a title.
To rename a title:
1. In the Title menu, use and to select the title.
2. Press to bring up the menu for the title.
3. Use and to select Rename Title, and press
Title Name:
ENTER.
4. In the Title Name pop-up box that appears, use
TITLE_
the arrow controls and ENTER to select and press
the on-screen buttons to change the title.
5. Select OK to save the new name.
6. Select Exit to cancel the change.
A B C D E F G H I J K 0 1 2
L M N O P Q R S T U V 3 4 5
W X Y Z ( ) _ : ? . 6 7 8 9
Space Caps BkSp Delete Clear Exit OK
Erasing a Title
You can erase a title from the Title menu using the Erase Title menu option.
Note: If you are using a DVD+R disc, you cannot reuse the space used by a title when it is erased.
To erase a title:
1. In the Title menu, use and to select the title.
2. Press to bring up the menu for the title.
3. Use and to select Erase Title, and press ENTER.
4. In the confirmation dialog that appears, select Yes and press ENTER to erase the title.
21
Page 28
OMPDDVR100.book Page 22 Monday, September 19, 2005 8:35 AM
Editing Recorded DVDs
Overwriting a Title (DVD+RW Only)
If you are using a DVD+RW, you can overwrite a title using the Overwrite Title option in the Title
menu. When you select this option, the recorder will automatically set the recording mode to
Overwrite Title, at which point any new recording will overwrite the selected title.
To overwrite a title:
1. In the Title menu, use and to select the title.
2. Press to bring up the menu for the title.
3. Use and to select Overwrite Title, and press ENTER.
4. Begin a new recording. It will overwrite the title you selected.
Overwriting from a Title (DVD+RW Only)
If you are using a DVD+RW, you can overwrite from the beginning of a title to the end of the disc
using the Overwrite Disc option in the Title menu. When you select this option, the recorder will
automatically set the recording mode to Overwrite Disc, at which point any new recording will
overwrite the disc beginning with the selected title.
To overwrite from a title to the end of the disc:
1. In the Title menu, use and to select the title.
2. Press to bring up the menu for the title.
3. Use and to select Overwrite Disc, and press ENTER.
4. Begin a new recording. It will overwrite from the title you selected to the end of the disc.
Using Edit Mode
Edit Mode allows you to change the contents of individual titles
on the disc. You can enter Edit Mode for the currently playing title
by pressing EDIT, or you can enter from the Title menu as
described in “Editing a Title” on page 21. You can do the
following in Edit Mode:
• Create or delete a chapter marker
EDIT MODE
Title: 01/03
Chapter: 01/01
Pause
Chapter marker
Hide chapter
Index picture
Split title
• Hide a chapter
• Set an index picture for the title
• Split the title into two
Creating/Deleting a Chapter Marker
Chapter markers indicate where chapters begin within a title. You can create and delete chapter
markers in Edit Mode.
To create a new chapter marker:
1. Pause title playback at the location where you would like the new chapter to start.
2. Select Chapter Marker in the Edit Mode menu and press .
3. Select Insert Marker and press ENTER. A new chapter will be created, beginning at the
current location.
22
Page 29
OMPDDVR100.book Page 23 Monday, September 19, 2005 8:35 AM
To delete a chapter marker:
1. Pause title playback in the chapter whose marker you would like to delete.
2. Select Chapter Marker in the Edit Mode menu and press .
3. Select Delete Marker and press ENTER. The recorder will delete the marker for the current
chapter and merge it with the previous chapter.
To delete all chapter markers, instead select Delete All Markers. The recorder will delete all
chapter markers, and the title will then contain only one chapter.
Hiding a Chapter
Using the Hide Chapter option in the Edit Mode menu, you can make the current chapter
invisible during playback. That is, when playing the DVD in playback mode or on other DVD
players, a hidden chapter will be skipped, though it is still on the disc.
Note: When in Edit Mode, the hidden chapter will still play back.
Editing Recorded DVDs
To hide a chapter:
1. Pause title playback in the chapter you would like to hide.
2. Select Hide Chapter in the Edit Mode menu and press ENTER. The recorder will mark the
current chapter hidden so it will not be played back.
Setting an Index Picture
Each title has an index picture that shows in the Title menu. You can set a title’s index picture
using the Index Picture option in the Edit Mode menu.
To set the index picture:
1. Pause title playback on the frame you would like to use as the index picture.
2. Select Index Picture in the Edit Mode menu and press ENTER.
Splitting a Title (DVD+RW Only)
If you are using a DVD+RW disc, you can split a title into two using the Split Title option in the
Edit Mode menu.
Note: Splitting a title cannot be reversed.
To split a title:
1. Pause title playback where you would like to split the title.
2. Select Split Title in the Edit Mode menu and press ENTER. The recorder will split the title,
beginning the new title at the current location. This may take a few minutes, depending on
the length of the title.
23
Page 30
OMPDDVR100.book Page 24 Monday, September 19, 2005 8:35 AM
Playing DVDs
DVDs will play upon insertion. The player can perform all standard DVD playback and search
functions.
The LCD Readout
When playing a DVD, the first two digits of the readout indicate the current chapter. The rest of
the digits indicate the current playback time.
The rest of the readout behaves as described in “Understanding the LCD Readout” on page 11.
The On-Screen Display
The DVD OSD has two modes:
The first mode (press DISPLAY once) shows the current repeat mode, playback mode, title,
chapter, audio channel, and playback time.
NORMAL PLAY T01/03 C01/10 AU01/01 00:00:01
The second mode (press DISPLAY twice) displays and allows you to
change the current repeat mode, playback mode, title, chapter,
audio channel, subtitle channel, camera angle, and playback time.
To change a setting:
1. Select the setting using and .
2. Press to bring up a list of options for the setting.
(If the setting to be changed is Title, Chapter, Angle, or Time,
enter the desired value using the remote keypad and skip step 3.)
3. Use and to select the desired option.
4. Press ENTER.
Press DISPLAY a third time to exit the OSD.
Navigating Menus
When in a DVD menu, use the arrow controls to navigate.
Press ENTER to select an item.
Press MENU to return to the previous menu.
DVD
MODE NORMAL
Trick mod PLAY
TITLE 01/03
CHAPTER 01/10
AUDIO 01/01-English
SUBTITLE Off
ANGLE 01/01
T-TIME 00:00:01/01:59:59
Controlling Playback
Press once to stop the DVD at the current location, and twice to stop the DVD completely.
When the DVD is playing, press to pause it.
When the DVD is paused, press to step forward one frame at a time.
Press to return to the previous chapter.
Press to skip to the next chapter.
24
Page 31
OMPDDVR100.book Page 25 Monday, September 19, 2005 8:35 AM
Press to fast reverse the DVD. Press to fast forward the DVD. Repeated presses cycle through
the speed options: ×2, ×4, ×16, ×32, and normal speed.
Press to play the video at a slower speed. Repeated presses cycle through the speed options:
×1/2, ×1/4, ×1/8, ×1/16, and normal speed.
Press to return to normal play mode or to start playing the DVD again when it is stopped or
paused.
Press MENU to return to the last DVD menu.
Searching to a Location
You can search to a chapter or time on the current disc using the SEARCH button.
To search to a location:
1. Press SEARCH once to bring up the Chapter Search menu and twice to bring up the Time
Search menu.
Playing DVDs
2. Enter the desired chapter/time using the remote keypad.
3. Press ENTER.
Programming Playback Sequence
The PROGRAM button brings up the Program menu, which allows you to program playback
sequence.
To program playback sequence:
1. Press PROGRAM to bring up the Program
menu.
2. Use and to select a title, then press ENTER
(press ADD/CLEAR to add the whole title to the
playlist).
3. Use and to select a chapter, then press
ADD/CLEAR to add it to the playlist.
4. Repeat 2–3 until all desired chapters have been
added to the playlist.
5. Press to move to the Program column.
6. Select a playlist item and press ENTER to begin
playing back the playlist from that point.
Edit program play list
TITLE
TITLE 01
TITLE 02
TITLE 03
TITLE 04
TITLE 05
TITLE 06
TITLE 07
TITLE 08
Edit program play list
Chapter of title 01
..
Chapter 01
Chapter 02
Chapter 03
Chapter 04
Chapter 05
Chapter 06
Chapter 07
Favorite/Program
Favorite/Program
To remove an item from the playlist, select it and press ADD/CLEAR.
To exit the Program menu, press RETURN.
25
Page 32
OMPDDVR100.book Page 26 Monday, September 19, 2005 8:35 AM
Playing Video CDs
Video CDs can contain video or still images such as photos. Your DVD recorder will play all
standard Video CD formats.
Upon insertion, the player will read and begin to play the CD.
If there is a menu on the CD, it will appear, allowing you to navigate through the tracks stored
on the CD. Otherwise, the player will begin playing the video back beginning with the first track.
If the CD contains still pictures, the player will display them as a slideshow.
The LCD Readout
When playing a Video CD, the first two digits of the readout indicate the current track. The rest
of the digits indicate the current playback time.
The rest of the readout behaves as described in “Understanding the LCD Readout” on page 11.
The On-Screen Display
The Video CD OSD has two modes:
The first mode (press DISPLAY once) displays the current repeat mode, playback mode, track,
playback control status (PBC—the playback control status determines whether the disc menu is
available), and playback time.
NORMAL PLAY TR01/10 PBC ON 00:00:01
The second mode (press DISPLAY twice) displays and allows you to
change the current repeat mode, playback mode, track, audio
channel, playback control status, and playback time.
To change a setting:
1. Select the setting using and .
2. Press to bring up a list of options for the setting.
(If the setting to be changed is Track or Time, enter the desired value using the remote
keypad and skip step 3.)
3. Use and to select the desired option.
4. Press ENTER.
VCD
MODE NORMAL
Trick mod PLAY
TRACK 01/10
AUDIO STEREO
PBC PBC ON
TR-TIME 00:00:01-01:59:59
Press DISPLAY a third time to exit the OSD.
Navigating Menus
Press and to scroll through menu pages.
To view an item, enter its number on the keypad and press ENTER.
Note: To view an item, the menu page containing the item must be visible before you enter the
item’s number.
Controlling Playback
Press once to stop the disc at the current location, and twice to stop the disc completely.
26
Page 33
OMPDDVR100.book Page 27 Monday, September 19, 2005 8:35 AM
When the disc is playing, press to pause it.
When the disc is paused, press to step forward one frame at a time.
Press to return to the previous track.
Press to skip to the next track.
Press to fast reverse the video. Press to fast forward the video. Repeated presses cycle
through the speed options: ×2, ×4, ×16, ×32, and normal speed.
Press to play the video at a slower speed. Repeated presses cycle through the speed options:
×1/2, ×1/4, ×1/8, ×1/16, and normal speed.
Press to return to normal play mode or to start playing the disc again when it is stopped or
paused.
Press RETURN to return to the menu.
Searching to a Location
Using the SEARCH button, you can search to a track, a time measured from the beginning of the
disc, or a time measured from the beginning of the track.
Playing Video CDs
To search to a location:
1. Press SEARCH once to bring up the Track Search menu, twice to bring up the Disc Time Search
menu, and a third time to bring up the Track Time Search menu.
2. Enter the desired track/time using the remote keypad.
3. Press ENTER.
Programming Playback Sequence
The PROGRAM button brings up the Program menu, which allows you to program playback
sequence.
To program playback sequence:
1. Press PROGRAM to bring up the Program
menu.
2. Use and to select a track, then press
ADD/CLEAR to add it to the playlist.
3. Repeat step 3 until all desired tracks have been
added to the playlist.
4. Press to move to the Program column.
5. Select a playlist item and press ENTER to begin playing back the playlist from that point.
To remove an item from the playlist, select it and press ADD/CLEAR.
Edit program play list
TRACK
TRACK 01
TRACK 02
TRACK 03
TRACK 04
TRACK 05
TRACK 06
TRACK 07
TRACK 08
Favorite/Program
To exit the Program menu, press RETURN.
27
Page 34
OMPDDVR100.book Page 28 Monday, September 19, 2005 8:35 AM
Playing Audio CDs
Audio CDs will play upon insertion. All standard
Audio CD navigation features are available.
When an Audio CD begins playing, a display will
appear showing all tracks on the CD and allowing
you to navigate the tracks. In addition, you can
program playback sequence.
CDDA - PLAY 00:00:01-00:04:59
FILES&DIRECTORY
TRACK 1
TRACK 2
TRACK 3
TRACK 4
TRACK 5
TRACK 6
TRACK 7
TRACK 8
FAVORITE/PROGRAM
The LCD Readout
When playing an Audio CD, the first two digits of the readout indicate the current track. The rest
of the digits indicate the current playback time.
The rest of the readout behaves as described in “Understanding the LCD Readout” on page 11.
The On-Screen Display
The Audio CD OSD (press DISPLAY) displays and allows you to
change the current repeat mode, playback mode, audio channel,
track, and playback time.
Press DISPLAY a second time to exit the OSD.
To change a setting:
1. Select the setting using and .
2. Press to bring up a list of options for the setting.
CDDA
MODE NORMAL
TRICK PLAY
AUDIO STEREO
TRACK 01 / 10
TIME 00:00:01-00:04:59
(If the setting to be changed is Track or Time, enter the desired value using the remote
keypad and skip step 3.)
3. Use and to select the desired option.
4. Press ENTER.
Controlling Playback
Press to stop playback.
When the disc is playing, press to pause it.
Press to return to the previous track.
Press to skip to the next track.
Press to fast reverse the audio. Press to fast forward the audio. Repeated presses cycle
through the speed options: ×2, ×4, and normal speed.
Press to return to normal play mode or to start playing the disc again when it is stopped or
paused.
To skip directly to a track, enter the track number on the keypad and press ENTER.
28
Page 35
OMPDDVR100.book Page 29 Monday, September 19, 2005 8:35 AM
Programming Playback Sequence
The navigation menu that appears when you first insert an Audio CD allows you to program
playback sequence.
To program playback sequence:
1. Use and to select a track, then press
ADD/CLEAR to add it to the playlist.
2. Repeat until all desired tracks have been added
to the playlist.
3. Press to move to the Program column.
4. Select a playlist item and press ENTER to begin
playing back the playlist from that point.
To remove an item from the playlist, select it and press ADD/CLEAR.
Playing Audio CDs
CDDA - PLAY 00:00:01-00:04:59
FILES&DIRECTORY
TRACK 1
TRACK 2
TRACK 3
TRACK 4
TRACK 5
TRACK 6
TRACK 7
TRACK 8
FAVORITE/PROGRAM
29
Page 36
OMPDDVR100.book Page 30 Monday, September 19, 2005 8:35 AM
Playing Kodak Picture CDs
Upon insertion, the player will read and begin to play your Kodak Picture CD, displaying a
slideshow of the images on the disc.
The LCD Readout
When playing a Kodak Picture CD, the first two digits of the readout indicate the current image
number.
The rest of the readout behaves as described in “Understanding the LCD Readout” on page 11.
Controlling Playback
Press or RETURN to stop slideshow playback and return to the menu.
When the disc is playing, press to pause it.
Press to start playing the slideshow again when it is stopped or paused.
Press to return to the previous image.
Press to skip to the next image.
To skip directly to an image, enter the image number on the remote keypad and press ENTER.
Navigating Menus
Press or RETURN while the slideshow is playing to
bring up the thumbnail menu, which displays
thumbnails of the images on the disc.
Press and to scroll through menu pages.
Use the arrow controls to select the desired image and
press ENTER. Alternatively, enter the number of the
desired image on the remote keypad and press ENTER.
The selected image will display on the screen.
Transforming Images
Press to rotate the image 90° clockwise.
Press to rotate the image 90° counterclockwise.
Press to flip the image vertically.
Press to flip the image horizontally.
30
Page 37
OMPDDVR100.book Page 31 Monday, September 19, 2005 8:35 AM
Enabling Slideshow Transition Effects
Press ANGLE to cycle through the slideshow transition effects:
• Random Wipe Mode
• Top to Bottom
• Bottom to Top
• Left to Right
•Righ to Left
• Extend Center Vertically
• Extend Center Horizontally
• Compress Center Vertically
• Compress Center Horizontally
• Diagonal Left Top
• Diagonal Right Top
• Diagonal Left Bottom
• Diagonal Right Bottom
• Window Horizontally
• Window Vertically
• Edge to Center
• Center to Edge
Playing Kodak Picture CDs
Repeating Images
Press REPEAT to cycle through the repeat modes: Off, Image, Directory, and All.
31
Page 38
OMPDDVR100.book Page 32 Monday, September 19, 2005 8:35 AM
Playing Media on Data CDs
Upon inserting a data CD, the player will display a menu showing all media files on the disc and
allowing you to select files for playback.
The LCD Readout
When playing media on a data CD, the first two digits of the readout indicate the current file
number. The rest of the digits indicate the current playback time (audio/video files only).
The rest of the readout behaves as described in “Understanding the LCD Readout” on page 11.
The On-Screen Display
There are three different OSD modes, one for each type of media file (audio, image, and video).
Each mode displays and allows you to change settings for the associated type of media file.
Setting the Type in the OSD selects the mode.
The audio and video modes display and allow you to change the
current repeat mode, playback mode, audio channel, and playback
time.
The image mode displays and allows you to change the current
repeat mode, playback mode, image transition effect (wipe) mode,
zoom level, and image rotation.
To change a setting:
1. Select the setting using and .
2. Press to bring up a list of options for the setting.
File Play
TYPE AUDIO
MODE NORMAL
TRICK PLAY
AUDIO STEREO
TIME 00:00:01 / 00:04:59
File Play
TYPE PIC
MODE NORMAL
TRICK PLAY
WIPE RANDOM
ZOOM FITSCREEN
ROTATE CLOCKWISE 0
(If the setting to be changed is Time, enter the desired value using the remote keypad and
skip step 3.)
3. Use and to select the desired option.
4. Press ENTER.
Using the Menu
The menu allows you to navigate files and
program playback sequence.
The left column of the menu allows you to
navigate the directory structure of the disc and
displays any image (JPEG), video (MPEG), or audio
(MP3) files on the disc.
File Play - STOP
FILES&DIRECTORY
1
FOLDER 1
2
FOLDER 2
3
AUDIO 1.MP3
4
AUDIO 2.MP3
5
IMAGE 1.JPG
6
IMAGE 2.JPG
7
VIDEO 1.MPG
8
VIDEO 2.MPG
FAVORITE/PROGRAM
To play back a file, use and to select it, then
press ENTER. The recorder will then sequentially progress through any other files of the same
type in the same directory.
32
Page 39
OMPDDVR100.book Page 33 Monday, September 19, 2005 8:35 AM
You can also play back audio files while displaying image files. To do so, begin playback of an
audio file, then select an image file for playback. The audio will play while the image slideshow
displays.
The right column of the menu allows you to program playback sequence by creating a playlist.
See “Programming Playback Sequence” on page 34.
Controlling Audio File Playback
Press to pause playback. Press to resume playback.
Press once to stop CD playback.
Press to return to the previous file. Press to skip to the next file.
Press to fast reverse playback. Press to fast forward playback. Repeated presses cycle
through the speed options: ×2, ×4, ×8, ×16, ×32, and normal speed.
Press to return to normal play mode or to start playing the disc again when it is stopped.
Playing Media on Data CDs
Controlling Image File Playback
Press to pause playback. Press to resume playback.
Press to stop the slideshow and return to the menu.
Press to return to the previous image. Press to skip to the next image.
Press to rotate the image 90° clockwise.
Press to rotate the image 90° counterclockwise.
Press to flip the image vertically.
Press to flip the image horizontally.
Press ANGLE to cycle through the slideshow transition effects:
• Random Wipe Mode
• Top to Bottom
• Bottom to Top
• Left to Right
•Righ to Left
• Extend Center Vertically
• Extend Center Horizontally
• Compress Center Vertically
• Compress Center Horizontally
• Diagonal Left Top
• Diagonal Right Top
• Diagonal Left Bottom
• Diagonal Right Bottom
• Window Horizontally
• Window Vertically
• Edge to Center
• Center to Edge
33
Page 40
OMPDDVR100.book Page 34 Monday, September 19, 2005 8:35 AM
Playing Media on Data CDs
Controlling Video File Playback
When video is playing, press to pause it. Press to resume playback.
Press to stop playback and return to the menu.
Press to return to the previous file. Press to skip to the next file.
Press to fast reverse playback. Press to fast forward playback. Repeated presses cycle
through the speed options: ×2, ×4, ×8, ×16, ×32, and normal speed.
Press to play the video at a slower speed. Repeated presses cycle through the speed options:
×1/2, ×1/4, ×1/8, and normal speed.
Press to return to normal play mode or to start playing the disc again when it is stopped.
Searching to a Location
Using the SEARCH button, you can search to a file in the current directory or a time in the
current file (audio/video files).
To search to a location:
1. Press SEARCH once to search to a file, twice to search to a time in the current file (audio/
video files).
2. Enter the desired file number or time using the remote keypad. The location you enter will
display on the menu as you enter it.
3. Press ENTER.
Programming Playback Sequence
The navigation menu that appears when you first insert a data CD allows you to program
playback sequence.
To program playback sequence:
1. Use and to select a file, then press
ADD/CLEAR to add it to the playlist.
2. Repeat until all desired files have been added
to the playlist.
3. Press to move to the Program column.
4. Select a playlist item and press ENTER to begin
playing back the playlist from that point.
To remove an item from the playlist, select it and press ADD/CLEAR.
File Play - STOP
FILES&DIRECTORY
1
FOLDER 1
2
FOLDER 2
3
AUDIO 1.MP3
4
AUDIO 2.MP3
5
IMAGE 1.JPG
6
IMAGE 2.JPG
7
VIDEO 1.MPG
8
VIDEO 2.MPG
FAVORITE/PROGRAM
34
Page 41
OMPDDVR100.book Page 35 Monday, September 19, 2005 8:35 AM
Configuring the Recorder
The Setup menu allows you to configure the operation of the recorder. You can change video,
audio, and language settings, control access to mature programming, and configure other
general behavior.
To use the Setup menu:
1. Press the SETUP button to bring up the menu.
2. Once the menu appears, use the and buttons to navigate the sub-menus listed at the side
of the menu.
3. Press to enter a sub-menu. (Press repeatedly to leave a sub-menu.)
4. Use and to select an item.
5. Press ENTER to bring up a list of the available options for the selected item.
6. Use and to select the desired option and then press ENTER to select it.
7. Press the SETUP button to exit the menu.
The following is a description of the contents of the Setup menu and their use.
General
The General sub-menu allows you to change
video output settings, enable/disable a
screen saver, and restore all recorder settings
to factory defaults. The menu items are as
follows:
SYSTEM SETUP - GENERAL
Screen saver
Progressive/Interlace
Video output format
Restore factory settings
OFF
Interlace
NTSC
Screen Saver
Turns the screen saver on and off. When
on, a screen saver will appear after a predefined period of inactivity.
Progressive/Interlace
Selects progressive scan or interlaced video output. Progressive scan offers crisp, flicker-free
video and higher quality than interlaced.
Note: Progressive scan only works with component video connections to displays that
support it. Check to ensure your display supports progressive scan before configuring
the recorder to use it.
OK
Video Output Format
Selects the video format used to transmit video to an external display:
• NTSC—A format used primarily in North and Central America
• PAL—A format used in various parts of the world, including Europe, Asia, South America,
and the Middle East
Restore Factory Settings
Resets all recorder settings to factory defaults
35
Page 42
OMPDDVR100.book Page 36 Monday, September 19, 2005 8:35 AM
Configuring the Recorder
Playback
The Playback sub-menu allows you to change
audio and video playback settings and set up
parental controls. The menu items are as
follows:
TV Aspect Ratio
SYSTEM SETUP - PLAYBACK
TV aspect ratio
Rating level
Digital audio output
Analog audio output
Speaker setting
16:9
OFF
RAW
2 CH
Selects the aspect ratio used by the
external display and the method used to
display widescreen video on nonwidescreen displays:
• 16:9—Native widescreen
• Pan Scan—Crops the video image to fill the entire screen of a 4:3 format display
• Letter Box—Displays the full image on the screen of a 4:3 format display, but does not fill
the entire screen
4:3PS
4:3LB
16:9
Rating Level
When you select this item, the recorder will ask for the
Enter Password
current parental control password. Enter the password using
the remote keypad, then press ENTER. The factory default
password is '1234'.
OK Cancel
Once you enter the correct password, the recorder will
display a pop-up box where you can select the content
rating above which a password will be required, or set a new
password.
OK
To change the protection level:
1. Use the arrow controls to select the drop-down box and
press ENTER.
2. Then use and to select the desired rating level and
press ENTER. The available ratings are
•Off
• 8: Adult
•7: NC-17
•6: R
•5: PG-R
•4: PG-13
•3: PG
•2: G
•1: Kid Safe
36
Set Rating Level
OFF
New password
OK
NEW
Page 43
OMPDDVR100.book Page 37 Monday, September 19, 2005 8:35 AM
Configuring the Recorder
To set a new password:
1. Use the arrow controls to select the NEW button and
press ENTER. Another pop-up box will display asking for
the new password.
New password
Confirm password
New Password
OK
Cancel
2. Enter a new four-digit password in the New Password
box.
3. Press to select the Confirm Password box and enter the same password again.
4. Press ENTER to change the password.
To cancel the password change, use the arrow controls to select CANCEL and press ENTER.
Digital Audio Output
Configures the digital audio output format: Raw or LPCM
Analog Audio Output
Configures the analog audio output format: 2 CH (stereo) or 5.1 CH (surround)
When 2 CH is selected, only the FR and FL outputs in the AUDIO OUT block on the rear of the
recorder will be active.
When 5.1 CH is selected, all outputs in the AUDIO OUT block will be active.
Speaker Setting
Brings up a pop-up box that allows you to
change settings for the 5.1 channel audio
outputs. The parameters are
• Front Speaker—Sets the size of the front
channel speakers and their distance from the
listening position in meters
• Center Speaker—Sets the size of the center
SPEAKER SETTING
Front Speaker
Center Speaker
Surround Speaker
Subwoofer
Dynamic Range Compression
Large
Small
Small
Test OK
Distance 4.5 M
Distance 4.5 M
Distance 4.5 M
No
Off
channel speaker and their distance from the
listening position in meters
• Surround Speaker—Sets the size of the side channel speakers and their distance from the
listening position in meters
• Subwoofer—Turns subwoofer output on and off
• Dynamic Range Compression—Turns dynamic range compression on and off
Select Tes t to test the configuration by playing noise on each of the channels sequentially.
Select OK to confirm the settings and return to the Playback menu.
Note: Analog Audio Output above must be set to 5.1 CH to access this menu option.
37
Page 44
OMPDDVR100.book Page 38 Monday, September 19, 2005 8:35 AM
Configuring the Recorder
Record
The Record sub-menu configures DVD
recording. The menu items are as follows:
Auto Chapter Marker
SYSTEM SETUP - RECORD
Auto chapter marker
Default source
Default quality
5 minutes
Tuner
SP
Sets up automatic chapter marking,
which creates a new DVD chapter at
regular intervals. You can set the
recorder to create a new chapter every 5,
10, 15, or 20 minutes, or you can turn off
automatic chapter marking.
Default Source
Sets the audio/video source selected when the recorder is turned on: AV1, AV2, AV3, DV
(IEEE 1394), or Tuner
Default Quality
Sets the default quality used for recording:
Name Format Bit Rate Capacity Quality
HQ (High Quality) 720 × 480 (NTSC)
9.5Mbps ~60 minutes Full DVD quality
720 × 576 (PAL)
SP (Standard Play) 720 × 480 (NTSC)
720 × 576 (PAL)
LP (Long Play) 352 × 480 (NTSC)
352 × 576 (PAL)
EP (Extended Play) 352 × 480 (NTSC)
352 × 576 (PAL)
SLP (Super Long Play) 352 × 240 (NTSC)
352 × 288 (PAL)
Language
The Language sub-menu allows you to
change the language used by the player for
the On-Screen Display (OSD), menus, audio,
and subtitles. The menu items are as follows:
OSD Language
Changes the language of the Setup
menu and the OSD
Menu Language
Changes the language used for disc menus
5.1Mbps >120 minutes Standard DVD quality
3.4Mbps >180 minutes Similar to S-VHS
2.5Mbps >240 minutes Similar to VHS in SP
mode
1.7Mbps >360 minutes Similar to VHS in EP
mode
SYSTEM SETUP - LANGUAGE
OSD language
Menu language
Subtitle language
Audio language
English
English
OFF
English
Subtitle Language
Changes the language used for subtitles
38
Page 45
OMPDDVR100.book Page 39 Monday, September 19, 2005 8:35 AM
Audio Language
Changes the language used for audio
Configuring the Recorder
Channel Scan
The Channel Scan sub-menu configures the
television tuner. The menu items are as
follows:
SYSTEM SETUP - CHANNEL SCAN
Tuner input source
Scan channels
Modify channel information
Air
Tuner Input Source
Sets the type of television signal the
tuner uses:
• Air—Used when an antenna is
connected to the recorder’s television input
• Standard—Used for a standard cable television connection
• IRC—A type of cable television signal used primarily on the east coast of the US
• HRC—A type of cable television signal used primarily on the west coast of the US
Note: If you are connecting directly to a cable television wall outlet, contact your cable
company to find out which system is in use in your area. IRC will work with most
systems.
Scan Channels
Scans the signal spectrum and weeds out the channels with insufficient signal strength
Modify Channel Information
Brings up a pop-up box that allows you to change settings for
individual television channels. The parameters are
• Name—Selects the channel number to be modified. Enter the
channel number on the remote keypad and press ENTER, or
CHANNEL
Name
Frequency
Skip
Fine tune
use the CHANNEL buttons on the remote to adjust the
channel.
• Frequency—Shows the frequency used for the channel
selected in Name. Press or to scan for a strong signal.
OK Cancel
• Skip—Determines whether the channel is available when
using the CHANNEL buttons on the remote. When set to Yes,
the recorder will skip the channel when you scroll through
channels using the CHANNEL buttons.
• Fine Tune—Adjusts the frequency used for the channel in small increments for better
reception. Use and to adjust this parameter.
SCAN
EDIT
Ch002
55.25MHz
No
39
Page 46
OMPDDVR100.book Page 40 Monday, September 19, 2005 8:35 AM
Configuring the Recorder
Clock
The Clock sub-menu allows you to set the
current date and time.
SYSTEM SETUP - CLOCK
Date (mm/dd/yy)
Time (hh:mm:ss)
To set the date/time:
1. Use and to select Date or Time and
press ENTER.
2. Enter the desired value using the keypad.
Alternatively, you can select each digit
individually by pressing and , then adjust it by pressing and .
3. Press ENTER to set the time/date.
1 2 / 0 1 / 0 3
1 2 : 0 0 : 0 0
40
Page 47
OMPDDVR100.book Page 41 Monday, September 19, 2005 8:35 AM
Troubleshooting
Symptom Possible Cause Resolution
Power does not come onPower cord(s) not
securely connected
Power outlet is off or
not working
Remote control not
functioning
No picture Incorrect video
Unclear or noisy
Batteries inserted
improperly
Batteries low on
energy
A button is stuck Jog any stuck buttons on the remote to unstick
Obstacle between
remote and recorder
The remote is too far
from the recorder
format selected
No signal Make sure the proper source is selected on the
Signal cable(s) not
securely connected
Radio interference Check for any electronic devices nearby that
Incorrect video
format selected
Poor television signal If you are using an antenna, move the antenna
Make sure the power cable is securely connected
to a wall outlet.
Try plugging a different device into the outlet
and see if it turns on. If not, check that the
outlet is on or use a different outlet.
Make sure the batteries are inserted and
oriented properly.
Replace the batteries.
them.
Remove the obstacle.
Move closer to the recorder.
Set Progressive/Interlace and Video Output
Format as appropriate in the Setup menu under
the General sub-menu. See “General” on
page 35.
external display. If there is still no picture, check
the signal cable(s) and ensure the recorder is on
and working.
Make sure the signal cable(s) are firmly
connected.
might be interfering with the video signal or the
recorder’s operation.
Set Progressive/Interlace and Video Output
Format as appropriate in the Setup menu under
the General sub-menu. See “General” on
page 35.
to a position with better reception, or obtain
and use a more powerful antenna.
If the recorder is connected to a cable TV signal,
ensure the cable is connected securely.
Otherwise, contact your cable service provider.
41
Page 48
OMPDDVR100.book Page 42 Monday, September 19, 2005 8:35 AM
Troubleshooting
Symptom Possible Cause Resolution
Distorted image Display format set
incorrectly
No sound Audio cable(s) not
securely connected
Audio cable(s)
connected to
incorrect input
Incorrect audio
format selected
Audio muted Unmute the audio by pressing the MUTE button
Disc fails to load Unreadable disc Ensure disc is not scratched or dirty. Clean and
Disc format not
supported
Recorded disc fails to
play on other
player(s)
Disc not finalized If you are using a DVD+R disc, ensure it is
Disc not made
compatible
Disc format not
supported
Check that the correct TV Aspect Ratio is
selected under the Playback sub-menu in the
Setup menu. See “Playback” on page 36.
Check that Progressive/Interlace and Video
Output Format are set correctly in the Setup
menu under the General sub-menu. See
“General” on page 35.
Make sure the audio signal cables are firmly
connected.
Make sure the audio cables are connected to the
same input as the video.
Select the correct audio output format in the
Setup menu.
on the remote.
re-insert as necessary.
Ensure the disc has a format compatible with
the recorder (see “Specifications” on page 43).
finalized before using it with other players (see
“Finalizing the Disc (DVD+R Only)” on page 20).
If you are using a DVD+RW disc, ensure you have
made it compatible (see “Making the Disc
Compatible with Other DVD Players (DVD+RW
Only)” on page 20).
Not all players support DVD+R/RW discs. Ensure
your player supports these formats.
Note: Further troubleshooting information may be found on the Protron website at
www.protronusa.com.
Support Information
Do not return this product to your retailer until you have performed the steps laid out in
“Unpacking Your New DVD Recorder” on page 2 and contacted the customer service
center. Merchandise may not be returned to Protron without a return form authorization.
Before contacting Protron customer service, please record the following information, which may
be found on the bottom of your DVD recorder:
• Model Number
• Serial Number
The Protron customer service center may be contacted 24 hours a day, 7 days a week at the
following number:
1-888-257-8899
42
Page 49
OMPDDVR100.book Page 43 Monday, September 19, 2005 8:35 AM
Specifications
General
Dimensions 17"W × 3"H × 13"D
Weight 8.8lbs
Playback Formats DVD, DVD-R/RW, DVD+R/RW, CD-ROM, CD-R/RW, CD-DA, VCD, SVCD, MP3 CD
Record Formats DVD+R/RW
Inputs 1 × television (F)
Outputs 1 × television pass thru (F)
Power Input 100–120VAC, 50–60Hz
Power Consumption Playback: 29W
Storage Temperature –15 to 55°C
Operating Temperature 5 to 40°C
1 × 4-pin IEEE 1394
3 × composite video (RCA)
3 × S-Video
3 × stereo audio (RCA)
1 × component video (RCA)
1 × S-Video
1 × composite video (RCA)
1 × 5.1 channel audio (RCA)
1 × coaxial digital (RCA)
1 × optical digital (TOSLINK™)
Standby: <3W (Green)
Television Tuner
Tune r Ty p e NTSC-M, CATV, 125 channels
Frequency Range 54.25–802.25MHz
Input Sensitivity 48dBuV
Video
D/A Sample Rate 54MHz
D/A Resolution 10 bits
A/D Sample Rate 5MHz
A/D Resolution 10 bits
Dynamic Range >100dB @ 1kHz
THD+N <–90dB @ 1kHz
Crosstalk <–110dB @ 1kHz
Audio
D/A Max. Sample Rate Channels 1–2 (FL/FR): 200kHz
Channels 3–6: 100kHz
D/A Resolution 24 bits
A/D Max. Sample Rate 96kHz
A/D Resolution 24 bits
Frequency Response +0.5/–1.0dB, 4Hz–44kHz
Dynamic Range >80dB @ 1kHz
THD <–65dB @ 1kHz
Channel Separation >80dB @ 1kHz
43
Page 50
OMPDDVR100.book Page 44 Monday, September 19, 2005 8:35 AM
Limited Warranty
Protron warrants this product to be free from manufacturing defects in material and
workmanship under normal use for the period listed at the bottom of this document.
How to obtain service:
• Call the Protron Customer Support line at 1-888-257-8899. If the issue cannot be resolved
over the phone, a service tag number will be issued and the product must be returned to
Protron, at your expense, for assessment and repair/replacement. To request warranty
repair, you may also contact us by email at service@protronusa.com. For all other customer
service related inquiries, please email us at customerservice@protronusa.com.
• Proof of purchase in the form of a bill of sale or receipted invoice with product name,
model and serial #, which provides evidence that the product is within the warranty period,
must accompany the product to obtain warranty service.
This warranty does not cover:
• Physical or cosmetic damages.
• Damage caused by abuse and/ or neglect.
• Ordinary adjustments as outlined in the owners manual that can be performed by the
customer.
• Damage to equipment not properly connected to the product.
• Any cost incurred in shipping the product for repair.
• Signal reception problems caused by external antenna, cable systems or interference.
• Incompatibility due to a change in TV/CATV broadcast systems after the product was sold.
• Batteries.
• Images burnt onto the screen.
• Initial installation and related adjustments.
• Power surge and/or damage by lightning.
• Force majeure or uncontrollable external force damage.
• Product shipped for service with inadequate packaging or packaging materials
What we will do:
• Protron will assess the product and cover all labor charges to repair your product.
• Protron will provide new, or at our discretion, refurbished replacement parts required to
repair your product.
This warranty is void if:
• Product is used in a commercial application or rental.
• Damaged through misuse, negligence or abuse.
• Modified or repaired by anyone other than an authorized PROTRON service center.
• Damaged because it is improperly connected to any other equipment.
• The original proof of purchase cannot be supplied.
44
Page 51
OMPDDVR100.book Page 45 Monday, September 19, 2005 8:35 AM
• The identifiable markings on the product such as Serial # are defaced, unrecognizable, or
missing.
• The product is used outside the country in which it was originally sold.
This warranty is non-transferable and only applies to the original purchase. Any implied
warranties, including the warranty of merchantability, are limited in duration to the period of
this expressed warranty and no warranty whether expressed or implied shall apply to the
product thereafter. Under no circumstance shall PROTRON be liable for any loss or consequential
damage arising out of the use of this product. This warranty gives specific legal rights. However,
you may have other rights that may vary from state/province to state/province. Some states/
provinces do not allow limitations on implied warranties or exclusions of consequential damage.
Therefore these restrictions may not apply to you.
90 days Labor and Parts
Limited Warranty
45
Page 52
OMPDDVR100.book Page 46 Monday, September 19, 2005 8:35 AM
Protron Digital Corporation
http://www.protronusa.com/
PD-DVR100
OMPDDVR100
Loading...
