Protech Systems PROX-1750, Prox-1750G1, Prox-1750G2 User Manual

USER’S

MANUAL

ProX-1750

Pentium® 4/Pentium® 4-M
Motherboard
With VGA / Sound/ 2LAN

Prox-1750 M5

Copyright Notice

Prox-1750G1/G2 Pentium® 4/

Pentium®4-M

Main Board

With VGA / SOUND / Dual LAN

OPERATION MANUAL

COPYRIGHT NOTICE

This operation manual is meant to assist both Embedded Computer
manufacturers and end users in installing and setting up the system. The
information contained in this document is subject to change without any
prior notice.

This manual is copyrighted February 2003. You may not reproduce or
transmit in any form or by any means, electronic, or mechanical, including
photocopying and recording.

ACKNOWLEDGEMENTS

All trademarks and registered trademarks mentioned herein are the property
of their respective owners.

CE NOTICE

This is a class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.

Copyright Notice

FCC NOTICE

This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.

You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void your
authority to operate such equipment.

Contents

TABLE OF CONTENTS

CHAPTER 1 INTRODUCTION

1-1 About This Manual ....................................................... 1-2

1-2 System Specifications ................................................... 1-3

1-3 Safety Precautions ......................................................... 1-6

CHAPTER 2 HARDWARE CONFIGURATION

2-1 Jumper & Connector Quick Reference Table ............... 2-2

2-2 Component Locations ................................................... 2-3

2-3 How to Set the Jumpers ................................................ 2-5

2-4 COM Port Connector ………………………………… 2-6

2-5 RS232/422/485 (COM2) Selection ............................... 2-8

2-6 JCOM1 & COM2 (JCOM2) RI & Voltage Selection ... 2-9
2-7 COM3 & COM4 RI & Voltage Selection ……………. 2-11
2-8 Keyboard & PS/2 Mouse Connector …………………. 2-13
2-9 Reset Connector ……………...………………………. 2-13
2-10 External Speaker Connector ……………..…………… 2-14

2-11 Hard Disk Drive LED Connector .........................…..... 2-14

2-12 Power LED Connector ……………………………….. 2-14
2-13 EXTSIM# Connector.. ……………………………….. 2-15
2-14 ATX Power Button …………………………………… 2-15

2-15 Keylock Connector …………………………………… 2-15

2-16 IrDA Connector …………...………………………….. 2-16

2-17 Printer Connector ...…................................................... 2-16

2-18 ATX Power Connector ………….................................. 2-17

2-19 Clear CMOS Data Selection .......................................... 2-18

2-20 VGA Connector …………………...........................…. 2-19

2-21 USB & LAN Connector …....................................…… 2-20

2-22 USB Power Setting …………………………………… 2-22

2-23 LAN2 Enable/Disable Connector ................................. 2-23

2-24 Wake-on-modem Connector ….....................……........ 2-24

2-25 CPU Fan Connector …………..…................................ 2-24

2-26 System Fan Connector …….......................................... 2-24

2-27 Reset/NMI/Clear Watchdog Selection .......................... 2-25

2-28 Hard Disk Drive Connector …….................................. 2-26

2-29 Floppy Disk Drive Connector …................................... 2-27

2-30 Sound Connector ...............……………........................ 2-29

Contents

2-31 CD Audio-In Connector ……………............................ 2-30

2-32 Memory Installation ………………………………….. 2-31

2-33 PPCI Connector ...................……………...................... 2-32

2-34 P4/P4-M CPU Selection ……………………………… 2-33
2-35 EPPCI IRQ Selection ………………………………… 2-34

CHAPTER 3 SOFTWARE UTILITIES

3-1 Introduction ................................................................... 3-2

3-2 VGA Driver Utility ....................................................... 3-2

3-3 Flash BIOS Update ....................................................... 3-3

3-4 LAN Driver Utility ….................................................... 3-5

3-5 Sound Driver Utility ………………………………….. 3-7

3-6 Watchdog Timer Configuration .................................... 3-8

CHAPTER 4 AWARD BIOS SETUP

4-1 Introduction ................................................................... 4-2

4-2 Entering Setup ............................................................... 4-3

4-3 The Standard CMOS Features …….............................. 4-4

4-4 The Advanced BIOS Features …................................... 4-8

4-5 Advanced Chipset Feature ............................................ 4-11

4-6 Integrated Peripherals ……........................................... 4-14

4-7 Power Management Setup ............................................ 4-18

4-8 PNP/PCI Configuration …............................................. 4-20

4-9 PC Health Status ……................................................... 4-22

4-10 Frequency / Voltage Control …..................................... 4-23

4-11 Load Fail-Safe Defaults ................................................ 4-24

4-12 Load Optimized Defaults …..………………………… 4-24
4-13 Password Setting ……………………………………... 4-25

4-14 Save & Exit Setup ......................................................... 4-26

4-15 Exit Without Saving ...................................................... 4-27

APPENDIX A EXPANSION BUS

ISA Bus Pin Assignment .......................................................... A-2

PCI Bus Pin Assignment …………………………………….. A-3

Contents

APPENDIX B TECHNICAL SUMMARY

Block Diagram ......................................................................... B-2

Interrupt Map ............................................................................ B-3

RTC (Standard) RAM Bank ..................................................... B-4

Timer & DMA Channels Map .................................................. B-5

I/O & Memory Map ................................................................. B-6

APPENDIX C TROUBLE SHOOTING

Trouble Shooting for Error Messages ...................................... C-2

Trouble Shooting for POST Codes .......................................... C-8

Page:1-1

INTRODUCTION

This chapter gives you the information for Prox-1750G1/G2. It also
outlines the System specifications.

Section includes:

z About This Manual

z System Specifications

z Safety Precautions

Experienced users can skip to chapter 2 on page 2-1
for a Quick Start.

CHAPTER

1

Chapter 1 Introduction

Page: 1-2

Prox-1750G1/G2 USER

′

S MANUAL

1-1. ABOUT THIS MANUAL

Thank you for purchasing our Prox-1750G1/G2 Socket 478 Mainboard

enhanced with VGA/Sound/Dual LAN, which is fully PC / AT compatible.
The Prox-1750G1/G2 provides faster processing speed; greater
expandability and can handle more tasks than before. This manual is
designed to assist you how to install and set up the system. It contains four
chapters. The user can apply this manual for configuration according to the
following chapters:

Chapter 1 Introduction

This chapter introduces you to the background of this manual, and the
specifications for this system. The final page of this chapter will indicate
how to avoid damaging this board.

Chapter 2 Hardware Configuration

This chapter outlines the component locations and their functions. In the
end of this chapter, you will learn how to set jumper and how to con figure
this card to meet your own needs.

Chapter 3 Software Utilities

This chapter contains helpful information for proper installations of the
VGA utility, LAN utility, Sound utility, and Flash BIOS Update. It also
describes the Watchdog-timer configuration.

Chapter 4 Award BIOS Setup

This chapter indicates you how to set up the BIOS configurations.

Appendix A Expansion Bus

This Appendix introduces you the expansion bus for ISA BUS and PCI
BUS.

Appendix B Technical Summary

This section gives you the information about the Technical maps.

Appendix C Trouble Shooting

This section outlines the error messages and offers you the methods to
solve the problems.

Chapter 1 Introduction

Prox-1750G1/G2 USER′S MANUAL

Page: 1-3

1-2. SYSTEM SPECIFICATIONS

z CPU (mPGA478):

Prox-1750G1: Intel® Pentium® 4 processor in mPGA478 Socket.
Prox-1750G2: Intel® Pentium® 4 processor -M in mPGA478 Socket.

1.5~3.06 GHz clock generator.
Front Side Bus 533/400 MHZ.
Auto detect voltage regulator.
Intel 845G B version support H-T Tech.

z MEMORY :

Supports up to 2GB DDR SDRAM.
Two 184-pin DDR DIMM sockets on board.

z CACHE :

Built-in CPU.

z REAL-TIME CLOCK :

256-byte battery backed CMOS RAM.
Hardware implementation to indicate century rollover.

z BIOS :

Phoenix-AwardBIOS™ for plug & play function

.

Easy update 512KB flash EEPROM.
Support S/IO Setup.

z KEYBOARD CONNECTOR :

Mini DIN connector.
Supports for AT/PS2 keyboard.

z MOUSE CONNECTOR :

Mini DIN connector.
Supports for PS/2 Mouse.

z BUS SUPPORT :

External 1 ISA, 6 PCI Bus
External 1 EPCI Bus

Chapter 1 Introduction

Page: 1-4

Prox-1750G1/G2 USER

′

S MANUAL

z DISPLAY :

Prox-1750G1 built in Intel® 845GE
Prox-1750G2 built in Intel® 845GV
Onboard 15-pin VGA D-SUB connector, support for resolution on SVGA
Monitor.

z WATCHDOG :

I / O port 0443H to Enable watchdog
I / O port 0441H to Disable watchdog
Selectable for NMI or Reset function by jumper setting
Time-out timing select 16 / 24 / 32 / 40 / 48 / 56 / 64 / 72 / 80 / 88 / 96 / 104 /
112 / 120 sec +/- 25%.

z IDE INTERFACE :

Two IDE ports support up to four IED devices.
Supports Ultra DMA 33/66/100.

z FLOPPY DISK DRIVER INTERFACE :

Support up to two Floppy Disk Drives, 3.5" and 5.25" (360K / 720K / 1.2M /

1.44M / 2.88M).

z USB CONNECTOR :

Three sets of USB connector & USB power (+5.0V/+5.0V Stand By)
selection.
Support up to six USB 2.0 ports.

z LAN ADAPTER :

Dual ports, Intel® 82562ET PHY & Intel® 82551QM or Intel 82540EM
(Giga Lan)
Two RJ-45 Jack onboard
LAN1: 10BaseT/100 BaseTx Ethernet
LAN2: 10/100 (82551QM) or 10/100/1000 (82540EM)
Support wake-on-LAN function.

z SERIAL PORT :

Four high speed 16550 Compatible UARTs with Send / Receive 16 Byte
FIFOs; COM1/3/4:RS-232; COM2:RS-232/422/485
MIDI Compatible
Programmable Baud Rate Generator

Chapter 1 Introduction

Prox-1750G1/G2 USER′S MANUAL

Page: 1-5

z SOUND :

Realtek ALC202A (AC’97 Codec).
Fully Compliant AC’97 Analog I/O Component
16-Bit Stereo Full-Duplex Codec
Four Analog Line-level Stereo Inputs for Connection.
High Quality CD Input with Ground Sense
Stereo Line-Level Output
Interface: Line-In, Line-Out, Microphone, and CD Audio-In.

z HARDWARE MONITORING FUNCTION :

Monitor Voltage, CPU temperature, & Cooling fan.
If CPU Temperature is over setting, the buzzer will send out a warming.

z IRDA PORT :

5-pin Infrared port, support IrDA v1.0 SIR protocol

z PARALLEL PORT :

SPP / ECP / EPP Function.
1 port, bi-directional parallel port.

z GREEN FUNCTION :

Software supported by BIOS setup

z LED INDICATOR :

System power
Hard Disk access
LAN LED indicator

z DMA CONTROLLER :

82C37 x 2

z DMA CHANNELS :

7

z INTERRUPT CONTROLLERS :

82C59 x 2

z INTERRUPT LEVELS :

15

Chapter 1 Introduction

Page: 1-6

Prox-1750G1/G2 USER

′

S MANUAL

z OPERATING TEMPERATURE :

0 to 60°C.

z BOARD DIMENSIONS :

305mm x 244mm, 12” x 9.61”

z BOARD NET WEIGHT :

0.67 Kg.

1-3. SAFETY PRECAUTIONS

Follow the messages below to avoid your systems from damage:

1. Keep your system away from static electricity on all occasions.

2. Prevent electric shock. Don‘t touch any components of this card when the
card is power-on. Always disconnect power when the system is not in use.

3. Disconnect power when you change any hardware devices. For instance,
when you connect a jumper or install any cards, a surge of power may
damage the electronic components or the whole system.

Page 2-1

HARDWARE
CONFIGURATION

** QUICK START **

Helpful information describes the jumper & connector settings, and
component locations.

This section includes:

z Jumper & Connector Quick Reference Table

z Component Locations

z Configuration and Jumper settings

z Connector’s Pin Assignments

CHAPTER

2

Chapter 2 Hardware Configuration

Page: 2-2

Prox-1750 USER'S MANUAL

2-1. JUMPER & CONNECTOR QUICK REFERENCE TABLE

COM Connector ….................................……...........

………………………………..…..

JCOM1, COM2

COM3, COM4

RS232/422/485 (COM2) Selection ......................…. JP3

COM1 & COM2 RI & Voltage Selection …………. JP4
COM3 & COM4 RI & Voltage Selection …………. JP1
Keyboard & PS/2 Mouse Connector ………………. JKBMS1

Reset Connector ...................................................…. JPANEL1

(13, 15)

External Speaker Connector ……….………………. JPANEL1

(1, 3, 5, 7)

Hard Disk Drive LED Connector ........................….. JPANEL1

(9, 11)

Power LED Connector ….................……………….. JPANEL1

(8, 10, 12)

EXTSMI# Connector ….................………………… JPANEL1

(2, 4)

ATX Power Button …………..…………………….. JPANEL1

(14, 16)

KEYLOCK …………………………………………. JPANEL1

(17, 18)

IRDA Connector …………………………………… IRDA1

Printer Connector .................................................…. JPRNT1

ATX Power Connector …………………………….. JATXPWR1, JATXPWR2
Clear CMOS Data Selection ……………………….. JCMOS1

VGA Connector ..........................................………... JVGA1

USB & LAN Connector ...........................…………..

Front USB Connector ...........................….………..

JRJ45USB1, JRJ45USB2

JUSB3, JUSB2 (Optional)
USB Power Setting ………………………………….
…………………………………

JUSBV1, JUSBV2,

JUSBV3
LAN2 Enable/Disable Selection ….………………... JP6
Wake-On-Modem Connector ………………………. WOL1 (JWOL1)

CPU Fan Connector .............................................….. JCFAN1

System Fan Connector ……………………………… JSFAN1, JSFAN2
Reset/NMI/Clear Watchdog Selection ……………….. JP2

Hard Disk Drive Connector .................................….. IDE1, IDE2

Floppy Disk Drive Connector ..............................….. FDD1

Sound Connector ..………………………………….. JAUDIO1
CD Audio-In Connector ….………………………… JCDIN1, JCDIN2

Memory Installation .............................................…..

DDR1, DDR2
PPCI Connector ……………………………………..

PPCI
P4/P4-M CPU Selection …………………………….

JP11
EPPCI IRQ Selection ……………………………….

JP10
Reserved Pin ………………………………………...

JP5,JP7

Chapter 2 Hardware Configuration

Prox-1750 USER'S MANUAL

Page: 2-3

2-2. COMPONENT LOCATIONS

Prox-1750G1 Connector, Jumper and Component locations

Chapter 2 Hardware Configuration

Page: 2-4

Prox-1750 USER'S MANUAL

Prox-1750G2 Connector, Jumper and Component locations

Chapter 2 Hardware Configuration

Prox-1750 USER'S MANUAL

Page: 2-5

2-3. HOW TO SET THE JUMPERS

You can configure your board by setting the jumpers. Jumper is consists of
two or three metal pins with a plastic base mounted on the card, and by
using a small plastic "cap", Also known as the jumper cap (with a metal
contact inside), you are able to connect the pins. So you can set-up your
hardware configuration by "opening" or "closing" pins.

The jumper can be combined into sets that called jumper blocks. When the
jumpers are all in the block, you have to put them together to set up the
hardware configuration. The figure below shows how this looks like.

JUMPERS AND CAPS

If a jumper has three pins (for example, labelled PIN1, PIN2, and PIN3),
You can connect PIN1 & PIN2 to create one setting and shorting. You can
either connect PIN2 & PIN3 to create another setting. The same jumper
diagrams are applied all through this manual. The figure below shows what
the manual diagram looks like and what they represent.

Chapter 2 Hardware Configuration

Page: 2-6

Prox-1750 USER'S MANUAL

JUMPER DIAGRAMS

JUMPER SETTINGS

Chapter 2 Hardware Configuration

Prox-1750 USER'S MANUAL

Page: 2-7

2-4. COM PORT CONNECTOR

Four COM ports are enhanced in this board namely: JCOM1, COM2,
COM3 and COM4. JCOM1, COM3 and COM4 are fixed for RS-232
while COM2 is selectable for RS-232/422/485.

JCOM1 : COM1 Connector, DB9 male connector
The JCOM1 Connector assignments are as follows :

PIN ASSIGNMENT

1 NDCD1
2 RXD1
3 TXD1
4 NDTR1
5 GND
6 NDSR1
7 NRTS1
8 NCTS1
9 NRI1

COM2 : COM2 Connector
The COM2 Connector assignments are as follows :

ASSIGNMENT

PIN

RS-232 RS-422 RS-485

1 NDCD2 TX- TX­2 RXD2 TX+ TX+
3 TXD2 RX+ RX+
4 NDTR2 RX- RX­5 GND GND GND
6 NDSR2 RTS- NC
7 NRTS2 RTS+ NC
8 NCTS2 CTS+ NC
9 NRI2 CTS- NC

10 NC NC NC

JCOM 1

5

10

1
6

COM2

Chapter 2 Hardware Configuration

Page: 2-8

Prox-1750 USER'S MANUAL

COM3 : COM3 Connector
The COM3 Connector assignments are as follows :

PIN ASSIGNMENT

1 NDCD3
2 RXD3
3 TXD3
4 NDTR3
5 GND
6 NDSR3
7 NRTS3
8 NCTS3
9 NRI3

10 NC

COM4 : COM4 Connector
The COM4 Connector assignments are as follows :

PIN ASSIGNMENT

1 NDCD4
2 RXD4
3 TXD4
4 NDTR4
5 GND
6 NDSR4
7 NRTS4
8 NCTS4
9 NRI4

10 NC

COM3

5

10

1

6

5

10

1

6

COM4

Chapter 2 Hardware Configuration

Prox-1750 USER'S MANUAL

Page: 2-9

2-5. RS232/422/485 (COM2) SELECTION

JP3 : RS-232/422/485 Selection
COM1, COM3, & COM4 is fixed for RS-232 function only.
COM2 is selectable for RS-232, 422, 485 function.
The jumper settings are as follows :

COM 2

Function

Jumper Setting

(pin closed)

Jumper

Illustration

RS-232

Open

RS-422

1-2, 5-6, 7-8, 9-10
11-12,13-14,15-16
17-18, 19-20

RS-485

1-3, 4-6, 7-8, 9-10
11-12,13-14,15-16
17-18, 19-20

*** Manufactory default --- RS-232.

Chapter 2 Hardware Configuration

Page: 2-10

Prox-1750 USER'S MANUAL

2-6. JCOM1 & COM2(JCOM2) RI & VOLTAGE SELECTION

JP4: JCOM1 & COM2(JCOM2) RI & Voltage Selection
The selections are as follows:

COM PORT SELECTION

JUMPER

SETTINGS

JUMPER

ILLUSTRATION

RI 7-9

9

10

1

2

JP4

5V 1-3

9

10

1

2

JP4

JCOM1

12V 3-5

9

10

1

2

JP4

*** Manufactory default -- RI.

Chapter 2 Hardware Configuration

Prox-1750 USER'S MANUAL

Page: 2-11

COM PORT SELECTION

JUMPER

SETTINGS

JUMPER

ILLUSTRATION

RI 8-10

9

10

1

2

JP4

5V 2-4

9

10

1

2

JP4

COM2

(JCOM2)

12V 4-6

9

10

1

2

JP4

*** 1. Manufactory default – RI.

2. JCOM2 is shared with COM2.

Chapter 2 Hardware Configuration

Page: 2-12

Prox-1750 USER'S MANUAL

2-7. COM3 & COM4 RI & VOLTAGE SELECTION

JP1: COM3 & COM4 RI & Voltage Selection
The selections are as follows:

COM PORT SELECTION

JUMPER

SETTINGS

JUMPER

ILLUSTRATION

RI 7-9

9

10

1

2

JP1

5V 1-3

9

10

1

2

JP1

COM3

12V 3-5

9

10

1

2

JP1

*** Manufactory default -- RI.

Chapter 2 Hardware Configuration

Prox-1750 USER'S MANUAL

Page: 2-13

COM PORT SELECTION

JUMPER

SETTINGS

JUMPER

ILLUSTRATION

RI 8-10

9

10

1

2

JP1

5V 2-4

9

10

1

2

JP1

COM4

12V 4-6

9

10

1

2

JP1

*** Manufactory default -- RI.

Chapter 2 Hardware Configuration

Page: 2-14

Prox-1750 USER'S MANUAL

2-8. KEYBOARD & PS/2 MOUSE CONNECTOR

JKBMS1 : Keyboard & PS/2 Mouse Connector
The pin assignments are as follows :

PIN ASSIGNMENT

1 L_KDAT
2 NC
3 GND
4 VCC
5 L_KCLK
6 NC
7 L_MDAT
8 NC

9 GND
10 VCC
11 L_MCLK
12 NC

2-9. RESET CONNECTOR

JPANEL1 (13-15) : Reset Connector.
The pin assignments are as follows :

PIN ASSIGNMENT

13 GND
15 RST_BUTT

R
e

s

e

t

1

2

3

4

5

6

JKBMS1

7

8

9

Chapter 2 Hardware Configuration

Prox-1750 USER'S MANUAL

Page: 2-15

2-10. EXTERNAL SPEAKER CONNECTOR

JPANEL1 (1,3,5,7) : External Speaker Connector
The pin assignments are as follows :

PIN ASSIGNMENT

1 SPK3
3 NC
5 NC
7 SPK VCC

2-11. HARD DISK DRIVE LED CONNECTOR

JPANEL1 (9-11) : Hard Disk Drive LED Connector
The pin assignments are as follows :

PIN ASSIGNMENT

9 VCC3_3

11 HD_LED

2-12. POWER LED CONNECTOR

JPANEL1 (8,10,12) : Power LED Connector
The pin assignments are as follows :

PIN ASSIGNMENT

8 LED+
10 LED+
12 LED-

S
p
e
a
k
e
r

H
D
D
_

L

E

D

Chapter 2 Hardware Configuration

Page: 2-16

Prox-1750 USER'S MANUAL

2-13. EXTSMI# CONNECTOR

JPANEL1 (2,4) : EXTSMI# Connector
The pin assignments are as follows :

PIN ASSIGNMENT

2 GPIO7

4 GND

2-14. ATX POWER BUTTON

JPANEL1 (14,16) : ATX Power Button
The pin assignments are as follows :

PIN ASSIGNMENT

14 PW_BN1
16 PW_BN2

2-15. KEYLOCK CONNCETOR

JPANEL1 (19,20,21,22,23,24) : KEYLOCK Connector

The pin assignments are as follows :

PIN ASSIGNMENT

17 KEYLOCK
18 GND

A

T

X

-

B
T

N

KEYLOCK

Chapter 2 Hardware Configuration

Prox-1750 USER'S MANUAL

Page: 2-17

2-16. IRDA CONNECTOR

JPANEL1 (19,20,21,22,23,24) : Infrared Connector.
Share with IRDA1.
The pin assignments are as follows :

PIN ASSIGNMENT

19 GND
20 NC
21 VCC5
22 GND
23 IRTX2
24 IRRX2

2-17. PRINTER CONNECTOR

JPRNT1 : Printer Connector
The pin assignments are as follows :

JPRNT1

PIN ASSIGNMENT PIN ASSIGNMENT

1 STB 14 AFD
2 P0 15 ERR
3 P1 16 INIT
4 P2 17 SLIN
5 P3 18 GND
6 P4 19 GND
7 P5 20 GND
8 P6 21 GND

9 P7 22 GND
10 ACK 23 GND
11 BUSY 24 GND
12 PE 25 GND
13 SLCT

I

R
D
A

Chapter 2 Hardware Configuration

Page: 2-18

Prox-1750 USER'S MANUAL

2-18. ATX POWER CONNECTOR

JATXPWR1 : ATX Power Connector
The pin assignments are as follows :

JATXPWR1

20

10

1

11

PIN ASSIGNMENT

1 +3.3V

2 +3.3V

3 GND

4 +5.0V

5 GND

6 +5.0V

7 GND

8 Power Good

9 +5.0V Standby

10 +12.0V
11 +3.3V
12 -12.0V
13 GND
14 Power On
15 GND
16 GND
17 GND
18 -5.0V
19 +5.0V
20 +5.0V

Chapter 2 Hardware Configuration

Prox-1750 USER'S MANUAL

Page: 2-19

JATXPWR2 : ATX Power Connector
The pin assignments are as follows :

PIN ASSIGNMENT

1 VCC12

2 VCC12

3 GND

4 GND

2-19. CLEAR CMOS DATA SELECTION

JCMOS1 : Clear CMOS Data Selection
The selection are as follows :

FUNCTION JUMPER SETTING

(pin closed)

JUMPER

ILLUSTRATION

Normal 1-2

Clear CMOS 2-3

*** Manufacturing Default is set as Normal.

Note: To clear CMOS data, user must power-off the computer and set the

jumper to “Clear CMOS” as illustrated above. After five to six
seconds, set the jumper back to “Normal” and power-on the
computer.

3

1

JATXPWR2

4

2

Chapter 2 Hardware Configuration

Page: 2-20

Prox-1750 USER'S MANUAL

2-20. VGA CONNECTOR

JVGA1 : VGA Connector
The pin assignments are as follows:

1

5

6

10

11

15

JVGA1

PIN ASSIGNMENT

1 RED
2 GREEN
3 BLUE
4 NC
5 GND
6 GND
7 GND
8 GND

9 VGA_P5V
10 GND
11 NC
12 DDCDA
13 HSYNC
14 VSYNC
15 DDCLK

Chapter 2 Hardware Configuration

Prox-1750 USER'S MANUAL

Page: 2-21

2-21. USB & LAN CONNECTOR

JRJ45USB1: USB & LAN Connector
This connector contains two USB ports and one LAN.
The pin assignments are as follows:

LAN

PIN ASSIGNMENT

1 TX+

2 TX-

3 RX+

4 ISOLATED GND

5 ISOLATED GND

6 RX-

7 ISOLATED GND

8 ISOLATED GND
11 Pull Hi
12 LED - Yellow
13 Pull Hi
14 LED - Green

USB

PIN ASSIGNMENT

A1 +5.0V or +5.0V Standby
A2

USBP0−
A3 USBP0+
A4 GND
B1 +5.0V or +5.0V Standby
B2

USBP1−
B3 USBP1+
B4 GND

JRJ45USB1

Yellow

Green

Chapter 2 Hardware Configuration

Page: 2-22

Prox-1750 USER'S MANUAL

JRJ45USB2: USB & LAN Connector

This connector contains two USB ports and one LAN.
The pin assignments are as follows:

LAN

PIN ASSIGNMENT

INTEL82551QM INTEL 82540

1 TX+ MDIO+
2 TX- MDIO­3 RX+ MDI1+
4 ISOLATED GND MDI1­5 ISOLATED GND MDI2+
6 RX- MDI2­7 ISOLATED GND MDI3+

8 ISOLATED GND MDI3­11 Pull Hi Orange­12 LED – Yellow Yellow­13 Pull Hi Pull Hi
14 LED - Green LED - Green

USB

PIN ASSIGNMENT

A1 +5.0V or +5.0V STAND BY
A2

USBP0−
A3 USBP0+
A4 GND
B1 +5.0V or +5.0V STAND BY
B2

USBP1−
B3 USBP1+
B4 GND

Note: JUSB2 share the JRJ45USB2 for cable with rear USB bracket.

INTEL 82540 Giga Lan Selection
10 MB No Display
100MB Yellow Display
1000MB Orange Display

JRJ45USB2

(For INTEL 82551QM )

Yellow

Green

JRJ45USB2

(For INTEL 82540EM Giga Lan)

Yellow/Orange

Green

JUSB2

A5

B5

A1

B1

Chapter 2 Hardware Configuration

Prox-1750 USER'S MANUAL

Page: 2-23

JUSB3: Front USB Connector
The pin assignments are as follows:

PIN ASSIGNMENT

1 +5.0V or +5.0V STAND BY
2 +5.0V or +5.0V STAND BY
3 USB_D4-­4 USB_D5-­5 USB_D4++
6 USB_D5++
7 GND
8 GND
9 NC

10 NC

2-22. USB POWER SETTING

JUSBV2: JRJ45USB1 POWER SELECTION

PIN ASSIGNMENT

1 +5.0V
2 PIN#A1

PIN#B1

3 +5.0V STAND BY

JUSBV1: JRJ45USB2 POWER SELECTION

PIN ASSIGNMENT

1 +5.0V
2 PIN#A1

PIN#B1

3 +5.0V STAND BY

JUSB3

910

1

2

JUSBV2

1

JUSBV1

1

Chapter 2 Hardware Configuration

Page: 2-24

Prox-1750 USER'S MANUAL

JUSBV3: JRJ45USB2 POWER SELECTION

PIN ASSIGNMENT

1 +5.0V
2 USB_Power
3 +5.0V STAND BY

2-23. LAN2 ENABLE / DISABLE SELECTION

JP6: LAN2 Enable / Disable Selection (for JRJ45USB2)
The selections are as follows:

SELECTION JUMPER SETTINGS

(pins closed)

JUMPER

ILLUSTRATION

Enabled 1-2

Disabled 2-3

*** 1. Manufactory default --- Enabled.

2. LAN1 Enable/Disable Selection (for JRJ45USB1) by BIOS Setting.

JUSBV3

1

Chapter 2 Hardware Configuration

Prox-1750 USER'S MANUAL

Page: 2-25

2-24. WAKE-ON-MODEM CONNECTOR

WOL1 : Wake-On-Modem Connector
The pin assignments are as follows:

PIN ASSIGNMENT

1 5V STANDBY
2 GND
3 ACTIVE SIGNAL

2-25. CPU FAN CONNECTOR

JCFAN1 : CPU Fan connector
The pin assignments are as follows:

PIN ASSIGNMENT

1 GND
2 +12V
3 FAN1

2-26. SYSTEM FAN CONNECTOR

JSFAN1 : System Fan connector
The pin assignments are as follows:

PIN ASSIGNMENT

1 GND
2 +12V
3 FAN0

JSFAN2 : System Fan connector
The pin assignments are as follows:

PIN ASSIGNMENT

1 GND
2 +12V
3 FAN2

WOL1

1

Chapter 2 Hardware Configuration

Page: 2-26

Prox-1750 USER'S MANUAL

2-27. RESET/NMI/CLEAR WATCHDOG SELECTION

JP2 : Reset/NMI/Clear Watchdog Selection
The selections are as follows:

FUNCTION

JUMPER SETTING

(pin closed)

JUMPER

ILLUSTRATION

RESET

1-2

NMI

3-4

CLEAR WATCHDOG

5-6

***Manufacturing Default is set as NMI.

 User may select to use the Reset or NMI watchdog. NMI, also known as Non-

Maskable Interrupt, is used for serious conditions that demand the processor’s
immediate attention; it cannot be ignored by the system unless it is shut off
specifically. To clear NMI command, user should short the “Clear Watchdog”
pin via push button.

Chapter 2 Hardware Configuration

Prox-1750 USER'S MANUAL

Page: 2-27

2-28. HARD DISK DRIVE CONNECTOR

The Prox-1750 possesses two HDD connectors, IDE1 and IDE2.

IDE1: Hard Disk Drive Connector
The pin assignments are as follows:

IDE1

39

40

1

2

PIN ASSIGNMENT PIN ASSIGNMENT

1 IDERST 21 IDEREQ
2 GND 22 GND
3 IDED7 23 IDEIOW
4 IDED8 24 GND
5 IDED6 25 IDEIOR
6 IDED9 26 GND
7 IDED5 27 IDE ORDY
8 IDED10 28 GND

9 IDED4 29 IDEACK
10 IDED11 30 GND
11 IDED3 31 IRQ14
12 IDED12 32 NC
13 IDED2 33 IDEA1
14 IDED13 34 P66 DETECT
15 IDED1 35 IDEA0
16 IDED14 36 IDEA2
17 IDED0 37 IDECS1P
18 IDED15 38 IDECS3P
19 GND 39 IDEACTP
20 NC 40 GND

Chapter 2 Hardware Configuration

Page: 2-28

Prox-1750 USER'S MANUAL

IDE2: Hard Disk Drive Connector
The pin assignments are as follows:

IDE2

39

40

1

2

PIN ASSIGNMENT PIN ASSIGNMENT

1 IDERST 21 IDEREQ

2 GND 22 GND

3 IDED7 23 IDEIOW

4 IDED8 24 GND

5 IDED6 25 IDEIOR

6 IDED9 26 GND

7 IDED5 27 IDE ORDY

8 IDED10 28 GND

9 IDED4 29 IDEACK
10 IDED11 30 GND
11 IDED3 31 IRQ14
12 IDED12 32 NC
13 IDED2 33 IDEA1
14 IDED13 34 S66 DETECT
15 IDED1 35 IDEA0
16 IDED14 36 IDEA2
17 IDED0 37 IDECS1P
18 IDED15 38 IDECS3P
19 GND 39 IDEACTS
20 NC 40 GND

Chapter 2 Hardware Configuration

Prox-1750 USER'S MANUAL

Page: 2-29

2-29. FLOPPY DISK DRIVE CONNECTOR

FDD1 : Floppy Disk Drive Connector
You can use a 34-pin daisy-chain cable to connect two FDD. On one end of
this cable there is a 34-pin flat cable to attach the FDD on the board; the
other side is attaches to two FDD.
The pin assignments are as follows :

FDD1

33

34

1

2

PIN ASSIGNMENT PIN ASSIGNMENT

1 GND 2 DENSEL
3 GND 4 NC
5 NC 6 DENSEL1
7 GND 8 INDEX

9 GND 10 MOTEA
11 GND 12 DRVB
13 GND 14 DRVA
15 GND 16 MOTEB
17 GND 18 DIR
19 GND 20 STEP
21 GND 22 WDATA
23 GND 24 WGATE
25 GND 26 TK00
27 GND 28 WPT
29 GND 30 RDATA
31 GND 32 SIDE1
33 GND 34 DSKCHG

Chapter 2 Hardware Configuration

Page: 2-30

Prox-1750 USER'S MANUAL

2-30. SOUND CONNECTOR

JAUDIO1 : Sound Connector, including Line-In, Line-Out & Mic. Also can
support only MIC connector. The pin assignments are as follows :

Line-In

PIN ASSIGNMENT

32 LINE_L
33 AUD_GND
34 AUD_GND
35 LINE_R

Line-Out

PIN ASSIGNMENT

22 SPK-L
23 NC
24 NC
25 SPK-R

Mic-In

PIN ASSIGNMENT

1 CGND
2 MIC_IN
3 CGND
4 NC
5 +5VAUDIO

Line-In

Line-Out

Mic-In

JAUDIO1

2

3

4

5

22

232425

32

33

34

35

1

Chapter 2 Hardware Configuration

Prox-1750 USER'S MANUAL

Page: 2-31

2-31. CD AUDIO-IN CONNECTOR

JCDIN1 : CD Audio-in Connector
The pin assignments are as follows:

PIN ASSIGNMENT

1 CDL
2 CD_GND
3 CDR
4 CD_GND

JCDIN2 : CD Audio-in Connector
The pin assignments are as follows:

PIN ASSIGNMENT

1 CDL
2 CD_GND
3 CD_GND
4 CDR

JCDIN1

JCDIN2

1

Chapter 2 Hardware Configuration

Page: 2-32

Prox-1750 USER'S MANUAL

2-32. MEMORY INSTALLATION

The Prox-1750 embedded board supports two DDR memory sockets for a
maximum total memory of 2GB in DDR memory type. The memory module
capacities supported are 64MB, 128MB, 256MB, 512MB and 1GB. The
following table lists the supported DDR DIMM configurations. Intel 845G
supports configurations defined in the JEDEC DDR DIMM specification only
(A,B,C). Non-JEDEC standard DIMMs such as double-sided x 16 DDR
SDRAM DIMMs are not supported.

Supported DDR DIMM Configurations.

Density 64Mbit 128Mbit 256Mbit 512Mbit
Device
Width

X8 X16 X8 X16 X8 X16 X8 X16

Single/
Double

SS/DS SS/DS SS/DS SS/DS SS/DS SS/DS SS/DS SS/DS

184-pin
DDR

64/128
MB

32MB/
NA

128/25
6MB

64MB/
NA

256/51
2MB

128M
B/NA

512/10
24M

256M
B/NA

Installing and Removing Memory Modules

To install the DDR modules, locate the memory slot on the embedded board
and perform the following steps:

1. Hold the DDR module so that the key of the DDR module align with

those on the memory slot.

2. Gently push the DDR module in an upright position until the clips of

the slot close to hold the DDR module in place when the DDR module

touches the bottom of the slot.

3. To remove the DDR module, press the clips with both hands.

Chapter 2 Hardware Configuration

Prox-1750 USER'S MANUAL

Page: 2-33

2-33. PPCI CONNECTOR

You will find a PPCI connector in our Prox-1750. This connector is used to

connect our SCSI daughter boards.

The pin assignments are as follows:

PPCI

A

30

B30

A

1

B1

PIN ASSIGNMENT PIN ASSIGNMENT

A1 GND B1 GND
A2 AD0 B2 AD1
A3 AD2 B3 AD3
A4 AD4 B4 AD5
A5 AD6 B5 AD7
A6 AD8 B6 AD9
A7 AD10 B7 AD11
A8 VCC B8 VCC
A9 AD12 B9 AD13
A10 AD14 B10 AD15
A11 AD16 B11 AD17
A12 AD18 B12 AD19
A13 AD20 B13 AD21
A14 AD22 B14 AD23
A15 VCC B15 VCC
A16 AD24 B16 AD25
A17 AD26 B17 AD27
A18 AD28 B18 AD29
A19 AD30 B19 AD31
A20 PIRQ#B B20 PAR
A21 PP CLK B21 IRDY#
A22 ID SEL B22 TRDY#
A23 CBE#0 B23 CBE#1
A24 CBE#2 B24 CBE#3
A25 PGNT#3 B25 PREQ#3
A26 SERR# B26 PERR#
A27 PIRQ#A B27 PCI_RST#
A28 STOP# B28 PLOCK#
A29 DEVSEL# B29 FRAME#
A30 GND B30 GND

0 The PPCI expansion connector of this Card is designed based on PCI Bus Master.

That means when the PPCI expansion connector is used, the 4

th

PCI slot on the

backplane is occupied.

Chapter 2 Hardware Configuration

Page: 2-34

Prox-1750 USER'S MANUAL

2-34. P4/P4-M CPU SELECTION

JP11 : P4/P4-M CPU Selection. This jumper is for Prox-1750G2 only.

The selections are as follows:

FUNCTION

JUMPER SETTING

(pin closed)

JUMPER

ILLUSTRATION

P4-M 1-2

P4 Open

 Please be aware that when using Pentium 4-M CPU, JP11 jumper must

set as closed, otherwise the P4-M CPU will be damaged, vice versa.

Chapter 2 Hardware Configuration

Prox-1750 USER'S MANUAL

Page: 2-35

2-35. EPPCI IRQ SELECTION

JP10 : EPPCI IRQ Selection. This jumper is for Prox-1750G2
only.

The selections are as follows:

FUNCTION

JUMPER SETTING

(pin closed)

JUMPER

ILLUSTRATION

PCI-IRQB 1-2

PCI-SERIRQ 2-3

** Manufacturing default: PCI-IRQB.

Page: 3-1

SOFTWARE
UTILITIES

This chapter comprises the detailed information of VGA driver,
LAN driver, Sound driver, and flash BIOS update. It also describes
on how to install the watchdog timer.

Section includes:

z VGA Driver Utility

z Flash BIOS Update

z LAN Driver Utility

z SOUND Driver Utility

z Watchdog Timer Configuration

CHAPTER

3

Chapter 3 Software Configuration

Page:3-2

Prox-1750G1/G2 USER

′

S MANUAL

3-1. INTRODUCTION

Enclosed with our Prox-1750G1/G2 package, you will find a CD ROM disk
containing all types of drivers we have. As a Prox-1750G1/G2 user, you
will only need the some of files contained in the CD ROM disk, please tak e
note of the following chart :

File name

(Assume that CD ROM drive is D:)

Purpose

D:\VGA\ For VGA driver installation
D:\Flash\Awdflash.exe For BIOS update
D:\LAN\ For LAN Driver installation
D:\Sound\ For Sound driver installation
D:\Utility\Infinst_autol.exe

***Install this software first!

For Intel® Chipset Software
Installation Utility
Software Update 95/98/98SE/2K.

3-2. VGA DRIVER UTILITY

The VGA interface is embedded with our Prox-1750G1/G2 system to support
CRT display, Panel Link and TV-Out Encoder. The following illustration
briefly shows you the content of VGA driver in D:\VGA\:

1. Win 9x program

2. WinNT4.0 program

3. Win 2000 program

Chapter 3 Software Configuration

Prox-1750G1/G2 USER′S MANUAL

Page:3-3

3-2-1. Installation of VGA Driver

(1) Start the computer (Win 9x/NT/2K).
(2) Insert the Utility Disk into the CD ROM drive or drive A/B.
(3) Double-click “D:\VGA\WIN9X\SETUP.EXE

(if D is not your CD ROM drive and substitute D with th e righ t d riv e) in

the text entry area and press OK.

(4) Click “Next” on the Welcome screen.
(5) Read the license agreement and click “Yes” to continue.
(6) The driver files will now be installed. When finished, choose the

“Yes” to reboot option, and click “Finished” to restart your computer.

The driver should now be loaded.

 For more information on VGA driver installation, please refer to the

readme.txt found on the sub-directory of the VGA driver utility.

3-3. FLASH BIOS UPDATE

3-3-1. System BIOS Update:

Users of Prox-1750G1/G2 can use the program “Awdflash.exe” contained
in CD ROM for BIOS update. This is found in D:\flash\Awdflash.exe.

3-3-2. To update BIOS :

(1) Install “Awdflash.exe” from the CD ROM Disk into your system.
(2) Insert the new BIOS file you have obtained from Prox-1750G1/G2

vendor.

(3) Type the pathname to Awdflash.exe and execute the BIOS update with

file b55xxxxx.bin
C:\UTIL\AWDFLASH\AWARDFLASH H50xxxxx.bin

(4) The screen will display the table below:

FLASH MEMORY WRITER v7.xx

( C ) Award Software 2000 All Rights Reserved

For i845-ITE8712-6A69RP69C-0 DATE : 05/06/01

Flash Type - SST 49LF004A /3.3V

File Name to Program : B55xxxxx.bin
Checksum

: XXXXX

Error Message : Do You Want To Save BIOS (Y/N)

Chapter 3 Software Configuration

Page:3-4

Prox-1750G1/G2 USER

′

S MANUAL

If you want to save up the original BIOS, enter “Y ”and press < Enter > .
If you choose “N”, the following table will appear on screen.

FLASH MEMORY WRITER v7.xx

( C ) Award Software 2000 All Rights Reserved

For i845-ITE8712-6A69RP69C-0 DATE : 05/06/01

Flash Type - SSL 49LF004A /3.3V

File Name to Program : H50xxxxx.bin
Checksum

: XXXXX

Error Message : Are You Sure To Program (Y/N)

Select “Y”, and the BIOS will be renewed. When you are refresh ing your
BIOS, do not turn off or reset the system, or you will damage the BIOS.
After you have completed all the programming, you will see the line:
“Reset System or power off to accomplish update process!”. Please turn off
or reset the system. Then the Flash BIOS is fully implemented.

Chapter 3 Software Configuration

Prox-1750G1/G2 USER′S MANUAL

Page:3-5

3-4. LAN DRIVER UTILITY

3-4-1. Introduction

The Prox-1750G1/G2 Mainboard is enhanced with LAN function that
can support various network adapters. The content of the LAN driver
is found as follows :

1. Windows 9x

2. Windows NT

3. Windows 2000

4. Netware

5. DOS

6. OS2

7. Linux

8. Unix

3-4-2. Installation Procedure for Windows 9x

(1) Insert the LAN Driver disk into Drive A or CD ROM drive.
(2) In the “My computer”, select the “Control Panel” icon.
(3) In the “Control Panel” windows, select the “System” icon.
(4) The “System Properties” window will appear, select the “Device

Manager” and look for the “Network Adapter – PCI Fast Ethernet
Adapter”.

(5) Click “Properties” and then “PCI Fast Ethernet Adapter Properties”,

choose the “Driver” icon.

(6) Click “Update Driver” icon, and follow the remaining instruction.

Chapter 3 Software Configuration

Page:3-6

Prox-1750G1/G2 USER

′

S MANUAL

3-4-3. Installation Procedure for Windows NT

1. In the Main group to NT, select the “Control Panel” icon.

2. In the Control Panel window, choose the “Network” icon.

3. In the Network Settings dialog box, choose the “Add adapter” button.

The Add Network Adapter dialog box appears.

4. In the list of network cards, select “<Other> requires disk from

manufacturer”, and then press <Enter> button.

5. Insert the LAN Driver disk in Drive A or CDROM drive, and type

D:\LAN, and then choose OK button.

6. Follow the remaining instruction, and re-boot your system to complete

the installation process.

Chapter 3 Software Configuration

Prox-1750G1/G2 USER′S MANUAL

Page:3-7

3-5. SOUND DRIVER UTILITY

3-5-1. Introduction

The ALC201A sound function enhanced in this system is fully
compatible with Windows 98, Windows NT 4.0, Windows 2000 and
Windows XP. Below, you will find the content of the Sound driver :

1. Win 98 program

2. Win NT 4.0 program

3. Win 2000 program

4. Win XP Program

3-5-2. Installation Procedure for Windows 9x/NT/2000

(1) From the task bar, click on Start, and then Run.
(2) In the Run dialog box, type D:\Sound\path\setup, where

“D:\Sound\path” refers to the full path to the source files.

(3) Click on the OK button or press the ENTER key.
(4) Click on the “Next” and OK prompts as they appear.
(5) Reboot the system to complete the driver installation.

Chapter 3 Software Configuration

Page:3-8

Prox-1750G1/G2 USER

′

S MANUAL

3-6. WATCHDOG TIMER CONFIGURATION

This board has watchdog timer function for monitoring whether the system
is still work or not after a period of time. The user can select watchdog
timer to system reset or NMI (Non Maskable interrupt) depending on the
jumper set in “Reset/NMI/Clear Watchdog Selection” as described in
chapter 2. This is defined at I/O port 443H. When you want to enable the
watchdog timer, please write I/O port 443H, then the system will either
reset itself or perform the NMI function. Likewise, when you want to
disable the function, write I/O port 441H, the system will run the command
to stop the Watchdog function.

In Prox-1750G1/G2 watchdog function, You must write your program so
when it writes I/O port address 443 for enable watchdog and write I/O port
address 441 for disable watchdog. The timer's intervals have a tolerance of
25% so you should program an instruction that will refresh the timer about
every second.

The following program shows you how to program the watch timer in your
program.

Watchdog enable program:

MOV AX, 000FH (choose the values you need; start from 0)
MOV DX, 0443H
OUT DX, AX

Watchdog disable program:

MOV AX, 000FH (this value can be ignored)
MOV DX, 0441H
OUT DX, AX
The Watchdog Timer control table is as follows:

Level Value Time/sec Level Value Time/sec

1 F 0 9 7 64
2 E 8 10 6 72
3 D 16 11 5 80
4 C 24 12 4 88
5 B 32 13 3 96
6 A 40 14 2 104
7 9 48 15 1 112
8 8 56 16 0 120

Page: 4-1

AWARD
BIOS SETUP

This chapter shows how to set up the Award BIOS.
Section includes:

z Introduction
z Entering Setup
z The Standard CMOS Features
z The Advanced BIOS Features
z The Advanced Chipset Features
z Integrated Peripherals
z Power Management Setup
z PnP/PCI Configurations
z PC Health Status
z Frequency/Voltage Control
z Load Fail-Safe Defaults
z Password Setting
z Save and Exit Setup
z Exit Without Saving

CHAPTER

4

Chapter 4 Award BIOS Setup

Page: 4-2

Prox-1750G1/G2 USER

′

S MANUAL

4-1. INTRODUCTION

This chapter will show you the function of the BIOS in managing the featur es
of your system. The Prox-1750G1/G2 Socket 370 Mainboard is equipped with
the BIOS for system chipset from Award Software Inc. This page briefly
explains the function of the BIOS in managing the special features of your
system. The following pages describe how to use the BIOS for system chipset
Setup menu.

Your application programs (such as word processing, spreadsheets, and games)
rely on an operating system such as DOS or OS/2 to manage such things as
keyboard, monitor, disk drives, and memory.

The operating system relies on the BIOS (Basic Input and Output system), a
program stored on a ROM (Read-only Memory) chip, to initialize and
configure your computer's hardware. As the interface between the hardware
and the operating system, the BIOS enables you to make basic changes to
your system's hardware without having to write a new operating system.

The following diagram illustrates the interlocking relationships between the
system hardware, BIOS, operating system, and application program:

Chapter 4 Award BIOS Setup

Prox-1750G1/G2 USER′S MANUAL

Page: 4-3

4-2. ENTERING SETUP

When the system is powered on, the BIOS will enter the Power-On Self
Test (POST) routines and the following message will appear on the lower
screen:

PRESS <DEL> TO ENTER SETUP, ESC TO SKIP MEMORY TEST

As long as this message is present on the screen you may press the <Del>

key (the one that shares the decimal point at the bottom of the number
keypad) to access the Setup program. In a moment, the main menu of the
Award Setup Program will appear on the screen:

Phoenix - AwardBIOS CMOS Setup Utility

▶Standard CMOS Features

▶Advanced BIOS Features

▶Advanced Chipset Features

▶Integrated Peripherals

▶Power Management Setup

▶PnP/PCI Configurations

▶PC Health Status

▶Frequency/Voltage Control

Load Fail-Safe Defaults

Load Optimized Defaults

Set Supervisor Password

Set User Password

Save & Exit Setup

Exit Without Saving

Esc : Quit ↑↓→← : Select Item
F10 : Save & Exit Setup

Time, Date, Hard Disk Type . . .

Setup program initial screen

You may use the cursor the up/down keys to highlight the individual menu
items. As you highlight each item, a brief description of the highlighted
selection will appear at the bottom of the screen.

Chapter 4 Award BIOS Setup

Page: 4-4

Prox-1750G1/G2 USER

′

S MANUAL

4-3. THE STANDARD CMOS FEATURES

Highlight the〝STANDARD CMOS FEATURES〞and press the <ENTER>
key and the screen will display the following table:

Phoenix - AwardBIOS CMOS Setup Utility

Standard CMOS Features

Date (mm:dd:yy)
Time (hh:mm:ss)

Wed, Aug 7 2002
10 : 50 : 17

Item Help

▶ IDE Primary Master
▶ IDE Primary Slave
▶ IDE Secondary Master
▶ IDE Secondary Slave

Drive A
Drive B

Video
Halt On

Base Memory
Extended Memory
Total Memory

[None]
[IBM-DHEA-36481]
[None]
[CD-540E]

[1.44M, 3.5 in.]
[None]

[EGA/VGA]
[All, But Keyboard]

640K
129024K
130048K

Menu Level ▶

Change the day, month,
year and century

↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help

F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults

Standard CMOS Setup Screen

In the above Setup Menu, use the arrow keys to highlight the item and then use
the <PgUp> or <PgDn> keys to select the value you want in each item. Note
that as you highlight each item, the description of the selected item is found on
the right side of the screen.

Date:

< Month >, < Date > and <Year >. Ranges for each value are in the CMOS
Setup Screen, and the week-day will skip automatically.

Time:

< Hour >, < Minute >, and < Second >. Use 24 hour clock format, i.e., for PM
numbers, add 12 to the hour. For example: 4: 30 P.M. You should enter the
time as 16:30:00.

Chapter 4 Award BIOS Setup

Prox-1750G1/G2 USER′S MANUAL

Page: 4-5

IDE Primary Master / Slave:
IDE Secondary Master / Slave:

The options for these items are found in its sub menu. By pressing the
<ENTER> key, you are prompt to enter the sub menu of the detailed options
as shown below:

Phoenix - AwardBIOS CMOS Setup Utility

IDE Primary Master

IDE HDD Auto-Detection

[Press Enter]

Item Help

IDE Primary Master
Access Mode

Capacity

Cylinder
Head
Precomp
Landing Zone
Sector

[Auto]
[Auto]

37511 MB

17956
16
65535
17955
255

Menu Level ▶▶

To auto-detect the
HDD’s size, head…on
this channel

↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help

F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults

Table 1 – IDE Primary Master sub menu

Descriptions on each item above are as follows:

1. IDE HDD Auto-detection

Press the enter key to auto-detect the HDD on this channel. If detection
is successful, it fills the remaining fields on this menu.

2. IDE Primary Master

There are three available option on this category, namely: None, Auto,
and Manual. By selecting “Manual”, you can set the remaining fields
on this screen, such as -
a. Cylinder – Set the number of cylinders for this hard disk.
b. Head – Set the number of read/write heads.
c. Precomp - ***Warning! Setting a value of 65535 means no HDD.
d. Landing Zone
e. Sector – Set the number of sector per track

Chapter 4 Award BIOS Setup

Page: 4-6

Prox-1750G1/G2 USER

′

S MANUAL

3. Access Mode

There are four available options for this item, namely: Normal, LBA,
Large and Auto. Choose the access mode for this hard disk.

4. Capacity

Disk Drive capacity (Approximated). Note that this size is usually
slightly greater than the size of a formatted disk given by a disk­checking program.

DRIVE A AND DRIVE B:

Select the type of floppy disk drive installed in your system. The available
options are 360KB 5.25in, 1.2KB 5.25in, 720KB 3.5in, 1.44MB 3.5in,

2.88MB 3.5in and None.

VIDEO:

This category selects the type of video adapter used for the primary system
monitor. Although secondary monitors are supported, you do not have to
select the type in Setup. Available Options are Mono, Color 40,
VGA/EGA, and Color 80.

EGA/VGA Enhanced Graphics Adapter/Video Graphics Array.

For EGA, VGA, SEGA, SVGA or PGA monitor

adapters.
CGA 40 Color Graphics Adapter, power up in 40 column mode.
CGA 80 Color Graphics Adapter, power up in 80 column mode.
MONO Monochrome adapter, includes high resolution

monochrome adapters.

HALT ON:

This category allows user to choose whether the computer will stop if an error
is detected during power up. Available options are “All errors”, “No errors”,
“All, But keyboard”, “All, But Diskette”, and “All But Disk/Key”.

BASE MEMORY:

Displays the amount of conventional memory detected during boot up.

EXTENDED MEMORY:

Displays the amount of extended memory detected during boot up.

TOTAL MEMORY:

Displays the total memory available in the system.

Chapter 4 Award BIOS Setup

Prox-1750G1/G2 USER′S MANUAL

Page: 4-7

HARD DISK ATTRIBUTES:

Type Cylinders Heads V-P comp LZone Sect Capacity

1 306 4 128 305 17 10
2 615 4 300 615 17 20
3 615 6 300 615 17 30
4 940 8 512 940 17 62
5 940 6 512 940 17 46
6 615 4 65535 615 17 20
7 642 8 256 511 17 30
8 733 5 65535 733 17 30

9 900 15 65535 901 17 112
10 820 3 65535 820 17 20
11 855 5 65535 855 17 35
12 855 7 65535 855 17 49
13 306 8 128 319 17 20
14 733 7 65535 733 17 42
15 000 0 0000 000 00 00
16 612 4 0000 663 17 20
17 977 5 300 977 17 40
18 977 7 65535 977 17 56
19 1024 7 512 1023 17 59
20 733 5 300 732 17 30
21 733 7 300 732 17 42
22 733 5 300 733 17 30
23 306 4 0000 336 17 10
24 977 5 65535 976 17 40
25 1024 9 65535 1023 17 76
26 1224 7 65535 1223 17 71
27 1224 11 65535 1223 17 111
28 1224 15 65535 1223 17 152
29 1024 8 65535 1023 17 68
30 1024 11 65535 1023 17 93
31 918 11 65535 1023 17 83
32 925 9 65535 926 17 69
33 1024 10 65535 1023 17 85
34 1024 12 65535 1023 17 102
35 1024 13 65535 1023 17 110
36 1024 14 65535 1023 17 119
37 1024 2 65535 1023 17 17
38 1024 16 65535 1023 17 136
39 918 15 65535 1023 17 114
40 820 6 65535 820 17 40
41 1024 5 65535 1023 17 42
42 1024 5 65535 1023 26 65
43 809 6 65535 852 17 40
44 809 6 65535 852 26 61
45 776 8 65335 775 33 100

47 AUTO

Award Hard Disk Type Table

Chapter 4 Award BIOS Setup

Page: 4-8

Prox-1750G1/G2 USER

′

S MANUAL

4-4. THE ADVANCED BIOS FEATURES

Choose the〝ADVANCED BIOS FEATURES〞in the main menu, the screen
shown as below.

Phoenix - AwardBIOS CMOS Setup Utility

Advanced BIOS Features

Virus Warning

CPU Internal Cache

[Disabled]
[Enabled]

Item Help

External Cache

CPU L2 Cache ECC Checking

Processor Number Feature

Quick Power On Self Test

First Boot Device

Second Boot Device

Third Boot Device

Boot Other Device

Swap Floppy Drive

Boot Up Floppy Seek

Boot Up NumLock Status

Gate A20 Option

Typematic Rate Setting

x Typematic Rate (Chars/Sec)
x Typematic Delay (Msec)

Security Option

OS Select For DRAM > 64MB

HDD S.M.A.R.T. Capability

Report No FDD for WIN 95

Small Logo (EPA) Show

[Enabled]
[Enabled]
[Enabled]
[Enabled]
[Floppy]
[HDD-0]
[LS120]
[Enabled]
[Disabled]
[Enabled]
[On]
[Fast]
[Disabled]
6
250
[Setup]
[Non-OS2]
[Disabled]
[No]
[Disabled]

Menu Level ▶

Allows you to choose
the VIRUS warning
feature for IDE Hard
Disk boot sector
protection. If this
function is enabled and
someone attempt to
write data into this area,
BIOS will show a
warning message on
screen and alarm beep

↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help

F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults

Advanced BIOS Features Setup Screen

The “ADVANCED BIOS FEATURES SETUP” allow you to configure your
system for basic operation. The user can select the system’s default speed,
boot-up sequence, keyboard operation, shadowing and security.

Chapter 4 Award BIOS Setup

Prox-1750G1/G2 USER′S MANUAL

Page: 4-9

A brief introduction of each setting in the BIOS FEATURES SETUP
program is given below.

VIRUS WARNING :

This item allows you to choose the Virus Warning feature for IDE Hard Disk
boot sector protection. When this function is enabled, the BIOS will
supervise the boot sector and partition table of the hard disk drive for any
attempt for modification.

CPU INTERNAL CACHE/EXTERNAL CACHE :

These two categories speed up memory access. However, it depends on
CPU/chipset design.

CPU L2 CACHE ECC CHECKING :

This item allows you to enable or disable CPU L2 Cache ECC checking.

PROCESSOR NUMBER FEATURE :

This option is for Pentium III processor only. During Enabled, this will check
the CPU Serial number. Disabled this option if you don’t want the system to
know the Serial number.

QUICK POWER ON SELF TEST:

This item allows you to speed up Power On Self Test (POST) after power-up
the computer. When enabled, the BIOS will shorten or sk ip some check items
during POST.

FIRST/SECOND/THIRD/OTHER BOOT DEVICE:

The BIOS load the operating system in a sequence selected by these items.

SWAP FLOOPY DRIVE:

This field is effective only in systems with two floppy drives. Selecting
Enabled assigns physical drive B to logical drive A, and physical drive A to
logical drive B.

BOOT UP FLOPPY SEEK:

You may enable / disable this item to define whether the system will look for
a floppy disk drive to boot at power-on, or proceed directly to the hard disk
drive.

Chapter 4 Award BIOS Setup

Page: 4-10

Prox-1750G1/G2 USER

′

S MANUAL

BOOT UP NUMLOCK STATUS:

Select power on state for NumLock.

GATE 20A OPTION:

This entry allows you to select how the gate A20 is handled . When Normal
was set, a pin in the keyboard controller controls Gate A20. And when Fast
was set, the chipset controls Gate A20.

TYPEMATIC RATE SETTING:

Enable this item if you wish to be able to configure the characteristics of
your keyboard. Typematic refers to the way in which characters are entered
repeatedly if a key is held down. For example, if you press and hold down
the "A" key, the letter "a" will repeatedly appear on your screen on your
screen until you release the key. When enabled, the typematic rate and
typematic delay can be selected.

TYPEMATIC RATE (CHARS/SEC):

This item sets the number of times a second to repeat a key stroke when you
hold the key down. The choices are 6, 8, 10, 12, 15, 20, 24, and 30.

TYPEMATIC DELAY (MSEC):

The item sets the delay time after the key is held down before it begins to
repeat the keystroke. The choices are 250, 500, 750, and 1000.

SECURITY OPTION:

This category allows you to limit access to the system and Setup, or just to
Setup.

System The system will not boot and access to Setup will be

denied if the correct password is not entered at the
prompt.

Setup The system will boot, but access to Setup will be

denied if the correct password is not entered at the
prompt.

 To disable security, select PASSWORD SETTING at Main Menu and

then you will be asked to enter password. Do not type anything and just
press <Enter>, it will disable security. Once the security is disabled, the
system will boot and you can enter Setup freely.

Chapter 4 Award BIOS Setup

Prox-1750G1/G2 USER′S MANUAL

Page: 4-11

OS SELECT FOR DRAM >64MB :

Select the operating system that is running with greater than 64MB or RAM
on the system. You may choose OS2 or Non-OS2.

REPORT NO FDD FOR WIN 95 :

Select Yes to release IRQ6 when the system contains no floppy drive, for
compatibility with Windows 95 logo certification. In the Integrated
Peripherals screen, select Disabled for the Onboard FDC Controller field.

4-5. ADVANCED CHIPSET FEATURES

Choose the〝ADVANCED CHIPSET FEATURES〞from the main menu,

the screen shown as below.

Phoenix - AwardBIOS CMOS Setup Utility

Advanced Chipset Features

DRAM Timing Selectable
CAS Latency Time

Active to Precharge Delay

[By SPD]
[2.5]

[6]

Item Help

DRAM RAS-to-CAS Delay
DRAM RAS Precharge
Turbo Mode
Memory Frequency For
System BIOS Cacheable
Video BIOS Cacheable
Memory Hole At 15M-16M
Delayed Transaction
AGP Aperture Size

** On-Chip VGA Setting **
On-Chip VGA
On-Chip Frame Buffer Size
I/O Channel Check NMI

[3]
[3]
[Disabled]
[Auto]
[Enabled]
[Disabled]
[Disabled]
[Enabled]
[64MB]

[Enabled]
[8MB]
[Disabled]

Menu Level ▶

↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help

F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults

Advanced Chipset Features Setup

Chapter 4 Award BIOS Setup

Page: 4-12

Prox-1750G1/G2 USER

′

S MANUAL

The parameters in this setup screen are for system designers, service
personnel, and technically competent users only. Do not reset these values
unless you understand the consequences of your changes.

DRAM TIMEING SELECTABLE:

The value in this field depends on performance parameters of the installed
memory chips (DRAM). Do not change the value from the factory setting
unless you install new memory that has a different performance rating than
the original DRAMs.

CAS LATENCY TIME:

When synchronous DRAM is installed, the number of clock cycles of CAS
latency depends on the DRAM timing.

DRAM RAS-TO-CAS DELAY:

This item let you insert a timing delay between the CAS and RAS strobe
signals, used when DRAM is written to, read from, or refreshed. Fast
gives faster performance; and Slow gives more stable performance. This
field applies only when synchronous DRAM is installed in the system.
The choices are 2 and 3.

DRAM RAS PRECHARGE TIME:

If an insufficient number of cycles is allowed for the RAS to accumulate its
charge before DRAM refresh, the refresh may be incomplete and the DRAM
may fail to retain data. Fast gives faster performance; and Slow gives more
stable performance. This field applies only when synchronous DRAM is
installed in the system. The choices are 2 & 3.

SYSTEM BIOS CACHEABLE:

This item allows you to enable caching of the system BIOS ROM at F0000h­FFFFFh, resulting in better system performance. However, if any program
writes to this memory area, a system error may result.

VIDEO BIOS CACHEABLE:

This item allows you to enable caching of the video BIOS, resulting in better
system performance. However, if any program writes to this memory area,
a system error may result.

Chapter 4 Award BIOS Setup

Prox-1750G1/G2 USER′S MANUAL

Page: 4-13

MEMORY HOLE AT 15M-16M:

You may reserve this area of system memory for ISA adapter ROM. When
this area is reserved, it cannot be cached. The user information of
peripherals that need to use this area of system memory usually discusses
their memory requirements.

DELAY TRANSACTION:

The chipset has an embedded 32-bit posted write buffer to support delay
transactions cycles. Select Enabled to support compliance with PCI
specification version 2.1.

AGP APERTURE SIZE:

The aperture is a portion of the PCI memory address range dedicated for
graphics memory address space. Host cycles that hit the aperture range are
forwarded to the AGP without any translation.

ON-CHIP Frame Buffer SIZE:

Select the on-chip frame buffer size for VGA drive use. The available
choices are 8MB, and Disabled.

IO CHANNEL CHECK NMI:

This field enable or disable IO channel check NMI. Before selecting this
function, the user should check first that NMI function is enabled as
described in chapter 2 (Reset/NMI/Clear Watchdog Selection)

Chapter 4 Award BIOS Setup

Page: 4-14

Prox-1750G1/G2 USER

′

S MANUAL

4-6. INTEGRATED PERIPHERALS

Choose〝INTEGRATED PERIPHERALS〞from the main setup menu, a
display will be shown on screen as below:

Phoenix - AwardBIOS CMOS Setup Utility

Integrated Peripherals

On-Chip Primary PCI IDE

IDE Primary Master PIO

IDE Primary Slave PIO

IDE Primary Master UDMA

IDE Primary Slave UDMA

[Enabled]
[Auto]
[Auto]
[Auto]
[Auto]

Item Help

On-Chip Secondary PCI IDE

IDE Secondary Master PIO

IDE Secondary Slave PIO

IDE Secondary Master UDMA

IDE Secondary Slave UDMA

USB Controller

USB 2.0 Controller

USB Keyboard Support

USB Mouse Support

AC97 Audio

Onboard/CNR LAN selection

Init Display First

BIOS Flash Function

IDE HDD Block Mode

POWER ON Function

x KB Power ON Password
x Hot Key Power ON

Onboard FDC Controller

Onboard Serial Port 1

Onboard Serial Port 2

UART Mode Select

x RxD, TxD Active
x IR Transmission Delay
x UR2 Duplex Mode

x Use IR Pins

Onboard Parallel Port

Parallel Port Mode

x EPP Mode Select

x ECP Mode Use DMA

PWRON After PWR-Fail

Onboard Serial Port 3

Serial Port 3 Use IRQ

Onboard Serial Port 4

Serial Port 4 Use IRQ

[Enabled]
[Auto]
[Auto]
[Auto]
[Auto]
[Enabled]
[Enabled]
[Disabled]
[Disabled]
[Auto]
[Auto]
[Onboard/AGP]
[Enabled]
[Enabled]
[BUTTON ONLY]
[Enter]
[Ctrl-F1]
[Enabled]
[3F8/IRQ4]
[2F8/IRQ3]
[Normal]
[Hi, Lo]
[Enabled]

Half

IR-Rx2Tx2
[378/IRQ7]
[SPP]
EPP1.7

3
[Off]
[3E8]
[IRQ10]
[2E8]
[IRQ11]

Menu Level ▶

↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help

F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults

INTEGRATED PERIPHERALS

Chapter 4 Award BIOS Setup

Prox-1750G1/G2 USER′S MANUAL

Page: 4-15

By moving the cursor to the desired selection and pressing <F1> key, the
all options for the desired selection will be displayed for choice.

ON-CHIP PRIMARY PCI IDE
ON-CHIP SECONDARY PCI IDE:

The Integrated peripheral controller contains an IDE interface with support for
two IDE channels. Select Enabled to activate each channel separately.

IDE PRIMARY MASTER/SLAVE PIO:
IDE SECONDARY MASTER/SLAVE PIO:

The four IDE PIO fields allow you to set a PIO mode (0-4) for each of the
four IDE devices that the onboard IDE interface supports. Modes 0 through
4 provide successively increased performance. In Auto mode, the system
automatically determines the best mode for each device.

IDE PRIMARY MASTER/SLAVE UDMA:
IDE SECONDARY MASTER/SLAVE UDMA:

UDMA (Ultra DMA) is a DMA data transfer protocol, that utilizes ATA
commands and the ATA bus to allow DMA commands to transfer data at a
maximum burst rate of 33 MB/s. The implementation of UDMA is possible
only if your IDE hard drive supports it and the operating environ-ment
includes a DMA driver (Windows 95 OSR2 or a third-party IDE bus master
driver). If you hard drive and your system software both support Ultra
DMA/33, select Auto to enable BIOS support.

USB CONTROLLER:

Select enabled if the system contains a Universal Serial Bus (USB) controller
and you have USB peripherals.

USB KEYBOARD SUPPORT:

Select enabled if the system contains a Universal Serial Bus (USB) controller
and you have a USB Keyboard.

USB MOUSE SUPPORT:

Select enabled if the system contains a Universal Serial Bus (USB) controller
and you have a USB Mouse.

INIT DISPLAY FIRST:

This item allows you to decide to active whether PCI Slot or on-chip VGA
first.

Chapter 4 Award BIOS Setup

Page: 4-16

Prox-1750G1/G2 USER

′

S MANUAL

AC97 AUDIO:

This item allows you to decide to enable or disable the 810 chipset family to
support AC97 Audio.

IDE HDD BLOCK MODE:

Block mode is also called block transfer, multiple commands, or multiple
sector read/write. If your IDE hard drive supports block mode (most new
drives do), select Enabled for automatic detection of the optimal number of
block read/writes per sector the drive can support.

ONBOARD FDC CONTROLLER:

Select Enabled if the system has a floppy disk controller (FDC) installed on
the system board and you wish to use it. If you install and-in FDC or the
system has no floppy drive, select Disabled.

ONBOARD SERIAL PORT 1
ONBOARD SERIAL PORT 2:

Select an address and corresponding interrupt for the first and second serial
ports.

UART MODE SELECT:

Select an operating mode for the second serial port. The choices are IrDA,
Normal and ASK IR.

RxD, TxD ACTIVE:

Consult your IR peripheral documentation to select the correct setting of the
TxD and RxD signals.

UR2 DUPLEX MODE:

This item allows you to select the IR half/full duplex function.

ONBOARD PARALLEL PORT:

This field determine access onboard parallel port controller with which I/O
address.

PARALLEL PORT MODE:

Select an operating mode for the onboard parallel port. The available
choices are SPP, EPP, ECP, or ECP+EPA modes.

Chapter 4 Award BIOS Setup

Prox-1750G1/G2 USER′S MANUAL

Page: 4-17

EPP MODE SELECT:

This item allows you to configure the parallel port for the selected EPP
mode. The Selection of EPP port type is 1.7 or 1.9.

ECP MODE USE DMA:

This item allows you to configure the parallel port DMA chan nel for the
selected ECP mode. This selection is only available when ECP or
ECP+EPP is selected in Parallel Port mode.

PWRON AFTER PWR-FAIL:

This item allows you to select if you want to power on the system after
power failure.

ONBOARD SERIAL PORT 3:
ONBOARD SERIAL PORT 4:

Select a logical COM port name and matching address for the third and
forth serial ports. Select an address and corresponding interrupt for third
and forth serial port.

SERIAL PORT 3 USE IRQ:
SERIAL PORT 4 USE IRQ:

The items set the IRQ address of the serial ports.

Chapter 4 Award BIOS Setup

Page: 4-18

Prox-1750G1/G2 USER

′

S MANUAL

4-7. POWER MANAGEMENT SETUP

Choose〝POWER MANAGEMENT SETUP〞option on the main menu, a
display will be shown on screen as below :

Phoenix - AwardBIOS CMOS Setup Utility

Power Management Setup

ACPI Function
Power Management

[Enabled]
[User Define]

Item Help

MODEM Use IRQ
Suspend Mode
Soft-Off by PWR-BTTN
Wake-Up by PCI card
Wake up On LAN

Resume by Alarm
x Date (of Month) Alarm
x Time (hh:mm:ss) Alarm

** Reload Global Timer Events **

Primary IDE 0

Primary IDE 1

Secondary IDE 0

Secondary IDE 1

FDD, COM, LPT Port

[3]
[Disabled]
[Instant-Off]
[Enabled]
[Enabled]
[Disabled]
[0]
[0 : 0 : 0]

[Disabled]
[Disabled]
[Disabled]
[Disabled]
[Disabled]

Menu Level ▶

↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help

F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults

Power Management Setup Screen

The “Power Management Setup” allows the user to configure the system to
the most effectively save energy while operating in a manner consistent with
your own style of computer use.

ACPI FUNCTION:

Users are allowed to enable or disable the Advanced Configuration and
Power Management (ACPI).

Chapter 4 Award BIOS Setup

Prox-1750G1/G2 USER′S MANUAL

Page: 4-19

POWER MANAGEMENT:

This item allows the user to select the type or degree of power saving and is
directly related to the following modes:
a. HDD Power Down
b. Suspend Mode

MODEM USE IRQ:

This item enable you to name the interrupt request (IRQ) line assigned to
the modem (if any) on your system. Activity of the selected IRQ always
awakens the system.

SUSPEND MODE:

When enabled and after the set time of system inactivity, all devices except
the CPU will be shut off.

SOFT-OFF BY PWR-BTTN:

Pressing the power button for more than 4 seconds forces the system to
enter the Soft-Off state when the system has “hung”. The choices are
Delay 4 Sec and Instant-Off.

WAKE-UP BY PCI CARD:

An input signal on the serial Ring Indicator (RI) line (in other words, an
incoming call on the modem) awakens the system from the soft-off state.

RESUME BY ALARM:

When enabled, you can set the date and time at which the RTC alarm
awakens the system from Suspend mode.

PM EVENTS:

PM Events are I/O events whose occurrence can prevent the system from
entering a power saving mode or can awaken the system from such a mode.
In effect, the system remains alert for anything, which occurs to a device,
which is configured as Enabled, even when the system is in a power down
mode.

nPrimary IDE 0 oPrimary IDE 1
pSecondary IDE 0 qSecondary IDE 1
rFDD, COM, LPT Port sPCI PIRQ[A-D]#

Chapter 4 Award BIOS Setup

Page: 4-20

Prox-1750G1/G2 USER

′

S MANUAL

4-8. PNP/PCI CONFIGURATION

Choose 〝PNP/PCI CONFIGURATION〞 from the main menu, a display
will be shown on screen as below:

Phoenix - AwardBIOS CMOS Setup Utility

PnP/PCI Configurations

PNP OS Installed

Reset Configuration Data

[Yes]
[Disabled]

Item Help

Resources Controlled By

x IRQ Resources
x DMA Resources

PCI/VGA Palette Snoop

[Auto(ESCD)]

Press Enter
Press Enter

[Disabled]

Menu Level ▶

Select Yes if you are
using a Plug and Play
capable operating
system Select No if you
need the BIOS to
configure non-boot
devices

↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help

F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults

PNP/PCI CONFIGURATION

This section describes how to configure PCI bus system. PCI, also known as
Personal Computer Interconnect, is a system which allows I/O devices to
operate at speeds nearing the speed of the CPU itself uses when communi­cating with its own special components. This section covers technical items,
which is strongly recommended for experienced users only.

PNP OS INSTALLED:

This item allows you to determine install PnP OS or not.

Chapter 4 Award BIOS Setup

Prox-1750G1/G2 USER′S MANUAL

Page: 4-21

RESET CONFIGURATION DATA:

Normally, you leave this field Disabled. Select Enabled to reset Extended
System Configuration Data (ESCD) when you exit Setup if you have
installed a new add-on and the system configuration has caused such a
serious conflict that the operating system can not boot.

RESOURCE CONTROLLED BY:

The Award Plug and Play Bios can automatically configure all of the booth
and Plug and Play-compatible devices. However, this capability means
absolutely nothing unless you are using a Plug and Play operating system
such as Windows 95. By choosing “manual”, you are allowed to
configure the IRQ Resources, DMA Resources and Memory Resources.
The choices are Auto(ESCD) and Manual.

IRQ RESOURCES:

You may assign each system interrupt a type, depending on the type of
device using the interrupt.

IRQ3/4/5/7/9/10/11/12/14/15 ASSIGNED TO:

This item allows you to determine the IRQ assigned to ISA bus and is not
available to any PCI slot. Legacy ISA for devices compliant with the origi­nal PC AT bus specification, PCI/ISA PnP for devices compliant with the
Plug and Play standard whether designed for PCI or ISA bus architecture.

DMA RESOURCES:

When resources are controlled manually, assign each system DMA channel
a type, depending on the type of device using the DMA channel.

DMA 0/1/3/5/6/7 ASSIGNED TO:

Legacy ISA for devices compliant with the original PC AT bus specifi­cation, PCI/ISA PnP for devices compliant with the Plug and Play standard
whether designed for PCI or ISA bus architecture.

PCI/VGA PALETTE SNOOP:

Leave this field at disabled.

Chapter 4 Award BIOS Setup

Page: 4-22

Prox-1750G1/G2 USER

′

S MANUAL

4-9. PC HEALTH STATUS

Choose 〝PC HEALTH STATUS〞 from the main menu, a display will
be shown on screen as below:

Phoenix - AwardBIOS CMOS Setup Utility

PC Health Status

CPU Warning Temperature

Current CPU Temperature

Current SYSTEM Fan Speed

Current CPU Fan Speed

Vcore

[50½C/122½F]
[49½C/120½F]

0 RPM

2481 RPM

1.42V

Item Help

3.3 V

+5 V

+12 V

-12 V

-5 V

VBAT (V)

5VSB (V)

Shutdown Temperature

3.34V

5.05V

11.79V

(-) 12.52V

(-) 4.99V

3.18V

4.96V

[60½C/140½F]

Menu Level ▶

↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help

F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults

PC Health Status Setup Screen

CPU WARMING TEMPERATURE:

Select the combination of lower and upper limits for the CPU temperature.
If the CPU temperature extends beyond either limit, any warning
mechanism programmed into your system will be activated.

CURRENT CPU TEMPERATURE:

This field displays the current CPU temperature, if your computer contains
a monitoring system.

Chapter 4 Award BIOS Setup

Prox-1750G1/G2 USER′S MANUAL

Page: 4-23

SHUTDOWN TEMPERATURE:

User is allowed to set the temperature on which the system automatically
shutdown when reaches or exceeds the temperature set.

4-10. FREQUENCY/VOLTAGE CONTROL

Choose 〝FREQUENCY/VOLTAGE CONTROL〞 from the main menu,
a display will be shown on screen as below:

Phoenix - AwardBIOS CMOS Setup Utility

Frequency/Voltage Control

Spread Spectrum

[Disabled]

Item Help

Menu Level ▶

↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help

F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults

Frequency / Voltage Control Setup Screen

This setup menu allows you to specify your settings for frequency/voltage
control.

SPREAD SPECTRUM:

This item allows you to enable or disable the spread spectrum modulate.

Chapter 4 Award BIOS Setup

Page: 4-24

Prox-1750G1/G2 USER

′

S MANUAL

4-11. LOAD FAIL-SAFE DEFAULTS

By pressing the <ENTER> key on this item, you get a confirmation dialog
box with a message similar to the following:

Load Fail-Safe Defaults ( Y/N ) ? N

To use the BIOS default values, change the prompt to "Y" and press the
<Enter > key. CMOS is loaded automatically when you power up the
system.

4-12. LOAD OPTIMIZED DEFAULTS

When you press <Enter> on this category, you get a confirmation dialog
box with a message similar to the following:

Load Optimized Defaults ( Y/N ) ? N

Pressing "Y" loads the default values that are factory setting for optimal
performance system operations.

Chapter 4 Award BIOS Setup

Prox-1750G1/G2 USER′S MANUAL

Page: 4-25

4-13. PASSWORD SETTING

User is allowed to set either supervisor or user password, or both of them.
The difference is that the supervisor password can enter and change the
options of the setup menus while the user password can enter only but do not
have the authority to change the options of the setup menus.

TO SET A PASSWORD

When you select this function, the following message will appear at the
center of the screen to assist you in creating a password.

Enter Password:

Type the password up to eight characters in length, and press < Enter >.
The password typed now will clear any previously entered passwor d from
CMOS memory. You will be asked to confirm the password. Type the
password again and press the < Enter > key. You may also press < Esc >
to abort the selection and not enter a password.

 User should bear in mind that when a password is set, you will be

asked to enter the password everything you enter CMOS setup Menu.

TO DISABLE THE PASSWORD

To disable the password, select this function (do not enter any key when
you are prompt to enter a password), and press the <Enter> key and a
message will appear at the center of the screen:

PASSWORD DISABLED!!!

Press any key to continue...

Press the < Enter > key again and the password will be disabled. Once the
password is disabled, you can enter Setup freely.

Chapter 4 Award BIOS Setup

Page: 4-26

Prox-1750G1/G2 USER

′

S MANUAL

4-14. SAVE & EXIT SETUP

After you have completed adjusting all the settings as required, you must
remember to save these setting into the CMOS RAM. To save the settings,
select “SAVE & EXIT SETUP” and press <Enter>, a display will be shown
as follows:

Phoenix - AwardBIOS CMOS Setup Utility

▶Standard CMOS Features

▶Advanced BIOS Features

▶Advanced Chipset Features

▶Integrated Peripherals

▶Power Management

▶PnP/PCI Configura

▶PC Health Status

▶Frequency/Voltage Control

Load Fail-Safe Defaults

Load Optimized Defaults

Set Supervisor Password

word

etup

Saving

Esc : Quit F9 : Menu in BIOS ↑↓→← : Select Item
F10 : Save & Exit Setup

Save Data to CMOS

When you confirm that you wish to save the settings, your system will be
automatically restarted and the changes you have made will be implemented.
You may always call up the setup program at any time to adjust any of the
individual items by pressing the <Del> key during boot up.

Save to CMOS and EXIT Y/N)? Y

Chapter 4 Award BIOS Setup

Prox-1750G1/G2 USER′S MANUAL

Page: 4-27

4-15. EXIT WITHOUT SAVING

If you wish to cancel any changes you have made, you may select the
“EXIT WITHOUT SAVING” and the original setting stored in the CMOS
will be retained. The screen will be shown as below:

Phoenix - AwardBIOS CMOS Setup Utility

▶Standard CMOS Features

▶Advanced BIOS Features

▶Advanced Chipset Features

▶Integrated Peripherals

▶Power Management

▶PnP/PCI Configura

▶PC Health Status

▶Frequency/Voltage Control

Load Fail-Safe Defaults

Load Optimized Defaults

Set Supervisor Password

word

etup

Saving

Esc : Quit F9 : Menu in BIOS ↑↓→← : Select Item
F10 : Save & Exit Setup

Abandon all Datas

Quit Without Saving (Y/N)? N

Page: A-1

EXPANSION
BUS

This appendix indicates the pin assignments.

Section includes:

z ISA BUS Pin Assignment

z PCI BUS Pin Assignment

APPENDIX

A

Appendix A Expansion Bus

Page: A-2

Prox-1750G1/G2 USER

′

S MANUAL

ISA BUS PIN ASSIGNMENT

The ISA-bus connector is divided into two sets : one consists of 62 pins; the other
consists of 36 pins.

The pin assignments as follows :

B A D C

PIN ASSIGNMENT PIN ASSIGNMENT PIN ASSIGNMENT PIN ASSIGNMENT

B1 GND A1 -I/O CH CHK D1 -MEMCS16 C1 SBHE
B2 RESET A2 SD07 D2 -I/OCS16 C2 LA23
B3 +5V A3 SD06 D3 IRQ10 C3 LA22
B4 IRQ9 A4 SD05 D4 IRQ11 C4 LA21
B5 -5V A5 SD04 D5 IRQ12 C5 LA20
B6 DRQ2 A6 SD03 D6 IRQ15 C6 LA19
B7 -12V A7 SD02 D7 IRQ14 C7 LA18
B8 OWS A8 SD01 D8 -DACK0 C8 LA17
B9 +12V A9 SD00 D9 DRQ0 C9 -MEMR
B10 GND A10 -I/O CH RDY D10 -DACK5 C10 -MEMW
B11 -SMEMW A11 AEN D11 DRQ5 C11 SD08
B12 -SMEMR A12 SA19 D12 -DACK6 C12 SD09
B13 -IOW A13 SA18 D13 DRQ6 C13 SD10
B14 -IOR A14 SA17 D14 -DACK7 C14 SD11
B15 -DACK3 A15 SA16 D15 DRQ7 C15 SD12
B16 -DRQ3 A16 SA15 D16 +5V C16 SD13
B17 -DACK1 A17 SA14 D17 -MASTER C17 SD14
B18 -DRQ1 A18 SA13 D18 GND C18 SD15
B19 -REFRESH A19 SA12
B20 BCLK A20 SA11
B21 IRQ7 A21 SA10
B22 IRQ6 A22 SA09
B23 IRQ5 A23 SA08
B24 IRQ4 A24 SA07
B25 IRQ3 A25 SA06
B26 -DACK2 A26 SA05
B27 T/C A27 SA04
B28 BALE A28 SA03
B29 +5V A29 SA02
B30 OSC A30 SA01
B31 GND A31 SA00

D1

C1 C18

D18

A31

B31

A1

B1

Appendix A Expansion Bus

Prox-1750G1/G2 USER′S MANUAL

Page: A-3

PCI BUS PIN ASSIGNMENT

Like ISA-BUS connector, the PCI-BUS edge connector is also divided into two
sets: one consists of 98-pin; the other consists of 22-pin.
The pin assignments are as follows :

B52

A52

B62

A

62

A49

B49

B1

A1

B A B A

PIN ASSIGNMENT PIN ASSIGNMENT PIN ASSIGNMENT PIN ASSIGNMENT

B1 -12V A1 TRST# B31 +3.3V A31 AD18
B2 TCK A2 +12V B32 AD17 A32 AD16
B3 GND A3 TMS B33 C/BE2# A33 +3.3V
B4 TDO A4 TDI B34 GND A34 FRAME#
B5 +5V A5 +5V B35 IRDY# A35 GND
B6 +5V A6 INTA# B36 +3.3V A36 TRDY#
B7 INTB# A7 INTC# B37 DEVSEL# A37 GND
B8 INTD# A8 +5V B38 GND A38 STOP#
B9 REQ3# A9 CLKC B39 LOCK# A39 +3.3V
B10 REQ1# A10 +5V(I/O) B40 PERR# A40 SDONE
B11 GNT3# A11 CLKD B41 +3.3V A41 SB0#
B12 GND A12 GND B42 SERR# A42 GND
B13 GND A13 GND B43 +3.3V A43 PAR
B14 CLKA A14 GNT1# B44 C/BE1# A44 AD15
B15 GND A15 RST# B45 AD14 A45 +3.3V
B16 CLKB A16 +5V(I/O) B46 GND A46 AD13
B17 GND A17 GNT0# B47 AD12 A47 AD11
B18 REQ0# A18 GND B48 AD10 A48 GND
B19 +5V(I/O) A19 REQ2# B49 GND A49 AD09
B20 AD31 A20 AD30 B52 AD08 A52 C/BE0#
B21 AD29 A21 +3.3V B53 AD07 A53 +3.3V
B22 GND A22 AD28 B54 +3.3V A54 AD06
B23 AD27 A23 AD26 B55 AD05 A55 AD04
B24 AD25 A24 GND B56 AD03 A56 GND
B25 +3.3V A25 AD24 B57 GND A57 AD02
B26 C/BE3# A26 GNT2# B58 AD01 A58 AD00
B27 AD23 A27 +3.3V B59 +5V(I/O) A59 +5V(I/O)
B28 GND A28 AD22 B60 ACK64# A60 REQ64#
B29 AD21 A29 AD20 B61 +5V A61 +5V
B30 AD19 A30 GND B62 +5V A62 +5V

Page: B-1

TECHNICAL
SUMMARY

This section introduce you the maps concisely.

Sections include:

z Block Diagram

z Interrupt Map

z RTC (Standard) RAM Bank

z Timer & DMA Channels Map

z I / O & Memory Map

APPENDIX

B

Appendix B Technical Summary

Page: B-2

Prox-1750G1/G2 USER

′

S MANUAL

BLOCK DIAGRAM

P

r

o

c

e

s

s

o

r

P

4

_

C

P

U

S

o

c

k

e

t

4

7

8

G

M

C

H

B

r

o

o

k

D

A

L

E

-

G

8

4

5

G

/

G

E

I

C

H

4

8

2

8

0

1

D

B

L

P

C

S

I

O

W

8

3

6

2

7

H

F

F

l

o

o

p

y

P

a

r

a

l

l

e

l

S

e

r

i

a

l

1

S

e

r

i

a

l

2

K

e

y

b

o

a

r

d

M

o

u

s

e

L

A

N

1

8

2

5

6

2

E

M

A

u

d

i

o

C

o

d

e

c

A

L

C

2

0

1

A

PCI C ONN1

PCI C ONN2

PCI C ONN3

PCI C ONN4

PCI C ONN5

PCI C ONN6

PPC I C ONN

LAN 2

82551QM/82540EM

P

C

I

/

I

S

A

I

T

8

8

8

8

F

/

B

F

ISA CONN1

C

l

o

c

k

S

y

n

t

h

e

s

i

z

e

r

C

y

8

2

3

2

3

P

C

2

0

0

/

2

6

6

D

D

R

A

M

M

o

d

u

l

e

s

I

S

A

S

U

P

E

R

I

O

W

8

3

8

7

7

T

F

S

e

r

i

a

l

3

S

e

r

i

a

l

4

F

i

r

m

W

a

r

e

H

u

b

4

M

B

F

l

a

s

h

B

I

O

S

U

S

B

1

.

1

/

2

.

0

S

i

x

P

o

r

t

I

D

E

P

r

i

m

a

r

y

I

D

E

S

e

c

o

n

d

a

r

y

V

G

A

D

S

U

B

A

G

P

4

X

O

R

2

M

u

s

e

d

I

n

t

e

l

D

V

O

p

o

r

t

s

V

R

M

9

.

0

H

I

P

6

3

0

2

1

0

0

M

H

z

/

1

3

3

M

H

z

3

5

0

M

p

i

x

e

l

s

/

s

Appendix B Technical Summary

Prox-1750G1/G2 USER′S MANUAL

Page: B-3

INTERRUPT MAP

IRQ ASSIGNMENT

0 System TIMER interrupt from TIMER-0
1 Keyboard output buffer full
2 Cascade for IRQ 8-15
3 Serial port 2
4 Serial port 1
5 Parallel Port 2
6 Floppy Disk adapter
7 Parallel port 1
8 RTC clock

9 Available
10 Serial port 3
11 Serial port 4
12 Available
13 Math coprocessor
14 Hard Disk adapter
15 Available

Appendix B Technical Summary

Page: B-4

Prox-1750G1/G2 USER

′

S MANUAL

RTC (STANDARD) RAM BANK

CODE ASSIGNMENT

00h Seconds
01h Second alarm
02h Minutes
03h Minutes alarm
04h Hours
05h Hours alarm
06h Day of week
07h Day of month
08h Month

09h Year
0Ah Status register A
0Bh Status register B
0Ch Status register C
0Dh Status register D

0Eh-7Fh 114 Bytes of User RAM

Appendix B Technical Summary

Prox-1750G1/G2 USER′S MANUAL

Page: B-5

TIMER & DMA CHANNELS MAP

Timer Channel Map

:

Timer Channel Assignment

0 System timer interrupt
1 DRAM Refresh request
2 Speaker tone generator

DMA Channel Map

:

DMA Channel Assignment

0 Available
1 Available
2 Floppy Disk adapter
3 Available
4 Cascade
5 Available
6 Available
7 Available

Appendix B Technical Summary

Page: B-6

Prox-1750G1/G2 USER

′

S MANUAL

I/O & MEMORY MAP

Fixed I/O Ranges Decoded by ICH2

:

I/O Address Read Target Write Target Internal Unit

00h-08h DMA Controller DMA Controller DMA
09h-0Eh Reserved DMA Controller DMA
0Fh DMA Controller DMA Controller DMA
10h-18h DMA Controller DMA Controller DMA
19h-1Eh Reserved DMA Controller DMA
1Fh DMA Controller DMA Controller DMA
20h-21h Interrupt Controller Interrupt Controller Interrupt
24h-25h Interrupt Controller Interrupt Controller Interrupt
28h-29h Interrupt Controller Interrupt Controller Interrupt
2Ch-2Dh Interrupt Controller Interrupt Controller Interrupt
2Eh-2Fh LPC SIO LPC SIO Forwarder to LPC
30h-31h Interrupt Controller Interrupt Controller Interrupt
34h-35h Interrupt Controller Interrupt Controller Interrupt
38h-39h Interrupt Controller Interrupt Controller Interrupt
3Ch-3Dh Interrupt Controller Interrupt Controller Interrupt
40h-42h Timer/Counter Timer/Counter PIT (8254)
43h Reserved Timer/Counter PIT
4E-4F LPC SIO LPC SIO Forwarder to LPC
50h-52h Timer/Counter Timer/Counter PIT
53h Reserved Timer/Counter PIT
60h Microcontroller Microcontroller Forwarder to LPC
61h NMI Controller NMI Controller Processor I/F
62h Microcontroller Microcontroller Forwarder to LPC
63h NMI Controller NMI Controller Processor I/F
64h Microcontroller Microcontroller Forwarder to LPC
65h NMI Controller NMI Controller Processor I/F
66h Microcontroller Microcontroller Forwarder to LPC
67h NMI Controller NMI Controller Processor I/F
70h Reserved5 NMI & RTC controller RTC
71h RTC Controller RTC Controller RTC
72h RTC Controller NMI & RTC controller RTC
73h RTC Controller RTC Controller RTC
74h RTC Controller NMI & RTC controller RTC
75h RTC Controller RTC Controller RTC
76h RTC Controller NMI & RTC controller RTC
77h RTC Controller RTC Controller RTC

Appendix B Technical Summary

Prox-1750G1/G2 USER′S MANUAL

Page: B-7

I/O Address Read Target Write Target Internal Unit

80h DMA Controller DMA controller &

LPC/PCI

DMA

81h-83h DMA Controller DMA Controller DMA
84h-86h DMA Controller DMA Controller &

LPC or PCI

DMA

87h DMA Controller DMA Controller DMA
88h DMA Controller DMA Controller &

LPC or PCI

DMA

89h-8Bh DMA Controller DMA Controller DMA
8Ch-8Eh DMA Controller DMA Controller &

LPC or PCI

DMA

08Fh DMA Controller DMA Controller DMA
90h-91h DMA Controller DMA Controller DMA
92h Reset Generator Reset Generator Processor I/F
93h-9Fh DMA Controller DMA Controller DMA
A0h-A1h Interrupt Controller Interrupt Controller Interrupt
A4h-A5h Interrupt Controller Interrupt Controller Interrupt
A8h-A9h Interrupt Controller Interrupt Controller Interrupt
ACh-ADh Interrupt Controller Interrupt Controller Interrupt
B0h-B1h Interrupt Controller Interrupt Controller Interrupt
B2h-B3h Power Management Power Management Power Management
B4h-B5h Interrupt Controller Interrupt Controller Interrupt
B8h-B9h Interrupt Controller Interrupt Controller Interrupt
BCh-BDh Interrupt Controller Interrupt Controller Interrupt
C0h-D1h DMA Controller DMA Controller DMA
D2h-DDh Reserved DMA Controller DMA
DEh-DFh DMA Controller DMA Controller DMA
F0h See Note 3 FERR# /IGNNE#/

Interrupt Controller

Processor interface

170h-177h IDE Controller1 IDE Controller1 Forwarded to IDE
1F0h-1F7h IDE Controller2 IDE Controller2 Forwarded to IDE
376h IDE Controller1 IDE Controller1 Forwarded to IDE
3F6h IDE Controller2 IDE Controller2 Forwarded to IDE
4D0h-4D1h Interrupt Controller Interrupt Controller Interrupt
CF9h Reset Generator Reset Generator Processor interface

Notes:

1. Only if IDE Standard I/O space is enabled for Primary Drive. Otherwise, the target is PCI.

2. Only if IDE Standard I/O space is enabled for Secondary Drive. Otherwise, the target is PCI.

3. If POS_DEC_EN bit is enabled, reads from F0h will not be decoded by the ICH2. If
POS_DEC_EN is not enabled, reads from F0h will forward to LPC.

Appendix B Technical Summary

Page: B-8

Prox-1750G1/G2 USER

′

S MANUAL

Memory Decode Ranges From Processor Perspective :

Memory Range Target Dependency/Comments

0000 0000h-000D FFFFh
0010 0000-TOM (Top of
Memory)

Main Memory TOM registers in Host Controller

000E 0000h-000F FFFFh FWH Bit 7 in FWH Decode Enable

Register is set
FEC0 0000h-FEC0 0100h I/O APIC inside ICH2
FFC0 0000h-FFC7 FFFFh
FF80 0000h-FF87 FFFFh

FWH Bit 0 in FWH Decode Enable

Register
FFC8 0000h-FFCF FFFFh
FF88 0000h-FF8F FFFFh

FWH Bit 1 in FWH Decode Enable

Register
FFD0 0000h-FFD7 FFFFh
FF90 0000h-FF97 FFFFh

FWH Bit 2 in FWH Decode Enable

Register is set
FFD8 0000h-FFDF FFFFh
FF98 0000h-FF9F FFFFh

FWH Bit 3 in FWH Decode Enable

Register is set
FFE0 0000h-FFE7 FFFFh
FFA0 0000h-FFA7 FFFFh

FWH Bit 4 in FWH Decode Enable

Register is set
FFE8 0000h-FFEF FFFFh
FFA8 0000h-FFAF FFFFh

FWH Bit 5 in FWH Decode Enable

Register is set
FFF0 0000h-FFF7 FFFFh
FFB0 0000h-FFB7 FFFFh

FWH Bit 6 in FWH Decode Enable

Register is set
FFF8 0000h-FFFF FFFFh
FFB8 0000h-FFBF FFFFh

FWH Always Enabled.

The top two 64K blocks of this

range can be swapped as

described in Section 6.4.1.
FF70 0000h-FF7F FFFFh
FF30 0000h-FF3F FFFFh

FWH Bit 3 in FWH Decode Enable 2

Register is set
FF60 0000h-FF6F FFFFh
FF20 0000h-FF2F FFFFh

FWH Bit 2 in FWH Decode Enable 2

Register is set
FF50 0000h-FF5F FFFFh
FF10 0000h-FF1F FFFFh

FWH Bit 1 in FWH Decode Enable 2

Register is set
FF40 0000h-FF4F FFFFh
FF00 0000h-FF0F FFFFh

FWH Bit 0 in FWH Decode Enable 2

Register is set
Anywhere in 4GB range D110 LAN Controller Enable via BAR in Device

29:Function 0 (D110 LAN

Controller)
All Other PCI None

Page: C-1

TROUBLE
SHOOTING

This section outlines the error messages that may occur when you
operate the system. It also gives you the suggestions on solving the
problems.

Section includes:

z Trouble Shooting for Error Messages

z Trouble Shooting for POST Code

APPENDIX

C

Appendix C Trouble Shooting

Page: C-2

Prox-1750G1/G2 USER

′

S MANUAL

TROUBLE SHOOTING FOR ERROR MESSAGES

The following information gives you the error messages and the trouble­shooting. Please adjust your systems according to the messages below. And
make sure all the components and connectors are in proper position and
firmly attached. If the errors still encountered, please contact with your
distributor for maintenance.

POST BEEP :

Currently there are two kinds of beep codes in BIOS. One code indicates
that a video error has occurred and the BIOS cannot initialize the video
screen to display any additional information. This beep code consists of a
single long beep followed by two short beeps. The other code indicates that
your DRAM error has occurred. This beep code consists of a single long
beep repeatedly.

CMOS BATTERY HAS FAILED :

This message informs you that the CMOS battery is no longer functional.
The user should replace it.

CMOS CHECKSUM ERROR :

This message informs you that the CMOS is incorrect. This error may
have caused by a weak battery. Check the battery and replace if necessary.

DISK BOOT FAILURE, INSERT SYSTEM DISK AND PRESS ENTER :

No boot device was found. This could mean that either a boot drive was
not detected or the drive does not contain proper system boot files. Insert a
system disk into Drive A: and press < Enter >. If you assumed the system
would boot from the hard drive, make sure the controller is inserted
correctly and all cables are properly attached. Also make sure the disk is
formatted as a boot device. Then reboot the system.

DISKETTE DRIVES OR TYPES MISMATCH ERROR - RUN SETUP :

Type of diskette drive installed in the system is different from the CMOS
definition. Run Setup to reconfigure the drive type correctly.

Appendix C Trouble Shooting

Prox-1750G1/G2 USER′S MANUAL

Page: C-3

DISPLAY SWITCH IS SET INCORRECTLY :

Display switch on the motherboard can be set to either monochrome or
color. This indicates the switch is set to a different setting than indicated in
Setup. Determine which setting is correct, and then either turn off the
system and change the jumper, or enter Setup and change the VIDEO
selection.

DISPLAY TYPE HAS CHANGED SINCE LAST BOOT :

Since last powering off the system, the display adapter has been changed.
You must configure the system for the new display type.

EISA CONFIGURATION CHECKSUM ERROR
PLEASE RUN EISA CONFIGURATION UTILITY :

The EISA non-violatile RAM checksum is incorrect or cannot correctly
read the EISA slot. This can indicate either the EISA non-volatile
memory has become corrupt or the slot has been configured incorrectly.
Also be sure the card is installed firmly in the slot.

EISA CONFIGURATION IS NOT COMPLETE
PLEASE RUN EISA CONFIGURATION UTILITY :

The slot configure information stored in the EISA non-volatile memory is
incomplete.
Note: When either of these errors appear, the system will boot in ISA mode,
which allows you to run the EISA Configuration Utility.

ERROR ENCOUNTERED INITIALIZING HARD DRIVE :

Hard drive cannot be initialized. Be sure the adapter is installed correctly
and all cables are correctly and firmly attached. Also be sure the correct
hard drive type is selected in Setup.

ERROR INITIALIZING HARD DISK CONTROLLER :

Cannot initialize controller. Make sure the cord is correctly and firmly
installed in the bus. Be sure the correct hard drive is selected in Setup. Also
check to see if any jumper needs to be set correctly on the hard drive.

Appendix C Trouble Shooting

Page: C-4

Prox-1750G1/G2 USER

′

S MANUAL

FLOPPY DISK CNTRLR ERROR OR NO CNTRLR PRESENT :

Cannot find or initialize the floppy drive controller. Make sure the
controller is installed correctly and firmly. If there are no floppy drives
installed, be sure the Diskette Drive selection in Setup is set to NONE.

INVALID EISA CONFIGURATION
PLEASE RUN EISA CONFIGURATION UTILITY

:

The non-volatile memory containing EISA configuration information was
programmed incorrectly or has become corrupt. Re-run EISA configuration
utility to correctly program the memory.
Note: When this error appears, the system will boot in ISA mode, which
allows you to run the EISA Configuration Utility.

KEYBOARD ERROR OR NO KEYBOARD PRESENT

:

Cannot initialize the keyboard. Make sure that the keyboard is properly
attached and no keys being pressed during the boot.
If you are purposely configuring the system without a keyboard, set the
error halt condition in Setup to HALT ON ALL, BUT KEYBOARD. This
will cause the BIOS to ignore the missing keyboard and continue the boot.

MEMORY ADDRESS ERROR AT ... :

Indicates a memory address error at a specific location. You can use this
location along with the memory map for your system to find and replace the
bad memory chips.

MEMORY PARITY ERROR AT ... :

Indicates a memory parity error at a specific location. You can use this
location along with the memory map for your system to find and replace the
bad memory chips.

MEMORY SIZE HAS CHANGED SINCE LAST BOOT :

Memory has been added or removed since the last boot. In EISA mode use
Configuration Utility to reconfigure the memory configuration. In ISA
mode enter Setup and enter the new memory size in the memory fields.

Appendix C Trouble Shooting

Prox-1750G1/G2 USER′S MANUAL

Page: C-5

MEMORY VERIFY ERROR AT ... :

Indicates an error verifying a value already written to memory. Use the
location along with your system's memory map to locate the bad chip.

OFFENDING ADDRESS NOT FOUND :

This message is used in conjunction with the I/O CHANNEL CHECK and
RAM PARITY ERROR messages when the segment that has caused the
problem cannot be isolated.

OFFENDING SEGMENT :

This message is used in conjunction with the I/O CHANNEL CHECK and
RAM PARITY ERROR messages when the segment that has caused the
problem has been isolated.

PRESS A KEY TO REBOOT :

This will be displayed at the bottom screen when an error occurs that
requires you to reboot. Press any key and the system will reboot.

PRESS F1 TO DISABLE NMI, F2 TO REBOOT :

When BIOS detects a Non-maskable Interrupt condition during boot, this
will allow you to disable the NMI and continue to boot, or you can reboot
the system with the NMI enabled.

RAM PARITY ERROR – CHECKING FOR SEGMENT :

Indicates a parity error in Random Access Memory.

Should be Empty But EISA Board Found
PLEASE RUN EISA CONFIGURATION UTILITY :

A valid board ID was found in a slot that was configured as having no
board ID.
Note: When this error appears, the system will boot in ISA mode, which
allows you to run the EISA Configuration Utility.

Should Have EISA Board But Not Found
PLEASE RUN EISA CONFIGURATION UTILITY :

The board installed is not responding to the ID request, or no board ID has
been found in the indicated slot.
Note: When this error appears, the system will boot in ISA mode, which
allows you to run the EISA Configuration Utility.

Appendix C Trouble Shooting

Page: C-6

Prox-1750G1/G2 USER

′

S MANUAL

Slot Not Empty :

Indicates that a slot designated as empty by the EISA Configuration Utility
actually contains a board.

SYSTEM HALTED, (CTRL-ALT-DEL) TO REBOOT :

Indicates the present boot attempt has been aborted and the system must be
rebooted. Press and hold down the CTRL and ALT keys and press DEL.

Wrong Board in Slot
PLEASE RUN EISA CONFIGURATION UTILITY :

The board ID does not match the ID stored in the EISA non-volatile
memory.
Note: When this error appears, the system will boot in ISA mode, which
allows you to run the EISA Configuration Utility.

FLOPPY DISK(S) FAIL (80) :

Unable to reset floppy subsystem.

FLOPPY DISK(S) FAIL (40) :

Floppy type dismatch.

Hard Disk(S) Fail (80) :

Hard Disk Drive reset failed.

Hard Disk(S) Fail (40) :

Hard Disk Drive controller diagnostics failed.

Hard Disk(S) Fail (20) :

Hard Disk Drive initialization error.

Hard Disk(S) Fail (10) :

Unable to recalibrate fixed disk.

Hard Disk(S) Fail (08) :

Sector Verify failed.

Keyboard is locked out – Unlock the key :

BIOS detect the keyboard is locked. P17 of keyboard controller is pulled
low.

Appendix C Trouble Shooting

Prox-1750G1/G2 USER′S MANUAL

Page: C-7

Keyboard error or no keyboard present :

Cannot initialize the keyboard. Make sure the keyboard is attached
correctly and no keys are being pressed during the boot.

Manufacturing POST loop :

System will repeat POST procedure infinitely while the P15 of keyboard
controller is pull low. This is also used for M/B burn in test.

BIOS ROM checksum error – System halted :

The checksum of ROM address F0000H-FFFFFH is bad.

Memory test fail :

BIOS reports the memory test fail if the onboard memory is tested error.
