REED RELAY SWITCHER CARD
INSTALLATION & OPERATION MANUAL
INTEGRA III SYSTEM
Model 655B Shown
www.protechaudio.com
The Model 655B Reed Relay Switcher Card is designed to operate as a remote switching control in professional audio systems. Typical applications a r e public address systems, broadcast studios, sales presentation rooms, head­phone listening systems, multi-room audio systems, and recording systems. The actual application of the amplifiers is found in buildings such as airports, factories, courthouses, casinos, convention centers, libraries, hotels, racetracks, training systems, corpo­rate boardrooms, etc. The Model 655B incorporates 8 individual reed relays. The relays are mounted on a single, plug-in printed circuit board. Each relay has a Form A normally open (SPST) contact arrangement. The relays are acti­vated by grounding the control pin. Relay control pins may be ganged together to operate more than one relay from a single switch closure. Different combina­tions of relays may be created by isolating the remote switch closures through diodes.
Reed relays are much faster operating than standard electro-mechanical relays. The average switching time for the reed relay is 1 millisecond. This fast operating time makes them ideal devices for line level audio applications. The relay cards are designed to operate alone or in conjunction with other switching cards in the INTEGRA III SYSTEM. The Model 655B is designed to mount in the Model s 857B or 858B Card Frames. The unit may be mixed or matched with other INTEGRA III SYSTEM cards to create a complete audio system. The card frames will allow mounting of either 9 audio cards and plug-in power supply card (Model 858B), or 10 audio or switching cards when used with an external power supply (Model 857B). If additional information is needed, contact Applications Assis­tance by calling 631-584-5855. The reed relay cards may be expected to provide years of uninterrupted, quality service.
Protech Audio Corporation, PO Box 597, 192 Cedar River Road, Indian Lake, New York, 12842, Voice 518-648-6410 Fax 518-648-6395
INSTALLATION
The 655B Reed Relay Switching Card is designed to be mounted in the Model 857B, or 858B Card Frame Assembly. The Model 857B Card Frame will accomodate up to 10 audio cards, and requires an external power supply (Model
66708). The Model 858B Card Frame will accomodate up to 9 audio cards, and has a built-in power supply card (Models 2000-PS-A).
Both card frames assemblies bus the DC power to the individual card slots, and provide screw-type barrier termi­nation points for audio and DC connections.
The determination as to which backplane assembly to use in your project, was made prior to our factory receiving the order. The backplane assembly you have received will accomodate the group of cards you or your designer have speciifed.
The actual steps necessary for installation of the 655B Reed Relay card, are comparable to those necessary for any of the INTEGRA III SYSTEM cards. They are as follows:
1- Mount the card frame in an appropriate EIA 19" width rack, using 4 screws of sufficient tensile strength to provide secure mounting.
2- A determination has been made as to which type of power supply will be used on your system. Follow the instructions for the type of power supply you will be installing.
4- Unpack each individual card, inspect for shipping damage, and assuming none is found, slide the card half-way into the appropriate slot. After all cards have been installed card at a time and turn on the power supply. Make sure no unusual loading is noticed at the power supply. If loading is noticed, turn off the power supply, unplug the card and recheck terminations. If no loading is noticed, continue inserting each card in the card frame, checking power supply loading as each card is plugged in. When all the cards have been plugged in, the installation is complete, and all that remains is the alignment.
half-way into the card frame, plug in one
ALIGNMENT
The Model 655B does not require alignment. Operation of the card may be checked in the following manner:
1- Apply a signal representative of the actual signal level to be used, to contact K1, In (Pin #19).
2- While monitoring the output at pin K1 Out (Pin #11), ground switch #1 (Pin #2). Check for proper signal level at the output pin.
3- Repeat steps 1 & 2 for each switch channel on the Model 655B.
This completes the installation and alignment of your Model 655B Reed Relay Switching Card. The card(s) may be expected to deliver years of uninterrupted service.
PROTECH AUDIO
857B & 858B BACKPLANE CONNECTIONS
GROUND RELAY SWITCH PINS TO ACTIVATE RELAYS
16
17
18
K1 IN
K2 IN
K3 IN
K4 IN
K5 IN
K6 IN
K7 IN
K8 IN
K5 OUT
K6 OUT
K7 OUT
K8 OUT
SPECIFICATIONS
19
20
21
22
23
24
25
26
27
28
29
30
®
INTEGRA III SYSTEM
CONNECTOR & PROGRAM DRAWING
MODEL 655B
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
K2 SWITCH
K1 SWITCH
GROUND
K3 SWITCH
K4 SWITCH
K5 SWITCH
K6 SWITCH
GROUND
K7 SWITCH
K8 SWITCH
K1 OUT
K2 OUT
GROUND
K4 OUT
K3 OUT
EXTERNAL POWER SUPPLY. If an external power supply is to be used, terminate the proper supply connections to pins 1, 2, & 3 of the DC connector, as shown in the card frame layout drawing Turn on the power supply, and using a DC voltmeter, check for correct voltage and polarity at pins 1, 2, & 3 of of the DC connector.
INTERNAL POWER SUPPLY. If a plug-in power supply card is to be used, plug in the supply card, and check for proper illumination of both plus and minus DC green LED's.
3- Terminate all input, output, and switch connections, using the card connection drawing on the facing page. Shielded cable is recommended for all audio connections.
Note 1­The alignment procedures for INTEGRA III SYSTEM cards, differ from card type to card type. Therefore it is necessary to consult the alignment procedure for each type of card being installed, to properly align a card frame using different card types.
Page 2
RELAY TYPE......................................................
CONTACT FORM...............................................
CONTACT RATING (SWITCHING)........................
CONTACT CARRY CURRENT...............................
POWER REQUIREMENTS..................................
RELAY ENABLE.................................................
SIZE.........................................................................
TEMPERATURE.................................................
Reed 1A
0.75 Amps DC
1.5 Amps +18-24VDC At 48ma per card External Switch to Ground
2.5"H x 8.0"D x 1.1"W 0-70 Degrees C
