Page 1

SUPER COACHVAC PARTS

PRODUCT PRICE LIST

JANUARY • 2008

Page 2

• All prices, speciﬁ cations and offers effective January 1, 2008 and are subject to change without notice.

• Shipping is prepaid on all orders greater than $2,500.00 in the Continental U.S.

Warranty Info – All ProTeam vacuums carry an unmatched 3 year parts, labor and motor warranty.

Lifetime warranty on molded body parts. Please see owner’s manual for complete warranty details.

Trademarks and Patents –

ProTeam, TailVac, QuarterVac, Super CoachVac, LineVacer, ProClean, Four Level, JetSweep, Intercept Micro, QuietPro, ProForce, ProDuster and Team Cleaning are trademarks and service marks of ProTeam, Inc. E-Z Glide patent No. 5,659,923 is a trademark of ProTeam,Inc. ManageMen is a registered trademark of ManageMen in the USA. Velcro is a registered trademark of Velcro Industries in the USA.

Page 3

TABLE OF CONTENTS

Vacuums ....................................................................................... 2

Attachment Kits ............................................................................ 3-4

Individual Tools ............................................................................. 5-6

Filters ............................................................................................ 7

Replacement Parts ........................................................................ 8

Accessories.................................................................................... 9

Educational Materials .................................................................... 9

Super CoachVac

MegaVac

Parts ............................................................................ 12-13

Super QuarterVac

QuietPro

QuarterVac

TailVac

BP Parts ........................................................................ 16-17

Parts ................................................................................ 20-21

, Super CoachVac® HEPA & CoachVac™ Parts ....... 10-11

& Super QuarterVac® HEPA Parts ...................... 14 -15

Parts ......................................................................... 18-19

ProVac/AviationVac Parts ............................................................... 22-23

QuietPro

ProClean

LineVacer

ProForce

GoCartVac

CN HEPA Parts .............................................................. 24-25

& ProClean HEPA Parts ................................................. 26-27

Parts ............................................................................ 28-29

1500XP Parts................................................................. 30-31

1500 Parts..................................................................... 32-33

™

Parts .......................................................................... 34-35

Index ............................................................................................ 36 -40

Sales Representatives .................................................................... inside back cover

Page 4

VACUUMS VACUUMS

LARGE CAPACITY BACKPACKS

SUPER COACHVAC

100653* Super CoachVac w/Attachment Kit B (101336) $509.00

100710 Super CoachVac w/Attachment Kit C (100077) 519.00

100709 Super CoachVac w/Attachment Kit D (100079) 529.00

105893 Super CoachVac w/Flooring Installation Kit A (105889) 539.00

105895 Super CoachVac w/Flooring Installation Kit B (105890) 519.00

105897 Super CoachVac w/Flooring Installation Kit C (105891) 509.00

101830

Super CoachVac w/Hard Surface Flooring Kit (101829) 509.00

106512 Super CoachVac w/1½'' Telescoping Wand Kit (106291) 509.00

106731 Super CoachVac w/1¼'' Tapered Wand Kit (106730) 489.00

COACHVAC

100643* CoachVac w/Attachment Kit B (101336) 499.00

101549 CoachVac w/Attachment Kit A (100078) 499.00

100707 CoachVac w/Attachment Kit C (100077) 509.00

100708 CoachVac w/Attachment Kit D (100079) 519.00

MEGAVAC

100657* MegaVac w/Attachment Kit B (101336) 529.00

101529 MegaVac w/Attachment Kit C (100077) 539.00

100717 MegaVac w/Attachment Kit D (100079) 549.00

105892 MegaVac w/Flooring Installation Kit A (105889) 539.00

105894 MegaVac w/Flooring Installation Kit B (105890) 549.00

105896 MegaVac w/Flooring Installation Kit C (105891)

(100181)

(100315)

(100182)

510.539.00

MID CAPACITY BACKPACKS

SUPER QUARTERVAC

106205* Super QuarterVac w/Attachment Kit B (101336) $509.00

106206 Super QuarterVac w/Attachment Kit A (100078) 509.00

106513 Super QuarterVac w/1½'' Telescoping Wand Kit (106291) 509.00

QUARTERVAC

101245* QuarterVac w/Attachment Kit B (101336) 499.00

101164 QuarterVac w/Standard 1¼'' Kit (100090) 479.00

101548 QuarterVac w/Attachment Kit A (100078) 499.00

101247 QuarterVac w/Attachment Kit C (100077) 509.00

101248 QuarterVac w/Attachment Kit D (100079) 519.00

101250 QuarterVac w/Turbo Brush 1¼'' Kit (100091) 539.00

106515 QuarterVac w/1½'' Telescoping Wand Kit (106291) 499.00

QUIETPRO BP

105732* QuietPro BP w/Attachment Kit B (101336) 589.00

105733 QuietPro BP w/Attachment Kit A (100078) 589.00

106518 QuietPro BP w/1½'' Telescoping Wand Kit (106291) 589.00

TAILVAC

101550* TailVac w/Attachment Kit B, 1½'' hose (101336) 519.00

101293 TailVac w/Standard 1¼'' Kit (101324) 499.00

101528 TailVac w/Attachment Kit C, 1½'' hose (100077) 529.00

105030 TailVac w/Deluxe 1¼'' Kit (103090) 519.00

106514 TailVac w/1½'' Telescoping Wand Kit (106291) 519.00

(101163)

(105739)

(101292)

(106070)

HEPA & CANISTER VACUUMS

LINEVACER

100277* LineVacer HEPA w/High Filtration Vac Kit (100163) $719.00 100280 LineVacer ULPA w/High Filtration Vac Kit (100163) 889.00 100279 LineVacer HEPA Cart w/High Filtration Vac Kit (100163) 819.00 100282 LineVacer ULPA Cart w/High Filtration Vac Kit (100163) 999.00

SUPER COACHVAC HEPA

106573* Super CoachVac HEPA w/Attachment Kit B (101336) 519.00 106580 Super CoachVac HEPA w/1½'' Telescoping Wand Kit (106291) 519.00

SUPER QUARTERVAC HEPA

106577* Super QuarterVac HEPA w/Attachment Kit B (101336) 519.00 106579 Super QuarterVac HEPA w/1½'' Telescoping Wand Kit (106291) 519.00

QUIETPRO CN HEPA

106207* QuietPro CN HEPA w/Attachment Kit B (101336) 639.00 106208 QuietPro CN HEPA w/High Filtration Vac Kit (100163) 639.00 106517 QuietPro CN HEPA w/1½'' Telescoping Wand Kit (106291) 639.00

PROCLEAN

103258* ProClean w/Attachment Kit B (101336) 549.00 103259 ProClean w/Attachment Kit C (100077) 549.00 103260 ProClean w/Attachment Kit D (100079) 549.00 103220 ProClean w/Restaurant Kit (100727) 589.00 106516 ProClean w/1½'' Telescoping Wand Kit (106291) 549.00

(100667)

(103131)

(106572)

(106102)

(106576)

SPECIALTY VACUUMS

GOCARTVAC

106209* GoCartVac w/GoCartVac Kit (104885) $3,449.00

PROVAC

100729* ProVac w/Restaurant Kit (100727) 549.00 100829 ProVac w/Attachment Kit A (100078) 509.00 103246 ProVac w/Attachment Kit B (101336) 509.00 106519 ProVac w/1½'' Telescoping Wand Kit (106291) 509.00

AVIATIONVAC

106542* AviationVac w/Aviation 1½" Kit #1 (106502) 599.00 103024 AviationVac w/Aviation 1¼'' Kit #2 (103222) 579.00

(106087)

(100617)

(103023)

UPRIGHTS

(104301)

PROFORCE 1500XP

104301* ProForce 1500XP $539.00

PROFORCE 1500

104300* ProForce 1500 419.00

* Denotes Standard Conﬁ guration Kit

(104300)

Page 5

KITS

COMMERCIAL TWO-PIECE 1½" WAND KIT #1

1½" Attachments with a Two-Piece Wand Option

Each Kit contains: Two-Piece, Two-Bend Aluminum Wand – 56" (101338) Upholster y Tool – 5" (100115) Dust Brush – 3" (100110) Crevice Tool – 17" (100108) And a choice of the following ﬂ oor tools:

Kit A. 100078 14" Floor Tool w/Scallops (100147) $76.86 Kit B. 101336 14" E-Z Glide Floor Tool w/Brush (101446) 88.00 Kit C. 100077 11" Floor Tool w/Adjustable Brush (100083) 87.60 Kit D. 100079 16" Floor Tool w/Adjustable Brush (100092) 96.53

COMMERCIAL ONE-PIECE 1½" WAND KIT #2

1½" Attachments with a One-Piece Wand Option

Each Kit contains: One-Piece, Two-Bend Aluminum Wand – 56" (100102) Upholster y Tool – 5" (100115) Dust Brush – 3" (100110) Crevice Tool – 17" (100108) And a choice of the following ﬂ oor tools:

Kit E. 100650 14" Floor Tool w/Scallops (100147) $76.86 Kit F. 101337 14" E-Z Glide Floor Tool w/Brush (101446) 88.00 Kit G. 10 0711 11" Floor Tool w/Adjustable Brush (100083) 87.60 Kit H. 100712 16" Floor Tool w/Adjustable Brush (100092) 96.53

STANDARD 1¼" KIT

Kit No. 101324 TailVac Standard 1¼" Attachment Kit $65.72 Kit No. 100090 Standard 1¼" Attachment Kit 65.72

Each kit contains: Upholstery Tool – 5½" (103087) w/Removable Brush (103088) Cuff Adapter – 1¼" x 1¼" (103099) Reducer Cuff* (101092) Curved Chrome Wand w/Button Lock – 1¼" x 13" (103505) Chrome Telescoping Wand w/Button Lock – 24" to 40" (106343) Crevice Tool – 13" (103086) Multi-Sur face Floor Tool – 10" (106709) Dust Brush, Rectangular 90/180° Swivel – 2½" (103089)

*Reducer cuff is not included with the TailVac Standard 1¼" Kit

DELUXE 1¼'' KITS

Kit No. 103090 TailVac Deluxe 1¼" Attachment Kit $88.00 Kit No. 103467 Deluxe 1¼" Attachment Kit 88.00

Each kit contains: Crevice Tool – 13" (103086) Cuff Adapter – 1¼" x 1¼" (103099) Reducer Cuff* (101092) Chrome Telescoping Wand w/Button Lock – 24" to 40" (106343) Carpet Tool w/Scallops 12" (103085) Natural Fiber Hard Floor Tool – 12" (103084) Curved Chrome Wand w/Button Lock – 1¼" x 13" (103505) Dust Brush, Rectangular 90/180° Swivel – 2½" (103089) Upholstery Tool – 5½" (103087) w/Removable Brush (103088)

COMMERCIAL 1½" TELESCOPING WAND KIT #3

Kit No. 106291 1½" Attachments $92.70

Each kit contains: 1½" 42" to 59" Aluminum Telescoping Wand (106290) Crevice Tool – 17" (100108) Dust Brush – 3" (100110) Upholstery Tool – 5" (100115) 14" E-Z Glide Floor Tool w/Brush (101446)

TAPERED

Kit No. 106730 1½ " Att achments $65.72

Each kit contains: 54" One-Bend Chrome Tapered Wand (100136) Crevice Tool – 17" (100108) Dust Brush – 3" (100110) Upholstery Tool – 5" (100115) 10" Multi-Sur face Floor Tool (106709)

1¼"

WAND KIT

*Reducer cuff is not included with the TailVac Deluxe 1¼" Kit

TURBO BRUSH 1¼" KITS

A. Kit No. 101346 $133.67

TailVac Standard 1¼" Attachment Kit with Turbo Brush Kit contains: TailVac Standard 1¼" Kit (101324) 11" Turbo Brush Tool – 1¼" (100117)

B. Kit No. 100091 133.67

Standard 1¼" Attachment Kit with Turbo Brush Kit contains: Standard 1¼" Kit (100090) 11" Turbo Brush Tool – 1¼" (100117)

C. Kit No. 100135 93.99

Turbo Brush with Wand Kit contains: 11" Turbo Brush Tool – 1¼” (100117) 54" One-Bend Chrome Tapered Wand – 1½" to 1¼" (100136)

Page 6

KITS

RESTAURANT 1½" KIT

Kit No. 100727 $99.62

Each kit contains: Hard Floor Tool w/Nylon Brush – 14" (100623) Dust Brush – 3" (100110) Upholstery Tool – 5" (100115) Two-Piece Aluminum Wand w/Button Lock – 56" (101338) Crevice Tool 11" (100107) Ca rpet Tool w/Sc allo ps 14" (100147 )

Extra 10-pk Intercept Micro Filters, extra cloth ﬁ lter and 5-year motor

warranty included with purchase of ProVac or ProClean with Restaurant Kit.

AVIATION 1½" KIT #1

Kit No. 106502 $118.45

Aviation 1½" Attachment Kit Each kit contains: Dust Brush, Horsehair – 3" (100110) Crevice Tool – 17" (100108) Aluminum One-Piece, Two-Bend Wand – 49" (106293) Upholstery Tool – 5" (100115) Aluminum Gulper Floor Tool – 12" (100155)

GOCARTVAC 1¼" KIT

1¼" Attachments with a Telescoping Wand

Kit No. 104885 $60.00

Kit contains:

Chrome Telescoping Wand w/Button Lock – 24" to 40" (106343)

10" Multi-Surface Floor Tool (106709)

13" Crevice Tool (103086)

Upholstery Tool – 5½" (103087) w/Removable Brush (103088)

Dust Brush, Rectangular 90/180° Swivel – 2½" (103089)

FLOORING INSTALLATION 1½" KIT

1½" Attachments with a Two-Piece Wand Each Hard Surface Flooring Kit contains:

Two-Piece, Two-Bend Aluminum Wand – 56" (101338)

Dust Brush – 3" (100110)

Crevice Tool – 17" (100108)

And a choice of the following ﬂ oor tools:

Kit A. 105889 14" Floor Tool w/Scalloped Felt Brush (100144) $89.51

Kit B. 105890 20" JetSweep® w/Brush (101613) 97.65

Kit C. 105891 14" Hard Floor Tool w/Horse Hair Brush (100614) 89.51

AVIATION 1¼" KIT #2

Kit No. 103222 $65.72

Each kit contains: Curved Chrome Wand w/Button Lock – 1¼" x 13" (103505) Crevice Tool – 13" (103086)

Upholstery Tool – 5½" (103087) w/Removable Brush (103088)

Dust Brush, Rectangular 90/180° Swivel – 2½" (103089) Cuff Adapter – 1¼" x 1¼" (103099) Carpet Tool w/Scallops 12" (103085) Chrome Telescoping Wand w/Button Lock – 24" to 40" (106343)

HIGH FILTRATION VAC 1½" KIT

Kit No. 100163 $83.54

Each kit contains: Dust Brush – 3" (100110) Carpet Tool w/Scallops – 14" (100147) Upholstery Tool – 5" (100115) One-Bend Bulk Pick-Up Tool – 36" (100150) Two-Piece Aluminum Wand w/Button Lock – 56" (101338)

HARD SURFACE FLOORING 1½" KIT

Kit No. 101829 $87.88

Kit contains:

Two-Piece, Two-Bend Aluminum Wand – 56" (101338)

Dust Brush – 3" (100110)

Crevice Tool – 28" (100109)

Upholstery Tool – 5" (100115)

14" Hard Floor Tool w/Felt Brush – Scalloped & Flat (106194)

Page 7

INDIVIDUAL TOOLS

CREVICE TOOLS

No. Product Name Size List Price

104832 Replacement Crevice Tool

(ProForce 1500XP) 1½" $ 2.48

100107 11" Crevice Tool 1½" 6.41

103086 13" Crevice Tool 1¼" 5.52

100108 17" Crevice Tool 1½" 8.63

100109 28" Crevice Tool 1½" 15.59

DUST BRUSHES

No. Product Name Size List Price

103089 2½" Rectangular 90/180º Swivel 1¼" $ 6.63

100110 3" Dust Brush w/Reducer 1½" 7.75

102659 5" Long Dust Brush 1¼" 11.36

104833 Combo Upholstery/Dust Brush

(ProForce 1500XP) 1¼" 18.69

UPHOLSTERY TOOLS

No. Product Name Size List Price

103087 5½" Upholstery Tool 1¼" $ 6.63

(Includes Removable Brush No. 103088)

100115 5" Upholstery Tool 1½" 11.14

BULK PICK-UP TOOLS

No. Product Name Size List Price

100946 27" Straight Bulk Pick-Up Tool 1½" $14.88

100150 36" One-Bend Bulk Pick-Up Tool 1½" 16.07

100151 42" One-Bend Bulk Pick-Up Tool 1½" 29.74

PIPE CLEANER TOOLS

No. Product Name Size List Price

100113 1" to 4" Overhead Pipe Cleaner 1½" $57.93

(Includes Reducer Cuff)

100114 4" to 8" Overhead Pipe Cleaner 1½" 66.84

(Includes Reducer Cuff)

WANDS

No. Product Name Size List Price

103505 13" Curved Chrome Wand 1¼" $13.99

w/Button Lock

100167 13" Curved Chrome Wand 1¼" 13.99

100104 60" Straight Extension* 1½" 49.77

Aluminum Wand

100102 56" One-Piece, 1½" 39.74

Two-Bend Aluminum Wand*

101338 56" Two - Pie ce, Two-Bend 1½" 50.13

Aluminum Wand w/Button Lock*

100136 54" One-Bend Chrome 1½" to 1¼" 33.80

Tapered Wand for Turbo Brush

106343 24" to 40" Chrome 1¼" 27.85

Telescoping Wand w/Button Lock

100082 24" to 40" Chrome 1¼" 27.85

Tel escoping Wand

105693 59" Two-Piece 1½" 49.98

Friction Fit Aluminum

Sidewinder Straight Wand

105695 59" One-Piece 1½" 42.98

Friction Fit Aluminum

Sidewinder Straight Wand

102266 54" Two-Piece 1½" 48.95

Friction Fit Aluminum

Button Lock Wand

106290 42" to 59" Aluminum 1½"

Tel escoping Wand 61. 80

106293 49" One-Piece, Two-Bend 1½"

Aluminum Wand 56.65

*Wands come complete with tool couplings.

Page 8

INDIVIDUAL TOOLS

FLOOR TOOLS

CARPET FLOOR TOOLS

No. Product Name Size List Price

100117 11" Turbo Brush 1¼” $75.75

Works only with friction ﬁ t wand

103085 12" Carpet Tool w/Scalloped 1¼” 25.62

100730 12" Paddle Floor Tool 1½

103608 11" Turbo Brush 1½

Works only with friction ﬁ t wand

100083 11" Floor Tool 1½ w/Adjustable Nylon Brush

100147 14" Floor Tool w/Scalloped 1½

103032 JetSweep 15, 15" Floor Tool 1½

w/Nylon Brush

106245 15" Sidewinder Carpet Tool 1½

100092 16" Floor Tool 1½

w/Adjustable Nylon Brush

105691 18" Sidewinder Carpet Tool 1½

" 26.74

" 75.75

" 38.99

" 31.19

" 46.78

" 47.38

" 42.33

" 47.38

FLOOR TOOLS

HARD FLOOR TOOLS

No. Product Name Size List Price

103084 12" Natural Fiber Hard Floor Tool 1¼” $28.96

100143 14" Hard Floor Tool w/Felt Brush 1½

100144 14" Hard Floor Tool 1½

w/Felt Brush/Scalloped

100623 14" Hard Floor Tool 1½ w/Nylon Brush

100614 14" Hard Floor Tool 1½ w/Horse Hair Brush

106194 14" Hard Floor Tool w/Felt 1½ Brush – Scalloped & Flat

106246 15" Sidewinder Hard Floor Tool 1½

w/Nylon Brush

101613 JetSweep 20, 20" Hard Floor Tool 1½ w/Nylon Brush

105692 18" Sidewinder Hard Floor Tool 1½ w/Nylon Brush

" 44.56

" 47.90

" 45.36

" 49.44

" 65.72

" 51. 50

MULTI-SURFACE FLOOR TOOLS

No. Product Name Size List Price

106709 10" Multi-Sur face Floor Tool 1¼

101446 14" E-Z Glide w/Nylon Brush 1½

100155 12" Gulper Aluminum Floor Tool 1½

" $28.96

" 46.78

" 42.38

Note: Additional specialty attachments may be available upon request. Contact Customer Service. All attachments are non-metallic unless otherwise noted.

Page 9

FILTERS FILTERS

INTERCEPT MICRO FILTERS

No. Product Name /Media/Machine List Price* 100431 Intercept Micro Filters, $15.00

One Pack of 10; 496 sq. in. ﬁ ts Super QuarterVac, Super QuarterVac HEPA, QuarterVac, TailVac, ProVac, QuietPro BP, GoCartVac, AviationVac (Case = 20 packs) 100331 Intercept Micro Filters, 20.00 One Pack of 10; 698 sq. in. ﬁ ts Super CoachVac, Super CoachVac HEPA, CoachVac, MegaVac (Case = 20 packs) 100291 Intercept Micro Filters, One Pack of 10; 29.95 698 sq. in. ﬁ ts LineVacer (Case = 20 packs) 104544 Intercept Micro Filters, One Pack of 10; 24.00 698 sq. in. ﬁ ts QuietPro CN HEPA, ProClean (formerly Running Vac) (Case = 20 packs) 103483 Intercept Micro Filters, One Pack of 10; 9.99

3.25 qt. / 248 sq. in. ﬁ ts ProForce (Case = 25 packs) *Price is for one pack of 10 ﬁ lters

UPRIGHT REPLACEMENT FILTERS

No. Product Name / Description List Price 105136 Replacement HEPA Media Exhaust Filter $6.30 104246 Replacement Exhaust Filter Cover 4.73 104281 Replacement Motor Intake Filter 2.58

MICRO CLOTH FILTERS

No. Product Name /Machine List Price 100564 Micro Cloth Filter for Super QuarterVac, $22.61

Super QuarterVac HEPA, QuarterVac, ProVac, TailVac, QuietPro BP GoCartVac, AviationVac 100565 Micro Cloth Filter for CoachVac, 27.37 Super CoachVac, Super CoachVac HEPA, MegaVac, LineVacer

103115 Micro Cloth Filter for QuietPro CN HEPA, 28.55 ProClean, ProClean HEPA

HIGH FILTRATION DISKS

No. Product Name / Media / Machine List Price

101220 High Filtration Disks for Dome Filter, $9.99

One Pack of Two; ﬁ ts Super QuarterVac,

QuarterVac, CoachVac, Super CoachVac,

MegaVac, ProVac, QuietPro BP, AviationVac

102761 High Filtration Disks for Dome Filter, 10.19

One Pack of Two; QuietPro CN HEPA,

TailVac, ProClean (formerly RunningVac)

DOME FILTER FOAM MEDIA

No. Product Name / Machine List Price

100343 Foam Filter Media for Dome Filter, $1.22

ﬁ ts Super QuarterVac, QuarterVac,

CoachVac, Super CoachVac, MegaVac,

LineVacer, ProVac, QuietPro BP, AviationVac

101949 Foam Filter Media for Dome Filter, 1.22

ﬁ ts QuietPro CN HEPA, TailVac, ProClean

(formerly the RunningVac)

SOUND EXHAUST

No. Product Name / Machine List Price

100698 Sound Mufﬂ er ﬁ ts QuarterVac $ 21.83

105800 Sound Mufﬂ er for Super QuarterVac, 21.83

Super QuarterVac HEPA, AviationVac, ProVac

100597 Sound Mufﬂ er ﬁ ts Super CoachVac, 21.83

Super CoachVac HEPA, CoachVac, MegaVac

103123 Exhaust/Sound Filter for QuietPro CN HEPA, 14.97

ProClean (formerly the RunningVac)

103638 True HEPA Filter Assembly w/Electrical 114.35

Connector for QuietPro CN HEPA

HEPA/ULPA FILTERS

No. Product Name /Machine List Price 104274 True HEPA Filter Assembly, Complete $224.36

w/BottomCap for LineVacer (Black) 104275 True ULPA Filter Assembly Complete 266.81 w/BottomCap for LineVacer (Black) 103638 True HEPA Filter Assembly w/Electrical 114.35 Connector for QuietPro CN HEPA 106526 HEPA Dome Filter for Super CoachVac HEPA, 9.99 Super QuarterVac HEPA (Fits all backpack vacuums except TailVac)

Page 10

REPLACEMENT PARTS REPLACEMENT PARTSREPLACEMENT PARTS

TURBO BRUSH REPLACEMENT PARTS

No. Product Name List Price

1 104010 Top Cove r $22.28

2 104011 1¼" Neck Assembly Complete 20.76

104012 1½" Neck Assembly Complete 20.76

3 103974 Bushing w/Holder 4.33

4 104017 Back Wheel, Set of 2 1.97

5 104016 Rear Axle, Set of 2 1.97

6 104021 Bottom Cover 17.52

7 104018 Front Axle, Set of 2 1.68

8 104019 Front Wheel, Set of 2 1.68

9 104022 Squeegee 2.22

10 104020 Belt 5.57

11 104023 Belt Guard .80

12 103975 Brush Arm, Set of 2 3.46

13 104024 Brush Roller Assembly 19.47

ATTACHMENT REPL ACEMENT PARTS

No. Product Name List Price

100084 Replacement Brush – 11" Floor Tool (100083) $ 8.36

100093 Replacement Brush – 16" Floor Tool (100092) 9.48

100713 Replacement Nylon Brush – 14.08

14" Floor Tool (100623)

100714 Replacement Horse Hair Brush – 18.20

14" Floor Tool (100614)

100141 Replacement Bumper – 14" Floor Tool (100147) 3.90

100145 Replacement Felt – 14" Floor Tool (100143) 6.68

100146 Replacement Felt, Scalloped – 6.68

14" Floor Tool (100144)

100085 Adjustment Lever – 11" Floor Tool (100083) 12.49

100094 Adjustment Lever – 16" Floor Tool (100092) 12.49

100097 Screw – 11" – 16" Floor Tools (100083/100092) 1.13

100098 Spring – 11" – 16" Floor Tools (100083/100092) 1.71

100096 Brush Height Adjustment Knob – 3.98

11" – 16" Floor Tools (100083/100092)

100116 Replacement Nylon Brush – 5" Upholstery Tool 6.68

(100115)

100112 Reducer – 3" Dust Nylon Brush (100110) 3.92

103088 Removable Brush – 5½" Upholstery Tool (103087) 3.34

100099 Replacement Nut – Aluminum Wands 7.25

100100 Replacement Ring – Aluminum Wands 1.68

100101 Replacement Sleeve – Aluminum Wands 4.17

101445 Retro Kit – 14" E-Z Glide Floor Tool 24.50

(ﬁ ts 100147 Floor Tool)

101155 Replacement Nylon Brush – 3.95

E-Z Glide 14" Floor Tool

101880 Replacement Nylon Brush – JetSweep 20, 13.37

20" Hard Floor Tool, Set of 2

101475 Repair Kit – Felt Floor Tools: Support Bars 10.51

and Screws

101473 Repair Clip with Screws – 14" Hard Floor Tool 2.16

w/Nylon Brush (100623)

101092 Reducer Cuff 6.85

103099 Cuff Adapter 2.48

105694 Replacement Nylon Brush – 18" Sidewinder 15.35

Hard Floor Tool (105792)

101615 Replacement Blue Bumper 7.14

for JetSweep 20 (101613)

Page 11

ACCESSORIES

EDUCATION

PRODUSTER AND SLEEVES

No. Product Name List Price

101788 P. O. P. P a c k age $ 36.75

One wool duster (extendable to 4 ft.)

and one pack of 10 sleeves in hanging

point-of-purchase (P.O.P.) package

101808 P.O. P. C a s e 345.00

12 individual point-of-purchase (P.O.P.)

packages. Each package contains one wool

duster with one pack of 10 sleeves.

101533 500 sleeves (10 packs of 50) 236.25

101532 50 sleeves (1 pack of 50) 26.25

THE PROTEAM VAC STATION

No. Product Name List Price

102947 Vac Station $49.95

MISCELLANEOUS

No. Product Name List Price 100361 Waist Belt Extension (18'') $18.39 106346 Waist Belt Extension (18'') Nifco 18.39 100360 Waist Belt Extension (10'') 17.60 106345 Waist Belt Extension (10'') Nifco 17.60 102604 Schulte Cord Holder 8.11 100376 Water Lift Gauge 75.79 101394 Ergonomic Wand Handles, Set 22.21 101709 25' 16-Gauge Extension Cord (Blue)* 26.57 101680 50' 16-Gauge Extension Cord (Blue)* 46.49 101678 50' 16-Gauge Extension Cord (Yellow)* 27.50 103441 Cord Lock (ProClean) 9.87 106261 6' Static Strap Kit (ProForce) 76.65 106274 10' Static Strap Kit (ProForce) 89.25

*Includes a Cord Wrap

POINT-OF-PURCHASE ITEMS

No. Product Name List Price

104029 Vac Display Mannequin $183.75

Custom powder-coated metal

backpack display. Holds 1 vacuum

104158 (12'') Display Pedestal 31.50

104159 (18'') Display Pedestal 31.50

105537 Set of Pedestals; (1) 12'' Display Pedestal 57.75

and (1) 18'' Display Pedestal

100180 Demo Dufﬂ e Bag - holds 42.00

vacuum and complete demo kit.

100719 Logo Banner - 2' x 3' vinyl ProTeam 30.00

logo banner w/metal grommets.

104160 Floor Mat 152.25

105031 ALA Price Tags (Set of 25) 13.76

Displays do not include vacuums

EDUCATIONAL VIDEOS

No. Product Name List Price

105498 Training/Sales DVD – The ProTeam® Way $19.95

104812 Pest Control DVD – Introduction to 19.95

Pest Control System

106501 Vacuums – Set-Up/Training/Operation DVD

English/Spanish 19.95

MANAGEMEN® TEAM CLEANING® PROGRAMS

No. Product Name List Price

100630 How to Coach a Successful Team: $99.95

Audio Tape, VHS, DVD that is menu driven

and also contains the Spanish version of the

video, Playbook, ISSA’s 447 Cleaning Times,

Wooden’s Pyramid of Success and a Janitor

University Philosophy of Cleaning poster.

101122 How to Be a Light Duty Specialist™: 99.95

Audio Tape, VHS Tape, menu driven DVD

that also contains Spanish, Light Duty Playbook,

1 Scouting Report in English and 1 Scouting

Report in Spanish.

100628 How to Be a Vacuum Specialist™: 99.95

Audio Tape, VHS Tape, menu driven DVD

that also contains a Spanish version of the video,

Vacuum Playbook, 1 Scouting Report in English

and 1 Scouting Report in Spanish, 1 Simpliﬁ ed

Simon Vacuum Brochure.

100629 How to Be a Restroom Specialist™: 99.95

Audio Tape, VHS Tape, menu driven DVD

that contains a Spanish version of the video,

Restroom Playbook, 1 Scouting Report in

English and 1 Scouting Report in Spanish.

104152 How to Be a Utility Specialist™ in Carpet Care: 99.95

VHS, DVD, Playbook and 3 Scouting Reports.

If you have any questions regarding kit contents contact ManageMen

at: 1045 E. 4500 S., Salt Lake City, Utah 84117

or call (801) 263-0861.

Page 12

SUPER COACHVAC/SUPER COACHVAC HEPA/ & COACHVAC PARTS

Page 13

SUPER COACHVAC/SUPER COACHVAC HEPA/

& COACHVAC PARTS

No. Product Name Qty List Price

1 100197 Twist Cap (Purple) 1 ea. $ 31.53 2 100331 698 Sq. In. Intercept Micro Filter 10/pk 20.00 3 100565 Micro Cloth Filter 1 ea. 27.37 4 101737 Carry Handle w/Rivet and Washer Set 1 set 7.89 5 100356 Shoulder Strap Assembly (includes: #5a, 5b, 5c) 1 set 15.77 5a 100358 Shoulder Strap Plastic Adjustment Buckle (Top) 1 ea. .91 5b 100357 Shoulder Strap Plastic Adjustment Buckle (Bottom) 1 ea. .91 5c 103627 Sternum Strap Buckles (Latch and Keeper) 1 set 1.94 6 105046 Backplate (includes: #7) 1 ea. 24.26 7 100375 Barrel Nut Connection Set for Backplate (Replacement) 1 set 5.46 8 100716 Backplate (Black) Connection Set: 4 Screws w/Washers 1 set 12.13 9 106719 Waist Belt Keeper and Latch 1 ea. 10.99 10 100359 Waist Belt (includes: #9) 1 ea. 36.38

100354 Strap Assembly Complete (includes: #5, 9) 1 set 48.51 103166 Backplate (Black) System Complete (includes: #4, 5, 6, 7, 8, 9) 1 set 60.64

11 100641 Power Cord (18" 14/3) Assembly 1 set 17.59 12 101610 Switch Cord Assembly (includes: #12, 13, 14) 1 set 33.96 101714 Switch Cord w/Crimps 1 ea. 12.13 13 101472 Switch Box w/Velcro and New Lamb Switch 1 set 21.83 14 106066 On/Off Switch (must use with #106287) 1 ea. 6.60 106287 15 100597 Sound Mufﬂ er 1 ea. 21.83 16 105044 Motor Shroud Cover w/Screw Set: 2 Screws 1 set 20.79 17 100335 Motor Compression Ring w/Screws 1 set 10.31 100378 Compression Ring Screw Set: 4 Screws 1 set 2.73 18 100014 Tetraseal 1 ea. 10.92 19 105697 Carbon Brush Set for CoachVac Motor (Domel Motor) 1 set 19.40

100424 Carbon Brush Set for CoachVac Motor (Ametek Motor) 1 set 15.77 105164 Carbon Brush Set for Super CoachVac Motor (Domel Motor) 1 set 19.40 101720 Carbon Brush Set for Super CoachVac Motor (Ametek Motor) 1 set 19.40 20 105720 Motor/Fan (120 V) w/Crimps for CoachVac 1 ea. 83.69 105162 Motor/Fan (120V) w/Crimps for Super CoachVac 1 ea. 109.15 100379 Motor Ground and Wire Clamp Set w/Screws 1 set 5.46 100380 Motor Crimp Set: 5 Female, 3 Male, Ground Crimp Connector 1 set 9.70

21 100368 Motor Mounting System Set: 3 Well Nuts, 3 Bolts, 3 Washers, 3 Covers 1 set 12.13 22 100586 Bottom Bumper 1 ea. 6.68 23 100030 Dome Filter w/Foam Media 1 ea. 7.28 24 100343 Foam Filter Media for Dome Filter 1 ea. 1.22 101220 High Filtration Disk (optional) 2/pk 9.99 25 103048 Static-Dissipating Hose w/Cuffs (Black) 1 ea. 23.05 26 101928 Replacement Double Swivel Elbow Cuff (Black) 1 ea. 8.38 27 100694 28 101543 Filter Guard (Optional) 1 ea. 8.93 29 103476 Thermal Protector 1 ea. 13.30 30 106526 Replacement HEPA Dome Filter 1 ea. 9.99

101678 50' Extension Cord (Not Shown) 1 ea. 27.50

Switch Box w/Velcro and Screws 1 ea. 16.28

Replacement Swivel Cuff (Black) 1½" 1 ea. 4.98

Page 14

MEGAVAC PARTS

Page 15

MEGAVAC PARTS

No. Product Name Qty List Price

1 100320 Twist Cap (Black) 1 ea. $ 31.53 2 100331 698 Sq. In. Intercept Micro Filter 10/pk 20.00 3 100565 Micro Cloth Filter 1 ea. 27.37 4 101737 Carry Handle w/Rivet and Washer Set 1 set 7.89 5 100356 Shoulder Strap Assembly (includes: #5a, 5b, 5c) 1 set 15.77 5a 100358 Shoulder Strap Plastic Adjustment Buckle (Top) 1 ea. .91 5b 100357 Shoulder Strap Plastic Adjustment Buckle (Bottom) 1 ea. .91 5c 103627 Sternum Strap Buckles (Latch and Keeper) 1 set 1.94 6 105046 Backplate (includes: #7) 1 ea. 24.26 7 100375 Barrel Nut Connection Set for Backplate (Replacement) 1 set 5.46 8 100374 Backplate Connection Set: 4 Screws w/Washers, Stand Offs 1 set 12.13 9 106719 Waist Belt Keeper and Latch 1 ea. 10.99 10 100359 Waist Belt (includes: #9) 1 ea. 36.38

100354 Strap Assembly Complete (includes: #5, 9) 1 set 48.51 103166 Backplate System Complete (includes: #4, 5, 6, 7, 8, 9) 1 set 60.64

11 100641 Power Cord (18" 14/3) Assembly 1 set 17.59 12 101610 Switch Cord Assembly (includes: #12,13,14) 1 set 33.96 101714 Switch Cord w/Crimps 1 ea. 12.13 13 101472 Switch Box w/Velcro and New Lamb Switch 1 set 21.83 14 106066 On/Off Switch (must use with #106287) 1 ea. 6.60 106287 Switch Box w/Velcro and Screws 1 ea. 16.28 15 105070 Bottom Twist Cap (Black) 1 ea. 36.38 16 100597 Sound Mufﬂ er 1 ea. 21.83 17 105044 Motor Shroud Cover w/Screws 1 set 20.79 18 100335 Motor Compression Ring w/Screws 1 set 10.31 100378 Compression Ring Screw Set: 4 Screws 1 set 2.73 19 100014 Tetraseal 1 ea. 10.92 20 105164 Carbon Brush Set for MegaVac Motor (Domel Motor) 1 set 19.40 101720 Carbon Brush Set for MegaVac Motor (Ametek Motor) 1 set 19.40 21 105162 Motor/Fan (120V) w/Crimps for MegaVac 109.15

100379 Motor Ground and Wire Clamp Set w/Screws 1 set 5.46 100380 Motor Crimp Set: 5 Female, 3 Male, Ground Crimp Connector 1 set 9.70

22 100368 Motor Mounting System Set: 3 Well Nuts, 3 Bolts, 3 Washers, 3 Covers 1 set 12.13 23 100030 Dome Filter w/Foam Media 1 ea. 7.28 24 100343 Foam Filter Media for Dome Filter 1 ea. 1.22 101220 High Filtration Disk (optional) 2/pk 9.99 25 104998 Bottom Twist Cap Gasket 1 ea. 8.49 26 103048 Static-Dissipating Hose w/Cuffs (Black) 1 ea. 23.05 27 101928 Replacement Double Swivel Elbow Cuff (Black) 1 ea. 8.38 28 100694 Replacement Swivel Cuff (Black) 1½" 1 ea. 4.98 29 101543 Filter Guard (Optional) 1 ea. 8.93 30 103476 Thermal Protector 1 ea. 13.30

101678 50' Extension Cord (Not Shown) 1 ea. 27.50

Page 16

SUPER QUARTERVAC/ SUPER QUARTERVAC HEPA PARTS

Page 17

SUPER QUARTERVAC/

SUPER QUARTERVAC HEPA PARTS

No. Product Name Qty List Price 1 101928 Replacement Double Swivel Elbow Cuff (Black) 1½" 1 ea. $ 8.38 2 106073 Twist Cap (Purple) 1 ea. 26.68 3 100431 496 Sq. In. Intercept Micro Filter 10/pk 15.00 4 100564 Micro Cloth Filter 1 ea. 22.61 5 103048 Static-Dissipating Hose (Black) w/Cuffs 1½" 1 ea. 23.05 6 100694 Replacement Swivel Cuff (Black) 1½" 1 ea. 4.98 7 100030 Dome Filter w/Foam Media 1 ea. 7.28 8 100343 Foam Filter Media for Dome Filter 1 ea. 1.22 101220 High Filtration Disk (optional) 2/pk 9.99 9 100586 Bottom Bumper 1 set 6.68 10 100014 Tetraseal 1 ea. 10.92 11 105162 Motor/Fan (120 V) w/Crimps 1 ea. 109.15

100379 Motor Ground Wire Clamp Set w/Screws 1 set 5.46 100380 Motor Crimp Set: 5 Female, 3 Male, Ground Crimp Connector 1 set 9.70

12 105164 Carbon Brush Set (Domel Motor) 1 set 19.40 13 100335 Motor Compression Ring w/Screws 1 set 10.31 100378 Compression Ring Screws: 4 Screws 1 set 2.73 14 105044 Motor Shroud Cover w/Screws: 2 Screws 1 set 20.79 15 105800 Sound Mufﬂ er 1 ea. 21.83 16 100368 Motor Mounting System Set: 3 Well Nuts, 3 Bolts, 3 Washers, 3 Covers 1 set 12.13 17 101714 Switch Cord w/Crimps 1 set 12.13 101610 Switch Cord Assembly (includes: #18, 19, 20) 1 ea. 33.96 18 106066 On/Off Switch (must use with #106287) 1 ea. 6.60 106287 Switch Box w/Velcro and Screws 1 ea. 16.28 19 101472 Switch Box w/Velcro and New Lamb Switch 1 set 21.83 20 100641 Power Cord (18" 14/3) Assembly 1 set 17.59 21 100358 Shoulder Strap Plastic Adjustment Buckle (Top) 1 ea. .91 22 101737 Carry Handle w/Rivet and Washer Set 1 set 7.89 23 103627 Sternum Strap Buckles (Latch and Keeper) 1 set 24 106719 Waist Belt Keeper and Latch 1 ea. 10.99 25 100359 Waist Belt (includes: #24) 1 ea. 36.38 26 100375 Barrel Nut Connection Set for Backplate (Replacement) 1 set 5.46 27 100357 Shoulder Strap Plastic Adjustment Buckle (Bottom) 1 ea. .91 28 105046 Backplate Assembly (includes: #26) 1 ea. 24.26

100354 Strap Assembly Complete (includes: #21, 23, 24, 27, 28) 1 set 48.51 103166 Backplate System Complete (includes: #21, 22, 23, 24, 26, 27, 28, 29, 30) 1 set 60.64

29 100716 Backplate (Black) Connection Set: 4 Screws w/Washers 1 set 12.13 30 100356 Shoulder Strap Assembly (includes: #21, 23, 28) 1 set 15.77 31 103476 Thermal Protector 1 ea. 13.30 32 106526 Replacement HEPA Dome Filter 1 ea. 9.99 101678 50' Extension Cord (Not Shown) 1 ea. 27.50

1.94

Page 18

QUIETPRO BP PARTS

Page 19

QUIETPRO BP PARTS

No. Product Name Qty List Price

1 101928 Elbow Cuff, Swivel 1 ea. $ 8.38 2 104273 Twist Cap (Black) 1 ea. 26.68 3 100431 496 Sq. In. Intercept Micro Filter 10/pk 15.00 4 100564 Micro Cloth Filter 1 ea. 22.61 5 103048 Static-Dissipating Hose (Black) w/Cuffs 1½" 1 ea. 23.05 6 100694 Replacement Swivel Cuff (Black) 1½" 1 ea. 4.98 7 100343 Foam Filter Media for Dome Filter 1 ea. 1.22 101220 High Filtration Disk (Optional) 2/pk 9.99 8 100030 Dome Filter w/Foam Media 1 ea. 7.28 9 100586 Bottom Bumper 1 ea. 6.68 10 100641 Power Cord Assembly Complete w/Strain Relief 1 set 17.59 11 105748 Switch Cord Assembly Complete F/QuietPro 1 set 34.13 12 101472 Switch Box w/Velcro and Screws 1 set 21.83 13 105438 On/Off Switch 1 ea. 17.98 14 100368 Motor Mounting System Set: 3 Well Nuts, 3 Bolts, 3 Washers, 3 Covers 1 set 12.13 15 105643 Tetraseal, Motor 1 ea. 10.50 16 105722 Motor, (120V), 2-Stage (includes: #17) 1 ea. 89.25 105697 Carbon Brush Set for QuietPro Motor 1 set 19.40 17 105605 Gasket, Motor 1 ea. 5.78 18 105149 Cap, Motor 1 ea. 16.28 19 105763 Screw, 10-32 x .75, Self Tapping 4/pk. 2.63 20 105619 Motor Mount Assembly (includes: #17, 18, 19) 1 set 29.93 21 105653 Dual Speed Module and Schematic 1 ea. 55.65 22 105150 Exhaust Housing, Motor 1 ea. 12.60 23 105767 Screw, #8 x ½", Phillips, Hi/Lo 4/pk. 2.63 24 105422 Acoustical Insert, Left 1 ea. 23.10 25 105419 Acoustical Insert, Right 1 ea. 23.10 26 105337 Ring, Motor Housing, Large 1 ea. 12.86 27 105342 Foam, Ring, Motor Housing 1 ea. 15.75 28 105343 Foam, Cover, Motor Housing 1 ea. 11.03 29 105341 Cover, Motor Housing 1 ea. 10.76 30 105613 Motor Mount 1 ea. 6.30 31 100716 Backplate (Blk) Connection Set: 4 Screws w/Washers 1 set 12.13 32 100358 Shoulder Strap Plastic Adjustment (Top) 1 ea. .91 33 101737 Carry Handle w/Rivet and Washer Set 1 set 7.89 34 100356 Shoulder Strap Assembly: (includes: #32, 35) 1 set 15.77 35 100357 Shoulder Strap Plastic Adjustment (Bottom) 1 ea. .91 36 106719 Waist Belt Keeper and Latch 1 ea. 10.99 37 105046 Backplate Assembly (includes: #38) 1 set 24.26

103166 Backplate System Complete (includes: #31, 32, 33, 34, 35, 36, 37, 38, 39, 40) 1 set 60.64 100354 Strap Assembly Complete (includes: #32, 34, 35, 36, 39, 40) 1 set 48.51

38 100375 Barrel Nut Connection Set for Backplate (Replacement) 1 set 5.46 39 100359 Waist Belt (includes: #36, 40) 1 ea. 36.38 40 103627 Sternum Strap Buckles (Latch and Keeper) 1 set 1.94 41 105620 Housing, Exhaust, Motor F/QuietPro (includes: #22, 23) 1 set 29.93 42 105621 Kit, Foam, Laminate Acoustical Panels (includes: #24, 25) 1 set 38.33 43 105622 Kit, Exhaust, Foam and Ring (includes: #26, 27, 28) 1 set 33.60 44 105623 Kit, Cover, Exhaust F/QuietPro (includes: #29, 30) 1 set 15.75 101678 50' Extension Cord (Not Shown) 1 ea. 27.50

Page 20

QUARTERVAC PARTS

Page 21

QUARTERVAC PARTS

No. Product Name Qty List Price

1 104273 Twist Cap (Black) 1 ea. $26.68 2 100431 496 Sq. In. Intercept Micro Filter 10/pk 15.00 3 100564 Micro Cloth Filter 1 ea. 22.61 4 101737 Carry Handle w/Rivet and Washer Set 1 set 7.89 5 100356 Shoulder Strap Assembly (includes: #5a, 5b, 5c) 1 set 15.77 5a 100358 Shoulder Strap Plastic Adjustment Buckle (Top) 1 ea. .91 5b 100357 Shoulder Strap Plastic Adjustment Buckle (Bottom) 1 ea. .91 5c 103627 Sternum Strap Buckles (Latch and Keeper) 1 set 1.94 6 105046 Backplate (includes: #7) 1 ea. 24.26 7 100375 Barrel Nut Connection Set for Backplate (Replacement) 1 set 5.46 8 100716 Backplate (Black) Connection Set: 4 Screws w/Washers 1 set 12.13 9 106719 Waist Belt Keeper and Latch 1 ea. 10.99 10 100359 Waist Belt (includes: #9) 1 ea. 36.38

100354 Strap Assembly Complete (includes: #5, 9) 1 set 48.51 103166 Backplate (Black) System Complete (includes: #4, 5, 6, 7, 8, 9) 1 set 60.64

11 100641 Power Cord (18" 14/3) Assembly 1 set 17.59 12 101714 Switch Cord w/Crimps 1 set 12.13 101610 Switch Cord Assembly (includes: #12, 13, 14) 1 ea. 33.96 13 101472 Switch Box w/Velcro and New Lamb Switch 1 set 21.83 14 106066 On/Off Switch (must use with 106287) 1 ea. 6.60 106287 Switch Box w/Velcro and Screws 1 ea. 16.28 15 100698 Sound Mufﬂ er 1 ea. 21.83 16 100352 Plastic Air Diffuser w/Screw Set: 2 Screws 1 set 10.31 17 100335 Motor Compression Ring w/Screws 1 set 10.31 100378 Compression Ring Screws: 4 Screws 1 set 2.73 18 100014 Tetraseal 1 ea. 10.92 19 105697 Carbon Brush Set for QuarterVac Motor (Domel Motor) 1 set 19.40 101531 Carbon Brush Set for QuarterVac Motor (Ametek Motor) 1 set 19.40 20 105721

100379 Motor Ground Wire Clamp Set w/Screws 1 set 5.46 100380 Motor Crimp Set: 5 Female, 3 Male, Ground Crimp Connector 1 set 9.70

21 100586 Bottom Bumper 1 set 6.68 22 100368 Motor Mounting System Set: 3 Well Nuts, 3 Bolts, 3 Washers, 3 Covers 1 set 12.13 23 100030 Dome Filter w/Foam Media 1 ea. 7.28 24 100343 Foam Filter Media for Dome Filter 1 ea. 1.22 101220 High Filtration Disk (optional) 2/pk 9.99 25 103048 Static-Dissipating Hose (Black) w/Cuffs 1½" 1 ea. 23.05 26 101928 Replacement Double Swivel Elbow Cuff (Black) 1½" 1 ea. 8.38 27 100694 Replacement Swivel Cuff (Black) 1½" 1 ea. 4.98 28 103476 Thermal Protector 1 ea. 13.30

101678 50' Extension Cord (Not Shown) 1 ea. 27.50

Motor/Fan (120 V) w/Crimps 1 ea. 71.56

Page 22

TAILVAC PARTS

Page 23

TAILVAC PARTS

No. Product Name Qty List Price

1 101288 Blind Twist Cap Assembly (Grey) 1 ea. $26.68 2 101934 Twist Cap for Hose Cuff (Grey) 1 ea. 26.68 3 102784 Dome Filter w/Foam Media 1 ea. 7.28 4 101949 Foam Filter Media for Dome Filter 1 ea. 1.22 102761 High Filtration Disc (optional) 2/pk 10.19 5 100564 Micro Cloth Filter 1 ea. 22.61 6 100431 496 sq. in. Reusable Intercept Micro Filter 10/pk 15.00 7 101184 3’ to 1’ Stretch Hose w/Cuffs 1¼" (Black) 1 ea. 21.23 101705 3’ to 1’ Stretch Hose w/Cuffs 1½" (Black) 1 ea. 23.05 8 102878 Waist Belt w/Velcro® 1 ea. 49.56 103025 Retroﬁ t set: Waist Belt and Monostrap 1 set 57.18 9 101274 Waist Belt Connection Set: 4 Screws, 6 Washers, 2 Stand-offs 1 set 4.05 10 102879 Monostrap Assembly 1 ea. 18.20 11 102604 Shulte Cord Holder 1 ea. 8.11 12 101272 Step Cap Screw Kit: 4 Screws 1 set 3.03 13 101711 Shroud Retro Kit (Grey) w/2 Screws 1 ea. 24.26 14 103236 Motor Seal 1 ea. 6.07 15 101189 Motor/Fan (120 V) w/Crimps (Ametek) 1 ea. 81.78 16 102988 Carbon Brush Set for Motor (Ametek) 1 set 19.35 17 103043 Fan and Brush Cover Kit 1 ea. 17.59 18 101271 Motor Mount Screw Kit: 5 Screws, 4 Washers, 1 Nut 1 ea. 1.83 19 100950 Director Plate 1 ea. 9.54 20 101713 Power Cord (35” 18/2) Assembly Complete w/Strain Relief with Locknut and Washer 1 set 17.59 21 100743 Double Pole On/Off Switch 1 ea. 6.60 22 101228 Front Sound Foam Bafﬂ e 1 ea. 4.25 23 101229 Rear Sound Foam Bafﬂ e 1 ea. 3.64 24 103262 Step Cap (Grey) w/Power Nozzle Receptacle Hole w/Attached Front Sound Foam 1 set 30.32 25 101953 Receptacle Replacement Kit: 2 Rivets, 2 Washers, 1 Receptacle, 1 Connector and Wire Assembly, 2 Female Crimps 1 ea. 5.28 26 101437 Replacement Fixed Hose Cuff (Black) 1½" to 1¼" 1 ea. 5.17 101536 Replacement Fixed Hose Cuff (Black) 1½" 1 ea. 3.89 27 101436 100694 Replacement Swivel Cuff (Black) 1½" 1 ea. 4.98

101678 50' Extension Cord (Not Shown) 1 ea. 27.50

Replacement Swivel Cuff (Black) 1¼" 1 ea. 5.17

Page 24

PROVAC & AVIATIONVAC PARTS

Page 25

PROVAC & AVIATIONVAC PARTS

No. Product Name Qty List Price

1 104273 Twist Cap (Black) 1 ea. $ 26.68 2 100431 496 Sq. In. Intercept Micro Filter 10/pk 15.00 3 100564 Micro Cloth Filter 1 ea. 22.61 4 101737 Carry Handle w/Rivet and Washer Set 1 set 7.89 5 100356 Shoulder Strap Assembly (includes: #5a, 5b, 5c) 1 set 15.77 5a 100358 Shoulder Strap Plastic Adjustment (Top) 1 ea. .91 5b 100357 Shoulder Strap Plastic Adjustment (Bottom) 1 ea. .91 5c 103627 Sternum Strap Buckles (Latch and Keeper) 1 set 1.94 6 105046 Backplate (includes: #7) 1 ea. 24.26 7 100375 Barrel Nut Connection Set for Backplate (Replacement) 1 set 5.46 8 100716 Backplate (Black) Connection Set: 4 Screws w/Washers 1 set 12.13 9 106719 Waist Belt Keeper and Latch 1 ea. 10.99 10 100359 Waist Belt (includes: #9) 1 ea. 36.38

100354 Strap Assembly Complete (includes: #5, 9, 10) 1 set 48.51 103166 Backplate System Complete (includes: #4, 5, 6, 7, 8, 9, 10) 1 set 60.64

11 100641 Power Cord (18" 14/3) Assembly 1 set 17.59 12 101610 Switch Cord Assembly Complete (includes: #12, 13, 14) 1 set 33.96

101714 Switch Cord w/Crimps 1 ea. 12.13 101715 Switch Cord w/Crimps (AviationVac) 1 ea. 12.13 101717 Switch Cord Assembly Complete w/Switch and Box (AviationVac) 1 ea. 33.96

13 101472 Switch Box w/Velcro and New Lamb Switch 1 set 21.83 14 106066 On/Off Switch (Must be Used with 106287) 1 ea. 6.60 106287 Switch Box w/Velcro and Screws 1 ea. 16.28 15 105800 Sound Mufﬂ er 1 ea. 21.83 16 105044 Motor Shroud Cover with Screws (2 Screws) 1 set 20.79 17 100335 Motor Compression Ring w/Screws 1 set 10.31 100378 Compression Ring Screw Set: 4 Screws 1 set 2.73 18 100014 Tetraseal 1 ea. 10.92 19 105697 Carbon Brush Set for ProVac Motor (Domel Motor) 1 set 19.40

100424 Carbon Brush Set for ProVac Motor (Ametek Motor) 1 set 100173 Carbon Brush Set for 400 Hz Motor (AviationVac) 1 set 43.90 20 105720 Motor/Fan (120 V) w/Crimps for ProVac 1 ea. 83.69 100171 Motor/Fan w/Rectiﬁ er and Crimps (400Hz) (ProVac AviationVac) 1 set 115.22 100174 Motor Rectiﬁ er (ProVac AviationVac) 1 ea. 26.68 100379 Motor Ground Connection and Wire Clamp Set w/Screws 1 set 5.46 100380 Motor Crimp Set: 5 Female, 3 Male, Ground Crimp Connector 1 set 9.70

21 100586 Bottom Bumper 1 ea. 6.68 22 100368 Motor Mounting System Set: 3 Well Nuts, 3 Bolts, 3 Washers, 3 Covers 1 set 12.13 23 100030 Dome Filter w/Foam Media 1 ea. 7.28 24 100343 Foam Filter Media for Dome Filter 1 ea. 1.22 101220 High Filtration Disk (Optional) 2/pk 9.99 25 100505 Static-Dissipating Hose (Black) w/Cuffs 1½" 1 ea. 24.20 103237 Static-Dissipating Hose (AviationVac) 1¼" (Black) 1 ea. 24.20 26 100694 Replacement Swivel Cuff (Black) 1½" 1 ea. 4.98

102715 Replacement Double Swivel Elbow Cuff 1¼" (Black) (AviationVac) 1 ea. 8.43 103279 Replacement Swivel Cuff 1¼" (Black) (AviationVac) 1 ea. 6.18

27 103476 Thermal Protector 1 ea. 13.30 101678 50' Extension Cord (Not Shown) 1 ea. 27.50

15.77

Page 26

QUIETPRO CN HEPA PARTS

Page 27

QUIETPRO CN HEPA PARTS

No. Product Name Qty List Price

1 105991 On/Off Switch (2 Stage) 1 ea. $ 14.85 2 102784 Dome Filter w/Filter Media 1 ea. 7.28 3 101949 Replacement Foam Media for Dome Filter 1 ea. 1.22 102761 High Filtration Disk (Optional) 2/pk 10.19 4 103236 Motor Seal 1 ea. 6.07 5 106103 Motor/Fan (120V) for QuietPro CN HEPA w/Crimps 1 ea. 89.25 6 105697 Carbon Brush Set for QuietPro CN HEPA Motor (Domel Motor) 1 set 19.40 7 105430 Upper Foam Compression Ring 1 ea. 13.40 8 105949 Noise Supression Filter Assembly 1 ea. 19.43 9 105948 Noise Supression Foam 1 ea. 11.03 10 103121 Motor Mount 1 ea. 14.70 11 103266 Motor Mount and Vented Exhaust Cover Screw Kit 1 set 4.60 12 102127 Small Strain Relief 1 ea. .26 13 105653 Dual Speed Module F/Quiet Pro 1 ea. 55.65 14 103318 Top Cap, Black 1 ea. 31.53 15 104544 698 Sq. In. Intercept Micro Filter 10/pk 24.00 16 103115 Micro Cloth Filter 1 ea. 28.55 17 103125 Foam Inlet Damper B 1 ea. 8.63 18 103124 Foam Inlet Damper A 1 ea. 12.95 19 103256 Rear Foam Diffuser 1 ea. 9.98 20 103638 Replacement HEPA Filter Kit (includes: #11, 20, 29) 1 ea. 114.35 21 103117 Tool Dock 1 ea. 18.20 22 103441 Cord Lock 1 ea. 9.87 23 106203 Wire Harness Assembly: 3 Wires and Strain Relief 1 set 21.00 24 103545 Conical Washer for Swivel Caster 1 set 3.99 25 103114 Swivel Caster 1 ea. 10.36 26 106107 Ground Jumper 1 ea. 8.93 27 103268 Rear Wheel Mounting Screw Kit: 2 Screws 1 set 1.83 28 103267 Rear Wheel Assembly Kit: 2 Wheels, 2 Spacers, 2 Screws 1 set 12.94 29 103215 Power Cord (18" 16/3) Assembly w/Locknut and Washer 1 ea. 17.59 30 100694 Replacement Swivel Cuff (Black) 1½" 1 ea. 4.98 31 103172 78" Static Dissipating Hose w/Cuffs (Black) 1½" 1 set 31.53 32 103150 Replacement Long Swivel Cuff (Black) 1½" 1 ea. 10.35 101678 50' Extension Cord (Not Shown) 1 ea. 27.50

Page 28

PROCLEAN & PROCLEAN HEPA PARTS

Page 29

PROCLEAN & PROCLEAN HEPA PARTS

No. Product Name Qty List Price

1 103318 Top Cap, Black 1 ea. $ 31.53 2 104544 698 Sq. In. Intercept Micro Filter 10/pk 24.00 3 103115 Micro Cloth Filter 1 ea. 28.55 4 103669 On/Off Switch w/Splitters (includes: 2 ea. of #6) 1 ea. 16.97 5 103212 Wire Harness Assembly: 3 Wires and Strain Relief 1 set 10.12 6 103647 Split Jumpers 1 ea. 3.25 7 105047 Receptacle Assembly for Powerhead 1 ea. 6.25 8 103236 Motor Seal 1 ea. 6.07 8a 105430 Upper Foam Compression Ring 1 ea. 13.40 9 102784 Dome Filter w/Filter Media 1 ea. 7.28 10 101949 Replacement Foam Media for Dome Filter 1 ea. 1.22 102761 High Filtration Disk (Optional) 2/pk 10.19 11 105687 Motor/Fan (120V) for ProClean w/Crimps 1 ea. 109.15 12 105164 Carbon Brush Set for ProClean Motor (Domel Motor) 1 set 19.40 101720 Carbon Brush Set for ProClean Motor (Ametek Motor) 1 set 19.40 13 103121 Motor Mount 1 ea. 14.70 14 103117 Tool Dock 1 ea. 18.20 15 103266 Motor Mount and Vented Exhaust Cover Screw Kit 1 set 4.60 16 103215 Power Cord (18" 16/3) Assembly w/Locknut and Washer 1 ea. 17.59 17 103123 Exhaust Foam 1 ea. 14.97 18 103360 Cover Assembly, Vented Exhaust 1 ea. 28.88 19 103256 Rear Foam Diffuser 1 ea. 9.98

103124 Foam Inlet Damper A (not shown) 1 ea. 12.95 103125 Foam Inlet Damper B (not shown) 1 ea. 8.63

20 103267 Rear Wheel Assembly Kit: 2 Wheels, 2 Spacers, 2 Screws 1 set 12.94 21 103268 Rear Wheel Mounting Screw Kit: 2 Screws 1 set 1.83 22 103114 Swivel Caster 1 ea. 10.36 23 103545 Conical Washer for Swivel Caster 1 set 3.99 24 103172 78" Static Dissipating Hose w/Cuffs (Black) 1½" 1 set 31.53 25 100694 Replacement Swivel Cuff (Black) 1½" 1 ea. 4.98 26 103150 Replacement Long Swivel Cuff (Black) 1½" 1 ea. 101678 50' Extension Cord (Not Shown) 1 ea. 27.50 27 103638 Replacement HEPA Filter Kit (includes: #15, 16, 27) 1 ea. 114.35 28 103476 Thermal Protector 1 ea. 13.30

10.35

Page 30

LINEVACER PARTS

Page 31

LINEVACER PARTS

No. Product Name Qty List Price

1 104276 Latch Cap w/Cuff (Black) 1 ea. $ 35.78 2 100291 698 Sq. In. Intercept Micro Filter 10/pk 29.95 3 100565 Micro Cloth Filter 1 ea. 27.37 4 100286 Top or Bottom Cap Latch Set: 3 Latches, 3 Locks w/6 Fastening Rivets, 6 Washers 1 set 22.24 5 101737 Carry Handle w/Rivet and Washer Set 1 set 7.89 6 100356 Shoulder Strap Assembly (includes: #7a, 7b, 7c) 1 set 15.77 7 105046 Backplate (includes: #8) 1 ea. 24.26 7a 100358 Shoulder Strap Plastic Adjustment (Top) 1 ea. .91 7b 100357 Shoulder Strap Plastic Adjustment (Bottom) 1 ea. .91 7c 103627 Sternum Strap Buckles (Latch and Keeper) 1 set 1.94 8 100375 Barrel Nut Connection Set for Backplate (Replacement) 1 set 5.46 9 100374 Backplate Connection Set: 4 Screws w/Washers, Stand Offs 1 set 12.13 10 106719 Waist Belt Keeper and Latch 1 ea. 10.99 11 100359 Waist Belt (includes: #10) 1 ea. 36.38

100354 Strap Assembly Complete (includes: #6, 7, 10) 1 set 48.51 103166 Backplate System Complete (includes: #5, 6, 7, 8, 9, 10) 1 set 60.64 12 100641 Power Cord (18" 14/3) Assembly Complete 1 set 17.59 100299 15' Cart power Supply Cord Complete w/Crimps (100279, 100282) 1 set 36.38 13 101610 Switch Cord Assembly 120V (includes: #13, 14, 15) 1 set 33.96 101714 Switch Cord w/Crimps 1 ea. 12.13 101716 26" Switch Cord Assembly Complete 120V 1 set 36.38 14 101472 Switch Box w/Velcro and New Lamb Switch 1 set 21.83 101718 Switch Box w/Belt Clip (for cart) (100279, 100282) 1 set 24.26

15 106066 On/Off Switch (must use with #106287) 1 ea. 6.60 106287 Switch Box w/Velcro and Screws 1 ea. 16.28 16 104275 ULPA Filter Assembly Complete w/Bottom Cap (100280, 100282) 1 set 266.81 17 104274 HEPA Filter Assembly Complete w/Bottom Cap (100277, 100279) 1 set 224.36 18 100335 Motor Compression Ring w/Screws 1 set 10.31 100378 Compression Ring Screw Set: 4 Screws 1 set 2.73 19 100014 Tetraseal 1 ea. 10.92 20 105697 100424 Carbon Brush Set for LineVacer Motor (Ametek Motor) 1 set 15.77 21 105720 Motor/Fan (120 V) w/Crimps 1 ea. 83.69

100380 Motor Crimp Set: 5 female, 3 Male and a Ground Crimp Connector 1 set 9.70 100379 Motor Ground, Wire Clamp Set w/Screws 1 set 5.46

22 100368 Motor Mounting System Set: 3 Well Nuts, 3 Bolts, 3 Washers, 3 Covers 1 set 12.13 23 100030 Dome Filter w/Foam Media 1 ea. 7.28 24 100343 Foam Filter Media for Dome Filter 1 ea. 1.22 25 103048 Static-Dissipating Hose w/Cuffs (Black) 1 ea. 23.05 26 101928 Replacement Double Swivel Elbow Cuff (Black) 1 ea. 8.38 27 100694 Replacement Swivel Cuff (Black) 1½" 1 ea. 4.98 28 100718 Cart Plate for Cart Assembly 1 ea. 20.01 29 100287 LineVacer Cart Assembly Complete 1 set 209.00 30 103476 Thermal Protector 1 ea. 13.30

101678 50' Extension Cord (Not Shown) 1 ea. 27.50

Carbon Brush Set for LineVacer Motor (Domel Motor) 1 set 19.40

Page 32

PROFORCE 1500XP PARTS

No. Product Name Qty List Price

1 104234 Cover, Bag Housing, Grey F/XP 1 ea. $15.75

2 104232 Latch, Release, Bag Cover 1 ea. 4.20

3 104233 Spring, Release Button, F/Bag Cover Latch 2/pk 2.10

4 104235 Seal, Transition Duct/Bag Cover, Upper 1 ea. 3.15

5 104236 Duct, Transition, Bag Cover, F/XP 1 ea. 6.30

6 104238 Seal, Transition Duct/Bag Cover Nozzle Plate, Lower 1 ea. 2.10

7 104239 Plate, Bag Cover Nozzle, F/XP 1 ea. 4.91

8 104242 Spring, Bag Cover Latch 1 ea. 3.15

9 104243 Plate, Bag Cover Latch 1 ea. 2.31

10 104505 Screw, Phillips, 4.2mm x 9.5mm 2/pk 2.10

11 1042 41 Gasket, Bag Cover 1 ea. 2.31

12 10 4 493 Screw, Phillips, 4.2mm x 38mm 4/pk 3.15

13 10 5486 Filter Cover Kit w/Riveted Hinge and 6 Rivets

(includes: #1–12) 1 kit 41.58

14 104490 Bag Housing Assembly, Grey w/Riveted Hinge

& Decal Includes Bag Cover Nozzle Plate 1 ea. 37.80

15 10 4491 Rivet F/Bag Housing Assembly 6/pk 3.15

16 104255 Handle w/Over Mold and Decal 1 ea. 21.00

17 1042 8 4 Cord, Power, w/Strain Relief, 50' Yellow 1 ea. 32.34

18 103483 Intercept Micro Filter 10/pk 9.99

19 10508 8 Handle Bezel w/Screws 1 ea. 7. 51

20 104738 Seal, Gasket, Bag Housing 1 ea. 2.31

21 104283 Switch, Filter, Lock-Out 1 ea. 9. 82

22 104281 Filter, Double Layer Motor Intake 1 ea. 2.58

23 104282 Cover, Switch, Filter Lock-out 1 ea. 2.31

24 104268 Bracket, Cord Wrap 1 ea. 4.20

25 104269 Spring, Compression, Cord Wrap Bracket 1 ea. 2.31

26 104270 Washer, Compression Spring, Cord Wrap Bracket 1 ea. 1.05

27 105147 Switch, Rocker, On/Off 1 ea. 12.60

28 104264 Bushing, Handle Tube 1 ea. 1.16

29 104259 Plate, Handle Nut 1 ea. 1.16

30 104265 Handle, Carry w/Tool Caddy, F/XP 1 ea. 5.25

31 10 42 94 Wand, F/XP 1 ea. 13.8 6

32 105091 Clasp, Strain Relief Kit w/Fastner, Yellow 1 ea. 5.78

33 104271 Screw, Cord Wrap, 4mm x 35mm, Phillips Round Head 1 ea. 2.10

34 104509 Screw, Phillips, M4 x 10mm x .07 Pitch,

F/Handle Assembly 1 ea. 2.10

35 105075 Screw, Phillips, 2.9mm x 13mm, F/Switch Cover 1 ea. 3.75

36 104266 Screw, Handle Assembly 1 ea. 1.16

37 104493 Screw, Phillips, 4.2mm x 35mm 4/pk 3.15

38 104958

39 104959 Handle, Tube Assembly Complete, F/XP

(includes: #16, 19, 24, 25, 26, 27, 28, 33, 34, 38) 1 ea. 57.17

40 104961 Hose, Assembly w/Cuffs, F/XP (includes: #42) 1 ea. 40.43

41 105502 Handle Kit (includes: #16, 19, 24, 25, 26, 27, 33, 34) 1 kit 37.80

42 105573 Quick Release Hose Cuff 1 ea. 8.94

Handle, Tube w/Wire Harness, Rivet Nut and Plug Rivet

1 ea. 25.41

Page 33

PROFORCE 1500XP PARTS

No. Product Name Qty List Price

1 104209 Screw, Phillips, 4.2mm x 12mm F/Wand Guide 2/pk $2.50

2 104261 Guide, Wand, Upper Left 1 ea. 3.15 3 104260 Guide, Wand, Upper Right 1 ea. 3.15 4 104263 Switch, Wand Lockout 1 ea. 6.93 5 104245 Bulkhead, Dark Grey 1 ea. 7. 92 6 104253 Seal, Lower Air Duct , Nitrile 1 ea. 1.16 7 104267 Screw, Phillips, 4.2mm x 19mm F/Lower Air Duct 2/pk 3.50 8 104250 Air Duct Assembly 1 ea. 9. 82 9 104536 Motor Housing, Charcoal 1 ea. 25.20

10 104504 Bearing, Pivot 2/pk 3.15 11 10430 6 Wheel, Rear 2/pk 11.55 12 10 5136 Filter, Exhaust, HEPA Media 1 ea. 6.30

13 10 424 6 Cover, Filter Cartridge, Charcoal 1 ea. 4.73 14 103532 Foam, Sound, Motor Housing, Front Panel 1 ea. 4.91 15 103533 Foam, Sound, Motor Housing, Left Panel 1 ea. 2.89 16 103531 Foam, Sound, Motor Housing, Rear Panel 1 ea. 6.93 17 104247 Motor Mount, Lower Nitrile 1 ea. 5.78 18 104249 Motor Mount, Upper Nitrile 1 ea. 9.82 19 104957 Motor Assembly w/Jumpers (includes: A, B) 1 kit 69.30 20 105488 Motor Housing Sound Filter (includes: #14,15,16) 1 kit 13 .86 21 105490 Wand Kit (includes: #1, 2, 3, 4) 1 kit 9.24 22 105489 Air Duct Kit (includes: #6, 7, 8) 1 kit 10.40 23 104494 Power Nozzle Cover w/Detent Springs & Decal 1 ea. 25.74 24 104279 Switch, Safety, Power Nozzle Lockout 1 ea. 7.13 25 104212 Circuit Breaker 1 ea. 11. 6 6 26 104496 Screw, Phillips, 2.9mm x 35mm, F/Brush Retainer 4/pk 2.50

27 104499 Retainer, Brush Roll 2/pk 2.31 28 104216 Brush Roll, Power Nozzle, 14" 1 ea. 26.25 29 104218 Bumper, Power Nozzle, Vinyl 1 ea. 6.30 30 104500 Brace, Formed Wire, F/Power Nozzle Base 2/pk 2.31 31 104221 Baseplate, Power Nozzle 1 ea. 29.40 32 104497 Screw, Phillips, 4.2mm x 35mm F/Base Cover 8/pk 3.15 33 104501 Roller, Front 2/pk 4.20 34 104502 Shaft, Front Roller Axle 2/pk 2.31 35 104503 Clamp, Rear Wheel 1 set 4.04 36 104495 Screw, Phillips, 4.2mm x 19mm F/Powerhead 5/pk 3.15 37 104227 Sleeve, Hose, Air Duct 1 ea. 2.31 38 104230 Hose, Power Nozzle to Air Duct, Lower 1 ea. 3.30 39 104217 Belt, Drive, F/Brush Roll 1 ea. 5.25 40 104506 Motor, Power Nozzle with Crimps 1 ea. 47.25 41 104498 Grommet, Vibration, Power Nozzle Motor, Nitrile 2/pk 2.31 42 104224 Cover, Air Duct, Power Nozzle 1 ea. 4.34 43 104226 Board, Vacuum Operation Indicator 1 ea. 8.40 44 104507 Spring, Detent, Upright Lock 2/pk 3.15 45 105371 Screw, Phillips, 4.2mm x 19mm, F/Power Nozzle Motor 2/pk 2.10 46 105281 Carbon Brush Set for ProForce Motor 1 set 19.40 47 105760 Thermal Protector 1 ea. 8.66

105754 Wire Harness Kit includes: 1 set 29.93 A. Harness, Jumper, Red B. Harness, Jumper, White C. Sensor, Bag Full Indicator D. Harness, Main Power Supply E. Harness, Wire, Power Nozzle F. Harness, Power Nozzle Switch

Page 34

PROFORCE 1500 PARTS

No. Product Name Qty List Price

1 104569 Cover, Bag Housing, Grey 1 ea. $15.75

2 104570 Plate, Bag Cover Nozzle 1 ea. 5.25

3 104571 Duct, Crossover, Bag Cover 1 ea. 7. 51

4 104574 Plug, Access Port 1 ea. 3.14

5 104575 Seal, Crossover Duct/Bag Cover Nozzle Plate, Lower 1 ea. 2.10

6 104576 Seal, Crossover Duct, Inlet 1 ea. 2.10

7 104232 Latch, Release, Bag Cover 1 ea. 4.20

8 104243 Flex Plate, Bag Cover Latch 1 ea. 2.31

9 104241 Seal, Gasket, Bag Cover 1 ea. 2.31

10 104233 Spring, Release Button, F/Bag Cover Latch 2/pk 2.10

11 104242 Spring, Bag Cover Latch 1 ea. 3.15

12 10 4577 Screw, Phillips, 4.2mm x 9.5mm 4/pk 2.10

13 10 4 493 Screw, Phillips, 4.2mm x 38mm 4/pk 3.15

14 105491 Filter Cover Kit, w/Riveted Hinge and

6 Rivets (includes: #1-13) 1 kit 36.96

15 10 4739 Bag Housing Assembly, Grey, w/Riveted Hinge

and Decal Includes Bag Cover Nozzle Plate 1 ea. 37.80

16 104 491 Rivet F/Bag Housing Assembly 6/pk 3.15

17 1042 55 Handle w/Over Mold and Decal 1 ea. 21.00

18 104284 Cord, Power Clasp, 50' Yellow (includes: #34) 1 ea. 32.34

19 103483 Intercept Micro Filter 10/pk 9.9 9

20 104281 Filter, Motor Intake 1 ea. 2.58

21 104738 Seal, Gasket, Bag Housing 1 ea. 2.31

22 104283 Switch, Filter, Lock-Out 1 ea. 9. 82

23 104282 Cover, Switch, Filter Lock-out 1 ea. 2.31

24 105075 Screw, Phillips, 2.9mm x 13mm, F/Switch Cover 1 ea. 3.75

25 104509 Screw, Phillips, F/Handle Assembly

M4 x 10mm x .07 Pitch 1 ea. 2.10

26 104268 Bracket, Cord Wrap 1 ea. 4.20

27 104269 Spring, Compression, Cord Wrap Bracket 1 ea. 2.31

28 104270 Washer, Compression Spring, Cord Wrap Bracket 1 ea. 1.05

29 104271 Screw, Cord Wrap, 4mm x 35mm

Phillips Round Head 1 ea. 2.10

30 105090 Handle Bezel w/Screws 1 ea. 7. 51

31 10 4741 Handle, Carry 1 ea. 4.62

32 105114 Handle, Tube Assembly Complete

(includes: #17, 25, 26, 27, 28, 29, 30, 36, 38, 39) 1 kit 57.17

33 1042 59 Plate, Handle Nut 1 ea. 1.16

34 105091 Clasp, Strain Relief, Yellow 1 ea. 5.78

35 104493 Screw, Phillips, 4.2mm x 35mm 4/pk 3.15

36 104958

37 10426 6 Screw, Handle Assembly 1 ea. 1.16

38 105147 Switch, Rocker, On/Off 1 ea. 12 .60

39 104264 Bushing, Handle Tube 1 ea. 1.16

40 105501 Handle Kit

(includes: #17, 25, 26, 27, 28, 29, 30, 38) 1 kit 37.80

Handle, Tube w/Wire Harness, Rivet Nut and Plug Rivet

1 ea. 25.41

Page 35

PROFORCE 1500 PARTS

No. Product Name Qty List Price 1 104306 Wheel, Rear 2/pk $11.55 2 104250 Air Duct Assembly 1 ea. 9. 82

3 104957 Motor Assembly Kit w/Jumpers (includes: C, D) 1 ea. 69.30

4 104504 Bearing, Pivot 2/pk 3.15 5 103532 Foam, Sound, Motor Housing Front Panel 1 ea. 4.91 6 104536 Motor Housing, Charcoal 1 ea. 25.20 7 103533 Foam, Sound, Motor Housing Left Panel 1 ea. 2.89

8 103531 Foam, Sound, Motor Housing Rear Panel 1 ea. 6.93 9 104245 Bulkhead, Dark Grey 1 ea. 7. 92 104253 Seal, Lower Air Duct , Nitrile 1 ea. 1.16

11 1042 4 9 Motor Mount, Upper Nitrile 1 ea. 9. 82

12 10 4247 Motor Mount, Lower Nitrile 1 ea. 5.78

13 10 5136 Filter, Exhaust, HEPA Media 1 ea. 6.30 14 104246 Cover, Filter Cartridge, Charcoal 1 ea. 4.73 15 10 4578 Air Duct, Upper ProForce 1500 1 ea. 6.30

16 104209 Screw, Phillips, 4.2mm x 12mm, F/Upper Air Duct 2/pk 2.50 17 104267 Screw, Phillips, 4.2mm x 19mm F/Lower Air Duct 2/pk 3.50 18 1054 88 Motor Housing Sound Filter Kit (includes: #5, 7, 8) 1 kit 13. 86 19 105 489 Air Duct Kit (includes: #2, 10, 17) 1 kit 10.40 20 104494 Power Nozzle Cover w/Detent Springs & Decal 1 ea. 25.74 21 104279 Switch, Safety, Power Nozzle Lockout 1 ea. 7.13 22 104212 Circuit Breaker 1 ea. 11.66

23 104496 Screw, Phillips, 2.9mm x 13mm, F/Brush Retainer 4/pk 2.50 24 104499 Retainer, Brush Roll 2/pk 2.31 25 104216 Brush Roll, Power Nozzle, 14" 1 ea. 26.25 26 104218 Bumper, Power Nozzle, Vinyl 1 ea. 6.30 27 104500 Brace, Formed Wire, F/Power Nozzle Base 2/pk 2.31 28 104221 Baseplate, Power Nozzle 1 ea. 29.40 29 104497 Screw, Phillips, 4.2mm x 35mm F/Base Cover 8/pk 3.15 30 104501 Roller, Front 2/pk 4.20 31 10 45 02 Shaft, Front Roller Axle 2/pk 2.31

32 104503 Clamp, Rear Wheel 1 set 4.04 33 104 495 Screw, Phillips, 4.2mm x 19mm, F/Powerhead 5/pk 3.15 34 104227 Sleeve, Hose, Air Duct 1 ea. 2.31 35 104230 Hose, Power Nozzle to Air Duct, Lower 1 ea. 3.30 36 104217 Belt, Drive, F/Brush Roll 1 ea. 5.25 37 104506 Motor, Power Nozzle with Crimps 1 ea. 47.25 38 104498 Grommet, Vibration, Power Nozzle Motor, Nitrile 2/pk 2.31 39 104224 Cover, Air Duct, Power Nozzle 1 ea. 4.34 40 104226 Board, Vacuum Operation Indicator 1 ea. 8.40 41 104507 Spring, Detent, Upright Lock 2/pk 3.15 42 105371 Screw, Phillips, 4.2mm x 19mm, F/Power Nozzle Motor 2/pk 2.10 43 105281 Carbon Brush Set for ProForce Motor 1 set 19.40 44 105760 Thermal Protector 1 ea. 8.66

105755 Wire Harness Kit includes: 1 set 29.93 A. Sensor, Bag, Full Indicator B. Harness, Wire, Main Power Supply

C. Harness, Jumper, White D. Harness, Jumper, Red

E. Harness, Wire, Power Nozzle F. Harness, Power Nozzle Switch

Page 36

GOCARTVAC PARTS

Page 37

GOCARTVAC PARTS

No. Product Name Qty List Price

1 104273 Twist Cap (Black) 1 ea. $26.68 2 100431 496 Sq. In. Intercept Micro Filter 10/pk 15.00 3 100564 Micro Cloth Filter 1 ea. 22.61 4 106282 Power Cord Replacement, Complete 1 ea. 60.90 5 100352 Plastic Diffuser w/Connection Screw Set (2 screws) 1 set 10.31 6 100335 Compression Ring w/Connection Screws 1 set 10.31 100378 Compression Ring Connection Screws 1 set 2.73 7 100014 Tetraseal 1 ea. 10.92 103731 Carbon Brush Set for 36V motor 1 set 17.22 8 103732 36V Motor w/Crimps, Replacement 1 set 189.00 103617 Complete 36V Motor Assembly w/Seal, Compression Ring 1 set and Relay (includes: #6, 7, 8, 9) 230.42 9 105496 Battery Control Module 1 ea. 73.50 10 100368 Motor Mounting System Set 1 set 12.13 11 103916 Receptacle, 2-Wire w/Crimps 1 ea. 6.51 12 104272 Receptacle Screw Set 1 set 2.10 13 100030 Dome Filter w/Foam Media 1 ea. 7.28 14 100343 Foam Filter Media for Dome Filter 1 ea. 1.22 101220 High Filtration Disk (Optional) (2 pack) 2/pk 9.99 15 103623 Electriﬁ ed Hose, 1¼" x 20' Long, 2-Wire 1 ea. 197.61 16 102715 Replacement Swivel Elbow Cuff, Black 1 ea. 8.43 17 106550 Switch Replacement 1 ea. 8.40 18 106284 Kit, Vacuum Attachment Hardware for Cart 1 ea. 2.63 19 106219 Kit, Power Receptacle Cord 1 set 13.91 20 106211 Box, Sound w/Corner Rails 1 set 362.25 21 106213 Cart Assembly 1 ea. 399.98 22 106214 Kit, Mounting Hardware 1 set 16.01 23 103718 Hose Wrap, Blk 1 ea. 21.00 24 106241 Kit, Receptacle for Box Assembly 1 ea. 8.93 25 106215 Kit, Box Assembly 1 set 117.60 26 106277 Harness, Charging w/Connectors 1 ea. 78.75 27 106216 Kit, Battery Wiring Harness 1 set 84.80 28 106280 Lead, Wire, Battery, Fusible Link, Replacement #8AWG, w/Terminals 1 ea. 31.50 29 106279 30 106278 Harness, Battery 1 ea. 50.40 31 106217 Kit, Receptacle 1 set 55.65 32 106281 Switch Assembly w/Crimps 1 ea. 36.75 33 106218 Kit, Charger, 36V, 18.5A, w/Terminals 1 ea. 682.50 34 106276 Battery, Lead Acid, 12V, 37AH 1 ea. 252.00 35 106283 Kit, Attachment Hardware for Charger and Box Assembly 1 ea. 2.63 36 103476 Thermal Protector 1 ea. 13.30 37 106297 Wheel Set, Rear 1 set 99.75 38 106298 Wheel Set, Front 1 ea. 23.10 101678 50' Extension Cord (Not Shown) 1 ea. 27.50

Lead, Wire, Battery, Red, #8AWG, w/Terminals 1 ea. 23.10

Page 38

INDEX INDEX

Part No. Product Name Page No(s).

100014 Tetraseal 11, 13, 15, 19, 23, 29

100030 Dome Filter w/ Foam Media 13, 15, 17, 19, 23, 29

100077 Kit C. with 11" Floor Tool w/Adjustable Brush (100083) 2, 3

100078 Kit A. with 14" Floor Tool w/Scallops (100147) 2, 3

100079 Kit D. 16" Floor Tool w/Adjustable Brush (100092) 2, 3

100082 Chrome Telescoping Wand – 24" to 40" 3, 4, 5

100083 Kit C. with 11" Floor Tool w/Adjustable Brush 3, 6, 8

100084 Replacement Brush – 11" Floor Tool (100083) 8

100085 Adjustment Lever – 11" Floor Tool (100083) 8

100090 Standard 1.25" Attachment Kit 2, 3

100091 Standard 1.25" Attachment Kit with Turbo Brush 2, 3

100092 Kit D. 16" Floor Tool w/Adjustable Brush 3, 6, 8

100093 Replacement Brush – 16" Floor Tool (100092) 8

100094 Adjustment Lever – 16" Floor Tool (100092) 8

100096 Brush Height Adjustment Knob – 11" – 16" Floor Tools (100083/100092) 8

100097 Screw – 11" – 16" Floor Tools (100083/100092) 8

100098 Spring – 11" – 16" Floor Tools (100083/100092) 8

100099 Replacement Nut – Aluminum Wands 8

100100 Replacement Ring – Aluminum Wands 8

100101 Replacement Sleeve – Aluminum Wands 8

100102 One -Piece, Two-Bend Aluminum Wand – 56" 3, 5

100104 60" Straight Extension Aluminum Wand 5

100107 Crevice Tool – 11" 4, 5

100108 Crevice Tool – 17" 3, 4, 5

100109 28" Crevice Tool 4, 5

100110 Dust Brush – 3" 3, 4, 5, 8

100112 Reducer – 3" Dust Nylon Brush (100110) 8

100113 1" to 4" Overhead Pipe Cleaner (Includes Reducer Cuff ) 5

100114 4" to 8" Overhead Pipe Cleaner (Includes Reducer Cuf f) 5

100115 Upholster y Tool – 5" 3, 4, 5, 8

100116 Replacement Nylon Brush – 5" Upholstery Tool 8

100117 11" Turbo Brush Tool – 1.25" 3, 6

100135 Turbo Brush with Wand 3

100136 54" One-Bend Chrome Tapered Wand – 1.5" to 1.25" 3, 5

100141 Replacement Bumper – 14" Floor Tool (100147) 8

100143 14" Hard Floor Tool w/Felt Brush 6, 8

100144 14" Floor Tool w/Felt Brush/Scalloped 4, 6, 8

100145 Replacement Felt – 14" Floor Tool (100143) 8

100146 Replacement Felt, Scalloped – 14" Floor Tool (100614) 8

100147 14" Floor Tool w/Scallops 3, 4, 6, 8

100150 36" One -Bend Bulk Pick-Up Tool 4, 5

100151 42" One-Bend Bulk Pick-Up Tool 5

100155 12" Gulper Aluminum Floor Tool 6

100163 High Filtration Vac 1.5" Kit 2, 4

100167 Curved Chrome Wand – 1.25" x 13" 3, 4, 5

100171 Motor/Fan w / Re ct iﬁ er and Crimps (400Hz) (ProVac AviationVac) 23

100173 Carbon Brush Set for 400 Hz Motor (AviationVac) 23

100174 M otor Rectiﬁ er (ProVac AviationVac) 23

100180 Demo Dufﬂ e Bag 9

100181 CoachVac 2

100197 Twist Cap ( Purpl e) 11

100277

100279 LineVacer HEPA Cart w/High Filtration Vac Kit (100163)

LineVacer HEPA w/High Filtration Vac Kit (100163) 2, 29

2, 29

Part No. Product Name Page No(s).

100280 LineVacer ULPA w/High Filtration Vac Kit (100163) 2, 29

100282 LineVacer ULPA Cart w/High Filtration Vac Kit (100163) 2, 29

100286 Top or Bottom Cap Latch Set 29

100287 LineVacer Cart A ssembly Complete 29

100291 Intercept Micro Filters 7, 29

100299 15' Cart power Supply Cord Complete w/Crimps 29

100315 MegaVac 2

100320 Twist Cap (Black) 13

100331 698 Sq. In. I Intercept Micro Filters 7, 11, 13

100335 Motor Compression Ring w/Screws 11, 13, 15, 19, 23, 28, 35

100343 Foam Filter Media for Dome Filter 11, 13, 15, 17, 19, 23, 29

100352 Plastic Air Diffuser w/Screw Set 19, 35

100354 Strap Assembly Complete 11, 13, 15, 17, 19, 23, 29

100356 Shoulder Strap Assembly 11, 13, 15, 17, 19, 23, 29

100357 Shoulder Strap Plastic Adjust. Buckle (Bottom) 11, 13, 15, 17, 19, 23, 29

100358 Shoulder Strap Plastic Adjustment Buckle (Top) 11, 13, 15, 17, 19, 23, 29

100359 Waist Belt 11, 13, 15, 17, 19, 23, 29

100360 Waist Belt Extension (10" ) 9

100361 Waist Belt Extension (18") 9

100368 Motor Mounting System Set 11, 13, 15, 17, 19, 23, 29, 35

100374 Backplate Connection Set 13, 29

100375 Barrel Nut Connection Set for Backplate (Replacement) 11, 13, 15, 17, 19, 23, 29

100376 Water Lift Gauge 9

100378 Compression Ring Screw Set 11, 13, 15, 19, 23, 29, 35

100379 Motor Ground and Wire Clamp Set w/Screws 11, 13, 15, 19, 23, 29

100380 Motor Crimp Set : 5 Female, 3 Male, Ground Crimp Connector 11, 13, 15, 19, 23, 29

100424 Carbon Brush Set for Coach Vac Motor (Ametek Motor) 11, 23, 29

100431 Reusable Intercept Micro Filters 7, 15, 17, 19, 1, 23, 35

100505 Static-Dissipating Hose (Black) w/Cuffs 1½" 23

100564 Micro Cloth Filter 7, 15, 17, 19, 21, 23, 35

100565 Micro Cloth Filter 7, 11, 13, 29

100586 Bottom Bumper 11, 15,17, 19, 23

100597 S ound Mu fﬂ er 7, 11, 13

100614 14" Hard Floor Tool w/Horse Hair Brush 4, 6, 8

100 617 Pr oVac 2

100623 14" Hard Floor Tool w/Nylon Brush 4, 6, 8

100628 How to Be a Vacuum Specialist 9

100629 How to Be a Restroom Specialist 9

100630 How to Coach a Successful Team 9

100641 Power Cord (18" 14/3) Assembly 11, 13, 15, 17, 19, 23, 29

100643 CoachVac w/Attachment Kit B (101336) 2

100650 Kit E. with 14" Floor Tool w/Scallops (100147) 3

100653 SuperCoach w/Attachment Kit B (101336) 2

100657 MegaVac w/Attachment Kit B (101336) 2

100 667 Linevacer 2

100694 Replacement Swivel Cuff (Blk) 1½" 11, 13, 15, 17, 19, 21, 23, 25, 27, 29

100 698 So und Mufﬂ er 7, 19

100707 CoachVac w/Attachment Kit C (100 077) 2

100708 CoachVac w/Attachment Kit D (100079) 2

100709 SuperCoach w/Attachment Kit D (100079) 2

100710 Super CoachVac w/Attachment Kit C (100077) 2

100711 Kit G. with 11" Floor Tool w/Adjustable Brush (100083) 3

100712 Kit H. with 16" Floor Tool w/Adjustable Brush (100092) 3

100713 Replacement Nylon Brush 8

100714 Replacement Horse Hair Brush 8

Page 39

INDEX INDEX

Part No. Product Name Page No(s).

100716 Backplate (Blk) Connection Set 11, 15, 17, 19, 23

100717 MegaVac w/Attachment Kit D (100079) 2

100718 Cart Plate for Cart Assembly 29

100719 Log o B anner 9

100727 Restaurant 1½" Kit 2, 4

100729 ProVac w/Restaurant Kit (100727) 2

100730 12" Paddle Floor Tool 6

100743

100829 ProVac w/Attachment Kit A (100078) 2

100946 27" Straight Bulk Pick-Up Tool 5

100950 Director Plate 21

101092 Red uc er Cuf f 3, 8

101122 How to Be a Light Duty Specialist 9

101155 Replacement Nylon Brush 8

101163 Qu ar te rVac 2

101164 QuarterVac w/Standard 1¼" Kit (100090) 2

101184 3-1 Stretch Hose w/ Cuffs 1¼" 21

101189 Motor/Fan (120V) with Crimps/Thermal Protector 21

101220 High Filtration Disk (Optional) 7, 11, 13, 15, 17, 19, 23, 35

101228 Front Sound Foam Bafﬂ e 21

101229 Rear Sound Foam Bafﬂ e 21

101245 QuarterVac w /Attachment Kit B (101336) 2

101247 QuarterVac w/Attachment Kit C (100077) 2

101248 QuarterVac w/Attachment Kit D (100079) 2

101250 QuarterVac w/Turbo Brush 1¼” Kit (100091) 2

101271 Motor Mount Screw Kit: 6 Screws, 4 Washers 21

101272 Step Cap Screw Kit: 4 Screws 21

101274 Waist Belt Connection Set 21

101288 Blind Twist Cap Assembly (Grey) 21

101292 Tail Vac 2

101293 TailVac w/Standard 1¼" Kit 2

101324 TailVac Standard 1¼" Kit 2, 3

101336 Kit B. with 14" E-Z Glide Floor Tool w/Brush (101446) 2, 3

101337 Kit F. with 14" E-Z Glide Floor Tool w/Brush (101446) 3

101338 Two-Piece, Two-Bend Aluminum Wand – 56" 3, 4, 5

101346 TailVac Standard 1¼" Attachment Kit with Turbo Brush 3

101394 Ergonomic Wand Handles 9

101436 Replacement Swivel Cuf f (Black) 1¼" 21

101437 Replacement Fixed Hose Cuf f (Black) 1½" x 1¼" 21

101445 Retro Kit – 14" E-Z Glide® Floor Tool 8

101446 14" E-Z Glide w/ Nylon Brush 3, 6

101472 Switch Box w/Velcro and New Lamb Switch 11, 13, 15, 17, 19, 23, 29

101473 Repair Clip with Screws – 14" Hard Floor Tool 8

101475 Repair Kit – Felt Floor Tools: Suppor t Bars 8

101528 TailVac w/Attachment Kit C, 1½" Hose (100077) 2

101529 MegaVac w/Attachment Kit C (100077) 2

101531 Carbon Brush Set for QuarterVac Motor (A metek Motor) 19

101532 ProDuster 50 sleeves 9

101533 ProDuster 50 0 sleeves 9

101536 Replacement Fixed Hose Cuf f (Black) 1½" 21

101543 Filter Guard 11, 13

101548 QuarterVac w/Attachment Kit A 2

101549 CoachVac w/Attachment Kit A 2

101550 TailVac w/Attachment Kit B, 1½" hose 2

101610 Switch Cord Assembly 11, 13, 15, 19, 23, 29

101613 JetSweep 20, 20” Hard Floor Tool w/Nylon Brush 4, 6

On/Off Switch 21

Part No. Product Name Page No(s).

101615 Replacement Blue Bumper for JetSweep 20 8

101678 50' E xtension Cord (Yellow) 9, 11, 13, 15, 17, 19, 21, 23, 25, 27, 29, 35

101680 50' Extension Cord (Blue) 9

101705 3-1 Stretch Hose w/ Cuffs 1½" 21

101709 25' Extension Cord (Blue) 9

101711 Shroud Retro Kit (Grey) w/Screws 21

101713 Power Cord (18” 16/3) Assembly 21

101714 Switch Cord w/Crimps 11, 13, 15, 19, 23, 29

101715 Switch Cord w/Crimps (AviationVac) 23

101716 26" Switch Cord Assembly Complete 120V 29

101718 Switch Box w/Belt Clip (for cart) 29

101720 Carbon Brush Set for Ametek Motor 11, 13, 27

101737 Carry Handle w/Rivet and Washer Set 11, 13, 15, 17, 19, 23, 29

101788 Produster P.O.P. Package 9

1018 0 8 Pr o d u s ter P. O.P. C as e 9

Hard Surface Flooring 1½" Kit 2, 4

101829

Super CoachVac w/Hard Surface Flooring Kit (101829) 2

101830

101880 Replacement Nylon Brush – JetSweep 20, 8

101928 Replacement Double Swivel Elbow Cuff (Black) 11, 13, 15, 17, 19, 29

101934 Twist Cap for 1½" Cuff (Grey) 21

101949 Foam Filter Media for Dome Filter 7, 21, 25, 27

101953 Receptacle Replacement Kit 21

102127 Small Strain Relief 25

102266

102604 Schulte Cord Holder 9, 21

102659 5" Long Dust Brush 5

102715 Replacement Swivel Elbow Cuff 1¼" (Black) 23, 35

102761 High Filtration Disk (optional) 7, 21, 25, 27

102784 Dome Filter w/ Foam Media 21, 25, 27

102878 Waist Belt w/Velcro 21

10287 9 Monost rap 21

102947 Vac Station 9

102988 Carbon Brush Set for TailVac Motor 21

103024 AviationVac w/Aviation 1¼" Kit #2 2

10302 5 R etroﬁ t Set: Waist Belt and Monostrap 21

103032 JetSweep 15, 15" Floor Tool w/Nylon Brush 6

103043 Fan and Brush Cover Kit 21

103048 Static-Dissipating Hose w/Cuffs (Black) 1½" 11, 13, 15, 17, 19, 29

103083 10½" Multi-Sur face Floor Tool 3, 6

103084 12" Natural Fiber Hard Floor Tool 3, 4, 6

103085 12" Carpet Tool w/Scallops 3, 4, 6

103086 Crevice Tool – 13" 3, 4, 5

103087 5½" Upholstery Tool w/Removable Brush (103088) 3, 4, 5, 8

103088 Removable Brush – 5½” Upholstery Tool (103087) 3, 4, 5, 8

103089 Dust Brush, Rectangular 90/180° Swivel – 2½" 3, 4, 5

103090 TailVac Deluxe 1¼" Attachment Kit 2, 3

103099 Cuff Adapter – 1¼" x 1¼" 3, 4, 8

103114 Swivel Caster 25, 27

103115 Micro Cloth Filter 7, 25, 27

103117 To ol D o c k 2 5, 2 7

103121 Motor Mount 25, 27

103123 Exhaust Foam 7, 27

103124 Foam Inlet Damper A 25, 27

103125 Foam Inlet Damper B 25, 27

54" Two-Piece 1½" Friction Fit Aluminum Button Lock Wand 5

Page 40

INDEX INDEX

Part No. Product Name Page No(s).

103131 ProClean 2

103150 Replacement Long Swivel Cuff (Black) 1½" 25, 27

103166 Backplate System Complete 11, 13, 15, 17, 19, 23, 29

103172 78” Static Dissipating Hose w/Cuffs (Black) 1½" 25, 27

103212 Wire Harness Assembly 27

103215 Power Cord (18" 16/3) Assembly w/Locknut and Washer 25, 27

103220 ProClean w/Restaurant Kit (100727) 2

103222 Aviation 1¼" Attachment Kit #2 2, 4

103236 Motor Seal 21, 25, 27

103237 Static-Dissipating Hose (AviationVac) 1¼" (Black) 23

103246 ProVac w/Attachment Kit B (101336) 2

103256 Rear Foam Diffuser 25, 27

103258 ProClean w/Attachment Kit B (101336) 2

103259 ProClean w/Attachment Kit C (100077) 2

103260 ProClean w/At tachment Kit D (100079) 2

103262 Step Cap (Grey) 21

103266 Motor Mount and Vented Exhaust Cover Screw Kit 25, 27

103267 Rear Wheel Assembly Kit 25, 27

103268 Rear Wheel Mounting Screw Kit 25, 27

103279 Replacement Swivel Cuff 1¼" (Black) (AviationVac) 23

103318 Top Cap, Black 25, 27

103360 Cover A ssembly, Vented Exhaust 27

1034 41 Cord Lo ck 9, 25

103467 Deluxe 1¼" Attachment Kit 3

103476 Thermal Protector 11, 13, 19, 23, 27,29, 35

103483 Intercept Micro Filters 7, 30, 32

103505 13" – 1¼" Curved Chrome Wand w/Button Lock 3, 4, 5

103531 Foam, Sound, Motor Housing, Rear Panel 31, 33

103532 Foam, Sound, Motor Housing, Front Panel 31, 33

103533 Foam, Sound, Motor Housing, Lef t Panel 31, 33

103545 Conical Washer for Swivel Caster 25, 27

103608 11" Turbo Brush 6

103617 Complete 36V Motor Assembly w/Seal, Compression Ring and Relay 35

103623 Electriﬁ ed Hose, 1¼" x 20' Long, 2-Wire 35

103627 Sternum Strap Buckles ( Latch and Keeper) 11, 13, 15, 17, 19, 23, 29

103638 Replacement HEPA Filter Kit 7, 25, 27

103647 Split Jumpers 27

103669 On/O f f Sw itch w /Split te rs 27

103718 Hose Wrap, Black 35

103731 Carbon Brush Set for 36V motor 35

103732 36V Motor w/Crimps, Replacement 35

103909 Momentary Switch 35

103916 Receptacle, 2-Wire w/Crimps 35

103974 B us hing w/ Holder 8

103975 Brush Arm, Set of 2 8

104 010 Top Co ve r 8

104011 1¼" Neck Assembly Complete 8

104012 1½" Neck Assembly Complete 8

104 016 Rear Axle 8

104017 Back Wheel 8

104 018 Front Axle 8

104019 Front Wheel 8

104 020 Be lt 8

104021 Bottom Cover 8

Part No. Product Name Page No(s).

104022 Squeegee 8

104023 Belt Guard 8

104024 Brush Roller Assembly 8

104029 Vac Display Mannequin 9

104152 How to Be a Utilit y Specialist in Carpet Care 9

104158 (12") Display Pedestal 9

104159 (18") Display Pedestal 9

104160 Floor Mat 9

104209 Screw, Phillips, 4.2mm x 12mm F/Wand Guide 31, 33

104212 Circuit Breaker 31, 33

104216 Brush Roll, Power Noz zle, 14" 31, 33

104217 Belt, Drive, F/Brush Roll 31, 33

104218 Bumper, Power Nozzle, Vinyl 31, 33

104221 Baseplate, Power Noz zle 31, 33

104224 Cover, Air Duct, Power Noz zle 31, 33

104226 Board, Vacuum Operation Indicator 31, 33

104227 Sleeve, Hose, Air Duct 31, 33

104230 Hose, Power Nozzle to Air Duct, Lower 31, 33

104232 Latch, Release, Bag Cover 30, 32

104233 Spring, Release Button, F/ Bag Cover L atch 30, 32

104234 Cover, Bag Housing, Grey F/XP 30

104235 Seal, Transition Duct/Bag Cover, Upper 30

104236 Duct, Transition, Bag Cover, F/XP 30

104238 Seal, Transition Duct/Bag Cover Nozzle Plate, Lower 30

104239 Plate, Bag Cover Nozzle, F/XP 30

104241 Seal, Gasket, Bag Cover 30, 32

104242 Spring, Bag Cover Latch 30, 32

104243 Flex Plate, Bag Cover Latch 30, 32

104245 Bulkhead, Black 31, 33

104246 Replacement Exhaust Filter Cover, Charcoal 7, 31, 33

104247 Motor Mount, Lower Nitrile 31, 33

104249 Motor Mount, Upper Nitrile 31, 33

104250 Air Duct Assembly 31, 33

104253 Seal, Lower Air Duc t , Nitrile 31, 33

104255 Handle w/Over Mold and Decal 30, 32

104259 Plate, Handle Nut 30, 32

104260 Guide, Wand, Upper Right 31

104261 Guide, Wand, Upper Left 31

104263 Switch, Wand Lockout 31

104264 Bushing, Handle Tube 30, 32

104265 Handle, Carry w/Tool Caddy, F/XP 30

104266 Screw, Handle Assembly 30, 32

104267 Screw, Phillips, 4.2mm x 19mm F/Lower Air Duct 31, 33

104268 Bracket, Cord Wrap 30, 32

104269 Spring, Compression, Cord Wrap Bracket 30, 32

104270 Washer, Compression Spring, Cord Wrap Bracket 30, 32

104271 Screw, Cord Wrap, 4mm x 38mm, Phillips Round Head 30, 32

104272 Receptacle Screw Set 35

104273 Twist Cap ( Black) 17, 19, 23, 35

104274 HEPA Filter Assembly w/Bottom Cap 7, 29

104275 ULPA Filter Assembly Complete w/Bottom Cap 7, 29

104276 Latch Cap w/Cuff (Black) 29

104279 Switch, Safety, Power Nozzle Lockout 31, 33

104281 Replacement Motor Intake Filter 7, 30, 32

104282 Cover, Switch, Filter Lock-out 30, 32

104283 Switch, Filter, Lock-Out 30, 32

Page 41

INDEX INDEX

Part No. Product Name Page No(s).

104284 Cord, Power, w/Strain Relief, 50’ Yellow 30, 32

1042 94 Wan d, F/XP 30

104300 ProForce 1500 2

104301 Pro Force 1500XP 2

104306 Wheel, Rear 31, 33

104490 Bag Housing Assembly, Grey w/Riveted Hinge 30

104491 Rivet F/Bag Housing Assembly 30, 32

104493 Screw, Phillips, 4.2mm x 38mm 30, 32

104494 Power Nozzle Cover w/Detent Springs & Decal 31, 33

104495 Screw, Phillips, 4.2mm x 19mm F/Powerhead 31, 33

104496 Screw, Phillips, 2.9mm x 35mm, F/Brush Retainer 31, 33

104497 Screw, Phillips, 4.2mm x 35mm F/Base Cover 31, 33

104498 Grommet, Vibration, Power Nozzle Motor, Nitrile 31, 33

104499 Retainer, Brush Roll 31, 33

104500 Brace, Formed Wire, F/Power Nozzle Base 31, 33

104501 Roller, Front 31, 33

104502 Shaf t, Front Roller Axle 31, 33

104503 Clamp, Rear Wheel 31, 33

104504 Bearing, Pivot 31, 33

104505 Screw, Phillips, 4.2mm x 9.5mm 30

104506 Motor, Power Nozzle with Crimps 31, 33

104507 Spring, Detent, Upright Lock 31, 33

104509 Screw, Phillips, M4 x 10mm x .07 Pitch, 30, 32

104536 Motor Housing, Charcoal 31, 33

104544 Intercept Micro Filters, One Pack of 10 7, 25, 27

104569 Cover, Bag Housing, Grey 32

104570 Plate, Bag Cover Noz zle 32

104571 Duct, Crossover, Bag Cover 32

104574 Plug, Access Port 32

104575 Seal, Crossover Duct/ Bag Cover Nozzle Plate, Lower 32

104576 Seal, Crossover Duct, Inlet 32

104577 Screw, Phillips, 4.2mm x 9.5mm 32

104578 Air Duct, Upper ProForce 1500 33

104738 Seal, Gasket, Bag Housing 30, 32

104739 Bag Housing Assembly, Grey 32

104741 H an dle, Ca rr y 32

104812 Pest Control DVD – Introduction to Pest Control System 9

104832 Replacement Crevice Tool (ProForce 1500XP) 5

104833 Combo Upholstery/Dust Brush 5

104885 GoCartVac 1¼" Kit 5

104957 Motor Assembly Kit w/Jumpers 31, 33

104958 Handle, Tube w/Wire Harness, Rivet Nut and Plug Rivet 30, 32

104959 Handle, Tube Assembly Complete, F/XP 30

104961 Hose, Assembly w/Cuffs, F/XP 30

104998 Bottom Twist Cap Gasket 13

105030 TailVac w/ Deluxe 1¼" Kit (103090) 2

105031 AL A Price Tags 9

105044 Motor Shroud Cover w/Screws 11, 13, 15, 23

105046 Backplate 11, 13, 15, 17, 19, 23, 29

105047 Receptacle Assembly for Powerhead 27

105070 Bottom Twist Cap (Black) 13

105075 Screw, Phillips, 2.9mm x 13mm, F/Switch Cover 30, 32

105088 Handle Bezel w/Screws 30

105090 Handle Bezel w/Screws 32

105091 Clasp, Strain Relief, Yellow 30, 32

105114 Handle, Tube Assembly Complete 32

Part No. Product Name Page No(s).

105136 Replacement HEPA Media Exhaust Filter 7, 31, 33

105147 Switch, Rocker, On/Off 30, 32

105149 Cap, Motor 17

105150 Exhaust Housing, Motor 17

105162 Motor/Fan (120V) w/Crimps for Domel Motor 11, 13, 15

105164 Carbon Brush Set for Domel Motor 11, 13, 15, 27

105281 Carbon Brush Set for ProForce Motor 31, 33

105337 Ring, Motor Housing, Large 17

105341 Cover, Motor Housing 17

105342 Foam, Ring, Motor Housing 17

105343 Foam, Cover, Motor Housing 17

105371 Screw, Phillips, 4.2mm x 19mm, F/Power Noz zle Motor 31, 33

105419 Acoustical Insert, Right 17

105422 Acoustical Insert, Left 17

105430 Upper Foam Compression Ring 25, 27

105438 O n/O ff Sw it ch 17

105486 Filter Cover Kit w/Riveted Hinge and 6 Rivet s 30

105488 Motor Housing Sound Filter 31, 33

105489 Ai r Duct K it 31

105490 Wan d Kit 31

105491 Filter Cover Kit, w/Riveted Hinge and 32

105496 Batter y Control Module 35

105498 Training/Sales DVD – The ProTeam® Way 9

105501 Handle Kit 32

105502 Handle Kit 30

105537 Set of Pedestals 9

105573 Quick Release Hose Cuff 30

105605 Gasket, Motor 17

105613 Motor Mount 17

105619 Motor Mount Assembly 17

105620 Housing, Exhaust, Motor F/QuietPro 17

105621 Kit, Foam, Laminate Acoustical Panels 17

105622 Kit, Exhaust, Foam and Ring 17

105623 Kit, Cover, Exhaust F/QuietPro 17

105643 Tetraseal, Motor 17

105653 Dual Speed Module and Schematic 17, 25

105687 Motor/Fan (120V) for ProClean w/Crimps (Domel Motor) 27

105691 18" Sidewinder Carpet Tool 6

105692 18" Sidewinder Hard Floor Tool w/Nylon Brush 6

105693 59" Two-Piece Friction Fit Aluminum Sidewinder Straight Wand 5

105694 Replacement Nylon Brush 18" Sidewinder 8

105695 59" One-Piece Friction Fit Aluminum Sidewinder Straight Wand 5

105697 Carbon Brush Set for CoachVac Motor (Domel Motor) 11, 17, 19, 23, 25, 29

105720 Motor/Fan (120 V) w/Crimps for Domel Motor 11, 23, 29

105721 Motor/Fan (120 V) w/Crimps (Domel) 19

105722 Motor, (120V ), 2-Stage 17

105732 QuietPro w/Attachment Kit B (101336) 2

105733 QuietPro w/Attachment Kit A (100078) 2

105748 Switch Cord Assembly Complete F/QuietPro 17

105754 Wire Harness Kit 31

105755 Wire Harness Kit 33

105760 Thermal Protector 31, 33

105763 Screw, 10-32 x .75, Self Tapping 17

105767 Screw, #8 x 1/2", Phillips, Hi/Lo 17

Page 42

INDEX INDEX

Part No. Product Name Page No(s).

1058 00 So un d Mu fﬂ er 15

105889 Flooring Installation 1.5" Kit A 2, 4

105890 Flooring Installation 1.5" Kit B 2, 4

105891 Flooring Installation 1.5" Kit C 2, 4

105892 MegaVac w/Flooring Installation Kit A (105889) 2

105893 Super CoachVac w/ Flooring Installation Kit A (105889) 2

105894 MegaVac w/ Flooring Installation Kit B 105890 2

105895 Super CoachVac w/Flooring Installation Kit B (105890) 2

105896 MegaVac w/Flooring Installation Kit C (105891)

105897 Super CoachVac w/ Flooring Installation Kit C (105891) 2

105948 Noise Supression Foam 25

105949 Noise Supression Filter Assembly 25

105991 On/Off Switch (2 Stage) 25

106066 On/Off Switch 11, 13, 15, 19, 23, 29

106070 S up er Qu ar te rVac 2

106073 Twist Cap ( Purple) 15

106087 GoCart Vac 2

106102 QuietPro CN 2

106103 Motor/Fan (120V) for ProClean w/Crimps (Domel Motor) 25

106107 Ground Jumper 25

106194 14" Hard Floor Tool w/Felt Brush – Scalloped & Flat 6

106203 Wire Harness Assembly: 3 Wires and Strain Relief 25

106205 Super QuarterVac w/Attachment Kit B (101336) 2

1062 06

106207 QuietProCN HEPA w/Attachment Kit B (101336) 2

106208 QuietProCN HEPA w/High Filtration Vac Kit (100163) 2

106209 GoCartVac w/GoCart Kit (104885) 2

106211 Box, Sound w/Corner Rails 35

106213 Car t Assembly 35

106214 Kit, Mounting Hardware 35

106215 Kit, Box Assembly 35

106216 Kit, Batter y Wiring Harness 35

106217 Kit, Receptacle 35

106218 Kit, Charger, 36V, 18.5A, w /Terminals 35

106219 Kit, Power Receptacle Cord 35

106241 Kit, Receptacle for Box Assembly 35

106245 15" Sidewinder Carpet Tool 5

106246 15" Sidewinder Hard Floor Tool 6, 35

106261

Super QuarterVac w/Attachment Kit A (100078) 2

6' Static Strap Kit (ProForce) 9

51011 2

Part No. Product Name Page No(s).

106274

106276

106277 Harness, Charging w/Connectors 35

106278 Harness, Battery 35

106279 Lead, Wire, Battery, Red, #8AWG, w /Terminals 35

106280 Lead, Wire, Battery, Fusible Link, Replacement #8AWG, w/Terminals 35

106281 Switch Assembly w/Crimps 35

106282 Power Cord Replacement, Complete 35

106283 Kit, Attachment Hardware for Charger and Box Assembly 35

106284 Kit, Vacuum Attachment Hardware for Cart 35

106287 Switch Box w/Velcro and Screws 11, 13, 15, 19, 23, 29

106290 1½" Aluminum Telescoping Wand 42" to 59" 6

106291 Commercial 1½" Telescoping Wand Kit 3

106293 49" One-Piece, Two-Bend Aluminum Wand 4, 5

106297

106298

106343 24" to 40" – 1¼" Telescoping Wand w/Button Lock 3, 4, 5

106501 Vacuums – Set-Up/Training/Operation DVD 9

106502 Aviation 1½" Kit #1 2, 4

106512 Super CoachVac w/1½" Telescoping Wand Kit (106291) 3

106513 Super QuarterVac w/1½" Telescoping Wand Kit (106291) 3

106514 TailVac w/1½" Telescoping Wand Kit (106291) 3

106515 QuarterVac w/1½" Telescoping Wand Kit (106291) 3

106516 ProClean w/1½" Telescoping Wand Kit (106291) 3

106517 QuietPro CN HEPA w/1½" Telescoping Wand Kit (106291) 3

106518 QuietPro BP w/1½" Telescoping Wand Kit (106291) 3

106519 ProVac w/1½" Telescoping Wand Kit (106291) 3

106526 Super QuarterVac HEPA 7, 11,15

106542 AviationVac w/Aviation 1½" Kit #1 2

106550 Switch Replacement 35

106573

106577

106579

106580

106709

106730 Tapered 1¼" Wand Kit 3

106731 Super CoachVac w/1¼" Tapered Wand Kit (106730) 2

10' Static Strap Kit (ProForce) 9

Battery, Lead Acid, 12V, 37AH 35

Wheel Set, Rear 35

Wheel Set, Front 35

HEPA Dome Filter for Super CoachVac HEPA,

Super CoachVac HEPA w/Attachment Kit B (101336) 2

Super QuarterVac HEPA w/Attachment Kit B (101336) 2

Super CoachVac HEPA w/1½'' Telescoping Wand Kit (106291) 2

10" Multi-Surface Floor Tool 4

Page 43

SALES REPRESENTATIVES

1 Ryan, Saffel & Associates

AK, WA, OR, HI 2731 152nd Avenue, NE Redmond, WA 98052-5544 (425) 885-7090 FAX (425) 881-8733 [email protected]

2 Access Group N. CA

Northern CA, Northern NV 14470 Doolittle Drive San Leandro, CA 94577 (510 ) 567-10 00 (800) 482-6088 FAX (510) 567-1005 [email protected]

3 Access Group S. CA

Southern CA, Southern NV 912 W. Tenth Street Azusa, CA 91702 (626) 815-4200 (800) 540-9001 FAX (626) 815-4300 [email protected]

4 TRC Marketing, Inc.

MT, ID, WY, UT, CO, AZ, NM, El Paso, TX 4665 Joliet Street Denver, CO 80239 (303) 373-1940 (800) 748-2290 FAX (303) 371-1557 laurie@ trcmarketinginc.com

5 D.C. Brown, Inc.

ND, SD, MN, Northwest WI 7104 Ohms Lane, Ste. 214 Minneapolis, MN 55439-2129 (952) 896-1890 FAX (952) 896-1970 [email protected]

6 K.J.A., Inc.

NE, IA, KS, MO 9000 Fernald Drive St. Louis, MO 63123 (314) 842-6222 (800) 892-1733 FAX (314) 842-4128 [email protected]

7 Demlow Marketing

OK, AR, TX, LA P.O. Box 7945 (77270) 4910 Darling St. Houston, TX 77007 (713) 864-2947 (800) 334-4923 FAX (713) 864-7054 [email protected]

8 Osborne Sales Group

IN, OH, Western PA, KY, WV 4010 North Bend Road, Suite 101 Cincinnati, OH 45211 (513) 481-6200 FAX (513) 389-3992 [email protected]

9 Hinton Sales, Inc.

TN, MS, AL, GA 6659-D Peachtree Industrial Blvd. Norcross, GA 30092 (770) 326-6455 (800) 344-2638 FAX (770) 326-6189 [email protected]

10 Norsen Sales & Marketing, Inc.

NY State 157 West Main Street Victor, NY 14564 (585) 924-9180 (800) 866-7736 FAX (585) 924-9230 [email protected]

11 Market Advantage Plus

VT, NH, ME, MA, CT, RI 56 Leonard St., Unit 4 Foxboro, MA 02035 (508) 543-3605 (800) 564-6320 (New England only) FAX (508) 543-7147 [email protected]

12 Bull’sEye

NJ, Metro NY, Long Island, NY 73 Cedar Avenue Hershey, PA 17033 (888) 381-8892 (717) 533-3601 FA X (717) 533- 4671 [email protected]

13 Buckley & Associates

Eastern PA, DE, MD, DC, VA, NC, SC 5707 Centre Square Dr. Centreville, VA 20120 (703) 631-8138 FAX (703) 631-7841 [email protected]

14 The DeBolt Company, Inc.

FL 3650 Coral Ridge Dr., Suite 112 Coral Springs, FL 33065 (954) 255-5061 (800) 866-0618 FAX (954) 255-5062 chris@ DeBoltCo.com

15 The RTF Group, Inc.

IL, WI 49 Sherwood Terrace, #49C Lake Bluff, IL 60044 (847) 234-7300 (800) 860-6162 FAX (847) 234-7301 [email protected]

16 Maintenance Kleaning Technologies

MI 120 Bay Circle Drive Holland, MI 49424 (616) 886-2206 FAX (616) 546-2815 [email protected]

CANADA

1 British Columbia Ryan, Saffel & Associates 2731 152nd Avenue, NE

Redmond, WA 98052-5544 (425) 885-7090 FAX (425) 881-8733 [email protected]

17 Western Canada (except BC) Rev Sales & Marketing, Inc.

AB, SK, MB, YT, NWT, NU 505-8840, 210 St. Langley, BC Canada (604) 338-1849 FAX (604) 513-1811 [email protected]

18 Eastern Canada McConnell-Spadafora

ON, PQ, NB, NS, PEI, NL 850 Legion Road, Unit 4 Burlington, Ontario L7S 1T5 (905) 681-9563 (866) 700-8889 FAX (905) 681-1727 [email protected]

ProTeam, Inc. 5118 N. Sawyer Ave Boise, Idaho 83714 ph 866.888.2168 www.pro-team.com

Page 44

Headquarters 5118 N Sawyer Ave Boise, Idaho 83714

Mailing Address PO Box 7385 Boise, Idaho 83707

FOR MORE INFORMATION ABOUT OUR COMPLETE LINE OF VACUUMS

CALL 800.541.1456 OR VISIT www.pro-team.com

101771 / Printed 4-08
