I
Preface
Notice
The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or
inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage
resulting from the use (or misuse) of this publication.
This publication and any accompanying software may not, in whole or in part, be reproduced, translated,
transmitted or reduced to any machine readable form without prior consent from the vendor, manufacturer
or creators of this publication, except for copies kept by the user for backup purposes.
Brand and product names mentioned in this publication may or may not be copyrights and/or registered
trademarks of their respective companies. They are mentioned for identification purposes only and are not
intended as an endorsement of that product or its manufacturer.
©August 2003
Trademarks
This product incorporates copyright protection technology that is protected by method claims of certain
U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights
owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and
is intended for home or other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
Intel and Pentium are registered trademarks of Intel Corporation.
II
Preface
FCC Statement
(Federal Communications Commission)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the service representative or an experienced radio/TV technician for help.
Warning
Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the manufacturer for compliance with the above standards could void your authority to operate the equipment.
III
Preface
IMPORTANT SAFETY INSTRUCTIONS
When using your telephone equipment, basic safety precautions should always be followed to reduce the
risk of fire, electric shock and injury to persons, including the following:
1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub,
in a wet basement or near a swimming pool.
2. Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm.
There may be a remote risk of electrical shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They
may explode. Check with local codes for possible special disposal instructions.
5. This product is intended to be supplied by a Listed Power Unit (DC Output 20V, 2.5A minimum).
CAUTION
Always disconnect all telephone lines from the wall outlet before servicing or disassembling this equipment.
TO REDUCE THE RISK OF FIRE, USE ONLY NO. 26 AWG OR LARGER,
TELECOMMUNICATION LINE CORD
IV
Preface
Instructions for Care and Operation
The computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:
1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be
damaged.
2. Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of
heating element. This is an electrical appliance. If water or any other liquid gets into it, the computer
could be badly damaged.
Do not expose the computer
to any shock or vibration.
Do not place it on an unstable
surface.
Do not place anything heavy
on the computer.
Do not expose it to excessive
heat or direct sunlight.
Do not leave it in a place
where foreign matter or moisture may affect the system.
Don’t use or store the computer in a humid environment.
Do not place the computer on
any surface that will block the
vents.
V
Preface
3. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and
other strong magnetic fields. These can hinder proper performance and damage your data.
4. Follow the proper working procedures for the computer. Shut the computer down properly and
don’t forget to save your work. Remember to periodically save your data as data may be lost if the
battery is depleted.
5. Take care when using peripheral devices.
Do not turn off the power
until you properly shut down
all programs.
Do not turn off any peripheral
devices when the computer is
on.
Do not disassemble the computer by yourself.
Perform routine maintenance
on your computer.
Use only approved brands of
peripherals.
Unplug the power cord before
attaching peripheral devices.
VI
Preface
Power Safety
The computer has specific power requirements:
• Only use a power adapter approved for use with this computer.
• Your AC adapter may be designed for international travel but it still requires a
steady, uninterrupted power supply. If you are unsure of your local power specifications, consult your service representative or local power company.
• The power adapter may have either a 2-prong or a 3-prong grounded plug. The
third prong is an important safety feature; do not defeat its purpose. If you do not
have access to a compatible outlet, have a qualified electrician install one.
• When you want to unplug the power cord, be sure to disconnect it by the plug head,
not by its wire.
• Make sure the socket and any extension cord(s) you use can support the total current load of all the connected devices.
• Before cleaning the computer, make sure it is disconnected from any external
power supplies (i.e. AC adapter or car adapter).
Do not plug in the power
cord if you are wet.
Do not use the power cord if
it is broken.
Do not place heavy objects
on the power cord.
Power Safety
Warning
Before you undertake
any upgrade procedures, make sure that
you have turned off the
power, and disconnected all peripherals
and cables (including
telephone lines). It is
advisable to also remove your battery in
order to prevent accidentally turning the
machine on.
VII
Preface
Battery Precautions
• Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.
• Recharge the batteries using the computer’s system. Incorrect recharging may make the battery explode.
• Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative
or qualified service personnel.
• Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully.
Batteries may explode or leak if exposed to fire, or improperly handled or discarded.
• Keep the battery away from metal appliances.
• Affix tape to the battery contacts before disposing of the battery.
• Do not touch the battery contacts with your hands or metal objects.
Battery Disposal
The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of
its useful life, under various state and local laws, it may be illegal to dispose of this battery into the municipal
waste stream. Check with your local solid waste officials for details in your area for recycling options or proper
disposal.
Caution
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used battery according to the manufacturer’s instructions.
VIII
Preface
Touch Panel Care
• Touch Panels are made of glass, so do not subject them to heavy shock or stress.
• Do not place heavy objects on the Touch Panel.
• Please use a dry soft cloth when cleaning (do not use any organic solvent acid or alkali solution).
Cleaning
Do not apply cleaner directly to the computer; use a soft clean cloth.
Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.
Servicing
Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and
the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer
from the power supply. Then refer servicing to qualified service personnel under any of the following conditions:
• When the power cord or AC/DC adapter is damaged or frayed.
• If the computer has been exposed to rain or other liquids.
• If the computer does not work normally when you follow the operating instructions.
• If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).
• If there is an unusual odor, heat or smoke coming from your computer.
IX
Preface
Travel Considerations
Packing
As you get ready for your trip, run through this list to make sure the system is ready to go:
1. Check that the battery pack and any spares are fully charged.
2. Power off the computer and peripherals.
3. Close the display panel and make sure it’s latched.
4. Disconnect the AC adapter and cables. Stow them in the carrying bag.
5. The AC adapter uses voltages from 100 to 240 volts so you won’t need a second voltage adapter.
However, check with your travel agent to see if you need any socket adapters.
6. Put the computer in its carrying bag and secure it with the bag’s straps.
7. If you’re taking any peripherals (e.g. a printer, mouse or digital camera), pack them and those
devices’ adapters and/or cables.
8. Anticipate customs - Some jurisdictions may have import restrictions or require proof of ownership
for both hardware and software. Make sure your “papers” are handy.
Power Off Before Traveling
Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container).
Putting a notebook which is powered on in a travel bag may cause the vents/intakes to be blocked. To prevent
your computer from overheating make sure nothing blocks the vent/fan intake while the computer is in use.
X
Preface
On the Road
In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind:
Hand-carry the computer - For security, don’t let it out of your sight. In some areas, computer theft is
very common. Don’t check it with “normal” luggage. Baggage handlers may not be sufficiently careful.
Avoid knocking the computer against hard objects.
Beware of Electromagnetic fields - Devices such as metal detectors & X-ray machines can damage the
computer, hard disk, floppy disks, and other media. They may also destroy any stored data - Pass your
computer and disks around the devices. Ask security officials to hand-inspect them (you may be asked to
turn it on). Note: Some airports also scan luggage with these devices.
Fly safely - Most airlines have regulations about the use of computers and other electronic devices in
flight. These restrictions are for your safety, follow them. If you stow the computer in an overhead compartment, make sure it’s secure. Contents may shift and/or fall out when the compartment is opened.
Get power where you can - If an electrical outlet is available, use the AC adapter and keep your battery(ies) charged.
Keep it dry - If you move quickly from a cold to a warm location, water vapor can condense inside the
computer. Wait a few minutes before turning it on so that any moisture can evaporate.
XI
Preface
Developing Good Work Habits
Developing good work habits is important if you need to work in front of the computer for long periods
of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your
hands, wrists or other joints. The following are some tips to reduce the strain:
• Adjust the height of the chair and/or desk so that the keyboard is at or slightly
below the level of your elbow. Keep your forearms, wrists, and hands in a relaxed
position.
• Your knees should be slightly higher than your hips. Place your feet flat on the
floor or on a footrest if necessary.
• Use a chair with a back and adjust it to support your lower back comfortably.
• Sit straight so that your knees, hips and elbows form approximately 90-degree
angles when you are working.
• Take periodic breaks if you are using the computer for long periods of time.
Remember to:
• Alter your posture frequently.
• Stretch and exercise your body several times a day.
• Take periodic breaks when you work at the computer for long periods of time. Frequent and short breaks are better than fewer and longer breaks.
XII
Preface
Lighting
Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your
neck and shoulders.
• Position the display to avoid glare or reflections from overhead lighting or outside sources of light.
• Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen
clearly.
• Position the display directly in front of you at a comfortable viewing distance.
• Adjust the display-viewing angle to find the best position.
XIII
Preface
Contents
Notice ...........................................................................I
Trademarks ..........................................................I
FCC Statement ...................................................II
Instructions for Care and Operation ................. IV
Power Safety .....................................................VI
Battery Precautions ..........................................VII
Touch Panel Care .......................................... VIII
Cleaning ........................................................ VIII
Servicing ........................................................ VIII
Travel Considerations .......................................IX
Remember to: ......................................................... I-XI
Introduction
Overview ..................................................................1-1
Advanced Users .....................................................1-1
Beginners and Not-So-Advanced Users .................1-1
Warning Boxes .......................................................1-2
Not Included ...........................................................1-2
System Software .....................................................1-2
Quick Start Guide .....................................................1-3
System Map ..............................................................1-4
Model Differences ..................................................1-4
Getting to Know Your Computer ...........................1-5
Top View ................................................................. 1-6
The LCD Swivel Screen .......................................... 1-7
Top View with LCD Open .................................... 1-8
PC Camera ............................................................ 1-9
LCD Swivel Screen .............................................. 1-9
LED Power Indicators .......................................... 1-9
Cover Sensors ..................................................... 1-10
LCD Swivel & Side Hinges ............................... 1-11
Power Button ...................................................... 1-11
Stereo Speakers .................................................. 1-11
Keyboard ............................................................ 1-12
TouchPad & Buttons .......................................... 1-12
Microphone ......................................................... 1-12
Front View ............................................................. 1-13
LCD Latches ....................................................... 1-13
Microphone-In Jack ............................................ 1-13
Headphone-Out Jack .......................................... 1-14
Infrared Transceiver ........................................... 1-14
LED Status Indicators ......................................... 1-14
Hot-Key Buttons ................................................. 1-15
Left Side View ....................................................... 1-16
Security Lock Slot .............................................. 1-16
Vent .................................................................... 1-16
Stylus Pen Holder ............................................... 1-16
Right Side View ..................................................... 1-17
XIV
Preface
4-in-1 Flash Card Reader ....................................1-17
2 * USB 2.0 Ports ................................................1-18
PC Card Slot ........................................................1-18
Rear View ...............................................................1-19
External Monitor (CRT) Port ..............................1-19
RJ-45 LAN Jack ..................................................1-19
RJ-11 Phone Jack ................................................1-20
DC-In Jack ..........................................................1-20
Vent .....................................................................1-20
Bottom View ..........................................................1-21
Stylus Pen Holder ................................................1-21
Battery .................................................................1-21
Wireless LAN (Network) Module ......................1-22
Hard Disk Drive ..................................................1-22
Vent .....................................................................1-22
Using The Computer
Overview ..................................................................2-1
The Power Sources ...................................................2-2
AC Adapter ............................................................2-2
Battery ....................................................................2-3
Recharging the Battery with the AC Adapter ........2-3
Proper handling of the Battery Pack .....................2-3
Turning on the Computer .........................................2-4
LED Indicators .........................................................2-5
LED Power Indicators ........................................... 2-5
LED Status Indicators ............................................ 2-6
Hard Disk Drive ....................................................... 2-7
The Floppy Disk Drive (Optional) ........................... 2-8
Inserting/Removing Floppy Disks ......................... 2-8
CD Device/DVD Device (Optional) ........................ 2-9
Optional CD/DVD Device Options ..................... 2-10
Loading CDs or DVDs ........................................ 2-10
Handling CDs or DVDs ....................................... 2-11
4-in-1 Card Reader ................................................. 2-12
PC Card Slot .......................................................... 2-13
Inserting and Removing PC Cards ...................... 2-13
Hot-Keys ................................................................ 2-14
The Keyboard ........................................................ 2-15
The Function Keys ............................................. 2-15
Numeric Keypad ................................................. 2-16
Touch Panel (Model A Only) ................................ 2-17
TouchPad and Buttons/Mouse ............................... 2-19
Configuring the TouchPad and Buttons .............. 2-20
Adding a Printer ..................................................... 2-21
USB Printer .......................................................... 2-21
Install Instructions: ............................................. 2-21
Parallel Printer ..................................................... 2-22
Install Instructions: ............................................. 2-22
XV
Preface
Advanced Controls
Overview ..................................................................3-1
Advanced Video Controls ........................................3-2
Opening the LCD ...................................................3-2
Video Driver Controls ..............................................3-3
Making Adjustments for the Display .....................3-3
Display Properties ..................................................3-4
S3 Control Taskbar Utility .....................................3-5
S3 Advanced Display Properties ............................3-5
Display Devices ........................................................3-7
Power Management Features ...................................3-8
Advanced Configuration and Power Interface .......3-8
Enabling Power Options ...........................................3-9
Conserving Power (Individual Components) ....... 3-10
Turn off Monitor .................................................3-10
Turn off Hard Disk ..............................................3-10
Conserving Power (System) .................................3-11
Hibernate Mode vs. Shutdown .............................3-11
Standby Mode vs. Hibernate Mode ......................3-11
Standby ................................................................3-12
Hibernate .............................................................3-12
Configuring the Power Button .............................3-13
Battery Information ................................................3-14
New Battery ........................................................3-14
Battery Life ......................................................... 3-14
Battery FAQ ........................................................ 3-15
Conserving Battery Power ................................... 3-15
Via Power Saver 2.0 .............................................. 3-16
PC Camera ............................................................. 3-17
PC Camera Audio Setup ...................................... 3-17
AMCAP ............................................................... 3-19
Set Capture File ..................................................... 3-19
Wireless LAN Module ........................................... 3-20
Drivers & Utilities
Overview .................................................................. 4-1
What to Install .......................................................... 4-2
New Hardware Found ............................................ 4-2
Authorized Driver Message ................................... 4-3
Version Conflict Message ..................................... 4-3
Updating/Reinstalling Individual Drivers ............. 4-3
Driver Installation .................................................... 4-4
Automatic Driver Installation ............................... 4-4
Windows XP ............................................................ 4-6
VIA 4 in 1 ............................................................. 4-6
VIA VGA (Video) ................................................ 4-6
VIA Audio ............................................................ 4-6
VIA LAN .............................................................. 4-7
Modem .................................................................. 4-7
XVI
Preface
PC Card/PCMCIA .................................................4-7
PC Camera ............................................................4-8
Wireless LAN .......................................................4-8
Touch Panel (Model A Computers) ......................4-9
Infrared (VIA FIR) ................................................4-9
TouchPad ............................................................4-10
VIA USB 2.0 .......................................................4-10
VIA Power Saver ................................................4-10
BIOS Utilities
Overview ..................................................................5-1
Important BIOS Settings ..........................................5-2
The Power-On Self Test (POST) .............................5-3
FirstWare Utilities ..................................................5-4
POST Screen ............................................................5-5
Failing the POST ....................................................5-6
Fatal Errors ............................................................5-6
Non-Fatal Errors ...................................................5-6
The Setup Program ...................................................5-7
Entering Setup ........................................................5-7
Setup Screens .........................................................5-7
Main Menu ...............................................................5-8
System Time & Date (Main Menu) ..........................5-8
Primary Master (Main Menu) ..................................5-9
QuickBoot Mode: (Main Menu) ..............................5-9
Summary screen: (Main Menu) ............................... 5-9
Advanced Menu ..................................................... 5-10
Firstware Language: (Advanced Menu) ................ 5-11
Firstware Authentication Level: (Advanced Menu) .. 511
Firstware Video Mode: (Advanced Menu) ............ 5-11
Boot-time Diagnostic Screen: (Advanced Menu) .. 5-11
Advanced Chipset Control: (Advanced Menu) ..... 5-12
I/O Device Configuration: (Advanced Menu) ....... 5-12
Legacy USB Support: (Advanced Menu) .............. 5-13
Large Disk Access Mode: (Advanced Menu) ........ 5-13
Installed O/S: (Advanced Menu) ........................... 5-13
Reset Configuration Data: (Advanced Menu) ....... 5-13
Security Menu ........................................................ 5-14
Security Menu ........................................................ 5-14
Set Supervisor Password (Security Menu) ............ 5-15
Set User Password (Security Menu) ...................... 5-15
Fixed disk boot sector: (Security Menu) ................ 5-15
Virus check/System backup reminder: (Security Menu)
5-15
Password on boot: (Security Menu) ....................... 5-16
Power Menu ........................................................... 5-17
PC Beep: (Power Menu) ........................................ 5-17
Turbo/DeTurbo (Power Menu) .............................. 5-17
Boot Menu ............................................................. 5-18
XVII
Preface
Boot Menu ..............................................................5-18
Phoenix FirstWare Utilities ..................................5-19
Exit Menu ...............................................................5-20
Upgrading The Computer
Overview ..................................................................6-1
When Not to Upgrade ............................................6-2
Removing the Battery ...............................................6-3
Battery Removal Process .......................................6-3
Upgrading the Hard Disk Drive ...............................6-4
Hard Disk Upgrade Process ...................................6-4
Upgrading the System Memory (RAM) ...................6-5
Memory Upgrade Process ......................................6-5
Upgrading the Processor ..........................................6-7
Troubleshooting
Overview ..................................................................7-1
Basic Hints and Tips ................................................7-2
Backup and General Maintenance ............................7-3
Viruses ......................................................................7-4
Upgrading and Adding New Hardware/Software .... 7-5
Power ........................................................................7-7
Display .....................................................................7-9
Hard Disk & Boot Password ..................................7-11
Floppy Disk Drive (Optional) ................................7-12
Audio ..................................................................... 7-13
CD Device (Optional) ............................................ 7-14
PC Card .................................................................. 7-16
Keyboard and Mouse ............................................. 7-17
Printer ..................................................................... 7-18
Operation ............................................................... 7-19
Appendix A. Model A Specifications
Processor Options ............................................... A-1
Memory ............................................................... A-1
Core Logic .......................................................... A-1
Structure .............................................................. A-1
Security ............................................................... A-1
BIOS ................................................................... A-1
LCD ..................................................................... A-1
Storage ................................................................ A-2
PC Card ............................................................... A-2
Audio ................................................................... A-2
Keyboard ............................................................. A-2
Interface .............................................................. A-3
Power .................................................................. A-3
Indicators ............................................................. A-3
Buttons ................................................................ A-3
Environmental Spec ............................................ A-4
XVIII
Preface
Physical Dimensions ........................................... A-4
Weight ................................................................. A-4
Optional ............................................................... A-4
Appendix B. Model B Specifications
Processor Options ................................................ B-1
Memory ............................................................... B-1
Core Logic ........................................................... B-1
Structure .............................................................. B-1
Security ................................................................ B-1
BIOS .................................................................... B-1
LCD ..................................................................... B-1
Storage ................................................................. B-2
PC Card ............................................................... B-2
Audio ................................................................... B-2
Keyboard ............................................................. B-2
Interface ............................................................... B-3
Power ................................................................... B-3
Indicators ............................................................. B-3
Buttons ................................................................ B-3
Environmental Spec ............................................ B-4
Physical Dimensions ........................................... B-4
Weight ................................................................. B-4
Optional ............................................................... B-4
Overview 1 - 1
1
Introduction
Chapter 1: Introduction
Overview
This manual refers to the hardware and essential software required to run your
computer. Depending on how your system is configured, some or all of the
features described may already be set up. This chapter covers:
• The Manual — how to use it
• System Map — navigating around your computer
Advanced Users
If you are an advanced user you may skip over most of this manual. However
you may find it useful to refer to the
“What to Install” on page 4 - 2, “BIOS
Utilities” on page 5 - 1 and
“Upgrading The Computer” on page 6 - 1. You
may find the notes marked with a
of interest to you.
Beginners and Not-So-Advanced Users
If you are new to computers (or do not have an advanced knowledge of them)
then you should try to look through all the documentation. Do not worry if you
do not understand everything the first time. Keep this manual nearby and refer
to it to learn as you go. You may find it useful to refer to the notes marked with
a
as indicated in the margin.
Notes
Check the light colored
boxes with the mark
above to find detailed
information about the
computer’s features.
Introduction
1 - 2 Overview
1
Warning Boxes
No matter what your level please pay careful attention to the warning and safety information indicated by the symbol. Also please note the safety and
handling instructions as indicated in the
Preface.
Not Included
Operating Systems (e.g. Windows XP etc.) have their own manuals, as do applications (e.g. word processing, spreadsheet and database programs). If you
have questions about the operating systems or programs then please consult
the appropriate manuals.
System Software
Your computer may already come with system software pre-installed. Where
this is not the case, or where you are re-configuring your computer for a different system, you will find this manual refers to the following operating systems:
• Microsoft Windows XP
Quick Start Guide 1 - 3
1
Introduction
Quick Start Guide
This guide assumes that you are already familiar with computers and can tell
at a glance what and where all the key components are. If you are not that comfortable with this type of device, then please refer to the following pages,
which give an overview of the system.
It is still best to review these steps, before taking any action. If there is anything you are not sure about, then please refer to the appropriate chapter before
continuing.
Unless you need to install an operating system, your computer should be ready
to work right out of the box. Before you begin please follow the safety instructions in the Preface.
1. Remove all packing materials.
2. Securely attach any peripherals you want to use with the computer (e.g.
keyboard and mouse) to their ports.
3. Attach the AC adapter to the DC-in jack at the rear of the computer (see
“Rear View” on page 1 - 19), then plug the AC power cord into an outlet,
and connect the AC power cord to the AC adapter.
4. Raise the LCD Swivel Screen to a comfortable viewing angle.
5. Press the power button to turn “On”.
Peripheral Devices
Please note that peripherals (printers, digital cameras, etc.)
which attach to your
computer by USB
ports may be connected after Windows is
up and running. All other peripherals must be
connected before you
turn on the system.
Introduction
1 - 4 System Map
1
System Map
Your computer has a lot of built-in features. Most of these are enabled by your
operating system. Further explanations of the various subsystems are covered
in the chapter or pages indicated.
Model Differences
This notebook series includes two different model types. Model A includes a
Touch Panel screen, Model B does not. The specifications for each model are
listed in “Appendix A. Model A Specifications” on page A - 1 and “Appendix
B. Model B Specifications” on page B - 1.
In addition both Model A and Model B have two different designs as pictured
on the following page.
System Map 1 - 5
1
Introduction
Getting to Know Your Computer
The following graphics will help you to become familiar with the basic functions, and to learn the location of the various ports and components of your
computer.
Design Differences
This manual refers to
the two notebook designs pictured on this
page.
The designs vary
slightly in external design. Photographs
used throughout this
manual are of Design I.
Design I Design II
Figure 1 - 1
Design Differences
Introduction
1 - 6 Top View
1
Top View
To open the LCD display:
1. Place the computer on a stable surface.
2. Press the latches in the direction of the arrows (press in) to release the
top cover.
3. Lift the top cover to reveal the LCD Swivel Screen and keyboard.
4. Adjust the LCD Swivel Screen to a comfortable viewing angle.
5. The LED indicators show the power and battery status of the computer.
6. If you wish to operate the computer in Tablet Mode see page 1 - 7.
2
11
Figure 1 - 2
Top View with LCD
Panel Closed
1. LCD Latches
2. LED Indicators
1
2
The LCD Swivel Screen 1 - 7
1
Introduction
The LCD Swivel Screen
You can use the computer either in Notebook Mode, or in Tablet Mode. To
put the computer into Tablet Mode:
1. Unlock the LCD side hinges & by moving them in the direction of the
arrows, then lock the side hinges.
2. Carefully rotate the LCD fully in the direction indicated by the arrow .
3. Push the LCD down and lock it in position by moving latches & in and
to the left.
Figure 1 - 3
Rotating the LCD
Swivel Screen
1 2
3
4 5
1 2
3
4
5
1 2
Introduction
1 - 8 The LCD Swivel Screen
1
Top View with LCD Open
Figure 1 - 4
Top View with LCD
Panel Open
1. Built-In PC Camera
(Optional)
2. LCD Swivel Screen
3. LED Power
Indicators
4. Cover Sensors
5. LCD Swivel Hinge
6. LCD Side Hinges
7. Power Button
8. Speakers
9. Keyboard
10. TouchPad and
Buttons
11. Built-In Microphone
2
6
3
4
1
9
7
10
5
8
11
6
8
The LCD Swivel Screen 1 - 9
1
Introduction
PC Camera
If you have purchased the optional PC Camera, make sure you install the software application (see “PC Camera” on page 4 - 8 & 3 - 17).
LCD Swivel Screen
The computer comes with a TFT (Thin Film Transistor), Liquid Crystal Display screen (see “LCD” on page A - 1 for details) with built-in touch panel
functionality. The screen can rotate and tilt for best visibility in Notebook
Mode, and flip for use in Tablet Mode. The screen may be rotated to appear
in Landscape Mode or Portrait Mode by means of the video driver (see “S3
Control Taskbar Utility” on page 3 - 5) or “Q” Hot-Key (see “Q Key Functions” on page 2 - 14).
If your computer is Model A the screen also acts as a Touch Panel when the
driver is installed (see “Touch Panel (Model A Computers)” on page 4 - 9).
You can use a stylus pen (you can also use your finger or any soft-tipped object as the input device) to point directly to objects on the screen in much the
same way as you would use your mouse as the pointing device (see “Touch
Panel (Model A Only)” on page 2 - 17).
LED Power Indicators
These indicators display the system power status, and battery status of the
computer (see “LED Power Indicators” on page 2 - 5).
Touch Panel Input
Device (Model A
Only)
Do not use any sharp
or pointed objects as
your input device e.g.
the end of a pen or
pencil. Ideally you
should only use a stylus pen (PDA type) as
your input device.
Introduction
1 - 10 The LCD Swivel Screen
1
Cover Sensors
These switches act as sensors to tell when the LCD Swivel Panel is closed, or
is in Notebook Mode, or in Tablet Mode.
The left LCD cover sensor is used when the computer is in Notebook Mode,
or the LCD Swivel Panel is closed. When this sensor is activated (e.g. when
the LCD Swivel Panel is closed or you press the sensor) the default setting of
your operating system’s power scheme (“When I close the lid of my portable
computer”) sends the computer into a power saving state (see Figure 3 - 10
on page 3 - 13).
The right LCD cover sensor is used in conjunction with the “Q” Hot-Key, and
when the computer is in Tablet Mode (see “Q Key Functions” on page 2 -
14 for full details). If the computer is in Notebook Mode you can press the
“Q” Hot-Key and right LCD cover sensor simultaneously to rotate the screen
or send the computer in to a power saving state.
The LCD Swivel Screen 1 - 11
1
Introduction
LCD Swivel & Side Hinges
Release the side hinges in the direction indicated by the arrows on the top panel, and swivel the LCD panel in the direction indicated on the top panel.
Power Button
Press this button to turn your computer On or Off (see “Turning on the
Computer” on page 2 - 4).
This button may also be used as a suspend/resume
key, once configured as such in the power management control panel of your
operating system (see “Configuring the Power Button” on page 3 - 13).
Stereo Speakers
Two built-in speakers provide rich, stereo sound.
Forced Off
If the system “hangs”,
and the Ctrl + Alt + Del
key combination
doesn’t work, press the
power button for 4 sec-
onds, or longer, to
force the system to
turn itself off.
Shutdown
Please note that you should always shut your computer down by choosing the Shut
Down/Turn Off Computer command from the Start menu in Windows. This will
help prevent hard disk or system problems.
Introduction
1 - 12 The LCD Swivel Screen
1
Keyboard
The computer has a “Win Key” keyboard including an embedded numeric
keypad. It has the same features as a full-sized desktop keyboard and can easily be replaced with a different language keyboard should you desire.
TouchPad & Buttons
The pointing device features a sensitive glide pad for precise movements. It
functions the same way as a two-button mouse. The right TouchPad button is
the same as the right mouse button; the left TouchPad button is the same as
the left mouse button (see “Configuring the TouchPad and Buttons” on
page 2 - 20).
Microphone
Record on your computer with the built-in microphone.
Front View 1 - 13
1
Introduction
Front View
LCD Latches
Slide the LCD latches to the right to release the LCD panel (slide to the left to
lock the panel down in tablet mode).
Microphone-In Jack
Record on your computer with an external microphone (the microphone-in
jack is colored pink).
Figure 1 - 5
Front View
1. LCD Latches
2. Microphone-In Jack
3. Headphone-Out
Jack
4. Infrared
Transceiver
5. Scroll/Enter Wheel
6. LED Status
Indicators
7. 3 * Hot-Key Buttons
(Esc, Tab, & “Q”
Rotate)
1
2
1
Infrared Communication
The Infrared transceiver operates on a “Line of Sight”. Make sure nothing is blocking the “Line of Sight” between your system’s transceiver and the destination’s
transceiver.
3 4 5
6 7
Introduction
1 - 14 Front View
1
Headphone-Out Jack
Headphones may be connected through this jack (the headphone-out jack is
colored green). Note: Set your system’s volume to a reduced level before connecting to this jack.
Infrared Transceiver
The infrared transceiver enables communication between the computer and
another similarly equipped device, and is 4M bps FIR, IrDA 1.1 compliant.
For further information please refer to the manual of the device you wish to
connect.
Scroll/Enter Wheel
The wheel key works as a scrolling key (in much the same way as the keyboard arrow keys) if moved to the left or right. If you push the key in it will
act as an Enter/Return key.
LED Status Indicators
These display the system’s operational status. Refer to “LED Power Indica-
tors” on page 2 - 5 for more information on what the lights mean.
Front View 1 - 15
1
Introduction
Hot-Key Buttons
The three Hot-Key buttons include Tab & Esc keys (these keys are particularly useful in Tablet Mode), and a “Q” key to rotate the screen between Portrait and Landscape modes it also acts as a lid/power button (see “Q Key
Functions” on page 2 - 14 for full details).
Windows Media
Player and Screen
Rotation
If you are playing a
DVD/VCD video in
Windows Media Player, do not rotate the
screen while playing
the video. If you wish
to rotate the screen,
quit the Media Player
program first, rotate
the screen, then open
the player to play the
video.
Introduction
1 - 16 Left Side View
1
Left Side View
Security Lock Slot
To prevent possible theft, a Kensington-type lock can be attached to this slot.
Locks can be purchased at any computer store.
Vent
This enables airflow to prevent the computer from overheating.
Stylus Pen Holder
Keep the stylus pen in this holder when not in use.
31 2
Figure 1 - 6
Left Side View
1. Security Lock Slot
2. Vent
3. Stylus Pen Holder
Overheating
To prevent your computer from overheating
make sure nothing
blocks the vent/fan intake while the computer is in use.
Right Side View 1 - 17
1
Introduction
Right Side View
4-in-1 Flash Card Reader
The card reader allows you to use four of the most popular digital storage
cards. The formats which can be read include:
• MMC (MultiMedia Card)
• SD (Secure Digital)
• MS (Memory Stick)
• SM (SmartMedia Card)
See “4-in-1 Card Reader” on page 2 - 12.
1 2 3
Figure 1 - 7
Right Side View
1. 4-in-1 Flash Card
Reader
2. 2 * USB 2.0 Ports
3. PC Card Slot
USB Cables
Make sure that your
USB cable connector
is orientated the correct way before inserting it into the USB Port.
It will only fit one way
(don’t force it).
External CD Devices
External CD devices (e.g. CD-ROM drives, DVD-ROM drives, CD-RW drives and
Combination drives) may be plugged in to either of the USB ports.
Introduction
1 - 18 Right Side View
1
2 * USB 2.0 Ports
These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for
low-speed peripherals such as keyboards, mice or scanners, and for highspeed peripherals such as external DVD devices, CD devices, HDDs, digital
video cameras or high-speed scanners etc. Devices can be plugged into the
computer, and unplugged from the computer, without the need to turn the system off (if the power rating of your USB device is 500mA or above, make sure
you use the power supply which comes with the device).
PC Card Slot
The 3.3V/5V slot may be used for a Type-II PC Card (PC Cards were also previously referred to as PCMCIA) and fully supports Cardbus. Refer to “PC
Card Slot” on page 2 - 13 for more information.
Optional USB 2.0 CD
Device
If your purchase includes the external
USB 2.0 CD Device,
you can connect it to
the USB port.
Rear View 1 - 19
1
Introduction
Rear View
External Monitor (CRT) Port
Connect an external VGA monitor (CRT) to this port to allow dual video or
simultaneous display on the LCD and external VGA monitor (see “Display
Devices” on page 3 - 7).
RJ-45 LAN Jack
This port supports LAN (Network) functions.
Note: Broadband (e.g. ADSL) modems usually connect to the LAN port.
Figure 1 - 8
Rear View
1. External Monitor
(CRT) Port
2. RJ-45 LAN Jack
3. RJ-11 Phone Jack
4. DC-In Jack
5. Vent
2
Overheating
To prevent your computer from overheating make sure nothing blocks the vent/fan
intake while the computer is in use.
1 3 4 5
Introduction
1 - 20 Rear View
1
RJ-11 Phone Jack
This port connects to the built-in modem. You may plug the telephone line directly into this RJ-11 telephone connection.
Note: Broadband (e.g. ADSL) modems usually connect to the LAN port.
DC-In Jack
Plug the supplied AC adapter into this jack to power your computer.
Vent
This enables airflow to prevent the computer from overheating.
Bottom View 1 - 21
1
Introduction
Bottom View
Stylus Pen Holder
The stylus pen fits in this holder.
Battery
See “Battery Information” on page 3 - 14 for information on battery use and
care.
Figure 1 - 9
Bottom View
1. Stylus Pen Holder
2. Battery
3. Modem &
Wireless LAN
Module Cover
4. Hard Disk Cover
5. RAM Cover
6. CPU Cover
7. Vent
7
1
2
4
5
3
CPU
The CPU is not a user
serviceable part.
Opening this compartment, or accessing the
CPU in any way, may
violate your warranty.
6
1
Overheating
To prevent your computer from overheating
make sure nothing
blocks the vent/fan intake while the computer is in use.
Introduction
1 - 22 Bottom View
1
Wireless LAN (Network) Module
If your computer has the 802.11b Wireless LAN module the antenna and other
components are not externally visible (please check with your service representative). If your configuration includes the module(s), make sure to install
the driver (see “Wireless LAN” on page 4 - 8). Make sure the wireless mod-
ule is OFF when you are using the computer aboard aircraft (see sidebar
note).
Hard Disk Drive
The internal hard disk drive is used to store your data. See page 6 - 4 for information on upgrading/replacing your hard disk drive.
Vent
This enables airflow to prevent the computer from overheating.
Wireless Device
Operation Aboard
Aircraft
The use of any portable electronic transmission devices
aboard aircraft is usually prohibited.
Make sure the module
is OFF if you are using
the computer aboard
aircraft.
When your computer
‘Boots Up’ the module
will be ON.
To toggle power to the
WLAN module use the
key combination Fn +
F11.
Drive Warning
Don’t try to remove the hard disk (HDD) while the system is on. This could cause
data loss or damage. Unauthorized removal or tampering with the HDD may violate
your warranty. If you are in doubt, consult your service representative.
Using The Computer
Overview 2 - 1
2
Chapter 2: Using The Computer
Overview
To learn more about using your computer, please read this chapter.
This chapter includes:
• The Power Sources
• Turning on the Computer
• The LED Indicators
• The Hard Disk Drive
• The Floppy Disk Drive (Optional)
• CD/DVD Device (Optional)
• 4-in-1 Card Reader
• The PC Card Slot
• The Hot-Keys
• The Keyboard
• The Touch Panel
• The TouchPad & Buttons/Mouse
• Adding a Printer (general guidelines)
Using The Computer
2 - 2 The Power Sources
2
The Power Sources
The computer can be powered by either an AC adapter or a battery pack.
AC Adapter
Use only the AC adapter that comes with your computer. The wrong type of
AC adapter will damage the computer and its components.
1. Attach the AC adapter to the DC-in jack at the rear of the computer.
2. Plug the AC power cord into an outlet, and then connect the AC power cord
to the AC adapter.
3. Raise the LCD Swivel Panel to a comfortable viewing angle.
4. Press the power button to turn “On”.
Power Button as
Standby or Hibernate
Button
Fully ACPI-compliant
OS’s such as Windows
XP can use the “Power
Options” control panel
to set the power button
to send the system into
Standby or Hibernate
mode (see your OS’s
documentation, or
“Configuring the
Power Button” on
page 3 - 13 for de-
tails).
Using The Computer
The Power Sources 2 - 3
2
Battery
The battery allows you to use your computer while you are on the road or an
electrical outlet is unavailable. Battery life varies depending on the applications and the configuration you're using. To increase battery life, let the battery discharge completely before recharging.
We recommend that you do not remove the battery. For more information on
the battery, please refer to “Battery Information” on page 3 - 14.
Recharging the Battery with the AC Adapter
The battery pack automatically recharges when the AC adapter is attached and
plugged into an electrical outlet. If the computer is powered on, and in use, it
will take several hours to fully recharge the battery. When the computer is
turned off but plugged into an electrical outlet, battery charge time is less. (Refer to “LED Indicators” on page 2 - 5 for information on the battery charge
status, and to “Battery Information” on page 3 - 14 for more information on
how to maintain the battery pack.).
Proper handling of the Battery Pack
• DO NOT disassemble the battery pack under any circumstances
• DO NOT expose the battery to fire or high temperatures, it may explode
• DO NOT connect the metal terminals (+, -) to each other
Low Battery Warning
When the battery is
critically low, immediately connect the AC
adapter to the computer or save your work,
otherwise, the unsaved data will be lost
when the power is depleted.
Using The Computer
2 - 4 Turning on the Computer
2
Turning on the Computer
Now you are ready to begin using your computer. To turn it on simply press
the power button on the front panel.
When the computer is on, you can use the power button as a Standby/Hibernate/Shutdown hot-key button when it is pressed for less than 4 seconds
(pressing and holding the power button for longer than this will shut the computer down). Use Power Options in the Windows control panel to configure
this feature.
If the computer is in Tablet Mode you can use the “Q” Hot-Key as a power
button (see “Q Key Functions” on page 2 - 14 for full details).
Shutdown
Note that you should
always shut your computer down by choosing the Shut Down/
Turn Off Computer
command from the
Start menu in Windows. This will help
prevent hard disk or
system problems.
Forced Off
If the system “hangs”, and the Ctrl + Alt + Del key combination doesn’t work, press
the power button for 4 seconds, or longer, to force the system to turn itself off.
Using The Computer
LED Indicators 2 - 5
2
LED Indicators
There are two sets of LED indicators (LED Power Indicators and LED Status Indicators) on your computer that will display helpful information about
the current status of the computer. The LED Power Indicators are also visible when the top of your computer is closed (in Notebook Mode).
LED Power Indicators
Icon Color Description
Orange The AC Adapter is plugged in
Green The computer is on
Blinking Green The computer is in standby mode
Orange The battery is being charged
Green The battery is fully charged
Blinking Orange The battery has reached critically low power status
Table 2 - 1
LED Power
Indicators
Using The Computer
2 - 6 LED Indicators
2
LED Status Indicators
Icon Color Description
Green The WLAN Module is On
Green Hard Disk/System activity
Green Number Lock is activated
Green Caps Lock is activated
Green Scroll Lock is activated (to activate press Fn & ScrLk)
Table 2 - 2
LED Status
Indicators
Using The Computer
Hard Disk Drive 2 - 7
2
Hard Disk Drive
The hard disk drive is used to store your data in the computer. The hard disk
can be taken out to accommodate other 2.5" IDE hard disk drives with a height
of 9.5 mm.
The hard disk is accessible from the bottom of your computer as seen below. Further details on removing and inserting the hard disk are available in
“Upgrading the Hard Disk Drive” on page 6 - 4.
Power Safety
Before attempting to
access any of the internal components of
your computer please
ensure that the machine is not connected
to the AC power, and
that the machine is
turned off. Also ensure
that all peripheral cables, including phone
lines, are disconnected
from the computer.
Figure 2 - 1
Hard Disk Location
1
Hard Disk
1
Using The Computer
2 - 8 The Floppy Disk Drive (Optional)
2
The Floppy Disk Drive (Optional)
The optional external 1.44 MB, 3.5" USB floppy disk drive can connect to
any of the USB ports on the computer. By default it is drive “A:” and can be
used as a boot device if properly set in the BIOS (refer to “Boot Menu” on
page 5 - 18). If your purchase configuration does not include this option you
can purchase a USB floppy disk drive from a computer store.
Inserting/Removing Floppy Disks
When using the floppy drive, always insert your floppy diskette with the labelside facing up. To remove the inserted diskette, press the eject button on the
top-right corner of the floppy drive.
Media Warning
Don’t try to remove a
floppy disk while the
system is accessing it.
This may cause the
computer to “crash”
and damage your data.
sk
Eject Button
Using The Computer
CD Device/DVD Device (Optional) 2 - 9
2
CD Device/DVD Device (Optional)
The optional external CD/DVD Device is USB 2.0 compliant and can connect
to any of the USB ports on the computer. If your purchase configuration does
not include this option you can purchase a USB CD/DVD Device from a computer store.
When used with your computer the device must be powered by an AC power
source via the AC adapter. When used with the AC adapter make sure the
power switch is set to EXT (external power).
Optional CD Device
with Desktop
Computers
You can use the CD
device with desktop
computers without the
AC power adapter (the
power switch should
be set to USB).
Figure 2 - 2
External CD Device
Headphone Jack
Power Switch
AC Adapter
USB 2.0 Cable
Using The Computer
2 - 10 CD Device/DVD Device (Optional)
2
Optional CD/DVD Device Options
The optional external CD device is available in CD-ROM, or DVD-ROM, or
CD-RW, or Combination CD-RW and DVD-ROM drive configurations. The
CD Device is usually labeled “Drive D:”, and may be used as a boot device if
properly set in the BIOS (“Boot Menu” on page 5 - 18).
Loading CDs or DVDs
To insert a CD/DVD, press the eject button and carefully place a CD/DVD
onto the disc tray with label-side facing up (use just enough force for the disc
to click onto the tray’s spindle). Gently push the CD/DVD tray in until its lock
“clicks” and you are ready to start. The LED indicator will light up while data
is being accessed, or while an audio/video CD, or DVD, is playing. If power
is unexpectedly interrupted, insert an object such as a straightened paper clip
into the emergency tray release hole to open the tray.
Using The Computer
CD Device/DVD Device (Optional) 2 - 11
2
Handling CDs or DVDs
Proper handling of your CDs/DVDs will prevent them from being damaged.
Please follow the advice below to make sure that the data stored on your CDROMs/DVD-ROMs can be accessed.
Remember to:
• Hold the CD or DVD by the edges; do not touch the surface of the disc.
• Use a clean, soft, dry cloth to remove dust or fingerprints.
• Do not write on the surface with a pen.
• Do not attach paper or other materials to the surface of the disc.
• Do not store or place the CD or DVD in high-temperature areas.
• Do not use benzene, thinner, or other cleaners to clean the CD or DVD.
• Do not bend the CD or DVD.
• Do not drop or subject the CD or DVD to shock.
CD Emergency Eject
If you need to manually
eject a CD (e.g. due to
an unexpected power
interruption) you may
push the end of a
straightened paper clip
into the emergency
eject hole. However
please do NOT use a
sharpened pencil or
similar object that may
break and become
lodged in the hole.
Using The Computer
2 - 12 4-in-1 Card Reader
2
4-in-1 Card Reader
The 4-in-1 Card Reader allows you to use four of the most popular digital storage cards.
To read from the card, simply insert the card into the slot and it will appear as
a removable device. The formats which can be read include:
• MMC (MultiMedia Card)
• SD (Secure Digital)
• MS (Memory Stick)
• SM (SmartMedia Card)
SmartMedia Cards
Note that SmartMedia
Cards should be inserted as illustrated in
Figure 2 - 3.
Figure 2 - 3
4-in-1 Card Reader
(With SmartMedia
Card)
Using The Computer
PC Card Slot 2 - 13
2
PC Card Slot
The computer is equipped with a PCMCIA 3.3V/5V slot for one type II PC
Card. Make sure you install the driver for the PC Card (see “What to Install”
on page 4 - 2).
Inserting and Removing PC Cards
• Align the PC Card with the slot and push it in until it locks into place.
• To remove a PC Card, simply press the eject button next to the slot.
Figure 2 - 4
PC Card Slot
Conserving Battery
Power
To conserve battery
power remove any unused PC Cards from
the computer (PC
Cards quickly use up
battery power even if
the system enters
sleep mode).
1
1
Using The Computer
2 - 14 Hot-Keys
2
Hot-Keys
The four Hot-Key buttons include Tab & Esc keys (these keys are particularly
useful in Tablet Mode) and a wheel key for scrolling/Enter key functionality.
(Move the wheel left or right for scrolling functions in much the same way as
the keyboard arrow keys; push the wheel in for Enter/Return functions.) In
Tablet Mode the “Q” key is used to toggle the screen rotation between Landscape and Portrait configurations; it also acts as a lid/power button. The table
below lists the function options depending upon the time duration the key is
pressed (see sidebar for use in Notebook mode).
Computer
Power
State
“Q” key function Time Pressed
On Rotate Screen
Less than 0.8 seconds
On
Initiates the default setting of OS’s power
scheme - “When I press the power button
on my portable computer” - (see Figure 3 -
10 on page 3 - 13)
More than 0.8 seconds but
less than 4 seconds
On System Shutdown More than 4 seconds
Off System Power On N/A
Right Cover Sensor
The right LCD cover
sensor
(see “Cover
Sensors” on page 1 -
10) is used in conjunc-
tion with the “Q” HotKey to tell the computer when it is in Tablet
mode (when the computer is in Tablet mode
the right cover sensor
is depressed).
If you are in Notebook
mode you can perform
the same set of functions listed in the table
by pressing the “Q” key
and right cover sensor
simultaneously.
Table 2 - 3
Q Key Functions
Using The Computer
The Keyboard 2 - 15
2
The Keyboard
The Function Keys
On the bottom-left of the keyboard is the Fn key, or Function key, which al-
lows you to change operational features instantly. To use the functions press
and hold the Fn key, then press the appropriate function key (F3 - F11 etc.)
located on your keyboard.
Function Keys Description
Fn + F3 Mute Toggle
Fn + F4 Sleep/Resume Toggle
Fn + F5 Decrease Audio Volume
Fn + F6 Increase Audio Volume
Fn + F7 Display Toggle
Fn + F8
Decrease LCD
Brightness
Fn + F9
Increase LCD
Brightness
Fn + F11
Wireless LAN Module
On/Off Toggle
Other Keyboards
If your keyboard is
damaged or you just
want to make a
change, you can use
any standard USB keyboard. The system will
detect and enable it
automatically. However special functions/hot
keys unique to the system’s regular keyboard
may not work.
Table 2 - 4
Function Keys
Wireless Device Operation
Aboard Aircraft
The use of any portable electronic
transmission devices aboard aircraft is
usually prohibited.
Make sure the module is OFF if you are
using the computer aboard aircraft.
When your computer ‘Boots Up’ the
module will be ON.
To toggle power to the WLAN module
use the key combination Fn + F11.
Using The Computer
2 - 16 The Keyboard
2
Numeric Keypad
The keyboard has an embedded numerical keypad for easy numeric data input.
Activate the Number Lock feature by pressing the Fn and Num Lk key combination. You may check if Number Lock is enabled or not by looking at the
LED status indicators (see “LED Indicators” on page 2 - 5). To type a number from the numeric keypad make sure Num Lk is enabled, then press the
key on the numeric keypad. (To type a letter from the numeric keypad if Num
Lk is enabled, hold down the Fn key and press the appropriate letter key.)
Activate Scroll Lock by pressing the Fn and Scr Lk key combination.
Special Characters
Some software applications allow the
number-keys to be
used with Alt to produce special characters. These special
characters can only be
produced by using the
numeric keypad. Regular number keys (in
the upper row of the
keyboard) will not
work. Make sure that
Num Lock is on.
Figure 2 - 5
Keyboard
Fn Key
Num Lk &
Scr Lk Keys
Numeric Keypad
Function Keys
Numeric Keypad
Using The Computer
Touch Panel (Model A Only) 2 - 17
2
Touch Panel (Model A Only)
If your computer is Model A the screen also acts as a Touch Panel when the
driver is installed (see “Touch Panel (Model A Computers)” on page 4 - 9).
You can use a stylus pen (you can also use your finger or any soft-tipped object as the input device) to point directly to objects on the screen in much the
same way as you would use your mouse as the pointing device
A new icon ( or )will appear in the taskbar (if you do not see the icon go
to the Touch Panel control panel and click the tickbox to display the icon in
the taskbar - see Figure 2 - 7) after you install the Touch Panel driver. Click
this icon to switch your input device (stylus pen, finger, eraser etc.) to act as a
left or right mouse button. The Touch Panel control panel allows you to configure the input options (see over for screen examples).
Touch Panel Input
Device (Model A
Only)
Do not use any sharp
or pointed objects as
your input device e.g.
the end of a pen or
pencil. Ideally you
should only use a stylus pen (PDA type) as
your input device.
Figure 2 - 6
Touch Panel
Control Panel
Using The Computer
2 - 18 Touch Panel (Model A Only)
2
Figure 2 - 7
Touch Panel
Control Panel
Configuration
Options
Using The Computer
TouchPad and Buttons/Mouse 2 - 19
2
TouchPad and Buttons/Mouse
The TouchPad is a device for pointing (controlling input positioning) on the
computer’s display screen by sensing finger movement, and downward pressure.
It is an alternative to the mouse; however, you can also add a mouse to
your computer through one of the USB ports.
The TouchPad buttons function in much the same way as a two-button mouse
(see Figure 2 - 8 on page 2-20 for screen examples).
Mouse Driver
If you are using an external mouse your operating system may be
able to auto-configure
your mouse during its
installation or only enable its basic functions.
Be sure to check the
device’s user documentation for details.
Using The Computer
2 - 20 TouchPad and Buttons/Mouse
2
Configuring the TouchPad and Buttons
Once you have installed the TouchPad drivers (see “What to Install” on
page 4 - 2) you can configure the functions by double-clicking the TouchPad
driver icon on the taskbar. You may then configure the TouchPad tapping,
buttons, scrolling, pointer motion and sensitivity options to your preferences.
You will find further information on this at www.synaptics.com.
Figure 2 - 8
Mouse Properties
Using The Computer
Adding a Printer 2 - 21
2
Adding a Printer
The most commonly used peripheral is a printer. The following conventions
will help you to add a printer, however it is always best to refer to the printer
manual for specific instructions and configuration options.
USB Printer
Most new printers have a USB interface connection. You may use either of the
USB ports on your computer to connect the printer.
Install Instructions:
1. Set up the printer according to its instructions (unpacking, paper tray, toner/
ink cartridge etc.).
2. Turn ON the computer.
3. Turn ON the printer.
4. Connect the printer’s USB cable to one of the USB ports on the computer.
5. Windows will identify the printer and either load one of its own drivers or ask
you to supply one. Follow the on-screen instructions.
Using The Computer
2 - 22 Adding a Printer
2
Parallel Printer
This is still the most common type of printer. A Parallel to USB converter
may be purchased at most computer stores.
Install Instructions:
1. Set up the printer according to its instructions (unpacking, paper tray, toner/
ink cartridge etc.).
2. Attach the parallel cable to the printer.
3. Connect the printer’s parallel cable to the Parallel to USB converter, and
then plug the converter into the USB port.
4. Turn ON the printer.
5. Turn ON the computer.
6. Windows (some operating systems may require a driver to recognize the
parallel to USB adapter) will identify the printer and either load one of its
own drivers or ask you to supply one. Follow the on-screen instructions.
Advanced Controls
Overview 3 - 1
3
Chapter 3: Advanced Controls
Overview
This chapter covers:
• Advanced Video Controls
• Power and Battery Management Features
• PC Camera Module (optional)
• Wireless LAN Module (optional)
Note: All operating system pictures in this manual are from the Microsoft
Windows XP OS.
Drivers
You are unable to use
most advanced controls until the necessary drivers and
utilities are properly installed. If your system
hasn’t been properly
configured (your service representative
may have already
done that for you), refer to “What to In-
stall” on page 4 - 2 for
installation instructions.
Advanced Controls
3 - 2 Advanced Video Controls
3
Advanced Video Controls
This section is about making adjustments for the LCD, and switching display
devices.
Opening the LCD
As you open the lid, adjust it so you can look at the screen straight on, without
any glare. If necessary, adjust the brightness controls (Fn + F8/F9). The Fn +
F7 key combination allows you to toggle through display options if you have
a monitor attached (“Function Key Combination” on page 3 - 7).
Protecting the LCD
Do not allow any foreign objects (i.e. paper
or plastic) to get between the lid/LCD and
the work panel. They
could damage or
scratch the LCD and/or
accidentally activate
the close cover switch.
Figure 3 - 1
Brightness
Controls
Fn
F9
F8F7
Advanced Controls
Video Driver Controls 3 - 3
3
Video Driver Controls
The video interface lets you change the screen resolution and color output to
whatever is most comfortable/efficient for you. This is a matter of hardware,
video memory and the driver for your operating system. The driver interface
shows the available options (see A - 1 & B - 1 for the LCD options).
You can switch display devices from the Display Properties control panel in
Windows as long as the video driver is installed (see “What to Install” on
page 4 - 2).
Making Adjustments for the Display
The higher the resolution you set the LCD for, the more information the LCD
can display on screen. To change the LCD’s resolution and color depth go to
the Display Properties control panel:
1. Click Start, point to Settings (or just click Control Panel) and click Control
Panel (if you are in Category View choose Appearance and Themes).
2. Double-click Display (icon).
3. In the Display Properties dialog box, click Settings (tab).
4. In Screen resolution, move the slider to the preferred setting for
resolution (see in Figure 3 - 2 on page 3-4).
5. In Color quality, click the arrow and scroll to the preferred setting for color
depth (see in Figure 3 - 2 on page 3-4).
Screen Resolution/
Screen Area Note
You may set the resolution to a higher setting than the panel
supports, however this
will require you to pan
(scroll) around the
screen as the display
area will be larger than
what you can see on
the LCD.
1
2
Advanced Controls
3 - 4 Video Driver Controls
3
Display Properties
When the Display Properties control panel is open, click the Advanced
(button) to bring up the options tabs. Clicking through these tabs allows you
to make any video adjustments you require.
Figure 3 - 2
Display Properties
1
2
3
3
Advanced Controls
Video Driver Controls 3 - 5
3
S3 Control Taskbar Utility
With the video driver installed the S3 Control Utility will appear in the taskbar. Click the icon to bring up the menu below. From this menu you can
enable/disable displays, and configure the rotation of the display.
S3 Advanced Display Properties
With the video driver installed additional tabs are available in the Advanced
Display Properties (Figure 3 - 2 on page 3-4). Click Advanced in the Display Properties Control Panel (see “Making Adjustments for the Display” on
page 3 - 3) to see the additional tabs.
Windows Media
Player and Screen
Rotation
If you are playing a
DVD/VCD video in
Windows Media Player, do not rotate the
screen while playing
the video. If you wish
to rotate the screen,
quit the Media Player
program first, rotate
the screen, then open
the player to play the
video.
Figure 3 - 3
S3 Taskbar Utility
Figure 3 - 4
S3 Display Tabs
3
S3
Tabs
Advanced Controls
3 - 6 Video Driver Controls
3
The S3 tabs allow you to adjust the displays and video settings (note some options will only appear when you have attached an external monitor/LCD).
Screen examples are shown below.
Help Menus
Right-click on any item
in the S3 tabs to bring
up the “What’s This?”
button.
Click the button to
bring up the help
menu.
Help Menu
Figure 3 - 5
S3 Display Tabs
Control Panels
Advanced Controls
Display Devices 3 - 7
3
Display Devices
Besides the built-in LCD, you can also use an external VGA monitor (CRT)
as your display device. A VGA monitor connects to the external monitor
(CRT) port
(Figure 3 - 6).
To use an external display:
1. Attach the VGA monitor (CRT) to the external monitor port.
2. Click the icon in the taskbar to bring up the menu to select the CRT (it
should have a tick alongside it) and allow the monitor time to refresh the
display.
OR
1. Attach the VGA monitor (CRT) to the external monitor port.
2. Click Advanced in the Display Properties Control Panel (see “Making
Adjustments for the Display” on page 3 - 3) to see the additional tabs.
3. Select the S3 Display tab.
4. Click to put a tick in the tickbok under the CRT icon.
5. Click Apply > OK and allow the monitor time to refresh the display.
6. Click Yes to confirm the settings.
Figure 3 - 6
Rear View
1
1
Function Key
Combination
You can use the FN +
F7 key combination to
toggle through the display options:
• LCD Only
• CRT Only
•LCD + CRT
Make sure you give the
displays enough time
to refresh.
Advanced Controls
3 - 8 Power Management Features
3
Power Management Features
To conserve power, especially when using the battery, your computer uses the
ACPI power management system. Power management conserves power by
controlling individual components of the computer (the monitor and hard disk
drive) or the whole system.
Advanced Configuration and Power Interface
The ACPI interface provides the computer with enhanced power saving techniques and gives the operating system (OS) direct control over the power and
thermal states of devices and processors. For example, it enables the OS to set
devices into low-power states based on user settings and information from applications. ACPI is fully supported in Windows XP.
Advanced Controls
Enabling Power Options 3 - 9
3
Enabling Power Options
Power Options are enabled through the control panel in your Windows sys-
tem (Power Options). With other operating systems you may have power
management available, so check your documentation.
You may conserve power through individual components or throughout the
whole system.
Figure 3 - 7
Power Options
Control Panel
Advanced Controls
3 - 10 Enabling Power Options
3
Conserving Power (Individual Components)
Turn off Monitor
To conserve power, you can set the monitor to turn off after a specified time.
Turn off Hard Disk
The computer's hard disk motor will be turned off if the hard disk drive has
not been accessed for a specified period of time. If the system reads or writes
data, the hard disk motor will be turned back on.
Resuming Operation
The system can resume from Monitor or
Hard Disk Standby by
pressing a key on the
keyboard.
Figure 3 - 8
Power Schemes
Advanced Controls
Enabling Power Options 3 - 11
3
Conserving Power (System)
With this function you can stop the computer’s operation and restart where
you left off. This system features Standby and Hibernate sleep mode levels
(Hibernate mode will need to be enabled by clicking the option in the Hiber-
nate tab in the Power Options control panel - Figure 3 - 9 on page 3-12).
Hibernate Mode vs. Shutdown
Hibernate mode and Shutdown are the same in that the system is off and you
need to press the power button to turn it on. Their main difference is:
When you come back from hibernation, you can return to where you last left
off (what was on your desktop) without reopening the application(s) and
file(s) you last used.
You can use either method depending on your needs.
Standby Mode vs. Hibernate Mode
If you want to stay away from your work for just a while, you can put the system on standby instead of in hibernation. It takes a longer time to wake up the
system from Hibernate mode than from Standby mode.
Advanced Controls
3 - 12 Enabling Power Options
3
Standby
Standby saves the least amount of power, but takes the shortest time to return
to full operation. During Standby the hard disk is turned off, and the CPU is
made to idle at its slowest speed. All open applications are retained in memory. When you are not using your computer for a certain length of time, which
you specify in the operating system, it will enter Standby mode to save power.
Hibernate
Hibernate uses no power and saves all of your information on a part of the
HDD before it turns the system off. Although it saves the most power it takes
the longest time to return to full operation. You can set your computer to automatically enter Hibernate mode when the battery power is almost depleted.
You will need to enable Hibernate mode from the Hibernate tab in the Power
Options control panel. The system will resume from Hibernate mode by
pressing the power button.
System Resume
The system can resume from Standby
mode by:
• Pressing the power
button
• Pressing the key
combination Fn +
F4
• An alarm resume
that is enabled and
expires
• An incoming call
received on the
modem
Figure 3 - 9
Enable Hibernation
Advanced Controls
Enabling Power Options 3 - 13
3
Configuring the Power Button
The power button may be set to send the computer in to either Standby or Hibernate mode (Figure 3 - 10). In Standby mode, the LED will flash
green. In Hibernate mode the LED will be off. If you are in a power saving
mode set to save power through individual components (e.g. hard disk, monitor), the LED will remain green.
Sleep Button
You may also configure the Sleep/Resume
key combination (Fn +
F4) from the menu illustrated in Figure 3 -
10. In Windows this is
referred to as the
Sleep button.
Figure 3 - 10
Power Options
(Advanced - Power
Buttons)
Power Button
Sleep/Resume
(Sleep) Button
Lid
Advanced Controls
3 - 14 Battery Information
3
Battery Information
Please follow these simple guidelines to get the best use out of your battery.
New Battery
Always completely discharge, then fully charge, a new battery before using it
(see “Battery FAQ” on page 3 - 15 for instructions on how to do this).
Battery Life
Your computer’s battery life is dependent upon many factors, including the
programs you are running, and peripheral devices attached. Power Options
settings in the OS will help prolong the battery life if configured appropriately.
Battery life may be shortened through improper maintenance. To optimize the
life and improve its performance, fully discharge and recharge the battery at
least once every 30 days.
We recommend that you do not remove the battery yourself. If you do need to
remove the battery for any reason see “Removing the Battery” on page 6 - 3.
Caution
Danger of explosion if
battery is incorrectly
replaced.
Replace only with the
same or equivalent
type recommended by
the manufacturer. Discard used battery according to the
manufacturer’s instructions.
Advanced Controls
Battery Information 3 - 15
3
Battery FAQ
How do I completely discharge the battery?
Use the computer with battery power until it shuts down due to a low battery.
Don’t turn off the computer by yourself even when you see a message that indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own (it is best to disable the Power Options
functions in the Control Panel). As the battery nears the end of its life save
and close any critical files.
How do I fully charge the battery?
When charging the battery, don’t stop until the LED charging indicator light
changes from orange to green.
How do I maintain the battery?
Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Conserving Battery Power
The LCD display consumes a lot of power, so lowering the brightness level
will save power. Different applications and external devices consume battery
power even when they are not being used (see the sidebar note for further
recommendations on battery conservation).
Conserving Battery
Power
To conserve battery
power:
Close modem or communication applications when they are not
being used.
Remove any unused
PC Cards from the
computer (PC Cards
quickly use up battery
power even if the system enters sleep
mode).
Disconnect any unnecessary external devices.
Advanced Controls
3 - 16 Via Power Saver 2.0
3
Via Power Saver 2.0
After installing the driver (see “VIA Power Saver” on page 4 - 10) you will
have the VIA Power Saver 2.0 utility available to you. You can click the shortcut on the desktop or the program icon (Startup > Programs/All Programs >
VIA > Power Saver) to bring up the utility. The VIA Power Saver utility will
give you information on power consumption and management. You can configure the settings for best power management when powered by battery (DC
IN) or by the AC adapter (AC IN).
Figure 3 - 11
VIA Power Saver 2.0
Control Panel
Advanced Controls
PC Camera 3 - 17
3
PC Camera
If you have purchased the optional PC Camera you will need to install the device driver for it as indicated in “PC Camera” on page 4 - 8.
After installing the driver you can run the application software by going to the
Camtel USB PC Camera item in the Start > Programs/All Programs menu
and selecting the AMCAP program.
PC Camera Audio Setup
If you wish to capture video & audio with your camera, it is necessary to setup
the audio recording options in Windows.
1. Go to the Start menu and point to Settings (or just click Control Panel) and
click Control Panel, then double-click the Sounds & Audio Devices icon
(Category View > Speech, and Audio Devices).
2. Click Advanced in the Vo lume tab.
3. Click Options (Volume Control) and scroll down and click Properties.
4. Click Recording (Adjust volume for) and click Microphone (check box),
then click OK.
5. Make sure the Select (check box) in the Recording Control panel, under
the Microphone section, is checked (boost the volume as high as it will go).
6. Close the open windows.
Advanced Controls
3 - 18 PC Camera
3
Figure 3 - 12
Audio Setup
Advanced Controls
PC Camera 3 - 19
3
AMCAP
AMCAP is a video viewer useful for general purpose video viewing and testing, and capturing video files to .avi format.
1. Run the AMCAP program from the Start > Programs/All Programs >
Camtel USB PC Camera menu (it is recommended that you set the cap-
ture file before the capture process - see Set Capture File below).
2. Go to the Capture menu heading (if you wish to capture audio make sure
that the Capture Audio option is ticked) and select Start Capture.
3. On the first run of the program (if you have not set the captured file) you will
be asked to choose a file name and size (see the sidebar - Pre-Allocating
File Space) for the captured file. Click Start Capture again.
4. Click OK to start capturing the video, and press Esc to stop the capture.
5. If you wish to, you may go to the File menu and select Save Captured
Video As..., choose a file name and location, then click Open (you can view
the file using the Windows Media Player).
Set Capture File
In AMCAP program you will only be asked to set the capture file name on the
first run of the program. When you run the program the next time the file will
automatically be overwritten with the newly captured file. To avoid overwriting files you can go to the Set Capture File.. option in the File menu, and set
the file name and location before capture. Set the name and location then click
Open
(you can choose Cancel to ignore the file size if prompted).
Pre-Allocating File
Space
You may pre-allocate
the file size for the capture file in the AMCAP
program. You can
choose to ignore this
by clicking Cancel.
Pre-allocating space
on the hard disk can
improve the capture
quality (particularly of
large capture files), by
reducing the amount of
work the hard disk has
to do in finding space
for the video data as it
is being captured.
You may find it helpful
to defragment the HDD
before capture.
Advanced Controls
3 - 20 Wireless LAN Module
3
Wireless LAN Module
If you have purchased the optional IEEE 802.11b Wireless LAN USB module
make sure you install the driver for it (see “Wireless LAN” on page 4 - 8). A
status icon will appear in the taskbar, and a shortcut to the IEEE 802.11b
WLAN utility will appear on the desktop . Double-click the desktop icon
to configure the settings for your WLAN module.
Make sure the module is powered on before installing the driver To toggle
power to the WLAN module use the key combination Fn + F11.
Full instructions for use of the Wireless LAN module are available in the manual installed with the driver. The User Manual is in Adobe .pdf format (Start
menu and point to Programs/All Programs > IEEE 802.11b WLAN Utility
(USB) then select the User Manual).
Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission
devices aboard aircraft
is usually prohibited.
Make sure the module is
OFF if you are using the
computer aboard aircraft.
When your computer
‘Boots Up’ the module
will be ON.
To toggle power to the
WLAN module use the
key combination Fn +
F11.
Drivers & Utilities
Overview 4 - 1
4
Chapter 4: Drivers & Utilities
Overview
This chapter deals with installing the drivers and
utilities essential to the operation or improvement
of some of the computer’s subsystems. The system
takes advantage of some newer hardware components for which the latest versions of most available
operating systems haven’t built in drivers and utilities. Thus, some of the system components won’t
be auto-configured with an appropriate driver or
utility during operating system installation. Instead,
you need to manually install some system-required
drivers and utilities. In this chapter, we group driver
and utility installation instructions by operating
system. The following operating systems are covered.
• Windows XP Professional & Home Editions
Assumption
We assume that you will install all drivers and utilities
from the built-in CD device and it is assigned to “Drive
D:”. In addition, all file extensions can be seen [see
“Navigate (Browse..) to D:” on page 4 - 2].
Drivers & Utilities
4 - 2 What to Install
4
What to Install
The Device Drivers & Utilities + User’s Manual
CD-ROM contains the drivers and utilities neces-
sary for the proper operation of the computer.
Table 4 - 1 on page 4-5 lists what you need to in-
stall manually according to your choice of the operating system. It is very important that the drivers
are installed in the order indicated in the table.
New Hardware Found
If you see the message “New Hardware Found”
(Found New Hardware Wizard) during the
installation procedure (other than when outlined in
the driver install procedure), click Cancel to close
the window, and follow the installation procedure
as directed.
Navigate (Browse..) to D:
You will notice that many of the instructions for driver
installation require you to “Navigate (Browse) to D:”.
In this case “D:” is the drive specified for your CD device. Not all computers are setup the same way, and
some computers have the CD listed under a different
drive letter - e.g. if you have two hard drives (or hard
disk partitions) one may be designated as “Drive C:”
and the other as “Drive D:”. In this case the CD device
may be designated as “Drive E:” - Please make sure
you are actually navigating to the correct drive letter
for the CD device.
When you click the Browse (button) after clicking
Run in the Start menu you will see the “Look in:” dialog box at the top of the Browse window. Click the
scroll button to navigate to My Computer to display
the devices and drive letters.
Drivers & Utilities
What to Install 4 - 3
4
Authorized Driver Message
If you receive a message telling you that the driver
you are installing is not authorized (Digital Signa-
ture Not Found), just click Yes or Continue Anyway to ignore the message and continue the
installation procedure.
You will receive this message in cases where the
driver has been released after the version of Win-
dows you are currently using. All the drivers provided will have already received certification for
Windows.
Version Conflict Message
During driver installation if you encounter any “file
version conflict” message, please click Yes to
choose to keep the existing (newer) version.
Updating/Reinstalling Individual
Drivers
If you wish to update/reinstall individual drivers it
may be necessary to uninstall the original driver.To
do this go to the Control Panel in the Windows OS
and double-click the Add/Remove Programs
item. If you see the individual driver listed (if not
see below), uninstall it, following the on screen
prompts (it may be necessary to restart the computer). Go to the appropriate section of the manual to
complete the update/reinstall procedure for the
driver in question.
If the driver is not listed in the Add/Remove Pro-
grams item:
1. Click Start (menu), point to Settings and click
Control Panel. Double-click System (icon)
and then click Hardware (tab) > Device Man-
ager (button).
2. Double-click the device you wish to update/
reinstall the driver for (you may need to click
“+”).
3. Look for the Update Driver button (check the
Driver tab) and follow the on screen prompts.
Drivers & Utilities
4 - 4 Driver Installation
4
Driver Installation
You have a choice of installation methods to install
your drivers.
Automatic Driver Installation
Insert the Device Drivers & Utilities + User’s Manual CD-ROM and the Drivers Installer application
will run automatically.
1. Check the driver installation order from the table
Table 4 - 1 on page 4-5 (the drivers must be
installed in this order).
2. Double-click the driver you wish to install (do not
press any keys).
3. Follow the installation procedure as listed in the
manual installation process (the automatic
installation procedure eliminates the need to
navigate to the setup executable file).
Manual Driver Installation
Insert the Device Drivers & Utilities + User’s Manual CD-ROM and close the Drivers Installer appli-
cation. Follow the procedures listed in this chapter.
Figure 4 - 1
Drivers Installer
Note: The Touch Panel driver must be installed
manually.
Drivers & Utilities
Driver Installation 4 - 5
4
Table 4 - 1 - Install Procedure
Driver Windows XP Home/ Professional Editions
VIA 4 in 1 page 4 - 6
VIA VGA (Video) page 4 - 6
VIA Audio page 4 - 6
VIA LAN page 4 - 7
Modem page 4 - 7
PCMCIA/PC Card page 4 - 7
PC Camera page 4 - 8
Wireless LAN page 4 - 8
Touch Panel (Manual Install Only for Model A
computers only)
page 4 - 9
Infrared (VIA FIR) page 4 - 9
TouchPad page 4 - 10
VIA USB 2.0 page 4 - 10
VIA Power Saver page 4 - 10
Drivers & Utilities
4 - 6 Windows XP
4
Windows XP
This section covers driver and utility installation instructions for the Windows XP OS.
VIA 4 in 1
1. Click Start (menu) > Run...
2. Navigate (Browse..) to D:\Drivers\4 in
1\VIAHyperion4in1447v.exe and click OK.
3. Click Next > Yes > Next > Next > Next >
Next.
4. Click OK to restart the computer.
VIA VGA (Video)
1. Click Start (menu) > Run...
2. Navigate (Browse..) to
D:\Drivers\VGA\SETUP.EXE and click OK.
3. Click Next > Next > (click Continue Anyway
if asked if you want to continue).
4. Click Finish to restart the computer.
VIA Audio
1. Click Start (menu) > Run...
2. Navigate (Browse..) to
D:\Drivers\Audio\Setup.exe and click OK >
Next > Next.
3. Click Finish to restart the computer.
4. Click the Speaker icon in the taskbar for
configuration options.
Windows XP Service Pack 1
Make sure that you install Windows XP Service
Pack 1 before installing all the drivers for Windows
XP.
Drivers & Utilities
Windows XP 4 - 7
4
VIA LAN
1. Click Start (menu) > Run...
2. Navigate (Browse..) to
D:\Drivers\LAN\setup.exe and click OK >
OK.
3. The network settings can now be configured.
Modem
1. Click Start (menu) > Run...
2. Navigate (Browse..) to
D:\Drivers\Modem\Setup.exe and click OK.
3. Click
(button).
4. Click .
5. The modem is ready for dial-up configuration.
PC Card/PCMCIA
1. Click Start (menu) > Run...
2. Navigate (Browse..) to
D:\Drivers\PCMCIA\Setup.exe and click
OK.
3. Click Next > Next.
4. Click Finish to restart the computer.
Modem Country Selection
Be sure to check if the modem country selection is appropriate for you (Control Panel > Phone and Mo-
dem Options).
Drivers & Utilities
4 - 8 Windows XP
4
PC Camera
1. Click Start (menu) > Run...
2. Navigate (Browse...) to
D:\Drivers\PCCam\SETUP.exe and click
OK.
3. Click Next.
4. Click Finish to restart the computer.
5. To run the application software go to the PC
Camera 301P USB Camera item in the Start
> Programs/All Programs menu, and select
the AMCAP program.
Wireless LAN
Make sure the module is powered on before installing the driver To toggle power to the WLAN module use the key combination Fn + F11.
1. Click Start (menu) > Run
...
2. Navigate (Browse..) to
D:\Drivers\WLAN\Setup.exe and click OK.
3. Click Next > Next > Yes > Next > Next.
4. Click Ye s if you wish to add a shortcut to the
WLAN utility on the desktop.
5. Follow the instructions (Next > Next > OK) to
install the Adobe Acrobat Reader (if you do
not already have Adobe Acrobat Reader
installed) and
click Continue Anyway if asked
if you want to continue.
6. Click Finish and restart the computer.
The Wireless LAN User Manual is in Adobe .pdf
format (Start menu and point to Programs/All
Programs > IEEE 802.11b WLAN Utility (USB)
then select the User Manual).
Drivers & Utilities
Windows XP 4 - 9
4
Touch Panel (Model A Computers)
1. If you can see the My Computer icon on your
desktop (if you cannot see the My Computer
icon go to step 2) click on it once to select it,
then right-click it to make the sub-menu appear
and scroll down to Properties and click on it
(go to step 3).
2. If you cannot see the My Computer icon click
Start (menu), then point to (but don’t click just
highlight it) My Computer. Right-click it to
make the sub-menu appear and scroll down to
Properties and click on it (go to step 3).
3. Click the Hardware (tab), then click Device
Manager (button).
4. Click “+” next to Mice and other pointing
devices (if its sub-items are not shown).
5. Double-click Microsoft Serial Mouse and
click Driver (tab).
6. Click Update Driver (button).
7. When the Hardware Update Wizard appears,
click “Install from a list or specific location
(Advanced)” then click Next.
8. Select “Don’t search. I will choose the driver
to install.” and click Next.
9. Click Have Disk (button) and navigate
(Browse...) to D:\Drivers\Touch Panel and
click Open > OK > Next (click Ye s and/or
Continue Anyway if asked if you want to
continue),
10.Click Finish and close the open windows.
11.See“Touch Panel (Model A Only)” on page 2 -
17.
Infrared (VIA FIR)
1. Click Start (menu) > Run...
2. Navigate (Browse..) to
D:\Drivers\FIR\Setup.exe and click OK.
3. Click Next > Next.
4. Click Finish and restart the computer.
Drivers & Utilities
4 - 10 Windows XP
4
TouchPad
1. Click Start (menu) > Run...
2. Navigate (Browse...) to D:\Drivers\Touch
Pad\Setup.exe and click OK.
3. To continue click Next > Next > Next (click
Continue Anyway if asked if you want to
continue).
4. Click Finish to restart the computer.
5. You may then configure your TouchPad as
outlined in “Configuring the TouchPad and
Buttons” on page 2 - 20.
VIA USB 2.0
1. Click Start (menu) > Run...
2. Navigate (Browse...) to
D:\Drivers\USB\Setup.exe and click OK.
3. To continue click Next > Next.
4. Click Ye s (a prompt will pop-up to ask you if
you want to restart directly after the driver has
completed installation) to restart the computer
after the installation procedure is completed.
VIA Power Saver
1. Click Start (menu) > Run...
2. Navigate (Browse...) to D:\Drivers\Power
Saver 2.0\Setup.exe and click OK.
3. To continue click Next > Yes > Next.
4. Click Finish to restart the computer.
5. See “Via Power Saver 2.0” on page 3 - 16.
BIOS Utilities
Overview 5 - 1
5
Chapter 5: BIOS Utilities
Overview
This chapter gives a brief introduction to the computer’s built-in software:
Diagnostics: the POST (Power-On Self Test)
Configuration:the Setup & FirstWare utilities
If your computer has never been set up, or you are making important changes
to the system (e.g. hard disk setup), then you should review this chapter first
and note the original settings found in Setup. Even if you are a beginner, keep
a record of the settings you find and any changes you make. This information
could be useful if your system ever needs servicing.
There is one general rule: Don’t make any changes unless you are sure of
what you are doing. Many of the settings are required by the system, and
changing them could cause it to become unstable or worse. If you have any
doubts, consult your service representative.
BIOS Settings
Warning
Incorrect settings can
cause your system to
malfunction. To correct
mistakes, return to Setup and restore the Setup Defaults with <F9>.
BIOS Utilities
5 - 2 Important BIOS Settings
5
Important BIOS Settings
Generally speaking you should not have to adjust any of the BIOS settings as
they will already be set for your computer. However the following is a quick
reference to the most important settings you may need to change at some
point.
Option Page # Purpose
Boot Menu 5 - 18
Specifies the order of the devices on which the computer searches for an operating system as it starts
up.
Table 5 - 1
Important BIOS
Settings
BIOS Utilities
The Power-On Self Test (POST) 5 - 3
5
The Power-On Self Test (POST)
Each time you turn on the computer, the system takes a few seconds to conduct a POST, including a quick test of the RAM. However you will only see
the POST screen as illustrated in
Figure 5 - 1 if you have “Enabled” the
Boot-Time Diagnostic option (see “Boot-time Diagnostic Screen: (Ad-
vanced Menu)” on page 5 - 11).
As the POST proceeds, the computer will tell you if there is anything wrong.
If there is a problem which prevents the system from booting, it will display a
system summary and prompt you to run Setup.
If there are no problems, the Setup prompt will disappear and the system will
load the operating system. Once that starts, you can’t get into Setup without
rebooting.
POST Screen &
Phoenix Firstware
Note that you may not
see the POST screen as
illustrated in Figure 5 -
1, if the Boot-Time Di-
agnostic option is disa-
bled.
If you have enabled the
Boot-Time Diagnostic
option then the Phoenix
FirstWare Utilities
menu will not appear.
At any time during the
boot process you can
press the F2 key to enter
the Setup configuration
utility.
BIOS Utilities
5 - 4 The Power-On Self Test (POST)
5
FirstWare Utilities
The FirstWare utilities screen will appear as the computer boots up (you will
see the Logo screen as long as the Boot-Time Diagnostic is Disabled - see
“POST Screen & Phoenix Firstware” on page 5 - 3). The message “Click
mouse or press <Enter> for System Utilities” will appear at the bottom of the
screen. Pressing the Enter key or clicking the mouse will bring up the options.
To enter the Setup utilities scroll, select and click “Launch System Setup”.
You may also access the Setup utilities by pressing the F2 key at any time dur-
ing the boot process. The FirstWare utilities also allow you to select a boot device, set password options, and get information on the system.
BIOS Utilities
POST Screen 5 - 5
5
POST Screen
Post Screen
1. BIOS information
2. CPU type
3. Memory status
4. HDD identification
notice
5. Enter Setup prompt
appears only during
POST
Figure 5 - 1
POST (Sample)
Screen
PhoenixBIOS 4.0 Release 6.0
Copyright 1985-2002 Phoenix Technologies Ltd.
All Rights Reserved
VIA VLINK (CLE2666 + VT8235)
BIOS Version 1.00.P2
KBC Version 1.00.P1
CPU = VIA C3 processor 1.00 GHz
639K System RAM Passed
221K Extended RAM Passed
System BIOS shadowed
Video BIOS shadowed
Fixed Disk 0: IC25N020ATCS04-0
Press <F2> to enter SETUP
5
3
2
1
4
BIOS Utilities
5-6POST Screen
5
Failing the POST
Errors can be detected during the POST. There are two categories, “fatal” and
“non-fatal”.
Fatal Errors
These stop the boot process and usually indicate there is something seriously
wrong with your system. Take the computer to your service representative or
authorized service center as soon as possible.
Non-Fatal Errors
This kind of error still allows you to boot. You will get a message identifying
the problem (make a note of this message!) followed by the prompt:
• Press <F1> to resume,
• <F2> to enter Setup
Press F1 to see if the boot process can continue. It may work, without the cor-
rect configuration.
Press F2 to run the Setup program and try to correct the problem. If you still
get an error message after you change the setting, or if the “cure” seems even
worse, call for help.
