Control your home through your
smartphone!
The product:
џ PS Plug is a Wi-Fi programmable
controller. The device is an Internet
connected relayed module, that
includes a weekly schedule. The
latter could be programmed and
controlled via an Internet
connected PC desktop computer or
a smartphone.
џ PS Plug allows the fast
automatization of every electrical
device, regardless of its
manufacturer or model.
џ The technology set in PS Plug allows
it to connect with any wireless
Internet, without the need of any
additional settings.
џ is an intricate system with PS Plug
which you can manage and adjust
the whole system at your home,
office or villa.
џ allows the users to receive PS Plug
real time information for all
connected devices — their work and
current status.
2
Why choose PS Plug
џ Provides comfort and mobility
џ Optimizes the control of the connected appliances
џ Complete integrated control system
џ Easy to use and user friendly software interface
џ Mobile application running on all mobile OS
could be used forPS Plug
џ Control of small electrical appliances
џ Control of interior and exterior lighting
џ Control of irrigation systems
џ Fan control
џ Presence simulation
3
Technical specifications
4
Switching socket
Air humidity during transportation
Charging block
Working frequency
Size
Working temperature
Storage temperature
Working humidity
Ambient temperature during transportation
Network topology
Protection degree, provided by the shell
10A
from 5% till 90% without condense
90V - 250V AC 50-60Hz
Wi-Fi (b/g/n) 2,4GHz
110x62x73mm (LxWxH)
0°— + 45°C
-20°— + 60°C
5% — 90% without condense
from –20°С till +60°С
Wireless communication
IP20 – in installation position
5
Safety instructions
Please, read before using the device for the first time
The outlined safety procedures below are to be followed while using the current
product. Please, do follow all warnings in the device’s user manual.
General safety instructions
You are the only one responsible for the device’s usage, as well as for any caused
damages in consequence of that. The device’s usage is a subject of the set safety
measures for the customers and their environment. Please do not press the
device too hard. Always use it and its accessories gently and keep them in a clean
place, away from any dust. Do not expose them to open fire or in any proximity to
lighted tobacco products. Do not let the device and its accessories to fall down, do
not throw or fold them. Do not use any aggressive chemicals, detergents or
aerosols for their cleaning. Do not paint them and do not attempt to disassemble
the device or its accessories. That could be accomplished only by a qualified
professional. The device’s working temperature is from 0°С till +45°С and storing
temperature of –20°С till +60°С. For removing electric products’ waste, the
6
national and regional legislations are followed. The device is to be installed in
electric switchboards or in the device/s it will manage and is created to control
household devices and equipment.
Any unauthorized reconstruction and/or product modification is strictly
forbidden following the European safety and approval directives (CE). Services,
settings and repairs could be accomplished only by an authorised service provider.
For its repair use only the original spare parts. The usage of other spare parts could
cause significant damages or injuries. If you notice any damage, please stop using
the device. Before cleaning the device, disconnect it from the power supply. Do
not use any liquids or aerosols.
7
Attention! Damaged power supply cables are a life treat as could lead to an
electric shock.
Do not use the device if there is a damaged cable, power supply cord or network
plug. In case of a fault, turn to a qualified technician!
Do not leave children with the device without supervision!
Do not let children play with the device. They cannot properly assess the danger of
using electric devices. The device is not intended for use by individuals (including
children) with limited physical, sensory or mental capabilities or without any
experience and/or knowledge unless they are controlled by an individual
responsible for their safety or have received instructions on how to use it. Use, set
and keep the product only in places away from children. Do not leave the packing
materials spread aimlessly. They could be a dangerous toy for your children. Your
new device contains many small components with sharp edges that could cause
injuries and upon disassemble - a swallowing or suffocation risk.
8
Electric safety
This device could be used only when powered by the specific supply unit. Every
other way could be dangerous and terminates the validity of any issued device’s
certificate. Use the correct external power supply. The device should be powered
only by the specific power supply as indicated on the nominal electric power
supply’s nameplate. If unsure of the power supply’s type, please turn to the
authorized service provider or to the local electric services company. Please, be
extremely careful. Store and use the device in a place far from water or other
liquids as those could cause a short circuit.
Dangerous environment limitation usages
Do not use this device in gas stations, gas storages, chemical plants or in places
where flow blasting is taking place, locations with potentially explosive
environment, for instance in places such as fueling areas, gas storages, ship holds,
chemical plants, in installations for fuel or chemical transportation or storage and
in zones where the air contains chemicals or particles such as grain, dust or metal
particles. The sparks in such places could cause a blast or fire and in consequence a severe health damage, even death.
9
In case you are in a flammable materials’ environment, the device must be turned
off and the user is to follow all instructions and warning labels. The sparks in such
places could cause fires or explosions, leading to injuries and even death.
We highly recommend to not use the device in fueling areas, workshops or gas
stations. The customers should follow the limitations set for high frequency
devices’ usage in fuel storages, chemical plants or in places of flow blasting work
process.
Damages requiring repair
In case of any of the outlined cases below, unplug the device from the power
supply and look for an authorized service provider or turn to the supplier for
specialized repair: the product had been exposed to rain or moisture, slipped, hit,
damaged or has visible overheating traces.
Even though you are following the user manual, the device is not working
correctly. Do not expose it to heating or in a close proximity to a heating source,
such as radiators, thermal accumulators, furnaces or other equipment (including
amplifiers) that emit heat. Keep your device from any humidity. Never use the
product in rain, in a close proximity to sinks, in other moist environment or in such
10
with high air humidity. If the device ever gets wet, do not attempt to dry it off in a
furnace or a dryer for the risk of damage is high!
Do not use the device after a sudden temperature change. If you are transferring
the device between environments with big temperature and humidity level
differences, it is possible for the steam to condense on the surface and inside of
the device. In order to avoid the device’s damage, please do wait for the moisture
to evaporate before using the device. Do not insert any elements in the device that
are not part of its original accessories!
EU-regulations and disposal
The device fulfills all needed standards for the free movement of goods within the
EU. This product is an electric device and as such must be collected and dispose of
according to the European directive on waste electrical and electronic equipment
(WEEE)
This product is in accordance of the regulations in Directive 2002/95/EC of the
European Parliament and of the Council of 27 January 2003 on the restriction of
11
the use of certain hazardous substances in electrical and electronic equipment
(RoHS) and its recasts.
Burns and fire prevention
Do not use the device if the premises’ temperature goes above 40°C. Keep the
highly flammable materials away from the device. Make sure free air access
around the device is available.
12
PS Plug is a Wi-Fi programmable controller, suitable for domestic and industrial
buildings without the need of additional wiring.
With you can easily control coffee machines, fans, irons, electric bulbs, PS Plug
irrigations systems, and more from your smartphone, watch or tablet.
PS Plug guarantees the high security level and data and login storage via a
secure server.
PS Plug has a user friendly interface and a smartphone application running on all
mobile OS. There is also an option for control via a smartwatch.
PS Plug connects very easily to a chosen Wi-Fi router. This is accomplished via
the proSmart application for your smartphone, smartwatch, PC or tablet. You
can add a new device in three quick and easy steps. Upon installation of the
product the customer is to install according to the user manual to the PS Plug
desired device it would be controlling.
The products complies to the requirements of EN 50491-3.
13
PS Plug is created to work on the following environmental conditions:
- For premises’ work;
- For altitude up to 2000m;
- For ambient temperature from 0°С till +45°С;
- For average maximum air humidity for temperature of up to 31°С 80%, linear decreasing to 30% average humidity for 45°С temperature;
Attention! The protection against inflation and fire spreading is provided by
the terminal equipment in which you would be embedding your device.
Please keep all devices for remote control away from children.
14
Installation guide
Step 1:
1.1 Every PS Plug set includes:
1 pc control block;
1 pc user manual for installation
Unpack the device and take the two main
elements out of the box (Scheme 1).
Connect your PS Plug to any electrical
appliance by placing the device in a Schuko socket.
Scheme 1
Attention! Do not modify or influence the built in protection of the electric
device in any way!
15
16
1.2 Installation
PS Plug is a device meant to be
plugged in a Schuko socket.
(Scheme 2).
Scheme 2
1.3 A few requirements must always be considered and followed during
installation:
- The device’s installation and connection must be accomplished
according to the national legislation for electrical installations.
- All activities on the device’s installation, uninstallation, service
and repair are to be made only after it had been securely removed from
17
the power supply (the controller itself, as well as the chain it controls
through the relayed exit).
- Disengagement tool must be provided for the electric installation
during the device’s installation and the needed safety is to be ensured
for the service provided.
- All connections to the relay’s outputs in the device must be
conducted with conductors with an insulation resistance not lower than that
of the insulated conductors of РVС Т 105°С.
- The device is installed only in a shell allowing the needed level of
protection of the end product. Its installation on accessible surfaces and
covers, allowing the easy access without the use of any instrument, is strictly
forbidden.
- The device’s installation must be accomplished in such a way as to
deem it impossible to accidentally activate the reset button.
18
Step 2: Initial setting up and connection to a chosen Wi-Fi network
In order for the device to work properly, it must be connected to an
Internet network. After installation, wait 10 seconds, press and hold the button
for 5 seconds and track the light indicator on the device!
Attention! In Access Point mode and ProSmartConfig, if you hold the button for 5
seconds the device will reset to initial settings!
2.1 ProSmartConfig mode
The central block’s green light emitting diode starts blinking very rapidly for a
quick period of time. That indicates the device is in ProSmartConfig mode. Please
connect your mobile device to the Wi-Fi network where will be operating PS Plug
in. Open the proSmart mobile app on your smartphone or tablet. If you still do not
have the mobile app installed, you can download it from Google Play store,
Apple store or Windows Phone Store.
19
Log in to your profile with your email and password. If this is your first proSmart
device and you have not registered yet, you can do that in proSmart’s webpage:
https://prosmartsystem.com/en
Press the ‘Add’ button for adding a new device, located in the upper hand side
of the screen.
Press the button ‘PROSMART CONFIG’ (Scheme 3), type in the password of your
selected Wi-Fi network and click on ‘SEARCH’ (Scheme 4).
20
Scheme 4Scheme 3
Watch the green light on the device. When the light goes off and then starts
blinking every 3 seconds, PS Plug is ready to work.
Look at the mobile device’s screen. The app is now ready to control .PS Plug
If you have used ProSmart Config mode, please proceed to Step 3.
21
2.2 AP (Access Point) mode
If you do not wish to use this mode, press twice the button quickly and the device
will be transferred to standard connection mode AP.
The green light emitting diode blinks in an interval of one second. This indicates
that the device's Wi-Fi module is in AP mode and you can connect to it through
your PC or mobile device.
2.2.1 Initiate a wireless network search from your smartphone or laptop and
connect to the PS Plug’s AP (the wireless network). Every device creates a
network with its own name, starting with BSwitch_xxx and a combination of
letters and numbers. For example BSwitch_254 and it does not require a
password for access.
22
Scheme 5
2.2.2 After connecting, your browser will automatically open a new page giving
you the chance to choose the wireless network, to which you want to connect
the device (Scheme 5).
If your browser does not open automatically, please open it manually for the
automatic opening of the browser is a manual setting and thus it could be
turned off.
23
2.2.3 If your
smartphone, tablet or
laptop did not
automatically load the
settings page, as shown
in Scheme 5, it could be
accomplished manually.
Open your browser and
write the following
address: 192.168.10.1
Scheme 6
2.2.4 Choose the desired Wi-Fi network, type in your password and click
on the ‘Connect’ button - Scheme 6
2.2.5. In up to 20 seconds will switch to a working mode and thePS Plug
light indicator will be on all the time, blinking shortly every second.
Congratulations! You connected your device successfully and can now add
your profile in https://prosmartsystem.com/en so you can control and monitor
its work.
24
2.3 Working mode – When PS Plug is in Working mode, the green light blinks
every 3 seconds. If you hold the button for 5 seconds, PS Plug will go to settings
in ProSmartConfig mode.
Step 3: User profile creation:
3.1 Once connected to the Internet, becomes invisible to the otherPS Plug
devices in the network. The only way to connect with is via the userPS Plug
profile, associated with the particular device. If you do not have one, you can
load the proSmart’s page: https://prosmartsystem.com/en or download and
install the proSmart app in your smartphone or tablet:
25
3.2 If you choose to use a browser,
open
https://prosmartsystem.com/en in
your PC desktop or mobile device
and press the ‘Log in’ button in the
upper right corner (Scheme 7).
Scheme 7
3.3 If you access the website or the app for the first
time, you need to register or log in with your Facebook
or Google + accounts by just clicking the particular
button. (Scheme 8).
Scheme 8
26
3.4 New user registration.
Fill in the registration form and click the
‘Register ’ button. You are now
registered and may enter the app.
(Scheme 9).
Scheme 9
27
Step 4: Adding a device
If you have used ProSmartConfig mode from step 2, please proceed to step 4.3.
4.1 Home Screen —After the successful login with username and password, you
should already be seeing the home screen in your profile and can add the device
you have received. Enter the serial number of your device that you PS Plug
previously connected to the wireless network (Scheme 10).
Scheme 10
4.2 Click on the ‘Search’ button and after successfully finding your device, the
application will redirect you to the main controlling screen (Scheme 11).
28
Scheme 11
In order to set a name for your device, as well as a time zone and location, press
the button in the upper right corner and fill in the fields (Scheme 12). From
that window you can also delete the device from your profile via
clicking the deletion button in the bottom right corner.
29
Scheme 12
4.3 You can now set and control your device.
In the upper left corner you can find three buttons: Main screen, Schedule
and Graphics (Scheme 13).
Main screen
Schedule Graphics
Scheme 13
30
Step 5: Main screen
5.1 On the main screen are the operating mode buttons (Scheme 11):
џ Off - the device does not work
џ Manual - the device is on
џ Schedule - the device performs the schedule
5.2 Timer - When selecting Timer, the appliance switches on and remains
switched on according to the user's set time. After the set time has elapsed, the
PS Plug returns automatically to the previous mode of operation (Scheme 14)
Scheme 14
31
5.3 Sharing devices
From the Shared devices menu via a button , placed in the upper right
corner of the proSmart application‘s screen, every device’s owner can share
them with other registered users via an email.
Step 6: servicingPS Plug
6.1 is cleaned with a dry or slightly dampened with water towel.PS Plug
The use of aggressive or abrasive cleaning liquids is strictly forbidden.
32
Warranty
The warranty of the device is 24 months from the date of purchase. The serial
number of the device is unique and you need to present it in the event PS Plug
of a problem during the warranty period.
The warranty will not be recognized if any of the following events occur:
• Lost or counterfeited warranty card;
• Damages, caused from wrong installation and exploitation;
• Attempted repair from an unauthorized service provider;
• Chemical, electrical or other influence on the product, which is not part
of its natural usage.
• Distorted physical integrity of the device
All claims under the warranty are to be directed at the shop the device had
been bought from or directly at the manufacturer Pro Smart Inc.
Manufacturer:
Pro Smart Inc
78 Maestro Kanev Str.
1618 Sofia, Bulgaria
prosmartsystem.com/en
Loading...
