USER MANUAL

Model PSVR65

Important Information

WARNING

To reduce the risk of fire or shock hazard, do not expose this VCR to rain or moisture.

Cautions

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: To reduce the risk of electric shock, match wide blade of plug to wide slot, fully insert.

ATTENTION: Pour Žviter les chocs Žlectriques, introduire la lame la plus large de la fiche dans la borne correspondante de la prise et pousser jusqœ au fond.

Refer to the identification/rating label on the back of the product for the proper operating voltage.

FCC Regulations state that unauthorized changes or modifications to this equipment may void the userÕs authority to operate it.

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol indicates Òdangerous voltageÓ inside the product that presents a risk of electric shock or personal injury.

This symbol indicates important instructions accompanying the product.

This reminder is provided to call your attention to Article 820-40 of the National Electrical Code (Section 54 of the Canadian Electrical Code, Part 1) which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.

Product Registration

Please fill out the product registration card and return it immediately. Returning this card allows us to contact you if needed.

Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the serial and model numbers in case you need them. The numbers are located on the back of the VCR.

Model No. ___________________________________________________________________

Serial No. ____________________________________________________________________

Purchase Date: _______________________________________________________________

Dealer/Address/Phone: ______________________________________________________

_____________________________________________________________________________

PSVR65

Table of Contents

Hooking Up the VCR

Choosing a Hookup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Antenna or Cable System Without a Cable Box . . . . . . . .3

Cable System With Cable Box to

Unscramble All Channels . . . . . . . . . . . . . . . . . . . . . .4

Cable System With Cable Box to

Unscramble Only Pay Channels . . . . . . . . . . . . . . . .5

Digital Satellite Receiver . . . . . . . . . . . . . . . . . . . . . . . . . .6-7

Connecting Two VCRs for Copying Tapes . . . . . . . . . . . .8

Setting Up the VCR

Startup

Check Accessories With VCR . . . . . . . . . . . . . . . . . .9

Attach Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Insert Batteries in Remote . . . . . . . . . . . . . . . . . . . . .10

Use the on-Screen Menu System . . . . . . . . . . . . . . .10

Turn on the TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Turn on the VCR . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Set Up a Digital Satellite

Receiver and Cable Box . . . . . . . . . . . . . . .11-13

Use the CHANNELS Menu to Set Up

a Digital Satellite Receiver or Cable Box . . .13

Set Up Clock and Auto Channel Search . . . . . . . . .14

Use SETUP menu to Auto Clock Set . . . . . . . . . . . .15

Use SETUP menu to Auto Channel Search . . . . . .15

Set Up VCR Plus+ Channels . . . . . . . . . . . . . . . . . .15

Program VCR for VCR1 or VCR2¥DVD Buttons .16 Add or Remove Channels From VCRÕs Memory .16

Select a Language/Choisissez une Langue . . . . . .16

Use TV¥VCR Button . . . . . . . . . . . . . . . . . . . . . . . . .17

Set Auto TV/VCR Feature . . . . . . . . . . . . . . . . . . . .17

Using the Remote Control

Light Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Component Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

VCR Function Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

TV, Cable Box, and Satellite Receiver

Function Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Controlling the VCR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Controlling a Laserdisc Player or DVD Component . . .21

Controlling a TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Controlling a Cable Box or a Satellite Receiver . . . . . . .23

Controlling an Auxiliary Component . . . . . . . . . . . . . . .24

Playing a Tape

To Play a Tape . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Using the Playback Features . . . . . . . . . . . . . . . . . . . .26-32

Auto Play Feature . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Pause for Stop-Action . . . . . . . . . . . . . . . . . . . . . . . .26

Slow Motion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Picture Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Frame Advance . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Automatic Tracking . . . . . . . . . . . . . . . . . . . . . . . . . .27

Manual Tracking . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

DISPLAY Button . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Program Information . . . . . . . . . . . . . . . . . . . . . . . .28

Time Counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Auto Repeat Feature . . . . . . . . . . . . . . . . . . . . . . . . .29

Tape Playback HI-FI/LINEAR/MIX Feature . . . .30

Pro-Tect Plusª Locking Feature . . . . . . . . . . . . . . .30

Index Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Go-To Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Blank Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Playback and Recording Feature

COMMERCIALAADVANCE . . . . . . . . . . . . . . . . . . .33-34

Recording a Program

Basic Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Recording Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Program Express Recording . . . . . . . . . . . . . . . . . . . . . . .36

Express Recording (XPR) . . . . . . . . . . . . . . . . . . . . . . . . . .37

Recording While YouÕre Away

VCR Plus+ and Timer Recording . . . . . . . . . . . .38-43

Recording Broadcast Stereo TV or SAP . . . . . . . . . . . . . .44

Recording Audio Only . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Using Two VCRs for Copying

and Editing Tapes . . . . . . . . . . . . . . . . . . . . . . . .46-47

Reference

Controls (Front Panel, Back Panel,

and Display Panel) . . . . . . . . . . . . . . . . . . . . . . . .48-50

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Cleaning the VCR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . .52-54

Questions and Answers About

CommercialAAdvanceª . . . . . . . . . . . . . . . . . . . . .55

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

Hooking Up the VCR

The hookups on pages 3 through 7 are divided into two hookup types: Basic (A) and Advanced (B and C).

The basic hookup shows the backs of TVs that have only an antenna/cable connection. It is the easier of the two and additional accessories may not be needed.

The advanced hookup shows the VCR hooked up to a TV with audio and video jacks. This connection may improve the picture quality as well as convenience of operation.

Choosing a Hookup

Answer the questions to choose the hookup for your VCR.

1. How does your TV receive signals?

Choose one answer from below.

A. Outside antenna Ð Turn to page 3.

B. Rabbit ears (set-top) and/or bow tie antenna Ð Turn to page 3.

C. Cable System Ð Go to question 3.

D. Satellite System and another source (A, B, C) Ð Go to question 3.

2. What type of cable-TV system* do you have?

Choose one answer from below.

A. Cable without a box Ð Turn to page 3.

B. Cable box to unscramble all the channels Ð Turn to page 4.

C. Cable box to unscramble only pay channels, such as HBO, Showtime, Cinemax, etc. Ð Turn to page 5.

*You may need to contact your local cable company for assistance.

3. What type of satellite system do you have?

Choose one answer from below.

A. Satellite receiver connected to TV without audio/video inputs Ð Turn to page 6.

B. Basic satellite receiver connected to TV with audio/video inputs Ð Turn to page 7.

C. Deluxe satellite receiver connected to TV with audio/video inputs Ð Turn to page 7.

Optional Hookups

How to Hook Up Two VCRs for Copying Tapes

1. Select a hookup by answering the questions above.

2. Then modify the connections as shown on page 8.

Antenna or Cable System Without a Cable Box

3 4

AUDIO

VIDEO

IN OUT

Back of VCR

Back of TV

300/75 Ohm

Adapter

From Antenna

or Cable

Cable/

Antenna

VHF

UHF

RF Coaxial Cable

(supplied)

75 to 75/300 Ohm

Separator

FROM

ANTENNA

OUT

TELEVISION

MONO

3 4

AUDIO

VIDEOR

IN OUT

S-VIDEO

AUDIO

CABLE / ANTENNA

L /

MONO

RIGHT

VIDEO INPUT

INOUT

Back of TV

Back of VCR

Audio/Video Cables

FROM

ANTENNA

OUT

TELEVISION

From Antenna

or Cable

300/75 Ohm

Adapter

RF Coaxial Cable

(supplied)

MONO

Antenna or Cable System Without a Cable Box

Basic Hookup

Use this hookup for a simple connection which requires fewer accessories.

1. Set the CH3 CH4 switch on back of VCR to either channel 3 or 4.

Tune the TV to this channel and use the TV¥VCR button to watch the VCR.

2. Connect as shown.

This connection may require additional accessories not provided.

3. Plug in power cords of VCR and TV.

4. Go to page 9 for VCR setup information.

Advanced Hookup

Use this hookup for slightly improved picture quality, hi-fi stereo playback, and more convenient operation Ñ use of TV¥VCR button not required.

1. Connect as shown.

This connection requires additional accessories not provided.

If your TV is not stereo, a Y-adapter may be required to hear sound from both channels.

2. Plug in power cords of VCR and TV.

3. Go to page 9 for VCR setup information.

You will tune the TV to its video input to watch the VCR.

Set the Auto TV/VCR feature to OFF. (See page 17.)

Hooking Up the VCR

3 4

AUDIO

VIDEOR

IN OUT

Back of VCR

OUTIN

Cable Box

From Cable

RF Coaxial

Cable

Back of TV

Cable/

Antenna

VHF

UHF

RF Coaxial Cable

(supplied)

75 to 75/300 Ohm

Separator

FROM

ANTENNA

OUT

TELEVISION

MONO

Cable System with Cable Box to Unscramble All Channels

Position Cable Box

Position the remote-controllable cable box on top of the VCR. You may need to position it at different angles before the VCR can control it. Make sure the cable box does not cover the transmitting window on top of the VCR.

Basic Hookup

Use this hookup for a simple connection which requires fewer accessories.

1. Set the CH3 CH4 switch on back of VCR to either channel 3 or 4.

You will tune the TV to this channel and use the TV¥VCR button to watch the VCR.

2. Connect as shown.

This connection may require additional accessories not provided.

3. Plug in power cords of VCR, TV, and cable box.

4. Go to page 9 for VCR setup information.

Remote Sensor

Cable Box

Transmitting Windows

Advanced Hookup

Use this hookup for slightly improved picture quality, hi-fi stereo playback, and more convenient operation Ñ use of TV¥VCR button not required.

1. Connect as shown.

This connection requires additional

accessories not provided.

If your TV is not stereo, a Y-adapter may be required to hear sound from both channels.

2. Plug in power cords of VCR, TV, and cable box.

3. Go to page 9 for VCR setup information.

You will tune the TV to its video input to watch the VCR.

Set the Auto TV/VCR feature to OFF. (See page 17.)

Caution: The unauthorized recording of satellite broadcasts, television programs, or other materials may infringe the rights of others.

From Cable

Back of VCR

MONO

IN OUT

AUDIO

S-VIDEO

Back of TV

Cable Box

RF Coaxial

Cable

VIDEOR

IN OUT

Audio/Video Cables

VIDEO INPUT

RIGHT

INOUT

AUDIO

L /

MONO

3 4

CABLE / ANTENNA

OUTIN

FROM

ANTENNA

OUT

TELEVISION

RF Coaxial Cable

(supplied)

Cable System with Cable Box to Unscramble Only Pay Channels

3 4

AUDIO

VIDEOR

IN OUT

Back of VCR

OUTIN

Cable Box

From Cable

RF Coaxial

Cable

Back of TV

Cable/

Antenna

VHF

UHF

RF Coaxial Cable

(supplied)

75 to 75/300 Ohm

Separator

FROM

ANTENNA

OUT

TELEVISION

MONO

Cable System with Cable Box to Unscramble Only Pay Channels

(such as HBO, Showtime, Pay-Per-View, etc.)

Position Cable Box

Basic Hookup

Use this hookup for a simple connection which requires fewer accessories.

1. Set the CH3 CH4 switch on back of VCR to either channel 3 or 4.

You will tune the TV to this channel and use the TV¥VCR button to watch the VCR.

2. Connect as shown.

This connection may require additional accessories not provided.

3. Plug in power cords of VCR, TV, and cable box.

4. Go to page 9 for VCR setup information.

Remote Sensor

Cable Box

Transmitting Windows

Advanced Hookup

Use this hookup for slightly improved picture quality, hi-fi stereo playback, and more convenient operation Ñ use of TV¥VCR button not required.

1. Connect as shown.

This connection requires additional accessories not provided.

If your TV is not stereo, a Y-adapter may be required to hear sound from both channels.

2. Plug in power cords of VCR, TV, and cable box.

3. Go to page 9 for VCR setup information.

You will tune the TV to its video input to watch the VCR. All pay channels are viewed through the VCR.

From Cable

RF Coaxial Cable (supplied)

Signal Splitter

Cable Box

OUTIN

MONO

IN OUT

AUDIO

S-VIDEO

Back of TV

Back of VCR

VIDEOR

IN OUT

Audio/Video Cables

VIDEO INPUT

RIGHT

INOUT

AUDIO

L /

MONO

3 4

CABLE / ANTENNA

FROM

ANTENNA

OUT

TELEVISION

Hooking Up the VCR

3 4

AUDIO

VIDEOR

IN OUT

VIDEO R AUDIO L

S-VIDEO

CH3 CH4

IN FROM ANT

SATELLITE IN

OUT TO TV

Back of VCR

Back of Satellite Receiver

From

Satellite

Dish

RF Coaxial Cable

Audio/Video Cables

(supplied)

From

Cable, Cable Box

or Antenna

Back of TV

Cable/

Antenna

VHF

UHF

RF Coaxial Cable

(supplied)

75 to 75/300 Ohm

Separator

FROM

ANTENNA

OUT

TELEVISION

MONO

Digital Satellite Receiver

Position the Receiver

Position the receiver above the VCR. You may need to position it at different angles before the VCR can control it. Make sure the receiver does not cover the transmitting window on top of the VCR.

Do not stack electronic components or other objects on top of the satellite receiver. The slots on top of the receiver must be left uncovered to allow proper airflow to the unit. Blocking the airflow to the unit could impair performance or damage your receiver and other components. Also, do not stack the satellite receiver on top of a Òhot componentÓ such as an audio power amplifier.

Basic Hookup

Use this hookup if your TV does not have audio/video jacks.

1. Set the CH3 CH4 switch on the back of the satellite receiver to either channel 3 or 4.

You will tune the VCR to this channel or its

line input (L1) to record from the receiver.

To watch the satellite receiver, turn off the VCR.

If you want to watch or record the signal from your antenna, cable, or cable box, make sure the satellite receiver is turned off.

2. Set the CH3 CH4 switch on back of VCR to either channel 3 or 4.

Satellite Receiver

Remote Sensor

Transmitting Windows

You will tune the TV to this channel and use the TV¥VCR button to watch the VCR.

3. Connect as shown.

This connection may require additional accessories not provided.

4. Plug in power cords of VCR, TV, and receiver.

5. Go to page 9 for VCR setup.

Caution: The unauthorized recording of satellite broadcasts, television programs, or other materials may infringe the rights of others.

Digital Satellite Receiver

3 4

AUDIO

VIDEOR

IN OUT

VIDEO R AUDIO L

S-VIDEO

CH3 CH4

IN FROM ANT

SATELLITE IN

OUT TO TV

S-VIDEO

AUDIO

CABLE / ANTENNA

L /

MONO

RIGHT

VIDEO

INPUT

INOUT

Back of TV

Audio/Video Cables

(supplied)

Back of VCR

Back of Satellite Receiver

From

Satellite

Dish

RF Coaxial Cable

(supplied)

RF Coaxial Cable

From

Cable, Cable Box

or Antenna

FROM

ANTENNA

OUT

TELEVISION

MONO

Advanced Hookup with Basic Receiver

Use this hookup if your TV has audio/video jacks

and your receiver has one set of AUDIO/VIDEO

jacks.

1. Set the CH3 CH4 switch on back of receiver to either channel 3 or 4.

You will tune the VCR to this channel to record from the satellite receiver.

To watch the satellite receiver, tune your TV to its video input channel.

If you want to watch or record the signal from your antenna, cable, or cable box, make sure the satellite receiver is turned off.

2. Set the CH3 CH4 switch on back of receiver to either channel 3 or 4.

You will tune the TV to this channel and use the TV¥VCR button to watch the VCR.

RCA Satellite Receiver

3. Connect as shown.

This connection may require additional accessories not provided.

4. Plug in power cords of VCR, TV, and receiver.

5. Go to page 9 for VCR setup information.

Advanced Hookup with Deluxe Receiver

Use this hookup if your TV has audio/video jacks

and your receiver has two sets of AUDIO/VIDEO

jacks.

1. Set the CH3 CH4 switch on back of receiver to either channel 3 or 4.

You will tune the TV to this channel and use the TV¥VCR button to watch the VCR.

To record from the satellite receiver, you will

tune the VCR to its line input (L1).

To watch the satellite receiver, tune your TV to its video input channel.

2. Connect as shown.

This connection may require additional accessories not provided.

3. Plug in power cords of VCR, TV, and receiver.

4. Go to page 9 for VCR setup information.

CH3 CH4

Back of Satellite Receiver

IN FROM ANT

OUT TO TV

S-VIDEO

VIDEO R AUDIO L

Audio/Video Cables

(supplied)

MONO

VIDEOR

AUDIO

IN OUT

Audio/Video Cables

VIDEO INPUT

RIGHT

AUDIO

L /

MONO

IN OUT

S-VIDEO

Back of TV

From Cable Box or Antenna

SATELLITE IN

From

Satellite

Dish

Back of VCR

FROM

ANTENNA

OUT

TELEVISION

3 4

RF Coaxial Cable

INOUT

CABLE / ANTENNA

(supplied)

3 4

AUDIO

VIDEOR

IN OUT

3 4

AUDIO

VIDEOR

IN OUT

Playback VCR

RF Coaxial Cable

(supplied)

Recording VCR

Audio/Video

Cables

RF Coaxial

Cable

Use the previously selected

hookup to the TV.

From Antenna, Cable

or Cable Box

FROM

ANTENNA

OUT

TELEVISION

FROM

ANTENNA

OUT

TELEVISION

MONO

Hooking Up the VCR

Connecting Two VCRs for Copying Tapes

Basic Hookup

Use this hookup for a simple connection which requires fewer accessories.

1. Select a hookup from pages 2 - 7, and then modify with this connection.

2. Set the CH3 CH4 switch on the playback VCR to either channel 3 or 4.

You will tune the recording VCR to this channel to receive the signal from the playback VCR.

3. Connect as shown.

This connection may require additional accessories not provided.

4. Plug in power cords of VCRs and TV.

5. Go to page 9 for VCR setup information.

Caution: The unauthorized recording of satellite broadcasts, television programs, or other materials may infringe the rights of others.

Advanced Hookup

Use this hookup for slightly improved copy quality and more convenient operation Ñ use of TV¥VCR button not required.

1. Select a hookup from pages 2 - 7, and then modify with this connection.

2. Connect as shown.

This connection requires additional accessories not provided.

If your other VCR is not stereo, plug this VCR into the AUDIO L MONO jack of the other VCR to hear sound from both channels.

3. Plug in power cords of VCRs and TV.

4. Go to page 9 for VCR setup information.

You will select the line input (audio/video) on the recording VCR to receive the signal from the playback VCR.

Playback VCR

MONO

Audio/Video

IN OUT

AUDIO

IN OUT

AUDIO

Cables

VIDEOR

IN OUT

Audio/Video

Cables

VIDEOR

IN OUT

RF Coaxial

Use the previously selected

hookup to the TV.

3 4

Recording

VCR

3 4

Cable

FROM

ANTENNA

OUT

TELEVISION

From Antenna, Cable

FROM

ANTENNA

OUT

TELEVISION

or Cable Box

Setting Up the VCR

MUTE

PREV CH

DISPLAY

INPUT

TV•VCR

CLEAR

SPEED

REW

PLAY FF

STOP

PAUSE

REC

PROG

•

SLOW

TRACKING

•

VCR•DVD

1 4 7

2 5 8

PWR

VOL

EDIT

F.ADV

MOVE

2nd

1st

Setting Up the VCR

Now that you have properly connected the TV and VCR, you are ready to set up the VCR to meet your personal needs. This section discusses the basic setup necessary for your VCR to operate properly.

Startup

Check Accessories With VCR

Contact your dealer if any items are missing.

4 “AAA” Batteries

Remote

(Stock No. 232843)

Attach Power Cord to Back of VCR

RF Coaxial Cable

(Stock No. 221396)

Power Cord

(Stock No. 218104)

Startup

PROG

•

1 4 7

2 5 8

MOVE

MENU CLEAR

CHANNEL

DISPLAY

TRACKING

Insert Batteries In Remote

Use the On-Screen Menu System

Point and Select is the method you use to move through the menu system. There are two ways to access (or change) a menu or feature: number buttons and arrow buttons. Only the number buttons are referenced throughout this manual to explain the VCR features and operations.

Using the Number Buttons

Press MENU¥PROG to display the VCR MAIN MENU. Then use the number button on the remote that corresponds to the number on the menu to select (or change) an item. Using the number button allows you to point and select a menu item at the same time.

Using the Arrow Buttons

Press MENU¥PROG on the remote or MENU on the VCR to display the VCR MAIN MENU. Then use the or arrow button to point to a menu or item. Press MENU¥PROG on the remote or MENU on the VCR to select (or change) the item.

The and arrow buttons move from one location to another. Use these buttons to select a function such as minutes or hours during clock set. Then use the up and down arrows to change.

Turn On the TV

1. Turn on the TV.

2. If you use one of the basic hookups, tune the TV to the channel selected with the CH3 CH4 switch on back of VCR.

If you used one of the advanced hookups, tune the TV to the TVÕs video input. (See TV ownerÕs manual for details.)

Remote

Buttons Located

Behind Left

Turn On the VCR

1. Press VCR1 on the remote.

The first time you turn on the VCR, the SETUP menu will appear. Follow the steps on the screen to automatically set-up a satellite receiver or cable box, set the time, auto channel search, and select some feature options.

■ Press number button 1 on the remote to Begin setup. Proceed to Auto

satellite receiver and/or cable box Setup.

■ Press number button 2 on the remote to Cancel the setup.

If you choose not to use the SETUP menu, follow the steps below to manually set up the VCR so it will operate properly.

If the SETUP menu does not appear, or you prefer, you can manually select the SETUP menu. Each of these features may also be performed individually.

To manually select the SETUP menu.

■ Press MENU¥PROG to display the VCR MAIN MENU.

■ Press 5 to display the SETUP menu.

Setting Up the VCR

SETUP

The setup procedure will help you configure your VCR. Would you like to begin the setup procedure now?

1 Begin setup 2 Cancel

Set Up a Digital Satellite Receiver and/or Cable Box

The DSS and cable box setups allow the VCR to record programs from a compatible cable box and/or satellite receiver.

■ The VCR will turn on a digital satellite receiver and tune it to the channel you

want to record during timer recordings. Position the receiver above the VCR to receive the infrared remote signal. (See pages 6-7.)

■ If your cable box can be controlled by remote, the VCR may be able to tune it

to the channel you want to record during VCR Plus+ and timer recordings. Position the remote-controllable cable box on top of the VCR to receive the infrared remote signal. (See pages 4-5.)

Set Up a Digital Satellite Receiver

1. Satellite receiver not used:

Press 2. Setup is not required.

Satellite receiver used:

Press 1 to continue.

2. Press two numbers on the remote to enter the channel that your VCR receives signals from the receiver. Press 0 before a single-digit number. Valid numbers are 02 Ð 69. Channels 3 and 4 are typical selections; however, some satellite receiver models permit you to use a vacant UHF channel. Refer to your receiver ownerÕs manual for details.

If you connected your receiver to the VCR using the receiverÕs AUDIO/VIDEO OUT jacks, press INPUT to select VIDEO1 or VIDEO2.

Press CLEAR on the remote to correct an entry.

3. Press MENU¥PROG to proceed.

ÒThe VCR will now receive all signals from the DSS receiver onÓÐ Ð message appears.

SETUP

Would you like to set up the VCR to control a DSS receiver?

1 Yes 2 No

DSS SETUP

On what ANTENNA channel does the VCR receive signals from the DSS receiver?

Press 02-69 or INPUT Press MENU to exit

Startup

Set Up a Digital Satellite Receiver (continued)

4. Press MENU¥PROG to proceed.

Digital satellite receiver turned on:

The receiver turned on and tuned to channel 200. Press 1 and proceed to CABLE BOX SETUP.

The VCR will now turn on and tune your receiver to the correct channel during timer recordings. Ð Ð Ð DSS will appear for channels 100 and over in the timer program menu.

Digital satellite receiver did not turn on:

If your receiver does not turn on, try repositioning the receiver and press 2 to try again.

Cancel digital satellite receiver setup:

Press 3 to cancel DSS SETUP. The VCR will not turn on or control the receiver.

Set Up a Cable Box

5. Set up the VCR to control a cable box:

Press 1 if you would like to set up the VCR to control a cable box.

Press 2 if you do not want to set up the VCR to control a cable box.

6. Cable box not used for all channels:

Press 2. Setup is not required. Skip to Set Time and Date.

Cable box used for all channels:

Press 1 to continue.

Press two numbers on the remote to enter the channel that your VCR receives signals from your cable box. Press 0 before a single-digit number. Valid numbers are 01 Ð 13.

If you connected your cable box to the VCR using the boxÕs AUDIO/VIDEO OUT jacks, press INPUT to select VIDEO1 or VIDEO2.

Press CLEAR on the remote to correct an entry.

7. Press MENU¥PROG to proceed.

The VCR will now receive all signals from the cable box on channel Ð Ð message appears.

8. Press MENU¥PROG to proceed.

9. Manually Controlled Cable Box:

You are finished with cable box setup. Repeatedly press MENU¥PROG to exit CABLE BOX SETUP. Proceed to Set the Time and Date.

Remote Controlled Cable Box:

Enter your cable box code from the chart on the next page and follow the onscreen directions. The VCR changes the cable box from channel 02 to channel 09 when you enter the correct code for your cable box.

If none of the codes work, try repositioning the cable box and entering the codes again. If the codes still do not work, this VCR cannot control your cable box during VCR plus+ or timer recordings. Press MENU¥PROG to exit the CABLE BOX SETUP. Proceed to Set the Time and Date.

DSS SETUP

The VCR will now receive all signals from the DSS receiver on ANTENNA channel 03 (or CABLE CHANNEL 03).

Press MENU to proceed

Did the DSS receiver turn on and tune to channel 200?

1 YES, setup complete 2 NO, try again 3 NO, cancel setup

SETUP

Would you like to set up the VCR to control a cable box?

1 Yes

CABLE BOX SETUP

Do you use your cable box to receive ALL channels?

1 Yes 2 No

CABLE BOX SETUP On what channel does the VCR receive signals from the cable box (usually 3, 4, or video)

CABLE BOX SETUP

The VCR will now receive all signals from the cable box on channel 03

CABLE BOX SETUP

Enter the code for your cable box from the list in your User's Manual.

CABLE BOX SETUP

Please turn on the cable box and tune it to channel 2.

CABLE BOX SETUP

Did the cable box tune to channel 9?

1 YES, setup is complete 2 NO, try again

Set Up a Digital Satellite Receiver and/or Cable Box (continued)

Compatible Cable Box Control

Setting Up the VCR

Brand of Cable-TV Box*

ABC Anvision Cablestar Eagle Eastern International General Instrument Hamlin Hitachi Jerrold Macom Magnavox NSC Oak Oak Sigma Panasonic Philips Pioneer Randtek RCA Regal Regency Samsung Scientific Atlanta Sylvania Teknika Texscan Tocom Unika Universal Viewstar Warner Amex Zenith

Code Number(s)

53,54 07, 08 07, 08

07,08

04, 05, 15, 23, 24, 25, 30, 36

12, 13, 34,48

37, 43

04, 05, 15, 23, 24, 25, 30, 36, 45, 46,47

37, 43

07, 08, 19, 26, 28, 29, 32, 33, 40, 41

01, 16, 38

03, 27, 39

07, 08, 19, 26, 28, 29, 32, 33, 40, 41

18, 20, 44

07, 08 00, 27 12, 13 02, 33

03, 22, 35

11 06

10, 11

17, 21,49, 50

31, 32, 41

51, 52

07, 08, 19, 26, 28, 29, 32, 33, 40, 41

14, 42

Use the CHANNELS Menu to Set Up a Digital Satellite Receiver or a Cable Box

If you ever want to set up the cable box or satellite receiver:

1. Press MENU¥PROG to display the VCR MAIN MENU on the TV screen.

2. Press 4 to display the CHANNELS menu.

3. Select Cable box or DSS Setup.

■ Press 5 to select Cable box Setup.

■ Press 6 to select DSS Setup.

4. Follow the directions on the screen as previously described.

VCR MAIN MENU 1 VCR Plus+ 2 Timer Recordings 3 Set Clock 4 Channels 5 Setup 6 Preferences 7 Language/Langue 8 Audio

0 Exit

CHANNELS

1 Auto Channel Search 2 Add/Remove Channels 3 Signal Type: CABLE 4 VCR Plus+ Channel List 5 Cable box Setup 6 DSS Setup

0 Exit

Startup

Set Up Clock and Auto Channel Search

Follow the steps on the screen to auto channel search and automatically set the clock*. If the SET TIME ZONE or SET DAYLIGHT SAVINGS screen appears, follow step 1 or 2 below. If the SETUP menu appears, skip to step 3.

1. If the SET TIME ZONE screen appears, select a time zone:

Press the number on the remote (1-6) corresponding to the ÒstandardÓ time zone you live in. If you do not know your time zone, press 7 and an automatic setting will be made.

If you select Automatic for your time zone, the VCR will set the clock using the first Coordinated Universal Time information it finds. If the time is not correct, select a time zone or set the clock manually. If the time is incorrect by a few minutes (more than one minute), the local station may not be transmitting the correct time.

SET TIME ZONE What is your time zone? 1 Eastern 2 Central 3 Mountain 4 Pacific 5 Alaska 6 Hawaii 7 Automatic Press MENU to continue

SET DAYLIGHT SAVINGS

Does your area observe Daylight Savings Time from April to October?

1 Yes, DST is observed 2 No 3 Automatic Press MENU to continue

2. If the SET DAYLIGHT SAVINGS screen appears:

Press 1 if your area observes daylight savings time from April to October or press 2 if your area does not observe daylight savings time. If you do not know, press 3.

The VCR will set the time according to the information received from the broadcast.

3. When the auto channel search SETUP screen appears:

Press 1 if you would like the VCR to search for and store all available channels. Press 2 if you wish to skip this step.

If you skip auto channel search during setup, the auto clock set feature will not be performed in this sequence.

4. Press MENU¥PROG on the remote if all antenna or cable connections are completed. Auto channel search will be performed followed by automatic clock set.

If The Auto Clock Set was unsuccessful message appears, you can press 1 to set the clock manually or try auto clock set again. The clock must be set before you can use the timer recording feature.

Try Auto Clock Set Again: If you think there is a local station (usually PBS) broadcasting the XDS* (Extended Data Services--time) information, make sure the Auto Clock Set feature is set to ON on the TIME menu (press 2 to exit SETUP, press MENU¥PROG to display the VCR MAIN MENU, press 3 to display the TIME menu, and press 2 to turn the Auto Clock Set feature ON). Tune the VCR to the channel you believe is broadcasting the information before turning off the VCR. If the time does not set within ten minutes, XDS information is not available. Set the time and date manually.

SETUP

Would you like the VCR to search for and store all available channels?

1 Search for channels 2 Skip this step

Make sure all antenna connections to the VCR are complete.

Press MENU when ready

SETUP

The VCR is now setting the clock. This may take several minutes.

Press MENU to cancel

Set Clock Manually: Follow the directions on the following page to manually set the clock.

* Signal not available in all areas.

Use SETUP Menu to Auto Clock Set

Setting Up the VCR

If the AUTO CLOCK SET was unsuccessful:

1. Press 1 to display the set time and date screen.

2. Enter the time and date with the number buttons on the remote.

Press 0 before single-digit numbers.

Example: press 0, then 5, then 0, then 7 for a time of 5:07. Press 1 for AM or 2 for PM.

Press CLEAR on the remote to change incorrect entries.

3. Press MENU¥PROG on the remote to remove the SET TIME AND DATE screen from the TV screen and start the clock.

The time will appear in the VCRÕs display panel and the time and date will appear on the TV screen when you press DISPLAY.

If you ever need to reset the clock:

1. Press MENU¥PROG on remote to display the VCR MAIN MENU on the

TV screen.

2. Press 3 to display the TIME menu.

3. Press 1 to display the set time and date screen.

If you set the clock manually, Auto Clock Set is switched to OFF.

SETUP The Auto Clock Set was unsuccessful. Would you like to set the time and date?

1 Set Time and Date 2 Skip this step

VCR MAIN MENU

1 VCR Plus+ 2 Timer Recordings 3 Time

TIME

1 Set Time and Date

SET TIME AND DATE

Time --:--

(hh:mm)

Date --/--/--

Press MENU to exit

Use SETUP Menu to Auto Channel Search

If you ever need to repeat Auto Channel Search because you change cable or antenna signals:

1. Press MENU¥PROG on remote to display the VCR MAIN MENU on the TV screen. If this menu does not appear:

■ Make sure TV is tuned to same channel as the CH3 CH4 switch on the back of

the VCR or the TVÕs video input (refer to TVÕs manual).

■ Press VCR1 (VCR2¥DVD), then press MENU¥PROG again.

■ If you use a basic hookup, check VCR indicator in display panel--it should

be on.

■ Check the connections.

2. Press 4 to display the CHANNELS menu.

3. Press 1 to begin Auto Channel Search.

The VCR automatically selects the Signal Type: Cable (cable-TV) or ANTENNA. If you need to change the setting manually, press 3.

Set Up VCR Plus+ Channels

The VCR must be set up with the VCR Plus+ channels before you can record using VCR Plus+. This can be done now or at a later time.

■ Press 1 if you would like to set up the VCR Plus+ channels now.

(Details are on page 38.)

■ Press 2 if you wish to skip this step.

VCR MAIN MENU 1 VCR Plus+ 2 Timer Recordings 3 Time 4 Channels 5 Setup 6 Preferences 7 Language/Langue 8 Audio

0 Exit

CHANNELS

1 Auto Channel Search 2 Add/Remove Channels 3 Signal Type: CABLE 4 VCR Plus+ Channel List 5 Cable box Setup 6 DSS Setup

0 Exit

SETUP

Would you like to set up the channel lists for the VCR Plus+ feature?

1 Set up VCR Plus+ 2 Skip this step

Startup

Program VCR for VCR1 or VCR2•DVD Button

You can program this VCR to respond to the VCR1 or VCR2¥DVD button on the remote. Details are on page 21.

■ Press 1 if you want your VCR to respond to the VCR1 button.

■ Press 2 if you want your VCR to respond to the VCR2¥DVD button on the

remote.

Remember you must press VCR1 or VCR2¥DVD on the remote Ñwhichever you selected in the menu Ñ before the remote will operate this VCR.

Setup is complete. Press MENU¥PROG to return to the VCR MAIN MENU.

Add or Remove Channels From the VCR’s Memory

You may want to add or remove channels if some of the channels are not active, have weak signals, or you do not want to watch them.

We recommend channels be placed in memory using the Auto Channel Search feature described earlier before adding or removing channels. Channels 2-13, L1, and L2 are preset at the factory.

SETUP

Using the buttons VCR1 and VCR2, your remote can control 2 VCRs. What do you want to call this VCR?

1 VCR1 2 VCR2

SETUP

The setup procedure

is successful. You

are now ready to

begin using your VCR.

Press MENU to continue

VCR MAIN MENU 1 VCR Plus+ 2 Timer Recordings 3 Time 4 Channels 5 Setup 6 Preferences 7 Language/Langue 8 Audio

0 Exit

1. Press MENU¥PROG on the remote to see the VCR MAIN MENU on the TV screen.

2. Press 4 to display the CHANNELS menu.

3. Press 2 to display the ADD/REMOVE CHANNELS menu.

4. Follow the directions on the screen.

5. Add or remove more channels by entering channel numbers or using CHAN up or down on the remote or CHANNEL up or down on the VCR.

Select a Language/Choisissez une Langue

You can select the language for the displays on the VCR.

1. Press MENU¥PROG on the remote to see the VCR MAIN MENU on the TV screen.

2. Press 7 to display the LANGUAGE menu.

3. Select English or French.

■ Press 1 to select English.

■ Press 2 to select Fran•ais (French).

CHANNELS

1 Auto Channel Search 2 Add/Remove Channels

ADD/REMOVE CHANNELS

CH 03

is presently ADDED

Press CLEAR to remove Press MENU to exit

VCR MAIN MENU 1 VCR Plus+ 2 Timer Recordings 3 Time 4 Channels 5 Setup 6 Preferences 7 Language/Langue 8 Audio

0 Exit

LANGUAGE

Select a language.

1 English

2 Fran•ais

Press MENU to continue

Use TV•VCR Button

Skip this step if you used one of the advanced hookups.

When using one of the basic hookups, the TV¥VCR button lets you switch between the picture coming from the VCR or the picture from the TV channel. This button lets you record a program on the VCR while watching another channel on the TV. (Details are on page 35.)

1. Make sure the VCR indicator appears in the display panel.

If it does not appear, press TV¥VCR.

2. Press CHANNEL up or down on the VCR or CHAN on VCRÕs remote to change channels on the VCR.

The channel number changes in the display panel.

3. Press TV¥VCR to see the TV channels.

The VCR indicator does not light in the display panel. Change channels using

the TVÕs remote.

4. Return the TV to the VCR viewing channel Ñ CH3 or CH4.

5. Press VCR1, then TV¥VCR to switch back to the picture from the VCR.

Setting Up the VCR

Set Auto TV/VCR Feature

If you used one of the basic hookups and did not connect the audio/video jacks of the VCR to the TV, leave the Auto TV/VCR feature set to ON.

If you have connected your VCR using the audio/video input of your TV, you can

prevent the VCR indicator from turning on automatically and interrupting the cable

or antenna signal to your TV.

1. Press MENU¥PROG on remote to see VCR MAIN MENU on the TV screen.

2. Press 6 to display the PREFERENCES menu.

3. Press 3 to select Auto TV/VCR: ON or OFF.

■ Select ON if you used one of the basic hookups and watch your VCR on channel

3 or 4 of your TV. The VCR will automatically switch the TV¥VCR setting to VCR every time the VCR is turned on, a tape with the safety tab removed is inserted, or you press PLAY.

■ Select OFF if you used one of the advanced hookups and watch your VCR on the

video input channel of your TV. The VCR indicator will not turn on

automatically and the signal from your antenna or cable to your TV will not be interrupted.

Pressing TV¥VCR on the remote will still turn the VCR indicator on or off and

switch the antenna signal.

VCR MAIN MENU 1 VCR Plus+ 2 Timer Recordings 3 Time 4 Channels 5 Setup 6 Preferences 7 Language/Langue 8 Audio

0 Exit

PREFERENCES 1 Remote Control: VCR1 2 Auto Play: ON 3 Auto TV/VCR: ON 4 Front Panel: AUTO 5 CA Marking: ON 6 CA Playback: AUTO 7 CA Display: BLUE 8 Set Auto Repeat

0 Exit

Using the Remote Control

MUTE

PREV CH

DISPLAY

INPUT

TV•VCR

CLEAR

SPEED

REW

PLAY FF

STOP

PAUSE

REC

PROG

•

SLOW

TRACKING

•

VCR•

1 4 7

2 5 8

PWR

VOL

EDIT

F.ADV

MOVE

Using the Remote Control

This section explains the buttons and features of the remote control, including the following:

■ Light and Component Buttons ■ Controlling the VCR

■ VCR Function Buttons ■ Controlling a Laserdisc Player or DVD Component

■ TV Function Buttons ■ Controlling a TV

■ Cable Box or Satellite ■ Controlling a Cable Box or a Satellite Receiver

Receiver Function Buttons

Light Button

Your back-lit remote has a light button ( ) that glows in the dark. Press this button to light the buttons on the remote. The remote buttons remain lit when they are pressed within a few seconds of each other. If a button is not pressed within approximately eight seconds, the light turns off to conserve battery power.

■ Controlling an Auxiliary Component

Component Buttons

Press one of the following buttons to set the remote to operate that component:

AUX (Auxiliary)

Can be programmed to control a compatible RCA audio or ProScan, RCA, or GE video component. (See page 24.)

SAT¥CABLE

Turns on a compatible RCA cable box or ProScan, RCA, or GE satellite receiver. (See page 23.)

Used with PWR button to turn on another brand of cable box or satellite receiver, other than ProScan, RCA, or GE, when the remote is programmed to control that cable box. (See page 23.)

Turns on a compatible ProScan, RCA, or GE TV and sets the remote to control the TV. Used with PWR button to turn on another brand of TV, other than ProScan, when the remote is programmed to control that TV. (See page 22.)

VCR1

Turns on a compatible ProScan, RCA, or GE VCR and sets the remote to control the VCR.

VCR2¥DVD

Turns on a compatible ProScan, RCA, or GE VCR and sets remote to control VCR when it has been setup. Used with PWR button to turn on compatible ProScan or RCA Laserdisc player.

Can also be programmed to control a compatible RCA DVD component. (See page 21.)

VCR Function Buttons

MOVE

Press VCR1 (VCR2¥DVD) to set remote to control the VCR to use the function buttons.

VCR Function Buttons

CHAN Up or Down

Selects next higher or lower channel in the VCRÕs channel memory.

CLEAR

Resets time counter to 0:00:00. Allows you to change entries when setting up the VCR,

setting the clock, or setting a VCR Plus+ or timer recording.

DISPLAY

Shows VCR operating displays on the TV screen. Displays the time counter.

EDIT

Signals two properly connected compatible VCRs to begin copying a tape. (See page 47.)

F.ADV (Frame Advance)

Lets you view one frame with each press of the button while the tape is paused.

FF (Fast Forward)

Fast forwards the tape when the VCR is stopped. Searches the picture in forward motion during playback.

INPUT

Turns the line input on or off.

L1 or L2 appears in VCRÕs display panel and VIDEO1 or

VIDEO2 appears on TV screen. Line input refers to the signal coming from the component

connected to the audio/video input jacks on the back (L1) or front (L2) of the VCR.

MENU¥PROG

Displays the VCR MAIN MENU on the TV screen. Removes a menu from the screen.

MOVE Arrow Buttons ( )

Allow you to move through the menus, enter data and change settings of selected features. (See page 10.)

Numbers (0 through 9)

Select a channel up to 99 by pressing two numbers. Select a cable channel over 99 by pressing and holding 1

until 1Ð Ð appears on the screen. Then press the other two numbers.

PLAY

Plays a tape.

PWR

Turns off VCR when remote is set to control the VCR. Press twice to turn off all compatible ProScan or RCA

components.

PREV CH (Previous Channel)

Switches between two channels. Select one channel and then use the number buttons to

select another. Press PREV CH to switch between the two channels.

REC

Starts VCR recording. Used for express recording (XPR). (See page 37.)

REW (Rewind)

Rewinds the tape when the VCR is stopped. Searches the picture in reverse motion during playback.

Accesses INDEX, GO-TO, and BLANK SEARCH displays on TV screen when VCR is stopped.

Press during playback to advance the tape 60 or 120 seconds.

SLOW Ð / +

Used for slow-motion playback.

SPEED (Tape Speed)

Selects a recording speed (SP, LP, or SLP).

STOP

Stops the normal functions such as record, playback, rewind, fast forward, and pause.

TRACKING Up and Down

Lets you manually reduce the streaks that may appear on the picture during play or pause.

Reduces picture ÒjitterÓ during stop-action playback.

TV¥VCR

Switches the picture signal so that it either comes from the VCR or the TV channel. (See page 17.)

PAUSE

Pauses action for viewing during playback. Pauses recording to prevent recording of unwanted scenes.

Using the Remote Control

MOVE

MUTE

PREV CH

DISPLAY

INPUT

TV•VCR

CLEAR

SPEED

REW

PLAY FF

STOP

PAUSE

REC

PROG

•

SLOW

TRACKING

•

VCR•DVD

1 4 7

2 5 8

PWR

VOL

EDIT

F.ADV

MOVE

TV Function Buttons

Press the TV button to set remote to control a compatible TV. Some buttons may not work with the TV.

CHAN Up or Down

Selects next higher or lower channel in the TVÕs channel memory when remote is set to control a TV.

CLEAR

Removes menus or status displays from the screen.

DISPLAY

Shows the status displays on the screen. Removes menus or displays from the screen.

MOVE Arrow Buttons ( )

Allow you to move through the menus, enter data, and change settings of selected features.

MUTE

Turns the TV sound on or off.

Numbers (0 through 9 )

Select a channel up to 99 by pressing two numbers.

Select a cable channel over 99 by pressing and holding 1 until 1Ð Ð appears on the screen. Then press the other two numbers.

PWR (Power)

Turns off a compatible TV when remote is set to control TV.

Used with TV button to turn on a compatible TV, other than ProScan, when the remote is programmed to control that TV. (See page 22.)

Press twice to turn off all compatible ProScan and RCA components.

PREV CH (Previous Channel)

Switches between two channels. Select one channel and then use

the number buttons to select another. Press PREV CH to switch between the two channels.

Used as an ENTER button on some TVs.

SLOW Ð / +

Used with the TVÕs menus to select and adjust features.

VOL Up and Down

Raises and lowers sound.

Cable Box and Satellite Receiver Function Buttons

REC

Used with some Digital Satellite Systems with the one touch record feature.

Press the SAT¥CABLE button to set remote to control a compatible cable box or satellite receiver. Some buttons may not work with every cable box. If you have a receiver, test the ÒTV Function ButtonsÓ to see which ones operate it.

CHAN Up or Down

Selects next higher or lower channel.

Numbers (0 through 9)

Select a channel using the number buttons.

PWR

Turns off a compatible cable box or satellite receiver.

Press twice to turn off all compatible ProScan or RCA components.

Controlling a VCR

Controlling the VCR

The VCRÕs remote controls two compatible ProScan, RCA, or GE VCRs with the VCR1 and VCR2¥DVD buttons. Most compatible VCRs automatically respond to VCR1 without being programmed. If you own two compatible VCRs, test them to see if VCR1 turns on both VCRs. If it does, then you may want to program this VCR to respond to the VCR2¥DVD button on the remote.

VCR MAIN MENU

1 VCR Plus+

Program the VCR for Remote Control

Set the Remote Control feature of the VCR to the VCR1 or VCR2 position. The remote then controls the VCR with either the VCR1 or VCR2¥DVD button Ñ whichever position you select in the menu.

1. Press MENU¥PROG to display the VCR MAIN MENU.

2. Press 6 to display PREFERENCES.

3. Press 1 to activate the Remote Control feature.

4. Press VCR1 or VCR2¥DVD to change the setting and program this VCR to respond to the VCR1 or VCR2¥DVD button Ñ whichever you select.

Important Reminder: Remember you must press VCR1 or VCR2•DVD on the remote — whichever you selected in the menu — before the remote will operate this VCR.

2 Timer Recordings 3 Time 4 Channels 5 Setup 6 Preferences

PREFERENCES 1 Remote Control: VCR1 2 Auto Play: ON 3 Auto TV/VCR: ON 4 Front Panel: AUTO 5 CA Marking: ON 6 CA Playback: AUTO 7 CA Display: BLUE 8 Set Auto Repeat

0 Exit

PREFERENCES 1 Remote Control: VCR2 2 Auto Play: ON 3 Auto TV/VCR: ON 4 Front Panel: AUTO 5 CA Marking: ON 6 CA Playback: AUTO 7 CA Display: BLUE 8 Set Auto Repeat

0 Exit

Controlling a Laserdisc Player or DVD Component

The VCR2¥DVD button on the VCRÔs remote will also control the primary functions of a ProScan or RCA Laserdisc player without being programmed. It can also be programmed to control an ProScan, RCA or GE DVD component using the code below. If you ever need to reprogram the remote to operate a ProScan, RCA or GE VCR or a ProScan or RCA Laserdisc Player, use the code below.

Program the Remote Control

1. Turn on the component.

2. Point the VCR remote at the component

3. Hold the VCR2¥DVD button and press three number buttons to enter the code for the component.

4. Release the buttons.

5. Press PWR. If the component turns off, setup is complete.

Operate the Component

After you have set up your remote to control your component, test the remote buttons to see which ones operate it.

1. Point the remote at the component and press VCR2¥DVD.

2. If the component does not turn on in step 1, press VCR2¥DVD and then PWR.

3. Test the remote buttons to see which ones operate the component.

ProScan, RCA or GE Codes

VCR Laserdisc Player DVD

037 037 078

Using the Remote Control

Controlling a TV

The VCRÔs remote is preprogrammed to control the basic functions of a compatible ProScan, RCA, or GE TV. The remote can also be set up to control other manufacturerÔs brands. To program the remote, use the remote buttons that correspond to your brand.

Program the Remote for a TV

1. Turn on the TV.

2. Point the VCR remote at the TV.

3. Hold the TV button and press three number buttons for your brand. If the TV changes channels when the CHAN up or down button is pressed, setup is complete.

4. Release the buttons.

5. Repeat steps 2 Ð 4 with three other buttons if the first ones do not work.

TV Codes

Brand* Code

A-Mark . . . . . . . . . . . . . . . . . . . . . . . .102

Admiral . . . . . . . . . . . . . . . . . . . .005,114

Amtron . . . . . . . . . . . . . . . . . . . . . . .064

Akai . . . . . . . . . . . . . . . . . . . . . . .002,103

Anam . . . . . . . . . . . . . . . . . . . . . .104,105

Anam National . . . . . . . . . . . . .038,106

AOC . . . . . . . . . . . .011,019,027,088,107

Bell&Howell . . . . . . . . . . . . . . . . . . .005

Candle . . . . . . . . . . . . . . . . .011,027,033

Citizen . . . . . . . . . . . . . .011,027,033,064

Colortyme . . . . . . . . . . . . . .011,027,084

Concerto . . . . . . . . . . . . . . . . . . .011,027

Contec/Cony . . . .036,037,040,042,064

Craig . . . . . . . . . . . . . . . . . . . . . . . . . .064

Curtis Mathes . . . .000,011,015,027,037

CXC . . . . . . . . . . . . . . . . . . . . . . . . . .064

Daewoo . . . . . . . . .011,019,027,012,116

Daytron . . . . . . . . . . . . . . . . . . . .011,027

Dimensia . . . . . . . . . . . . . . . . . . . . . .000

Electrohome . . . . .006,011,014,027,038,

. . . . . . . . . . . . . . . . . . . . . . . . . . .061,068

Emerson . . . . .011,026,027,028,029,030,

. . . . . .031,032,037,042,053,064,065,067,

. . . . . . . . . .075,076,078,079,094,095,096

Envision . . . . . . . . . . . . . . . . . . .011,027

Fisher . . . . . . . . . . . . . . .017,021,039,041

Funai . . . . . . . . . . . . . . . . . . . . . . . . .064

Brand* Code

GE . . . . . . . . . .000,008,009,011,012,027,

. . . . . . . . . . . . . . . . .038,068,086,089,091

Goldstar . . . . . . . .003,004,006,011,019,

. . . . . . . . . . . . . . . . . . . . . . . .027,037,050

Hallmark . . . . . . . . . . . . . . . . . . .011,027

Hitachi . . . . . .009,011,027,036,037,040,

. . . . . . . . . .047,048,063,080,094,097,098

Infinity . . . . . . . . . . . . . . . . . . . . . . . .013

JBL . . . . . . . . . . . . . . . . . . . . . . . . . . .013

Jensen . . . . . . . . . . . . . . . . . . . . .011,027

JVC . .012,024,036,037,040,048,051,074

Kawasho . . . . . . . . . . . . . . .002,011,027

Kenwood . . . . . . . . . . .006,011,014,027

Kloss Novabeam . . . . . . . . . . . .035,043

KTV . . . . . . . . . . . . . . . . . . . . . . . . . .078

Loewe . . . . . . . . . . . . . . . . . . . . . . . . .013

Luxman . . . . . . . . . . . . . . . . . . . .011,027

LXI . . . . . . . . . .000,013,018,021,023,054

Magnavox . . .006,007,010,011,013,016,

. . . . . .027,033,035,043,049,066,087,089

Marantz . . . . . . . . . . . . .011,013,027,069

Memorex . . . . . . . . . . . . . . . . . . . . . .005

MGA . . . . . . . . . . .006,011,014,019,022,

. . . . . . . . . . . . . . . . .027,041,056,061,068

Mitsubishi . . . . . . .006,011,014,019,022,

. . . . . . . . . . . . .027,041,055,056,061,068

Brand* Code

MTC . . . . . . . . . . . . . . . . . . .011,019,027

Multivision . . . . . . . . . . . . . . . . . . . .081

NAD . . . . . . . . . . . . . . . . . . . . . .018,023

NEC . . . . . . . . .011,014,019,027,038,084

Panasonic . . . . . . . .012,013,038,086,111

Penney . . . . . .000,008,011,019,027,040,

. . . . . . . . . . . . . . . . . . . .068,077,086,088

Philco . . . .006,007,010,011,013016,019,

. . . . . .027,033,035,037,038,043,087,089

Philips . . .002,006,007,010,011,013,016,

. . . . . . . . . .033,035,037,038,043,066,073

Pioneer . . . . . .011,027,045,062,093,113

Portland . . . . . . . . . . . .011,019,027,037

ProScan . . . . . . . . . . . . . . . . . . . . . . .000

Proton . . . . . . . . . . . . . .011,027,037,072

Quasar . . . . . . . . . . . . . . . . .012,038,092

Radio Shack . . . . .000,021,025,036,037,

. . . . . . . . . . . . . . . . . . . . . . . .059,064,078

RCA . . . . . . . .000,006,011,019,027,034,

. . . . . . . . . .038,044,046,088,100,101,109

Realistic . . . . . . . . . . . . . . . . . . . . . . .021

Sampo . . . . . . . . . . . . . . . . . . . . .011,027

Samsung . . . . . . . .006,011,014,015,019

. . . . . . . . . . . . . . . . .027,036,037,077,110

Sanyo . . . . . . . .017,021,039,056,057,058

Scott . . . . . . . . . . . . . . . . . . .028,037,064

Sears . . . .000,006,011,014,017,018,021,

. . .023,027,039,040,041,051,071,083,095

Brand* Code

Sharp . . . . . . . . . . .011,020,025,027,037

. . . . . . . . . . . . . . . . .052,053,059,060,108

Signature . . . . . . . . . . . . . . . . . . .005,094

Sony . . . . . . . . . . . . . . . . . . . . . . . . . .002

Soundesign . . . . . . . . . . . . .011,027,033

Sylvania . . . . .006,007,010,011,013,016,

. . . . . .027,033,035,043,049,066,087,089

Symphonic . . . . . . . . . . . . .064,076,115

Tatung . . . . . . . . . . . . . . . . . . . . . . . .038

Technics . . . . . . . . . . . . . . . . . . . . . . .012

Techwood . . . . . . . . . . . . . . . . . .011,027

Teknika . . . . . . . . .011,019,027,033,036

. . . . . . . . . . . . . . . . . . . . . . .,037,040,066

Telecaption . . . . . . . . . . . . . . . . . . . .090

TMK . . . . . . . . . . . . . . . . . . . . . .011,027

Toshiba . . . . . . . . .018,021,023,040,071,

. . . . . . . . . . . . . . . . . . . . . . . .077,085,090

Universal . . . . . . . . . . . . . . . . . .008,009

Victor . . . . . . . . . . . . . . . . . . . . . . . . .051

Vidtech . . . . . . . . . . . . . . . . . . . .019,027

Wards . . . . . . . . . . .000,005,006,007,008

. . . . . .009,010,011,013,019,025,027,028,

. . . . . . . . . .035,043,059,066,076,082,089

Yamaha . . . . . . . . . . . . .006,014,019,027

Zenith . . . . . . . . . . . . . . . . . .001,099,114

*The remote may not be able to control every model TV of the brands listed.

Operate the TV

After you have set up your remote to control your TV, test the TV buttons to see which ones operate your TV.

1. Point the remote at the TV and press TV.

2. If the TV does not turn on in step 1, press TV and then PWR.

3. Use the ÒTV Function ButtonsÓ as described on page 20.

Helpful Hint: Notice the difference between the TV and VCR on-screen displays. This is one way to tell if the remote is set to control the VCR

Controlling a Cable Box or a Satellite Receiver

The SAT¥CABLE button on the VCRÕs remote is preprogrammed to control either a compatible RCA cable box or a ProScan, RCA, or GE satellite receiver. If your cable box or satellite receiver is another manufacturerÕs brand and has its own remote, you will probably be able to program the VCRÕs remote to control your cable box. To program the VCRÕs remote, enter the code that corresponds to your brand.

Program the Remote for a Cable Box

1. Turn on the cable box.

2. Point the VCR remote at the cable box.

3. Hold the SAT¥CABLE button and press three number buttons to enter the code for your brand.

4. Release the buttons.

5. Press PWR on the remote. If the cable box turns off, setup is complete.

6. Repeat steps 2 Ð 5 with a different code if the first one does not work.

Cable Box Codes

Brand* Code

ABC . . . . . . . . . . . . .022,046,053,054

Anvision . . . . . . . . . . . . . . . .007,008

Cablestar . . . . . . . . . . . . . . . .007,008

Diamond . . . . . . . . . . . . . . . . . . . .056

Eagle . . . . . . . . . . . . . . . . . . . .007,008

Eastern Int. . . . . . . . . . . . . . . . . . .002

General Instuments . . . . . . . . . . .046

GI 400 . . . . . . . .004,005,015,023,024,

. . . . . . . . . . . . . . . . . . . . .025,030,036

Hamlin . . . . . . .003,012,013,034,048

Hitachi . . . . . . . . . . . . . .037,043,046

Jerrold . . . . . . .004,005,015,023,024,

. . .025,030,036, 045,046,047,062,065

Macom . . . . . . . . . . . . . . . . . .037,043

Brand* Code

Magnavox . . . .007,008,019,021,026,

. . . . . . . . . . .028,029,032,033,040,041

NSC . . . . . . . . . . . . . . . . . . . . . . . .009

Oak . . . . . . . . . . . . . . . . .001,016,038

Oak Sigma . . . . . . . . . . . . . . . . . .016

Panasonic . . . . . . . . .003,027,039,061

Philips . . . .007,008,019,021,026,028,

. . . . . . . . . . . . . .029,032,033,040,041

Pioneer . . . . . . . . . . . . . .018,020,044

RCA . . . . . . . . . . . . . . . . . . . .000,027

Randtek . . . . . . . . . . . . . . . . .007,008

Regal . . . . . . . . . . . . . . . .003,012,013

Regency . . . . . . . . . . . . . . . . .002,033

Samsung . . . . . . . . . . . . . . . . . . . .044

Sci. Atlanta . . . .003,022,035,063,064

Brand* Code

Signature . . . . . . . . . . . . . . . . . . .046

Sprucer . . . . . . . . . . . . . . . . . . . . .027

Starcom . . . . . . . . . . . . . . . . . . . . .046

Stargate 2000 . . . . . . . . . . . . . . . .058

Sylvania . . . . . . . . . . . . . . . . .011,059

Teknika . . . . . . . . . . . . . . . . . . . . .006

Texscan . . . . . . . . . . . . . .010,011,059

Tocom . . . . . . . .017,021,049,050,055

Unika . . . . . . . . . . . . . . . .031,032,041

Universal . . . . . . . . . . . .051,052,060

Viewstar . . .007,008,019,021,026,028

. . . . . . . . . . . . . .029,032,033,040,041

Warner Amex . . . . . . . . . . . . . . .044

Zenith . . . . . . . . . . . .014,042,057,061

Satellite Receiver Codes

Brand* Code

Chaparral . . . . . . . . . . . . . . .080,081

Cheyenne . . . . . . . . . . . . . . . . . .081

Drake . . . . . . . . . . . . . . . . . . .082,083

GE . . . . . . . . . . . . . . . . . . . . . . . . . .000

General Instruments . . .092,093,094

*The remote may not be able to control every cable box or satellite receiver of the brands listed.

Brand* Code

Realistic . . . . . . . . . . . . . . . . . . . . .084

RCA. . . . . . . . . . . . . . . . . . . . . . . . 000

Sierra I,0II,0III . . . . . . . . . . . . . . .081

STS1 . . . . . . . . . . . . . . . . . . . . . . . .085

STS2 . . . . . . . . . . . . . . . . . . . . . . . .086

ProScan . . . . . . . . . . . . . . . . . . . . .000

Brand* . . . . . . . . . . . . . . . . . . . .Code

STS3 . . . . . . . . . . . . . . . . . . . . . . . .087

STS4 . . . . . . . . . . . . . . . . . . . . . . . .088

Toshiba .. . . . . . . . . . . . . . . . . . . .089

Uniden . . . . . . . . . . . . . . . . . . . . .090

Video Cipher II. . . . . . . . . . . . . . .091

Operate the Cable Box or Satellite Receiver

After you have setup your remote (if required) to control your cable box, test the buttons to see which ones operate your cable box or satellite receiver.

1. Point the remote at the cable box or satellite receiver and press SAT¥CABLE.

2. If the cable box does not turn on in step 1, press SAT¥CABLE and then PWR.

3. Use the ÒCable Box or Receiver Function ButtonsÓ for the cable box and test the ÒTV Function ButtonsÓ to see which ones operate the satellite receiver. (See page 20.)

Using the Remote Control

Controlling an Auxiliary Component

The remote that came packed with your VCR is also capable of controlling one compatible RCA audio component (such as an AM/FM radio, CD player, tape player, phonograph); ProScan, RCA or GE digital satellite receiver; or RCA DVD component. The remote must be programmed for the specific component it is to control. To program the remote, use the code that corresponds to your component.

Program the Remote for an Auxiliary Component

1. Turn on the component.

2. Point the VCR remote at the component.

3. Hold the AUX button and press three number buttons to enter the code for your component.

4. Release the buttons.

5. Press PWR on the remote. If the component turns off, setup is complete.

Type of Auxiliary Equipment and Code

AM/FM AUX Phono Tape1 CD Receiver Tape2 DVD

003 004 005 006 007 008 009 010

*The remote may not be able to control every ProScan, RCA, or GE model of

auxiliary equipment listed.

Cassette Satellite Cassette

Operate the Auxiliary Component

After you have setup your remote to control your component, test the buttons to see which ones operate the component.

1. Point the remote at the component and press AUX.

2. If the component does not turn on in step 1, press AUX and then PWR.

3. Test the buttons on the remote to see which ones operate your component.

Playing a Tape

OWEREJECTTV¥VCR

LAY

Playing a Tape

This section introduces you to the basic operation of your VCR and discusses the following playback features:

■ Auto Play ■ Manual Tracking ■ Tape Playback

■ Pause for Stop Action ■ DISPLAY Button ■ Pro-Tect Plus

■ Slow Motion ■ Program Information ■ Index Search

■ Picture Search ■ Time Counter ■ Go-To Search

■ Frame Advance ■ Auto Repeat ■ Blank Search

■ Automatic Tracking

To Play a Tape

Locking

Safety

1. Turn on the TV and tune it to channel 3, 4, or TVÕs video input to see the picture from the VCR.

2. Insert a tape in the VCR.

VCR automatically turns on. The cassette-in indicator lights, and

the VCR indicator lights if the Auto TV/VCR feature is set to ON. The

tape automatically begins playback if the safety tab on the cassette has been removed and the Auto Play feature is turned on.

3. Press PLAY, if necessary. PLAY appears in the VCRÕs display panel.

4. Press TRACKING up or down to remove any streaks from the picture, if necessary. (Details are on page 27.)

5. Press STOP.

6. Press REW on the remote or turn the SHUTTLE DIAL toward REW on the VCR.

The VCR will automatically rewind the tape if it reaches the end of the tape during playback. While rewinding, you can press PWR and the VCR will turn off after rewinding.

7. Press EJECT on the VCR to eject the tape once it is completely rewound.

Playing a Tape

OWEREJECTTV¥VCR

LAY

STOP

PAUSERECORD

VIDEO INMONO L¥AUDIO IN¥

INPUTPROG. EXPMENU CLEAR

CHANNEL

DISPLAY

TRACKING

Using the Playback Features

Auto Play Feature

This feature lets you tell the VCR whether you want it to automatically start playing a tape that is inserted with the safety tab removed.

1. Press MENU¥PROG on the remote to see the VCR MAIN MENU.

2. Press 6 to display the PREFERENCES menu.

3. Press 2 to select Auto Play: ON or OFF.

■■

Select ON to have a tape with the safety tab removed play automatically.

■ Select OFF if you do not want the tape with its safety tab

removed to start playing automatically.

Pause for Stop Action

This feature stops the tape in action and enables you to examine the details of the scene. Stop action works best with tapes recorded in the SP and SLP speeds.

1. Press PAUSE during playback to stop the action.

STILL appears in the VCRÕs display panel.

2. Press TRACKING up or down to reduce any jittering of the picture.

VCR MAIN MENU 1 VCR Plus+ 2 Timer Recordings 3 Time 4 Channels 5 Setup 6 Preferences 7 Language/Langue 8 Audio

0 Exit

PREFERENCES 1 Remote Control: VCR1 2 Auto Play: ON 3 Auto TV/VCR: ON 4 Front Panel: AUTO 5 CA Marking: ON 6 CA Playback: AUTO 7 CA Display: BLUE 8 Set Auto Repeat

0 Exit

3. Press PAUSE or PLAY to return to playback.

The VCR will automatically switch from stop-action playback to stop after a few minutes.

Slow Motion

You can view the picture in slow motion during play or play pause. SLOW Ð and + on the remote and the SHUTTLE DIAL on the VCR allow you to change the speed. Sound is turned off during slow-motion playback. Slow motion works best in the SP or SLP speed.

1. During playback, press SLOW + or Ð to start slowÐmotion playback or press PAUSE and turn the SHUTTLE DIAL on the VCR in either direction.

SLOW+ or SLOW- will appear in the VCRÕs display panel.

2. Press SLOW + to increase the speed or SLOW Ð to decrease the speed.

3. Use TRACKING up or down to remove any streaks from the picture.

4. Press PLAY to return to playback.

Release the SHUTTLE DIAL on the VCR to return to the pause mode.

Shuttle Dial

PLAY

PAUS E

The VCR will automatically switch from slow-motion playback to stop after a few minutes.

Picture Search

You can search a picture during playback by fast forwarding or rewinding the tape. Sound is turned off during picture search. The picture is best for tapes recorded in the SP or SLP speed.

Fast Forward Search

1. Press FF on the remote or turn the SHUTTLE DIAL clockwise toward FWD on the VCR to search forward at a faster-than-normal speed.

SRCH+ appears in the VCRÕs display panel.

2. To return to playback, press FF on the remote, PLAY, or turn the SHUTTLE DIAL again.

Rewind Search

1. Press REW on the remote or turn the SHUTTLE DIAL counterclockwise toward REW on the VCR to search in reverse at a faster-than-normal speed.

SRCH- appears in the VCRÕs display panel.

2. To return to playback, press REW on the remote, PLAY, or turn the shuttle dial again.

Using the Playback Features

Frame Advance

Frame advance lets you view one stop-action frame after another. Frame advance works best for tapes recorded in the SP or SLP speed.

1. Press PAUSE to stop the action. STILL appears in the VCRÕs display

panel.

2. Press F.ADV each time you want to view a frame of the scene.

3. Press PAUSE or PLAY to resume normal playback.

Automatic Tracking

The VCR has automatic tracking which adjusts the picture when playing back a tape recorded on another VCR. Automatic tracking is turned on whenever a tape is inserted or the VCRÕs power is turned on.

Manual Tracking

Occasionally, you may need to manually adjust tracking on a tape recorded on a different VCR or camcorder. The TRACKING buttons on the remote or VCR are used when playing a tape. They have no effect during recording.

■ When streaks or snow appear, press TRACKING up or down for the

best possible picture.

■ Press TRACKING up or down during stop-action pause to reduce

picture ÒjitterÓ.

■ To turn automatic tracking back on, press both TRACKING buttons on

the VCR at the same time or eject and re-insert the cassette.

Playing a Tape

DISPLAY Button

1. Press DISPLAY to display the status of the VCR, channel number, station ID (if available), time counter, title of program (if available) date, time, and tape speed on the TV screen. The time will appear in the display panel.

The time and date must be set before they are displayed. If you do not press DISPLAY again, these displays will time out.

2. Press DISPLAY again to display information about the program that is playing (if available).

If program information is not available, Title Unavailable will appear.

3. Press DISPLAY again to have only the time counter remain on the TV screen. The time counter will appear instead of the time in the VCRÕs display panel.

4. Press DISPLAY again to remove the time counter from the TV screen. The time counter will remain in the VCRÕs display panel and no status displays will appear on the TV screen.

This is convenient for editing tapes.

5. Press DISPLAY again to return to clear the status displays. No displays will appear on the screen. The clock will appear in the display panel.

Turning off the VCR automatically resets the displays.

STOP CH 05 0:30:00

Title: Joan’s Hour 11/18/96Mon01:30AM SLP

WABC

Status Displays Will Time Out

Press DISPLAY

Press

DISPLAY

Again

(Clock Appears in VCRÕs

Display Panel)

Press DISPLAY Button

Press

DISPLAY

Again

Press

DISPLAY

Again

Joan's Hour

Time Remaining 00:15

(Time Counter Appears

in VCRÕs Display Panel)

Press DISPLAY Again

No Displays Will Appear

(Time Counter Appears

in VCRÕs Display Panel)

PROGRAM DETAILS

Start 11:00 PM

Length 01:00

Rating PG

Press DISPLAY Again

0:30:00

Time Counter Only Will Not Time Out

Program Information

Some stations broadcast program information along with the program. When this information is available, it will be displayed automatically when you press the DISPLAY button.

1. Press DISPLAY to display the status displays on the TV screen.

The title of the program and station ID will appear if they are available.

If program information is not available, ÒTitle UnavailableÓ will appear.

2. Press DISPLAY again to display information about the program (start time, length, time remaining and rating) on the screen.

This display will time out automatically if no button is pressed, or press DISPLAY three times to remove the PROGRAM DETAILS screen from the TV. The clock will appear in the VCRÕs display panel.

STOP CH 05 0:30:00

WABC

Title: Joan’s Hour 11/18/96Mon01:30AM SLP

PROGRAM DETAILS

Joan's Hour

Start 11:00 PM

Length 01:00

Time Remaining 00:15

Rating PG

Time Counter

Using the Playback Features

The time counter shows the actual time it takes to record a program or play back a segment of a prerecorded tape. It helps locate the beginning or end of programs you taped. The time counter resets to 0:00:00 whenever the tape is ejected from the VCR.

For example, if a 30-minute program was recorded at the beginning of the tape, you would:

1. Insert the prerecorded tape. Press STOP. Make sure the tape is rewound.

2. Press DISPLAY three times to display only the time counter on the TV screen.

3. Press CLEAR to reset the time counter to 0:00:00.

4. Press FF on remote or turn the SHUTTLE DIAL on the VCR clockwise to fast forward the tape until the time counter reads 0:30:00. Press STOP.

This is the approximate end of the program and you can begin recording at this spot.

5. Press DISPLAY twice to remove the time counter from the screen and return to the normal displays.

0:30:00

Hours

Minutes

Seconds

Auto Repeat Feature

The VCR will automatically repeat a segment of tape.

1. Locate the beginning of the segment you want the VCR to repeat, and press STOP.

2. Press DISPLAY to display the time counter, and press CLEAR to reset it to 0:00:00.

3. Press MENU¥PROG on the remote to see the VCR MAIN MENU on the TV screen.

4. Press 6 to display the PREFERENCES menu.

5. Press 8 to display the AUTO REPEAT menu.

6. Use the number buttons to enter the length of time of the segment you want the VCR to repeat, in hours and minutes.

7. Press MENU¥PROG to remove the menu from the screen.

The VCR will play the tape until the specified counter reading is reached, rewind the tape and replay the segment over and over.

8. To stop auto repeat, display the AUTO REPEAT menu and press CLEAR. The tape will continue to play but without repeating.

Ejecting the tape will also cancel auto repeat.

VCR MAIN MENU 1 VCR Plus+ 2 Timer Recordings 3 Time 4 Channels 5 Setup 6 Preferences 7 Language/Langue 8 Audio

0 Exit

PREFERENCES 1 Remote Control: VCR1 2 Auto Play: ON 3 Auto TV/VCR: ON 4 Front Panel: AUTO 5 CA Marking: ON 6 CA Playback: AUTO 7 CA Display: BLUE 8 Set Auto Repeat

0 Exit

AUTO REPEAT

Set the length of time you want the tape to play in a repeating loop

Loop from 0:00 to -:--

Press MENU to exit

(h:mm)

Playing a Tape

Tape Playback: HI-FI/LINEAR/MIX Feature

The VCR records the same audio on both the Hi-Fi and linear tracks on the tape. The Hi-Fi sound is recorded on separate left and right stereo channels. Monaural sound is recorded on the linear track.

To enjoy Hi-Fi sound, you must connect your VCR to a stereo television or amplifier/receiver using the audio/video jacks. The Tape Playback: HIFI/LINEAR/MIX feature lets you select which audio you play back.

To Select Playback Sound

1. Press MENU¥PROG to see the VCR MAIN MENU on the TV screen.

2. Press 8 to see the AUDIO menu on the TV screen.

VCR MAIN MENU 1 VCR Plus+ 2 Timer Recordings 3 Time 4 Channels 5 Setup 6 Preferences 7 Language/Langue 8 Audio

0 Exit

3. Press 2 to switch between HI-FI, LINEAR, or MIX sound.

■ Select HI-FI to play back sound recorded on the Hi-Fi track and for

normal use.

The HIFI indicator is lit in the VCRÕs display panel during Hi-Fi playback.

■ Select LINEAR to play back the sound recorded on the linear monaural track,

such as a second audio program (SAP).

■ Select MIX to play back the sound recorded on both the linear track and the

Hi-Fi track, sound-on-sound.

Pro-Tect Plus™ Locking Feature

To protect your timer recordings from any unwanted changes, lock the VCR. When locked, the buttons on the VCR and remote will not operate the VCR. Just follow the directions below.

To Lock the VCR

1. Set up your VCR for a timer recording.

2. Insert a cassette with safety tab intact.

3. Place VCR in stop mode.

AUDIO

1 Reception: STEREO 2 Tape Playback: HI-FI

0 Exit

4. Press and hold PWR on the remote for at least six seconds until LOCK appears

in the VCR's display panel.

To Unlock the VCR

Press and hold VCR1 (VCR2¥DVD) on the remote until HELLO appears in the

VCRÕs display panel to unlock the controls.

Index Search

The VCR has a ÒVHS Index Search SystemÓ that automatically records an index mark on the tape every time you start a new recording. During playback you can locate the program you want to play by the number of index marks.

The VCR will automatically locate the index number you select. The VCR will search forward or reverse from the location you are on the tape.

1. Insert the prerecorded tape and press STOP.

2. Press SEARCH on the remote to display the INDEX SEARCH menu on the TV screen.

3. Press two number buttons to enter the number of index marks you want the VCR to search.

Press CLEAR to correct an entry.

4. Press FF on remote or turn the SHUTTLE DIAL clockwise toward FWD on the VCR to search forward.

Press REW on remote or turn the SHUTTLE DIAL counterclockwise toward REW on the VCR to search in reverse.

5. Press STOP to stop index searching.

Some index marks may be missed by the VCR.

■ A mark too close to your location on the tape.

■ The mark at the beginning of a recorded segment of five minutes or less.

■ The first index mark on the tape when you start at the beginning of the

tape.

Using the Playback Features

INDEX SEARCH

Enter Index Number

Press FWD or REW Press SEARCH to exit

0:30:00

Go-To Search

The go-to search feature allows you to locate a counter reading on the tape.

1. Insert the prerecorded tape and press STOP.

2. Press SEARCH on the remote twice to display the GO-TO SEARCH menu on the TV screen.

3. Press number buttons to enter the hour(s) and minute(s) of the time counter reading you want the VCR to search.

Press CLEAR to correct an entry.

4. Press FF on remote or turn the SHUTTLE DIAL clockwise toward FWD on the VCR to search forward.

Press REW on remote or turn the SHUTTLE DIAL counterclockwise toward REW on the VCR to search in reverse.

The time counter is displayed in the upper right corner of the TV screen during search, and the tape will play when the time counter reaches the requested number.

5. Press STOP to stop go-to searching.

GO-TO SEARCH

Current tape counter is

2:17:25

Press REW or FF to go to

0:00:00

Press SEARCH to exit

Playing a Tape

Blank Search

The VCR searches forward for blank portions of the tape that are more than six seconds in length.

1. Insert the tape and press STOP.

2. Press SEARCH on the remote three times to display the BLANK SEARCH menu on the TV screen.

3. Press FF or turn the SHUTTLE DIAL clockwise toward FWD to start the VCR searching for six seconds of blank tape.

A message appears on the TV screen if a blank area is not found.

4. Press STOP to stop blank searching.

BLANK SEARCH

Press FF to begin Searching for blank section of tape.

Press SEARCH to exit

Playback and Recording Feature

COMMERCIALAADVANCE™ Feature

COMMERCIALAADVANCEª is a patented technology that detects and marks

most commercials on your tape for any recording that is more than 15 minutes long. During playback, the VCR automatically skips the detected commercial segments or you can choose to manually skip them. This feature reduces three minutes of commercials into approximately 8-12 seconds of fast forwarding in the SLP speed. You can select a background of blue or see the video as the commercials are skipped.

After recording, the VCR rewinds the tape to the beginning of the recording and determines where the commercials are located. It then marks the beginning and end of the detected commercial segments and returns the tape to the end of the recording. It does not erase the commercials from the tape.

Because television signals do not indicate where commercials are located, this feature finds and marks them through a set of formulas based on how television is broadcast today. Since television stations broadcast differently and insert their own commercials, you may experience some variations in this featureÕs effectiveness. Station promotions, identifications, and announcements are not considered commercials Ñ but might be skipped.

COMMERICALAADVANCE™ Marking

1. Press MENU¥PROG, to display the VCR MAIN MENU.

2. Press 6 to display the PREFERENCES menu.

3. Make sure CA MARKING is set to ON. If not press, 5. The VCR will mark most commercials for the following types of recording.

VCR Plus+, Timer, or Express Recording: The VCR will automatically

mark the commercials after the power is turned off.

Manual Recording: When you press STOP to stop recording, the VCR will ask you if you want to mark the commercials. Just follow the on-screen display.

MARK and COMM alternate in the display panel while the VCR is marking commercials.

To Stop COMMERCIALAADVANCE™ Marking

Press STOP to cancel commercial marking.

To Turn Off Marking

For special VCR use (such as editing or copying) or if you decide not to use this

feature, turn COMMERCIALAADVANCEª marking (CA Marking) off.

1. Press MENU¥PROG, to display the VCR MAIN MENU.

2. Press 6 to display the PREFERENCES menu.

3. Press 5 to select CA Marking: OFF.

The VCR will not mark the commercials.

VCR MAIN MENU 1 VCR Plus+ 2 Timer Recordings 3 Time 4 Channels 5 Setup 6 Preferences

PREFERENCES 1 Remote Control: VCR1 2 Auto Play: ON 3 Auto TV/VCR: ON 4 Front Panel: AUTO 5 CA Marking: ON

The VCR is waiting to mark commercials in the program you recorded.

1 Mark them now 2 Mark them later 3 Don't mark commercials

The VCR will begin marking in 30 seconds...

Marking Commercials... Press STOP to cancel

PREFERENCES 1 Remote Control: VCR1 2 Auto Play: ON 3 Auto TV/VCR: ON 4 Front Panel: AUTO 5 CA Marking: ON 6 CA Playback: AUTO 7 CA Display: BLUE 8 Set Auto Repeat

0 Exit

COMMERCIALAADVANCEª is a trademark of Arthur D. Little Enterprises, Inc. A Jerry Iggulden invention licensed by Arthur D. Little Enterprises, Inc.

Commercial Advance Feature

To Select a Background for Playback

1. Press MENU¥PROG to display the VCR MAIN MENU.

2. Press 6 to display the PREFERENCES menu.

3. Press 7 to select CA Display: BLUE or VIDEO.

■ Select BLUE to have the VCR display a blue screen while it advances

through the block of marked commercials.

■ Select VIDEO to have the VCR display the video as it advances through

the block of marked commercials.

To Play Back a Recording Made Using COMMERCIALAADVANCE™

1. Press MENU¥PROG to display the VCR MAIN MENU.

2. Press 6 to display the PREFERENCES menu.

3. Press 6 to select CA Playback: AUTO or MANUAL.

■ Select AUTO to have the VCR automatically advance through the blocks

of marked commercials.

It works with most 30, 45, and 60-second commercials.

A commercial group starting within the first two minutes or last two minutes of a recording will not be automatically skipped.

A commercial will not be skipped if the recording starts in the middle of a commercial segment, one isolated commercial is shown without others, or a commercial is longer than one minute. Press FF to scan through the commercial.

It is possible that part of a recorded program might be skipped if the program segment is between commercials and less than one minute or there are frequent dark and quiet scenes. If part of the program is skipped, rewind the tape to the beginning of the skipped program segment and press PLAY.

■ Select MANUAL and the VCR will not advance through the blocks of

marked commercials until you press SEARCH.

The VCR will resume playback when it reaches the end of the marked commercials.

If you press SEARCH during playback of material other than commercials, the VCR will still advance to the end of the next ÒmarkedÓ commercial block and resume playback.

VCR MAIN MENU 1 VCR Plus+ 2 Timer Recordings 3 Time 4 Channels 5 Setup 6 Preferences 7 Language/Langue 8 Audio

0 Exit

PREFERENCES 1 Remote Control: VCR1 2 Auto Play: ON 3 Auto TV/VCR: ON 4 Front Panel: AUTO 5 CA Marking: ON 6 CA Playback: AUTO 7 CA Display: BLUE 8 Set Auto Repeat

0 Exit

VCR MAIN MENU 1 VCR Plus+ 2 Timer Recordings 3 Time 4 Channels 5 Setup 6 Preferences 7 Language/Langue 8 Audio

0 Exit

PREFERENCES 1 Remote Control: VCR1 2 Auto Play: ON 3 Auto TV/VCR: ON 4 Front Panel: AUTO 5 CA Marking: ON 6 CA Playback: AUTO 7 CA Display: BLUE 8 Set Auto Repeat

0 Exit

See page 55 for answers to common questions about COMMERCIALAADVANCEª .

Recording a Program

This section explains the available recording options, including the following:

■ Basic Recording

■ Recording Features

■ Program Express Recording

■ Express (XPR) Recording

■ VCR Plus+ Recording

■ Timer Recording

■ Broadcast Stereo TV or SAP (Second Audio Program) Recording

■ Audio Only Recording

■ Using Two VCRs for Copying and Editing Tapes

Basic Recording

Recording a Program

To Make a Recording

Turn on the TV and tune it to the VCR viewing channel, either 3, 4, or TVÕs video input channel.

1. Insert a tape with safety tab in place.

2. Press VCR1 (VCR2¥DVD) to set remote to control VCR.

3. If using one of the basic hookups, make sure the VCR indicator appears in the VCRÕs display

panel. If not, press TV¥VCR to turn it on.

4. Select recording speed by using SPEED on remote.

The tape speed indicator appears in the VCRÕs display panel and on the TV screen.

5. Select the channel to be recorded.

The channel number appears in the VCRÕs display panel and on the TV screen.

6. Press RECORD on the VCR or REC on the remote to begin recording. REC appears in the

VCRÕs display panel while the VCR is recording.

Watch a TV Channel While VCR is Recording a Different Channel

1. Follow steps 1 through 6 above.

2. If using one of the basic hookups, press TV¥VCR to switch to the TV channel.

The VCR indicator will turn off in the display panel.

3. Select the channel you want to watch with the VCRÕs remote or TVÕs channel buttons if the remote does not control your TV.

Press TV on VCR remote to control a compatible TV.

4. When recording is finished, press VCR1 (VCR2¥DVD) and STOP.

Recording a Program

MENU CLEAR

CHANNEL

DISPLAY

TRACKING

PROG. EXP

Recording Features

Recording Speeds

Press SPEED on the remote to select a recording speed (SP, LP, or SLP). The speed you select appears on the TV screen and in the VCRÕs display panel. The VCR automatically selects the playback speed (SP, LP, or SLP).

■ SP (Standard Play) gives the best quality recording. That is why most

prerecorded, rental tapes are recorded in SP. Fewer programs can be recorded on the tape. Special effects such as pause, slow motion, picture search, and frame advance work well.

■ LP (Long Play) gives twice the recording time of tapes recorded in SP.

Special effects in playback are not recommended in LP.

■ SLP (Super Long Play) gives three times the recording time of tapes

recorded in SP. Special effects such as pause, slow motion, picture search, and frame advance work well.

Recording Pause

This feature allows you to prevent recording short passages of unwanted material.

Recording Time

Cassette SP LP SLP

T-120 2Hr 4Hr 6Hr

T-160 2Hr 40Min 5Hr 20Min 8Hr

■ Press PAUSE during recording to stop and start recording.

RECP appears in the VCRÕs display panel.

■ The VCR will automatically switch from pause to stop after a few minutes.

Program Express Recording (VCR’s Display Panel)

Program express recording allows you to quickly program the VCR for one recording using the VCRÕs display panel instead of the on-screen menus. The VCR will turn off automatically at the end of the recording.

1. Insert a tape with safety tab in place.

2. Use the PROG. EXP and the CHANNEL up or down buttons behind left front panel control door to enter the information.

3. Press PROG. EXP to bring up the display.

The channel number flashes in the dislay panel.

4. Press the up or down arrow to select the channel number.

5. Repeat steps 2 - 3 to enter the START, END, DATE, and tape SPEED.

The time increases in increments of 30 minutes while the date increases in increments of one.

Buttons Located Behind Left

Front

6. Press PROG. EXP when SAVE flashes in the display.

SAVED appears to let you know the program is set.

7. Turn off VCR.

Express Recording (XPR)

OWEREJECTTV¥VCR

LAY

STOP

PAUSERECORD

VIDEO INMONO L¥AUDIO IN¥

INPUT PROG. EXPMENU CLEAR

CHANNEL

DISPLAY

TRACKING

SLP

VCR

H M

Express Recording (XPR)

Express recording enables you to record up to four hours of programming without using the timer program feature. The VCR will turn off automatically at the end of the recording.

Display showing 30 minutes

1. Insert a tape with safety tab in place.

2. Select the channel you want to record.

3. Select the desired recording speed using SPEED on the remote.

4. Press RECORD twice on the VCR or REC twice on the remote to activate XPR recording.

5. Press RECORD on the VCR or REC on the remote repeatedly until the amount of recording time for the program is displayed in the VCRÕs display panel or on the TV screen.

Press Recording

RECORD Time

RECORD LENGTH 0:00

CH 04

0:30 (30 Min)

1:00 (1 Hr)

1:30 (1 Hr, 30 Min)

2:00 (2 Hrs)

Press REC to set length

3:00 (3 Hrs)

4:00 (4 Hrs)

Express Display on

TV Screen

0:00 (Stops)

Each press increases the time.

The amount of time the VCR will record and X-REC will appear in the VCRÕs

display panel.

You can increase the amount of recording time by pressing REC on the remote or RECORD on the VCR.

Stopping a Recording in Progress

With the VCR: Press POWER and then STOP within a few seconds. With the Remote: Press VCR1 (VCR2¥DVD) and then STOP within a

few seconds.

(Normal Recording)

Recording a Program

Recording While You’re Away (VCR Plus+* Recording)

VCR Plus+ Setup for Antenna or Unscrambled Cable Systems (Not Requiring a Cable Box or Cable Box VCR Can Control)

A VCR Plus+ channel number is assigned for each broadcast or cable channel. These numbers are listed in most publications that list PlusCode* numbers.

1. Prepare the worksheet on the next page for the VCR Plus+ channels that are different than the channels you receive them on. Refer to the chart below for standardized VCR Plus+ channel numbers.

Broadcast or Cable-TV VCR Plus+ Channel Number You Station Name Channel Number Receive This Station On

HBO 33 See Note 1

ESPN 34 See Note 1

ABC See Note 2 See Note 1 FOX See Note 2 See Note 1

Note 1: Check your local or cable listing for the channel number you receive this station on. Note 2: Check your local listing for the broadcast or VCR Plus+ channel number assigned to this station.

2. Press MENU¥PROG on the remote to display the VCR MAIN MENU on the TV screen.

3. Press 4 to display CHANNELS menu.

4. Press 4 to display VCR Plus+ Channel List menu.

5. Using your worksheet, press two numbers to enter each channel number you receive on a different channel than the assigned VCR Plus+ channel number.

Press CHAN up or down to move the numbers up or down on the menu. Press CLEAR on the remote to erase a number.

6. Press MENU¥PROG when you are finished.

Auto channel search must be performed before setting the VCR Plus+ channel list.

SAMPLE

VCR MAIN MENU 1 VCR Plus+ 2 Timer Recordings 3 Time 4 Channels 5 Setup 6 Preferences 7 Language/Langue 8 Audio

0 Exit

CHANNELS

1 Auto Channel Search 2 Add/Remove Channels 3 Signal Type: CABLE 4 VCR Plus+ Channel List

VCR+ Channel My Channel

5 -4 -3 -> -> -> -2 -1 --

Standardized VCR Plus+ Channel Numbers for Cable-TV

U.S.A. List

35 American Movie Classics 39 Arts & Entertainment 57 Black Entertainment 54 Bravo 42 Cable News Network 45 Cinemax 98 Cinemax 2 37 The Discovery Channel 53 The Disney Channel 63 Entertainment Television 34 ESPN Sports Network 47 The Family Channel 33 Home Box Office 95 Home Box Office 2 96 Home Box Office 3 51 The Learning Channel 46 Lifetime

*VCR Plus+ and PlusCode are trademarks of Gemstar Development Corporation.

58 The Movie Channel 48 Music Television 49 The Nashville Network 38 Nickelodeon 64 Nostalgia Television 99 Quality Value Cable 41 Showtime 97 Showtime 2 59 Sports Channel 52 Turner Network Television 44 USA Network 62 Video Hits 1 93 Viewer’s Choice 1 94 Viewer’s Choice 2 55 WGN Chicago 43 WTBS Atlanta 60 WWOR New York

Canadian List

67 Allarcom Pay Television/Superchannel 44 Arts & Entertainment 72 Cable News Network-Headline News 61 Cable News Network 70 Canadian Home Shopping Network 56 Canal Famille 69 Cathay International Television Inc 68 Chinavision Canada Corp 60 Country Music Television 63 Family Channel 62 First Choice 96 First Choice Two 97 First Choice Three 99 First Choice Four 90 House of Commons 91 La Chaine Francaise 51 The Learning Channel

Use CHAN up/dn to select Press 0-9 to change Press MENU to exit

65 MeteoMedia/The Weather Network 48 MuchMusic Network 55 MusiquePlus 52 Nashville Network 73 Newsworld/CBC 53 Le Reseau des Sports 43 The Sports Network 64 Super Ecran 37 Super Ecran B 98 Super Ecran C 66 Telatino Network 46 TV5 Montreal 92 Viewer's Choice 1 93 Viewer's Choice 2 94 Viewer's Choice 3 95 Viewer's Choice 4 71 Vision TV: Canada’s Faith Network 38 Youth TV, Canada Inc

Recording While You’re Away

VCR Plus+äChannel Worksheet

Use this worksheet to create a listing from which you can set up your VCR for VCR Plus+ programming.

Broadcast or Cable TV

Station Name

(Such as ABC, NBC, CBS, etc.)

VCR Plus +

Channel Number*

(See Standardized VCR Plus+ Channel Chart)

Channel Number You

Receive This Station On**

*Check your local listing for broadcast or VCR Plus+ channel numbers assigned to network stations.

**Check your local or cable listing for the channel numbers to enter in this column.

Recording a Program

VCR Plus+ Recording (continued)

The VCR Plus+ and timer program features let you program the VCR to record up to eight different programs. Before using VCR Plus+ to record a program, make sure that:

■ The clock is set correctly.

■ A tape with safety tab has been inserted with enough tape to record the programs.

■ The remote is set to control the VCR Ñ using VCR1 (VCR2¥DVD).

■ The VCR is set up for VCR Plus+ programming.

■ If you receive all channels through a cable box, set up the cable box as shown on pages 12-13.

■ If you have an antenna, cable system not requiring a cable box, or a cable box this VCR can control, complete VCR

Plus+ setup on page 38.

Setting a VCR Plus+ Recording

1. Press MENU¥PROG on the remote to display the VCR MAIN MENU on the TV screen.

2. Press 1 to display the VCR PLUS+ menu.

3. Press numbers on the remote to enter the PlusCode number for the program you want to record. PlusCode numbers are found in most local TV listings.

Press CLEAR on the remote to correct an entry.

4. Press MENU¥PROG to enter the program.

If the VCR does not recognize the PlusCode number, ÒUnrecognized number... Please Re-enterÓ appears on the TV screen. Check the number and enter it again.

5. Press 1, 2, 3, or 4 to select type of program.

1 One Time Ð single program recorded once.

2 Daily Ð program recorded at same time every day.

3 Weekdays Ð program recorded at same time Monday through Friday.

4 Weekly Ð program recorded at same time once a week.

6. Select recording speed using SPEED on the remote.

7. Press CLEAR if you want to change the program end time.

This feature allows you to extend the recording time on VCR Plus+ programs. This option may be useful when recording programs such as sporting events that could go past scheduled broadcast times.

8. Press MENU¥PROG to enter your program. A reminder appears which will time out.

ÒPROGRAMS OVERLAPÓ may appear on the screen if you entered two programs where the times overlap.

9. The TIMER RECORDINGS menu appears. Press 3 to enter an additional VCR Plus+ program, or press 0 to exit.

10. Turn off the VCR before recording time.

TIMER appears in the VCRÕs display panel when the timer has been

programmed.

11. If using a cable box, leave it turned on. If the VCR cannot control the cable box, tune it to the channel you want to record.

Note: To clear a program see page 42.

VCR MAIN MENU

1 VCR Plus+

VCR PLUS+

Enter PlusCode number

(from TV listing)

Press MENU to exit

How often should this program record?

1 One Time 2 Daily (every day) 3 Weekdays (M-F) 4 Weekly (Once per week)

Program 1 (One Time) Channel 08 CABLE

Start Time 02:10 PM End Time 03:35 PM Start Date 11/18/96 Mon Tape Speed SLP 1=SP 2=LP 3=SLP Press CLEAR to correct Press MENU to save

Program 1 has been saved Remember to insert a

recordable tape and turn the VCR off before the program start time.

Recording While You’re Away

Recording While You’re Away (Timer Recording)

The timer program and VCR Plus+ features let you program the VCR to record up to eight different programs. Before setting the timer, make sure that:

■ The clock is set correctly.

■ A tape with safety tab has been inserted with enough tape to record the programs.

■ The remote is set to control the VCR Ñ using VCR1 (VCR2¥DVD).

■ If you receive all channels through a cable box or satellite receiver, set up the cable box or

satellite receiver on pages 11-13.

Setting a Timer Recording (Using On-Screen Menus)

1. Press MENU¥PROG on remote to display VCR MAIN MENU.

2. Press 2 to display TIMER RECORDINGS menu.

3. Press 1 to display Create a New Program menu.

4. Press 1, 2, 3, or 4 to select type of program.

1 One Time Ñ single program recorded once.

2 Daily Ñ program recorded at same time every day.

3 Weekdays Ñ program recorded at same time Monday through Friday.

4 Weekly Ñ program recorded at same time once a week.

5. Press number buttons on the remote to enter the channel number (or INPUT to select line input), start time including AM or PM, end time, and start date of the recording. Just follow the on-screen prompts.

Press CLEAR to correct an entry.

6. Select recording speed using SPEED on the remote.

7. Press MENU¥PROG to enter your program. A reminder appears which will time out.

ÒPROGRAMS OVERLAPÓ may appear on the screen if you have entered two programs where the times overlap.

8. The TIMER RECORDINGS menu appears. Press 1 to enter an additional timer program, or press 0 to exit.

9. Turn off the VCR before recording begins.

TIMER appears in the VCRÕs display panel when the timer has been

programmed.

10. If using a cable box, leave it turned on.

Note: To clear a program see page 42.

VCR MAIN MENU 1 VCR Plus+ 2 Timer Recordings

TIMER RECORDINGS

1 Create a New Program

How often should this program record?

1 One Time 2 Daily (every day) 3 Weekdays (M-F) 4 Weekly (Once per week)

Program 2 (One Time) Channel -- CABLE

Start Time 02:10 PM

Program 2 (One Time)

Channel 08 CABLE

Start Time --:--

End Time 03:35 PM

Program 2 (One Time) Channel 08 CABLE

Start Time 02:10 AM 1=AM End Time --:-- 2=PM

Program 2 (One Time) Channel 08 CABLE

Start Time 02:10 PM End Time 03:35 PM Start Date 11/18/96 Mon Tape Speed SLP 1=SP 2=LP 3=SLP Press CLEAR to correct Press MENU to save

Program 2 has been saved Remember to insert a

recordable tape and turn the VCR off before the program start time.

Important: If your cable box or satellite receiver is not controlled by the VCR, turn it on and tune it to the channel you want to record before the

Recording a Program

Stopping a VCR Plus+ or Timer Recording in Progress

With the VCR: Press POWER and then STOP within a few seconds.

With the Remote: Press VCR1 (VCR2¥DVD) and then STOP within a few seconds.

Checking, Editing, or Clearing a VCR Plus+ or Timer Recording

1. Press MENU¥PROG on remote to display VCR MAIN MENU on TV screen.

2. Press 2 to display the TIMER RECORDINGS menu.

VCR MAIN MENU 1 VCR Plus+ 2 Timer Recordings

3. Press 2 for Review Existing Progs. feature.

The first program in the timer is displayed.

■ Check the Programs: Press MENU¥PROG to display information for the

next program.

■ Edit the Program: Press DISPLAY to edit the program. The frequency

menu appears first so you can change how often you want to record the program.

How often should this program record?

1 One Time 2 Daily (every day) 3 Weekdays (M-F) 4 Weekly (Once per week)

0 Cancel

Press a number button to select the type of program you want to record.

Program 2 (One Time) Channel 08 CABLE

Start Time 02:10 PM End Time 03:35 PM Start Date 11/18/96 Mon Tape Speed SLP 1=SP 2=LP 3=SLP Press CLEAR to correct Press MENU to save

TIMER RECORDINGS

1 Create a New Program 2 Review Existing Progs.

Program 2 (One Time)

Channel 08 CABLE

Start Time 02:10 PM

End Time 03:35 PM

Start Date 11/18/96 Mon

Tape Speed SLP

Press DISPLAY to edit

Press CLEAR to delete

Press MENU for next prog

Edit the rest of the program using the CLEAR and number buttons.

■ Clear the Program: Press CLEAR when the program you want to remove

appears on the TV screen.

Timer Recording From the VCR’s Line Input

Recording While You’re Away

The line input refers to the signal coming from the AUDIO and VIDEO IN jacks of the VCR. Recording from the line input is convenient if you have a satellite receiver or similar component attached to these jacks.

To timer record from the component connected to the VCRÕs line input: press INPUT once to enter VIDEO1 to record from the jacks on the back of the VCR, or press INPUT twice to enter VIDEO2 to record from the jacks on the front of the VCR.

Program 2 (One Time) Channel VIDEO1

Start Time --:-- End Time --:-Start Date --/--/-Tape Speed SLP

Press CLEAR to correct Press MENU to save

Recording a Program

Recording Broadcast Stereo TV or SAP (Second Audio Program)

Some TV programs are broadcast with stereo audio or a second audio language (SAP). The Reception: STEREO/MONO/ SAP feature lets you select the type of audio you want to record. To enjoy Hi-Fi playback, you must connect your VCR to a stereo television or amplifier/receiver using the audio/video jacks as shown in the advanced hookups.

To Record Stereo Broadcast TV or SAP

Turn on the TV and tune it to the VCR viewing channel, either 3, 4, or TVÕs video input.

1. Insert a tape with safety tab in place.

2. If using one of the basic hookups, make sure the VCR indicator appears

in the VCRÕs display panel. If not, press TV¥VCR to turn it on.

3. Use SPEED on the remote to select a recording speed.

The tape speed indicator appears in the VCRÕs display panel and on the TV screen.

4. Select the channel or line input to be recorded.

The channel number, VIDEO1, or VIDEO2 appears on the TV screen.

5. Set the Reception: STEREO/MONO/SAP feature for the type of audio you want to record.

A. Press MENU¥PROG to display the VCR MAIN MENU on the TV screen.

B. Press 8 to display the AUDIO menu.

C. Press 1 to select the type of audio Reception: STEREO, MONO, or SAP.

■ Set to stereo for normal recording and to record broadcast stereo TV. The STEREO indicator lights in the VCRÕs display panel when the

station you are tuned to is broadcasting stereo.

■ Set to MONO if the stereo signal is weak and the sound is too ÒnoisyÓ.

■ Set to SAP to record SAP (second audio program) instead of the main

audio on the linear track. The main (or normal) audio will still be recorded on the hi-fi tracks.

The SAP indicator ( ) lights in the VCRÕs display panel.

Set the Tape Playback: HI-FI/LINEAR/MIX feature to LINEAR to hear SAP. (Details are on page 30.)

6. Press REC on remote or RECORD on the VCR to start recording. REC

appears in the VCRÕs display panel.

7. Press STOP when you are finished.

VCR MAIN MENU 1 VCR Plus+ 2 Timer Recordings 3 Time 4 Channels 5 Setup 6 Preferences 7 Language/Langue 8 Audio

0 Exit

AUDIO

1 Reception: STEREO 2 Tape Playback: HI-FI

0 Exit

Recording Audio Only

You can record audio only from another audio source connected to the AUDIO IN (MONO L and R) jacks on the back or front of the VCR. Any video on the tape will be erased when recording audio only.

To Record Audio Only

1. Press the INPUT button to select a line input.

Press INPUT once to record from the back AUDIO IN jacks. L1 appears in

the VCRÕs display panel and VIDEO1 appears on the TV screen.

Press INPUT twice to record from the front AUDIO IN jacks. L2 appears

in the VCRÕs display panel and VIDEO2 appears on the TV screen.

The VCR will record audio from the audio equipment connected to the AUDIO IN jacks.

2. Use SPEED on the remote to select the recording speed.

The tape speed indicator appears in the VCRÕs display panel and on the TV screen.

3. Make sure the Reception: STEREO/MONO/SAP feature is set to STEREO.

A. Press MENU¥PROG to display the VCR MAIN MENU on the TV

screen.

B. Press 8 to display the AUDIO menu.

C. Press 1 to select Reception: STEREO.

4. Start audio source playing and press REC on remote or RECORD on the VCR to begin recording.

REC appears in the VCRÕs display panel.

VCR MAIN MENU 1 VCR Plus+ 2 Timer Recordings 3 Time 4 Channels 5 Setup 6 Preferences 7 Language/Langue 8 Audio

0 Exit

AUDIO

1 Reception: STEREO 2 Tape Playback: HI-FI

5. Press STOP when you are finished.

To Play Back Audio

Connect the AUDIO OUT of the VCR to the appropriate input on your amplifier or receiver. Do not use the phono input. Refer to your amplifier or receiver userÕs guide for information.

0 Exit

Recording a Program

Using Two VCRs for Copying and Editing Tapes

Use this VCR as the playback VCR and the other VCR as the recording VCR. If you have two compatible VCRÕs, use the AutoEdit feature described on the next page.

Operating Instructions

1. Turn on the TV and VCRs.

2. Tune TV to the VCR viewing channel, either 3, 4, or TVÕs video input.

3. If you have connected your VCR using the Basic Hookup (page 8), tune recording VCR to channel 3 or 4 Ñ the one selected on the back of the playback VCR.

If you have connected your VCR using the Advanced Hookup (page 8), press

INPUT on recording VCR to select the line input. Select L1 to record from the jacks on the back or L2 to record from the jacks on the front.

4. Insert the tape you want to copy into the playback VCR. Insert a blank tape with safety tab in place into the recording VCR.

To prevent recording on-screen displays from the playback VCR, press DISPLAY four times. (See page 28 for details.)

5. Press PLAY, then PAUSE on playback VCR when you reach the point on the tape or program where you want to begin copying. If the tape was not recorded on the playback VCR, streaks may appear and you may need to adjust tracking.

6. Press RECORD, then PAUSE, on recording VCR.

7. Press PAUSE buttons on both VCRs at the same time to begin copying the tape.*

8. Edit out segments that you do not want to copy by pressing PAUSE on recording VCR to stop copying the tape. Then locate the next segment you want to copy on the playback VCR by using FWD, REW, and PLAY. Press PAUSE on the playback VCR. Press PAUSE at the same time on both VCRs to resume copying.

9. Press STOP on both VCRs when you are finished.

* You may turn off the TV after the recording has started as it does not have to be

on to copy a tape.

Caution: The unauthorized recording of television programs and other materials may infringe the rights of others.

Using Dual Remote with AutoEdit

Use this VCR as the playback VCR and set it to respond to VCR2¥DVD on the remote as described on page 21. Use your other compatible VCR as the recording VCR, which should respond to VCR1.

1. Follow steps 1 Ð 4 in the ÒOperating InstructionsÓ on page 46.

2. Press VCR1 on remote to control recording VCR. Press RECORD, then pause, to put recording VCR in pause mode.

3. Press VCR2¥DVD on remote to control playback VCR.

4. Use FF, REW, and PLAY to locate the point where you want to begin copying. Press PAUSE while VCR is playing to put playback VCR in pause mode.

5. Press EDIT on remote to start the VCRs copying.

6. Press EDIT again when you want to stop the tape from copying.

7. Repeat steps 4 Ð 6 as needed.

8. Press VCR1, STOP, then VCR2¥DVD, STOP, when you are finished.

Reference

OWEREJECTTV¥VCR

LAY

STOP PAUSERECORD

VIDEO INMONO L¥AUDIO IN¥

INPUT PROG. EXPMENU CLEAR

CHANNEL

DISPLAY

TRACKING

Reference

This reference section includes the following information:

■ Controls ■ Cleaning the VCR ■ Questions About Commercial Advance ■ Index

■ Specifications ■ Trouble Shooting Guide ■ Warranty Information

Controls

Front Panel

Tape Compartment

Shuttle

Control Door

Remote

CHANNEL/TRACKING Up or Down

Selects next higher or lower channel in the VCRÕs channel memory.

Adjusts tracking when a tape is playing. Allows you to change entries for selected menu features. Used to set a timer recording with the TV off.

CLEAR

Resets time counter to 0:00:00. Allows you to change entries for selected menu features.

DISPLAY

Displays VCR operating displays on the TV screen. Displays the time counter. Allows you to change entries for selected menu features.

EJECT

Press when the VCR is stopped to eject the cassette.

INPUT

Turns the line input on or off. L1 or L2 appears in

VCRÕs display panel and VIDEO1 or VIDEO2 appears on the TV screen.

Line input refers to the signal coming from the component connected to the AUDIO/VIDEO IN jacks

on the back (L1) or front (L2) of the VCR.

Displays the VCR MAIN MENU on the TV screen. Used with arrow buttons to select features in the menu.

MONO L¥AUDIO IN¥R Jacks

Receives audio signals from another component, like a VCR or camcorder when it is connected to these jacks.

Attach a component that is not stereo to the MONO L jack to hear sound on both channels.

Select L2 to record from these jacks.

Display

Control Door

PAUSE

Pauses action for viewing during playback. Pauses recording to prevent recording of unwanted scenes.

PLAY

Plays a tape.

POWER

Turns the VCR on or off.

PROG. EXP

Used with CHANNEL up and down buttons to set a timer recording with the TV off.

RECORD

Starts VCR recording. Used for express recording (XPR).

Remote Sensor

Receives signals from the remote control. Aim the remote at this sensor with no objects between them.

Shuttle Dial

Rewinds and fast forwards the tape when VCR is stopped. Plays the picture in slow motion during play pause. Searches the picture in forward and reverse during playback.

STOP

Stops the normal functions such as record, playback, rewind, fast forward, or pause.

TV¥VCR

Switches the picture signal so that it either comes from the VCR or the TV channel. (See page 17.)

VIDEO IN Jack

Receives video signals from another component, like a VCR or camcorder, when it is connected to this jack.

Select L2 to record from these jacks.

Back Panel

3 4

AUDIO

VIDEO

MONO

FROM

ANTENNA

L L

IN OUT

OUT

TELEVISION

Location of Controls

CH3 CH4 Switch

Selects the channel to which you will tune the TV to see the VCR picture if you connect the VCR using one of the basic hookups.

VIDEO and AUDIO IN (R and MONO L) Jacks

Receives signals from another component, like a VCR or camcorder, when it is connected to

these jacks. Use INPUT to select L1 in the

IN FROM ANTENNA Connector

Receives the signal from an antenna, cable system, or satellite receiver that is attached to this connector.

OUT TO TELEVISION Connector

Passes signal to TV using the cable supplied.

VCRÕs display panel.

Attach a component that is not stereo to the MONO L jack to hear sound on both channels.

VIDEO and AUDIO OUT (R and L) Jacks

Sends signals from VCR to another component, like a TV monitor or VCR, when it is connected to these jacks.

Display Panel

This VCR includes a feature that enables you to change the brightness level of the fluorescent display panel.

1. Press MENU¥PROG on the remote to see the VCR MAIN MENU on the TV screen.

2. Press 6 to display the PREFERENCES menu.

3. Press 4 to select Panel Display: AUTO, BRIGHT, or DIM.

■ Select AUTO to keep the display panel bright when VCR is on and dim

when it is off.

■ Select BRIGHT to keep the display panel bright.

■ Select DIM to keep the display panel dim.

VCR MAIN MENU 1 VCR Plus+ 2 Timer Recordings 3 Time 4 Channels 5 Setup 6 Preferences 7 Language/Langue 8 Audio

0 Exit

PREFERENCES 1 Remote Control: VCR1 2 Auto Play: ON 3 Auto TV/VCR: ON 4 Front Panel: AUTO 5 CA Marking: ON 6 CA Playback: AUTO 7 CA Display: BLUE 8 Set Auto Repeat

0 Exit

Reference

SLP

VCR

STEREO

HIFI

Display Panel (continued)

STEREO Indicator

Cassette-in Indicator

Status Indicators

Tape Speed Indicator

Cassette-In Indicator ( )

Lights when a tape is in the VCR.

Channel Number, L1, or L2

The channel number or line indicator (L1 or L2) is

displayed.

Press INPUT to select L1 to record from the jacks on the back of the VCR or L2 to record from the jacks on

the front of the VCR.

HIFI Indicator

Lights during hi-fi playback when the Tape Playback: HI-FI/LINEAR/MIX feature is set to HI-FI.

SAP Indicator

Time or Time Counter

Channel Number or Line Indicator (L1 or L2)

SAP Indicator ( )

Lights when the Reception: STEREO/MONO/SAP feature is set to SAP.

Status Indicators

Show what the VCR is doing.

BYE VCR turned off EJECT Ejecting tape FFWD Fast forward HELLO Turned on or unlocked LOCK Pro-Tect Plus turned on PLAY Playback REC Record REC P Record pause REW Rewind SAVE flashes Timer program entered with

TV off

Specifications

Format: VHS

Record/Playback Video: 4-Head

System Audio: 2 Hi-Fi record/playback system

Video Signal System: EIA standard: NTSC color

Antenna: 75-ohm external VHF/UHF combined antenna terminal

Tuner: USA: 181 channels capability*

(125 cable channels)

Canada: 178 channels capability*

(122 cable channels)

Type: Autoprogramming frequency synthesis

Power Requirement: 120V AC, 60 Hz

Power Consumption: 22 watts

Dimensions: 3.5 inches high

(90 mm)

15.43 inches wide (393 mm)

12.2 inches deep (314 mm)

Weight: 9.5 pounds

(4.3 kg)

Storage Temperature Range: - 22ûF (- 30ûC) to +149ûF (+65ûC)

Operating Temperature Range: +41ûF (+5ûC) to +104ûF (+40ûC)

*Check your cable companyÔs compatibility requirements.

Cleaning the VCR

Use a soft cloth or dusting attachment of your vacuum cleaner to dust your VCR. Remove dust from the ventilation holes on the top, back, sides, and bottom of the cabinet.

Plastic surfaces are easily scratched and can be marred by alcohol and various solvents. Avoid excessive use of oil-based furniture polishes since the materials used in the cabinet will accumulate more dust. We recommend using a non-abrasive, anti-static cleaner and polisher.

Reference

Trouble Shooting Guide

Sometimes problems can be easily solved by checking a few basic things. Check below before you call for help or take your VCR to an Authorized ProScan VCR Servicenter.

Trouble Here's what to try:

No power

Clock shows incorrect time or date

VCR does not respond to remote

Remote no longer controls a ProScan TV

■ Plug VCR into an operating outlet.

■ Check connections.

■ Clock was not set accurately (check AM/PM and date).

■ Time counter display appears in display panel. Press DISPLAY on

remote.

■ Press VCR1 (VCR2¥DVD) to set remote to control the VCR. See

page 21.

■ VCR2¥DVD button may be set to control a DVD. See page 21 to

change back to VCR2.

■ Aim remote at VCR with no objects between them.

■ Remove batteries and hold down one or more buttons for several

seconds to drain the microprocessor inside the remote to reset it. Reinstall the batteries and try remote again.

■ Change batteries.

■ Press TV to set remote to control the corresponding compatible TV.

See page 22.

■ Reprogram remote for ProScan or RCA TV. See page 22.

■ Aim remote at TV with no objects between them.

■ Change batteries.

■ Remove batteries and hold down one or more buttons for several

seconds to drain the microprocessor inside the remote to reset it. Reinstall the batteries and try remote again.

Remote no longer controls a compatible TV, cable box, satellite receiver, or auxiliary component

VCR only responds to VCR2¥DVD button on remote

No picture when VCR turned on Ð using a basic hookup

Poor or no picture for normal TV viewing

Time counter not working

■ Press TV, AUX, VCR2¥DVD or SAT¥CABLE to set remote to control a

compatible component. See pages 21-24.

■ Aim remote at component with no objects between them.

■ Reprogram remote after batteries have been changed.

■ Reprogram VCR2¥DVD button to operate compatible satellite

receiver. See page 23.

■ Change batteries.

■ Remove batteries and hold down one or more buttons for several

seconds to drain the microprocessor inside the remote to reset it. Reinstall the batteries and try remote again.

■ Check setting of Remote Control: VCR1/VCR2 feature. See page 21.

■ Press TV¥VCR to turn VCR indicator on. See page 17.

■ Check to see if Auto TV/VCR feature is set to OFF. See page 17.

■ Press TV¥VCR to turn VCR indicator off.

■ Switch TV to an active channel.

■ Check antenna connections.

■ The time counter does not advance during unrecorded portions of

tape. When an unrecorded segment of tape is encountered, the time counter will hold its count until recorded material is detected again.

■ A minus (Ð) will appear in front of the time if you rewind the tape

farther back than a counter reading of 0:00:00.

Trouble Here's what to try:

Troubleshooting Guide

Snowy or no picture during playback

Will not record or play

Streaks in picture during normal playback

Rewind does not operate

Will not record

VCR is paused during playback

■ Press TV¥VCR to turn VCR indicator on.

■ Check TV channel selected (3 or 4) to make sure it matches the channel

selected with CH3 CH4 switch on back of VCR.

■ Check TVÕs fine tuning.

■ Check video cable connections between VCR and TV monitor.

■ Set TV monitor to video input channel.

■ Try another tape.

■ Some snow/streaks are normal during search, frame advance, slow-

motion, or stop-action playback.

■ No cassette in VCR.

■ Eject and re-insert cassette.

■ Broken tape Ñ try another cassette.

■ Some snow/streaks are normal during search, frame advance, slow-

motion, or stop-action playback.

■ Tape already rewound.

■ Safety tab removed from cassette.

■ Make sure the line indicator (L1 or L2) is turned off in VCRÕs display

panel for normal recording from the VCRÕs tuner. Press INPUT to turn off the line indicator.

■ VCR is in pause mode. Press PAUSE or PLAY.

VCR Plus+ or timer recording not made or wrong program recorded

VCR makes noise when stopped

Will not auto search active channels correctly

Cannot select channels over 69

Cassette with safety tab removed does not start to play automatically

■ Wrong PlusCode number entered.

■ Cable box or satellite receiver was not turned on at time recording was

to begin. VCR cannot control cable box or satellite receiver, or component is positioned incorrectly.

■ Program entered incorrectly (wrong channel or times).

■ Power interruption. Clock area in display panel will show - -:- -.

■ Check to see if time and date are correct Ñ including AM/PM.

■ Program exceeded tapeÕs length or tape was not rewound beforehand.

■ VCR was not turned off at the time recording was to start.

■ No tape in VCR or cassetteÕs safety tab broken off.

■ VCR is removing tape from heads. This is normal. The head cylinder

inside the VCR will continue to rotate for a few minutes after you put the VCR in the stop mode.

■ Check antenna connections.

■ Check Signal Type: CABLE/ANTENNA feature. See page 15.

■ Cable channels over 69 can only be selected if Signal Type:

CABLE/ANTENNA feature is set to CABLE. Details are on page 15.

■ Set Auto Play ON/OFF feature to ON. Details are on page 26.

Reference

Trouble Shooting Guide (continued)

Trouble Here's what to try:

Segment of tape plays over and over

Stereo or SAP sound not recorded

No stereo sound during playback

Stereo audio too noisy

Tape continues forward or reverse search during jog shuttle operation

VCR forwards through commercials or momentarily displays a blue screen during playback

VCR forwards through a rental or pre-recorded tape displaying a blue screen

■Auto Repeat feature turned on. Details are on page 29.

■ Reception: STEREO/MONO/SAP feature must be set to STEREO to

record broadcast stereo. See page 44.

■ Reception: STEREO/MONO/SAP feature must be set to SAP to record

SAP. See page 44.

■ STEREO indicator not on. Station not broadcasting stereo.

■ Tape Playback: HI-FI/LINEAR/MIX feature must be set to HI-FI to

hear stereo sound during playback. See page 30.

■ Must use one of the advanced hook ups.

■ Stereo signal is weak. Set Reception: STEREO/MONO/SAP feature to

MONO. See page 44.

■ Press one of the TRACKING up or down buttons to minimize the noise.

■ Press PLAY¥PAUSE on the VCR or PLAY on the remote to return to

normal playback.

■ Press 3 or 4 to place VCR in pause mode.

■ COMMERCIALAADVANCEª CA PLAYBACK feature set to AUTO.

See pages 33-34.

■ Some tapes use special control track marking. Set the

COMMERCIALAADVANCEª CA PLAYBACK feature, in the

PREFERENCES menu to MANUAL.

COMMERCIALAADVANCEª feature does not mark commercials

Commercials recorded even though COMMERCIALAADVANCEª feature was turned on.

The commercial advance feature does not mark commercials under the following situations:

■ CA Marking: ON/OFF feature set to OFF. See page 33.

■ Recording is less than 15 minutes.

■ A single isolated commercial cannot be marked.

■ Recording started in the middle of a commercial segment.

■ The commercial is longer than one minute.

■ A commercial group within the first or last two minutes of a recording.

■ It does not mark commercials between 30-and-45 seconds and 45-and-

60 seconds.

■ Accuracy and effectiveness can vary depending upon program content

and the characteristics of the commercials.

■ Effectiveness may vary when local television stations insert their own

commercials.

■ COMMERCIALAADVANCEª is designed to record the commercials,

mark them, and then skip over the marked commercials during playback.

References

Questions and Answers About COMMERCIALAADVANCE™

Question Answer

Will commercials be scanned through only on playback of recordings?

How fast does the COMMERCIALA ADVANCEªVCR scan through the commercial breaks?

Are commercials still recorded if I want to watch them?

What if the VCR scans forward through part of my program?

Once a recording has been marked, does COMMERCIALAADVANCEª work each time the tape is played?

After marking commercials, is the tape left at the beginning or end of the recording?

Does the marking process interfere with other programmed recordings?

What happens if the marking process is interrupted?

Yes. The VCR does not rewind and mark commercial segments until after recording is finished.

In SLP tape speed, a 3-minute commercial break is scanned through in approximately 8-12 seconds. In SP, it takes about 25-35 seconds.

Yes. The recorded program, including commercials, can be viewed by setting the CA PLAYBACK feature to MANUAL.

Simply rewind the tape to just before the skipped segment, and press PLAY to view the program.

Yes. If the CA PLAYBACK feature is set to AUTO, the marked commercials should be skipped each time the tape is played in a

COMMERCIALAADVANCEª VCR.

The tape is left at the end of the recording so it is in position to begin additional programmed recordings.

No. If two or more recordings are programmed together without sufficient time to mark the first recording, marking will take place after all recordings have completed.

Marking can be interrupted to allow use of the VCR. Marking will resume again when the VCRÕs power is turned off as long as the tape has not been ejected from the VCR.

Does COMMERCIALAADVANCEªwork in all recording speeds?

Will COMMERCIALAADVANCEª marked recordings work in nonCOMMERCIALAADVANCEªVCRs?

Yes, COMMERCIALAADVANCEª works in SP and SLP.

A COMMERCIALAADVANCEª marked recording will play in a nonCOMMERCIALAADVANCEª VCR, but commercials will not

automatically be skipped.

Limited Warranty

What your warranty covers:

■ Any defect in material or workmanship.

For how long after your purchase:

■ Six months for labor charges

■ One year for parts.

The warranty period for rental units begins with the first rental or 45 days from the date of shipment to the rental firm, whichever comes first.

What we will do:

■ Pay any Authorized ProScan VCR Servicenter the labor charges to repair your VCR.

■ Pay any Authorized ProScan VCR Servicenter for the new or, at our option, refurbished

replacement parts required to repair your VCR.

How you get service:

■ Take your VCR to any Authorized ProScan VCR Servicenter. To identify your nearest

Authorized ProScan VCR Servicenter, ask your dealer, look in the Yellow Pages, or call 1-800PROSCAN.

■ Show the service technician your evidence of purchase date.

■ Pick up your VCR when repairs are completed.

What your warranty

■ Customer instruction. (Your OwnerÕs Manual clearly describes how to install, adjust, and

does not

cover:

operate your VCR. Any additional information should be obtained from your dealer.)

■ Installation and related adjustments.

■ Signal reception problems not caused by your VCR.

■ Damage from misuse or neglect.

■ Cleaning of video/audio heads.

■ Remote control batteries.

■ A VCR that has been modified or incorporated into other products or is used for institutional

or other commercial purposes.

■ A VCR purchased or serviced outside the USA.

■ Acts of God, such as, but not limited to lightning damage.

Product Registration:

■ Please complete and mail the Product Registration Card packed with your VCR. It will make it

easier to contact you should it ever be necessary. The return of the card is not required for warranty coverage.

How state law relates to this warranty:

■ This warranty gives you specific legal rights, and you also may have other rights that vary

from state to state.

What if you purchased your VCR outside the United States:

■ This warranty does not apply. Contact your dealer for warranty information.

Index

Accessories, Included . . . . . . . . .9

Add or Remove Channels

from Memory . . . . . . . . . . . .16

Advance, Commercial . .33,34,35

Antenna Connections . . . . . . .2,3

Arrow (MOVE) . . . . . . . .10,18-20

AUDIO Menu . . . . . . . . .30,44,45

AUDIO/VIDEO Jacks

. . . . . . . . . . .3-8,11,12,43,48,49

Auto Channel Search . . . . .14,15

Auto Clock Set . . . . . . . . . . . . .15

Auto Play Feature . . . . . . . .25,26

Auto Repeat Feature . . . . . . . .29

Auto TV/VCR Feature . . . .17,25

AutoEdit Feature . . . . . . . . . . .47

Automatic Tracking . . . . . . . . .27

AUX (Auxiliary) Button . . .18,24

Back Panel . . . . . . . . . . . . . . . . .49

Batteries, Inserting in Remote .10

Blank Search Feature . . . . . . . .32

Brightness, Front Panel . . . . . .49

Broadcast Stereo, Recording . .44 Buttons, Remote Control . .18-24

BYE Indicator . . . . . . . . . . . . . .50

Cable Box Setup . . . . . . . . . .11-13

Cable Box Codes . . . . . . . . .13,23

Cable Box Function

Buttons on Remote . . . . . . . .20

Cable System With

Cable Box, Connections .2,3-5

Cable System Without

Cable Box Connections . . . .2,3

Cassette-In Indicator . . . . . .25,50

CH3 CH4 Switch . . .3-8,11,17,49

CHANNEL Buttons . . . . . .18-20

Channel Number Indicator . . .50 Checking Timer and

VCR Plus+ Programs . . . . . .42

Checks, Trouble . . . . . . . . . .52-54

Choisissez une Langue . . . . . .16

CLEAR Button . . . . . . . . . . .18-20

Clearing Timer and

VCR Plus+ Programs . . . . . .42

Codes,

Auxiliary Components . . . .24

Cable Box . . . . . . . . . . . . . . . .23

DVD Component . . . . . . . . .21

Laserdisc Player . . . . . . . . . .21

Satellite Receivers . . . . . . . . .23

TV . . . . . . . . . . . . . . . . . . . . . .22

VCR2¥DVD Button . . . . . . .21

Commercial Advance . .33,34,55 Connections

Antenna . . . . . . . . . . . . . . . .2-3

Cable System With

Cable Box . . . . . . . . . . . . .2,4-5

Cable System Without

Cable Box . . . . . . . . . . . . . . .2,3

Satellite Receiver . . . . . . .2,6-7

Two VCRs . . . . . . . . . . . . . . . .8

Controlling a

Auxiliary Component . . . . .24

Cable Box . . . . . . . . . . . . . . . .23

DVD Component . . . . . . . . .21

Laserdisc Player . . . . . . . . . .21

Satellite Receiver . . . . . . . . .23

TV . . . . . . . . . . . . . . . . . . . . . .22

VCR . . . . . . . . . . . . . . . . . . . .21

Copying and Editing Tapes 46,47 Copying Tape, Connections . . .8

Date and Time, Setting . . . . . . .15

Daylight Savings Time . . . . . . .14

Digital Satellite Receiver,

Setup . . . . . . . . . . . . . . . . .11-13

DISPLAY Button . . . . . . .18-20,29

Display Panel . . . . . . . . . . . .49,50

Displays, Status . . . . . . . . . . . . .29

DSS SETUP Menu . . . . . . . . . . .11

EDIT Button . . . . . . . . . . . . . . . .47

Editing and Copying Tapes 46,47 Editing Timer and

VCR Plus+ Programs . . . . . .42

EJECT Button . . . . . . . . . . . .25,48

Express Recording . . . . . . . .36,37

F.ADV (Frame Advance)

Button . . . . . . . . . . . . . . . .19,27

Fast Forward Search . . . . . . . . .27

FF and FWD (Fast Forward)

Buttons . . . . . . . .18,19,27,46,47

FFWD Indicator . . . . . . . . . . . .48

Frame Advance . . . . . . . . . . . . .27

French Language . . . . . . . . . . .16

Front Panel . . . . . . . . . . . . . .46,47

Go-To Seach Feature . . . . . . . .31

HELLO Indicator . . . . . . . . .30,50

HIFI Indicator . . . . . . . . . . . .30,50

Hookups,

Antenna . . . . . . . . . . . . . . . .2-3

Cable System With

Cable Box . . . . . . . . . . . . .2,4-5

Cable System Without

Cable Box . . . . . . . . . . . . . . .2,3

Satellite Receiver . . . . . . .2,6-7

Two VCRs . . . . . . . . . . . . . . . .8

Index Search Feature . . . . . . . .31

Indicators . . . . . . . . . . . . . . . . . .50

INPUT Button . . . .18,19,43,48,49

Inserting Batteries in Remote .10 L1 and L2 Indicators .19,43,48,49

Language . . . . . . . . . . . . . . . . . .16

Laserdisc Player . . . . . . . . . . . .21

Light Button ( ) . . . . . . . . . . .18

Line Indicators

(L1 and L2) . . . . . . .19,43,48,49

Line Input, Recording From . .43

Locking the VCR . . . . . . . . . . . .30

LP Indicator . . . . . . . . . . . . . . . .50

LP Speed . . . . . . . . . . . . . . . . . .36

Manual Tracking . . . . . . . . . . . .27

MENU and

MENU¥PROG Buttons .11-16

MOVE Arrows . . . . . . . .10,18-20

MUTE Button . . . . . . . . . . . . . .20

Number Buttons . . . . . . . . .18,19

On-Screen Displays . . . . . . . . .29

PAUSE Button .18,19,26,36,46-48

Pause for Stop Action . . . . . . . .26

Pause, Recording . . . . . . . . . . .36

Picture Search . . . . . . . . . . . . . .27

Play a Tape . . . . . . . . . . . . . . . .25

PLAY Button . . . . .18,19,25,26,48

PLAY Indicator . . . . . . . . . . .25,50

Point and Select . . . . . . . . . . . . .10

POWER Button . . . . . . . .37,42,48

Power Cord, Attaching . . . . . . .9

PREV CH (Previous

Channel) Button . . . . . . .18-20

Pro-Tect Plusª Feature . . . . . .30

PROG. EXP (Program

Express) Button . . . . . . . .36,48

Program Information . . . . . . . .28

PWR (Power) Button . . . . . .18-24

REC and RECORD

Button . . . .18,19,35,37,44,46,47

REC Indicator . . . . . . . . . . . . . .50

REC P Indicator . . . . . . . . . . . .50

Reception: STEREO/

MONO/SAP Feature . . .44,45 Record One Channel While

Watching Another . . . . . . . .35

Recording

Audio Only . . . . . . . . . . . . . .45

Basic . . . . . . . . . . . . . . . . . . . .35

Express . . . . . . . . . . . . . . .36,37

One Channel While

Watching Another . . . . . . . .35

Pause . . . . . . . . . . . . . . . . . . .36

Timer . . . . . . . . . . . . . . . . .41-43

VCR Plus+ . . . . . . . . . .38-40,43

Speeds . . . . . . . . . . . . . . . . . .36

Remote Batteries, Inserting . . .10

Remote Control . . . . . . . .10,18-24

Remote Sensor . . . . . . . . . . . . . .48

Remove or Add

Channels from Memory . . .16 REW (Rewind)

Button . . . . . . . . .18,19,27,46,47

REW Indicator . . . . . . . . . . . . .50

Rewind Search . . . . . . . . . . . . .27

SAP Indicator . . . . . . . . . . .44,50

SAP, Recording . . . . . . . . . . . . .44

Satellite Receiver Codes . . . . . .23

Satellite Receiver Connections6-7

SAT¥CABLE Button . . . . . .18,23

SAVE Indicator . . . . . . . . . .36,50

SAVED Indicator . . . . . . . . .36,50

SEARCH Button . . . . .18,19,31,32

Sensor, Remote . . . . . . . . . . . . .48

SHUTTLE DIAL . . . . . . . . . .27,48

Signal Type: CABLE/

ANTENNA Feature . . . . . . .15

SLOW + and Ð Buttons .18,19,26 SLOW + and Ð Indicator . . .26,50

Slow Motion Playback . . . . . . .26

SLP Indicator . . . . . . . . . . . . . .50

SLP Speed . . . . . . . . . . . . . . . . .36

SP Indicator . . . . . . . . . . . . . . . .50

SP Speed . . . . . . . . . . . . . . . . . . .36

Specifications . . . . . . . . . . . . . . .51

SPEED Button .18,19,35-37,40,41

Speeds, Recording . . . . . . . . . .36

SRCH + and Ð Indicators . .27,50

Status Displays, On-Screen . . .29 Status Indicators, Front Panel .50

STEREO Indicator . . . . . . .44,50

Stereo Playback . . . . . . . . . . . . .30

Stereo TV, Recording . . . . . . . .44

STILL Indicator . . . . . . . . . .26,50

Stop Action Pause . . . . . . . . . . .26

STOP Button . . . . . . . . . .18,19,46

STOP Indicator . . . . . . . . . . . . .50

Stopping a Recording . . . . .37,41

TAPE Indicator . . . . . . . . . . . . .50

Tape Playback: HI-FI/

LINEAR/MIX Feature . . . . .30

Tape Speed Indicators . . . . .36,50

Tape, Playing . . . . . . . . . . . . . . .25

Time and Date , Setting . . . .14,15

Time Counter . . . . . . . . . . . .29,50

Time Display . . . . . . . . . . . . . . .50

Time Zone . . . . . . . . . . . . . . . . .14

TIMER FULL Indicator . . . . . . .50

TIMER Indicator . . . . . . . . . . . .50

Timer Programs

Checking . . . . . . . . . . . . . . . .42

Clearing . . . . . . . . . . . . . . . . .42

Editing . . . . . . . . . . . . . . . . . .42

Setting . . . . . . . . . . . . . . . . . .41

Stopping . . . . . . . . . . . . . . . .42

TRACKING Buttons . . . .18,19,27

Tracking, Automatic

and Manual . . . . . . . . . . . . . .27

Trouble Checks . . . . . . . . . .52-54

TV Buttons . . . . . . . . . . . .18,20,22

TV Codes . . . . . . . . . . . . . . . . . .22

TV¥VCR Button . . . . .17-19,48,50

VCR Controls . . . . . . . . . . . .48-50

VCR Function Buttons

on Remote . . . . . . . . . . . .18,19

VCR Indicator . . . . . . . . . . . . . .50

VCR Plus+

Channel Worksheet . . . . . . .39

Checking . . . . . . . . . . . . . . . .42

Clearing . . . . . . . . . . . . . . . . .42

Editing . . . . . . . . . . . . . . . . . .42

PlusCodes . . . . . . . . . . . . . . .40

Setting . . . . . . . . . . . . . . . . . .40

Standarized VCR Plus+

Channel Chart . . . . . . . . . . . .38

Stopping . . . . . . . . . . . . . . . .42

VCR, Cleaning . . . . . . . . . . . . . .51

VCR, Turn On . . . . . . . . . . . . . .11

VCR¥TV Button . . . . .17-19,48,50

VCR1 and VCR2¥DVD

Buttons . . . . . . . . . . . . . . .18,21

VCR1/VCR2 Feature . . . . . . . .21

VCRs, Connecting

for Tape Copying . . . . . . . . . .8

VIDEO1 or VIDEO2

Indicator . . . . . . . . . . . . . .12,43

VOL (Volume)

Up or Down Button . . . .18-21

Warranty, Limited . . . . . . . . . .56

Watch One Channel While

Recording Another . . . . . . .35

X-REC Indicator . . . . . . . . .37,50

Reference

We are committed to your complete satisfaction and viewing enjoyment. Any time you have a question or want information about your ProScan product, call our friendly toll-free number listed below. We’re always ready to help you Monday through Friday, 9 a.m. to 6 p.m. EST.

1-800-PROSCAN

If you would like a copy of this manual in French, please follow the instructions below:

Si un livret d’instructions en français n’est pas inclus avec votre appareil, vous pouvez en obtenir un (indiquer le numéro de modèle, votre nom, et votre adresse) en vous adressant à:

Thomson Electronique Grand Public du Canada Service des données techniques 6540 Tomken Rd Mississauga, Ontario L5T 2E9

If your VCR needs service, please contact your dealer or the nearest Servicenter from the yellow pages. Please do not send any products to the Indianapolis address listed in this manual or on the carton. This will only add delays in service for your product.

10330 North Meridian Street Indianapolis, IN 46290-1024

ProScan PSVR65 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
