Thank you for purchasing a PROSCALE® PROFREIGHT 332™, the heavy duty shipping scale. Please read all operating instructions
carefully before use. This electronic scale is a precision instrument. With normal care and proper treatment, it will provide years of
reliable service.
POWER SUPPLY
The PROFREIGHT 332™was designed to run with AC power (AC adapter included) or optional 3 x AAA batteries. The AC adaptor plugs
into the socket on the rear of the scales weighing indicator. If you want to use batteries, please install them in the battery compartment on the underside of the base of the scale.
Battery Installation
For battery installation, turn over the scale you’ll see the battery compartment on the underside of the base of the scale, lift and open
the battery cover, remove and/or install the batteries. Be sure that the batteries are installed correctly following the polarity
indicators in the battery compartment. Reinstall the battery cover.
OPERATION INSTRUCTIONS
Only operate the scale on a at, level surface that is stable and durable enough to support the scale and the items being placed on
the scale. Place the indicator away from the scale at a position that is easy to read.
Weighing Procedures
Press the [ON/OFF ]to turn ON/OFF the scale . The display will show ”0.00”. The scale is now ready for use. To begin weighing, follow
these steps:
1. Press the [UNIT] key to change the weighing unit between kg, lb:oz, lb and stone.
2. Press the [ZERO/TARE] key to TARE or Zero the scale
3. Press [HOLD] to store a weight value. Press [HOLD] again to clear.
Tare / Zero
Tare can be used for eliminating the weight value of an empty container. Place an empty container on the scale and press
[TARE/ZERO]. Then place the items to be weighed in the container. NOTE: When all weight is removed from the weighing tray, the
tared value of a container will be displayed as a negative number. Press [TARE/ZERO] again to return the scale to zero.
USER MANUAL
CALIBRATION
Calibration may be required when the scale is rst set up for use, or if the scale is moved to a dierent altitude or new location. This
is necessary because the weight of a mass in one location is not necessarily the same in another location. Also, with time and use,
mechanical deviations can occur.
How to calibrate: you must have an accurate 75kg weight in order to calibrate
1. Make sure the scale is turned o. Press and hold [ZERO] (do not release) and turn on the scale, release when the display shows
the A/D value (a series of random numbers).
2. Press [UNIT] , the display will show the “CAL” and then the correct calibration weight “75.00”.
3. Place the correct calibration weight on the platform and wait 5 seconds. The display will show ”PASS” and then return to normal
weighing mode.
4. Calibration is complete.
SCALE SET UP
The PROFREIGHT 332™ allows you adjust the default settings of the scale.
Backlight Setting
1. Make sure the scale is turned o. Press and hold [HOLD] and turn on the scale, release when the display shows “L-ON” or “L-OFF”.
2. Press [UNIT] to toggle the backlight setting ON= backlight is on or OFF= backlight is disabled
3. Press [HOLD] to conrm and enter auto-o setting mode.
Auto-o
4. The display will show “A-ON” or “A-OFF”
5. Press [UNIT] to toggle the auto-o setting ON =enabled (auto 2 mins default) or OFF=disable.
6. Turn the scale OFF and ON to return to normal weighing mode.
Display Messages
EEEEE : Overload
: Battery Low
SPECIFICATIONS
Capacity 150kg x 100g / 332lb x 0.2lb
Unit kg, lb:oz, lb, st
Tare Range Full capacity
Auto O 2 minutes
Op. Temp Optimum 10-40°C (50-104°f)
Power Source 6.0v /100 mA AC Power adaptor / 3 x AAA Batteries
Platform Dimension 315mm x 325mm
Scale Weight 5.0kg
