INSTRUCTION
MANUAL
Part No: O-IP3001
2
THE TAURUS CHARGER
The Taurus is an innovative multi function charger far superior to existing conventional chargers. This unit is especially designed to maximize
charge efficiency using its own unique algorithm. The integral 2 line, 16 character LCD screen displays various information relating to the
operating modes and adjustment parameters, as well as key functions - such as the battery charge state, which shows the percentage of
capacity remaining.
Taurus is very user friendly - even for beginners - thanks to its 2 automatic & 10 intelligent selectable “battery parameter” manual memories. The
manual 10 memories, containing factory pre-set battery parameters, can be re-programmed to store your own standard battery pack parameters
so that you can obtain the same precise results whenever you charge.
Features
• Designed to fast charge/discharge 1~30 cell Nickel Cadmium (NiCD) &
Nickel Metal Hydride (Ni-MH) battery packs, 1-6 cell (2~12 volt) Lead
Acid (Pb) batteries, 1 - 12 cells (3.6~37.0 volt) Lithium Ion/Lithium
Polymer and 1 - 12 cells (3.3~39.6 volt) Li-Fe batteries.
• Uses either 12 volt Lead Acid battery or 10-15 volt DC power supply
input (Not supplied).
• The most outstanding feature of the Taurus is its 10 user definable
intelligent manual battery memories, numbered 0 to 9. These enable
individual cell or pack parameters to be memorised and stored, i.e.
battery type, number of cells, battery capacity, charge current and
discharge current. As a result of this, up to 10 different battery packs can
have their individual charge/discharge requirements set. Additionally there
are 2 automatic settings in the memory area.
NOTE: The Taurus is supplied with the 10 memories already programmed.
Unless these programs exactly match your requirements, it will be
necessary to modify them to suit the battery packs being charged.
• To protect the charger and batteries, the maximum charge and discharge
currents are automatically limited - 180W charge and 80W discharge.
• When discharging battery packs, the discharge cut off voltage level can be
set to between 0.1 and 1.2v per cell for Ni-Cd or Ni-MH batteries, 2.7 to
3.6v per cell for Lithium Ion/Lithium Polymer and 2.7 to 3.3v per cell for
Li-Fe batteries. Lead acid discharge cut off voltage level is fixed at 1.8v
per cell.
• Zero Current Voltage Check prevents incorrect delta peak auto cutoff
caused by high connection resistance or high resistance/old/faulty
batteries.
• Low and over voltage input battery warning function-input voltages
outside the range 9.5 to 15.5 volts causes a warning message “Input
Power” to be shown on the display, together with an audible warning.
• Automatic initial charge stage checks the condition of the battery
being charged. If the battery is not in a condition suitable for charging,
the display shows a warning message “Output Battery Connector Error”
along with an audible warning.
• In the event of the battery being charged becoming disconnected from
the charger the display shows a warning message “Output Battery
Connector Error” along with an audible warning.
• Reverse polarity protection. The display will show “Output Battery
Reverse Polarity” if the battery being charged is connected in reverse
along with an audible warning.
LITHIUM ION/POLYMER BATTERY SAFETY WARNINGS
Vitally important safety information
Ensure that the charger and battery are placed on a non-flammable
surface whilst charging and ideally charge outdoors wherever
possible. NEVER charge a Lithium ION/Polymer battery inside a
vehicle whatever the circumstances.
Ensure that the charger is correctly set for the battery being charged,
checking both voltage and capacity. Be particularly careful if using a
series/parallel battery pack, or if using packs of different
specifications with the same charger.
Never charge at a rate higher than that recommended by the cell
manufacturer, this can be very dangerous.
DO NOT leave Lithium ION/Polymer batteries unattended whilst
they are charging. Monitoring the batteries during charging is very
important.
If the temperature sensor is not being used monitor the temperature
of the battery being charged every few minutes. If the battery
becomes hot to the touch, disconnect it from the charger
immediately and allow to cool. Do not recommence charging until
the battery and charger have been checked for compatibility and the
charger settings have been confirmed as being correct.
In the unlikely event of the Lithium ION/Polymer battery catching fire
DO NOT use water to attempt to put the fire out, instead use sand or a
fire extinguisher designed for electrical fires.
If used correctly, Lithium ION/Polymer battery packs are as safe
as any other type of rechargeable battery pack. However they do
require different charge regimes to the longer established Nickel
Cadmium and Nickel Metal Hydride technologies and do have to
potential of catching fire if severely mistreated.
If Lithium Polymer battery packs are short-circuited or severely
over-charged elemental Lithium may be deposited internally, and
if the battery pouch is damaged this can escape from inside the
battery. If this occurs a fire may be caused, as elemental Lithium
is highly reactive when exposed to water or moisture, producing
flammable hydrogen gas and corrosive fumes. Elemental Lithium is
not produced unless the battery pack is severely mistreated, so in
normal usage there is no likelihood of explosion or fire.
3
4
LITHIUM ION/POLYMER/FE BATTERIES
USAGE:
Lithium battery packs must NEVER be discharged below 3 volts per
cell as this will result in damage to the cells. If the voltage is allowed
to drop below 3 volts per cell the battery voltage may seem to
recover following a charge, but the battery may not then give its full
nominal capacity and a reduction in performance is likely – allowing
the voltage to drop below 3 volts per cell will invalidate all warranty
claims.
Never charge Lithium ION/Polymer battery packs at greater than 4.2
volts per cell, as this will cause irreversible damage to the cells and
will invalidate all warranty claims.
Do not use discharge rates in excess of those specified with the
battery pack as this will result in a significant drop in voltage under
load and will dramatically reduce the number of charge/discharge
cycles the battery pack will give.
Do not attempt to charge Lithium battery packs whilst the input
12 volt battery is being charged, as the voltage supplied to the
Lithium Polymer charger may be too high.
If disposing of Lithium battery packs ensure that the pack is
fully discharged by using a light bulb, electric motor or similar to
completely discharge the pack.
DO NOT allow any Lithium battery pack to short-circuit as this is likely
to result in a minor explosion and consequent fire.
BEFORE charging any Lithium battery packs they should be closely
inspected for any damage, such as punctures in the sleeving or if
the battery has swollen or expanded in size. If any such damage is
detected DO NOT charge, even if the battery otherwise appears to be
brand new.
Before commencing charging always double check the settings on
the charger to ensure it is set correctly for the battery pack to be
charged. Using the wrong settings is likely to result in damage to the
battery pack being charged and could result in the battery
catching fire.
Parameter NiCd / NiMH Li-Ion / Polymer Pb Li-Fe
Battery cells 1 ~ 30 cells 1 ~ 12 cells 2, 4, 6, 8, 10, 12V pack 1~12 cells
Capacity 100 ~ 20000mAh 100 ~ 20000mAh 0.50 ~ 50.00 Ah 100 ~ 20000mAh
Charge current 0.1 ~ 10.0A 0.1 ~ 10.0A (Capacity 2C limited) 0.1 ~ 10.0A 0.1 ~ 10.0A
Discharge current 0.1 ~ 10.0A 0.1 ~ 10.0A 0.1 ~ 10.0A 0.1 ~ 10.0A
Discharge voltage 0.1 ~ 1.2V/cell 2.7 ~ 3.6V/cell 1.8V/pack FIXED 2.7 ~ 3.3V/cell
Cycle direction CHG DCH, DCH CHG x x x
Temperature cut-off 10 ~ 55ºC 1ºC/step 10 ~ 55ºC 1ºC/step 10 ~ 55ºC 1ºC/step 10 ~ 55ºC 1ºC/step
Trickle charge current 0 ~ 500mA, Auto x x x
Delay between chg/dch 1 ~ 30 min x x x
Cycling 1~5 TIME x x x
TAURUS INSTRUCTIONS
1. Button structure
* Requires temperature sensor – O-IPTS – TEMPERATURE SENSOR WITH LEAD
Connection to Power Supply
The Taurus charger is designed to operate using either a 12 volt Lead Acid (Pb) battery or a suitable 10-15 volt power supply.
Connect the red wire with the large crocodile clip/4mm connectors from the charger to the + terminal of the power source, the black wire to the –
terminal, ensuring the correct polarity of the connections.
Connect the battery to be charged to the Taurus charger using appropriate charge leads - again being particularly careful to
ensure correct polarity.
5
NiCd 10C 3000mAh
[NiCd] BATTERY
CHARGE START
DOWN
M0] MEMORY SELECT
NiCd 10C 3000mAh
ENTER
[NiCd] BATTERY
DISCHARGE START
DOWN
CHARGE MODE
C:5.0A d15V/C
ENTER
UP
[NiCd] BATTERY
CYCLE START
2. Main Menu Flow Chart
SET
SET
DOWN
DISCHARGE MODE
D:2.0A 0.8V/CELL
ENTER
UP
SET
DOWN
CYCLE MODE
CHG DCH TIME 1
ENTER
UP
SET
DOWN
USER CONDITION
SETUP
UP
SET
DATA VIEW
BATTERY & CHARGER
ENTER
UP
TAURUS
DOWN
M0] MEMORY SELECT
NiCd 10C 3000mAh
UP/DOWN
DOWN
A2] MEMORY SELECT
NiMH AUTOMATIC
UP
DOWN
A1] MEMORY SELECT
NiCd AUTOMATIC
UP
M9] MEMORY SELECT
NiCd 10C 3000mAh
UP/DOWN
UP
NiCd 10C 3000mAh
NiCd 10C 3000mAh
C: 5.)A D: 3.0A
7. User data setup menu
6. Cycle data setup menu
8. Data View display
5. Discharge data setup menu
4. Charge data setup menu
3. Battery data setup menu
Select memory locations M0~M9,A1,
and A2 with UP/DOWN button
6
1] MEMORY SELECT
NiCd 6C 3000mAh
SET
M1] BATTERY SETUP
NiCd 6C 3000mAh
SET
M1] BATTERY SETUP
NiCd 6C 3000mAh
SET
1] MEMORY SELECT
NiCd 6CL 3000
DOWN UP/DOWNUP/DOWN
M1] BATTERY SETUP
NiCd 6C 3000mAh
SET
M1] BATTERY SETUP
NiMH 6C 3000mAh
SET
M1] BATTERY SETUP
NiMH 6C 3000mAh
DOWN
UP/DOWNUP/DOWN
M1] BATTERY SETUP
NiMH 6C 3000mAh
SET
UP
M1] BATTERY SETUP
LiLo 7.2V 3000mAh
SET
M1] BATTERY SETUP
LiLo 7.2V 3000mAh
M1] BATTERY SETUP
LiLo 7.2V 3000mAh
SET
UP/DOWNUP/DOWN
DOWN
UP
M1] BATTERY SETUP
LiPo 7.4V 3000mAh
SET
M1] BATTERY SETUP
LiPo 7.4V 3000mAh
UP/DOWNUP/DOWN
M1] BATTERY SETUP
LiPo 7.4V 3000mAh
SET
UP
CELL CAPACITY CHARGE DISCHARGE DELTA DCH VOLT CYCLE DIR CYCLE TIME
NiCd 6CELL 3000mAh 3.0A 3.0A 5mV 0.8V/CELL CHG DCH 1TIME
NiMH 6CELL 3000mAh 3.0A 3.0A 5mV 0.8V/CELL CHG DCH 1TIME
LiPo 7.4V 3000mAh 3.0A 3.0A X 3.0V/CELL X X
Li-Ion 7.4V 3000mAh 3.0A 3.0A X 3.0V/CELL X X
Pb 12V 15.00Ah 3.0A 3.0A X X X X
Li-Fe 6.6V 3000mAh 3.0A 3.0A X 3.0V/CELL X X
Battery type-change Cell number change Battery capacity-change
3. Battery Data Setup Menu
In this mode, you can set each battery type / cell number / battery capacity in a memory. Adjust the desired parameters with UP & DOWN buttons.
Factory default parameters of each battery type in memories.
7
DOWN
Li-lon/Po & Pb/LiFe battery Set the charge capacity. Note: In case of charging Lithium Ion/Polymer batteries, it is NOT possible to set charge
rates over 2C for the selected battery capacity
CHARGE MODE
C5.0A d15mV
4. Charge Data Setup Menu
SET
NiCd & NiMH battery Set charge capacity and Delta peak sensitivity.
UP/DOWN
CHARGE MODE
C5.0A d15mV
SET
UP/DOWN
CHARGE MODE
C:5.0A d:15mV
SET
CHARGE MODE
C5.0A
SET
UP/DOWN
CHARGE MODE
C5.0A
SET
8
M1] BATTERY SETUP
Pb 12V 15.00Ah
SET
M1] BATTERY SETUP
Pb 12V 15.00Ah
UP/DOWNUP/DOWN
M1] BATTERY SETUP
Pb 12V 15.00Ah
SET
UP
DOWN
M1] BATTERY SETUP
LiFe 6.6V 3000Ah
SET
M1] BATTERY SETUP
LiFe 6.6V 3000Ah
UP/DOWNUP/DOWN
M1] BATTERY SETUP
LiFe 6.6V 3000Ah
SET
UP
6. Cycle Data Setup Menu
NiCd & NiMH battery only Set cycle direction and cycle times.
CYCLE MODE
CHG DCH 1 TIME
SET
UP/DOWN
CYCLE MODE
CHG DCH 1 TIME
SET
UP/DOWN
CYCLE MODE
CHG DCH 1 TIME
SET
DISCHARGE MODE
D2.0A 0.8V/CELL
SET
UP/DOWN
DISCHARGE MODE
D2.0A 0.8V/CELL
SET
UP/DOWN
DISCHARGE MODE
D2.0A 0.8V/CELL
SET
DISCHARGE MODE
D2.0A 3.0V/CELL
SET
UP/DOWN
DISCHARGE MODE
D2.0A 3.0V/CELL
SET
UP/DOWN
DISCHARGE MODE
D2.0A 3.0V/CELL
SET
DISCHARGE MODE
D:2.0A
SET
UP/DOWN
DISCHARGE MODE
D:2.0A
SET
Li-lon/LiPo/LiFe battery Set discharge rates and discharge cut-off voltages.
Pb battery Set discharge rates (The Discharge cut-off voltage is xed at 1.8V per cell)
5. Discharge data Setup Menu
NiCd & NiMH battery Set discharge rates and discharge cut-off voltages.
9
8. Data View Display
All data of the cycle 1 to 5 times can be referred to with UP & DOWN buttons. Note: LCB means Lithium Cell Balancer (EQ-6+).
7=0.00 0.00 0.00
A=0.00 0.00 0.00
SET
1=0.00 0.00 0.00
4=0.00 0.00 0.00
SET
ENTER
LCB = VOLTAGE [00]
0.000Vavg 0.000V
SET
ENTER
CYCLE DATA [1]
C=0000 / D=0000mAh
ENTER
1. Input voltage 1. Setting temperature 1. Charge peak voltage 1. Discharge average voltage
2. Output voltage 2. Peak temperature 2. Charge time 2. Discharge time
3. Now temperature 3. Charge capacity 3. Discharge capacity
INPUT = 00.000V
OUTPUT = 00.000V
ENTER
SET
SET = 00 / PEAK=00.0
TEMP= 00.0°C
ENTER
SET
CHG PEAK = 00.000V
000m00s 00000mAh
ENTER
SET
DCH AVG = 00.000V
000m00s 00000mAh
ENTER
SET
UP/DOWN
SET
DATA VIEW
BATTERY & CHARGER
ENTER
UP/DOWN
7. User Data Setup Menu Each user setup data is separately stored in each memory.
USER
CONDITION SETUP
UP/DOWN
TEMPERATURE
CUT-OFF: 00°C
ENTER
SET
UP/DOWN
TRICKLE CHARGE
CURRENT: 000mA
ENTER
SET
UP/DOWN
DELAY BETWEEN
CHG/DCHG: 00min
ENTER
SET
UP/DOWN
BUZZER VOLUME
OFF
ENTER
SET
ENTER
UP/DOWN
10
11
9. Operating Display
If the ENTER button is pressed at Charge, Discharge, or Cycle displays, the selected mode is activated.
It is possible to change charge rates with the UP & DOWN button during operation, however, the charge rates can not be adjusted in Auto mode,
or during CV (Constant Voltage) charge.
If the ENTER button is pressed again during operation, the operation will stop and revert to the main display.
While the charger is being operated, the DATA VIEW screens can be shown by pressing the SETUP button.
NiCd, NiMH, Pb CHARGE OPERATING
SET
NiCd 000:00 00000
00’ 0.00A 00.00V
CHARGE MODE
C: 5.0A d: 15mV/C
ENTER
CHARGE MODE
C: 5.0A d: 15mV/C
CHG 000:00 00000
00’ 0.00A 00.00V
ENTER
2SEC
UP/DOWN
[NiCd] BATTERY
CHARGE START...
DATA VIEW
BATTERY&CHARGER
CHG Batt Type
Flashing alternately
TIME CAPACITY
STOP
“N/A” should be displayed, if a
temp sensor is not connected
to the charger
The Charge current can be
changed with UP/DOWN
buttons during charging
SET
LiPo 000:00 00%
00’ 0.00A 00.00V
CHARGE MODE
C: 5.0A
ENTER
CHARGE MODE
C: 5.0A
CHG 000:00 00000
00’ 0.00A 00.00V
ENTER
2SEC
UP/DOWN
[LiPo] BATTERY
CHARGE START...
DATA VIEW BATTERY
& CHARGER
CHG Batt Type
Flashing
TIME Charged amount by Percentage Batt Type Flashing (LiPo, Li-lon, LiFe Only)
STOP
“N/A” should be displayed, if a
temp sensor is not connected
to the charger
The Charge current can be
changed with UP/DOWN
buttons during charging
**
BALANCER
**
**
ADVISED
**
Li-Po, Li-lon, LiFe CHARGE OPERATION
This message will appear if a Lithium cell balancer is NOT
connected to the charger in LiPo, Li-lon and LiFe mode.
Note : In this Lithium mode, the charged amount can be shown as a percentage. So, you can stop charging and disconnect the Lithium battery
pack if this percentage is indicated 80% ~ 90% as you should be able to use this 80%~90% charged battery pack already if you want.
NiCd, NiMH, Pb DISCHARGE OPERATION
SET
NiCd 000:00 00000
00’ 0.00A 00.00V
DISCHARGE MODE
C:2.0A
ENTER
DISCHARGE MODE
C: 2.0A
DCH 000:00 00000
00’ 0.00A 00.00V
ENTER
2SEC
UP/DOWN
[NiCd] BATTERY
DISCHARGE START
DATA VIEW
BATTERY & CHARGER
DCH Batt Type
Flashing alternately
TIME CAPACITY
STOP
“N/A” should be displayed, if
a temp sensor is not
connected to the charger
The Discharge current can be
changed with UP/DOWN
buttons during discharging
SET
LiPo 000:00 00000
00’ 0.00A 00.00V
DISCHARGE MODE
C: 2.0A 3.0V/C
ENTER
DISCHARGE MODE
C: 2.0A 3.0V/C
DCH 000:00 00000
00’ 0.00A 00.00V
ENTER
2SEC
UP/DOWN
[LiPo] BATTERY
DISCHARGE START
DATA VIEW
BATTERY & CHARGER
DCH Batt Type
Flashing alternately
TIME
STOP
“N/A” should be displayed,
if a temp sensor is not
connected to the charger
The Discharge current can
be changed with UP/DOWN
buttons during discharging
**
BALANCER
**
**
ADVISED
**
Li-Po, Li-lon and LiFe DISCHARGE OPERATION
This message will appear if a Lithium cell balancer is NOT
connected to the charger in LiPo, Li-lon and LiFe mode.
CAPACITY
12
13
UP/DOWN
C1D 000:00 00000
00’ 0.00A 00.00V
CYCLE MODE
CHG DCH TIME:
ENTER
C1D 000:00 00000
00’ 0.00A 00.00V
[NiCd] BATTERY
CYCLE START...
C1D 000:01 00001
26’ 6.00A 12.37V
The Charge current can be
changed with UP/DOWN
buttons during charging
CYCLE DISCHARGE
C1D 019:59 01520
26’ DELAY 12.37V
C1D 048:23 01520
26’ 3.00A 12.37V
CYCLE DELAYCYCLE CHARGE
CYCLE OPERATING
NC 000:01 00000
24’ 0.00A 00.00V
CHARGE MODE
NiCd AUTOMATIC
ENTER
CHG 000:01 00000
24’ auto 00.00V
[NiCd] BATTERY
CHARGE START...
NC 000:01 00000
24’ 0.00A 00.00V
DISCHARGE MODE
NiCd AUTOMATIC
ENTER
DCH 000:01 00000
24’ auto 00.00V
[NiCd] BATTERY
DISCHARGE START...
D1C 000:01 00000
24’ 0.00A 00.00V
CYCLE MODE
NiCd AUTOMATIC
ENTER
D1C 000:01 00000
24’ auto 00.00V
[NiCd] BATTERY
CYCLE START...
AUTOMATIC OPERATING
While Auto mode is being activated, “auto” current is alternately displayed.
AUTO cycle operation is xed as discharge charge once.
Delay time is xed as 10 minutes in Auto mode.
CYCLE OPERATING MOD
CHARGE “C” FLASH
DELAY “1” FLASH
DISCHARGE “D” FLASH
CYCLE OPERATING MODE
C1D CHARGE, CYCLE TIME, DISCHARGE
D1C DISCHARGE, CYCLE TIME, CHARGE
ENTER
TRK 120:35 03215
38’ FINISH 9.12V
CHG 120:35 03215
38’ 5.00A 9.12V
CHARGE MODE
C: 5.0Ad: 15mV/C
CHG 120:35 03215
38’ 0.10A 9.12V
END OPERATION
If the ENTER button is pressed for 2 seconds in the END display, it reverts to the main display.
(If the ENTER button is briey pressed or the battery pack is disconnected, it won’t revert to the main display.)
Operating data can be referred to the above “8. Data View Display”
During trickle charging, the parameters of “CHG, TRK, FINISH, trickle current” ash.
Trickle charge
If trickle currents are set to 100~500mAh at “USER CONDITION SETUP”, the trickle charge proceeds with the selected trickle currents.
The trickle charge proceeds with 1/20 currents of the selected capacity in Auto mode, however, there is NO trickle charge in cases of lower
than 100mAh.
Even if the trickle currents are set, if a charge process is stopped due to the optional temperature or safety-timer function, the trickle charge
won’t work at all.
ENTER
DCH 38.24 02400
36’ FINISH 4.80V
DCH 38:24 02400
36’ 2.00A 4.80V
DISCHARGE MODE
C: 2.0A: 0.8V/CELL
ENTER
C1D 142:34 02860
37’ FINISH 4.82V
C1D 042:34 02860
37’ 2.00A 4.82V
CYCLE MODE
CHC DCH TIME:1
2 SEC
2 SEC
2 SEC
14
15
INPUT VOLTAGE
ERROR 0.00Vi
10. Message Display
OUTPUT BATTERY
CONNECT ERROR
OUTPUT BATTERY
REVERSE POLARITY
OUTPUT BATTERY
OPEN CIRCUIT
OUTPUT CIRCUIT
PROBLEM
PAUSE...
CHARGER TOO HOT
OUTPUT VOLTAGE
TOO HIGH 0.00V
OUTPUT VOLTAGE
TOO LOW 0.00V
TEMPERATURE
SENSOR ERROR
BATT. TEMPERATURE
TOO HIGH 00.0°C
INTERNAL TEMP
SENSOR ERROR
When the input voltages exceed the range of 11~15V.
When the charger starts without connecting to the battery pack.
When the battery pack is disconnected during operation.
When the battery terminals short-circuit for a while.
When the temperature of the charger rises over 115°C, the charger stops temporarily until the temperature drops lower than 70°C.
When the output voltages are too high.
When the output voltages are too low.
When the thermal probe is incorrectly connected, or the probe is defective.
When the temperature of the battery pack is higher than the selected temperature, this message is shown. The previous operation should
resume when the temperature of the battery pack becomes 2°C lower than the selected temp.
When the temperature of the charger rises over 125°C.
When the charger starts without connecting the battery pack in reverse.
DATA COMMUNICATION ERROR
When the internal interface of the charger is defective.
Ripmax Ltd, 241 Green Street, Enfield, EN3 7SJ.
United Kingdom.
www.ripmax.com
Please retain this information for future reference
Loading...
