USER GUIDE
EMERGENCY CHAIR PS-183
Review 02/19
USER MANUAL // EMERGENCY CHAIR PS-183
Review 02/19
3
INDEX
01 INTRODUCTION
01.1 Using this manual 05
01.2 Characteristics 06
01.2 Technical data sheet 06
02 INSTALATION
02.1 Transporting and unpacking 07
03 OPERATING
03.1 General elements of evacuation chair PS-183 08
03.2 Chair’s use 09
03.3. Notes 09
04 GENERAL MAINTENANCE 11
05 LEGAL NOTICES 12
06 PRODUCT WARRANTY 13
USER MANUAL // EMERGENCY CHAIR PS-183
Review 02/19
5
01.1 Using this manual
This manual provides using and maintenance instructions of the product, as well as the way of xing minor
faults that could appear.
It is recommended before the operation of the product
to read carefully this manual in order to avoid damages
caused by a misuse.
Do not lose this document, it should be accessible to
any doubt that could appear by medical personnel.
Remember that a good use and maintenance are necessary for the proper operation of the product.
Each product incorporates an identication sticker with
the serial number and the model. Keep these numbers
so that they can be indicated to the dealer if necessary.
01 INTRODUCTION
USER MANUAL // EMERGENCY CHAIR PS-183
Review 02/19
6
01.2 Characteristics
1. Use for emergency situations in elderly people, public safety, hospitals,
hotels, etc.
2. It can be folded. Easy storage
3. You can descend stairs continuously thanks to the tracks of the chair.
4. Four wear resistant wheels.
5. It has pull through, 2 telescoping long handles and 2 back handles built
in to lift patients & carry them through narrow passages.
6. Telescoping backrest, foldable and easy for storage.
01.3 Technical data sheet
MEASURES AND FEATURES //
LENGHT 110 cm
WIDTH 50 cm
HEIGHT 77 cm
WEIGHT 22 Kg
MAX. LOAD 160 Kg
FOLDED SIZE 110x50x30 cm
EXTENSIBLE HANDLE SIZE 145x120x105 cm
01 INTRODUCTION
USER MANUAL // EMERGENCY CHAIR PS-183
Review 02/19
7
02 INSTALATION
02.1 Transport and unpacking
First remove the packaging carefully so as not to damage the outside of the stretcher.
1. Transport
· Always x the load, if it is necessary stack. you should
follow the diagram shown.
· Transport the level load and following all the precepts
and regulations regarding the transport of loads.
2. Unpacking
· Put the box on a at and stable surface, open the seal
carefully not to damage inside.
· Remove the product from the inside of the case as
shown in the chart below.
Each product has been thoroughly inspected when
leaving the factory. To ensure that the transport has not
deteriorated it, please inspect the exterior and interior
carefully, and in the event of any damage, contact the
installer immediately.
PACKING UNIT
RESPECT THE PACKAGING TRANSPORT POSITION
UNPACKING THE PRODUCT
ALWAYS USE FLAT SURFACE
USER MANUAL // EMERGENCY CHAIR PS-183
Review 02/19
8
03.1 General elements of CHAIR PS-183
1. Telescoping backrest
2. Transport handles
3. Footrest
4. Completely foldable
5. Chair with tracks anti-slide
03 OPERATING
4
5
1
2
3
USER MANUAL // EMERGENCY CHAIR PS-183
Review 02/19
9
03.2 Chair’s use
1. After the patient sits down, secure the seat belts.
2. The head can be adjusted according to the height of the patient.
3. Track system: Open the chair to extend the track and the track frame
will be blocked.
4. Go down the stairs:
Open the chair: push the chair to the stairs and make the chair fall back, hold
the chair, make sure the chair goes in a straight line.
03.3 Notes
1. The operator must read the manual rst, operate the product correctly
and examine it before using it, or the company will not be responsible for the
risk of accidents.
2. We suggest that the man or woman who drives the chair be t.
3. When transportation is carried out, secure the safety belts to prevent
damage.
4. If you notice any damage to the chair, you should replace it immedia-
tely.
5. Check the seat belts frequently, replace the damaged parts at the
same time.
03 OPERATING
USER MANUAL // EMERGENCY CHAIR PS-183
Review 02/19
11
04 GENERAL MAINTENANCE
CLEANING
Keeping the equipment clean is essential to ensure
good use and durability of the assembly. It is necessary
to perform a thorough cleaning periodically, especially
in areas exposed to dirt that can suer damage such as
gears, connectors, buttons, etc. Do not use high pressure washers, they may damage the electrical elements.
CONTROLS AND SELECTORS
Due to the intense and continuous use of the movable elements, as the controls and selectors, periodically
check the proper functioning of the same. There may
be faults in the micro-breakers and wiring, check the
xings and electrical or mechanical connections that
may exist.
OIL
In general, any moving part must be oiled. Our products come from the factory completely oiled and lubricated, however, it is possible that with the time and
use of the product the elements are decreased, either
by loss of lubrication or by dirt. Clean and grease periodically aected areas, according to manufacturer’s
specications.
Check for loose, missing, or worn parts. Periodically
inspect all moving parts to make sure components are
tight.
Due to its dry slip system, do not grease the platform
guide.
ATTENTION: Do not lubricate the rail and / or stretcher
when connected to the mains.
WEARING AREAS
Inspecting regularly to see if there is wear on the system components is a preventive measure that can reduce breakdowns. Check for possible lubricant leaks,
grooves or bearings in poor condition.
MECHANICAL FASTENING ELEMENTS
In general, we call mechanical fastening elements for
the components that are used to x the whole of the
product, mainly fasteners and derivatives.
In some conditions of use, due to vibrations and impacts, certain elements can lose their tightening torque or xing properties.
Check periodically that there are no loose elements,
especially in moving parts of the assembly. Always observe the recommended tightening torques.
REPLACEMENT OF COMPONENTS
This instruction manual does not include procedures
for all parts. Typically, qualied service personnel replace wires, switches and certain mechanical parts without the need for step-by-step procedures.
Qualied service personnel should contact our sales
department for information on ordering parts and installing them.
MAKE SURE THESE ZONES ARE FREE OF WATER AND MOISTURE. PLEASE SPECIFY CAREFULLY WITHOUT WETING THEM DURING THE WASHING OF THE ASSEMBLY.
USER MANUAL // EMERGENCY CHAIR PS-183
Review 02/19
12
05 LEGAL NOTICES
This document may contain technical inaccuracies or
typographical errors.
Periodic changes are made to the information contained herein; These changes will be incorporated in new
editions of the publication.
Promeba, S.L. Reserves the right to make any changes
or improvements to the products described in this publication, if deemed appropriate.
Promeba, S.L. May have patents or pending patent
applications addressing issues described in this document. The possession of this document does not confer
any license on said patents.
The information contained in this document does not
aect or change the specications or warranties of the
product Promeba, S.L.
No part of this document shall be construed as an express or implied license or indemnication under the
intellectual property rights of Promeba, S.L. Or third
parties.
All information contained in this document has been
obtained in specic environments and is presented as
an illustration. Results obtained in other operating environments may vary.
Promeba, S.L. may use or distribute the information
provided by the customer in a way that creates timely,
without incurring any obligation with the client.
USER MANUAL // EMERGENCY CHAIR PS-183
Review 02/19
13
06 PRODUCT WARRANTY
Promeba, S.L. ensures that your products have passed
satisfactorily all the established quality controls, both
functional and material. The duration of the warranty is
2 years from the date of purchase of the product.
This warranty is valid only when it is presented with
the original invoice or proof of purchase (indicating the
date of purchase, model and dealer name) together
with the defective product during the period covered
by the warranty. Promeba, S.L. reserves the right not
to oer the free warranty service if the indicated documents are not presented or if the information they
contain is incomplete or illegible.
1. This warranty does not apply if the model name or serial number of the product has been altered, deleted, disappeared or is unreadable.
2. This warranty does not cover transport costs or the risks associated with transporting your product to and from
Promeba, S.L.
3. This warranty does not cover any of the following:
a) Periodic maintenance and repair or replacement of
parts derived from normal wear and tear.
b) Periodic maintenance and repair or replacement of
consumables (components that are expected to require
periodic replacement during the life of the product, such
as non-rechargeable batteries, bulbs, etc.). Parts from nor-
mal wear and tear....
c) Damage or defects arising from improper use, operation or treatment of the product and not from normal use
of the product.
d) Damage arising from:
i. Misuse, including:
- Treatment resulting in damage or changes in the physical, surface or appearance of the product.
- Installation, use or storage of the product in a manner
that does not comply with the instructions described
by Promeba, S.L.
- Maintenance of the product in a manner that does not
comply with the instructions of Promeba, S.L. for proper maintenance.
- Installation or use of the product in a manner that
does not respect the technical or safety standards of
the country where it is used or installed.
ii. Use of components not provided with the product or
improper installation of accessory parts not previously
tested.
iii. States or defects of the system in which the product
is used or incorporated with the exception of other products Promeba, S.L. designed for use with the product.
iv. Use of the product with accessories, peripheral units
and other products of a type, condition or standards
not established by Promeba, S.L.
v. The manufacturer or distributor will be solely responsible for deciding the shipment of the parts for repair,
or replacement of the product in its entirety. In no case
will workers be sent for such repair or replacement of
the product.
Except in the cases mentioned above, Promeba, S.L.
shall not give any warranties with respect to the product, performance, accuracy, reliability or adaptability
to a purpose of the logical or other equipment. If this
exception is not lawful or contemplated by the current
law, Promeba, S.L. limit or exclude its warranties only
to the extent permitted by law.
The only obligation on the part of Promeba, S.L. in
connection with this warranty is to repair or replace
the parts subject to the terms and conditions of this
warranty.
Promeba, S.L. is not responsible for the loss or damage
of products, this warranty or others, including economic loss or non-evaluable damages; The price paid for
the product; Loss of prots, income, information, usufruct or use of the product or associated products or
indirect, accidental or critical loss or damage.
This clause refers to whether the loss or damage is due
to deterioration or inoperability of the associated product due to defects or unavailability of Promeba, S.L.,
which has caused a downtime, loss of user time or a
business interruption.
In cases where the law prohibits or limits these exclusions of liability, Promeba, S.L. exclude or limit its liability only to the extent permitted by applicable law.
For example, there are countries that prohibit the exclusion or limitation of damages caused by negligence, reckless negligence, willful misconduct, fraud, and
similar acts. The responsibility of Promeba, S.L. in this
warranty will not exceed, in any case, the price paid for
the product, but if the current law allows only limitations of greater responsibilities, these will apply.
ER-0687/1998
PROMEBA, S.L.
Ctra C-16 Km 59.5 · 08650 Sallent (Barcelona) · SPAIN
T. 93 837 12 00 · Fax 93 820 61 08
promeba@promeba.com · www.promeba.com
All rights reserved. Variations can be done whitout notice.
Promeba, S.L. is to be considered not responsible for damages caused by the lack or the wrongness
of the information here mentioned.
