HD
RANGER
2 3/
CONNECTION FOR FIBRE OPTICAL TEST
OPTICAL OPTION + 5 GHz RF AUXILIARY INPUT
QUICK REFERENCE GUIDE
1
Visit us at www.TestEquipmentDepot.com
99 Washington Street
Melrose, MA 02176
Phone 781-665-1400
Toll Free 1-800-517-8431
FC-APC connector (optical signal input)
1
1
FIBRE OPTICAL TEST SELECTION
Tools
LTE Ingress Test
Attenuation Test
Fibre Optic Test
Merogram
FIBRE OPTICAL TEST PERFORMANCE
(Selective measurement of optical power on three bands: 1310/1490/1550 nm)
DEFAULT
04/03/2013 14:33
0
-10
-20
-30
Wavelength:
Reference:
Current:
Attenuation:
Exit
8
Fibre Optic Test
FAIL PASS PASS
-9.8
-9.8
0.0
1550
-10.7
-12.7
-2.0
1310 1490
-9.7
-14.7
-5.0
Set Reference
9
CH
Advanced
nm
dBm
dBm
dB
5h15
Max.
Status message depending on the level of attenuation.
1
1
Power level of the signal.
2
3
Wavelength of the signal (nm).
Power level of the reference signal, which is used to calibrate
4
Th.
2
and calculate the attenuation level (dBm).
5
Power level of the test signal at the user's access point (dBm).
Attenuation level (dB); Attenuation = Current - Reference.
6
3
"Advanced" key to access these options: Threshold attenuation
7
4
(see Th. dashed line) and Max. attenuation (see Max. dashed line).
5
"Exit" button to exit the screen.
8
6
"Set Reference" key to calibrate the reference signal..
9
7
HD
RANGER
2 3/
OPTICAL OPTION + 5 GHz RF AUXILIARY INPUT
QUICK REFERENCE GUIDE
CONNECTION FOR SELECTIVE OPTICAL TO RF SIGNAL CONVERTER
1
1
FC-APC connector (optical signal input)
2
Connection to measure the RF signal converted from optical
BNC connector (RF output signal converted from the optical input signal (1))
Universal connector for F/F or F/BNC adapter (RF input signal)
2
CONFIGURATION OF SELECTIVE OPTICAL TO RF SIGNAL CONVERTER
(1) Optical Fibre Input Selection
Terrestrial Settings
Signal Source:
Band:
Decoder TS Input:
RF Demodulator
Terrestrial Settings
Signal Source:
Band:
Decoder TS Input:
RF Demodulator
Terrestrial Settings
Signal Source:
Band:
Decoder TS Input:
RF Demodulator
RF
Terrestrial
RF
Terrestrial
Fiber Optic
Terrestrial
RF
IP-TV
Fiber Optic
5GHz
Input
(2) Optical Module Enable and Wavelength* Selection
Fiber Optic Settings
Supply Output:
Supply Voltage:
Optical Module...
Optical Module
Module:
Disabled
Disabled
Enabled
Optical Module
Module:
Wavelength:
Attenuator:
Enabled
1310 nm
1310 nm
On
1490 nm
1550 nm
Disabled
External
Disabled
Enable the optical module to
configure additional
parameters.
1310 nm
1490 nm
1550 nm
-0.0 dBm
-2.0 dBm
-5.0 dBm
* Selection of wavelength to be converted to RF
