USER’S MANUAL
99 Washington Street
Melrose, MA 02176
800.517.8431
TestEquipmentDepot.com
SATELLITE RECEIVER & CABLE TESTER
RP-050
- 0 MI1040 -
Page 2
SAFETY NOTES
Read the instruction manual before using the equipment, mainly
"SAFETY RULES" paragraph.
The symbol
MANUAL". In this manual may also appear as a Caution or
Warning symbol.
Warning and Caution statements may appear in this manual to
avoid injury hazard or damage to this product or other property.
on the equipment means "SEE USER’S
Page 3
TABLE OF CONTENTS
1 GENERAL INFORMATION ................................................... 1
1.1 Description ......................................................................... 1
1.2 Specifications .....................................................................1
2 SAFETY RULES .................................................................... 3
3 OPERATING INSTRUCTION ................................................5
3.1 Description of the controls and elements........................... 5
3.2 Operating Instructions ........................................................ 6
3.2.1 Using combined with a TV level meter........................... 7
3.2.2 SAT-receiver test............................................................9
4 MAINTENANCE................................................................... 11
4.1 Cleaning recommendations ............................................. 11
English
09/03 RP-050
Page 4
SATELLITE RECEIVER & CABLE TESTER
RP-050
1 GENERAL INFORMATION
1.1 Description
RP-050
The
generator with which satellite receivers and coaxial cables of
buildings can be checked.
1.2 Specifications
RECEIVER TEST MODE
Frequency
Video carriers (FM)
IF L Band
UHF Band
Accuracy
Level Low mode
High mode
Audio subcarriers
Modulation (FM)
Audio
Video
Voltage and 22 kHz
indication
09/03 - 1 - RP-050
is a handy, versatile and easy to use signal
1050 MHz, 1575 MHz and
2100 MHz
525 MHz
1 %
90 dBµV ± 4 dB
105 dBµV ± 4 dB
7.02 MHz ± 0.2 MHz
Approx. 1 kHz
2 black, 1 white bars
13 V green LED illuminated
13 V + 22 kHz green LED flashes
18 V red LED illuminated
18 V + 22 kHz red LED flashes
English
Page 5
Connector
Power supply
F female (input/output)
13 - 18 V / 120 mA (by means of
RF cable or external DC supply)
Equipment consumption
3 W
Environmental operating conditions
: up to 2000 m
Altitude
Temperature range
Maximum relative humidity
: from 5° C to 40° C
: 80% (up to 31° C), decreasing
lineally up to 50% at 40° C.
Mechanical features
Dimensions
Weight
77 mm W x 85 mm H x 28 mm D
150 g
INCLUDED ACCESSORIES
AL-013
AD-060
External DC adapter
F/m - BNC/m adapter
OPTIONAL ACCESSORIES
CC-030
AD-058
AL-032
F/m - F/m coaxial cable
F/m - F/f quick adapter
230 V UK mains adapter
09/03 - 2 - RP-050
Page 6
2 SAFETY RULES
*
Use this equipment
systems with their comm on at ground potential
*
This equipment can be used in
installations
*
Use this instrument under the
conditions
*
Follow the
Maintenance Paragraph.
and
.
cleaning instructions
connected only to devices or
Pollution Degree 2 environments
specified environmental
described in the
.
CATEGORY I
.
English
09/03 - 3 - RP-050
Page 7
3 OPERATING INSTRUCTION
3.1 Description of the controls and elements
Figure 1.-
[1] IF OUTPUT
Frequency pilots output. On receiver Test mode this jack
will be connected with the IF input jack (SAT-antenna
input) of the SAT-Receiver.
[2] OFF - LOW - HIGH
With this switch, different attenuation modes of the
can be selected:
OFF Power off
LOW Output level 90 dBµV
HIGH Output level 105 dBµV
09/03 - 5 - RP-050
Front view
Output connector
Power / attenuation mode switch
RP-050
English
Page 8
[3] H ( 18 V )
Red LED for 18 V
This LED will be illuminated, if on the coaxial line is
present a 18 V supply voltage. If in addition, a 22 kHz
switching signal is superimposed on the 18 V supply
voltage, this LED will flash.
[4] V ( 13 V )
Green LED for 13 V
This LED will be illuminated, if on the coaxial line is
present a 13 V supply voltage. If in addition, a 22 kHz
switching signal is superimposed on the 13 V supply
voltage, this LED will flash.
[5] DC INPUT
DC power supply adapter jack
Jack to connect external DC power supply (13-18 V / 120
mA).
3.2 Operating Instructions
3.2.1 Using combined with a TV level meter
The
PROMAX
Satellite band like
Premium
1
MC-377+ including the OP-377-63 option.
09/03 - 6 - RP-050
has been specially designed for using joint to
RP-050
’s TV level meters, which are able to tune the
or
MC-377+
PROLINK-4/4C
1
.
Premium
,
PROLINK-3/3C
Page 9
Figure 2.-
1.- Separate the installation section that is desired to check
from the general panel or from one of the jack outlets of
the TV signal distribution network.
2.- Connect the
ends from section under test, and use the TV level meter
(RF input) on the other.
3.- Select on
amplifiers in the line, an output level (LOW) or (HIGH) by
means of the attenuation selector switch [2 ].
4.- Turns on the level meter, to select the representation of
the spectrum in the whole band (
maximum a 110 dB reference level.
5.- Verify on the TV level meter screen the presence of the
three pilot frequencies generated by the
as the received signal level to evaluate the attenuation
value from line.
6.- Tune on the level meter a pilot IF frequency (1050 MHz,
1575 MHz or 2100 MHz) on L band. On the level meter
screen on TV mode, there must be visible a picture with two
black and one white bar (See
09/03 - 7 - RP-050
Checking a TV SAT - UHF installation.
RP-050
OUTPUT [1] connector to one of the
RP-050
, depending on the presence of
Full Span
IMPORTANT REMARK
) and fix as
RP-050
as well
).
English
Page 10
If, in addition, the level meter sound is tuned to 7.02 MHz
(± 0.2 MHz), a tone of approximately 1 kHz will be audible
in the TV level meter.
Consequently, the correct equalisation of the selected
installation section will be able to be verified.
IMPORTANT REMARK:
Video carriers generated by
therefore the picture withs bars transmitted at
(525 MHz)
TV level meter since in Terrestrial band these equipments
WILL NOT BE VISUALIZED
are FM-modulated,
RP-050
on TV receiver nor
UHF
only demodulate AM signals.
It is possible to verify the pilot signal level using the
SPECTRUM analyser mode on a TV level meter.
band
REMARK:
The activation of the altennuator [2] aside from
affecting the video carriers output level could cause
a small offset on the tuned frequencies (<1%). In
order to compensate this frequency offset you are
recommended to tune the TV level meter again
whenever the selector switch [2] changes between
the LOW and HIGH position.
09/03 - 8 - RP-050
Page 11
3.2.2 SAT-receiver test
Figure 3.-
1.- Connect jack [1] RECEIVER to the
(SAT-antenna input) of the SAT-receiver to be tested.
2.- Connect SAT-receiver and television set (SCART-socket or RF-
connector).
3.- Switch on SAT-receiver and television set, in case of connection via
SCART-socket, switch television set to the AV-channel.
4.- In case of connection via RF-connector, tune SAT-receiver to
television set (with the help of the internal receiver pattern).
5.- Switch on
mode or HIGH mode.
6.- Tune on the SAT-receiver one pilot IF frequency (1050 MHz, 1575
MHz or 2100 MHz) on L band. On the television set, there must be
visible a picture with two black and one white bar.
If, in addition, the SAT-receiver is tuned in the audio stage to 7.02
MHz (± 0.2 MHz), a tone of approximately 1 kHz will be audible in the TV
set.
Consequently, the video and audio stage of the SAT-receiver can
be checked.
09/03 - 9 - RP-050
RP-050
SAT-receiver test
RP-050
with the IF - input jack
, slide attenuation selector switch [2] to LOW
English
Page 12
4 MAINTENANCE
The method of maintenance to be carried out by the user
consists of cleaning the cover. All other operations should be
carried out by authorised agents or by personnel qualified in
the service of instruments.
4.1 Cleaning recommendations
CAUTION
Do not use scented hydrocarbons or chlorides solvents.
Such products may attack the materials used in the
construction of the cover.
The cover should be cleaned by means of a light solution
of detergent and water applied with a soft cloth.
Dry thoroughly before using the system again.
English
09/03 - 11 - RP-050
