EN-264
DVB MPEG-4 HDTV ENCODER
& TRANSCODER
- 0 MI1720 -
SAFETY NOTES
Read the user’s manual before using the equipment, mainly " SAFETY RULES "
paragraph.
The symbol
on the equipment means "SEE INSTRUCTION MANUAL". In this
manual may also appear as a Caution or Warning symbol.
Boxes of WARNING AND CAUTION may appear in this manual to avoid hazard or
damage to people, to this product or other properties.
USER’S MANUAL. EN-264.
T A B L E OF C O N T E N T
1 GENERAL..................................................................................................................1
1.1 Description ..........................................................................................................1
1.2 Features ..............................................................................................................2
1.3 Especifications ....................................................................................................2
2 SAFETY RULES........................................................................................................5
2.1 General safety rules............................................................................................5
2.2 Descriptive Examples of Over-Voltage Categories.............................................6
3 INSTALLATION .........................................................................................................7
3.1 Front panel and rear panel instructions...............................................................7
4 MENU STRUCTURE AND OPERATION INSTRUCTIONS......................................9
4.1 Menu operating instructions..............................................................................11
4.1.1 Status menu................................................................................................11
4.1.2 Encoder Setup menu ..................................................................................12
4.1.3 Transcoder Setup Menu .............................................................................16
4.1.4 IP Board Setup Menu..................................................................................20
4.1.5 IP Board Setup Menu..................................................................................22
4.1.6 PID Processing Menu.................................................................................23
4.1.7 Output Setup Menu.....................................................................................24
4.1.8 System Menu..............................................................................................24
4.2 Installation.........................................................................................................25
5 MAINTENANCE.......................................................................................................27
5.1 Replacing the fuse.............................................................................................27
5.2 Cleaning Recommendations .............................................................................27
USER’S MANUAL. EN-264.
USER’S MANUAL. EN-264.
05/2013 Page 1
DVB MPEG-4 HDTV ENCODER &
TRANSCODER
EN-264
1
1 GENERAL
1.1 Description
EN-264 is a HD Encoder & Transcoder which fully complies with H.264 standard.
Integrated with the TSoIP board, the accepts TS over IP or ASI input for transcoding, or
alternatively accepts HD-SDI, HDMI or YPbPr input for encoding, the final output is
available in IP or ASI format. With extraordinary picture quality and significant
bandwidth liberation, EN-264 is the best choice for higher performance encoding and
migration from MPEG-2 to H.264.
Functions EN-264
HD SDI Input
√
HDMI Input
√
Y/Pb/Pr Input
√
CVBS Input
√
Audio 1 Input
√
Audio 2 Input
√
ASI Input √
ASI Output (x2)
√
10/100M TS Over IP
(6 Multicasts)
√
Remote Control
√
RS-232
√
1
Trademark of the DVB - Digital Video Broadcasting Project.
USER’S MANUAL. EN-264.
Page 2 05/2013
1.2 Features
• Conforms to H.264 High Profile 4.0 and Main Profile 4.0.
• TS to TS Transcoding MPEG-2 HD to H.264 HD/SD, or MPEG-2 SD to H.264
SD.
• Supports TS multiplexing, which can re-multiplex encoded programs and ASI
input programs into one TS stream.
• Supports full full HD 1080i.
• Multiple inputs HDMI, HD-SDI, YPbPr and CVBS for encoding.
• Support VBR and CBR encoding mode.
• Support Remux, can edit PSI/SI table information.
• 10M/100M Base-T TS over IP output.
• Auto-save when power off.
1.3 Especifications
Video input and compression
Input interface HD/SD-SDI/HDMI/YpbPr, CVBS video
interface.
Compression format AVC (H.264) encoding.
Compression bit rate 2~20 Mbps.
Audio input and compression
Compression format MPEG1 Layer2.
Signal sampling rate 48 KHz.
Compression rate 32~256 Kbps, 64~448 Kbps/AC3.
Input type Analog balance or unbalance audio interface
digital audio HD/SD-SDI HDMI.
DVB-ASI serial data input
Interface type 75 Ω, BNC interface.
Data mode Byte mode
Packet length 188/204 Bytes
Signal level 800±80 mV.
DVB-ASI serial data output
Interface type 75Ω， BNC interface.
Data mode Byte mode.
Packet length 188 Bytes.
Signal level 800±80 mV.
Bit rate 1.5~67 Mbps(adjustable).
USER’S MANUAL. EN-264.
05/2013 Page 3
TS over IP output
100Base-T RJ-45.
Maximum output bit rate 70 Mbits/s.
Transport protocols UDP/RTP, Multicast or Unicast.
Multicast control protocol IGMPV2.
ALIMENTATION
Power supply 90~250V-50/60Hz.
Consumption 19 W.
OPERATING ENVIRONMENTAL CONDITIONS
Altitude Up to 2000 m.
Temperature range From 0 to 45 °C.
Max. relative humidity 80 % (up to 31°C),
decreasing lineally up to 50% at 40 °C.
MECHANICAL FEATURES
Weight 3 Kg.
Dimensions 44 mm (W)× 240 mm (H)× 430 mm.
INCLUDED ACCESSORIES
1 x Coaxial cable.
1 x Power cable CA-05.
4 x RCA-BNC adapters.
2 x RCA-Audio adapters.
1 x DB9-Audio adapters (Left and right).
2 x Rack Handles.
1 x Certificate of Guarantee.
RECOMMENDATIONS ABOUT THE PACKING
It is recommended to keep all the packing material in order to return the
equipment, if necessary, to the Technical Service.
USER’S MANUAL. EN-264.
Page 4 05/2013
USER’S MANUAL. EN-264.
05/2013 Page 5
2 SAFETY RULES
2.1 General safety rules
∗ The safety could not be assured if the instructions for use are not closely
followed.
∗ Use this equipment connected only to systems with their negative of
measurement connected to ground potential.
∗ The equipment is a Class I equipment, for safety reasons plug it to a supply line
with the corresponding ground terminal.
∗ This equipment can be used in installations with Overvoltage Category I and
environments Pollution Degree 2.
∗ When using some of the following accessories use only the specified ones to
ensure safety:
Power cord.
∗ Observe all specified ratings both of supply and measurement.
∗ Remember that voltages higher than 70 V DC or 33 V AC rms are dangerous.
∗ Use this instrument under the specified environmental conditions.
∗ The user is only allowed to:
- Change fuses. They must be of the type and value specified.
- At the maintenance paragraph, specific instructions are provided for these
interventions.
- Any other change in the equipment must be exclusively carried out by
specialized technician staff.
∗ Negative of the signal is at ground potential.
∗ Do not obstruct the ventilation system of the equipment.
∗ Use for the signal inputs/outputs, specially when working with high levels,
appropriate low radiation cables.
∗ Follow the cleaning instructions described in the Maintenance paragraph.
