CompactMax-2
CompactMax-3
DVB-S/S2 TO DVB-T2 TRANSMODULATOR
- 0 MI2100 -
SAFETY NOTES
Read the user’s manual before using the equipment, mainly "SAFETY RULES"
paragraph.
The symbol
on the equipment means "SEE USER’S MANUAL". In this manual
may also appear as a Caution or Warning symbol.
WARNING AND CAUTION statements may appear in this manual to avoid injury
hazard or damage to this product or other property.
USER'S MANUAL VERSION
Version Date Webserver version
3.0 November 2018 1.16.697
November 2018
November 2018
SAFETY REQUIREMENTS
* The security can be compromised if not applied the instructions in this
manual.
* Remember that voltages higher than 70 V DC or 33 V AC rms are dangerous.
* Use this instrument under the specified environmental conditions.
* The user is not allowed to perform changes inside the equipmen t. Any change on
the equipment must be done exclusively by specialized staff.
* Do not obstruct the ventilation system of the equipment.
* Use appropriate low-level radia tion cables for input / output sig nals, espe cially on
high level signals.
* Follow the cleaning instructions described in the Maintenance paragraph.
November 2018
* Symbols related with safety:
Descriptive Examples of Over-Voltage Categories
Cat I Low voltage installations isolated from the mains.
Cat II Portable domestic installations.
Cat III Fixed domestic installations.
Cat IV Industrial installations.
November 2018
TABLE OF CONTENTS
1 INTRODUCTION........................................................................................ 1
1.1 Description .................................................................................... 1
2
PACKAGE CONTENT..........................................................................................................................3
3 DESCRIPTION AND LOCATION ELEMENTS..............................................................................4
4 ASSEMBLY INSTRUCTIONS............................................................................................................6
4.1 Rack mounting............................................................................... 6
4.2 Wall Mounting................................................................................ 6
5
WEBSERVER OP ERATION ...............................................................................................................7
5.1 Introduction................................................................................... 7
5.2 Login ............................................................................................ 7
5.3 Screen description .......................................................................... 9
5.4 Status Area ................................................................................... 9
5.5 Edit options ..................................................................................10
5.6 Setting parameters........................................................................11
5.6.1 Versions / Store.........................................................................12
5.6.2 Control.....................................................................................13
5.6.3 Logs ........................................................................................14
5.6.4 Receivers..................................................................................15
5.6.5 CAM.........................................................................................16
5.6.6 Input Services...........................................................................17
5.6.7 Output Services.........................................................................18
5.6.8 LCNs........................................................................................19
5.6.9 DVB-T2 modulators....................................................................20
6 SPECIFICATIONS
................................................................................22
7 MAINTENANCE
...................................................................................23
7.1 Cleaning Recommendations ............................................................23
November 2018 1
DVB-S/S2 TO DVB-T2 TRANSMODULATOR
CompactMax-2
CompactMax-3
1 INTRODUCTION
1.1 Description
The CompactMax is a compact transmodulation system that allows you to
distribute Satellite TV channels (DVB-S or DVB-S2) in Second Generat ion Digital
Terrestrial Television (DVB-T2) format.
The CompactMax has 4 satellite inputs
and 4 DVB-T2 independent outputs. Two
inputs are for free channels and the other two inputs for encrypted channels.
There are also two slots to insert a Card Access Module (CAM)* to decrypt these
channels and one input for RF loopthrough.
The CompactMax extracts the sequence of digital data (Transport Stream) of
DVB-S/S2 signal. TS tables are regenerated (PAT, PMTs, SDT and NIT) and PID
remapped. Then signal is modulated again in DVB-T2 format, in order to
distribute it at frecuencies between 47 and 858 MHz with a re solution of 1 kHz.
After going through this process, there are 4 DVB-T2 independent signals that
can be inserted into a television distribution network. The output signal has high
quality, allowing its way through multiple amplifier stages, drifte rs, long cables,
etc.
The CompactMax is managed through a webserver via remote control (LAN or
internet) and it is compatible with any standard browser. The webserver is easy
to use and has multiple setting options.
The CompactMax is integrated into a 19” (1U high) rack-mount case, which fits
in any TV head-end installation. It can also be mounted directly on the wall.
Among the practical applications of this transmodulator are:
• Filter services in order to choose what DVB-S/S2 channels will become
DVB-T2.
• Restoration of quality in a weak signal.
• To move DVB-T2 channels from one frequency to other.
• To change a programme grid without need to retune every TV on the
system.
• To avoid degradation of signal.
• To avoid overlapping on other channels.
• To distribute encrypted programmes as free view in an internal TV
network.*
• To use as a TV repeater to cover shadow areas.
* only available for CompactMax-2
It can be used in hotels, convention centres, hospitals, ships, emblematic
buildings, mansions, etc.
Figure 1.
* only available for CompactMax-2
2
November 2018
November 2018 3
2 PACKAGE CONTENT
Main Unit.
Quick guide.
Power line.
3 DESCRIPTION
Front view
Figure 2.
1. Power On indicator.
2. Error indicator.
3. Common Interface input (CI#1) for decoder card*.
4. Common Interface input (CI#2) for decoder card*.
5. IP address reset.
* only available for CompactMax-2
4
November 2018
