Pro-ject Audio Remote Box S User Instruction

Instruction manual

Pro-Ject Remote Box S

© Audio Trade GmbH · Pro-Ject Remote Box S · Version June 15th, 2013

1

2

Inhalt
Connections....................................................................	4
USB Connection..................................................................................	4
Mains power connection.......................................................................	4
Connection of infrared Repeaters..........................................................	4
Safety Instructions............................................................	4
Front panel......................................................................	5
Suggestions for placement...............................................	5
Setting up the Remote Box S.............................................	5
Installation of Java...............................................................................	5
Installation and Start of the configuration program..................................	5
Start of the configuration......................................................................	6
Search for your WLAN..........................................................................	6
Entering the WLAN access code............................................................	6
Finishing the configuration....................................................................	6

Operation of the Remote Box S with the App „Box Control“7.

Initial start of the app............................................................................	7
Select the Remote Box S........................................................................	7
Getting started with the app..................................................................	9
Commands for Pro-Ject devices............................................................	9
Programming of remote commands.....................................................	10
Settings menu....................................................................................	11
List of command windows...................................................................	11
Sorting the control windows................................................................	11
General Settings................................................................................	12
Specifications.................................................................	12
Service..........................................................................	12
Warranty.......................................................................	12
Copyright......................................................................	12

© Audio Trade GmbH · Pro-Ject Remote Box S · Version June 15th, 2013

3

Pro-Ject Remote Box S

Dear music lover, thank you for purchasing the Pro-Ject Audio Remote Box S.

In order to achieve maximum performance and reliability, you should study this instruction manual carefully.

Hazard warning for the user, the unit or possible misuse

Important notice

With the Remote Box S and the free Pro-Ject Box Control app you are able to control all Pro-Ject units with a infrared remote control via WLAN. The Box Control app is available for iOS units, e.g. the Apple iPhone, as well as for smartphones and tablets with the Android operating system. The Remote Box S simplifies and unifies the control of your complete hi-fi system tremendously. All infrared codes of the Pro-Ject units are already stored in the app – which btw. is able to control all Stream Box units from Pro-Ject except the Stream Box DS even more directly via WLAN, without infrared commands. The Remote Box S can even control devices from other manufacturers, the respective infrared (abbreviated IR) command code can be programmed into the app very easily.

Connections
USB	A	B
		Pro-Ject Audio Systems
		Vienna, Austria

Make all connections while the Remote Box S is disconnected from the power supply.

USB Connection

For configuration the Remote Box S must be connected to a PC via USB. The USB connection cable is included.

Mains power connection

The unit is supplied with a power supply suitable for your country’s mains supply. Check the label before connecting to ensure compliance with the mains rating in your house. Connect the low voltage plug from the power supply to the Power 9V socket before connecting the power supply to the mains.

It isn’t possible to disconnect the Remote Box S completely from mains power by a power button. Therefore it consumes a small amount of power permanently. If you are not going to use the unit for an extended period of time, e.g. vacation, we suggest to disconnect it from the AC mains.

Connection of infrared Repeaters

External infrared repeaters (available as accessory) can be connected to the 3,5mm jack plug socket to enhance the range of the Remote Box S or for installation in a second room. The jack plug socket A has no functionality.

Safety Instructions

Use the Remote Box S only with the DC 9V/2A power supply it is delivered with.

AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the voltage in your area meets the voltage requirements printed on the power supply. The power cord is used to disconnect the unit from the mains. Make sure that the power cord is easily accessible at all times. Never handle the device, the power cord/power supply while your hands are wet or damp.

Avoid letting liquids enter the device or the power supply. Never place any item containing liquid, such as a flower vase on or near the device. Never spill any liquid on the device or the power supply. Never place any naked flame sources, such as lighted candles on or near the device. The product shall not be used in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar conditions.

4
