Elpro Concept
A NEW CONCEPT OF DESIGN
Sleek case design | HD Progressive | High Resolution | Up to 400 cm wide
Installer: Avex | Location: Grand Hotel Karel V (Utrecht, the Netherlands)
Elpro Concept
Stylishly designed electric projection
screen for wall or ceiling mounting with
tab-tensioned system for a perfectly flat
screen surface. If you cannot hide the
case into the ceiling, use a projection
screen that is worth noticing.
STYLISH CASE
DESIGN
Tensioned Elpro Concept
• Stylish case design
• No screws visible for a clean (aesthetic) installation
• Available with HD Progressive for high resolution projection
• Available in a tab-tensioned (HD Progressive) and
a non-tensioned version
• Screen surface unrolls close to the wall after installation
• 5 year limited warranty on the projection screen and motor
• Motor installed in rubber dampers for a silent operation
HD PROGRESSIVE TAB-TENSIONED 5 YEAR
WARRANTY
SOLID STEEL
MOUNTING
Available dimensions
Minimum width: 180 cm |
Maximum width: | 380 cm
2.35:116:916:10 4:3
Elpro Concept
Available dimensions
Minimum width: 180 cm |
Maximum width: | 400 cm
High Resolution
HD Progressive 0.6
Viewing Angle: 170°
Gain: 0.6
HD Progressive 0.9
Viewing Angle: 170°
Gain: 0.9
HD Progressive 1.1
Viewing Angle: 170°
Gain: 1.1
HD Progressive 1.3
Viewing Angle: 150°
Gain: 1.3
Dual Vision
Viewing Angle: 130°
Gain: 0.9
Standard Resolution
Matte White
Viewing Angle: 120°
Gain: 1.0
HCCV
Viewing Angle: 100°
Gain: 1.1
Pearlescent
Viewing Angle: 80°
Gain: 1.5
HD Progressive 1.1 Perf
Viewing Angle: 170°
Gain: 1.1
Standard Resolution
Matte White
Viewing Angle: 120°
Gain: 1.0
High Contrast
Viewing Angle: 100°
Gain: 1.1
Datalux
Viewing Angle: 70°
Gain: 1.5
1:116:916:10 4:3
REFLECTING YOUR VISION | milestone.com
T +31 (0) 495 580 840 F +31 (0) 495 580 845 E emea.sales@milestone.com
Franklinstraat 14, 6003 DK Weert, P.O. Box 191, 6000 AD Weert, The Netherlands
©2017 Milestone AV Technologies. 170128/17 Projecta is a registered trademark of Milestone AV Technologies. All other brand
names or marks are used for identification purposes and are trademarks of their respective owners. All patents are protected
under existing designations. Other patents pending.
