INSTRUCTIONS FOR USE
Pro-Ject Speed Box S
Dear music lover, thank you for purchasing a PRO-JECT AUDIO Speed Box. * The unit permits electronic speed change of your
Pro-Ject record player between 33 and 45 r.p.m. and also permits the replay of shellac records by allowing ** 78 r.p.m. with an appropriate pulley and cartridge.
In order to achieve maximum performance and reliability you should study these instructions for use carefully.
!
Warning of a hazard for the user, the unit or possible misuse.
Important notice.
Safety instructions
AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the voltage in your area meets the voltage requirements printed on the power supply.
The power supply is used to disconnect the unit from the mains. Make sure that the power supply is easily accessible at all times.
!
Avoid letting liquids enter the device or the power supply. Never place any item containing liquid, such as a flower vase on or near the device. Never spill any liquid on the device or the power supply. Never place any naked flame sources, such as lighted candles on or near the device. The product shall not be used in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar conditions.
Never handle the device, the power supply while your hands are wet or damp.
Connecting the record player
Output
~16V
Pro-Ject Audio Systems,
Vienna, Austria
18V
Connect the power cable supplied *** (polarity socket of the record player. The original power supply of the record player is then no longer required.
!
Make all connections whilst the Speed Box is disconnected from the power supply.
Models with 16V/AC wall power supply only. 16V/190mA AC max.. * All Juke Box, Elemental and Debut Carbon models, all Phono and Phono/USB models, all models
with Automatic switch-off (like Debut III E) and electronic speed change (like Debut Carbon Esprit SB, RPM 6.1 SB, Xpression III Comfort, Xperience Comfort), Xtension (all models) and Signature may not be used with the Speed Box.
+
) to the socket Output ~16V and to the power supply
Mains power connection
Connect the low voltage plug from the power supply to the socket Power 18V " before connecting the power supply to the mains.
!
Never use any other power supply than the one supplied with the unit.
2
© Audio Trade GmbH · Pro-Ject Speed Box S · Revision 2013.10.23
