Pro-Ject Set Micro-Hifi-System User Manual

INSTRUCTIONS FOR USE

Pro-Ject Set “Micro-Hifi-System”

Dear music lover,

thank you for purchasing a Pro-Ject “Micro-Hifi-System”-Set. In order to achieve maximum performance and reliability you should study these instructions for use carefully.

!

Warning of a hazard for the user, the units or possible misuse.

Important notice.

Safety instructions

AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the voltage in your area meets the voltage requirements printed on the power supply.

The power cord/power supply is used to disconnect the unit from the mains. Make sure that the power cord/power supply is easily accessible at all times. cord/power supply while your hands are wet or damp.

!

Avoid letting liquids enter the device or the power supply. Never place any item containing liquid, such as a flower vase on or near the device. Never spill any liquid on the device or the power supply. Never place any naked flame sources, such as lighted candles on or near the device. The product shall not be used in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar conditions.

Never handle the device, the power

What’s in the box

Receiver Box S including remote control handset, power supply and power cord

Dock Box S Fi including remote control handset and power supply

CD Box S including remote control handset and power supply

Control it remote control handset

2 x Speaker Box 5 including wall mount brackets and instruction for use

Design Box 4iP Acryl

Speaker cable, length 2 x 3 meter

8 x banana plugs (4mm )

Interconnect cables, length 20 and 25cm

Connectors - Receiver Box

Pro-Ject Audio Systems, Vienna, Austria

Make all connections whilst the receiver is disconnected from the power supply.

!

2

Connecting receiver, docking station and CD player

Connect, using the supplied interconnect cables, the sockets IN1 on the receiver to the sockets OUT on the CD Box S. The sockets OUT of the Dock Box S Fi have to be connected to the sockets IN2 on the receiver.

Take care to connect the left and right channels correctly. The right channel is usually marked red,

!

the left channel black or white.

Antenna input

Connects any antenna cable with a co-axial DIN-plug / US-model F-plug.

Connecting receiver and speakers

The output terminals accept loudspeaker cables terminated with 4mm  Banana plugs, spades connectors or naked wire. Connect the cable terminals on the receiver to the terminals on the speakers.

The red speaker terminals carry the positive signal (+), the black speaker terminals the negative

!

signal (–). Make sure the polarity of the connection is correct at each end of the cables. Only connect one loudspeaker with an impedance not less than 4 ohms per channel.

Connectors - CD Box S

Pro-Ject Audio Systems, Vienna, Austria

Make all connections whilst the CD player is disconnected from the power supply.

!

Connection to a external A/D-converter

Connect the Co-axial out socket to a coaxial digital input on the D/A converter or AV processor. Doing so allows you to use the signal in its digital for further digital processing.

Connectors - Dock Box S Fi

18V

Pro-Ject Audio Systems, Vienna, Austria

!

Make all connections whilst the Dock Box is disconnected from the power supply.

Connecting to a computer, iPod® operating system

Connect the USB-output of the Dock Box to a free USB-socket on your computer and turn it on/make sure it is powered on.

When the Dock Box is connected to a computer, all functions of the Dock Box are blocked.

3

Connection to a TV-set or a beamer

Connect the S-VIDEO socket to a s-video input of your TV-set or beamer.

Fitting and adjustment of the iPod® cradle

Use the knurled screw supplied to fix the cradle to the Dock Box chassis. Do not fully tighten the screw yet. Now place your iPod the screw.

Suitable for iPods® with 30-pole connector only.

Use without the cradle breaks the 30-pole connector of the Dock Box and the socket of the iPod

!

Before connecting the iPod

®

on the Dock Box contacts. Move the cradle so that it supports the iPod® and tighten

®

, any sort of cover has to be removed.

.

Mains power connection

Receiver Box S Connect the low voltage plug from the power supply to the Power 20V supply to the mains.

CD Box S Connect the low voltage plug from the power supply to the Power 9V supply to the mains.

Dock Box S Fi Connect the low voltage plug from the power supply to the Power 18V supply to the mains.

"

socket before connecting the power

"

socket before connecting the power

"

socket before connecting the power

!

Never use any other power supply than the one supplied with the particular unit.

To switch on and off, loading the battery - Dock Box S Fi

The push button on the front panel turns the Dock Box on and off. The blue LED above the push button shows that the unit is switched on.

When the Dock Box is connected to the mains supply and switched on, the iPod as it is placed on the contacts. Recharging will continue even if the iPod possible, when the Dock Box is switched off.

®

will start recharging as soon

®

is on standby. Recharging is not

4

Remote control - Dock Box S Fi

Blanked out buttons do not carry a function !

ON/OFF

ENTER

MENU

REPEAT

7

8

0

7

8

0

Stepping between tracks, reverse and forward scanning

7

skips to the previous track.

SHUF

9

To switch on from standby or to standby

ON/OFF

0

turns the iPod® into standby.

To switch on from standby press any key (except ON/OFF).

Start / Pause

8

starts and pauses playback

9

skips to the next track

7

restarts the current track in playback mode

Press and hold the

7

button for reverse scanning, or the button

9

to start forward scanning.

Repeat play

REPEAT

7

starts repeat play for the current track. Pressing the button again starts repeat play for all tracks.

To deactivate repeat play press REPEAT once more.

Shuffle play

SHUF

9

activates and deactivates shuffle play

Navigating the menu

MENU

shows the menu. Returns to the previous step in the menu

and move the curser up and down, to highlight the requested option.

ENTER

selects or deselects the highlighted option. Shows the next step in the menu.

5

Remote control - Receiver Box S

To switch on from standby or to standby

ON/OFF

TUNE

CH+

INPUT

TUNE

ON/OFF

0

short press turns the unit on, long press takes it back into standby.

Powered on, a short press activates and deactivates mute

Volume

_

VOL-

OK

VOL+

VOL

0

and

VOL

+

0

adjust the sound volume

M1

M3

CH-

M4

M2

M5

Selecting an input

INPUT

0

selects the inputs and tuner mode in turns

Selecting the tuning mode

OK

M6

M7

M8

Pressing (min. 3 seconds) search (MANUAL), automatic program search (AUTO) and program selection from memory (MEMORY) in turns.

0

selects the tuning modes manual program

Manual program search - the display shows MANUAL

TUNE

decreases,

TUNE

increases the reception frequency in 50kHz steps.

Automatic program search - the display shows AUTO

CH-

0

starts the automatic frequency scan downwards,

CH+

0

starts the scan upwards.

Program selection from memory - the display shows MEMORY

M1

0

CH-

0

-

and

M8

0

activate the memory function. Pressing

CH+

0

select -memory function has to be activated- the memory positions 9 - 99.

M1

0

-

M8

0

access the presets 1 - 8 directly.

Saving a program in the memory list

OK

Tune to the frequency to be stored. Press

CH+

0

will select the next memory position up the list,

The memory positions 1 - 8 can be selected directly by pressing

OK

Press

6

0

once again to store the program at that position. The display shows STORED.

Saving a program to a particular memory position overwrites any program already stored at that position. The memory retains its contents through a power off/on cycle.

0

twice in rapid succession. The display will show STORE.

CH-

0

selects the next memory position down the list.

-

M8

0

M1

0

.
