Pro-Ject Power Box RS Amp User Manual

Pro-Ject Power Box RS Amp

INSTRUCTIONS FOR USE

2

Dear music lover,

AC outlet voltages vary from country to country. Before connecting to the mains, make sure that

nter the device. Never place any item containing liquid, such as a flower vase

be used in damp or wet

switched off or disconnected from the mains

and for any future

Power Box RS Amp.

!

thank you for purchasing a Pro-Ject Audio Systems Power Box RS Amp.

In order to achieve maximum performance and reliability you should study these instructions for use carefully.

Warning of a hazard for the user, the unit or possible misuse.

Important notice.

Safety instructions

the voltage in your area meets the voltage requirements printed on the device.

Never handle the device while your hands are wet or damp.

Avoid letting liquids e on or near the device. Never spill any liquid on the device or cables. Never place any naked flame sources, such as lighted candles on or near the device. The product shall not locations, next to a bathtub, sink, swimming pool or any other similar conditions.

Connecting Power Box RS Amp

Connect the power cable to the unitand to the mains. Then use special supplied cable to connect the Power Box RS Amp with the amplifier(s). Then the original power supply of the amplifier is no longer required.

Make all connections whilst the Power Box RS Amp is

Power Box RS Amp is designed only for Pro-Ject Audio Systems products with 2x48V power supply.

Amp Box DS, Amp Box DS Mono, Stereo Box RS, Amp Box RS, Amp Box RS Mono product with 2x48V power supply. Products with different input voltage cannot be used with the

.

3

Connection to one amplifier

Connection to two amplifiers

Incorrect use

Any of listed Pro-Ject amplifiers

can be connected

Connect only mono versions of the

amplifiers

Power Box RS Amp is not designed

to drive two stereo amplifiers

Main power switch

The toggle switch on the left side will turn the unit on or off. The blue LED above the switch shows that the unit is switched on.

4

Technical specifications Pro-Ject Power Box RS Amp

The manufacturer accepts no responsibility for damage caused by not adhering to these

changes to any part of the product by unauthorized persons

release the manufacturer from any liability over and above the lawful rights of the customer.

The information was correct at the time of going to press. The manufacturer reserves the right to

changes to the technical specification without prior notice as deemed necessary to uphold the ongoing process of technical development.

Input voltage: AC 230V/50Hz IEC C15 connector (120V/60Hz US version)

Output voltage: two outputs by 2 x 48V / 2.5A DC each

Filtration capacity: 40.000 µF

Output voltage ripple: 7mV peak to peak

Dimensions W x H x D: 201 x 72 x 195mm

Weight: 4,8kg

Service

Should you encounter a problem which you are not able to alleviate or identify, please contact your dealer for further advice. Only if the problem cannot be resolved there, the unit should be sent to the responsible distributor in your country.

Warranty

instructions for use. Modification or

Copyright, trademarks

Pro-Ject Audio Systems is a registered Trademark of H. Lichtenegger.

This guide was produced by: Pro-Ject Audio Systems Copyright

©
