PRO Intellect PRO 12 User Manual
PRO-12 SERIES
12 / 12M / 12P / 12WMP / 12PM / 12LPM
www.pro-intell.com
Money detector
User manual
English
2
PRO Intellect Technology Corporation offers the PRO-12 series of counterfeit currency
detectors. This series is designed for the authentication of banknotes from various currencies,
including United States dollars and the euro, as well as securities and documents such as
licenses, bonds, and excise stamps. The multi-stage verification accurately detects
counterfeit banknotes and documents that simple single-stage devices may fail to detect. This
device is designed for use in banks, accounting departments, currency exchanges,
supermarkets, etc.
1 Specifications
PRO-12 PRO-12P PRO-12M PRO-12WP PRO-12PM PRO-12LPM
UV lamp, W 2x6 2x6 2x6 6 2x6 2x6
Daylight lamp, W 4 4+6 4 4
Loupe magnification 2.5
Magnetic sensor + + +
Activation time , s 1
Wavelength, nm
365
Power supply 110/220V 50/60Hz
Power consumption, W 15 15 15 8 15 15
Dimensions, mm
Dimensions, inch
110x270x110
4 3/10(L) x
10 3/5(W) x
4 3/10(H)
140x270x140
5 ½ (L) x
10 3/5(W) x
5 ½ (H)
40x270x140
5 ½ (L) x
10 3/5(W) x
5 ½ (H)
40x270x140
5 ½ (L) x
10 3/5(W) x
5 ½ (H)
40x270x140
5 ½ (L) x
10 3/5(W) x
5 ½ (H)
40x270x140
5 ½ (L) x
10 3/5(W) x
5 ½ (H)
Net weight, g
Net weight, lb
650
1.4
930
2.1
930
2.1
930
2.1
930
2.1
930
2.1
3
2 Complete set and main differences of PRO-12 series
PRO-12
- Two 6W UV lights (total power 12 W)
PRO-12M
- Two 6W UV lights (total power 12 W)
- Magnetic sensor
PRO-12P
- Two 6W UV lights (total power 12 W)
- 4W fluorescent light
- Working table 50x90mm with ruler
4
PRO-12WPM
- 6W UV light
- Two fluorescent light
(upper 6W lamp, lower 4W lamp)
- Magnetic sensor
- Working table 50x90mm with ruler
PRO-12PM
- Two 6W UV lights (total power 12 W)
- 4W fluorescent light
- Magnetic sensor
- Working table 50x90mm with ruler
PRO-12LPM
- Two 6W UV lights (total power 12 W)
- 4W fluorescent light
- Magnetic sensor
- 2.5x Magnifying glass
- Working table 50x90mm with ruler
- Automatic power on/off sensor (~ 5 min
based on settings)
5
3 Appearance
1. Desktop surface.
2. Power switch (rear wall).
3. Operation mode switch (for PRO-12 and PRO-12M detectors: Power switch).
4. Fluorescent light working surface (for 12P, 12WP, 12PM, 12LPM models)
5. Magnetic sensor (for 12M, 12PM, 12LPM models)
6. Magnetic sensor indicator
7. Power on/off sensor (for 12LPM model) – to activate the device, place a banknote
over the on/off sensor
8. 2.5x magnification lens (for 12LPM model)
4 Safety precautions
1. The device should only be used on an even horizontal surface. Keep the device away
from water or small objects that can become embeddedin the internal components of the
device.
2. Do not place the device in direct sunlight or any strong artificial light that can interfere
8
3
7
1
3
2
6
5
UV detection
White transmitted light detection
Magnetic sensor
Figure 1
