Progressive Industries SSP-50 User Manual

Progressive Industries, Inc.

Operating Instructions for:

Model SSP-50

Rated at 120V/240V/50A

Manufactured by:

Progressive Industries, Inc.

414B Airport Boulevard

Morrisville, NC 27560

[phone]

www.progressiveindustries.net

Proudly manufactured i n t he U.S.A.

Smart Surge Instructions

Specifications

Rated at 120/240V/50A

Joule Rating: 1650J

Surge Amps: 45,000

Response Time: <1 NS

Circuit Tester Checks For:

Reverse Polarity

Open Neutral

Open Ground

Line 1 Surge Indicators Line 2

1. Plug Smart Surge into AC power. DO NOT plug in your RV at this

time.

2. Verify that both Number 1 red indicator lights are lit to reflect power

source is wired correctly.

3. Verify Line 1 and Line 2 green surge indicator lights are lit.

4. If proper red and green lights are lit, (Refer to diagram below), plug in

RV at this time.

Light 1 on, Light 2 on = Open Neutral
Light 1 off, Light 2 off = Open Ground

The green Surge Indicator lights tell you the condition of the surge
protector circuits. When the green indicator lights are lit, surge protector is
functional; if not, surge protector is compromised and needs to be replaced.
The four red indicator lights denote the wiring of the power source.
The chart printed on the front of the Surge Protector tells you the
wiring condition based on which lights are lit.

Surge Indicator

Weather Resistant

Portable Design

Fuse Protected

Lifetime Warranty

Green Surge Indicator Light

Red Light Number 1

Red Light Number 2

Wiring Configuration

Light 1 on, Light 2 off = Correct Wiring

Light 1 off, Light 2 on = Reverse Polarity

Features

Notes

Progressive Industries Warranty

Progressive Ind ustri es warrants this product to be free from defects in materials

and workmanship for the life of the unit. This is in lieu of all other
warranties, obligations, or liabilities expressed by the company. In the event
that a properly installed Smart Surge proves defective under normal use,

Progressive Industries will repair or replace the device at its discretion.

Progressive Ind ustri es cannot assume responsibility for acts of God, alterations,
shipping/handling, or any other factors not under the control of Progressive
Industries.

Progressive Industries has no responsibility for installation, personal injury,

property damage, incidental, contingent, or consequential damages of any kind
resulting from defects or failure of the unit to function.

The remedy for breach of this warranty is limited to the repair or replacement of

the defective product at Progressive Industries’ option. In no case shall the

liability prescribed by law exceed the purchase price. Some states do not allow
exclusion or limitation of incidental or consequential damages or allow
disclaimers, modifications or limitations on how long a warranty lasts; therefore,
the above warranties may not apply to you. This warranty gives you certain
legal rights, and you may have other rights, which may vary from state to state.

The address below is strictly a mailing address. Please do not attempt to visit
our facility during business hours as the company is not staffed, nor equipped to
handle on-site repair work. All returns must be routed through Technical
Support.

Progressive Industries, Inc.

414B Airport Boulevard
Morrisville, North Carolina 27560

The unit being returned must be properly packaged with the postage paid and
include the following information:

1) Date of purchase.

2) A detailed explanation of the problem/defect.

3) Your Name

4) Return Address and Phone Number

For 7 Days a Week Technical Support call [phone]

www.progressiveindustries.net

(Revision A)
