Model No. PFEL7806.0
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!
Serial No.
Serial Number Decal
(on underside of frame)
QUESTIONS?
As a manufacturer, we are committed to providing complete
customer satisfaction. If you
have questions, or if parts are
damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT
DIRECTLY.
USERʼS MANUAL
CALL TOLL-FREE:
1-888-533-1333
Mon.–Fri., 6 a.m.–6 p.m. MST
Sat. 8 a.m.–5 p.m. MST
ON THE WEB:
www.proformservice.com
CAUTION
Read all precautions and instructions in this manual before using
this equipment. Keep this manual for future reference.
TABLE OF CONTENTS
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
EFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
B
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
HOW TO USE THE ELLIPTICAL EXERCISER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
MAINTENANCE AND TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
CONDITIONING GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
WARNING DECAL PLACEMENT
The warning decal shown here has been
applied in the location shown. If the decal is
missing or illegible, call the telephone
number on the front cover of this manual
and request a free replacement decal.
Apply the decal in the location shown.
Note: The decal may not be shown at actual
size.
PROFORM is a registered trademark of ICON IP, Inc.
2
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your elliptical exerciser before using your elliptical
exerciser. ICON assumes no responsibility for personal injury or property damage sustained by or
through the use of this product.
1. Before beginning any exercise program,
consult your physician. This is especially
important for persons over the age of 35 or
persons with pre-existing health problems.
2. Use the elliptical exercise only as described
in this manual.
3. It is the responsibility of the owner to ensure
that all users of the elliptical exerciser are
adequately informed of all precautions.
4. The elliptical exerciser is intended for
home use only. Do not use the elliptical exerciser in a commercial, rental, or institutional
setting.
5. Keep the elliptical exerciser indoors, away
from moisture and dust. Place the elliptical
exerciser on a level surface, with a mat
beneath it to protect the floor or carpet.
Make sure that there is enough clearance
around the elliptical exerciser to mount, dismount, and use it.
6. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
7. Keep children under age 12 and pets away
from the elliptical exerciser at all times.
8. The elliptical exerciser should not be used by
persons weighing more than 275 lbs.
(124 kg).
9. Wear appropriate exercise clothes while
using the elliptical exerciser. Always wear
athletic shoes for foot protection while exercising.
10. Hold the handgrip pulse sensor or the handlebars when mounting, dismounting, or using
the elliptical exerciser.
11. The pulse sensor is not a medical device.
Various factors may affect the accuracy of
heart rate readings. The pulse sensor is
intended only as an exercise aid in determining heart rate trends in general.
12. Keep your back straight while using the elliptical exerciser; do not arch your back.
13. Over exercising may result in serious injury
or death. If you feel faint or if you experience
pain while exercising, stop immediately and
cool down.
14. When you stop exercising, allow the pedals
to slowly come to a stop.
15. The decal shown below has been placed on
the elliptical exerciser. If the decal is missing
or illegible, call toll-free telephone number
on the front cover of this manual and order a
free replacement decal. Apply the decal in
the location shown.
3
BEFORE YOU BEGIN
Thank you for selecting the revolutionary PROFORM
2.0 CROSSTRAINER elliptical exerciser. The 22.0
2
CROSSTRAINER elliptical exerciser provides a wide
array of features designed to make your workouts at
home more effective and enjoyable.
For your benefit, read this manual carefully before
you use the elliptical exerciser. If you have ques-
tions after reading this manual, please see the front
cover of this manual. To help us assist you, note the
product model number and serial number before con-
Fan
Handgrip Pulse Sensor
Console
®
tacting us. The model number and the location of the
erial number decal are shown on the front cover of
s
this manual.
To avoid a registration fee for any service needed
under warranty, you must register the elliptical
exerciser at www.proformservice.com/registration.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Game Controller
Handlebar
Pedal
Leveling Foot
Accessory Tray
Water Bottle Holder*
Wheel
Leveling Foot
*No water bottle is included
4
ASSEMBLY
M8 x 75mm Button
Screw (107)–4
M4 x 16mm
Self-tapping
Screw (79)–16
M8 x 42mm Bolt
(71)–4
M10 x 20mm x
1mm Washer
(81)–2
M10 x 20mm x
1.5mm Washer
(84)–2
M4 x 16mm
Screw (86)–8
M6 x 35mm Phillips
Screw (87)–8
M6 Split
Washer (88)–8
M10 x 23mm Shoulder
Screw (80)–8
M10 x 62mm Bolt (89)–2 M10 x 78mm Button Screw (90)–2
M10 x 20mm Button
Screw (91)–4
M10 x 20mm x
2mm Washer
(92)–4
M4 x 13mm
Washer (93)–2
M10 x 25mm
Washer (94)–4
M8 x 16mm Button
Screw (95)–3
M8 Nylon
Locknut (96)–4
M10 Nylon
Locknut (97)–2
Wave Washer
(98)–8
Star Washer
(100)–3
M8 x 15mm x 4.5mm
Washer (99)–4
M8 Split
Washer (72)–4
To hire an authorized service technician to assemble the elliptical exerciser, call 1-800-445-2480.
ssembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the
A
packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the
included hex keys, assembly requires a Phillips screwdriver , an adjustable
wrench , and a rubber mallet .
As you assemble the elliptical exerciser, use the drawings below to identify small parts. The number in parentheses
below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number
following the parentheses is the quantity needed for assembly. Note: Some small parts may have been pre-
assembled. If a part is not in the parts bag, check to see if it has been preassembled.
5
1.
To make assembly easier, read the information on page 5 before you begin assem-
ling the elliptical exerciser.
b
1
25
89
Orient the the Front Stabilizer (35) as shown.
ttach the two Wheels (25) to the Front Stabilizer
A
with two M10 x 62mm Bolts (89) and two M10
Nylon Locknuts (97).
Attach two Leveling Feet (26) to the underside of
the Front Stabilizer (35).
2. Have a second person tip the Frame (2) backward. Attach the Front Stabilizer (35) to the
Frame with two M10 x 78mm Button Screws (90).
25
89
2
90
35
97
26
35
26
2
3. Position the Base (1) near the Frame (2) as
shown. See the inset drawing. Attach two
Leveling Feet (26) to the underside of the Base.
Have a second person tip the Frame (2) forward.
Insert the Base (1) into the Frame. Attach the
Base with four M8 x 75mm Button Screws (107),
four M8 Split Washers (72), and four
M8 x 15mm x 4.5mm Washers (99).
3
2
1
99
72
107
26
99
72
107
1
26
6
4. Hook the front ends of the Frame Covers (105,
106) together. Attach each Frame Cover to the
Frame (2) with three M4 x 16mm Self-tapping
crews (79).
S
4
06
79
105
2
79
1
5. Have a second person hold the Upright (6) near
the Frame (2) as shown.
Pull the Wire Harness (48) out of the Frame (2)
and insert it upward through the Upright (6). Do
not let the Wire Harness or the Controller Wires
(110, 111) fall into the Upright; use a piece of
tape or an elastic band to hold the wires in place
until step 15.
Insert the Left and Right Controller Wires (110,
111) downward into the Frame (2). Pull the Right
Controller Wire, which has a tag attached, out of
the right side of the Frame. Then, pull the Left
Controller Wire out of the left side of the Frame.
Insert the Upright (6) into the Frame (2). Attach
the Upright with three M8 x 16mm Button
Screws (95) and three Star Washers (100).
Avoid pinching the Wires (48, 110, 111)
between the Upright and the Frame.
5
48
6
95
100
111
110
2
100
95
95
100
Avoid pinching
the wires during
this step
7
6. Orient the Left Roller Leg (12), which is marked
with a “Left” sticker, near the left Crank Arm (36)
as shown.
Apply a small amount of the included grease to
oth sides of a Wave Washer (98). Slide the
b
Wave Washer onto the end of the left Crank
Arm (36). Next, slide the Left Roller Leg (12)
onto the Crank Arm and set the Roller (22) on
the Base (1). Attach the Left Roller Leg with an
M10 x 23mm Shoulder Screw (80), an
M10 x 20mm x 1.5mm Washer (84), and a
Crank Axle Cap (30).
Repeat this step to attach the Right Roller
Leg (21) to the right Crank Arm (not shown).
6
36
98
30
84
1
80
2
1
2
1
22
7. Identify the Left Handlebar (8), which is marked
with a “Left” sticker. Insert the Left Handlebar into
one of the Handlebar Legs (11) as shown.
Attach the Left Handlebar (8) with two
M8 x 42mm Bolts (71) and two M8 Nylon
Locknuts (96). Make sure that the Nylon
Locknuts are inside the hexagonal holes.
Assemble the Right Handlebar and the other
Handlebar Leg (not shown) in the same way.
7
8
96
Hexagonal
Holes
71
11
8
8. Position an Inner Handlebar Cover (18) and an
Outer Handlebar Cover (19) around the Left
Handlebar (8) as shown. Then, pull the Left
andlebar Wire (108) out of the Left Handlebar
H
and insert it through the Inner Handlebar Cover.
Attach the Inner and Outer Handlebar
Covers (18, 19) with three M4 x 16mm Self-tapping Screws (79) and an M4 x 13mm Washer
(93). Start all three Self-tapping Screws before
tightening any of them. Avoid pinching the
Left Handlebar Wire (108) during this step.
Repeat this step for the Right Handlebar and
the Right Handlebar Wire (not shown).
8
79
108
19
8
9
7
93
Avoid pinching
the Handlebar
Wires (108, 109)
during this step
79
8
1
9. Apply a generous amount of grease to the Pivot
Axle (65) and insert it into the Frame (2).
Pull the Left Controller Wire (110) through the left
Frame Cover (17), and then pull the Right
Controller Wire (111) through the right Frame
Cover.
Attach each Frame Cover (17) to the Frame (2)
with two M4 x 16mm Screws (86). Avoid pinch-
ing the Controller Wires (110, 111) during this
step.
10. Connect the Left Handlebar Wire (108) to the
Left Controller Wire (110). Insert the excess wire
into the Left Handlebar (8).
Apply a small amount of grease to both sides of
a Wave Washer (98). Slide the Wave Washer
onto the left side of the Pivot Axle (65). Next,
slide the Left Handlebar (8) onto the Pivot Axle
as shown. Attach the Left Handlebar with an
M10 x 23mm Shoulder Screw (80) and an
M10 x 20mm x 1mm Washer (81). Avoid pinch-
ing the wires during this step.
Repeat this step for the Right Handlebar (9).
9
Grease
65
17
86
86
10
Avoid pinching
the wires during
this step
81
80
8
Grease
110
2
98
108
110
111
17
Avoid pinching
the Controller
Wires (110, 111)
during this step
9
65
9
11. Identify the Left Pedal (13) and the Left Pedal
Leg (14), which are marked with “Left” stickers,
and orient them as shown.
Attach the Left Pedal (13) to the Left Pedal
eg (14) with four M6 x 35mm Phillips
L
Screws (87) and four M6 Split Washers (88).
Start all four Phillips Screws before tightening any of them.
Repeat this step to attach the Right Pedal to
the Right Pedal Leg (not shown).
11
13
4
1
88
87
88
87
12. Apply a generous amount of grease to two Pedal
Leg Axles (32). Insert one Pedal Leg Axle into
the bottom of the Left Handlebar Leg (11). Insert
the other Pedal Leg Axle into the Left Roller
Leg (12).
Apply a small amount of grease to both sides of
two Wave Washers (98). Place a Wave Washer
on each Pedal Leg Axle (32).
Orient the Left Pedal Leg (14) as shown, and
slide it onto the Pedal Leg Axles (32). Attach the
Left Pedal Leg to the Left Handlebar Leg (11)
with two M10 x 23mm Shoulder Screws (80), two
M10 x 20mm x 2mm Washers (92), and two Axle
Caps (31).
Attach the Left Pedal Leg (14) to the Left Roller
Leg (12) with two M10 x 20mm Button
Screws (91) and two M10 x 25mm Washers (94);
do not overtighten the Button Screws. The
Legs (11, 14, 12) must pivot freely.
Repeat this step for the Right Pedal Leg (not
shown).
12
92
80
98
Grease
32
31
11
31
14
80
92
91
12
Grease
32
98
94
94
91
10
13. The Console (5) requires four 1.5V “D” batteries
(not included); alkaline batteries are
recommended. IMPORTANT: If the elliptical
xerciser has been exposed to cold tempera-
e
tures, allow it to warm to room temperature
efore inserting batteries into the Console. If
b
you do not do this, the console displays or
other electronic components may become
damaged. Remove the battery cover and insert
four batteries into the Console. Make sure that
the batteries are oriented as shown at the right.
Then, reattach the battery cover.
13
5
Batteries
Note: The Console (5) can be operated with an
optional power supply instead of batteries. To
purchase a power supply, call the toll-free
telephone number on the front cover of this
manual. Plug one end of the power supply into
the jack at the front of the elliptical exerciser.
Plug the other end of the power supply into an
appropriate outlet that is properly installed in
accordance with all local codes and ordinances.
14. Have a second person hold the Console (5) near
the Upright (6) as shown. Connect the console
wire harness to the Wire Harness (48).
Connect the right wire, which has a tag attached,
to the Right Controller Wire (111), which has a
tag attached. Then, connect the left wire to the
Left Controller Wire (110). Insert the excess wire
downward into the Upright (6).
Attach the Console (5) to the Upright (6) with
four M4 x 16mm Self-tapping Screws (79).
14
Console Wire Harness
79
79
48
Battery
Cover
5
Left Wire
110
Right Wire
111
79
6
15. Attach the Left and Right Upright Covers (10, 64)
to the Upright (6) with four M4 x 16mm
Screws (86).
16. Make sure that all parts of the elliptical exerciser are properly tightened. Note: Some hardware may be
left over after assembly is completed. To protect the floor or carpet from damage, place a mat under the
elliptical exerciser.
15
86
10
64
6
86
11
HOW TO USE THE ELLIPTICAL EXERCISER
HOW TO MOVE THE ELLIPTICAL EXERCISER
Due to the size and weight of the elliptical exerciser, moving it requires two persons. Stand in front of
the elliptical exerciser, hold the upright, and place one
foot against one of the front wheels. Pull on the
upright and have a second person lift the base until
the elliptical exerciser will roll on the front wheels.
Carefully move the elliptical exerciser to the desired
location, and then lower it to the floor.
Pull on
upright
Place
your foot
here
HOW TO EXERCISE ON THE ELLIPTICAL
EXERCISER
To mount the elliptical exerciser, hold the handlebars
and step onto the pedal that is in the lower position.
Then, step onto the other pedal. Push the pedals until
they begin to move with a continuous motion. Note:
The crank arm covers can turn in either direction.
It is recommended that you turn the crank arm
covers in the direction shown by the arrow below;
however, for variety, you can turn the crank arm
covers in the opposite direction.
Handlebars
Lift here
HOW TO LEVEL THE ELLIPTICAL EXERCISER
If the elliptical
exerciser
rocks slightly
on your floor
during use,
turn one or
both of the leveling feet
beneath the
base or
beneath the front stabilizer until the rocking motion is
eliminated.
Leveling
Feet
Crank Arm
Cover
To dismount the elliptical exerciser, wait until the pedals come to a complete stop. Note: The elliptical
exerciser does not have a free wheel; the pedals
will continue to move until the flywheel stops.
When the pedals are stationary, step off the higher
pedal first. Then, step off the lower pedal.
Pedals
12
ONSOLE DIAGRAM
C
FEATURES OF THE CONSOLE
The revolutionary console offers an array of features
designed to make your workouts more effective and
enjoyable. When you use the manual mode of the
console, you can change the resistance of the pedals
with the touch of a button. While you exercise, the
console will display continuous exercise feedback. You
can also measure your heart rate using the handgrip
pulse sensor.
Interactive Cross Trainer Programs
The console features nine interactive cross trainer programs designed to help you to burn calories and
develop your cardiovascular system while toning and
strengthening your muscles. The cross trainer programs automatically control the resistance of the pedals and prompt you to perform a variety of strength
exercises during your workout. Choose an upper body,
lower body, or total body cross trainer program to
focus your workout. Note: The strength exercises
require the use of dumbbells and an inflatable exercise ball (not included). To purchase dumbbells or
an exercise ball, call the toll-free telephone number on the front cover of this manual.
Smart Programs
In addition, the console offers three smart programs.
Each program automatically changes the resistance of
the pedals and prompts you to vary your pedaling
pace as it guides you through an effective workout.
Heart Rate Programs
The console also offers two heart rate programs that
automatically control the resistance of the pedals and
prompt you to maintain a constant pedaling pace to
keep your heart rate near target heart rate settings during your workouts.
Interactive Games
The console features two motivational interactive
games. Using the dual game controllers, play the challenging Fat Blocker™ game or the fast-paced Calorie
Destroyer™ game during your workouts—the harder
you exercise, the greater the advantage you will have!
The console keeps track of the four highest scores for
each game—compete with other users or try to top
your own high score.
Stereo Sound System
You can even connect your MP3 player or CD player
to the consoleʼs stereo sound system and listen to
your favorite music or audio books while you exercise.
To use the manual mode of the console, follow the
steps beginning on page 14. To use a cross trainer
program, see page 15. To use a smart program,
see page 17. To use a heart rate program, see page
18. To play the Fat Blocker game, see page 19. To
play the Calorie Destroyer game, see page 20. To
use the stereo sound system, see page 21.
13
OW TO USE THE MANUAL MODE
H
Note: If there is a sheet of clear plastic on the face
f the console, remove the plastic.
o
Begin pedaling or press any button on the
1
console to turn on the console.
moment after you begin pedaling or press a
A
button, the display will light.
Select the manual mode.
2
Each time you
turn on the console, the manual
mode will be
selected. If you
have selected a
program, reselect
the manual mode by pressing either of the
Programs buttons repeatedly until the words MANUAL MODE appear in the lower left corner of the
display.
Follow your progress with the display.
4
The upper left corner of the display will show
the elapsed time. Note: When a program is selected, the display will show the time remaining in the
rogram instead of the elapsed time.
p
The lower left corner of the display will show
the distance, in total revolutions, you have pedaled.
Change the resistance of the pedals as
3
desired.
As you pedal,
change the resistance of the pedals by pressing
any of the Quick
Resistance
buttons numbered 1 through 12. Note: After you press the buttons, it will take a moment for the pedals to reach
the selected resistance level.
The upper right corner of the display will show
the approximate number of calories you have
burned. The upper right corner of the display will
also show your heart rate when you use the handgrip pulse sensor (see step 5 on page 15).
The lower right corner of the display will show
your pedaling pace in revolutions per
minute (rpm).
The center of the display will show the resistance setting of the pedals for a few seconds each
time the resistance setting changes.
You can also view selected information at a larger
size. Press the Display button repeatedly to view
time and distance information, time and calorie
information, or time and pace information. Press
the Display button again to view all information. To
reset the display information, press the
Start/Reset button.
The console has three backlight options. The “On”
option keeps the backlight on while the console is
on. To conserve the batteries, the “Auto” option
keeps the backlight on only while you are pedaling. The “Off” option turns the backlight off. To
select a backlight option, first press and hold down
the Certified Personal Trainer Programs button for
several seconds. Next, press the increase button
to select the desired backlight option. Then, press
the Certified Personal Trainer Programs button to
save your selection.
14
Measure your heart rate if desired.
If there are
sheets of clear
plastic on the
etal contacts
m
on the handgrip
ulse sensor,
p
remove the plastic. To measure
your heart rate,
hold the handgrip
pulse sensor with
your palms resting against the metal contacts.
Avoid moving your hands or gripping the contacts too tightly.
When your pulse is detected, one, two, or three
dashes will appear in the display, and then your
heart rate will appear. For the most accurate heart
rate reading, hold the contacts for at least 15 seconds. Note: If you continue to hold the handgrip
pulse sensor, the display will show your heart rate
for up to 30 seconds.
If the display does not show your heart rate, make
sure that your hands are positioned as described.
Be careful not to move your hands excessively or
to squeeze the metal contacts too tightly. For optimal performance, clean the metal contacts using
a soft cloth; never use alcohol, abrasives, or
chemicals to clean the contacts.
ontacts
C
OW TO USE A CROSS TRAINER PROGRAM
H
Begin pedaling or press any button on the
console to turn on the console.
A moment after you begin pedaling or press a
utton, the display will light.
b
Select a cross trainer program.
To select one of
the nine cross
trainer programs,
press the
Interactive Cross
Trainer Programs
button repeatedly
until Program 1, 2,
3, 4, 5, 6, 7, 8, or 9 appears in the display. The
program time and a profile of the resistance settings for the program will also appear in the display.
After a moment, the voice of a personal trainer
will welcome you to the program and guide you
through the workout. To adjust the volume level of
the speakers, press the increase and decrease
buttons until the desired volume level is selected.
There are five volume levels.
Begin pedaling to start the program.
Profile
Turn on the fan if desired.
To turn on the fan at low speed, press the Fan
button once. To turn on the fan at high speed,
press the Fan button a second time. To turn off
the fan, press the Fan button a third time.
When you are finished exercising, the console
will turn off automatically.
If the pedals do not move for several seconds, a
tone will sound and the console will pause. If the
pedals do not move for several minutes and the
buttons are not pressed, the console will turn off
and the display will be reset.
Each program is divided into either 30 or 45 oneminute segments. One resistance setting and one
target rpm (pace) setting are programmed for
most segments. (Note: The same resistance
and/or target rpm setting may be programmed for
two or more consecutive segments.) During other
segments, the console will prompt you to perform
strength exercises.
The resistance setting and the target rpm for the
first segment will appear in the center of the display for a few seconds. The resistance setting will
then be indicated by the height of the flashing column of the profile in the display. The resistance
settings for the next several segments will be indicated by the heights of the columns to the right of
the flashing column.
When the first segment of the program ends, the
resistance setting and the target rpm for the second segment will appear in the center of the display for a few seconds to alert you. The entire
profile will then shift one column to the left, and
the pedals will automatically adjust to the resistance setting for the second segment.
15
As you exercise,
you will be
prompted to keep
our pedaling
y
pace near the tar-
et rpm setting for
g
the current segment. When an upward arrow appears in the display, increase your pace. When a downward
arrow appears in the display, decrease your pace.
When no arrows appear, maintain your current
pace.
Important: The target rpm settings are intended only to provide motivation. Your actual
pace may be slower than the target rpm settings. Make sure to exercise at a pace that is
comfortable for you.
If the resistance setting for the current segment is
too high or too low, you can manually override the
setting by pressing the Quick Resistance buttons.
Important: When the current segment of the
program ends, the pedals will automatically
adjust to the resistance setting for the next
segment.
Perform the first strength exercise when
4
prompted.
When the first strength exercise segment begins,
the name of the first strength exercise will appear
in the display for a few seconds. The time will
pause and flash in the display.
Note: Refer to the accompanying exercise chart
to see the correct form for each exercise. When
performing lunges, alternate legs with each repe-
ition. When performing dumbbell rows, perform
t
half the repetitions with your right arm and half
he repetitions with your left arm. The strength
t
exercises require the use of dumbbells and an
inflatable exercise ball (not included). To pur-
chase dumbbells or an exercise ball, call the
toll-free telephone number on the front cover
of this manual.
Continue the cross trainer program.
5
When you have performed the recommended
number of repetitions, the words START STRIDING will appear in the display. To continue the
cross trainer program, step onto the exerciser and
start pedaling. The pedals will automatically
adjust to the resistance setting for the next segment.
The program will continue in this way until the last
segment ends. To stop the program at any time,
stop pedaling. A tone will sound and the time will
begin to flash in the display. To restart the program, simply resume pedaling.
Follow your progress with the display.
6
See step 4 on page 14.
Measure your heart rate if desired.
7
See step 5 on page 15.
Step off the elliptical exerciser and prepare to
begin the first strength exercise. Perform repetitions of the exercise as directed by the personal
trainer. Exercise with a slow, steady motion; do
not perform more than one repetition during each
interval indicated by the personal trainer. The display will also count the repetitions as you perform
them.
16
Turn on the fan if desired.
8
See step 6 on page 15.
When you are finished exercising, the console
9
will turn off automatically.
See step 7 on page 15.
OW TO USE A SMART PROGRAM
H
Begin pedaling or press any button on the
console to turn on the console.
A moment after you begin pedaling or press a
utton, the display will light.
b
Select a smart program.
To select one of
the three smart
programs, press
the Certified
Personal Trainer
Programs button
repeatedly until
Program 1, 2, or
3 appears in the display. The program time and a
profile of the resistance settings for the program
will also appear in the display.
Begin pedaling to start the program.
Each program is divided into 20, 30, or 45 oneminute segments. One resistance setting and one
target rpm (pace) setting are programmed for
each segment. Note: The same resistance and/or
target rpm setting may be programmed for two or
more consecutive segments.
Profile
your pedaling
pace near the target rpm setting for
he current seg-
t
ment. When an
pward arrow
u
appears in the display, increase your pace. When a downward
arrow appears in the display, decrease your pace.
When no arrows appear, maintain your current
pace.
Important: The target rpm settings are intended only to provide motivation. Your actual
pace may be slower than the target rpm settings. Make sure to exercise at a pace that is
comfortable for you.
If the resistance setting for the current segment is
too high or too low, you can manually override the
setting by pressing the Quick Resistance buttons.
Important: When the current segment of the
program ends, the pedals will automatically
adjust to the resistance setting for the next
segment.
The program will continue in this way until the last
segment ends. To stop the program at any time,
stop pedaling. A tone will sound and the time will
begin to flash in the display. To restart the program, simply resume pedaling.
The resistance setting and the target rpm for the
first segment will appear in the center of the display for a few seconds. The resistance setting will
then be indicated by the height of the flashing column of the profile in the display. The resistance
settings for the next several segments will be indicated by the heights of the columns to the right of
the flashing column.
When the first segment of the program ends, the
resistance setting and the target rpm for the second segment will appear in the center of the display for a few seconds to alert you. The entire
profile will then shift one column to the left, and
the pedals will automatically adjust to the resistance setting for the second segment.
As you exercise, you will be prompted to keep
Follow your progress with the display.
See step 4 on page 14.
Measure your heart rate if desired.
See step 5 on page 15.
Turn on the fan if desired.
See step 6 on page 15.
When you are finished exercising, the console
will turn off automatically.
See step 7 on page 15.
17
OW TO USE A HEART RATE PROGRAM
H
Begin pedaling to turn on the console.
1
A moment after you turn on the console, the display will light.
Select a heart rate program.
2
To select one of the two heart rate program, press
the Certified Personal Trainer Programs button
repeatedly until Heart Rate 1 or 2 appears in the
display. The program time and a profile of the target heart rate settings for the program will also
appear in the display.
Enter a target heart rate setting.
3
When you select a
heart rate program, the maximum target heart
rate setting will
flash in the center
of the display. If
desired, use the
increase and decrease buttons to change the
maximum target heart rate setting, and then press
the Enter button. Note: If you change the maximum target heart rate setting, the intensity level
of the entire program will change.
Hold the handgrip pulse sensor.
4
It is not necessary to hold the handgrip pulse sensor continuously during a heart rate program;
however, you should hold the handgrip pulse sensor frequently for the program to operate properly.
Each time you hold the handgrip pulse sensor, keep your hands on the metal contacts
for at least 30 seconds.
Begin pedaling to start the program.
5
Each heart rate program is divided into either 20 or
30 one-minute segments. One target heart rate
setting is programmed for each segment. Note:
The same target heart rate setting may be programmed for two or more consecutive segments.
The target heart rate setting for the first segment
will be indicated by the height of the flashing column of the profile in the display. The target heart
rate settings for the next several segments will be
indicated by the heights of the columns to the
right of the flashing column.
When the first segment of the program ends, the
entire profile will shift one column to the left. The
target heart rate setting for the second segment
ill then be shown in the flashing column of the
w
profile.
As you pedal, the console will regularly compare
your heart rate to the target heart rate setting. If
your heart rate is too far below or above the target
heart rate setting, the resistance of the pedals will
automatically increase or decrease to bring your
heart rate closer to the target heart rate setting.
You will also be
prompted to pedal
at a steady pace.
When an upward
arrow appears in
the display,
increase your
pace. When a downward arrow appears in the
display, decrease your pace. When no arrows
appear in the display, maintain your current pace.
Important: Make sure to exercise at a pace
that is comfortable for you. Note: You can man-
ually override the resistance settings; however,
you may not maintain the target heart rate. Also,
when the console compares your heart rate to the
target heart rate setting, the resistance of the
pedals may automatically increase or decrease to
bring your heart rate closer to the target heart
rate setting.
The program will continue in this way until the last
segment ends. To stop the program at any time,
stop pedaling. A tone will sound and the time will
begin to flash in the display. To restart the program, simply resume pedaling.
Follow your progress with the display.
6
See step 4 on page 14.
Measure your heart rate if desired.
7
See step 5 on page 15.
Turn on the fan if desired.
8
See step 6 on page 15.
When you are finished exercising, the console
9
will turn off automatically.
See step 7 on page 15.
18
OW TO PLAY THE FAT BLOCKER GAME
H
The Fat Blocker game requires quick thinking and fast
reflexes. In addition to the console buttons, you will
use the four-button game controllers on the handlebar
to play the game. Follow the steps below to play the
Fat Blocker game.
Begin pedaling or press any button on the
console to turn on the console.
A moment after you begin pedaling or press a
button, the display will light.
Select the Fat Blocker game.
To select the Fat Blocker game, press the Fat
Blocker button. The words FAT BLOCKER will
appear at the top of the display.
Pedal to start the game.
When you start the Fat Blocker game, a game
arena will appear in the center of the display.
Your goal is to
maneuver the
blocks so that they
orm a complete
f
row of black
quares across
s
the entire arena.
Each time you complete a row of black squares,
the row will disappear, and all blocks above will
move downward one row.
As you play, the blocks will fall faster and faster;
however, your pedaling pace will affect the speed
of the blocks—the faster you pedal, the more
slowly the blocks will fall, giving you extra time to
position and orient the blocks. The game will continue until any part of a stacked block reaches the
top of the arena.
When the game ends, the display will show your
final score and the level of play that you reached.
The display will then show the four highest scores
recorded since the scores were reset. If desired,
press and hold down the right button on either
controller to reset the scores. Note: If your score
is one of the four highest, the display will prompt
you to enter a name consisting of three letters or
digits. While the line below the first letter is flashing, press the up and down buttons on either controller to select the desired letter or digit. Next,
press the right button on either controller and
select another letter or digit. Repeat this process
to select a third letter or digit. Then, press the
right button on either controller again. The display
will then show the four highest scores recorded
since the scores were reset.
Complete Row
A block composed of four or five black squares
will slowly move downward until it reaches the
bottom of the arena. Another block will then move
downward. There are blocks of eight different
shapes. As each block falls, you can move it to
the left or right using the left and right buttons on
the left controller. In addition, you can rotate the
block counterclockwise or clockwise using the left
and right buttons on the right controller. Once you
have positioned and oriented a block, you can
speed its motion to the bottom of the arena, if
desired, by pressing the down button on either
controller.
Follow your progress with the display.
While you exercise and play the Fat Blocker
game, the corners of the display will show the
elapsed time, the approximate number of calories
you have burned, and your pedaling pace. In addition, the display will show your current score and
the game level that you have reached.
To pause the game, press the Display button. To
resume the game, press the Display button
repeatedly until the words FAT BLOCKER appear
at the top of the display, and then begin pedaling.
When you are finished exercising, the console
will turn off automatically.
See step 7 on page 15.
19
OW TO PLAY THE CALORIE DESTROYER GAME
H
The Calorie Destroyer game is a fast-paced game that
pits you against a squadron of laser-firing drones. In
addition to the console buttons, you will use the fourbutton game controllers on the handlebar to play the
game. Follow the steps below to play the Calorie
estroyer game.
D
Begin pedaling or press any button on the
1
console to turn on the console.
Between the drones and the laser blaster are five
shields. You can hide the laser blaster below a
shield if desired. However, each time a shield is
it by a laser, a piece will be vaporized.
h
our goal is to keep the laser blaster from being
Y
hit and to keep any drone from reaching the bottom of the arena. If the laser blaster is hit, it will
be disabled and another laser blaster will appear
in its place; there are a total of four laser blasters.
If you vaporize the entire squadron of drones, a
new squadron will appear.
A moment after you begin pedaling or press a
button, the display will light.
Select the Calorie Destroyer game.
2
To select the Calorie Destroyer game, press the
Calorie Destroyer button. The word DESTROYER
will appear at the top of the display.
Pedal to start the game.
3
When you start the Calorie Destroyer game, a
game arena will appear in the display. Three rows
of drones will begin to move across the top of the
arena, periodically firing their lasers downward.
Each time the drones reach the left or right side
of the arena, they will reverse direction and move
downward.
As you play, the drones will move faster and
faster. The game will continue until all four laser
blasters are disabled or a drone reaches the bottom of the arena.
When the game ends, the display will show the
level of play that you reached and your final
score. The display will then show the four highest
scores recorded since the scores were reset. If
desired, press and hold down the right button on
either controller to reset the scores. Note: If your
score is one of the four highest, the display will
prompt you to enter a name consisting of three
letters or digits. While the line below the first letter
is flashing, press the up and down buttons on
either controller to select the desired letter or
digit. Next, press the right button on either controller and select another letter or digit. Repeat
this process to select a third letter or digit. Then,
press the right button on either controller again.
The display will then show the four highest scores
recorded since the scores were reset.
Follow your progress with the display.
4
While you exercise and play the Calorie Destroyer
game, the upper left corner of the display will
show the elapsed time. In addition, the display will
show the game level that you have reached and
your current score.
At the bottom of the arena is a laser blaster. You
can fire the laser blaster at the drones by pressing the up button on either controller. In addition,
while you are pedaling, you can move the laser
blaster to the left or right using the left and right
buttons on either controller. The faster you pedal,
the faster the laser blaster will move.
20
To pause the game, press the Display button. To
resume the game, press the Display button
repeatedly until the word DESTROYER appears at
the top of the display, and then begin pedaling.
When you are finished exercising, the console
5
will turn off automatically.
See step 7 on page 15.
OW TO USE THE STEREO SOUND SYSTEM
H
o play your own music or audio books through the
T
consoleʼs stereo sound system while you exercise,
irst locate the jack under the ledge on the console.
f
Plug an audio cable (not included) into the jack on the
console and into a jack on your MP3 player or CD
player; make sure that the audio cable is fully
lugged in.
p
Next, press the play button on your MP3 player or CD
player. Adjust the volume of the speakers using the
volume control on your MP3 player or CD player.
MAINTENANCE AND TROUBLESHOOTING
Inspect and tighten all parts of the elliptical exerciser
regularly. Replace any worn parts immediately.
To clean the elliptical exerciser, use a damp cloth and
a small amount of mild soap. Make sure to regularly
clean the rollers and the track on which the rollers
ride. Important: To avoid damage to the console,
keep liquids away from the console and keep the
console out of direct sunlight.
CONSOLE TROUBLESHOOTING
If the console display becomes dim, the batteries
should be replaced; most console problems are the
result of low batteries. See assembly step 13 on page
11 for replacement instructions.
HANDGRIP PULSE SENSOR TROUBLESHOOTING
If the console does not display your heart rate when
you hold the handgrip pulse sensor, or if the displayed
heart rate appears to be too high or too low, see step
5 on page 15.
HOW TO LEVEL THE ELLIPTICAL EXERCISER
belt, first remove the screws from the left and right
side shields (not shown). Note: There are two different
sizes of screws in the side shields. Be sure to note the
location of each screw. Then, gently pull the side
shields apart and remove the convenience tray.
Next, locate the Idler Screw (68) and loosen it one half
turn. Step onto the elliptical exerciser and move the
pedals. If the pedals continue to slip, turn the Idler
Screw another half turn and test the pedals again.
Continue in this way until the pedals no longer slip.
Then, replace the convenience tray and reattach the
side shields.
If the elliptical exerciser rocks slightly on your floor
during use, see HOW TO LEVEL THE ELLIPTICAL
EXERCISER on page 12.
HOW TO ADJUST THE DRIVE BELT
If the pedals slip while you are pedaling, even while
the resistance is adjusted to the highest setting, the
drive belt may need to be adjusted. To adjust the drive
68
21
EXERCISE GUIDELINES
WARNING: B
this or any exercise program, consult your
physician. This is especially important for
persons over the age of 35 or persons with
pre-existing health problems.
The pulse sensor is not a medical device.
Various factors may affect the accuracy of
heart rate readings. The pulse sensor is
intended only as an exercise aid in determining heart rate trends in general.
These guidelines will help you to plan your exercise
program. For detailed exercise information, obtain a
reputable book or consult your physician. Remember,
proper nutrition and adequate rest are essential for
successful results.
EXERCISE INTENSITY
Whether your goal is to burn fat or to strengthen your
cardiovascular system, exercising at the proper intensity is the key to achieving results. You can use your
heart rate as a guide to find the proper intensity level.
The chart below shows recommended heart rates for
fat burning and aerobic exercise.
efore beginning
ody uses carbohydrate calories for energy. Only after
b
the first few minutes of exercise does your body begin
to use stored fat calories for energy. If your goal is to
burn fat, adjust the intensity of your exercise until your
eart rate is near the lowest number in your training
h
zone. For maximum fat burning, exercise with your
heart rate near the middle number in your training
zone.
Aerobic Exercise—If your goal is to strengthen your
cardiovascular system, you must perform aerobic
exercise, which is activity that requires large amounts
of oxygen for prolonged periods of time. For aerobic
exercise, adjust the intensity of your exercise until
your heart rate is near the highest number in your
training zone.
WORKOUT GUIDELINES
Warming up—Start with 5 to 10 minutes of stretching
and light exercise. A warm-up increases your body
temperature, heart rate, and circulation in preparation
for exercise.
Training Zone Exercise—Exercise for 20 to 30 minutes with your heart rate in your training zone. (During
the first few weeks of your exercise program, do not
keep your heart rate in your training zone for longer
than 20 minutes.) Breathe regularly and deeply as you
exercise–never hold your breath.
To find the proper intensity level, find your age at the
bottom of the chart (ages are rounded off to the nearest ten years). The three numbers listed above your
age define your “training zone.” The lowest number is
the heart rate for fat burning, the middle number is the
heart rate for maximum fat burning, and the highest
number is the heart rate for aerobic exercise.
Burning Fat—To burn fat effectively, you must exercise at a low intensity level for a sustained period of
time. During the first few minutes of exercise, your
Cooling down—Finish with 5 to 10 minutes of
stretching. Stretching increases the flexibility of your
muscles and helps to prevent post-exercise problems.
EXERCISE FREQUENCY
To maintain or improve your condition, complete three
workouts each week, with at least one day of rest
between workouts. After a few months of regular exercise, you may complete up to five workouts each
week, if desired. Remember, the key to success is to
make exercise a regular and enjoyable part of your
everyday life.
22
STRENGTH TRAINING GUIDELINES
During strength exercises, you must maintain proper
orm for the best results. Maintaining proper form
f
involves moving through the full range of motion for
ach exercise and moving only the appropriate parts
e
of the body. Exercising in an uncontrolled manner will
reduce the benefits of strength exercises. On the exercise chart accompanying this manual are photographs
showing the correct form for several strength exercises.
Perform each repetition of each strength exercise
smoothly and without pausing. The exertion phase of
each repetition should last only about half as long as
the return phase. Proper breathing is also important.
Exhale during the exertion phase of each repetition
and inhale during the return phase—never hold your
breath.
To increase the size and strength of your muscles, you
must work your muscles at a level close to their maximum capacity. Your muscles will adapt and grow as
ou progressively increase the amount of weight that
y
you use. You can tone your muscles by working them
t a moderate percentage of their capacity. The proper
a
amount of weight to use for each strength exercise
depends on you—you must gauge your limits and
select an appropriate amount of weight.
It is important to avoid overdoing it during the first few
months of your exercise program. Progress at your
own pace and be sensitive to your bodyʼs signals. If
you experience pain or dizziness at any time while
exercising, stop immediately and cool down. Find out
what is wrong before continuing. Remember that adequate rest and a proper diet are important factors in
any exercise program.
23
PART LIST—Model No. PFEL7806.0 R0809A
Key No. Qty. Description Key No. Qty. Description
1
21Frame
3
42Inner Crank Arm Cover
51Console
61Upright
72Roller Cover
81Left Handlebar
91Right Handlebar
10 1 Left Upright Cover
11 2 Handlebar Leg
12 1 Left Roller Leg
13 1 Left Pedal
14 1 Left Pedal Leg
15 1 Right Pedal
16 1 Right Pedal Leg
17 2 Frame Cover
18 2 Inner Handlebar Cover
19 2 Outer Handlebar Cover
20 2 Axle Bearing
21 1 Right Roller Leg
22 2 Roller
23 2 Stabilizer Endcap
24 2 Roller Axle
25 2 Wheel
26 4 Leveling Foot
27 4 Wheel Bearing
28 1 Left Side Shield
29 1 Right Side Shield
30 2 Crank Axle Cap
31 4 Axle Cap
32 4 Pedal Leg Axle
33 8 Axle Bushing
34 4 Roller Bushing
35 1 Front Stabilizer
36 2 Crank Arm
37 1 Convenience Tray
38 2 Crank Hub
39 1 Pulley Spacer
40 1 Pulley
41 12 Axle Bushing
42 2 Pedal Leg Endcap
43 1 Crank Sleeve
44 2 Crank Bearing Set
45 1 Crank
46 8 Round Inner Cap
47 4 Snap Ring
48 1 Wire Harness
49 2 Base Endcap
50 1 Reed Switch/Wire
1 Base
2 Outer Crank Arm Cover
1 1 Belt
5
52 1 Flywheel
3 1 “C” Magnet
5
54 2 Outer Bearing Set
55 1 Magnet
56 1 Spring
57 1 Idler
58 1 Flywheel Pulley
59 1 Clamp
60 2 Inner Bearing Set
61 1 Motor
62 1 Resistance Cable Pulley
63 1 Resistance Cable Set
64 1 Right Upright Cover
65 1 Pivot Axle
66 2 Hub Cover
67 1 Stop Screw
68 1 Idler Screw
69 1 M8 Flange Screw
70 4 M8 x 35mm Screw
71 4 M8 x 42mm Bolt
72 4 M8 Split Washer
73 4 M4 x 12mm Flange Screw
74 8 M8 x 25mm Screw
75 2 3/8" Flange Screw
76 2 Control Grip
77 2 Pivot Bushing
78 2 Game Controller
79 37 M4 x 16mm Self-tapping Screw
80 8 M10 x 23mm Shoulder Screw
81 2 M10 x 20mm x 1mm Washer
82 4 M8 x 16mm Patch Screw
83 4 M8 x 25mm Washer
84 2 M10 x 20mm x 1.5mm Washer
85 10 M4 x 12mm Screw
86 10 M4 x 16mm Screw
87 8 M6 x 35mm Phillips Screw
88 8 M6 Split Washer
89 2 M10 x 62mm Bolt
90 2 M10 x 78mm Button Screw
91 4 M10 x 20mm Button Screw
92 4 M10 x 20mm x 2mm Washer
93 2 M4 x 13mm Washer
94 4 M10 x 25mm Washer
95 3 M8 x 16mm Button Screw
96 6 M8 Nylon Locknut
97 2 M10 Nylon Locknut
98 8 Wave Washer
99 4 M8 x 15mm x 4.5mm Washer
100 3 Star Washer
24
ey No. Qty. Description Key No. Qty. Description
K
101 2 M4 x 10mm Screw
02 1 Rear Base Cover
1
103 2 Side Base Cover
104 1 Center Base Cover
105 1 Left Frame Cover
06 1 Right Frame Cover
1
107 4 M8 x 75mm Button Screw
08 1 Left Handlebar Wire
1
Note: Specifications are subject to change without notice. See the back cover of this manual for information
about ordering replacement parts. *Indicates a non-illustrated part.
109 1 Right Handlebar Wire
10 1 Left Controller Wire
1
111 1 Right Controller Wire
112 1 M4 x 12mm Bright Screw
*4Hex Key
*
*1Userʼs Manual
1 Grease
25
EXPLODED DRAWING A—Model No. PFEL7806.0 R0809A
3
4
36
38
39
43
66
74
74
75
85
70
70
3
38
44
45
47
66
36
74
74
75
52
55
47
4
85
96
68
57
23
26
26
35
25
97
89
97
89
25
23
90
11
18
19
33
33
41
41
79
79
81
80
71
96
93
98
98
9
53
79
59
67
20
62
96
58
20
69
47
56
63
48
51
5
26
26
49
49
6
2
8
11
18
19
33
33
41
79
79
80
81
71
96
93
98
41
47
50
61
73
73
17
77
77
95
100
100
95
95
86
98
79
17
86
86
65
86
78
76
76
78
101
101
79
79
86
86
10
64
79
102
79
79
79
79
79
79
79
79
79
79
72
72
107
107
103
1
104
106
44
103
105
112
99
99
99
40
109
108
111
110
26
85
27
27
34
34
7
24
82
83
82
83
91
94
98
30
54
60
80
84
98
88
88
87
87
87
88
46
46
15
41
41
16
33
31
80
92
31
32
80
92
37
29
86
86
79
79
79
24
83
82
85
22
27
27
34
34
82
83
7
32
41
41
94
91
98
30
54
60
12
80
84
98
46
46
88
88
87
87
42
88
46
88
87
41
41
94
91
13
31
31
32
33
33
80
80
92
92
14
91
94
42
28
21
41
32
41
22
85
85
79
79
EXPLODED DRAWING B—Model No. PFEL7806.0 R0809A
27
ORDERING REPLACEMENT PARTS
To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to
provide the following information when contacting us:
• the model number and serial number of the product (see the front cover of this manual)
• the name of the product (see the front cover of this manual)
• the key number and description of the replacement part(s) (see the PART LIST and the EXPLODED
DRAWING near the end of this manual)
LIMITED WARRANTY
ICON Health & Fitness, Inc. (ICON) warrants this product to be free from defects in workmanship and
material, under normal use and service conditions, for a period of ninety (90) days from the date of purchase. There is a lifetime warranty on the frame. This warranty extends only to the original purchaser.
ICON's obligation under this warranty is limited to replacing or repairing, at ICON's option, the product
through one of its authorized service centers. All repairs for which warranty claims are made must be preauthorized by ICON. If the product is shipped to a service center, freight charges to and from the service
center will be the customerʼs responsibility. For in-home service, the customer will be responsible for a
minimal trip charge. This warranty does not extend to any product or damage to a product caused by or
attributable to freight damage, abuse, misuse, improper or abnormal usage or repairs not provided by an
ICON authorized service center; products used for commercial or rental purposes; or products used as
store display models. No other warranty beyond that specifically set forth above is authorized by ICON.
ICON is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the product or damages with respect to any economic loss, loss
of property, loss of revenues or profits, loss of enjoyment or use, costs of removal or installation or other
consequential damages of whatsoever nature. Some states do not allow the exclusion or limitation of incidental or consequential damages. Accordingly, the above limitation may not apply to you.
The warranty extended hereunder is in lieu of any and all other warranties and any implied warranties of
merchantability or fitness for a particular purpose is limited in its scope and duration to the terms set forth
herein. Some states do not allow limitations on how long an implied warranty lasts. Accordingly, the above
limitation may not apply to you.
This warranty gives you specific legal rights. You may also have other rights which vary from state to state.
ICON HEALTH & FITNESS, INC., 1500 S. 1000 W., LOGAN, UT 84321-9813
Part No. 243571 R0809A Printed in China © 2009 ICON IP, Inc.
Loading...
