Page 1
Powered Floor Standing &
Passive Architectural Subwoofers
Page 2
Powered Subwoofers
The new Proficient Protege subwoofers step up with more power, more deep
bass and a whole lot more pop for music and movie lovers. They offer as much
as +10dB more deep bass output than similar sized subwoofers on the market.
That’s more than you’d get by adding a second sub!
FS12
Powered 12" Floor Standing Sub
Woofers: Two 12" Polypropylene- Coated Fiber Composite
One Front-Firing Active; One Down- Firing Passive
Amplifier Type: Class D Amp
Power Rating Continuous: 300 Watts RMS
Power Rating Peak: 600 Watts Peak
Frequency Response: 28Hz - 150Hz
Subwoofer Output: 106dB SPL
Inputs: Left & Right Line Level, LFE
Outputs: Line Level High-Pass
Phase Switch: 0 - 180˚
Crossover: 50 Hz - 150Hz; Bypass
Additional Features: Auto On, Anti-Clipping Circuitry
Cabinet: Black Wood Grain with Dampened Rubber Feet
Dimensions: H 16⁄" x W 14½" x D 15½"
FS10
Powered 10" Floor Standing Sub
Woofers: Two 10" Polypropylene-Coated Fiber Composite
One Front-Firing Active; One Down- Firing Passive
Amplifier Type: Class D Amp
Power Rating Continuous: 250 Wat ts RMS
Power Rating Peak: 500 Watts Peak
Frequency Response: 30Hz - 150Hz
Subwoofer Output: 103dB SPL
Inputs: Left & Right Line Level, LFE
Outputs: Line Level High-Pass
Phase Switch: 0 - 180˚
Crossover: 50 Hz - 150Hz; Bypass
Additional Features: Auto On, Anti-Clipping Circuitry
Cabinet: Black Wood Grain with Dampened Rubber Feet
Dimensions: H 15⁄" x W 13¼" x D 14"
Each of the new Proficient Protege models features a powerful Class D amp, a
rugged composite-cone woofer and a down-firing passive radiator that really
brings out the ultra-deep bass notes. With line & LFE in, high-pass line out, volume,
crossover and phase controls, these subs will hook up with almost any system.
FS8
Powered 8" Floor Standing Sub
Woofers: Two 8" Polypropylene-Coated Fiber Composite
One Front-Firing Active; One Down- Firing Passive
Amplifier Type: Class D Amp
Power Rating Continuous: 200 Watts RMS
Power Rating Peak: 400 Watts Peak
Frequency Response: 32Hz - 150Hz
Subwoofer Output: 100dB SPL
Inputs: Left & Right Line Level, LFE
Outputs: Line Level High-Pass
Phase Switch: 0 - 180˚
Crossover: 50 Hz - 150Hz; Bypass
Additional Features: Auto On, Anti-Clipping Circuitry
Cabinet: Black Wood Grain with Dampened Rubber Feet
Dimensions: H 13⁄" x W 11¾" x D 12½"
Page 3
Architectural Subwoofers
If you want massive bass but don’t have the space, you want Proficient Protege
architectural subs. They mount flush into walls and ceilings and with our thinbezel design, you barely see them. But you'll definitely feel them. Our flagship is
a dual 8-inch inwall that really pumps out the deepest notes distortion-free.
M3
Amp/Crossover
Designed for ICS11, IWS105 & IWS85 Subwoofers
180 Watt High Current Mono Amp with Crossover
Variable Low Pass Crossover: 35Hz - 150Hz
LFE Input & Pass Through Output
Remote Power-On Switching via Signal Sensing
Includes Bolt-On Rack Ears
Dimensions: H 4" x W 17⁄" x D 12⁄"
Proficient Protege architectural subwoofers are designed to work with our M3. It's a
180 watt high-current mono amp/crossover that delivers the power you need to
rock any house. These subs are the best and easiest way to get high-impact bass
with zero impact on interior design.
I C S11
Passive 10" Ceiling Sub
Replaces ICS10 Ceiling Sub
Woofer: 10" Long Excursion Graphite Cone
Power Handling: 175 Watts RMS
Frequency Response: 30Hz - 120Hz
Includes Thin-Bezel Grille with Neo Magnets
Dimensions: Diameter 13⁄" x Depth 6½"
Ceiling Cut Out: Diameter 11⁄"
IWS10 5
Passive 10" Inwall Sub
Replaces IWS100 Inwall Sub
Woofer: 10" Long Excursion Treated Paper Cone
w/Inverted Ferrite Magnet Structure
Power Handling: 250 Watts RMS
Frequency Response: 36Hz - 150Hz
Includes Thin-Bezel Grille with Neo Magnets
Dimensions: H 13⁄" x W 13⁄" x D 3¾"
Wall Cut Out: H 12⁄" x W 12⁄"
IWS85
Passive Dual 8" Inwall Sub
Replaces IWS82 Inwall Sub
Woofers: Two 8" Long E xcursion Graphite Cones
Power Handling: 200 Watts RMS
Frequency Response: 30Hz - 120Hz
Includes Thin-Bezel Grille with Neo Magnets
Dimensions: H 20" x W 11⁄" x D 3½"
Wall Cut Out: H 18½" x W 9¾"
Page 4
1800 S McDowell Blvd • Petaluma, CA 94954 • 800.472.5555 • Fax 707.283.5901 • proficientaudio.com
©2015 Core Brands, LLC. All rights reser ved. Prof icient® is a registered trademark of Core Brands, LLC, a Nortek company.
SB0415
