Professional Series PS77692 User Manual
Jug Kettle
User Manual
PS77692
IMPORTANT SAFEGUARDS
Stainless Steel Kettle
1500W /220V~ 60Hz
Before using the unit for the rst time, please read the Instruction Manual
carefully.
Function Introduction:
• The unit consists of cordless kettle and base unit. Use the kettle only with
the supplied base unit.
• The unit is used only for boiling water. Do not use it for heating milk or
any beverage.
• The unit uses a thermostat and the main body could be rotated at
any angle on the base. The kettle is protected against dry boil and
has the function of switching off automatically when water has
boiled. If you switch on the unit when there are no water inside,
dry boil is happening. If this is the case, the built-in thermal safety switch will switch off automatically to avoid any damage. The
controller includes plastic fuse. It will start to work when other protectors
are unusable. The plastic fuse works only for one time. After it works,
it can not be used for a second time. The water kettle should be sent
immediately for replacement.
• Using it for the rst time, you need to clean the kettle inside. Fill the
unit with clean water, boil twice to get rid of the smutch inside of the stainless steel body. Then you can boil water with the unit for drinking.
• The length of the cord can be adjusted from the base unit.
Spout
Filter
Main Body
Indicator Light
Cord
Unit Parts
Lid
Water Indicator
Handle
Switch
Base Unit
READ ALL INSTRUCTIONS
BEFORE USE.
Safety Notes:
• Make sure that the voltage indicated on the unit corresponds with the
main voltage at your home.
• Place the unit on a stable at surface.
• Never use the unit where kids could reach.
• Never touch stainless body in the process of heating to avoid being burnt.
• Do not place the unit near the heat source.
• Avoid using the unit in a metal tray.
• Never immerse the unit into water.
• Do not allow water or other liquid penetrate the electrical parts inside the
kettle or the base unit. If the electrical parts are penetrated by water or
other liquid, get rid of the liquid rst, then the unit can be used again after
it becomes dry.
• Do not pull out the cord heavily to prevent damage. If the cord is
damaged, please turn to the technicians for replacement.
Operation Methods:
Remove the kettle from the base unit and ll the kettle via spout. Do not ll
water less than the "MIN" indication to prevent the kettle from dry boil. Do
not ll more than the "MAX" indication .Put the kettle into the base unit,then
plug the cord into the outlet.
Cover the lid, then push the switch to the "1" position and the unit starts to
work. If the lid is not well covered, the switch may not automatically switch
off. The boiling water may eject from the kettle and it may cause danger.
It will switch off automatically to the "0" position after the water boils. Before
you switch on again, you have to allow the built-in thermal safety switch
to cool down for a while. If you switch it to the "1" position before it cools
down, it may damage the unit.
When the outside kettle becomes hot, do not touch it. Do not let your hands
touch the steam. If you want to turn off the power before the water boils,
just push the switch to the "0" position. If you remove the kettle from the
base unit, it will switch off automatically. If you don't need to boil water, you
should push the switch to the "0" position to avoid dry boil.
Pour the water in your drinking bottle after the water stops boiling in order
to avoid being hurt.
