PA AUP240R
TECHNI CAL SPECIFICATION S
Output power RMS / MAX: 240/360W
Inputs: 1x LINE balanced/unbalanced | 1x T ELEPHONE/EMERGENCY | 1 x MICROPHONE
FOR PAGING
Input Sensitivity: LINE: 100mV - 500mV - 1V / 47 Kohm selectable | T ELEPHONE/EMERGENCY: Variable gain - 600 ohm | MICROPHONE FOR PAGING:
Variable gain - with priority contact
Signal Output: LINE OUTPUT
Output Levels: LINE OUTPUT: 1V / 600 ohm
Controls: 1 MASTER VOLUME CONTROL | 1 T REBLE TONES CONTROL | 1 BASS TONES
CONTROL
Loudspeakers outputs: Music and speech: 100/70/50V - 8 ohm | Only speech: 100V
Frequency response: 50Hz - 20KHz (-3dB)
Distortion (THD): < 1% (@ Pnom 1KHz)
S/N Ratio: > 80dB
Power Supply: 230/117Vac 50/60Hz 24V dc for Emergency
Operating temperature: 0 - 40º C
Input/Output Connectors: LINE: 1 x XLR balanced / 1xRCA L/R unbalanced | TELEPHONE/EMERGENCY: screw terminals | MICROPHO
NE FOR PAGING: screw terminals | LINE OUTPUT: 1x XLR balanced / 1x RCA L/R
unbalanced | OT HERS IN/OUT: screw terminals
Dimensions (W x H x D): 483 x 88 x 300mm - 2 rack unities 19''
Weight:13 Kg (28.665 lb)
PA AUP120R PA AUP480R
PA BM100A
240 W POWER AMPLIFIER
Category: Commerci al Audio » Ampli fiers
Bra nd: PROEL
Pr oduct Code: PA AUP2 40R
OVERVI EW
Thi s new Pr oel booster seri es h as been design ed to meet in a professional an d flexi ble way the con tin ue mark et
evoluti on an d demand. Such r ange of booster appli es to an operat ing pr ecise cri terion to ensure to th e user
hi gh perfor mance and reli abili ty. Main features:
8 ohm constant i mpedance outpu t and constant voltage (50/70/100 V)
Fu rther 100V output and 24Vdc ou tput available only for the booster as for paging pu rposes
Micr ophone stands i nput for preamplifi er stand r ef. BM100A with priority fun ction VOX
Fu rther prior ity inpu t thr oughou t a contact
Inpu t lin e signal con nector
Telephone in put
Low and h igh tone cont rol
Main master cont rol
PA-HF filter r ear inserti on
Rear groun d left selector
Rear power supply selector
24 Vdc power supply
