Proctor Silex 49969, 49977, 49978 User Guide
840267401
Single-Serve
Plus Coffee Maker
Cafetière 1 tasse Plus
Cafetera Individual
READ BEFORE USE
LIRE AVANT UTILISATION
LEA ANTES DE USAR
English....................................... 2
USA: 1-800-851-8900
www.proctorsilex.com
Français ................................... 14
Canada : 1-800-267-2826
www.proctorsilex.ca
Español ................................... 26
México: 01 800 71 16 100
www.proctorsilex.com.mx
Le invitamos a leer cuidadosamente
este instructivo antes de usar su
aparato.
Plus
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed to reduce the risk of fire, electric shock, and/or injury
to persons, including the following:
1. Read all instructions.
2. This appliance is not intended for use by persons (including
children) with reduced physical, sensory, or mental capabilities,
or lack of experience and knowledge, unless they are closely
supervised and instructed concerning use of the appliance by a
person responsible for their safety.
3. Close supervision is necessary when any appliance is used by or
near children. Children should be supervised to ensure that they do
not play with the appliance.
4. Do not touch hot surfaces. Use handles or knobs. Care must be
taken, as burns can occur from touching hot parts or from spilled,
hot liquid.
5. To protect against electric shock, do not place cord, plug, or coffee
maker in water or other liquid.
6. Unplug from outlet when the coffee maker is not in use and before
cleaning. Allow to cool before putting on or taking off parts and
before cleaning the appliance.
7. Coffee maker must be operated on a flat surface away from the
edge of counter to prevent accidental tipping.
8. Do not operate any appliance with a damaged supply cord or
plug, or after the appliance malfunctions or has been dropped or
damaged in any manner. Supply cord replacement and repairs must
be conducted by the manufacturer, its service agent, or similarly
qualified persons in order to avoid a hazard. Call the provided
customer service number for information on examination, repair, or
adjustment.
9. The use of accessory attachments not recommended by the
appliance manufacturer may cause injuries.
10. Do not use outdoors.
2
11. Do not let cord hang over edge of table or counter or touch hot
surfaces, including stove.
12. Do not place on or near a hot gas or electric burner, or in a heated
oven.
13. Do not use appliance for other than intended use.
14. WARNING! To reduce the risk of fire or electric shock, do not
remove the bottom cover of the coffee maker. There are no userserviceable parts inside. Repair should be done by authorized
service personnel only.
15. CAUTION! Cut Hazard: Removable single-serve pack holder contains
a sharp blade. Use caution when handling.
16. CAUTION! Cut Hazard: Piercing nozzle is sharp. Use caution when
cleaning.
SAVE THESE INSTRUCTIONS
Other Consumer Safety Information
This appliance is intended for household use only.
w WARNING
with a polarized plug (one wide blade) to reduce the risk of electric
shock. The plug fits only one way into a polarized outlet. Do not defeat
the safety purpose of the plug by modifying the plug in any way or by
using an adapter. If the plug does not fit fully into the outlet, reverse the
plug. If it still does not fit, have an electrician replace the outlet.
The length of the cord used on this appliance was selected to reduce
the hazards of becoming tangled in or tripping over a longer cord. If a
longer cord is necessary, an approved extension cord may be used.
The electrical rating of the extension cord must be equal to or greater
than the rating of the appliance. Care must be taken to arrange the
extension cord so that it will not drape over the countertop or tabletop
where it can be pulled on by children or accidentally tripped over.
To avoid an electrical circuit overload, do not use another high-wattage
appliance on the same circuit with this appliance.
Electrical Shock Hazard: This appliance is provided
3
Parts and Features
*To order parts:
US: 1.800.851.8900
www.proctorsilex.com
Canada: 1.800.267.2826
Mexico: 01 800 71 16 100
1. Reservoir
2. Lid
3. Piercing Nozzle
4. Cup Rest
5. Brew Light
6. BREW Button
7. Cord Storage
8. Removable Cup Rest*
9. Brew Basket Handle and Lock
10. Brew Basket*
11. Removable Holder for Ground
Coffee* (fits into brew basket
for brewing)
12. Removable Single-Serve Pack
Holder* (punches hole on
bottom of pack)
4
How to Brew a Single-Serve Pack
w CAUTION
Cut Hazard.
Removable single-serve pack holder has a sharp blade. Use
caution when handling.
NOTE:
• It can take up to 2 minutes before brewed coffee starts
dispensing into your cup. Total brew time average is 4
minutes. For best results, allow the coffee maker to cool for
at least 2 minutes between brewing cycles.
w WARNING
Burn Hazard.
To avoid contact with hot coffee or water:
• Do not fill water above MAX fill line (14 ounces [414 ml]).
• Fill reservoir with cup of water into which the coffee will be
brewed.
• Fully insert cup under brew basket.
• For best results, use K-Cup®* packs.
1. Plug into outlet and slide out the brew basket.
2. Place a pack into the single-serve pack holder.
3. Press down on the edge of the pack until
the pack snaps into place and hole is
“SNAP”
punched in the bottom. Do not remove
foil.
4. Slide brew basket back into unit.
* K-Cup is a registered trademark of Keurig, Inc. Use of the K-Cup
trademark does not imply any affiliation with or endorsement by
Keurig, Inc.
5
How to Brew a Single-Serve Pack (cont.)
5. Press down on brew basket handle to lock
and puncture the foil lid on the pack.
6. Fill reservoir with cup of water into which
the coffee will be brewed.
7. Close the water reservoir lid.
8. Adjust cup rest.
9. Fully insert cup under brew basket.
10. Press down the BREW Button. The power indicator light will
light up to show the coffee maker is on. Once the BREW
button has been depressed, the unit will brew for one
cycle. If the BREW button has been pressed with no water
in the reservoir, wait until the brew light turns off before
adding water to the reservoir. If the brew cycle needs to be
stopped during brewing, unplug the unit. Brew light will stay
on until cycle is complete even if unplugged.
11. Coffee maker will shut off automatically and light will go off
when brew cycle is completed. Unplug the unit.
12. Pull up on brew basket handle to unlock
and remove.
NOTES:
• Allow 2 minutes to cool in between brews.
• Brew basket and single-serve pack holder should be rinsed
after every use.
• Add only water to reservoir.
6
How to Brew Ground Coffee
NOTE:
• It can take up to 2 minutes before brewed coffee starts
dispensing into your cup. Total brew time average is 4
minutes. For best results, allow the coffee maker to cool for
at least 2 minutes between brewing cycles.
w WARNING
To avoid contact with hot coffee or water:
• Do not fill water above MAX fill line (14 ounces [414 ml]).
• Fill reservoir with the cup of water into which the coffee will
be brewed.
• Fully insert cup under brew basket.
• Remove single-serve pack holder before adding coffee
grounds to brew basket.
• To avoid overflow, keep ground coffee below MAX fill line.
1. Plug into outlet and slide out the brew basket.
2. To remove single-serve pack holder, press
down on the single-serve pack holder tab;
then lift out.
w CAUTION
Removable single-serve pack holder has a
sharp blade. Use caution when handling.
3. Place removable holder in brew basket and
add ground coffee. (3 tablespoons [44 ml]
is the MAX amount of any type of grounds.)
4. Slide brew basket back into unit and push
down on brew basket handle to lock.
Burn Hazard.
Cut Hazard.
7
How to Brew Ground Coffee (cont.)
5. Fill reservoir with cup of water into which the coffee will be
brewed.
6. Close the water reservoir lid.
7. Adjust cup rest.
8. Fully insert cup under brew basket.
9. Press down the BREW Button. The power indicator light will
light up to show the coffee maker is on. Once the BREW
button has been depressed, the unit will brew for one
cycle. If the BREW button has been pressed with no water
in the reservoir, wait until the brew light turns off before
adding water to the reservoir. If the brew cycle needs to be
stopped during brewing, unplug the unit. Brew light will stay
on until cycle is complete even if unplugged.
10. Coffee maker will shut off automatically and light will go off
when brew cycle is completed. Unplug the unit.
11. Pull up on brew basket handle to unlock
and remove.
NOTES:
• If finer ground coffee is used, coffee will continue to drip
after the light has gone off.
• Allow 2 minutes to cool in between brews.
• Brew basket and removable holder for ground coffee should
be rinsed after every use.
8
Care and Cleaning
w WARNING
Electrical Shock Hazard.
Do not immerse cord, plug, or coffee maker in any liquid.
NOTE: All coffee makers should be cleaned at least once a month
(once a week for areas with hard water).
1. Plug into outlet.
2. Pour 1/2 cup (118 ml) of plain white vinegar
and 1/2 cup (118 ml) of cold water into
reservoir.
3. Place a cup underneath to catch the water/
vinegar solution.
4. Press the BREW button once. After 30
seconds, unplug unit and allow vinegar to
clean. After 30 minutes, plug in unit and allow
it to finish the brew cycle. When brew cycle is finished, wait for
unit to cool. Empty cup and rinse. Repeat steps 1–4 with
1 cup (237 ml) of cold tap water.
5. Unplug unit.
6. Routine Cleaning of the Needle: The needle is
located in the lid of the coffee maker. Bend a
small paper clip as shown; insert the tip of the
paper clip through the hole/eye of the needle
(Figure A) and up into the needle (Figure B)
to ensure grounds have been removed. Brew
2 or 3 times with cold water to make sure
A
grounds have been removed from the piercing
needle.
B
9
Care and Cleaning (cont.)
7. Wipe exterior of unit with a damp, soapy cloth.
8. The removable single-serve pack holder, brew
basket, and removable holder for ground
coffee are all dishwasher-safe. NOTE: DO NOT
use the “SANI” setting when washing in the
dishwasher. “SANI” cycle temperatures could
damage your product.
w CAUTION
Removable single-serve pack holder has a sharp blade. Use
caution when handling.
9. Push cord into the back of the coffee maker
for easy storage.
Cut Hazard.
10
Troubleshooting Tips
PROBLEM PROBABLE CAUSE/SOLUTION
Coffee tastes
bad.
Water on counter
under unit.
Coffee maker will
not brew.
Coffee overflows
from brew
basket.
Coffee overflows
from mug.
• Coffee maker needs cleaning.
• Coffee ground too coarsely or too finely. Set
coffee grinder to automatic drip grind.
• Poor coffee quality and freshness.
• Poor water quality (use filtered or bottled
water).
• Overfilled water reservoir. Also check cup used
to fill reservoir. Some mugs/cups do not pour
cleanly and can dribble water down the side
of the cup and onto counter.
• Make sure you have allowed for the
2 minutes of cool-down time.
• If the BREW button has been pressed with no
water in the reservoir, wait until the brew light
turns off before adding water to the reservoir.
• Use removable holder for ground coffee.
• Use a lesser amount of ground coffee.
• When using whole bean coffee, a standard
automatic drip coffee grind will yield best
results. Be careful not to overgrind, since very
finely ground coffee can cause overflow in this
unit.
• To prevent coffee overflowing from a mug, use
the same mug to brew into that was used to
fill the water reservoir. Do not add more than
14 ounces (414 ml) of water.
11
Troubleshooting Tips (cont.)
PROBLEM PROBABLE CAUSE/SOLUTION
Water remaining
in reservoir.
Noise or steam at
the end of brew
cycle.
Coffee not
dispensing.
Water reservoir
fills too slowly.
Failed foil seal. • There is variability in the single-serve pack
Short brew cycle. • Single-serve pack is difficult to brew due to
• Added too much water. Remove singleserve pack and replace brew basket. Repeat
brewing cycle.
• Reduce amount of water in reservoir.
• Brew a different type of single-serve pack.
• Piercing nozzle is clogged with coffee grounds.
Turn unit off; unplug. Allow unit to cool
completely. To remove any built-up coffee
grounds, insert end of bent paper clip into eye
of piercing nozzle.
• Unit hasn’t cooled down. Allow 2 minutes
between brewing cycles.
• Try filling water reservoir before pushing down
brew basket handle to pierce single-serve
pack. Start brewing cycle.
manufacturing process which causes some
types of single-serve packs to be weaker
at the seams. Let cool 2 minutes between
brewing, use less water, or try a different
brand.
the coffee and its processing.
• Try a different brand of single-serve pack.
12
Loading...
