ProComSol COM-DROID Specifications

Description:

Combines all components needed for a cost-effective Android™ based HART®
Communicator

Includes:

• DevComDroid Smart Device Communicator Software

• HM-BT-BAT-ER Bluetooth HART Modem

• 1 Year warranty

Note: Smart Phone not included.

COM-DROID

Smart Communicator

for Android

MK-1042, 10/14/2014 Our Quality Management System is

ISO 9001:2008 Certified

Specifications:

DevComDroid Smart Device Communicator Software

DD Library Included
Generic DD Included
Current Library HCF Release 2014 No. 2 (call for latest data)
DD Updates Quarterly updates for 1 year free
DD Specification Enhanced DDL standard (IEC 61804-3)
Operating System Android Ice Cream Sandwich (4.0.3) or higher

HM-BT-BAT-ER Bluetooth HART Modem

Dimensions 2.00” x 2.75” x 0.80” (50mm x 70mm x 20mm)
Total Unit Weight 6 oz (170 g)
HART Specifications HART 4, HART 5, HART 6, HART 7,
HART Physical Layer Spec HCF_SPEC-54

Note: For full specifications see individual data sheets.
