VENT-FREE GAS WALL

FIREPLACE

OWNER’S OPERATION AND

INSTALLATION MANUAL

BLUE FLAME MODEL

MH30TBFL

WARNING: If the information in this manual is not

followed exactly, a re or explosion may result causing property damage, personal injury or loss of life.

— Do not store or use gasoline or other ammable va-

pors and liquids in the vicinity of this or any other appliance.

— WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any

phone in your building.

•

Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the re department.

—

Installation and service must be performed by a qualied installer, service agency or the gas supplier.

WARNING: This appliance is equipped for Natural and

Propane gas. Field conversion is not permitted other than between natural or propane gases.

Questions, problems, missing parts? Before returning to your retailer, call

our customer service department at 1-866-573-0674, 7:30 am - 4:15 pm CST,

Monday through Friday or email customerservice@usaprocom.com

Page 2

TABLE OF CONTENTS

Safety ........................................................ 3

Qualied Installing Agency ........................ 4

Specications ............................................ 5

Product Features ....................................... 6

Local Codes............................................... 6

Preparing For Installation .......................... 6

Unpacking.................................................. 7

Water Vapor: A By-Product Of

Unvented Room Heaters ....................... 7

Air For Combustion and Ventilation ........... 7

Installation ................................................. 9

Operation ................................................. 18

Electrical Connection ............................... 20

Electrical Wiring ....................................... 20

Inspecting Burners................................... 21

Care And Maintenance ............................ 22

Troubleshooting ....................................... 23

Technical Service..................................... 26

Replacement Parts .................................. 27

Accessories ............................................. 27

Service Hints ........................................... 27

Warranty .................................................. 32

SAVE THIS BOOK

INSTALLER: Leave this manual with the appliance.

CONSUMER: Retain this manual for future reference.

This is an unvented gas-red heater. It uses air (oxygen) from the room in which it is installed. Provisions for adequate combustion and ventilation air must be provided.

Refer to Air For Combustion and Ventilation section on

page 7 of this manual.

WARNING: Improper installation, adjustment, al-

teration, service or maintenance can cause injury or property damage. Refer to this manual for correct installation and operational procedures. For assistance or additional information consult a qualied installer, service agency or the gas supplier.

This appliance may be installed in an aftermarket,* permanently located, manufactured (mobile) home, where not prohibited by local codes.

This appliance is only for use with propane or natural gas. Field conversion by any other means including the use of a kit is not permitted.

* Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer.

www.usaprocom.com

200345-01A2

Page 3

SAFETY

IMPORTANT: Read this owner’s manual carefully and completely before trying to assemble, operate, or service this heater. Improper use of this heater can cause serious injury or death from burns, fire, explosion, electrical shock and carbon monoxide poisoning.

Only a qualied installer, service agent, or local gas supplier may install and service this product.

WARNING: Keep the appli-

ance area clear and free from

combustible materials, gasoline, and other ammable vapors and liquids.

WARNING: This appliance can be used with propane or natural gas. It is shipped from the factory adjusted for use with propane.

This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases.

CARBON MONOXIDE POISONING: Early

signs of carbon monoxide poisoning resemble the u, with headaches, dizziness or nausea. If you have these signs, the heater may not be working properly. Get fresh air at once! Have heater serviced. Some people are more affected by carbon monoxide than others. These include pregnant women, people with heart or lung disease or anemia, those under the inuence of alcohol and those at high altitudes.

NATURAL AND PROPANE/LP GAS: Natural

and Propane/LP gas are odorless. An odormaking agent is added to the gas. The odor helps you detect a gas leak. However, the odor added to the gas can fade. Gas may be present even though no odor exists.

WARNING: Any change to

this heater or its controls can

be dangerous.

WARNING: Do not use any

accessories not approved for use with this heater.

WARNING: Carefully super-

vise young children when they are in the room with the heater.

WARNING: Make sure grill guard is in place before running heater.

WARNING: Due to high temperatures, the appliance should be located out of trafc and away from furniture and draperies.

WARNING: Heater becomes very hot when running. Keep

children and adults away from

hot surfaces to avoid burns or clothing ignition. Heater will remain hot for a time after shutoff. Allow surfaces to cool before touching.

WARNING: Do not place clothing or other flammable material on or near the appliance. Never place any objects in the heater.

www.usaprocom.com

3200345-01A

Page 4

SAFETY

1. Do not place Propane/LP supply tank(s) inside any structure. Propane/LP supply tank(s) must be placed outdoors.

2. Heaters with a maximum input over 6,000 Btu/Hr shall not be installed in a bathroom. Heaters with a maximum input over 10,000 Btu/Hr shall not be installed in a bedroom.

3. This heater needs fresh air ventilation to run properly. This heater has an Oxygen Depletion Sensing (ODS) safety shutoff system. The ODS shuts down the heater if not enough fresh air is available. See Air for Combustion and Ventilation, pages 7 through 9. If heater keeps shutting off, see Troubleshooting, page 23.

4. Keep all air openings in front and bottom of heater clear and free of debris. This will ensure enough air for proper combustion.

5. If heater shuts off, do not relight until you have provided fresh, outside air. If heater keeps shutting off, have it serviced.

QUALIFIED INSTALLING AGENCY

Only a qualied agency should install and replace gas piping, gas utilization equipment or accessories, and repair and equipment servicing. The term “qualied agency” means any individual, rm, corporation, or company that either in person or through a representative is engaged in and is responsible for:

6. Do not run heater:

• Where ammable liquids or vapors are used or stored.

• Under dusty conditions.

7. Before using furniture polish, wax, carpet cleaner, or similar products, turn heater off. If heated, the vapors from these products may create a white powder residue within burner box or on adjacent walls or furniture.

8. Do not use heater if any part has been under water. Immediately call a qualied service technician to inspect the room heater and to replace any part of the control system and any gas control which has been under water.

9. Turn off and unplug heater and let cool before servicing. Only a qualied service person should service and repair heater.

10. Operating heater above elevations of 4,500 feet could cause pilot outage.

11. To prevent performance problems, do not use propane/LP fuel tank of less than 100 lbs. capacity.

a) Installing, testing, or replacing gas piping

b) Connecting, installing, testing, repairing,

or servicing equipment; that is experienced in such work; that is familiar with all precautions required; and that has complied with all the requirement of the authority having jurisdiction.

PATENT INFORMATION

This product may be covered by one or more of the following United States patents:

8,915,239 8,851,065 8,764,436 8,757,202 8,757,139 8,752,541 8,568,136 8,545,216 8,517,718 8,516,878 8,506,290 8,465,277 8,317,511 8,297,968 8,281,781 8,241,034 8,235,708 8,152,515 8,011,920 7,967,006 7,967,007

7,654,820 7,730,765 7,677,236 7,607,426 7,434,447

www.usaprocom.com

200345-01A4

Page 5

SPECIFICATIONS

Model MH30TBFL

Ignition Electric Piezo Ignitor

Gas Type Natural Gas Propane Gas

BTU/Hr Input Max. (available)

BTU/Hr Input Min. (available)

Pressure Regulator Setting 4" W.C. 9" W.C.

Inlet Gas Pressure*

(inches of water)

Heater Dimensions (HxWxD) 18.05"x 27.95" x 7.84"

Carton Dimensions (HxWxD) 22.83" x 30.31" x 10.04"

Heater Weight 26.5 lbs

Shipping Weight 31 lbs

* For purposes of input adjustment.

Electrical Requirement for Blower Kit (if equipped)

Voltage • 120 VAC, 60 Hz

26,000 26,000

16,000 21,000

Max. 9.5" Max. 14"

Min. 5" Min. 11"

www.usaprocom.com

5200345-01A

Page 6

PRODUCT FEATURES

SAFETY PILOT

This heater has a pilot with an Oxygen Depletion Sensing (ODS) safety shutoff system. The ODS/pilot shuts off the heater if there is not enough fresh air.

THERMOSTATIC CONTROL

The control automatically cycles the burner on and off to maintain a desired room temperature.

LOCAL CODES

Install and use heater with care. Follow all local codes. In the absence of local codes, use the latest edition of The National Fuel Gas Code, ANSI Z223.1/NFPA 54*.

*Available from:

American National Standards Institute, Inc.

1430 Broadway

New York, NY 10018

National Fire Protection Association, Inc.

1 Batterymarch Park

Quincy, MA 02269-9101

This heater is designed for vent-free operation. State and local codes in some areas prohibit the use of vent-free heaters.

PREPARING FOR INSTALLATION

2 GAS OPTIONS AVAILABLE

Your heater is equipped to operate on either Propane/LP or Natural gas. The heater is shipped from the factory ready for connecting to Propane/LP. The heater can easily be changed to Natural gas by having your qualied installer follow the instructions on page 13 and the markings on the heater.

State of Massachusetts: The installation must be made by a licensed plumber or gas tter in the Commonwealth of Massachusetts.

Sellers of unvented propane or natural gas-red supplemental room heaters shall provide to each purchaser a copy of 527 CMR 30 upon sale of the unit.

In the State of Massachusetts the gas cock must be a T-handle type. The State of Massachusetts requires that a exible appliance connector cannot exceed three feet in length.

Grill

Front Panel

Figure 1 - Vent-Free Gas Heater

Ignitor Button

Control Knob

Heater Cabinet

www.usaprocom.com

Before beginning assembly or operation of the product, make sure all parts are present. Compare parts with package contents list and Figure 1. If any part is missing or damaged, do not attempt to assemble, install or operate the product. Contact customer service for replacement parts.

200345-01A6

Page 7

UNPACKING

1. Remove heater from carton.

2. Remove all protective packaging applied to heater for shipping

WATER VAPOR: A BY-PRODUCT OF

UNVENTED ROOM HEATERS

Water vapor is a by-product of gas combustion. An unvented room heater produces approximately one (1) ounce (30 mL) of water for every 1,000 BTUs (0.3 KWs) of gas input per hour. Unvented room heaters are recommended as supplemental heat (a room) rather than a primary heat source (an entire house). In most supplemental heat applications, the water vapor does not create a problem. In most applications, the water vapor enhances the low humidity atmosphere experienced during cold weather.

AIR FOR COMBUSTION AND VENTILATION

WARNING: This heater shall

not be installed in a conned space or unusually tight construction unless provisions are provided for adequate combustion and ventilation air. Read the following instructions to insure proper fresh air for this and other fuel-burning appliances in your home.

Today’s homes are built more energy efcient than ever. New materials, increased insulation and new construction methods help reduce heat loss in homes. Home owners weather strip and caulk around windows and doors to keep the cold air out and the warm air in. During heating months, home owners want their homes as airtight as possible. While it is good to make your home energy efcient, your home needs to breathe. Fresh air must enter your home. All fuel-burning appliances need fresh air for proper combustion and ventilation. Exhaust fans, replaces, clothes dryers and fuel burning appliances draw air from the house to operate. You must provide adequate fresh air for these appliances. This will insure proper venting of vented fuel-burning appliances.

3. Check heater for any shipping damage. If heater is damaged, promptly inform dealer where you bought heater.

The following steps will help ensure that water vapor does not become a problem.

1. Be sure the heater is sized properly for the application, including ample combustion air and circulation air.

2. If high humidity is experienced, a dehumidier may be used to help lower the water vapor content of the air.

3. Do not use an unvented room heater as the primary heat source.

WARNING: This heater shall

not be installed in a room or space unless the required volume of indoor combustion air is provided by the method described in the National Fuel Gas

Code, ANSI Z223.1/NFPA 54, the International Fuel Gas Code, or

applicable local codes.

WARNING: If the area in which

the heater may be operated is smaller than that dened as an unconned space or if the building is of unusually tight construction, provide adequate combustion and ventilation air by one of the methods described

in the National Fuel Gas Code, ANSI Z223.1/NFPA 54, the International Fuel Gas Code, or

applicable local codes.

www.usaprocom.com

7200345-01A

Page 8

AIR FOR COMBUSTION AND VENTILATION

into Adjoining

VENTILATION AIR

Ventilation Air From Inside Building

This fresh air would come from an adjoining unconned space. When ventilating to an adjoining unconned space, you must provide two permanent openings: one within 12" of the ceiling and one within 12" of the oor on the wall connecting the two spaces (see options 1 and 2, Figure 2). You can also remove door into adjoining room (see option 3, Figure 2). Follow the National Fuel Gas Code, ANSI

Z223.1/NFPA 54, Air for Combustion and Ventilation for required size of ventilation

grills or ducts.

12"

Ventilation

Grills

Room,

Option 1

Remove Door into Adjoining

Room,

Option 3

Ventilation Grills

Into Adjoining Room,

Option 2

Ventilation Air From Outdoors

Provide extra fresh air by using ventilation grills or ducts. You must provide two permanent openings: one within 12" of the ceiling and one within 12" of the oor. Connect these items directly to the outdoors or spaces open to the outdoors. These spaces include attics and crawl spaces. Follow the National Fuel

Gas Code, ANSI Z223.1/NFPA 54, Air for Combustion and Ventilation for required size

of ventilation grills or ducts. IMPORTANT: Do not provide openings

for inlet or outlet air into attic if attic has a thermostat-controlled power vent. Heated air entering the attic will activate the power vent. Rework worksheet, adding the space of the adjoining unconned space. The combined spaces must have enough fresh air to supply all appliances in both spaces.

Ventilated Attic

To Attic

Outlet Air

12"

Figure 2 - Ventilation Air from Inside

Building

www.usaprocom.com

Crawl

Inlet Air

Crawl Space

Space

Ventilated

Figure 3 - Ventilation Air from Outdoors

200345-01A8

Page 9

INSTALLATION

5" Minimum to Top Surface of Carpeting,

FLOOR

NOTICE: This heater is intended for use as supplemental heat. Use this heater along with your primary heating system. Do not install this heater as your primary heat source. If you have a central heating system, you may run system’s circulating blower while using heater. This will help circulate the heat throughout the house. In the event of a power outage, you can use this heater as your primary heat source.

WARNING: A qualied ser-

vice person must install heater. Follow all local codes.

WARNING: Never install the

heater

• in a bedroom or bathroom

• in a recreational vehicle

• where curtains, furniture,

clothing, or other ammable objects are less than 36" from the front, top, or sides of the

heater

• in high trafc areas

• in windy or drafty areas

IMPORTANT: Vent-free heaters add moisture to the air. Although this is benecial, installing heater in rooms without enough ventilation air may cause mildew to form too much moisture. See Air for Combustion and Ventilation, pages 7 and 8.

CHECK GAS TYPE

Be sure your gas supply is right for your heater. Otherwise, call dealer where you bought the heater for proper type heater.

CLEARANCES TO

COMBUSTIBLES

Carefully follow the instructions below. This heater is a freestanding unit designed to be mounted on a wall or set on a base.

WARNING: Maintain the

minimum clearances shown in

Figure 4. If you can, provide greater clearances from oor, ceiling, and joining wall.

CEILING

36"

Minimum

8" Minimum From Sides of Heater

Left Side

Right Side

CAUTION: This heater cre-

ates warm air currents. These currents move heat to wall surfaces next to heater. Installing heater next to vinyl or cloth wall coverings or operating heater where impurities (such as tobacco smoke, aromatic candles, cleaning uids, oil or kerosene lamps, etc.) in the air exist, may cause walls to discolor.

www.usaprocom.com

Tile or Other Combustible Material

Figure 4 - Mounting Clearances as

Viewed From Front of Heater

LOCATING HEATER

This heater is designed to be mounted on a wall. For convenience and efciency, install heater:

1. Where there is easy access for operation, inspection, and service.

2. In the coldest part of room.

9200345-01A

Page 10

INSTALLATION

FASTENING HEATER TO WALL

Mounting Bracket

The mounting bracket is located on back panel of heater (see Figure 5). It has been taped there for shipping. Remove mounting bracket from back panel.

Mounting Bracket

(Shown with optional blower)

Figure 5 - Mounting Bracket Location

Methods For Attaching Mounting

Bracket To Wall

Use only the last hole on each end of mounting bracket to attach bracket to wall. Attach mounting bracket to a wall only in one of two ways:

1. Attaching to wall stud: This method pro- vides the strongest hold. Insert mounting screws through mounting bracket and into wall studs.

2. Attaching to wall anchor: This method allows you to attach mounting bracket to hollow walls (wall areas between studs) or to solid walls (concrete or masonry).

Decide which method better suits your needs. Either method will provide a secure hold for the mounting bracket.

Marking Screw Locations

1. Tape mounting bracket to wall where heater will be located. Make sure mounting bracket is level.

WARNING: Maintain mini-

mum clearances shown in Figure 4, page 9. If you can, provide greater clearances from oor and joining wall.

Mark screw locations on wall (see Figure 6).

Note: Mark only last hole on each end of mounting bracket. Insert mounting screws through these holes only.

3. Remove tape and mounting bracket from wall.

13 1/8"

Min.

Only Insert Mounting Screws Through Last

Hole On Each End

Adjoining Wall

Figure 6 - Mounting Bracket Clearances

Floor

/16"

/4"

Min.

www.usaprocom.com

200345-01A10

Page 11

INSTALLATION

Attaching Mounting Bracket To Wall

Note: Wall anchors, mounting screws, and spacers are in hardware package. The hardware package is provided with heater.

Attaching to Wall Stud Method

For attaching mounting bracket to wall studs:

1. Drill holes at marked locations using 9/64" drill bit.

2. Place mounting bracket onto wall. Line up last hole on each end of bracket with holes drilled in wall.

3. Insert mounting screws through bracket and into wall studs.

4. Tighten screws until mounting bracket is rmly fastened to wall studs.

Attaching to Wall Anchor Method

For attaching mounting bracket to hollow walls (wall areas between studs) or solid walls (concrete or masonry):

1. Drill holes at marked locations using 5/16" drill bit. For solid walls (concrete or masonry), drill at least 1" deep.

2. Fold wall anchor as shown in Figure 7.

3. Insert wall anchor (wings rst) into hole. Tap anchor ush to wall.

4. For thin walls (1/2" or less), insert red key into wall anchor. Push red key to “pop” open anchor wings (see Figure 8).

IMPORTANT: Do not hammer anchor key! For thick walls (over 1/2" thick) or solid walls, do not pop open wings.

5. Place mounting bracket onto wall. Line up last hole on each end of bracket with wall anchors.

6. Insert mounting screws through bracket and into wall anchors.

7. Tighten screws until mounting bracket is rmly fastened to wall.

Placing Heater On Mounting Bracket

1. Locate two horizontal slots on back panel of heater (see Figure 9).

2. Place heater onto mounting bracket. Slide horizontal slots onto stand-out tabs on mounting bracket.

Horizontal Slots

Stand-Out

Tab

(Shown with optional blower)

Mounting Bracket (attached to wall)

Figure 7 - Folding Anchor

Figure 8 - Popping Open Anchor Wings

For Thin Walls

www.usaprocom.com

Figure 9 - Mounting Heater Onto

Mounting Bracket

11200345-01A

Page 12

INSTALLATION

Installing Wall Spacers

1. Place heater on wall mounting bracket.

2. Mark screw locations on wall.

3. Remove heater from mounting bracket.

4. If installing bottom mounting screws into hollow or solid wall, install wall anchors. Follow steps 1 through 4 under Attaching To Wall Anchor Method, page 11. If installing bottom mounting screw into wall stud, drill holes at marked locations using 9/64" drill bit.

5. Replace heater onto mounting bracket.

6. Place spacers between bottom mounting holes and wall anchor or drilled hole.

Hold spacer in place with one hand. With other hand, insert mounting screw though bottom mounting hole and spacer. Place tip of screw in opening of wall anchor or drilled hole.

8. Tighten both screws until heater is rmly secured to wall. Do not over tighten.

Note: Do not replace front panel at this time. Replace front panel after making gas connections and checking for leaks.

INSTALLING LOG

1. Remove 2 screws securing screen to the front panel. Lift screen up and out to remove from heater. See Figure 11.

Screw Securing Screen

(Shown with optional blower)

Front View

Wall

Heater

Spacer

Side View

Figure 10 - Installing Bottom Mounting

Screws

2. Remove packaging material from log.

3. Slide slots on the ends of the log onto log brackets while inserting pins in the back of the log into slots in the back panel.

Slots in Back Panel for Log Pins

Screen

Figure 11 - Removing Screen

Log Bracket

Slot for Installing Log

www.usaprocom.com

Figure 12 - Installing Log

200345-01A12

Page 13

INSTALLATION

GAS SELECTION

This appliance is factory preset for propane/LP gas. No changes are required for connecting to propane/LP.

Only a qualied installer or service technician can perform gas selection and connecting to gas supply.

CAUTION: Two gas line in-

stallations at the same time are

prohibited.

CAUTION: To avoid gas leak-

age for the gas not being used at the inlet of regulator, a qualied installer or service technician must use supplied cap.

You will notice a color coded

plunger on the inside of the regulator. This is normal. When the inlet connection tting is inserted and tightened, this plunger will be pushed back by the tting making all of the adjustments for the gas being supplied. DO NOT REMOVE THE PLUNGER. The regulator will not work.

The inlet regulator is color coded for identication of the correct gas type. Blue is for propane (LP gas) and yellow is for natural gas.

INLET GAS PRESSURE MAX 1/2 PSIG (3.5 KPA)

Gas Connection

Figure 13 - Bottom of Heater

Yellow Natural Gas Plunger Underneath Metal Cap

Insert Gas Fitting for Natural Gas

Figure 14 - Gas Regulator

Blue Propane/LP Gas Plunger Underneath Dust Cover

Insert Gas Fitting for Propane/LP Gas

FOR PROPANE/LP GAS

INSTALLATION: BLUE

1. Remove blue dust cover.

LPG

Blue Dust Cover

www.usaprocom.com

DO NOT REMOVE

Blue Propane/LP

Plunger

Install Gas Fitting Here

13200345-01A

Page 14

INSTALLATION

2. Apply thread sealant to the threads on a 3/8" NPT brass connection tting. While pushing in, rotate the tting clockwise until the threads engage the regulator. After the tting has been hand tightened into the regulator use a wrench to complete tightening of the tting. Install additional tting to connect to the house supply.

FOR NATURAL GAS (NG)

INSTALLATION: YELLOW

1. Remove the blue dust cover from the regulator.

Blue Dust Cover

2. Remove the metal cap installed over the NG regulator inlet.

Use only the cap supplied on the regulator. Do not use an off the shelf pipe plug. This can damage the plunger. The supplied regulator cap is designed so it will not engage the unused gas type.

4. Apply thread sealant to the threads on the connection tting. While pushing in, rotate the tting clockwise until the threads engage the regulator. After the tting has been hand tightened into the regulator use a wrench to complete tightening of the tting. Install additional tting to connect to the house supply.

DO NOT use an off the shelf 3/8" NPT pipe plug. This will damage the plungers located inside the regulator.

Metal Cap

3. Install metal cap over LP/Propane regulator inlet. This will keep debris out of regulator.

DO NOT REMOVE

Yellow Natural Gas Plunger

Install Gas Fitting Here

Metal Cap

www.usaprocom.com

DO NOT try to remove the plungers from inside the regulator. The plunger will be pushed back as the tting is installed.

Make sure the type of gas being used is correct. Check to make sure the connection tting is in the correct inlet on the regulator. Refer to Connecting to Gas Supply, page 15.

If you are using natural gas and the pilot will not light, see Troubleshooting, page 23.

200345-01A14

Page 15

INSTALLATION

CONNECTING TO GAS SUPPLY

WARNING: A qualied ser-

vice technician must connect heater to gas supply. Follow all local codes.

WARNING: This appliance requires a 3/8" NPT (National Pipe Thread) inlet connection to the pressure regulator.

WARNING: For natural gas, Never connect heater to private (non-utility) gas wells. This gas is commonly known as wellhead gas.

WARNING: Do not over-

tighten gas connections.

CAUTION: Use only new, black iron or steel pipe. Internally tinned copper tubing may be used in certain areas. Check your local codes. Use pipe of 1/2" diameter or greater to allow proper gas volume to heater. If pipe is too small, undue loss of pressure will occur.

CAUTION: For natural gas, check your gas line pressure before connecting heater to gas line. Gas line pressure must be no greater than 9.5" of water. If gas line pressure is higher, heater regulator damage could occur.

CAUTION: For propane/ LP gas, Never connect heater directly to the gas supply. This heater requires an external regulator (not supplied). Install the external regulator between the heater and gas supply. Gas supplier provides external regulator for natural gas. The installer provides the external regulator for propane/LP gas.

CAUTION: Avoid damage to regulator. Hold gas regulator with wrench when connecting into gas piping and/or ttings.

CAUTION: Use pipe joint sealant that is resistant to gas (Propane/LP or Natural Gas).

Before installing heater, make sure you have the items listed below:

• piping (check local codes)

• sealant (resistant to natural gas and propane/LP gas)

• equipment shutoff valve*

• test gauge connection*

• sediment trap

• tee joint

• pipe wrench

• exible gas hose (check local codes)

* A CSA design-certied equipment shutoff valve with 1/8" NPT tap is an acceptable alternative to test gauge connection. Purchase the optional CSA design certied equipment shutoff valve from your dealer.

www.usaprocom.com

15200345-01A

Page 16

INSTALLATION

Typical Inlet Pipe Diameters

Use 3/8" black iron pipe or greater. Installation must include an equipment shutoff valve, union, and plugged 1/8" NPT tap. Locate NPT tap within reach for test gauge hook up. NPT tap must be upstream from heater (see Figure 15).

IMPORTANT: Install an equipment shutoff valve in an accessible location. The equipment shutoff valve is for turning on or shutting off the gas to the appliance.

Apply pipe joint sealant lightly to male threads. This will prevent excess sealant from going into pipe. Excess sealant in pipe could result in clogged heater valves.

The installer must supply an external regulator. The external regulator will reduce incom-

Ground Joint Union

Tee Joint

Reducer

Test Gauge Connection*

Sediment

Trap

Bushing to 1/8" NPT

1/8" NPT Plug Tap

Tee Joint

Pipe Nipple

Gap

3" Minimum

ing gas pressure. You must reduce incoming gas pressure to between 11" and 14" of water. If you do not reduce incoming gas pressure, heater regulator damage could occur. Install external regulator with the vent pointing down as shown in Figure 16. Pointing the vent down protects it from freezing rain or sleet.

Install sediment trap in supply line as shown in Figure 15. Place sediment trap where it is within reach for cleaning. Place sediment trap where trapped matter is not likely to freeze. A sediment trap traps moisture and contaminants. This keeps them from going into heater controls. If sediment trap is not installed or is installed wrong, heater may not run properly.

3/8" NPT

Pipe Nipple

Equipment Shutoff Valve

Natural Gas

From Gas Meter (5" W.C.** to 9.5" W.C. Pressure)

Propane/LP

From External Regulator (11" W.C.** to 14" W.C. Pressure)

Propane/LP Supply Tank

External Regulator with Vent Pointing Down

* Purchase the optional CSA design-certied equipment

Figure 15 - Gas Connection

shutoff valve from your dealer.

www.usaprocom.com

Figure 16 - External Regulator

with Vent Pointing Down

200345-01A16

Page 17

INSTALLATION

CHECKING GAS CONNECTIONS

WARNING: Test all gas piping and connections for leaks after installing or servicing. Correct all leaks at once.

PRESSURE TESTING GAS SUPPLY PIPING SYSTEM

Test Pressures In Excess Of 1/2 PSIG (3.5 kPa)

1. Disconnect heater with its appliance main gas valve (control valve) and equipment shutoff valve from gas supply piping system. Pressures in excess of 1/2 PSIG will damage heater regulator.

2. Cap off open end of gas pipe where equipment shutoff valve was connected.

3. Pressurize supply piping system by either using compressed air or opening gas supply valve.

Test Pressures Equal To or Less Than 1/2 PSIG (3.5 kPa)

Close equipment shutoff valve (see Figure 17).

2. Pressurize supply piping system by either using compressed air or opening gas supply valve.

3. Check all joints from gas supply (see Figure 18 or 19) to equipment shutoff valve. Apply a noncorrosive leak detection uid to all joints. Bubbles forming show a leak.

4. Correct all leaks at once.

Propane/LP Supply Tank

Gas Valve

WARNING: Never use an open ame to check for a leak. Apply a mixture of liquid soap and water to all joints. If bubbles form, there is a leak. Correct all leaks at once.

4. Check all joints of gas supply piping system. Apply mixture of liquid soap and water to gas joints. If bubbles form, there may be a leak.

5. Correct all leaks at once.

6. Reconnect heater and equipment shutoff valve to gas supply. Check reconnected ttings for leaks.

Equipment Shutoff Valve

Figure 17 - Equipment Shutoff Valve

Open

Closed

Gas Valve

Equipment Shutoff Valve

Figure 18 - Checking Gas Joints for

Open equipment shutoff valve (see Figure 17).

2. Open gas supply tank valve.

3. Make sure control knob of heater is in the OFF position.

4. Check all joints from equipment shutoff valve to control valve (see Figure 18 or 19). Apply a noncorrosive leak detection uid

Propane/LP Gas

PRESSURE TESTING HEATER GAS CONNECTIONS

www.usaprocom.com

Gas Meter

Equipment Shutoff Valve

Figure 19 - Checking Gas Joints for

Natural Gas

to all joints. Bubbles forming show a leak.

5. Correct all leaks at once.

6. Light heater (see Lighting Instructions on page 18). Check all other internal joints for leaks.

7. Turn off heater (see To Turn Off Gas Ap- pliance, page 19).

17200345-01A

Page 18

OPERATION

FOR YOUR SAFETY READ BEFORE LIGHTING

WARNING: If you do not fol-

low these instructions exactly, a

re or explosion may result causing property damage, personal injury or loss of life.

A. This appliance has a pilot which must

be lighted by hand. When lighting the pilot, follow these instructions exactly.

B. BEFORE LIGHTING smell all around

the appliance area for gas. Be sure to smell next to the oor because some gas is heavier than air and will settle on the oor.

WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electric switch; do

not use any phone in your building.

LIGHTING INSTRUCTIONS

1. STOP! Read the safety information above.

2. Make sure equipment shutoff valve is fully open.

3. Turn control knob clockwise to the OFF position.

4. Wait ve (5) minutes to clear out any air. Then smell for gas, including near the oor. If you smell gas, STOP! Follow "B" in the safety information above. If you do not smell gas, go to the next step.

5. Turn control knob counterclockwise to the PILOT position. Press in control knob for ve (5) seconds (see Figure 20).

Note: The rst time that the heater is oper-

ated after connecting the gas supply,the control knob should be pressed for about thirty (30) seconds. This will allow air to bleed from the gas system. If pilot does not stay lit, refer to Troubleshooting, pages

23 though 26. Also contact a qualied

service technician or gas supplier for repairs. Until repairs are made, light pilot with match.

• If control knob does not pop up when

released, contact a qualified service technician or gas supplier for repairs.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the re department.

C. Use only your hand to push in or turn

the gas control knob. Never use tools. If the knob will not push in or turn by hand, don’t try to repair it, call a qualied service technician. Force or attempted repair may result in a re or explosion.

D. Do not use this appliance if any part

has been under water. Immediately call a qualied service technician to inspect the appliance and to replace any part of the control system and any gas control which has been under water.

6. With control knob pressed in, push down and release ignitor button. This will light pilot. The pilot is attached to the front of burner. The pilot can be seen through the grill. If needed, keep pressing ignitor button until pilot lights.

Note: If pilot does not stay lit, refer to Troubleshooting, pages 23 though 26.

Also contact a qualied service technician

or gas supplier for repairs. Until repairs are made, light pilot with match. To light pilot with match, see Manual Lighting Procedure, page 19.

Ignitor Button

Control Knob

Figure 20 - Control Knob in the OFF

Position

www.usaprocom.com

200345-01A18

Page 19

OPERATION

7. Keep control knob pressed in for 30 seconds after lighting pilot. After 30 seconds, release control knob. If control knob does not pop up when released, contact a qualied service technician or gas supplier for repairs.

Note: If pilot goes out, repeat steps 2

through 6. This heater has a safety interlock system. Wait one (1) minute before lighting pilot again.

8. Turn control knob counterclockwise to desired heating level. The main burner should light. Set control knob to any heat level between 1 and 5.

CAUTION: Do not try to ad-

just heating levels by using the equipment shutoff valve.

THERMOSTAT CONTROL OPERATION

The thermostatic control used on this model differs from standard thermostats. Standard thermostats simply turn the burner on and off. The thermostat used on this heater senses the room temperature. At times the room may ex-

TO TURN OFF GAS TO APPLIANCE

Shutting Off Heater

Turn control knob clockwise to the OFF position.

MANUAL LIGHTING PROCEDURE

1. Remove front panel.

2. Follow steps 2 through 5 under Lighting Instructions, page 18.

3. With control knob pressed in, strike match. Hold match to pilot until pilot lights.

WARNING: If input gas type is NG, make sure NG pilot burner ignites. If input gas type is LP, make sure LP pilot burner ignites.

Natural Gas Burner

Pilot Air Inlet Hole

ceed the set temperature. If so, the burner will shut off. The burner will cycle back on when room temperature drops below the set temperature. The control knob can be set to any comfort level between HIGH (5) and LOW (1).

Turn control knob clockwise to the PILOT position.

4. Keep control knob pressed in for 30 seconds after lighting pilot. After 30 seconds, release control knob. Follow step 8 under Lighting Instructions, page 18.

5. Replace front panel.

Ignitor Electrode

Figure 21 - Pilot

Shutting Off Burner Only

(pilot stays lit)

Thermocouple

Propane/LP Gas Burner

Pilot Air Inlet Hole

www.usaprocom.com

19200345-01A

Page 20

ELECTRICAL CONNECTION

Thermostat Switch

Grounding Means

Metal Screw

FOR OPTIONAL BLOWER KIT

Do not use this heater if any

part of it has been under water. Immediately call a qualied service technician to inspect the heater and replace any part of

the electrical system which has

been under water.

GROUNDING INSTRUCTIONS

This heater is for use on 120 volts. The cord has a plug as shown at A in Figure 22. An adapter as shown at C is available for connecting three-blade grounding-type plugs to two-slot receptacles. The green grounding lug extending from the adapter must be connected to a permanent ground such as a properly grounded outlet box. The adapter should not be used if a three-slot grounded receptacle is available.

ELECTRICAL WIRING

Cover of

Grounding Pin

Grounded Outlet Box

Adapter

(Sold

Separately)

Figure 22 - Grounded Electrical Outlet

FAN OPERATION

To operate the manual unit, turn ON/OFF switch to the ON position. To operate the Automatic unit, turn AUTO/O/MAN switch to the desired position. MAN position will remain constantly on. AUTO position will be controlled by the sensor on the fan blower unit. The sensor will be activated when the temperature of the sensor head reaches the set point of the switch after the heater is started. To stop the operation, turn the switch to the O position.

Any electrical re-wiring of this appliance must be done by a qualied electrician. This wiring must be done in accordance with local codes and/or in Canada with the current CSA C22.1 Canadian Electrical Code, and for US installations, the National Electrical Code ANSI/

NFPA NO 70.

WARNING: If repairing or

replacing any electrical component or wiring, the original wire routing, color coding and securing locations must be followed.

CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation.

www.usaprocom.com

WARNING: Never attempt to service heater while it is plugged in, operating, or hot. Burns and electrical shock could result. Only a qualied service person should service or repair heater.

Verify proper operation after servicing. If any of the original wire as supplied with the appliance must be replaced, it must be replaced with a wire of at least a 105º C temperature rating.

Switch

Black Green White

AUTO O MAN

Motor

200345-01A20

Page 21

Tipping

INSPECTING BURNERS

IMPORTANT: Owner’s should check pilot ame pattern and burner ame pattern often. Incorrect ame patterns indicate the need for cleaning (see Care and Maintenance,

page 22) or service.

WARNING: Only a qualied service person should service and

repair heater. This includes maintenance requiring replacement or alteration of components.

PILOT FLAME PATTERN

Figure 23 shows a correct pilot ame pattern. Figure 24 shows an incorrect pilot ame pattern. The incorrect pilot ame is not touching the thermocouple. This will cause the thermocouple to cool, which shuts the heater off.

If pilot ame pattern is incorrect, as shown in Figure 24

• turn heater off (see To Turn Off Gas to Ap- pliance, page 19)

• see Troubleshooting pages 23 through 26.

WARNING: If yellow tipping

Notice: Do not mistake orange ames with yellow tipping. Dirt or other ne particles enter

the heater and burn causing brief patches of

orange ame.

Natural Gas

Shown

3-3.5" WC

8-11" WC

Figure 23 - Correct Pilot Flame Pattern

occurs, your heater could produce increased levels of carbon monoxide. If the burner ame pattern shows yellow tipping, follow instructions at bottom of

Natural Gas

Shown

3-3.5" WC

8-11" WC

this page.

BURNER FLAME PATTERN

Figure 25 shows a correct burner ame pattern. Figure 26 shows an incorrect burner ame pattern. The incorrect burner ame pattern shows yellow tipping of the ame. It also shows the ame higher than 1/2 the heat shield height.

If burner ame pattern is incorrect as shown in Figure 26:

• turn heater off (see To Turn Off Gas to Ap- pliance, page 19)

• see Troubleshooting pages 23 through 26.

www.usaprocom.com

Figure 24 - Incorrect Pilot Flame Pattern

Figure 25 - Correct Burner Flame Pattern

Yellow

Figure 26 - Incorrect Burner Flame

Pattern

21200345-01A

Page 22

CARE AND MAINTENANCE

WARNING: Turn off heater and let cool before servicing.

CAUTION: You must keep control areas, burner, and circulating

air passageways of heater clean. Inspect these areas of heater before each use. Have heater inspected yearly by a qualied service technician. Heater may need more frequent cleaning due to excessive lint from carpeting, bedding material, pet hair, etc.

WARNING: Failure to keep the primary air opening(s) of the

burner(s) clean may result in sooting and property damage.

MAIN BURNER

Periodically inspect all burner ame holes with the heater running. All slotted burner ame holes should be open with yellow ame present. All round burner ame holes should be open with a small blue ame present. Some

BURNER INJECTOR HOLDER AND PILOT AIR INLET HOLE

We recommend that you clean the unit every 2,500 hours of operation or every three months. We also recommend that you keep the burner tube and pilot assembly clean and free of dust and dirt. To clean these parts we recommend using compressed air no greater than 30 PSl. Your local computer store, hardware store, or home center may carry compressed air in a can. You can use a vacuum cleaner in the blow position. If using compressed air in a can, please follow the directions on the can. If you don’t follow

ODS/PILOT

Use a vacuum cleaner, pressurized air, or a small, soft bristled brush to clean.

A yellow tip on the pilot ame indicates dust and dirt in the pilot assembly. There is a small pilot air inlet hole about 2" from where the pilot ame comes out of the pilot assembly (see Figure 17). With the unit off, lightly blow air through the air inlet hole. You may blow through a drinking straw if compressed air is not available.

Air Passageways

Use a vacuum cleaner or pressurized air to clean.

burner ame holes may become blocked by debris or rust, with no ame present. If so, turn off the heater and let it cool, and remove blockage or replace burner. Blocked burner ame holes will create soot.

directions on the can, you could damage the pilot assembly.

1. Shut off the unit, including the pilot. Allow the unit to cool for at least thirty minutes.

2. Remove four screws securing front panel.

3. Pull front panel forward.

4. Inspect burner and pilot for dust and dirt.

5. Blow air through the ports/slots and holes in the burner.

6. Replace front panel using screws removed.

Natural Gas Burner

Pilot Air Inlet Hole

Figure 27 - Pilot Inlet Air Hole

Ignitor Electrode

Pilot Air Inlet Hole

CABINET

• Use a soft cloth dampened with a mild soap

and water mixture.

• Wipe the cabinet to remove dust.

Exterior

Thermocouple

Propane/LP Gas Burner

www.usaprocom.com

200345-01A22

Page 23

CARE AND MAINTENANCE

MAINTENANCE OF BLOWER MOTOR

Always disconnect the appliance from the main power supply and allow it to cool before any servicing operation.

The motors used on the fan heater and ame blower are pre-lubricated for extended bearing life and require no further lubrication. However, periodic cleaning/vacuuming of the appliance around the air intake and exhaust, as well as the fan heater is recommended. For

heavy or continuous use, periodic cleaning must be done more frequently. If the heater blows alternating cold and warm air, check the fan for free movement and for debris restricting air ow. If the fan does not move freely, the unit must be turned off and the fan replaced immediately in order to prevent further damage to the unit.

TROUBLESHOOTING

WARNING: If you smell gas:

• Shut off gas supply.

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any phone in your building.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the re department.

WARNING: Only a qualied service technician should service and repair heater. Make sure that power is turned off before proceeding. Turn off and let cool before servicing.

CAUTION: Never use a wire, needle, or similar object to clean ODS/pilot. This can damage ODS/ pilot unit.

IMPORTANT: Operating heater where impurities in air exist may create odors. Cleaning supplies, paint, paint remover, cigarette smoke, cements and glues, new carpet or textiles, etc., create fumes. These fumes may mix with combustion air and create odors.

Note: All troubleshooting items are listed in order of operation.

Problem Possible Cause Corrective Action

Using natural gas and pilot will not light.

Pressure Switch

When using natural gas (NG), there is a pressure switch that acts to turn off the gas ow to the pilot if the inlet pressure exceeds

9.5" WC. This is to prevent the operation of the unit on the wrong gas (propane/LP). If your natural gas supply exceeds 9.5" WC the unit will not operate. Either contact your gas supplier to check and adjust the inlet pressure or a qualied service technician can bypass the pressure switch.

Inlet pressure exceeds

9.5" WC.

Before attempting to bypass the pressure switch, make sure the type of gas being used is correct. Check to make sure the connection tting is in the correct inlet on the regulator. Refer to Connecting to Gas Supply, page 15.

Only a qualied installer should bypass the pressure switch. To bypass the pressure switch locate the set screw on the regulator. Use a small at bladed screw driver to turn the set screw counterclockwise 2 turns. This will bypass the pressure switch function.

www.usaprocom.com

Bypass pressure switch. See instructions below.

23200345-01A

Page 24

TROUBLESHOOTING

The entire gas delivery piping including connections inside the heater should be leak tested by the qualied installer. After leak testing the qualied installer should light the appliance. Refer to the correct ame pattern as illustrated on page 21. All ame patterns should be safely inside the product. If for any reason they are not, stop use of the appliance and call for repairs.

Pressure Switch Set Screw

Figure 28 - Gas Regulator Pressure

Problem Possible Cause Corrective Action

When ignitor button is pressed in, there is no spark at ODS/pilot.

When ignitor button is pressed in there is a spark at ODS/pilot but no ignition.

1. Ignitor electrode is positioned wrong. Ignitor electrode is broken.

2. Ignitor electrode is not connected to ignitor cable.

3. Ignitor cable is pinched or wet.

4 Broken ignitor cable.

5. Bad piezo ignitor.

6. Low battery.

1. Gas supply is turned off or equipment shutoff valve is closed.

2. Control knob not fully pressed in while pressing ignitor button.

3. Air in gas lines when installed.

4. ODS/pilot is clogged.

Incorrect inlet gas pressure or inlet regulator setting is damaged.

6. Control knob not in PILOT position.

7. Depleted gas supply (propane).

Switch

1. Replace electrode.

2. Replace ignitor cable.

3. Free ignitor cable if pinched by any metal or tubing. Keep ignitor cable dry.

4. Replace ignitor cable.

5. Replace piezo ignitor.

6. Replace battery.

1. Turn on gas supply or open equipment shutoff valve.

2. Fully press in control knob while pressing ignitor button.

3. Continue holding down control knob. Repeat igniting operation until air is removed.

Clean ODS/pilot (see Care and Maintenance, page 22) or

replace ODS/pilot assembly.

5. Check inlet gas pressure or replace inlet gas regulator.

6. Turn control knob to PILOT position.

7. Contact local propane/LP gas company.

www.usaprocom.com

200345-01A24

Page 25

TROUBLESHOOTING

Problem Possible Cause Corrective Action

ODS/pilot lights but ame goes out when control knob is released.

Burner(s) does not light after ODS/pilot is lit.

Delayed ignition of burner(s).

Burner backring during combustion

High yellow ame during burner combustion

Gas odor during combustion.

Slight smoke or odor during initial operation.

1. Control knob is not fully pressed in.

2. Control knob is not pressed in long enough.

3. Equipment shutoff valve is not fully open.

4. Thermocouple connection is loose at control valve.

5. Pilot flame not touching thermocouple, which allows thermocouple to cool, causing pilot ame to go out. This problem could be caused by one or both of the following:

A) Low gas pressure B) Dirty or partially clogged

ODS/pilot

6. Thermocouple damaged.

7. Control valve damaged.

1. Burner orice is clogged.

2. Burner orice diameter is too small.

3. Inlet gas pressure is too low.

1. Manifold pressure is too low.

2. Burner orice is clogged.

1. Burner orice is clogged or damaged.

2. Burner is damaged.

3. Gas regulator is damaged.

1. Not enough air.

2. Gas regulator is defective.

3. Inlet gas pressure is too low.

1. Foreign matter between control valve and burner.

2. Gas leak. (See Warning Statement at top of page 23).

1. Residues from manufacturing process.

1. Press in control knob fully.

2. After ODS/pilot lights, keep control knob pressed in 30 seconds.

3. Fully open equipment shutoff valve.

4. Hand tighten until snug, and then tighten 1/4 turn more.

5. A) Contact local natural or propane/LP gas company

B) Clean ODS/pilot (see

Care and Maintenance, page

22) or replace ODS/pilot assembly

6. Replace thermocouple.

7. Replace control valve.

1. Clean burner orifice (see Care and Maintenance, page

22) or replace burner orice.

2. Replace burner orice.

3. Contact local gas supplier.

1. Contact local gas supplier.

2. Clean burner (see Care and Maintenance, page 22) or replace burner orice.

1. Clean burner orifice (see Care and Maintenance, page

22) or replace burner orice.

2. Contact customer service.

3. Replace gas regulator.

Check burner for dirt and debris. If found, clean burner (see Care and Maintenance, page 22).

2. Replace gas regulator.

3. Contact local gas supplier.

1. Take apart gas tubing and remove foreign matter.

2. Locate and correct all leaks (see Checking Gas Connec- tions, page 17).

1. Problem will stop after a few hours of operation.

www.usaprocom.com

25200345-01A

Page 26

TROUBLESHOOTING

Problem Possible Cause Corrective Action

Heater produces a whistling noise when burner is lit.

Heater produces a clicking/ticking noise just after burner is lit or shut off.

White powder residue forming within burner box or on adjacent walls or furniture.

Heater produces unwanted odors.

Heater shuts off in use (ODS operates).

Gas odor exists even when control knob is in OFF position.

Moisture/condensation noticed on windows.

1. Turning control knob to high (5) position when burner is cold.

2. Air in gas line.

3. Air passageways on heater are blocked.

4. Dirty or partially clogged burner orice.

1. Metal is expanding while heating or contracting while cooling.

1. When heated, the vapors from furniture polish, wax, carpet cleaners, etc., turn into white powder residue.

Heater is burning vapors from paint, hair spray, glues, etc. See IMPORTANT statement, page 23.

2. Gas leak. See Warning Statement at the top of page 23.

3 Low fuel supply (propane/LP

gas only).

1. Not enough fresh air is available.

2. Low line pressure.

3. ODS/pilot is partially clogged.

1. Gas leak. See Warning Statement at top of page 23.

2. Control valve is defective.

1. Not enough combustion/ ventilation air.

1. Turn control knob to low (1) position and let warm up for a minute.

Operate burner until air is removed from line. Have gas line checked by local gas supplier.

Observe minimum installation clearances (Figure 4, page 9).

4 Clean burner (see Care and

Maintenance, page 22) or replace burner orice.

1. This is common with most heaters. If noise is excessive, contact qualied service technician.

1. Turn heater off when using furniture polish, wax, carpet cleaner or similar products.

1. Ventilate room. Stop using odor causing products while heater is running.

2. Locate and correct all leaks (see Checking Gas Connec- tions, page 17).

3. Rell supply tank (Propane/ LP models).

1. Open window and/or door for ventilation.

2. Contact local gas supplier.

3. Clean ODS/pilot (see Care and Maintenance, page 22).

1. Locate and correct all leaks (see Checking Gas Connec- tions, page 17).

2. Replace control valve.

1. Refer to Air for Combus- tion and Ventilation requirements, page 7.

TECHNICAL SERVICE

You may have further questions about installation, operation, or troubleshooting. If so, contact ProCom Heating, Inc. at 1-866-573-0674.

When calling, please have your model and serial numbers of your heater ready.

www.usaprocom.com

200345-01A26

Page 27

REPLACEMENT PARTS

1/2" Male Flare x 3/8" Female Pipe

Note: Use only original replacement parts. This will protect your warranty coverage for parts replaced under warranty.

PARTS UNDER WARRANTY

Contact authorized dealers of this product. If they can’t supply original replacement parts, call Customer Service toll free at 1-866-573-0674 for referral information.

When calling Customer Service or your dealer, have ready:

• Your name

• Your address

• Model and serial number of your heater

• How heater was malfunctioning

• Type of gas used (Propane/LP or Natural gas/NG)

• Purchase date

Usually, we will ask you to return the defective part to the factory

PARTS NOT UNDER WARRANTY

Contact authorized dealers of this product. If they can’t supply original replacement part(s) call Customer Service toll free at 1-866-573-0674 for referral information.

When calling Customer Service have ready:

• Model number of your heater

• The replacement part number

ACCESSORIES

Purchase these heater accessories from your local dealer. If they can not supply these accessories, contact ProCom Heating, Inc. at 1-866-573-0674 for information.

EQUIPMENT SHUTOFF VALVE

For all models. Equipment shutoff valve with 1/8" NPT tap.

Existing Gas Line

22" Flexible

Connector

Brass Shutoff Valve

OPTIONAL FAN KIT - 20UB100B-01

The fan has 3 settings AUTO/OFF/MAN. Please refer to 20UB100B-01 instructions.

1/2" Male Flare x 1/2" Male Pipe

1/2" Male Flare x 3/8" Male Pipe

INSTALLATION KIT

SERVICE HINTS

• pilot will not stay lit

• burners will have delayed ignition

• heater will not produce specied heat

• propane/LP gas supply might be low (propane/LP units only) You may feel your gas pressure is too low. If so, contact your local gas supplier.

When Gas Pressure Is Too Low

www.usaprocom.com

27200345-01A

Page 28

PARTS

MODEL MH30TBFL

www.usaprocom.com

200345-01A28

Page 29

PARTS

MODEL MH30TBFL

This list contains replaceable parts for your heater. When ordering replacement parts, follow the instructions listed under Replacement Parts on page 27 of this manual.

ITEM PART NUMBER DESCRIPTION QTY

1 ** Front Panel Assembly 1

2 ** Back Body Panel 1

3 MB060-01 Mounting Bracket 1

4 ML083-04 Piezo Ignitor 1

5 STL1001-250-B Thermostat Valve Assembly 1

6 ** Burner Assembly 1

7 ND0310A-MU-600-P16 ODS Pilot 1

8 ** Regulator Valve 1

9 ** Regulator Bracket 1

10 30L106B-01 Log 1

11 161148-01 Bezzel, Thermostat Control 1

PART AVAILABLE - NOT SHOWN

MB28001 Hardware Package 1

ML065-01 Thermostat Bulb Clip 2

** Not a eld replaceable part.

www.usaprocom.com

29200345-01A

Page 30

NOTES

________________________________________________________________

www.usaprocom.com

200345-01A30

Page 31

NOTES

________________________________________________________________

www.usaprocom.com

31200345-01A

Page 32

WARRANTY

KEEP THIS WARRANTY

Model _______________________________

Serial No. ____________________________

Date Purchased _______________________

Keep receipt for warranty verication.

IMPORTANT: We urge you to register your product within 10 days of date of installation, complete with entire serial number which can be found on the rating plate. Please ll out the warranty information above for your personal records. Retain this manual for future reference.

Always specify model and serial numbers when communicating with customer service.

We reserve the right to amend these specications at any time without notice. The only warranty applicable is our standard written warranty. We make no other warranty, expressed or implied.

LIMITED WARRANTY

ProCom Heating, Inc. warrants this product to be free from defects in materials and components for ONE (1) year from the date of rst purchase, provided that the product has been properly installed by a qualied installer in accordance with all local codes and instructions furnished with the unit, operated and maintained in accordance with all applicable instructions. To make a claim under this warranty, the Bill of Sale or cancelled check must be presented.

RESPONSIBILITY OF OWNER

This warranty is extended only to the original retail purchaser. This warranty covers the cost of part(s) required to restore this heater to proper operating condition. Warranty part(s) MUST be obtained through ProCom Heating, Inc. who will provide original factory replacement parts. Failure to use original factory replacement parts voids this warranty.

IMPORTANT: The heater MUST be installed by a qualied installer in accordance with all local codes and instructions furnished with the unit or the warranty is voided.

WHAT IS NOT COVERED

This warranty does not apply to parts that are not in original condition because of normal wear and tear or parts that fail or become damaged as a result of misuse, accidents, lack of proper maintenance or defects caused by improper installation. Travel, diagnostic cost, labor, transportation and any and all such other costs related to repairing a defective heater will be the responsibility of the owner.

TO THE FULL EXTENT ALLOWED BY THE LAW OF THE JURISDICTION THAT GOVERNS THE SALE OF THE PRODUCT, THIS EXPRESS WARRANTY EXCLUDES ANY AND ALL OTHER EXPRESSED WARRANTIES AND LIMITS THE DURATION OF ANY AND ALL IMPLIED WARRANTIES. INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE TO ONE (1) YEAR ON ALL COMPONENTS FROM THE DATE OF FIRST PURCHASE. PROCOM HEATING, INC.'S LIABILITY IS HEREBY LIMITED TO THE PURCHASE PRICE OF THE PRODUCT AND PROCOM HEATING, INC. SHALL NOT BE LIABLE FOR ANY OTHER DAMAGES WHATSOEVER INCLUDING INDIRECT. INCIDENTAL OR CONSEQUENTIAL DAMAGES.

Some states do not allow a limitation on how long an implied warranty lasts or an exclusion or limitation of accidental or consequential damages, the above limitation on implied warranties, or exclusion or limitation on damages may not apply to you.

This warranty gives you specic legal right, and you may also have other rights that vary from state to state.

ProCom Heating, Inc. Bowling Green, KY 42101 www.usaprocom.com 1-866-573-0674

200345-01 Rev. A 07/16
