PMS-01, PMS-02, PMK-16, PML-01, PMM01

Built-in Call Station, Compact and as Separate Components

Call station for built-in use in desk panels,

housings, front plates or on cranes

Call station as separate components: PMS-02, PML-01, PMM-01, PMK-16

Built-in Call Station

(L-No.: 1.222, 1.230, 1.250,1.216)

At a Glance:

• Designed as call station in separate components or as compact model for interiors (control centres and rooms, switching rooms, cranes, etc.)

• Configurable with up to 7 keypads with each 16 illuminated buttons

• Large range thanks to analogue voice transmission, control and signal data over a robust modem connection

• Freely programmable key functions (e.g. PA/intercom operation with acknowledge function, louder/softer, and alarm display and acknowledge function)

• Internal function and connection test

• Optionally with electret microphone or gooseneck

microphone (built-in or as separate components)

Date:

16.03.2009

Page:

1/9

Author: HS Document-No.:

DB_PMS-XX_12XX_00

Data Sheet

PMS-01, PMS-02, PMK-16, PML-01, PMM01

Built-in Call Station, Compact and as Separate Components

Components:

Name Description

PMS-01 (E)

L-No. 1.210

(gooseneck)

L-No. 1.211

(built-in mic)

PMK-16

Keypad with 16

illuminated

buttons

L-No. 1.216

PMK-16WF

Keypad with 16

buttons,

IP65

L-No. 1.217

PMS-02

L-No. 1.222

PML-01

L-No. 1.230

PMM-01

L-No. 1.250

Call station

electronics with

loudspeaker and

mic for desk

integration

Keypad for the

call station electronics PMS-01 or

PMS02

Water-spray

protected

keypad

according to

protection rating

IP65

Call station

electronics with

separate mic

and loudspeaker

Separate

loudspeaker for

PMS-02

Separate mic

for PMS-02

Size

in mm

Built-in

Depth

in mm

90 x 90 100

90 x 90 78

276 x 122

h = 69

90 x 90

78

13 x 250

Date:

16.03.2009

Page:

2/9

Author: HS Document-No.:

DB_PMS-XX_12XX_00

Data Sheet

PMS-01, PMS-02, PMK-16, PML-01, PMM01

Built-in Call Station, Compact and as Separate Components

Brief Description of Built-in Call Station (PMS-01):

The setup for the call station both as built-in model and as separate components is modular. The built-in call station consists of the following components:

- PMS-01 Call station electronics with built-in gooseneck microphone

- PMS-01 E Call station electronics with built-in electret microphone

- PMK-16 Keypad with 16 illuminated buttons in built-in housing

- PMK-16 WF Keypad with 16 buttons in built-in housing (IP65)

Optional:

- PML-01 Loudspeaker in an additional slide-in housing instead of

- PMM-01 Gooseneck microphone with installation flange instead of

The following components are required for the call station as separate components:

- PMS-02 Call station electronics with 25 W booster amplifier with

- PMK-16 Keypad with 16 illuminated buttons in built-in housing

- PMK-16 WF Keypad with 16 buttons in built-in housing (IP65)

- PML-01 Loudspeaker in an additional slide-in housing instead of

- PMM-01 Gooseneck microphone with installation flange instead of

The built-in call stations PMS-01 (with gooseneck microphone) and PMS-01 E

(with built-in microphone) are compact and designed for installation in e.g. desk panels. The loudspeaker is integrated in these call stations. As option the loudspeaker and the microphone can be connected separately.

The PMS-02 is the main component of the call station as separate components

and consists of the call station electronics including 25 W booster amplifier. Loudspeaker and microphone are connected externally (separately).

Up to 7 keypads (PMK-16, PMK-16 WF) can be attached to the PMS call stations.

and loudspeaker in built-in housing

the built-in loudspeaker

the built-in microphone

light grey plastic housing (ABS)

the built-in loudspeaker

the built-in microphone

Date:

16.03.2009

Page:

3/9

Author: HS Document-No.:

DB_PMS-XX_12XX_00

Data Sheet

PMS-01, PMS-02, PMK-16, PML-01, PMM01

Built-in Call Station, Compact and as Separate Components

The following two examples show how the individual components can be connected together:

Wiring diagram 1: PMS-01E with

7 keypads PMK-16

WIRING DIAGRAM 2: PMS-02E with 7 PMK-16 WF (IP65) keypads

Optionally the microphone PMM-01 and/or the loudspeaker PML-01 can be

connected as separate components instead of the built-in microphone and/or

loudspeaker of the PMS-01.

PMM-01 und PML-01

A four-wire connection between call station electronics and the 4NSA in the

DVS-21 system are required to operate a PMS-01 and PMS-01 E. The built-in

call station is complete after at least one keypad has been built in.

To operate a PMS-02 a 6-wire connection to the LF interface module 4NSA

must be established so that the integrated booster amplifier can run. The call station as separate components is completed by connecting at least one keypad, one loudspeaker and one microphone.

Both models can be configured with the help of the system software ICS.

Date:

16.03.2009

Page:

4/9

Author: HS Document-No.:

DB_PMS-XX_12XX_00

Data Sheet

PMS-01, PMS-02, PMK-16, PML-01, PMM01

Built-in Call Station, Compact and as Separate Components

Voice transmission between the call station and DVS-21 is analogue. Control and data transmission is handled by a microcontroller. Transmission is carried out with a modem connection. Busy signals, voice acknowledgments and call signals are indicated on the keypads through LEDs. The display and blink behaviour of the LEDs can be

programmed with the system software ICS of the DVS-21.

Mechanical Data:

95mm 93mm

90mm

Vorderansicht

Front view

PMS-01 E

Mit Elektret-/ oder Schwanenhalsmikrofon

With electret-/ or gooseneck microphone

90mm

5mm

Für Befestigung-

klammer

For

fixation

90mm

93mm

95mm

clamp

Klemme Terminal

22mm

56mm

63mm

95mm

Seitenansicht

Side view

Seitenansicht oben

Side view top

50mm

90mm 95mm

63mm

56mm

15mm

Klemme Terminal

Für Befestigung-

5mm

klammer

For

fixation

clamp

Date:

16.03.2009

Page:

5/9

Author: HS Document-No.:

DB_PMS-XX_12XX_00

Data Sheet

PMS-01, PMS-02, PMK-16, PML-01, PMM01

Built-in Call Station, Compact and as Separate Components

Date:

16.03.2009

6/9

Page:

6/9

DB_PMS-XX_12XX_00

Author: HS Document-No.:

DB_PMS-XX_12XX_00

Data Sheet

PMS-01, PMS-02, PMK-16, PML-01, PMM01

Built-in Call Station, Compact and as Separate Components

Date:

16.03.2009

Page:

7/9

Author: HS Document-No.:

DB_PMS-XX_12XX_00

Data Sheet

PMS-01, PMS-02, PMK-16, PML-01, PMM01

Built-in Call Station, Compact and as Separate Components

Technical Data PMS-01, PMS-01 E and PMS-02:

Operating Voltage: 48 V DC

Power, Intercom Amplifier: 4 W

Power, Booster Amplifier: 25 W

Idle Current: 25 mA

Current Consumption (Sending): 35 mA

Current Consumption (Receiving) Without Booster Amplifier: max. 200 mA

Current Consumption (Receiving) With Booster Amplifier: max. 1200 mA (only PMS-02)

Nominal Impedance: 600 Ω

Frequency Range: 300 - 8,000 Hz

Gooseneck Microphone: dynamic, kidney shape

Control Range Dynamic Compressor: 20 dB (speaking distance10 - 30

cm) (for gooseneck microphone)

Built-in Microphone: electret, ball shape (only PMS-01)

Date:

16.03.2009

Sound Pressure Level: >94 dB (distance 1 m)

Page:

8/9

Author: HS Document-No.:

DB_PMS-XX_12XX_00

Data Sheet

PMS-01, PMS-02, PMK-16, PML-01, PMM01

Built-in Call Station, Compact and as Separate Components

Accessories:

- Mounting flange for gooseneck microphone

- Transparent rubber cover for PMK-16 and PMK-16 WF

- Front door, transparent, for PMK-16 and PMK-16 WF

Article number:

772 000 02

Article number: 760 000 52

Article number: 760 000 45

Date:

16.03.2009

Page:

9/9

Author: HS Document-No.:

DB_PMS-XX_12XX_00
