Specifications and Main Features
- Brandlist- MN180HPA, MN180TPA, MN300HPA, MN300TPA among others.
- Uses Natural Gas as a fuel with specifying.
- Uses Piezo Ignitor Mechanism.
- Located in the lower levels of buildings Two types available, the Vent-Free MN300 and MN180. Air cannot escape from the heater, making it ideal for space heating.
- BTU output:
- MN180HPA: 18,000 BTU
- MN180TPA: 18,000 BTU
- MN300HPA: 30,000 BTU
- MN300TPA: 30,000 BTU
- Other numbers include Pressure Regulator Set-Up of 6’’ WC and Inlet Gas Pressure output of both a maximum of 10.5’’ WCC and a minimum of 7’’ WCC.
- Varying Dimensions between the two heaters include:
2:1 Dimension of MN180 HPA and TPA being 19237 while the other two are 26.7237
- Lastly weight differences can also be determined as
- Safety Devices as Oxygen Depletion Sensor or ODS for safety shuts off.
- Installations have to go according to local codes changed or complied with the latest edition electric fuel NTJG gas code ANSZ223.1.
Frequently Asked Questions
Q: Can more than one type of gas be used with the heater?
A: Natural gas is the only option available.
Q: What safety features does the heater have?
A: The heater contains an oxygen depletion sensor (ODS), which turns off the heater when there is not enough oxygen available.
Q: How do I ignite the heater?
A: Using the piezo ignitor button, light the pilot. Note: The appropriate lighting instructions are provided in the manual for best outcome.
Q: What should I do if the pilot light goes out?
A: Wait for about a minute before attempting to light the pilot. Thereafter, lighting instructions for the manual should be referred to.
Q: Are there any specific installation requirements?
A: Yes, do not install the heater in a confined area, or tight construction unless there is provision for fresh combustion air and ventilation.
Q: How often should the heater be inspected or cleaned?
A: The heater should be cleaned or inspected after every 2500 hours of use or 3 months regardless of the number of hours, and yearly by a qualified service person.
