For 25 years we have been developing, producing, and distributing high quality connecting systems in the 12-24 Volt range, providing customers with safe connections for on-board electrical systems in cars, trucks, mobile homes, motorbikes and boats.

Adding products, which have been especially developed for mobile applications through modern LED lighting technology as well as USB charging technology.

In year 2011 PRO CAR has acquired the manufacture of Paroli heated laminated fabrics as well as heated carpets- and mats for the mobile leisure market. For more than 15 years, Paroli heating fabric has been used in the original equipment and retrofitting of underfloor heating in camper vans, caravans, at home and in the workplace, where it has proven its worth.

Customers’ needs and demands, and our own experience and ideas keep our company up to date and dynamic, whereupon the quality of our products has the highest priority.

PRO CAR and their business partner are exhibiting at all important national and international trade fairs, which provides us with a wide range of detailed and specific customer information and feedback.

For further information visit our web-site: www.pro-car.de

Our sales programme for OEMs, industry and trade:

• Universal and safety universal plugs 1 A – 16 A for cigarette lighter and standard sockets

• Universal angular plugs with function control for mobile phone network and electrical accessories 7.5 A according to DIN EN ISO 4165

• Socket connectors, twin socket connectors, triple sockets and extention cables with contacts according to DIN ISO EN 4165

• Connectors with large socket connector (internal Ø 21 mm)

• Custom-made assemblies

• Hand, reading and supplementary lights and innovative LED technology

• Electronic alarm devices

• Charging cable with USB connector and USB sockets

• Heating fabric 12 V-230 V for use as a floor heating in recreation vans and caravans

• Heating mats and carpets 12 V and 230 V

All items also available in single packaging (SP).

2

swing-out puller tool

optionally with LED

or without LED

with maze-like strain relief

or with screwed strain relief

adaptor can be firmly positioned by a bayonet catch hence offering an excellent contact in the cigarette lighter socket

available as safety universal plug fused up to 16 A

or as unfused universal plug

3

screw terminal for cables up to 2,5 mm

2

25 Years

INNOVATION EXPERTISE PARTNER

Universal Plug with screwed strain relief

8 and 16 A, 12-24 V, fitting for cigarette lighter and standard sockets, screw terminals for cables up to 2.5 mm2, adaptor that can be firmly positioned by a bayonet catch, swing-out puller tool.

BP SP

SU = 500 SU = 60 8 A 67711000 67721000 16 A TÜV certified 67711010 67721010

Safety Universal Plug with screwed strain relief

With integrated, interchangeable fuse from 1-16 A, 12-24 V, fitting for cigarette lighter and standard sockets, screw terminals for cables up to 2.5 mm2, adaptor that can be firmly positioned by a bayonet catch, swing-out puller tool.

Universal Plug with maze-like strain relief

8 and 16 A, 12-24 V, fitting for cigarette lighter and standard sockets, screw terminals for cables up to 2.5 mm2, adaptor that can be firmly positioned by a bayonet catch, swing-out puller tool.

BP SP SU = 500 SU = 60

8 A 67713000 67723000 16 A TÜV certified 67713010 67723010

BP SP fused SU = 500 SU = 60 1 A 67712001 67722001 2 A 67712002 67722002 5 A 67712005 67722005 8 A 67712000 67722000 16 A TÜV certified 67712010 67722010

maze-l ike

strain relie f

BP = Bulk Packing SP = Single Packing SU = Sales Unit

screwe d

strain relie f

screwe d

strain relie f and LED

Safety Universal Plug with maze-like strain relief

With integrated, interchangeable fuse from 1-16 A, 12-24 V, fitting for cigarette lighter and standard sockets, screw terminals for cables up to 2.5 mm2, adaptor that can be firmly positioned by a bayonet catch, swing-out puller tool.

BP SP

fused SU = 500 SU = 60 1 A 67714001 67724001 2 A 67714002 67724002 5 A 67714005 67724005 8 A 67714000 67724000 16 A TÜV certified 67714010 67724010

4

Universal Plug with screwed strain relief and LED

8 and 16 A, 12-24 V, fitting for cigarette lighter and standard sockets, screw terminals for cables up to 2.5 mm2, adaptor that can be firmly positioned by a bayonet catch, swing-out puller tool.

BP SP SU = 500 SU = 60

8 A 67711100 67721100 16 A TÜV certified 67711110 67721110

. . . great contact and easy to connect!

Buckling Protective Sleeve

for universal plug and safety universal plug, standard internal Ø 4 mm.

BP 80106000

Power Plug 20 A max. / 12-24 V

Assembled with cable 2 x 2.5 mm2, length 1.2 m. Fitting for cigarette lighter and power sockets. For connecting coffee makers, kettles, heaters etc.

Safety Universal Plug with screwed strain relief and LED

With integrated, interchangeable fuse from 1-16 A, 12-24 V, fitting for cigarette lighter and standard sockets, screw terminals for cables up to 2.5 mm2, adaptor that can be firmly positioned by a bayonet catch, swing-out puller tool.

BP SP

fused SU = 500 SU = 60 1 A 67712101 67722101 2 A 67712102 67722102 5 A 67712105 67722105 8 A 67712100 67722100 16 A TÜV certified 67712110 67722110

Special versions on request.

BP SP SU = 100 SU = 60

max. 20 A 67101284 67101285

Universal Angular Plug

With operational check by diode. 7.5 A / 12-24 V, adaptor that can be firmly positioned by a bayonet catch, screwed strain relief, cable cross-section max. 1.5 mm2, Ø 8 mm, fitting for cigarette lighter and standard sockets according to DIN EN ISO 4165.

BP SP SU = 100 SU = 20 7,5 A 57730000 57730001

5

25 Years

INNOVATION EXPERTISE PARTNER

Bendable Universal Plug

Bendable up to 180°, with screw terminals, with or without strain relief, adaptor that can be ﬁrmly positioned by a bayonet catch, 12-24 V, ﬁtting for cigarette lighter and standard sockets.

BP SP SU = 100 SU = 60

8 A with screwed strain relief 67741000 67741500 8 A without strain relief 67741100 –

Bendable Safety Universal Plug

Bendable up to 180°, with screw terminals, with or without strain relief, adaptor that can be ﬁrmly positioned by a bayonet catch, 12-24 V, ﬁtting for cigarette lighter and standard sockets. With integrated, interchangeable fuse from 1-8 A / 12-24 V.

BP SP

fused SU = 100 SU = 60 1 A with screwed strain relief 67742001 – 2 A with screwed strain relief 67742002 – 8 A with screwed strain relief 67742000 67742500 1 A without strain relief 67742101 – 2 A without strain relief 67742102 – 8 A without strain relief 67742100 –

Bendable Universal Plug with Switch

8 A / 12-24 V, with single-pole circuit breaker 8 A, rocker switch imprinted with 0-I. The plug is bendable up to 180°, with screw terminals, adaptor that can be ﬁrmly positioned by a bayonet catch, ﬁtting for cigarette lighter and standard sockets.

BP SP SU = 100 SU = 60

8 A 67746000 67746500

Bendable Safety Universal Plug with Switch

8 A / 12-24 V, with single-pole circuit breaker 8 A, rocker switch imprinted with 0-I. The plug is bendable up to 180°, with screw terminals, adaptor that can be ﬁrmly positioned by a bayonet catch. With integrated, interchangeable fuse 8 A, ﬁtting for cigarette lighter and standard sockets.

BP SP fused SU = 100 SU = 60 8 A 67747000 67747500

Example of use

Offering sufficient space for your electronics.

dimensions for pcb:

- with screwed strain relief = 28.5 x 26.5 x 1.5 mm

- strain relief by prommet = 35.5 x 26.5 x 1.5 mm

BP = Bulk Packing SP = Single Packing SU = Sales Unit

Bendable Universal Plug with Switch

8 A / 12-24 V, with single-pole circuit breaker 8 A, rocker switch imprinted with 0-I, assembled with cable 2 x 0.75 mm2, length 2.0 m. The plug is bendable up to 180°, with screw terminals, adaptor that can be ﬁrmly positioned by a bayonet catch, ﬁtting for cigarette lighter and standard sockets.

BP SP SU = 100 SU = 60

8 A 67745000 67745500

Bendable Safety Universal Plug with Switch

8 A / 12-24 V, with single-pole circuit breaker 8 A, rocker switch imprinted with 0-I, assembled with cable 2 x 0.75 mm2, length 2.0 m. The plug is bendable up to 180°, with screw terminals, adaptor that can be ﬁrmly positioned by a bayonet catch. With integrated, interchangeable fuse 8 A, ﬁtting for cigarette lighter and standard sockets.

BP SP fused SU = 100 SU = 60 8 A 67748000 67748500

6

Standard Plug 8 A

With soldering contacts and maze-like strain relief, for connecting any type of 8 A accessory, 12-24 V, fitting for all standard sockets according to DIN EN ISO 4165.

BP SP SU = 500 SU = 60 8 A 67751000 67751500

. . . ﬁts well great conntections!

Standard Plug 15 A

With screw terminals, for connecting any type of 15 A accessory, 12-24 V, easy to assemble, optimal contact, fitting for all standard sockets according to DIN EN ISO 4165.

BP BP SU = 500 SU = 60

15 A 53005000 53005001

Standard Plug 12 A

With screw terminals and strain relief. For connecting any type of 12 A accessory, 12-24 V, ﬁtting for all standard sockets according to DIN EN ISO 4165.

BP SP SU = 500 SU = 60

12 A 58078300 58078301

DIN-Socket-Adaptor 16 A

12-24 V Adaptor for use of devices with cigarette lighter plug in standard sockets. Straight type, one side internal Ø 21mm ﬁtting for cigarette lighter plugs, other side ﬁtting for standard sockets according to DIN EN ISO 4165.

BP SP SU = 200 SU = 60 16 A 67872900 67882900

7

25 Years

INNOVATION EXPERTISE PARTNER

DIN-Standard Built-In Socket

With 6.3 mm ﬂat terminals. Fastening by hexagon nut, ﬁtting for standard and universal plug, internal Ø 12 mm, 16 A / 12-24 V max., TÜV certiﬁed and monitored, with contacts according to DIN EN ISO 4165. Port for installation 18 mm.

BP SP SU = 500 SU = 60

16 A 57607000 57607001

DIN-Standard Built-In Socket with Protective Cap

Dust and splash-proof version. With 6.3 mm flat terminals. Fastening by hexagon nut, fitting for standard and universal plug, internal Ø 12 mm, 16 A / 12-24 V max., TÜV certified and monitored, with contacts according to DIN EN ISO 4165. Port for installation 18 mm.

BP SP SU = 500 SU = 60

16 A 57607002 57607003

DIN-Standard Built-In Socket with Mounting Plate

With 6.3 mm ﬂat terminals. Fastening by hexagon nut, ﬁtting for standard and universal plug, internal Ø 12 mm, 16 A / 12-24 V max., TÜV certiﬁed and monitored, with contacts according to DIN EN ISO 4165. Port for installation 18 mm.

BP SP SU = 500 SU = 60

with protective cap 57607032 57607033 without protective cap 57607030 57607031

DIN-Standard Built-In Socket, Metal, with Protective Cap

With 6.3 mm ﬂat terminals. Fastening by hexagon nut, ﬁtting for standard and universal plug, internal Ø 12 mm, 16 A / 12-24 V max. Port for installation 18 mm.

BP SP SU = 100 SU = 60

16 A 53114320 53114321

DIN Built-In Socket, waterproof

12-24 V, waterproof to IP 67, cables are waterproof encapsulated, with screw cap, 16 A / 12-24 V max., internal Ø 12 mm, contacts according to DIN EN ISO 4165, ready-made 300 mm cable. Fastening by hexagon nut. Port for installation 18.0 mm. Temperature resistant -40°C to 105°C.

BP SP SU = 50 SU = 20

16 A 52005000 52005001

BP = Bulk Packing SP = Single Packing SU = Sales Unit

Triple Built-In Socket

Three standard sockets, 12-24 V, fitting for standard and universal plug. Connection with 6.3 mm flat terminals. Overall load up of all three sockets 16 A / 12-24 V max., internal Ø 12 mm, with contacts according to DIN EN ISO 4165.

BP SP SU = 100 SU = 60 16 A 57612002 57612003

8

Surface Mounted Socket

With 6.3 mm flat terminals, fitting for standard and universal plug, 16 A /12-24 V max., internal Ø 12 mm, TÜV certified and monitored, with contacts according to DIN EN ISO 4165.

BP SP SU = 100 SU = 60

16 A 57608000 57608001

Surface Mounted Socket with Protective Cap

Dust-proof and splash-proof version. With 6.3 mm ﬂat terminals, ﬁtting for standard and universal plug, 16 A / 12-24 V max., internal Ø 12 mm, TÜV certiﬁed and monitored, with contacts according to DIN EN ISO 4165.

BP SP SU = 100 SU = 60

16 A 57608002 57608003

Surface Mounted Power Socket

12-24 V. Current-carrying capacity: 20 A based on a cable cross section of

2.5 mm2, 16 A based on a cable cross section of 1.5 mm2. Internal Ø 21mm, with 6.3 mm flat terminals, fitting for universal plug.

BP SP SU = 100 SU = 60

12-24 V / m ax. 20 A 67604000 67614000

Power Socket Connector

12-24 V, 20 A max. based on a cable cross section of 2.5 mm2, 16 A based on a cable cross section of 1.5 mm2, for constructing overhung connection. Internal Ø 21 mm, with 6.3 mm flat terminals, fitting for universal plug.

BP SP SU = 100 SU = 60

12-24 V / m ax. 20 A, with base plate 67604500 67614500

Triple Surface Mounted Power Socket

12-24 V, 20 A max. based on a cable cross section of 2.5 mm2, 16 A based on a cable cross section of 1.5 mm2. Internal Ø 21 mm. Mounting screws included.

BP SP SU = 100 SU = 20

12-24 V 67601000 67611000

Triple Power Socket

With universal plug 16 A, connection possible to all cigarette lighter sockets and DIN standard sockets, 12-24 V, 16 A max. with three sockets. Internal Ø 21 mm. Cable 2 x 1.5 mm2 flat cable. Length 2.0 m.

BP SP SU = 50 SU = 20 12-24 V / 16 A 67601500 67611500

9

25 Years

INNOVATION EXPERTISE PARTNER

Power Socket with screw thread or clamp sleeve

Designed to operate electrical devices in cars, boats and caravans. Current-carrying capacity 20 A based on a cable cross section of 2.5 mm2, 16 A based on a cable cross section of 1.5 mm2. Internal Ø 21 mm, port for installation 27.8 mm. Fastening by hexagon nut or clamp sleeve.

BP SP SU = 160 SU = 60

12-24 V, screw thread black 68040800 68140800 12-24 V, screw thread red 68040810 68140810 12-24 V, screw thread green 68040820 68140820

12 V, clamp sleeve clear, illuminated 68040740 68140740 12 V, clamp sleeve red, illuminated 68040750 68140750 12 V, clamp sleeve green, illuminated 68040760 68140760 24 V, clamp sleeve clear, illuminated 68040770 68140770 24 V, clamp sleeve red, illuminated 68040780 68140780 24 V, clamp sleeve green, illuminated 68040790 68140790

12-24 V, clamp sleeve green, without illuminated 68040860 68140860

Power Socket with Mounting Plate

12-24 V with clamp sleeve, without illumination, with mounting plate for front installation in e.g. thick-walled wood panels. Designed to operate electrical devices in cars, boats and mobile homes. Current-carrying capacity 20 A based on a cable cross section of 2.5 mm2, 16 A based on a cable cross section of

1.5 mm2. Internal Ø 21 mm, port for installation 32 mm. Fastening by clamp sleeve snapped into the mounting plate, length 60 mm, width 45 mm, height 2.2 mm. Mounting screws included.

BP SP SU = 160 SU = 60

12-24 V, clamp sleeve green, with mounting plate 68041000 68141000

Motorcycle Socket with snap-on lid

12 V / 10 A, for connecting battery chargers, navigation systems, PDA’s and other devices. Fitting for universal and safety universal plug, weather and splash-proof, assembled with approx. 50 cm cable, internal Ø 21 mm.

BP SP SU = 50 SU = 20

12 V / 10 A 57607050 57607550

BP = Bulk Packing SP = Single Packing SU = Sales Unit

Cigarette Lighter with screw thread or clamp sleeve

12 and 24 V. With 6.3 mm flat terminals. Port for installation 27.8 mm. Fastening by hexagon nut. All versions also available for 24 V.

BP SP SU = 160 SU = 60

12 V, small knob, screw thread black 68031170 68131170 12 V, small knob, screw thread red 68031180 68131180 12 V, small knob, screw thread green 68031190 68131190 12 V, large knob, screw thread black 68031200 68131200 12 V, large knob, screw thread red 68031210 68131210 12 V, large knob, screw thread green 68031220 68131220

12 V, small knob, clamp sleeve clear, illuminated 68031050 68131050 12 V, small knob, clamp sleeve red, illuminated 68031060 68131060 12 V, small knob, clamp sleeve green, illuminated 68031070 68131070 12 V, large knob, clamp sleeve clear, illuminated 68031080 68131080 12 V, large knob, clamp sleeve red, illuminated 68031090 68131090 12 V, large knob, clamp sleeve green, illuminated 68031100 68131100

10

Power USB Built-In Socket

12-24 V DC / 5 V DC, 3,000 mA with integrated power voltage converter. For charging and operating sat navs, mobile phones, smart phones, digital cameras, PAD’s and devices that are suitable for charging by 5 Volt USB.

Fastening by plastic srew nut, installation dimensions Ø 27.8 mm, pre-assembled cable connection approx. 15 cm.

Input voltage 8-34 Volt , E1 certificate, Current consumption < 5 mA, Cable connection 15 cm, Cable cross section 0.5 mm², Panel thickness 2-8 mm, Install dimensions 27.8 mm +/- 0.1 mm, Output current max. 3 A

BP SP SU = 100 SU = 60

12-24 V, without mounting plate 67331000 67331500 12-24 V, with mounting plate, incl. screws 67332000 67332500

Power Double USB Socket

12-24 V DC / 5 V DC, 5,000 mA (2 x 2,500 mA) with integrated power voltage converter. For charging and operating sat navs, mobile phones, smart phones, digital cameras, PAD’s and devices that are suitable for charging by 5 Volt USB.

Fastening by plastic srew nut, installation dimensions Ø 27.8 mm, pre-assembled cable connection approx. 15 cm.

Input voltage 8-34 Volt , E1 certificate, Current consumption < 5 mA, Cable connection 15 cm, Cable cross section 0.5 mm², Panel thickness 2-8 mm, Install dimensions 27.8 mm +/- 0.1 mm, Output current max. 5 A (2 x 2,500 mA), Output current duration 4.4 A (2 x 2,200 mA)

BP SP SU = 100 SU = 60

12-24 V, without mounting plate 67321000 67321500 12-24 V, with mounting plate, incl. screws 67322000 67322500

Power USB Built-In Socket with Cap

12-24 V DC / 5 V DC, 3,000 mA with integrated power voltage converter. For charging and operating sat navs, mobile phones, smart phones, digital cameras, PAD’s and devices that are suitable for charging by 5 Volt USB.

Fastening by plastic srew nut, installation dimensions Ø 27.8 mm, pre-assembled cable connection appr. 15 cm.

Input voltage 8-34 Volt , E1 certificate, Current consumption < 5 mA, Cable connection 15 cm, Cable cross section 0.5 mm², Panel thickness 2-8 mm, Install dimensions 27.8 mm +/- 0.1 mm, Output current max. 3 A

BP SP SU = 100 SU = 60

12-24 V, without mounting plate 67331100 67331600 12-24 V, with mounting plate, incl. screws 67332100 67332600

Power Double USB Socket with Cap

12-24 V DC / 5 V DC, 5,000 mA (2 x 2,500 mA) with integrated power voltage converter. For charging and operating sat navs, mobile phones, smart phones, digital cameras, PAD’s and devices that are suitable for charging by 5 Volt USB.

Fastening by plastic srew nut, installation dimensions Ø 27.8 mm, pre-assembled cable connection appr. 15 cm.

Input voltage 8-34 Volt , E1 certificate, Current consumption < 5 mA, Cable connection 15 cm, Cable cross section 0.5 mm², Panel thickness 2-8 mm, Install dimensions 27.8 mm +/- 0.1 mm, Output current max. 5 A (2 x 2,500 mA), Output current duration 4.4 A (2 x 2,200 mA)

BP SP SU = 100 SU = 60

12-24 V, without mounting plate 67321100 67321600 12-24 V, with mounting plate, incl. screws 67322100 67322600

11

25 Years

INNOVATION EXPERTISE PARTNER

Power USB Surface Mounted Socket

12-24 V DC / 5 V DC, 3,000 mA with integrated power voltage converter. For charging and operating sat navs, mobile phones, smart phones, digital cameras, PAD’s and devices that are suitable for charging by 5 Volt USB.

Fastening by two screws. Pre-assembled cable connection approx. 15 cm.

Input voltage 8-34 Volt , E1 certificate, Current consumption < 5 mA, Cable connection 15 cm, Cable cross section 0.5 mm², Output current max. 3 A

BP SP SU = 100 SU = 60

12-24 V 67333000 67333500

Power Double USB Surface Mounted Socket

12-24 V DC / 5 V DC, 5,000 mA (2 x 2,500 mA) with integrated power voltage converter. For charging and operating sat navs, mobile phones, smart phones, digital cameras, PAD’s and devices that are suitable for charging by 5 Volt USB.

Fastening by two screws. Pre-assembled cable connection approx. 15 cm.

Input voltage 8-34 Volt , E1 certificate, Current consumption < 5 mA, Cable connection 15 cm, Cable cross section 0.5 mm², Output current max. 5 A (2 x 2,500 mA), Output current duration 4.4 A (2 x 2,200 mA)

BP SP

SU = 100 SU = 60

12-24 V 67323000 67323500

Surface Mounted Triple Socket with 2 Power Sockets and 1 Power USB Socket

Two power sockets for cooling boxes or devices that are suitable to be operated by 12-24 volt. Power USB socket 12-24 V DC / 5 V DC, 3,000 mA with integrated power voltage converter. For charging and operating sat navs, mobile phones, smart phones, digital cameras, PAD’s and devices that are suitable for charging by 5 Volt USB. Fastening by two screws. Pre-assembled cable connection approx. 15 cm.

Input voltage 8-34 Volt , E1 certificate, Current consumption < 5 mA, Cable connection 15 cm, Cable cross section 0.5 mm², Output current max. 3 A

BP SP SU = 100 SU = 20

12-24 V 67334000 67334500

BP = Bulk Packing SP = Single Packing SU = Sales Unit

Surface Mounted Triple Socket with 2 Power Sockets and 1 Power Double USB Socket

Two power sockets for cooling boxes or devices that are suitable to be operated by 12-24 volt. Power Double USB socket 12-24 V DC / 5 V DC, 5,000 mA (2 x 2,500 mA) with integrated power voltage converter. For charging and operating sat navs, mobile phones, smart phones, digital cameras, PAD’s and devices that are suitable for charging by 5 Volt USB. Fastening by two screws. Pre-assembled cable connection approx. 15 cm.

Input voltage 8-34 Volt , E1 certificate, Current consumption < 5 mA, Cable connection 15 cm, Cable cross section 0.5 mm², Output current max. 5 A (2 x 2,500 mA), Output current duration 4.4 A (2 x 2,200 mA)

BP SP SU = 100 SU = 20 12-24 V 67324000 67324500

12

Triple Socket with 2 Power Sockets and 1 Power USB Socket

Two power sockets for cooling boxes or devices that are suitable to be operated by 12-24 volt. Power USB socket 12-24 V DC / 5 V DC, 3,000 mA with integrated power voltage converter. For charging and operating sat navs, mobile phones, smart phones, digital cameras, PAD’s and devices that are suitable for charging by 5 Volt USB. Fastening by two screws. Connection with universal plug fits in cigarette lighter and standard sockets, cable length 2 m.

Triple Socket with 2 Power Sockets and 1 Power Double USB Socket

Two power sockets for cooling boxes or devices that are suitable to be operated by 12-24 volt. Power Double USB socket 12-24 V DC / 5 V DC, 5,000 mA (2 x 2,500 mA) with integrated power voltage converter. For charging and operating sat navs, mobile phones, smart phones, digital cameras, PAD’s and devices that are suitable for charging by 5 Volt USB. Fastening by two screws. Connection with universal plug fits in cigarette lighter and standard sockets, cable length 2 m.

Input voltage 8-34 Volt, E1 certificate, Current consumption < 5 mA, Output current max. 3 A

BP SP SU = 50 SU = 20

12-24 V 67335000 67335500

Bendable Double USB Charging Plug

12-24 V DC / 5 V DC 5,000 mA (2 x 2,500 mA) for charging and operating mobile phones, sat navs, MP3 players, digital cameras, tablets and other devices that are suitable for charging by 5 V USB. Connection possible to all cigarette lighter sockets and DIN standard sockets at 12-24 V electric circuit of cars, caravans and boats. Input voltage 8-34 Volt, E1 certificate, Output current max. 5 A (2 x 2,500 mA), Output current duration 4,4 A (2 x 2,200 mA)

BP SP SU = 100 SU = 60 12-24 V 67302100 67302500

Input voltage 8-34 Volt, E1 certificate, Current consumption < 5 mA, Output current max. 5 A (2 x 2,500 mA), Output current duration 4,4 A (2 x 2,200 mA)

BP SP SU = 50 SU = 20 12-24 V 67325000 67325500

. . . mature technology for original equipment!

13

25 Years

INNOVATION EXPERTISE PARTNER

Charging Cable with Micro USB Plug

12-24 V, output 5 V, 2,000 mA. For charging and operating sat navs, mobile phones, smart phones, PDAs, digital cameras and devices that are suitable for charging by 5 V USB. With high-performance flyback converter and integrated protection against short-circuit, polarity reversal and overload. Fitting for cigarette lighter and standard socket by using an up to 180° bendable universal plug, cable length approx. 1.80 m.

BP SP SU = 100 SU = 60

12-24 V 67303000 67303100

Charging Cable with Micro USB Plug for Motorbikes

12-24 V / 5 V 2,000 mA. For charging and operating sat navs, mobile phones, smart phones, PDAs, digital cameras and devices that are suitable for charging by 5 V. With high-performance flyback converter and integrated protection against short-circuit, polarity reversal and overload.

BP SP SU = 100 SU = 60

12-24 V 68302550 68302650

Charging Cable with Mini USB Plug

12-24 V, output 5 V, 2,000 mA. For charging and operating sat navs, mobile phones, smart phones, PDAs, digital cameras and devices that are suitable for charging by 5 V USB. With high-performance ﬂyback converter and integrated protection against short-circuit, polarity reversal and overload. Fitting for cigarette lighter and standard socket by using an up to 180° bendable universal plug, cable length approx. 1.80 m.

BP SP SU = 100 SU = 60

12-24 V 67854800 67864800

Charging Cable with Mini USB Plug for Motorbikes

12-24 V / 5 V 2,000 mA. For charging and operating sat navs, mobile phones, smart phones, PDAs, digital cameras and devices that are suitable for charging by 5 V. With high-performance flyback converter and integrated protection against short-circuit, polarity reversal and overload.

BP SP SU = 100 SU = 60

12-24 V 68302500 68302600

USB Extension Cable

With 2 A safety universal plug, input voltage 12 V battery power, output voltage USB 5 V DC 1,000 mA. For charging and operating sat navs, mobile phones, smart phones and devices that are suitable for charging by 5 Volt USB.

BP SP SU = 100 SU = 60

12 V 68302050 68302150

BP = Bulk Packing SP = Single Packing SU = Sales Unit

USB Charger Connector 5 V with Protective Cover

Input voltage 12 V battery power / output voltage USB 5 V DC 1,000 mA. For charging and operating sat navs, mobile phones, smart phones and devices that are suitable for charging by 5 Volt USB.

BP SP SU = 100 SU = 60 12 V 68302010 68302110

14

Extension Cable

2 x 0.75 mm2 helix cable. Length 0.6 m to 3.0 m. With 8 A safety universal plug (integrated fuse) and socket connector, internal Ø 21 mm, 12-24 V.

BP SP SU = 100 SU = 20

8 A 67818100 67828100

Extension Cable

2 x 0.75 mm2 flat cable. Length 4.0 m. With 8 A safety universal plug (integrated fuse) and fracture-proof socket connector with contacts according to DIN EN ISO 4165, fitting for standard and universal plug.

BP SP SU = 100 SU = 20

8 A 67814000 67824000

Extension Cable

2 x 0.75 mm2 flat cable. With 8 A safety universal plug (integrated fuse) and socket connector, internal Ø 21 mm, 12-24 V.

BP SP SU = 100 SU = 20

8 A, cable length 4.0 m 67814100 67824100 8 A, cable length 1.8 m 67814110 67824110

Connector

8 A, internal Ø 21 mm, with 1.0 m feeder and crocodile clips.

BP SP SU = 150 SU = 60

8 A 67874000 67884000

Helix Cable

2 x 0.75 mm2 helix cable. Length 0.6 m to 3.0 m. With 8 A safety universal plug (integrated fuse) or universal plug. Standard version 8 A. Special versions on request.

BP SP SU = 100 SU = 20 with safety universal plug 8 A 67838000 67848000 with universal plug 8 A 67837000 67847000

Flat Cable

2 x 0.75 mm2 flat cable. Length 4.0 m. With 8 A safety universal plug (integrated fuse) or universal plug. Standard version 8 A. Special versions on request.

BP SP VSU = 100 SU = 60 with safety universal plug 8 A 67834000 67844000 with universal plug 8 A 67833000 67843000

15

25 Years

INNOVATION EXPERTISE PARTNER

Flat Cable

2 x 0.75 mm2 flat cable. Length 1.8 m. With socket connector, internal Ø 21 mm, 12-24 V, 8 A max.

BP SP SU = 150 SU = 20

8 A 67877000 67887000

Adaptor

With standard plug and socket connector, internal Ø 21 mm, 12-24 V, 8 A max., 2 x 0.75 mm2 flat cable, length 0.25 m.

BP SP SU = 200 SU = 60

8 A 67872000 67882000

Helix Cable

2 x 0.75 mm2 helix cable. Length 0.6 m to 3.0 m. With socket connector, internal Ø 21 mm, 12-24 V, 8 A max

BP SP SU = 100 SU = 20

8 A 67878000 67888000

Adaptor with Power Plug

With socket connector, internal Ø 12 mm, according to DIN EN ISO 4165, 12-24 V, 16 A max. Flat cable 2 x 1.5 mm2, length 0.25 m.

BP SP SU = 200 SU = 60 16 A 67801000 67801500

. . . manufacturing and trade!

BP = Bulk Packing SP = Single Packing SU = Sales Unit

Socket Connector

To install individual extensions for supplying power to electric accessories and lights, 16 A / 12-24 V max., with contacts according to DIN EN ISO 4165.

BP SP SU = 100 SU = 60 16 A 57620000 57620001

16

Twin Socket Connector

With two standard sockets to connect two electric accessories, flexible connection to the board system using the TÜV certified safety universal plug with interchangeable 16 A fuse, with contacts according to DIN EN ISO 4165.

BP SP SU = 50 SU = 20

16 A 67652000 67662000

Power Twin Socket Connector

With universal plug 16 A, permits connection in all cigarette lighters sockets and DIN standard sockets, 12-24 V, max. 16 A with two socket-connectors, internal Ø 21mm. Sturdy design.

BP SP SU = 60 SU = 20

16 A 67654000 67664000

Twin Socket Connector

Connection is possible in all sockets for cigarette lighters, two large sockets, internal Ø 21 mm, 12-24 V, 2 x 8 A max. Integrated interchangeable 16 A fuse. 2 x 0.75 mm2 ﬂat cable, length 0.25 m.

BP SP SU = 100 SU = 20

16 A 67879000 67889000

Appliance Cable 2 A

Safety universal plug 2 A assembled with cable 2 x 0.4 mm2, length 2 m and DC connector, angled.

BP SP SU = 200 SU = 60 DC connector 2.1 x 5.5 mm 67854900 67864900 DC connector 2.5 x 5.5 mm 67854910 67864910

Triple Socket Connector

3 x 5 A, 12-24 V, for operating 3 consumers at the same time with 12-24 Volt plugs in cars, mobile homes, trucks and boats. Three large socket connectors, internal Ø 21 mm, sturdy version, max. overall load 3 x 5 A. Fits standard and cigarette lighter sockets when used with red adapter.

BP SP SU = 100 SU = 20

3 x 5 A 67879050 67889050

Appliance Cable 8 A

Safety universal plug 8 A assembled with cable 2 x 0.75 mm2, length 2 m and DC connector, straight.

BP SP SU = 200 SU = 60 DC connector 2.1 x 5.5 mm 67854930 67864930 DC connector 2.5 x 5.5 mm 67854920 67864920

17

25 Years

INNOVATION EXPERTISE PARTNER

Battery Control

Protects the battery from excessive discharge caused by electrical appliances such as coolboxes, seat heatings, fans, etc. by automatic cut-out of the power supply. Renewed cut-in with the return of normal voltage conditions. Fitting for cigarette lighter and standard socket, with LED operational check and short circuit protection. 1.0 m feeder with connector, internal Ø 21 mm, bendable and therefore adjustable to various space conditions around the cigarette lighter.

rated voltage 12 V, operation current 8 A, cut-out voltage 11.5 +/- 0.2 V, cut-in voltage 12.6 +/- 0.2 V, natural current consumption ON/OFF 20/5 mA

BP SP

SU = 100 SU = 10

12 V / 8 A 67301000 67301100

Dimmer 12 Volt DC and 12/24 Volt DC

Automatic switching between 12 V and 24 V operation. Regulates from 1.5 W up to 140 W 12 V DC and up to 280 W in 24 V DC systems. The dimmer is equipped with a unique output limiter, which maximizes the output to the nominal value for 12 and 24 V lamps and with a constant lighting feature. Short-circuit proof and protected against overloading, overvoltage, overtemperature and faulty connection. Dimensions 60 x 60 x 35 mm, opening for installation Ø 46 mm.

SP

Volt Watt SU = 50

white 12 V 70 W 50021000 brown 12 V 70 W 50021010 black 12 V 70 W 50021020 white 12 / 24 V max. 140 / 280 W 50022000 brown 12 / 24 V max. 140 / 280 W 50022010 black 12 / 24 V max. 140 / 280 W 50022020

Further colors on request.

. . . electronics for your safety!

k.o.-Gasalarm 12-24 Volt

The protection against attacks with narcotic gases in mobile homes, cars and trucks.

Warning by loud signal, long before the gas effects.

• warns for narcotic gases

• with 1.8 m cable and bendable universal plug with switch for multiple use in 12 V sockets for cigarette lighter and standard built-in sockets

• audible and optical signal

• dimensions 130 x 75 x 40 mm

• wall mounting included

SP

SU = 50

12-24 V 52002005

BP = Bulk Packing SP = Single Packing SU = Sales Unit

Voltage Converter

24 V DC / 12 V DC, with 1.2 m connection cable. Allows the use of your 12 V cool box in your truck or boat. The voltage converter simply plugs in between the on-board outlet and any 12 V 60 W device - not just cool boxes. The Pro Car voltage converter is ideal for using portable navigation systems, CD players, television sets, electric mugs, etc. Output power plug, internal Ø 21 mm, 72 W (120 W short time), cool current switch mode design with 88% efficiency level, low quiescent current (< 30 mA), internal protection against over-load, voltage peaks and over-heating.

SP SU = 10 24 V 68305000

18

Reading Light „Pilot Light“

Ready for use without assembly. Light unit with slide switch, antiglare screen, integrated reflector, flexible arm moveable in all directions and safety universal plug. With integrated 8 A fuse to protect the board system, according to DIN EN ISO 4165. Connection to cigarette lighter and standard sockets without any problems.

BP SP SU = 100 SU = 60

12 V / 10 W 57406005 57406006

Supplementary Light „Backseat Light“

8 A, best as reading light in the passenger car’s backseat, ideal for boats and caravans as well. Easy assembly by use of the enclosed assembly kit. Light unit with slide switch, antiglare screen and integrated reﬂector. Flexible light arm moveable in all directions.

BP SP SU = 50 SU = 20

12 V / 10 W 57405002 57405003

Exampl e of u se

spot not included in delivery!

Superlux Halogen Hand and Reading Light

All-round light for cars, boats and caravans. 12 V / 10 W halogen incandescent lamp and computer calculated reflector, optimal antiglare light distribution by prismatic lens, helix cable 0.6 to 3.0 m, safety universal plug, 8 A.

BP SP SU = 50 SU = 20

12 V / 10 W 57415002 57415001

Ambiance LED round

8-30 V battery current / 1 W. Flat, all-purpose LED light. Easy installation with glue or screws. Can be used in cars, boats and mobile homes. When used at home, a 230 V power supply unit for LEDs can be connected. Measurements Ø 52 mm x 6 mm, light color warm-white, 3,200 K, housing plastic with silver coated frame.

BP SP VKE = 50 VKE = 20

1 W 57402000 57402500

Power LED illuminant

with G4 pin base on the side, 1.5 W. 12-24 V DC / 12 V AC, Ø 30 mm, Light-color warm-white 2,700 K. Keeps stable at voltage 9-28 V DC / 9-20 V AC.

BP SP SU = 100 SU = 60

12-24 V 57429010 57429060

Ambiance LED square

8-30 V battery current / 1 W. Flat, all-purpose LED light. Easy installation with glue or screws. Can be used in cars, boats and mobile homes. When used at home, a 230 V power supply unit for LEDs can be connected. Measurements 70 x 70 x 6 mm, light color warm-white, 3,200 K, housing plastic with silver coated frame.

BP SP VKE = 50 VKE = 20 1 W 57403000 57403500

19

25 Years

INNOVATION EXPERTISE PARTNER

Mini LED Spot

8-30 V battery current. The ballast is integrated in the lamp base. Can be pivoted and swivelled, high luminance, making it ideal as a reading and spotlight in mobile homes, trucks, boats. When used at home a 230 V power supply unit can be connected. Light color warm-white 2,700 K, housing alluminium-matt.

BP SP SU = 20 SU = 20

without swi tch-key, 2.5 W 57421010 57421510 with switch -key, 2.5 W 57421111 57421611 Power LED Spot, 6 W, without switch-key, dimmable 57421200 – Power LED Spot, 6 W, with switch-key, dimmable 57421220 –

. . . future LED technology

Surface Mounted / Built-In Power LED

8-30 V battery current / 3 W. All-purpose surface mounted / built-in LED light, with integrated ballast, pleasant warm white light colour, large radiation angle of 160°, extremely slim design, making it ideal for installation in/under cupboards and as an energy-saving light in mobile homes, trucks, boats. When used at home a 230 V power supply unit can be connected. Light color warm-white, housing alluminium-matt.

BP SP SU = 50 SU = 40 without switch-key 57423000 57423500 with switch-key 57423011 57423511

Surface mounting

Diameter 85 mm Height 10 mm Operating voltage 8-30 V Current consumption 0.25 A (at 12 V) Power consumption 3 W LED Power 2.5 W Color temperature 2,700 Kelvin Angle of reﬂected beam 150°

Ø 70 mm, 9 mm ﬂat

/ 70 mm, 9 mm ﬂat

Surface Mounted Power LED

8-30 V battery current / 3.6 W. Flat, all-purpose LED light with a large radiation angle of 160°, and an extremely slim design, making it ideal for installation in/under cupboards and as an energy-saving light in mobile homes, trucks, and boats. When used at home a 230 V power supply unit can be connected. Mounting via adhesive pads. Light color warm-white, 2,700 K, housing alluminium-matt.

BP SP

SU = 20 SU = 20

round 57425000 57425500

square 57426000 57426500

. . . saves up to 80% energy!

BP = Bulk Packing SP = Single Packing SU = Sales Unit

Surface Mounted Power LED Maxi

11-30 V battery current / 6 W. All-purpose surface mounted Power LED light. Its large angle of reflected beam and its high capacity makes it perfect for illuminating rooms. For use in cars, boats, and mobile homes. When used at home a 230 V power supply unit can be connected. Measurements diameter 120 mm, height 10.5 mm. Light color warm-white, housing alluminium-matt.

BP SP

VSU = 20 SU = 20 6 W 57424000 57424500

20

Resolve a tyre puncture easier, faster and more effectively and enables you to continue driving within 3 minutes. Upon pressing a button the sealant is pumped in the tyre and the minimum air pressure for continue driving is established.

Instead of conventional latex products, PREMIUM SEAL uses a completely newly developed microﬁbre substance which can be quickly and easily rinsed out. No more sticky tyres and rims.

• seals punctures up to 5 mm

• water pollution class 1 (biodegradable substance)

• DEKRA tested

Easy and fast application of PS REPA

Repair Set for Cars and Motorcycles

for car tyres with an air pressure up to 2.5 bar and a tyre size till 245 mm.

1 can of PS REPA SET 650 ml.

SP SU = 10 54002530

Repair Set for Transporters and Caravans

for an air pressure up to 4.8 bar and a tyre size till 205 mm. 1 can PS REPA SET 650 ml and 1 can fuel gas 500 ml.

SP SU = 10 54002550

Repair Set for Transporters and Caravans

for an air pressure up to 4.8 bar and a tyre size till 245 mm. 2 can PS REPA SET 650 ml.

SP SU = 10 54002540

21

25 Years

INNOVATION EXPERTISE PARTNER

Heating Fabric, 12 volt, 32 volt and 230 volt

For more than 15 years, heating fabric has been used in the original equipment and retrofitting of underfloor heating in camper vans, caravans, at home and in the workplace (office, workshop or market stall), where it has proven its worth.

The heating fabric, less than 1 mm thick, is flexible and ideally suited for heating surfaces, stone slabs, tiles, mirrors, carpets, laminate and almost all floorings, which are also designed for underfloor heating. The glass fibre fabric consists of heat-conducting carbon fibres, which generate pleasant heat within a few minutes.

Available by the metre or ready to connect, the surface heating system is available in diverse dimensions and in voltages of 12, 32 and 230 volt for industry, trade and trades and craft professions. We also offer appropriate transformers for the low-voltage versions.

The heated fabric is also used in our heating carpets and PVC mats.

Technical specifications

for standard versions, ready assembled with power cord:

Voltage Output Width Length up to max.

12 volt approx. 160 watt/m2 50 cm 150 cm 32 volt approx. 160 watt/m2 60 cm 400 cm 80 cm 320 cm 230 volt approx. 160 watt/m2 30, 50, 60, 75 cm –

Power cable assembly:

12 volt = approx. 2.0 m power cord, with universal plug 32 volt = approx. 2.5 m power cord, end open 230 volt = approx. 2.5 m power cord, with flat two-pin plug

Heating Fabric

Voltage Width Art. No.

12 volt 50 cm 20105000

32 volt 60 cm 22106000

32 volt 80 cm 22108000

230 volt 30 cm 25103000

230 volt 50 cm 25105000

230 volt 60 cm 25106000

230 volt 75 cm 25107500

Output approx. 160 watt / m2.

Please give required length to nearest 10 cm.

Heating fabric incl. power cord assembly.

Advantages and properties:

• Short heating up time

• Low power consumption

• Low cost purchase and operation (use)

• Flexible and easy to lay (ready to connect)

• Maintenance free

• Silent

• No raised dust

22

Heating Carpet, 12 volt and 230 volt

Just put down and enjoy the heat. The new version of these carpets convince 6 different colors. After a short starting-up time (approx. 10 min.), a pleasant by their two-sided design, one side carpet and the other side anti-slip material. foot temperature of up to approx. 30 °C develops. The high-quality heating carpets are available in four standard sizes and Special sizes available on request.

Size Art.-No.

12 Volt silver dark grey brown light brown blue grew/brown plaid

ca. 25 W 60 x 40 cm 20203500 20203501 20203521 20203520 20203512 20203530 ca. 50 W 60 x 70 cm 20206000 20206001 20206021 20206020 20206012 20206030 ca. 70 W 60 x 100 cm 20209000 20209001 20209021 20209020 20209012 20209030

230 Volt

ca. 25 W 60 x 40 cm 25203500 25203501 25203521 25203520 25203512 25203530 ca. 50 W 60 x 70 cm 25206000 25206001 25206021 25206020 25206012 25206030 ca. 70 W 60 x 100 cm 25209000 25209001 25209021 25209020 25209012 25209030 ca. 100 W 80 x 90 cm 25201100 25201101 25201121 25201120 25201112 25201130

Velour Heating Carpet, 12 volt and 230 volt

Just put down and enjoy the heat. The new version of these carpets convince by their two-sided design, one side carpet and the other side anti–slip material. The high-quality heating carpets are available in four standard sizes. After a short starting-up time (approx. 10 min.), a pleasant foot temperature of up to approx. 30 °C develops. Special sizes available on request.

Size Art.-No.

12 Volt light beige

ca. 25 W 60 x 40 cm 20203522 ca. 50 W 60 x 70 cm 20206022 ca. 70 W 60 x 100 cm 20209022

230 Volt

ca. 25 W 60 x 40 cm 25203522 ca. 50 W 60 x 70 cm 25206022 ca. 70 W 60 x 100 cm 25209022 ca. 100 W 80 x 90 cm 25201122

Bathroom Heating Carpet 12 volt and 230 volt

Pleasantly warm feet in the bathroom. The upper material consists of a super soft pile and an anti-slip material on the back. The heated bathroom carpets are available in 3 standard sizes and 2 colors. The heating fabric can be removed using a zip, enabling the carpet to be cleaned in the washing machine at up to 60 °C.

Size Art.-No.

12 Volt blue white

ca. 30 W 55 x 40 cm 20404012 20404001 ca. 50 W 55 x 65 cm 20407012 20407001 ca. 70 W 55 x 95 cm 20401012 20401001

230 Volt

ca. 30 W 55 x 40 cm 25404012 25404001 ca. 50 W 55 x 65 cm 25407012 25407001 ca. 70 W 55 x 95 cm 25401012 25401001

23

25 Years

INNOVATION EXPERTISE PARTNER

PVC Heating Mats, 12 volt and 230 volt

The robust PVC heating mats can be used on both sides and are available in 4 standard sizes and 3 colors. After a short starting-up time (approx. 10 min.), a pleasant foot temperature of up to approx. 30° develops. Special sizes available on request.

Size Art.-No.

12 volt cm blue grey bla ck

approx. 25 W 60 x 40 20213512 20213563 20213560 approx. 50 W 60 x 70 20216012 20216063 20216060 approx. 70 W 60 x 100 20219012 20219063 20219060

230 volt

approx. 25 W 60 x 40 25213512 25213563 25213560 approx. 50 W 60 x 70 25216012 25216063 25216060 approx. 70 W 60 x 100 25219012 25219063 25219060 approx. 100 W 80 x 90 25211112 25211163 25211160

Heatable Auto Carpet

12 V for the driver side left or passenger side right, incl. power cord assembly with 1 m cable for connecting to a cigarette lighter and standard socket through the 12 V electric circuit. This auto carpet can be used anywhere; it includes a auto carpet surface and a anti-slip bottom. After a short starting-up time (approx. 10 min.), a pleasant foot temperature of up to approx. 30 °C develops. Dimensions 54 x 40 cm, approx. 22 Watt

Art.-No. Driver side, left 20201011 Passenger side, right 20201010

Heating Auto Carpet 12 V suitable for Fiat Ducato 2014

incl. power cord assembly with 1.2 m cable for connecting to a cigarette lighter and standard socket trough the 12 V electric circuit. The top of the heating carpet is auto carpet and the bottom is anti-slip material. After a short starting-up time (approx. 10 min.), a pleasant foot temperature of up to approx. 30 °C develops.

Output approx. 80 watt, color dark grey

Art.-No. Fiat Ducato 2014 20201020

Heating Auto Carpet 12 V suitable for VW T5

incl. power cord assembly with 1.2 m cable for connecting to a cigarette lighter and standard socket trough the 12 V electric circuit. The top of the heating carpet is auto carpet and the bottom is anti-slip material. After a short starting-up time (approx. 10 min.), a pleasant foot temperature of up to approx. 30 °C develops.

Output approx. 65 watt, color dark grey

Art.-No. VW T5 20201021

24

After a short heating time pleasant heat spreads, especially in the seat and back areas particularly sensitive to cold, hence also protects against health problems. When camping, on the terrace or in the garden, even cooler evenings can be enjoyed for a long, pleasant period.

The heater is run with 12 volt and requires only approx. 60 watt. The heat, around 35 °C, is uniformly distributed by a non-woven with stitched on copper steel conductors, and therefore very robust. It is connected using the universal plug, which fits in 12 volt DIN and cigarette lighter sockets.

With a transformer (available in the accessories), the cushions can also be used with a 230 volt supply.

EisEx Heating Cable, 12 volt, 24 volt and 48 volt

Adapts itself to every water pipe bend and quickly thaws out even frozen pipes and outlet valves. Can be used in all pipes at risk from frost and for special solutions. Ideal for winter camping in caravans and camper vans. The heating cable is laid or wound around pipes. It can be directly connected to the vehicle's 12 volt electrical system.

Can also be used via 230 volt with a transformer.

Orders must be for twice the length of the pipe to be heated. Special lengths and outputs available on request.

Lengths longer than 1 m available in 10 cm steps.

Output approx. 7.5 watt per metre.

Volt Art.-No.

12 20500000 24 21500000 48 23500000

Heated Seat Cushion, 12 volt

The cushion covers are made of approx. 66% cotton and approx. 34% acrylic and are fitted with a zip for easy removal; washable at 30°.

12 volt, 5 A with approx. 2.0 m power cord with universal plug.

Colors blue and grey.

Other colors available on request.

Watt Size Art.-No.

bl ue grey

approx. 60 120 x 50 x 4 cm 20700210 20700264

25

25 Years

INNOVATION EXPERTISE PARTNER

12 Volt Transformers

For connecting 12 Volt devices, e.g., electric coolers, lighting, PRO CAR heating cushion, bathroom and heating carpets, and PVC heating mats.

Art.-No.

230 V/12 V~ 100 VA 20901001 230 V/12 V~ 200 VA 20902001

. . . accessories for bathroom and heating carpets, as well as other consumer.

Electric socket power supply 60 W

230 V AC input / 12 V DC 5A output with approx. 1.2 m cable and connector, internal Ø 21 mm. For connecting 12 Volt devices, e.g., electric coolers, lighting, PRO CAR heating cushion, bathroom and heating carpets, and PVC heating mats.

IV EV VKE = 50 VKE = 20

20900700 20900750

Euro Flat Plug

with integrated black ON/OFF rocker switch, 23 cm cable and Euro socket connector. For operating PRO CAR heating carpets and other 230 Volt devices.

IV EV VKE = 100 VKE = 60 20901010 20901011

26
