Pro Boat PRB3750 User Manual

Formula Fastech 26 Brushless EP Deep-V Boat

Owners Manual

Specifications

Hull Length ................................................................................26.75 in (679mm)

Beam ........................................................................................8.375 in (213mm)

Motor ............................... Water-cooled Hi-performance A3630-1500 Brushless Motor

Radio System............................................................Pro Boat AM 27MHz Pistol-grip

Drive System .......................................... Direct Drive with Adjustable Propeller Strut

Steering System ......................................... Off-set Rudder with Built-in Water Pickup

Speed Control .................................................. Water-cooled 45-Amp Brushless ESC

www.ProBoatModels.com

Introduction

Thank you for purchasing the Pro Boat®
Formula Fastech 26 Brushless EP Ready-To-Run
boat. Please read these instructions carefully
before attempting to operate your boat.

The Formula Fastech 26 Brushless EP comes
Ready-To-Run with the Pro Boat 27MHz AM
radio system and electronic speed controller
already installed. All assembly and building is
done at the factory, allowing you to quickly
get your boat running.

Table of Contents

Introduction ......................................................................................................... 2

Table of Contents .................................................................................................2

Inspection ...........................................................................................................2

General Guidelines ............................................................................................... 3

Additional Required Items ..................................................................................... 3

Contents .............................................................................................................4

Section 1: Assembling the Boat Stand .................................................................... 4

Section 2: Installing the Transmitter Batteries .......................................................... 4

Section 3: Installing the 7.2V Ni-MH Battery Packs ................................................... 5

Section 4: Adjusting the Transmitter ....................................................................... 6

Section 5: Checking the Radio System .................................................................... 6

Section 6: Testing Your Boat in the Water ................................................................ 8

Section 7: Handling Adjustment .............................................................................8

Section 8: Maintenance ......................................................................................... 9

Section 9: Speed Control Programming ................................................................... 9

Section 10: Lubricating the Drive Shaft ................................................................... 9

Section 11: Warranty Information......................................................................... 10

Section 12: Replacement Parts ............................................................................. 12

Inspection

Carefully remove the boat and radio
transmitter from the box. Inspect the boat
to make sure no damage is present. If you
notice damage is present, please contact the
hobby shop where you purchased it.

22

General Guidelines

It is important that you read and follow this
instruction manual, along with the radio
system manual before you run this exciting
boat. Failure to read and understand the
manual could result in personal injury,
property damage or permanent damage to
your boat. It is also important to run your
boat responsibly. With proper care and
maintenance, you will be able to proudly
enjoy your Formula Fastech 26 Brushless
Deep-V for many years to come.

When operating the boat, stay clear of
people, full-scale boats, stationary objects
and wildlife. It is preferable to operate the
Formula Fastech 26 Brushless Deep-V in low
wake, low wind conditions and in areas free
of people, wildlife and objects.

Before you operate your model, make sure
that your frequency is clear. If someone
is operating on the same frequency, both
models could go out of control, possibly
causing damage to the models or to others.
Check all of the hardware, and the propeller
for damage and loose screws before and after
each run.

If at any time while operating your model
you sense any abnormal function, end your
operation immediately. Do not operate your
boat again until you are certain the problem
has been corrected. Always stay clear of

the propeller.

Additional Required Items

You will need to purchase the following to get your boat on the water:

• 8 AA alkaline batteries for the radio transmitter

• 7.2V Ni-MH Battery Pack with Deans Connector (PRB3313 or PRB3314) (2)

• Twin Peak Dual Battery Charger (DYN4033)

• Tamiya/Deans adapter (PRB3312)

PRB3313

3600mAh

PRB3314

4200mAh

3

Contents

Section 1: Assembling the Boat Stand

Attach the side stand pieces by interlocking
them into the end pieces as shown. Secure
the interlocking pieces with medium CA or
epoxy. Make certain you allow the adhesive
to fully cure before placing your boat on
the stand.

• Assembled Formula Fastech 26
Brushless EP RTR

• Pro Boat radio transmitter

• Boat stand

Section 2: Installing the Transmitter Batteries

Install 8 AA alkaline batteries into the
transmitter, following the instructions
provided for your radio system.
